2 13/16"
(71 mm)
3 5/16"
(84 mm)
1 1/8"
(28 mm)
6" to 16"
(152 mm to 406mm)
Centers
4 5/8"
(118 mm)
3X1 1/8"~1 1/2"
(29~38 mm)
Hole Size
5 1/4"
(134 mm)
1 3/16"
(30 mm)
Max. Deck
Thickness
P3523LF▲
Min.2 1/2" (64 mm)
Clearance to Back
Splash Recommended
7 13/16"
(198mm)
4 5/8"
(117 mm)
BATHROOM FAUCET:
4 5/16
(110 mm)
4 1/8
(105 mm)
1/2" NPSM
■ Westchester™ Collection
■ Two Handle Widespread, Deck Mount
■ 3 Hole Sink Applications
■ 6" To 16" Widespread
STANDARD SPECIFICATIONS:
• Maximum 1.0 gpm @ 60 psi, 3.8 L/min @ 414 kPa.
• Widespread - 6" (152mm)to 16" (406mm) centers.
• 1/4 turn handle stops
2 1/8"
(54 mm)
Dia.
"
1 3/8"
(35 mm)
Dia.
"
1 5/8"
(41 mm)
to
2 3/8"
(60 mm)
1 1/4"
(32 mm)
Dia.
• 1/2"-14 NPSM adapters
• Ceramic cartridge
• Red/Blue indicator markings
• Model have drain with pop-up type fitting with
plated flange and stopper.
WARRANTY:
• Lifetime limited warranty on parts (other than electronic
parts and batteries) and inishes; or, for commercial
users, for 5 years from the date of purchase.
• 5 year limited warranty on electronic parts (other than
batteries); or for commercial users, for 1 year from the
date of purchase. No warranty is provided on batteries.
▲ Designate proper nish sufx
PSP-L-P3523LF Rev. A
COMPLIES WITH:
• ASME A112.18.1 / CSA B125.1
• ASME A112.18.2 / CSA B125.2
Indicates compliance to
ICC / ANSI A117.1
• EPA WaterSense
®
