Installation and Assembly: Wallmount for CP A100 and
Whiteboard
Model: A100IWBMOUNT
Maximum Load Capacity for Screen: 53 lb (24 kg)
Maximum Load Capacity for Projector : 13.5 lb (6 kg)
1 of 16
3215 W. North Ave. • Melrose Park, IL 60160 • (800) 865-2112 or (708) 865-8870 • Fax: (708) 865-2941 • www.peerlessmounts.com
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
NOTE: Read entire instruction sheet before you start installation and assembly .
WARNING
• Do not begin to install your Peerless product until you have read and understood the instructions and warnings
contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, please
call Peerless customer care at 1-800-865-21 12.
• This product should only be installed by someone of good mechanical aptitude, has experience with basic building
construction, and fully understands these instructions.
• Make sure that the supporting surface will safely support the combined load of the equipment and all attached hardware and components.
• Never exceed the Maximum Load Capacity . See page one.
• If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs. Use of an
"edge to edge" stud finder is highly recommended.
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• Tighten screws firmly , but do not overtighten. Overtightening can damage the items, greatly reducing their holding
power.
• Carriage box has over 100 lbs (43 kg) of pressure. Be careful not to pinch fingers.
• This product is intended for indoor use only . Use of this product outdoors could lead to product failure and personal
injury.
• This product was designed and intended to be mounted to the following supporting surfaces checked below with the
hardware included in this product as specified in the installation sheet. To mount this product to an alternative supporting surface, contact Peerless customer care at 1 800 865-21 12.
• This product was designed to be installed on the following wall construction only;
WALL CONSTRUCTION ADDITIONAL HARDWARE REQUIRED
x Wood Stud None
Wood Beam None
x Solid Concrete None
x Cinder Block None
x Metal Stud Do not attach except with Peerless accessory kit for metal studs;
Contact Customer Service for Peerless accessory kit for metal studs.
Brick Contact Customer Service
Other or unsure? Contact Customer Service
Tools Needed for Assembly
• stud finder ("edge to edge" stud finder is recommended)
• phillips screwdriver
• drill
• 1/4" bit for concrete and cinder block wall
• 1/2" bit for metal stud wall
• 5/32" bit for metal or wood stud wall
• level
2 of 16
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
Before you begin, make sure all parts shown are included with your product.
A
V
X
Y
A
Parts List
Description Qty. Part #
wall mount assembly 1 055-1841
B projector tube 1 055-1839
C projector arm 1 055-1830
D adapter plate 1 055-1828
E hook bracket 2 055-1840
F vertical handle 2 055-1834
G horizontal handle 1 055-1858
H projector adapter plate 1 055-1822
I slide plate 1 055-1821
J projector mount 1 PRG-1
K #10-32 x 0.375" phillips screw 18 520-1130
L M6 x 12 mm serrated washer head socket pin screw 8 510-1050
M 0.25"ID spacer 4 590-1050
N 1/4-20 x 1.0" hex head screw 2 520-1606
O #10-32 x 3/8" serrated washer head socket pin screw 2 520-1151
P 0.25" ID nylon washer 4 540-9460
Q #14 x 2.5" wood screw 6 5S1-015-C03
R acorn nut 2 530-1049
S plug 1 590-1303
T #10-32 x 1-3/8" socket pin screw 2 510-1098
U alligator anchor 6 590-0097
5/32" (4 mm) security allen wrench 1 560-9646
W #10-32 x 1/4" socket pin screw 2 520-1196
flanged bushing
retainer bushing
Z
cable tie
toggler pack 1
1 590-1271
1 055-1836
6 560-9711
CC615
A
CARRIAGE
C
B
D
Parts may appear slightly different than illustrated.
EF
G
M
LK
N
RST
H J
O
I
P
Q
3 of 16
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
Parts List Continued
X
UV
WX Y
Z
Make sure that wall mount assembly (A) is level, use it as a template to mark the top two mouting holes.
1
Alternatively , the top two screws can be fastened 16" apart as detailed in step 2 while making sure that they are
level. In order to set the desired height of bottom of screen in the lowest position, refer to dimension X from the chart
below.
PROJECTOR
TOP
MOUNTING
HOLES
SCREEN
CHART
Screen Si z e Dim ension X
63" 36"
77'' 42"
A
BOTTOM OF
SCREEN
FLOOR
4 of 16
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
Installation to Wood Stud Wall
WARNING
• Installer must verify that the supporting surface will safely support the combined load of the equipment and all attached
hardware and components.
• Tighten wood screws so that wall plate is firmly attached, but do not overtighten. Overtightening can damage the
screws, greatly reducing their holding power.
• Never tighten in excess of 80 in. • lb (9 N.M.).
• Make sure that mounting screws are anchored into the center of the stud. The use of an "edge to edge" stud finder is
highly recommended.
• Hardware provided is for attachment of mount through standard thickness drywall or plaster into wood studs. Installers
are responsible to provide hardware for other types of mounting situations.
Make sure that the mounting holes are on the stud centerline. Drill six 5/32" (4 mm) dia. holes 2-1/2" (65 mm) deep.
2
Fasten two #14 x 2.5" wood screws (Q) into top mounting holes leaving a .25" of exposed thread as shown. Hook
wall mount assembly (A) onto #14 x 2.5" wood screws (Q) as shown in fig. 2.1.
Fasten four #14 x 2.5" wood screws (Q) into wall mount assembly (A) as shown in fig. 2.2. Make sure that the wall
mount assembly (A) is level, tighten all six #14 x 2.5" wood screws (Q).
Skip to step 3.
CARRIAGE
Q
A
.25"
CARRIAGE
fig. 2.1
A
Q
fig. 2.2
5 of 16
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
Installation to Solid Concrete or Cinder Block
WARNING
• When installing Peerless wall mounts on cinder block, verify that you have a minimum of 1-3/8" of actual concrete
thickness in the hole to be used for the concrete anchors. Do not drill into mortar joints! Be sure to mount in a solid
part of the block, generally 1" minimum from the side of the block. Cinder block must meet ASTM C-90 specifications.
It is suggested that a standard electric drill on slow setting is used to drill the hole instead of a hammer drill to avoid
breaking out the back of the hole when entering a void or cavity .
• Concrete must be 2000 psi density minimum. Lighter density concrete may not hold concrete anchor .
• Make sure that the supporting surface will safely support the combined load of the equipment and all attached hardware and components.
Use wall mount assembly (A) as a template to mark
2
mouting holes. Drill six 5/32" (4 mm) dia. holes to a
minimum depth of 2.5" (65 mm). Insert six anchors (U) in
holes flush with wall as shown (right). Fasten two #14 x
2.5" wood screws (Q) into top anchors (U) leaving a .25" of
exposed thread for each screw (Q) as shown. Hook wall
mount assembly (A) onto #14 x 2.5" wood screws (Q) as
shown in fig. 2.3. Fasten four #14 x 2.5" wood screws (Q)
into wall mount assembly (A) as shown. Make sure that the
wall mount assembly (A) is level, tighten all six #14 x 2.5"
wood screws (Q).
1
Drill holes and insert anchors (U).
2
A
concrete
surface
U
Skip to step 3.
WARNING
• Tighten screws so that wall mount is firmly attached,
but do not overtighten. Overtightening can damage
screws, greatly reducing their holding power.
• Never tighten in excess of 80 in. • lb (9 N.M.).
WARNING
• Always attach concrete anchors directly to loadbearing concrete.
• Never attach concrete anchors to concrete covered
with plaster, drywall, or other finishing material. If
mounting to concrete surfaces covered with a finishing
surface is unavoidable, the finishing surface must be
counterbored as shown below. Be sure concrete
anchors do not pull away from concrete when tightening screws. If plaster/drywall is thicker than 5/8",
custom fasteners must be supplied by installer .
CORRECT
concrete
wall plate
INCORRECT
concrete
wall plate
Q
Place wall mount assembly (A) over anchors (U) and
secure with screws (Q).
3
Tighten all fasteners.
SOLID
CONCRETE
A
CARRIAGE
CINDER BLOCK
Q
U
.25"
plaster/
CUT AW A Y VIEW
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
dry wall
plaster/
dry wall
6 of 16
Q
fig. 2.3
U
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
Installation to Metal Stud Wall (Metal Stud Accessory Kit ACC 615 Required)
WARNING
• Drywall must be 1/2" or thicker, and met al stud must be 24 gauge or thicker .
• Installer must verify that the supporting surface will safely support the combined load of the equipment and all attached
hardware and components.
Drill six 1/2" holes through drywall and metal studs. NOTE: It may be necessary to drill 5/32" pilot holes prior to
2
drilling 1/2" holes.
Refer to instruction sheet included with Peerless accessory kit ACC 615 for metal studs to install togglers.
Fasten two 1/4-20 x 2-1/2" screws into top mounting holes leaving a .25" of exposed thread on each as shown in
fig. 2.4. Hook wall mount assembly (A) onto 1/4-20 x 2-1/2" screws.
Fasten four 1/4-20 x 2-1/2" screws into wall mount assembly (A) as shown in fig. 2.5. Make sure that the wall mount
assembly (A) is level, tighten all six 1/4-20 x 2-1/2" screws.
1/4-20 X 2-1/2" PHILLIPS SCREWS
CARRIAGE
A
.25"
A
TOGGLER
CARRIAGE
fig. 2.4
1/4-20 X 2-1/2" PHILLIPS SCREWS
fig. 2.5
7 of 16
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
K
Slide projector tube (B) into
3
assembly (A) and secure with two #10-32 x
0.375" phillips screws (K) as shown below.
NOTE: Use correct set of mounting holes for
the screen size as shown below.
63" SCREEN
B
top of wall mount
NOTE: Twist tube
into wall mount
assembly (A).
A
CARRIAGE
Fasten three #10-32 x 0.375" phillips
4
screws (K) to carriage leaving three
threads exposed. Attach retainer
bushing (Y) and flanged bushing (X) to
wall mount assembly (A) using two
#10-32 x 0.375" phillips screws (K).
K
THREE
THREADS
EXPOSED
DETAIL 1
Hook adapter plate (D) onto three
4- 1
#10-32 x 0.375" phillips screws (K).
K
Y
X
A
K
K
77" SCREEN
B
A
CARRIAGE
4- 2
D
K
Fasten three #10-32 x 0.375" phillips
screws (K) into adapter plate (D).
Securely tighten all six #10-32 x
0.375" phillips
D
K
8 of 16
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
Fasten two #10-32 x 0.375" phillips screws (K) into adapter plate (D) leaving three threads exposed as shown in
5
detail 1. Hook each vertical handle (F) onto #10-32 x 0.375" phillips screw (K) as shown in fig 5.1. NOTE: Use top
slot for 77" screen or second slot from top for 63" screen. Fasten #10-32 x 0.375" phillips screws (K) through lower
slot of vertical handle (F) that lines up with the lower hole in adapter plate (D). Hole location for 77" screen is shown
in fig. 5.2. Securely tighten all four #10-32 x 0.375" phillips screws (K).
K
DETAIL 1
K
THREE THREADS
EXPOSED
D
F
Fasten horizontal handle (G) to vertical handle (F) using four #10-32 x 0.375" phillips
6
screws (K) and two acorn nuts (R).
77" SCREEN
63" SCREEN
fig. 5.1
K
NOTE: 77" hole location
shown. 63" will use second
from bottom hole on vertical
handle (F).
D
F
fig. 5.2
F
K
CABLES ROUTING THROUGH THE TUBE
CAN BE PULLED T AUGHT AND FIXED IN
LINE TO THE HORIZONTAL HANDLE(G) BY
USING CABLE TIES (Z). USE OTHER CABLE
TIES AS NEEDED.
9 of 16
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
K
R
G
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
Insert hook brackets into screen as shown in detail 2 and fig. 7.1. Secure each hook bracket (E) with M6 x 12 mm
7
serrated washer head socket pin screw (L) as shown in fig. 7.2 and detail 3.
DETAIL 2
SCREEN
BRACKET
63" SCREEN
77" SCREEN
SCREEN
E
fig. 7.1
SCREEN
E
L
DETAIL 3
fig. 7.2
10 of 16
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
Hook brackets (E) into adapter plate (D) as shown in fig. 8.1 and
8
detail 4. The hooks will go over the flange on the top and the bottom of
hook bracket (E) into the slots as shown in detail 4 and detail 6. Fasten
#10-32 x 1-3/8" socket pin screws (T) on each hook bracket (E), using
security allen wrench (V) and tighten to wall plate as shown in
detail 5.
T o remove screen from mount, loosen safety/security screws and lift screen
off of mount.
E
HOOK
FLANGE
D
CAUTION
• Do not tighten screws with excessive force.
Overtightening can cause damage to mount. Tighten
screws to 40 in. • lb (4.5 N.M.) maximum torque.
DETAIL 6
fig 8.2
DETAIL 4
D
E
D
BOTTOM OF HOOK
BRACKET (E)
E
D
T
DETAIL 5
SIDE VIEW
fig 8.1
Disengage connection block from projector mount assembly (J) by unscrewing captive screw and sliding out
9
connection block as shown.
J
CAPTIVE
SCREW
11 of 16
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
CONNECTION
BLOCK
Arrow on projector mount assembly (J) indicates front of mount. The arrow of projector mount assembly (J) should
10
face towards the round tube on projector arm (C).
Fasten projector mount assembly (J) to projector arm (C) using two 1/4-20 x 1.0" hex head screws (N), four 0.25" ID
nylon washers (P) and slide plate (I) as shown in fig. 10.2 and 10.3. Do not tighten 1/4-20 x 1.0" hex head
screws (N) fully to allow for adjustment. Insert rectangle plug (S) into projector arm (C) as shown in fig. 10.2.
Position projector mount assembly (J) so that hole corresponding to your size screen in projector arm (C) is in the
center of projector mount assembly (J) as shown in fig. 10.1. Securely tighten both 1/4-20 x 1.0" hex head screws
(N). NOTE: This can be adjusted during final projector alignment if needed.
S
J
P
N
N
C
ROUND TUBE
fig. 10.2
ARROW INDICA TES
I
FRONT OF MOUNT
77" SCREEN
63" SCREEN
J
C
P
I
FRONT VIEW
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
C
fig. 10.3
12 of 16
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
Bottom View
fig. 10.1
Place projector arm (C) onto projector tube (B) as shown in fig. 11.1. Align projector arm (C) so that the holes in
11
projector tube (B) are in the middle of projector arm (C) slot. NOTE: This can be adjusted during final projector
alignment if needed. Fasten projector arm (C) to projector tube (B) using two #10-32 x 3/8" serrated washer head
socket pin screws (O) as shown in fig. 11.2 and detail 6.
C
B
fig. 11.1
B
DETAIL 6
C
O
fig. 11.2
13 of 16
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
Attaching Adapter Plate to Projector
Align shoulder on connection block opposite notch in
12
adapter plate (H). Attach adapter plate ( H) to
connection block from projector mount assembly (J)
using two #10-32 x 3/8" serrated washer head socket
pin screws (O).
NOTCH INDICATES
FRONT OF
PROJECTOR
CONNECTION
BLOCK
SHOULDER
H
O
Attach adapter plate (H) to projector using
13
four M6 x 12 mm serrated washer head
socket pin screws (L) and 0.25" spacers (M).
NOTE: Shoulder of connection block indicates the back of projector. The screws (L)
should be placed in the center of slots. This
can be adjusted during final projector
alignment if needed.
PROJECTOR
L
SHOULDER
H
CONNECTION
BLOCK
M
14 of 16
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
Attaching Adapter Plate to Projector Mount
WARNING
• Do not lift more weight than you can handle. Use additional man power or mechanical lifting equipment to safely handle
placement of the projector.
Slide connection block with projector into projector mount assembly (J) as shown. Tighten captive screw to secure
14
projector to projector mount assembly (J).
ARROW INDICA TES
FRONT OF MOUNT
J
FRONT OF
MOUNT
CONNECTION
BLOCK
CAPTIVE
SCREW
IMPORTANT: For security installations, insert one #10-32 x 1/4" socket pin screw (W) through projector mount
15
assembly (J) and into connection block as shown. Tighten screw using 4mm security allen wrench (V).
J
W
CONNECTION
BLOCK
15 of 16
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
Projector Alignment
T o adjust yaw (swivel): Loosen screw on projector mount assembly (J) indicated below until projector mount
16
can be rotated. Rotate mount to desired position and retighten screw .
T o adjust pitch (forward and backward tilt): T urn knob on back of mount as shown below. Pull knob out and
turn by hand for easy adjustment or insert #2 phillips screwdriver in end of knob and turn.
T o adjust roll (side to side tilt): T urn knob on side of mount as shown below . Pull knob out and turn by hand
for easy adjustment or insert #2 phillips screwdriver in end of knob and turn.
ARROW INDICA TES
FRONT OF MOUNT
SCREW FOR YAW
(SWIVEL) STOP
J
KNOB FOR PITCH
ADJUSTMENT
BACK OF MOUNT
KNOB FOR ROLL
16- 1
ADJUSTMENT
To prevent tampering with the pitch and roll adjustments: Tighten the two tamper resistant security screws
on the projector mount assembly (J) using 4 mm security allen wrench (V) to lock the pitch and roll adjustments
fig. 16.1
as shown below.
NOTE: Tighten screws firmly, but do not overtighten. Overtightening can damage the mount.
CAUTION
• Do not adjust pitch or roll while tamper resistant security screws are fully engaged.
• Loosen the two tamper resistant security screws one complete turn before adjusting the projector mount assembly or
damage may occur.
TO LOCK ROLL TIGHTEN
TAMPER RESISTANT
SECURITY SCREW
TO LOCK PITCH TIGHTEN
TAMPER RESISTANT
SECURITY SCREW
FRONT VIEW
16 of 16
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
All other brand and product names are trademarks or registered trademarks of their respective owners.
SIDE VIEW
ISSUED: 04-08-08 SHEET #: 055-9094-2 06-06-08
© 2008, Peerless Industries, Inc. All rights reserved.
Loading...
