7 15/16"
(202 mm)
Φ 7/8"
( 22 mm)
3 5/16"
(85 mm)
5 3/16"
(132 mm)
3 15/16"
(100 mm)
Min. 2 1/2" (64 mm)
Clearance to Back Splash
Recommended
P191102LF
Optional 6"
Escutcheon
BATHROOM FAUCET:
■ Single Handle Deck Mount
■ 1 or 3 Hole Sink Applications
▲
5 15/16"
(151 mm)
30"
(763 mm)
RP101775
50/50 Push Pop-Up
2 1/8"
(54 mm)
1 1/2"
(38 mm)
STANDARD SPECIFICATIONS:
• Maximum 1.0 gpm @ 60 psi, 3.8 L/min @ 414 kPa.
• Solid brass casted body.
• One or three hole mount (escutcheon optional, included).
• Ceramic cartridge
• Red/Blue indicator markings
• Polymer braided flexible supply hose with 3/8" compression
fitting - 30" (763mm) long
• Models have 50/50 push pop-up
1 1/4"~1 1/2"
(31~38 mm)
Hole Size
2 1/16"
(53 mm)
2 9/16"
(65 mm)
Max. Deck
Thickness
WARRANTY
• Parts and Finish - Lifetime limited warranty;
or for commercial purchasers, 10 years for multi-family
residential (apartments and condominiums) and 5 years
for all other commercial uses, in each case from the
date of purchase.
3/8" compression tting
p
2 1/8"
(54 mm)
1 1/2"
(38 mm)
1 3/8"
(35 mm)
to
2 5/16"
(59 mm)
8 11/16"
(220 mm)
RP101776
Metal Push Pop-Up
1 3/8"
(35 mm)
to
2 5/16"
(59 mm)
8 11/16"
(220 mm)
COMPLIES WITH:
• ASME A112.18.1 / CSA B125.1
• ASME A112.18.2 / CSA B125.2
Indicates compliance to
ICC / ANSI A117.1- Valve control only
• EPA WaterSense
®
1 1/4"
(32 mm)
▲ Designate proper finish suffix
PSP-L-P191102LF Rev. F
1 1/4"
(32 mm)
