Peco Pro2B+ 23120910, Pro2B+ 23120911 Operator's Manual

Download

PECO

PECOPECO

PPP

MODEL# 23120910

PTO GRASS

COLLECTION

SYSTEM

CRZ, XRZ & XRZ Pro

2013-Newer

MODEL# 23120911

FastCat RZ

2015-Newer

OPERATOR’S MANUAL

ASSEMBLY OPERATION MAINTENANCE

MANUAL PART#: Q0472 REV: 3.0 (June 2017)

RESIDENTIAL BAGGING SYSTEM

TABLE OF CONTENTS

SECTION PAGE

Safety - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 Safety Alert Symbols- - - - - - - - - - - - - - - - - - - - - - 3 Warranty - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4

I INTRODUCTION AND DESCRIPTION - - - - - - - - - - - - 5 1-1 Introduction - - - - - - - - - - - - - - - - - - - - - - - - - 5 1-2 Description - - - - - - - - - - - - - - - - - - - - - - - - - 5

II INSTALLATION FOR USE - - - - - - - - - - - - - - - - - - - - - 5 2-1 Preparation Of Mower - - - - - - - - - - - - - - - - - - 5 2-2 Left & Right Frame Bracket Installation - - - - - - - 6 2-3 Rear & Lower Frame Bracket Installation - - - - - - 7 2-4 PTO Mount Plate Component Installation- - - - - - 8 2-5 PTO Assembly Installation - - - - - - - - - - - - - - - 9 2-6 Belt Installation and Adjustment & Belt Guard Installation - - - - - - - - - - - - - - - - - - 9-10 2-7 Blower Cone Installation - - - - - - - - - - - - - - - - - 11 2-8 Impeller Blade Removal/Replacement - - - - - - - - 11 2-9 Lower Mount Tube Installation - - - - - - - - - - - - - 12 2-10 Upper Frame Assembly Installation - - - - - - - - 12 2-11 Top Assembly Installation and Inlet Installation- - 13 2-12 Hinge Kit Assembly Installation- - - - - - - - - - - - 13 2-13 Boot To Mower Deck Installation- - - - - - - - - - - 14

SAFETY

SECTION PAGE

2-14 Weight Kit Assembly Installation - - - - - - - - - 15-16 2-15 Length of Hose Adjustment - - - - - - - - - - - - - - 17 2-16 Upper Hose Installation - - - - - - - - - - - - - - - - 17 2-17 Lower Hose To Blower Cone Installation- - - - - - 17 2-18 Lower Hose To Boot Installation - - - - - - - - - - - 17 2-19 Bag Assembly- - - - - - - - - - - - - - - - - - - - - - - 18 2-20 Bag Assembly Installation - - - - - - - - - - - - - - - 18

III OPERATING INSTRUCTIONS - - - - - - - - - - - - - - - - - - 19 3-1 General Safety - - - - - - - - - - - - - - - - - - - - - - - 19 3-2 Operation & Tips On Mowing - - - - - - - - - - - - - - 19 3-3 Disengagement Of The PTO Assembly - - - - - - - 19 3-4 Unloading The Collection System - - - - - - - - - - - 19 IV MAINTENANCE - - - - - - - - - - - - - - - - - - - - - - - - - 19-20 4-1 Maintenance Checklist - - - - - - - - - - - - - - - - 19-20 4-2 Lubrication- - - - - - - - - - - - - - - - - - - - - - - - - - 20 V PARTS AND SERVICE - - - - - - - - - - - - - - - - - - - - - - 20 5-1 Parts And Service Information - - - - - - - - - - - - - 20 Exploded Views And Parts List - - - - - - - - - - - - - 21-25 Safety Decals - - - - - - - - - - - - - - - - - - - - - - - - - - 26 Torque Specifications - - - - - - - - - - - - - - - - - - - - - 27 Troubleshooting - - - - - - - - - - - - - - - - - - - - - - - - - 28 Notes- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 29

1. Read the operator’s manual carefully and familiarize yourself with the proper use of your attachment. Do not allow

anyone who is not acquainted with the Safety Instructions to use your attachment.

2. Know the controls and how to stop them quickly. READ THE OPERATOR’S MANUAL!

3. Do not allow children to operate the machine. Do not allow adults to operate it without proper instruction.

4. Be especially watchful of children and pets entering into the area while operating.

5. Keep your eyes and mind on your machine while mowing or operating your attachment. Don’t let others distract

you.

6. Do not attempt to operate your machine when not in the driver’s seat.

7. Always shut off blades and engine when emptying the container.

8. Stop machine, shut off deck attachment, set parking brake, shut off engine and remove ignition key before

removing clogs, removing or replacing hose, boot, blower cone, or performing any maintenance.

9. Mow across the face of slopes (not more than 10 degrees); never up and down the face.

10. It is recommended that the container be emptied when half full while operating on slopes. Start mowing on slopes

when the container is empty.

11. Inspect your lawn and remove any foreign objects before mowing. Never deliberately run the mower across any foreign object.

12. Wear hearing protection.

13. Wear eye protection to prevent debris from getting into your eyes.

2017 (v1.0)

SAFETY

WARNING! NEVER operate the mower unless the discharge guard and either the deflector assembly or

the vacuum collector adapter are fastened securely in place.

WARNING! Do not work around the mower deck boot or the blower area until you are certain that the mower

blades and the blower impeller have stopped rotating.

WARNING! To avoid serious injury, perform maintenance on the vacuum collector; ONLY AFTER

STOPPING THE MOWER’S ENGINE AND WAITING FOR ALL MOVING PARTS TO COME TO A COMPLETE STOP. Set the parking brake. Always remove the ignition key before beginning maintenance.

WARNING! For your own personal safety, ALWAYS mow ACROSS the face of slopes and

NEVER UP and DOWN the face. NEVER attempt to mow excessively steep slopes, and use

caution when turning on any slope.

Safety Alert Symbol

This Safety Alert Symbol means: “ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!”

This symbol is used to call attention to safety precautions that

Should be followed by the operator to avoid accidents. When you see this symbol, carefully read the message that follows and heed its advice. Failure to comply with safety precautions could result in death or serious bodily injury.

Safety Signs

The signal words DANGER, WARNING, and CAUTION are used on the equipment safety signs. These words are intended to alert the viewer to the existence and the degree of hazard seriousness.

This signal word indicates a potentially hazardous situation which, if not

DANGER

White letters on RED

WARNING

Black letters on ORANGE

avoided, will result in death or serious injury.

This signal word indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

It may also be used to alert against unsafe practices.

CAUTION

Black letters on YELLOW

This signal word indicates a potentially hazardous situation which, if not avoided, will result in minor or moderate injury.

It may also be used to alert against unsafe practices.

2017 (v1.0)

PECO LIMITED WARRANTY FOR NEW PRODUCTS

A. WHAT IS UNDER WARRANTY?

PECO extends the following warranties to the original purchaser of each new PECO consumer product subject to the following limitations.

1. PRODUCT WARRANTY: Any part of any consumer product, which is defective in material or workmanship as delivered to the purchaser will be repaired or replaced, as PECO elects, without charge for parts or labor, if the defect appears within 12 months from the date of delivery of the product to the original purchaser. ALL DEFECTIVE PARTS MUST BE RETURNED TO PECO FOR INSPECTION TO DETERMINE VALIDITY OF WARRANTY CLAIMS. Freight and mailing will be borne by the customer.

2. PARTS REPLACED DURING WARRANTY: Any new PECO part which is furnished in performance of this warranty and is defective in material or workmanship as delivered to the purchaser will be repaired or replaced, before the expiration of the original warranty period, whichever is later.

3. COMMERCIAL USE: Products put to personal use around a single household or residence is considered 'Residential'; Products put to any business use (agricultural, commercial, or industrial) or used at multiple locations is considered 'Commercial.' Products designated as 'Commercial' are warrantied for 12 months from the date of delivery of the product to the original purchaser when used for in commercial applications. Products designated as 'Residential' are warrantied for 90 days from the date of delivery of the product to the original purchaser when in commercial applications.

B. SECURING WARRANTY ADJUSTMENTS

Call PECO for Return Authorization. Damaged or broken parts other than engines or batteries, must be returned to New PECO, Inc. at 10 Walden Drive, Arden, NC 28704 before any warranty adjustment can be authorized. At the time of requesting warranty adjustment, the purchaser must present evidence of the date of delivery of the product. The purchaser shall pay any charge for the product to and from Arden, NC.

C. ITEMS NOT COVERED BY PECO WARRANTY

Engines and batteries attached to PECO products are covered under a separate warranty by the respective manufacturer.

D. UNAPPROVED ALTERATION OR MODIFICATION

All obligations of New PECO, Inc. under this warranty shall be terminated if products are altered or modified in ways not approved by New PECO, Inc.

E. ACCIDENTS AND NORMAL MAINTENANCE

The warranty covers only defective material and workmanship. It does not cover depreciation or damage caused by normal wear, accident, improper use or abuse of products. The cost of normal maintenance and normal replacement of service items such as belts, cutting blades, hoses, etc., which are not defective shall be paid for by the purchaser.

F. NO REPRESENTATIONS ADDITIONAL WARRANTIES, DISCLAIMER

Neither New PECO, Inc. nor any company affiliated with it makes any warranties, representations or promises as to the quality of performance of its products other than those set forth herein. Except as described above, New PECO, Inc. makes no other warranties AND SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES OF FITNESS AND MERCHANTABILITY.

G. PRODUCTS USED FOR RENTAL OR LEASE PURPOSES ARE WARRANTIED FOR 45 DAYS

FROM DATE OF ORIGINAL SALE ONLY

H. REMEDIED EXCLUSIVE

The only remedies the purchaser has in connection with the breach or performance of any warranty on New PECO, Inc. consumer products are set forth above. In no event will PECO be liable for special incidental or consequential damages.

1. NO SERVICE CENTER WARRANTY The selling Service Center makes no warranty on his own on any item warranted by New PECO, Inc. unless he delivers to purchaser a separate written warranty certificate specifically warranting the item. The dealer has no authority to make any representation or promise on behalf of PECO or to modify the terms of this warranty in any way.

2017 (v1.0)

Section I

PRESS

INTRODUCTION & DESCRIPTION

1-1 Introduction

Your grass collection system has been designed to give you a low maintenance, simple, and effective way to collect the grass clippings from your mower. This manual is provided to give you the necessary instructions to properly mount and operate the collection system on your mower. Please read this manual thoroughly. Understand what each control is for and how to use it. Observe all safety decal precautions on the machine and noted throughout the manual. NOTE: All references made to right, left, front, rear, top or bottom are as viewed from the normal operator’s position on the mower.

1-2 Description

The grass collection system is designed for turf maintenance where there is a need to collect the grass clippings as the mower cuts the turf. It is also used for picking up leaves in pre-season and post-season cleanup. The blower, mounted on the right side of the unit, uses a belt and gearbox system from the engine PTO shaft. Drive train protection comes through belt slippage. The blower draws grass clippings from the discharge area of the cutting deck back to the collection bags at the rear portion of the mower frame. The operator can engage the blower with a spring-lock engagement handle on the right side of the unit. Once the bags are full with clippings, they can be easily released for dumping.

Remove the D-drive spacer using an arbor press or equivalent. On removal, adjacent bearing OUTER race must be supported or bearing damage may occur. Refer to Figure 2-1b.

Figure 2-1b

The engine pulley assembly must be installed using an arbor press or equivalent. Upon Installation, opposite bearing inner race must be supported or bearing damage may occur. Refer to Figure 2-1c.

Figure 2-1c

Section II

INSTALLATION FOR USE

2-1 Preparation Of Mower

From the underside of the engine, disconnect the wiring harness attached to the electric clutch. Remove the bolt and electric clutch from the mower. Refer to Figure 2-1a.

Figure 2-1a

Remove Bolt

Engine Bushing

Engine Pulley Installation

Use engine pulley assembly #2 P#(A0419). Fasten the engine pulley to the electric clutch assembly using (1) 7/16” hi-collar lock washer P#( ) and (1) 7/16”-20 x K0140 4” HHCS P#(K0359) as shown in Figure 2-1d. The added pulley will power the collection system. Torque the bolt to 55 ft./lbs. Re-connect the wiring harness to the electric clutch.

Figure 2-1d

Engine Pulley

Number Is

Stamped On

The Pulley

Bushing Here

Electric Clutch

Engine Pulley

Assembly

Hex Bolt

Lock Washer

2-2 Left and Right Frame Bracket Installation

Remove the rear bumper and hardware from the mower. Refer to Figure 2-2a.

Figure 2-2a

Secure the left frame bracket P#(B0837) to the mower rear frame using (3) 3/8”-16 x 1” HHCS P#(K1191) and (3) 3/8”-16 nylon flange locknut P#(K2038). Leave the hardware slightly loose until all the frame components are installed. Refer to Figure 2-2b.

Secure the right frame bracket P#(B0836) to the mower rear frame using (3) 3/8”-16 x 1” HHCS P#(K1191) and (3) 3/8”-16 nylon flange locknut P#(K2038). Leave the hardware slightly loose until all the frame components are installed. Refer to Figure 2-2b.

Figure 2-2b

(3) 3/8”-16 x 1”

Hex Bolts

(3) 3/8”-16

Locknuts

Left Frame

Bracket

Mower Rear

(3) 3/8”-16

Locknuts

Frame

Right Frame

Bracket

(3) 3/8”-16 x 1”

Hex Bolts

2-3 Rear Frame Bracket and Lower Frame Bracket Installation

Secure the rear frame bracket P#(B0855) to the inside of the left and right frame bracket using (2) 3/8”-16 x 1” HHCS P#(K1191) and (2) 3/8”-16 nylon flange locknuts P#(K2038). Use the top mounting holes. Leave the hardware slightly loose until all the frame components have been installed. Refer to Figure 2-3.

Figure 2-3

(1) 3/8”-16 x 1”

Hex Bolt

(Rear Frame Bracket)

(2) 3/8”-16 x 1”

Hex Bolt

(Lower Frame Bracket)

Secure the lower frame bracket P#(B0838) to the inside of the left, right and rear frame bracket using (4) 3/8”-16 x 1” HHCS P#(K1191) and (4) 3/8”-16 nylon flange locknuts P#(K2038). Refer to Figure 2-3.

NOTE: Tighten all frame component hardware at this time.

(2) 3/8”-16 Locknuts

(Rear Frame Bracket)

(1) 3/8”-16 x 1”

Hex Bolt

(Rear Frame Bracket)

Rear Frame

Bracket

(2) 3/8”-16 x 1”

Hex Bolt

(Lower Frame Bracket)

(4) 3/8”-16 Locknuts

(Lower Frame Bracket)

Lower Frame

Bracket

2-4 PTO Mount Plate Component Installation

Fasten the left PTO mount plate P#(B0748) the right frame bracket using (2) 3/8”-16 x 1” HHCS P#(K1191) and (2) 3/8”-16 nylon flange locknuts P#(K2038). Do not tighten the hardware. Fasten the right PTO mount plate P#(B0747) to the right frame bracket using (2) 3/8”-16 x 1” HHCS P#(K1191) and (2) 3/8”-16 nylon flange locknuts P#(K2038). Do not tighten the hardware. Refer to Figure 2-4a.

(4) 3/8”-16

Locknuts

Right Frame

Bracket

Insert the PTO stop plate P#(B0733) between the left and right PTO mount plates as shown in Figure 2-4b. Secure the PTO stop plate to the left and right PTO mount plates using (4) 1/4”-20 x 3/4” HHCS P#(K1222) and (4) 1/4”-20 nylon flange locknuts P#(K2014).

NOTE: Tighten all PTO mount plate component hardware at this time.

Figure 2-4a

Right PTO

Mount Plate

(2) 3/8”-16 x 1”

Hexbolts

Left PTO

Mount Plate

(2) 1/4”-20 x 3/4”

Hexbolts

PTO Stop

Plate

Figure 2-4b

Left PTO

Mount Plate

Right PTO

Mount Plate

(4) 1/4”-20

Locknuts

(2) 1/4”-20 x 3/4”

Hexbolts

(2) 3/8”-16 x 1”

Hexbolts

2-5 PTO Assembly Installation

Insert the PTO assembly P#(A1840) into the mounting slots on the PTO mount plates, as shown in Figure 2-5. Secure the PTO assembly with (1) PTO mount pin P#(B0274) and (1) hair pin clip P#(K0086). Remove the gear box pulley guard and hardware from the PTO assembly in preparation for the belt installation.

Loosen the (2) 5/16”-18 x 3/4” HHCS P#(K1153) that secure the gear box to the PTO assembly, as shown in Figure 2-6b. Loosen the adjustment bolt (1) 3/8”-16 x 2” hex bolt P#(K0348).

Figure 2-6b

Figure 2-5

PTO

Mount Pin

and Hardware

PTO

Assembly

Remove

Pulley Guard

2-6 Belt Installation and Adjustment and Pulley Guard Installation

Loosen

Hardware

Adjustment

Bolt

Slide the gearbox towards the mower until there is enough clearance for the kevlar belt to slide over both the engine and gearbox pulleys. Install the A54K kevlar belt P#(M0255). Insert the PTO mount pin P#(B0274), and secure the pin with (1) hair pin clip P#(K0086). Refer to Figure 2-6c.

Figure 2-6c

Installation/Removal: With the pulley guard, PTO mount pin and hair pin clip removed, loosen the (2) 5/16”-18 x 3/4” HHCS P#(K1153) that secure the gear box to the PTO assembly. Refer to Figure 2-6a.

Figure 2-6a

Loosen

Hardware

Wrap Belt Around

Both Pulleys

Adjustment: To adjust the belt tension, turn the adjustment bolt clockwise until there is 1” of deflection, with 10-11lbs of pressure applied to the center of the belt. When the belt has the proper tension, tighten the (4) 5/16”-18 x 3/4” HHCS that secure the gear box to the

PTO assembly. Replace the pulley guard and hardware.

2-6 Belt Installation and Adjustment and Pulley Guard Installation Continued...

Secure the top belt guard P#(B0862) tot he right frame bracket using (1) 3/8”-16 x 1” HHCS P#(K1191) and (1) 3/8”-16 nylon flange locknut P#(K2038) from the mount kit hardware bag, as well as (1) 3/8”-16 x 1” HHCS P#(K1191) and (1) 3/8”-16 nylon flange locknut P#(K2038) used in securing the lower frame bracket to the right frame bracket. Refer to Figure 2-6d.

Replace the belt guard and hardware removed from Section 2-5. Refer to Figure 2-6e.

Figure 2-6d

(1) 3/8”-16 x 1”

Hex Bolt

(1) 3/8”-16 Locknut

Lower Frame

Bracket Hardware

Figure 2-6e

Top Belt

Guard

Replace Belt

Guard & Hardware

2-7 Blower Cone Installation

Fasten the blower cone P#(V0016) to the blower housing located on the PTO assembly. Use (3) 1/4”-20 x 3/4”HHCS P#(K1222), (3) 1/4” lock washers P#(K0039), and (3) 1/4” flat washers P#(K0037) to secure the blower cone to the blower housing. Refer to Figure 2-7 for reference.

Figure 2-7

1/4”-20 x 3/4”

HHCS

Blower

Housing

2-8 Impeller Blade Removal/Replacement

To Remove: To access the impeller blade, remove the blower cone P#(V0016) and blower cone hardware from the blower housing. Remove the 5/16”-24 x 7/8” left hand thread hex bolt P#(K1171) and washer P#(K1446). Insert (1) 1/2”-13 x 1” hex bolt into the threads on the impeller blade. Tighten the hex bolt until the impeller blade breaks free from the PTO shaft. Remove the impeller blade assembly P#(A1839) from the PTO shaft. Remove the key P#(J0254) from the PTO shaft.

To Replace: Insert the key P#(J0254) into the keyway slot on the PTO shaft. Align the keyway slot on the bushing of the impeller blade assembly with the key on the PTO shaft and insert the impeller blade onto the PTO shaft. Secure the impeller blade with (1) 5/16”-24 x 7/8” left hand thread hex bolt P#(K1171) and (1) washer P#(K1446). Replace the blower cone P#(V0016) and blower cone hardware. Refer to Figure 2-8 for reference.

1/4” Lock

Washer

1/4” Flat

Washer

A1839

Impeller Blade

Assembly

Blower

Cone

Figure 2-8

J0254

Key

K1446

K1171

PTO Shaft

V0016

Cross Section View of

Blower Housing

2-9 Lower Mount Tube Installation

Position the lower mount tubes P#(B0752) on top of the two tabs on the rear frame bracket. Secure each lower mount tube using (2) 5/16”-18 x 2-1/4” u-bolts P#(K1098)

and (4) 5/16”-18 nylon flange locknuts P#(K2516) PER TUBE. Refer to Figure 2-9.

Lower Mount

Tubes

(2) 5/16”-18

U-Bolts

(PER TUBE)

(4) 5/16”-18

Locknuts

(PER TUBE)

Figure 2-9

Rear Frame

Bracket Tabs

2-10 Upper Frame Assembly Installation

Position the upper frame assembly P#(A2047) as shown in Figure 2-10 and lower the assembly onto the lower mount tubes. Secure the upper frame assembly with (2) clevis pins P#(K0133) and (2) hair pin clips P#(K0088).

Figure 2-10

Upper Frame

Assembly

Clevis

Hair Pin

Clip

2-11 Top Assembly To Upper Frame Assembly Installation & Inlet Installation

Position the top assembly P#(A2101) above the upper frame assembly as shown in Figure 2-11. Fasten the top assembly to the upper frame assembly using (2) 5/16”18 x 2-1/2” HHCS P#(K0125) and (2) 5/16”-18 nylon flange locknuts P#(K2516). Leave the locknuts slightly loose, to allow the top assembly to open and close easily. Refer to Figure 2-11 for hardware location.

Insert the Inlet P#(V0025) into the hole on the top assembly from the inside and then snap the inlet into place. The inlet should pivot freely about the hole.

2-12 Hinge Kit Assembly Installation

Assemble the hinge kit as shown in Figure 2-12, using (2) 5/16”-18 x 1” HHCS P#(K1154), (3) 5/16”-18 nylon flange locknuts P#(K2516), (5) 1/4” flat washers P#(K0037) and (2) swing arm brackets P#(ZT-0004). Place (1) vinyl cap P#(J0289) on the end of the hex bolts as shown in Figure 2-12. Leave the nuts loose enough to allow fluid movement of the top when opening and closing. When opened, the top should rest on the middle joint of the hinge allowing it to remain up.

Figure 2-12

K1154

K2516

K0037

J0289

ZT-0004

Figure 2-11

Inlet

Hex Bolt

Top Assembly

Nylon

Flange

Locknut

(2) 5/16”-18 x 2-1/2” HHCS

(2) 5/16”-18 Nylon

Flange Locknut

2-13 Boot To Mower Deck Installation

Secure the boot plate P#(B0807) to the top surface of the plastic boot P#(V1173) using (3) 5/16”-18 x 3/4” carriage bolts P#(K1142) and (3) 5/16”-18 nylon flange locknuts. Insert the carriage bolts from the inside so that the threads and locknuts are on the top of the boot plate. This will prevent grass clippings from collecting on the bolt threads. Secure the boot plate to the mower deck by inserting (1) boot rod P#(B0288) through the holes in the grass deflector mounting brackets. Insert (1) hair pin clip into the boot rod as shown in Figure 2-13.

Figure 2-13

Plastic

Boot

Hair Pin

Clip

Insert Boot

Rod

Boot

Plate

3) 5/16”-18 x 3/4” Carriage Bolts

(3) 5/16”-18 Locknuts

2-14 Weight Kit Installation /

Item # Part # Desc. Qty.

1 Y0025 28 lb. Suitcase Weight 1 2 B1021 Single Weight Bracket / Left Caster / Base 1 3 B1015 Weight Bracket / Clam p 1 4 HB0686 Single Weight Kit Hardware Bag 1

4.1 K1472 HHCS 5/16"-18 x 3" GR5 4

4.2 K2516 Ny-Flange Lock Nut 5/16"-18 4

4.3 K1473 Clevis Pin 1/2" x 3" 1

4.4 K1478 Hair Pin Cotter / Double Loop 1

4.4

4.1

4.3

4.2

Left Caster

To Install Weight Bracket

Step 1 - Position (#2) Base Under Caster Tubing w/ Opening Towards Caster Fork.

Step 2 - Position (#3) Clamp On Top Of Caster Tubing w/ Opening Towards Caster Fork.

Step 3 - Align (4) Holes In (#3) Clamp To Holes In (#2) Base

Step 4 - Loosely Fasten (#3) Clamp To (#2) Base Using (4) (#4.1) 5/16"-18 x 3" Bolts & (4) (#4.2) 5/16"-18 NyFlange Lock Nuts.

Step 5 - Position (#2 & #3) Assembly Along Caster Tubing To Prevent Interference From Caster Forks Or Any Other Objects. Tighten Fasteners In An 'X’ Pattern Until Assembly Is Firmly Clamped To Caster Tubing. Do Not Over tighten Resulting In Bending (#3) Clamp.

Step 6 - Insert (#1) Weight Into (#2) Base & Align Hole In Weight w/ Holes In (#2) Base.

Step 7 - Fasten (#1) Weight To (#2) Base Using (1) (#4.3) Clevis Pin & (1) (#4.4) Hair Pin Clip.

Refer to Figure 2-14a.

Figure 2-14a

2-14 Weight Kit Installation /

Item # Part # Desc. Qty.

1 Y0025 28 lb. Suitcase Weight 1 2 B1022 Single Weight Bracket / Right Caster / Base 1 3 B1015 Weight Bracket / Clamp 1 4 HB0686 Single Weight Kit Hardware Bag 1

4.1 K1472 HHCS 5/16"-18 x 3" GR5 4

4.2 K2516 Ny-Flange Lock Nut 5/16"-18 4

4.3 K1473 Clevis Pin 1/2" x 3" 1

4.4 K1478 Hair Pin Cotter / Double Loop 1

4.4

4.1

4.3

4.2

Right Caster

To Install Weight Bracket

Step 1 - Position (#2) Base Under Caster Tubing w/ Opening Towards Caster Fork.

Step 2 - Position (#3) Clamp On Top Of Caster Tubing w/ Opening Towards Caster Fork.

Step 3 - Align (4) Holes In (#3) Clamp To Holes In (#2) Base

Step 4 - Loosely Fasten (#3) Clamp To (#2) Base Using (4) (#4.1) 5/16"-18 x 3" Bolts & (4) (#4.2) 5/16"-18 NyFlange Lock Nuts.

Step 5 - Position (#2 & #3) Assembly Along Caster Tubing To Prevent Interference From Caster Forks Or Any Other Objects. Tighten Fasteners In An ‘X' Pattern Until Assembly Is Firmly Clamped To Caster Tubing. Do Not Over tighten Resulting In Bending (#3) Clamp.

Step 6 - Insert (#1) Weight Into (#2) Base & Align Hole In Weight w/ Holes In (#2) Base.

Step 7 - Fasten (#1) Weight To (#2) Base Using (1) (#4.3) Clevis Pin & (1) (#4.4) Hair Pin Clip.

Refer to Figure 2-14b.

Figure 2-14b

2-15 Length Of Hose Adjustment

The hoses in steps 2-16 and 2-17 must be cut to fit your machine. Follow steps 2-16 and 2-17. do not cut the hoses until you have tried to fit them on your machine. Remember that the hoses have to be long enough to adjust for the blower assembly’s movement as well as allow for enough clamping surface between the inlet, blower assembly, and the deck boot. Note: The upper hose should be no shorter than 18”.

2-16 Upper Hose Installation

Fasten the inlet to the plastic top by sliding the inlet from the inside of the top to the outside and lock into place. Slide a pre-assembled hose clamp P#(J0060) onto both ends of the 6” upper hose (Figure 2-18). Then slide one end of the 6” hose onto the inlet. Make sure there is about a two-inch overlap between the hose end and the container inlet. Proceed to slide the opposite end of the 6” hose onto the outlet of the blower assembly. See (Figure 2-18) for details. Make sure both ends of the hose are clearly attached to the inlet and the blower assembly inlet. Tighten the hose clamps.

2-17 Lower Hose To Blower Cone Installation

Slide a pre-assembled hose clamp P#(J0060) over both ends of the lower hose. Then proceed to slide the lower hose onto the blower cone. Tighten the hose clamp. The assembly should look like Figure 2-18.

2-18 Lower Hose To Boot Installation

Take the unattached end of the lower hose and slide it over the circular end of the boot. Use the lower hose clamp to secure the hose to the boot (Figure 2-18). Tip: Before securing clamp rotate hose counter-clockwise (away from yourself) approximately 1” to aid in retaining boot to mower deck.

Figure 2-18

Upper

Hose

Inlet

Blower

Outlet

Blower

Cone

Hose

Clamp

Lower

Hose

Clamp

Boot

2-19 Bag Assembly

First, take one of the Bag Ring Split Ends and insert it through the Bag Seam Opening. Next, rotate the Bag around the Bag Ring (1) full turn (360 degrees) until the Bag Ring Split Ends and the Bag Seam Opening are positioned on the same side. Then, connect the Bag Ring Split Ends using (1) End Connector. Last, rotate the Bag Ring and the End Connector Assembly (1/2”) turn (180 degrees) to position the Connector opposite of the Bag Seam Opening. Note Final End Connector Location below in Figure C. Repeat for each Bag.

Figure C

End Connector

Mesh Panel

Bag Ring

Bag Ring Split Ends

Bag Seam Opening

Nylon Panel

Top Assembly

Draw-Latch

Upper Frame Assembly Rail

Bag

2-20 Bag Assembly Installation

Slide the Completed Bag Assembly into the Upper Frame Assembly Rails and close the Top Assembly. Fasten the DrawLatch on either side to hold the bagger closed.

Completed Bag Assembly

Note Final End Connector Location

Mesh Panel

SECTION III - P2B

Disengagement Of The PTO Assy.

OPERATING INSTRUCTIONS

General Safety

Only qualified people familiar with this operator’s manual and the mower’s operator’s manual should operate this machine.

Operation And Tips On Mowing

A. Perform BEFORE EACH USE in the maintenance checklist under Section IV Maintenance.

B. Start mower.

C. With the mower at high idle speed, engage the mower deck.

D. While seated in the operator’s seat, pull the engagement handle of the PTO assembly towards the operator’s seat until the handle slides into position in the retaining slot. With the PTO assembly engaged, you can proceed to operate the control levers of the mower.

NOTE: If the collection system does not appear to be collecting the grass clippings, disengage the deck and PTO assembly, then, engage the parking brake and turn the mower off. Proceed to next section, and review the sections regarding PTO assembly Installation and belt installation/removal and adjustment. Check upper and lower hoses for any clogs.

A. To disengage the PTO assembly, slide the engagement handle out of the retaining slot and push the engagement handle away from the operator’s seat.

WARNING: The PTO assembly blades will continue to spin. DO NOT TOUCH the PTO assembly, pulleys, or the belt until the tractor is turned off. DO NOT adjust the belt tension until the mower is turned off. Refer to the belt adjustment section of the manual.

Unloading The Collection System

NOTE: To determine when the collection bags are full,

follow the following steps:

A. Stop the forward movement of the mower.

B. Disengage the mower deck.

C. Disengage the blower.

D. Engage the parking brake.

E. Once the parking brake has been engaged, then and

only then, walk behind the mower and check the collection bags by first unhooking the rubber strap with S-hook that secures the plastic top, then lift the plastic hood. Load in bags should not exceed the height of the installed bag.

F. To remove the bags from the frame slide bags out and

turn bags over to deposit clippings.

To obtain the maximum effectiveness from your collection system the tips listed below should be followed:

* Watch your speed- Normal conditions will allow a speed of up to approximately 5 mph, but thick, heavy damp conditions will require reduced ground speed.

* Mow with sharp blades- A sharp blade cuts cleaner.

* Wet grass and leaves will decrease effectiveness and will increase horsepower requirements.

* Mow at higher cutting heights- Remove and mulch no more than 2” of grass length with each mowing. (Experts recommend not cutting off more than 1/3 of the grass blade length at any given time.)

* Mow twice, at different height settings, (high, then low), if grass is extra tall.

* Remember that horsepower requirements will vary with the mowing conditions such as type and height of turf grass, moisture content, amount of leaves, whether the terrain is flat or hilly, etc.

G. Slide empty bags back onto the frame and secure

plastic top with the rubber strap with S-hook.

NOTE: Do not allow collection bags to become over-

filled as potential damage may occur to your equipment. Also, be sure to clean the hood screen as needed.

SECTION IV - MAINTENANCE

Maintenance Checklist

NOTE: REMOVE PTO ASSEMBLY BEFORE

RAISING DECK FOR MAINTENANCE.

Before each use:

1. Check blades and spindles to be sure that no foreign objects, such as wire or steel strapping bands, are wrapped around them.

2. Inspect blades for wear. Replace if necessary. If it is necessary to sharpen the blades, remove the blades from the spindles before sharpening. DO NOT sharpen blades while still attached to the mower.

3. Make sure all shields are in place and in good condition. Repair or replace any missing or damaged shields.

4. Perform lubrication per instructions.

5. Listen for abnormal sounds, which might indicate loose parts, damaged bearings, or other damage. Correct any deficiency before continuing operation.

6. With the engine off, engage the blower assembly. Check the belt tension and inspect the pulley belt for cracks or tears.

Lubrication

Gearbox:

1. Every 20 hours of use: Check oil levels in gearbox.

2. First 60 hours of use: Change oil.

3. Every 100 hours of use: Change oil.

NOTE: Oil in gearbox should cover the gears. If not, drain the gearbox and fill using an 80W-90 gear oil. The gearbox ships with 6.0 oz. of oil, but we recommend replacing with a measured 5.5 oz. to fill the gearbox. DO NOT OVERFILL!

7. Check for wear or deterioration of the upper or lower hoses. If there are any portions of the hose that have been torn or worn through, replace immediately.

After Each Use:

1. Clean all debris from machine especially from the container, underneath the belt shields, and safety decals. Replace any missing or illegible decals.

2. Inspect the unit for worn or damaged components. Repair or replace before the next use. Any replacement component installed during repair shall include the component’s current safety decal specified by the manufacturers to be affixed to the component.

3. Under normal usage, the bag material is subject to deterioration and wear and should therefore be frequently checked for necessary replacement. Any replacement bag should be checked to ensure compliance with the original manufacturer’s recommendations or specifications.

4. Check belt for proper tension.

Blower Assembly: NOTE: The following is for older PTO models that contain a greaseable zerc fitting. Newer models

contain maintenance-free bearings and are without a greasable fitting. .

1. On initial use: Grease the fitting on the blower shaft.

2. Every 25 hours of use: Re-grease the grease fitting.

NOTE: Use only white lithium based grease for lubrication of the shaft on the blower assembly.

SECTION V - PARTS & SERVICE

Parts And Service Information

Collection system owners should record the name and telephone number of their Service Center. Your Service Center will be happy to supply replacement parts, accessories, and do any service or repairs to your collection system. If for any reason your Service Center is unable to service your collection system or supply replacement parts, contact New Peco Inc. and include the following information on the chart below.

DOCUMENT THE FOLLOWING INFORMATION FOR FUTURE REFERENCE

Unit Model Number:_______________________________________________ Unit Engine Size:__________________________________________________ Unit Serial Number:________________________________________________ Date of purchase:________/________/_________ Dealer/Distributor Name:__________________________________________ Address: _________________________________ State:_______ Zip:_______ Phone Number: ____________________________________________________

10 Walden Dr | Arden, North Carolina 28704

Phone: 1-800-438-5823 | 828-684-1234

New PECO, Inc.

Fax: 828-684-0858

Email: peco@lawnvac.com

Website: www.lawnvac.com

Item # Part # Desc. Qty.

1 V2000 Pro 2 Bagger Top / Gen. 2 1 2 V2001 Screen 1 3 J4009 Short Rubber Strap w/ S-Hook 2 4 K1030 1/4"-20 x 1-1/4" Carriage Bolt 2 5 K0037 Flat Washer / 1/4" (.75 OD x .312 ID x .060 T) 2 6 K1128 1/4"-20 Nyloc Nut 2 7 K0062 3/16" x 1-1/2" Fender Washer, Z 2 8 K0114 Black Plastic Rivet 11

9 C0067 Dust Guard Mnt. Brkt. 1 10 V1117 Dust Guard 1 11 R0022 Decal / Built In The USA / Lg 1 12 R1069 Decal / W arning - Turn Off Blower 1 13 R1054 Decal / Important Check Hoses 1 14 R1051 Decal / W arning - Use Hearing Protection 1 15 R1057 Decal / 2" x 4" Red Reflector 2 16 C0026 Grass Deflector 1 17 B0676 Hinge Stop Pl. 1

TOP ASSEMBLY EXPLODED PARTS VIEW

A1840 PTO ASSEMBLY EXPLODED PARTS VIEW DESCRIPTION

A1840 PTO ASSEMBLY

Item # Doc # Title Qty

1 M0266 'A' PULLEY FOR DECK DRIVE PTO 1 2 K1446 1.187 OD x .380 ID x .187 WASHER 2 3 k1190 3/8"-16 x 3/4" HHCS 1 4 V0015 BLOWER HSG. 1 5 A0431 GEAR BOX 1 6 A0498 PULLEY ASSY. FOR GEAR BOX 2 7 K0360 7/8" SNAP RING 2 8 J0272 #9 WOODRUFF KEY 2

9 K0035 5/16-18 SET SCREW 2 10 E0015 PTO SHAFT HOUSING 1 11 n0147 BEARING 2.0472 OD, 0.9843 ID, 0.5906 W (6205RS PEER) 1 12 B0460 PTO SHAFT 1 13 N0165 BEARING 1 14 J0801 1/4"-28 ZIRC FITTING 1 15 K1215 3/8"-16 FLANGE NUT 7 16 B0466 BASE PL. 1 17 B0478 GEAR BOX PULLEY GUARD 1 18 K1153 5/16"-18 x 3/4" HHCS 4 19 K1178 5/16"-18 FLANGE NUT 4 20 k1191 3/8"-16 x 1" HHCS 2 21 K0037 1/4" FLAT WASHER .75 OD x .314 ID x .060 T 4 22 k1150 1/4"-20 x 2-1/4" HHCS 2 23 K1126 1/4"-20 FLANGE NUT 4 24 K1202 3/8"-16 x 4-1/2" HHCS G5 2 25 k1216 3/8"-16 NYLOC NUT 2 26 K0348 3/8"-16 x 2" ALL THREAD HHCS 1 27 k0042 5/16" FLAT WASHER .875 OD x .380 ID x .075 T 5 28 K0353 1/4"-20 x 1/2" HHSTS 3 29 J0303 SPRING 2 30 K1192 3/8"-16 x 1-1/4" HHCS 4 31 M0267 A28K KEVLAR BELT 1 32 V1151 5/8" ID x 4-3/4" BLACK HANDLE GRIP 1 33 K0048 3/8" LOCK WASHER 1 34 B0505 PTO ARM MNT. ROD 1 35 B0506 LT. PTO ARM 1 36 B0642 BLWR. MNT. BRKT. 1 37 B0643 RT PTO ARM 1 38 A1112 PTO HANDLE ASSY 1 39 B0510 SPACER BUSHING 1 40 B0511 SPACER BUSHING 1 41 K0403 WASHER 1-1/2" OD x 3/8" ID 3 42 B0739 Blower Hsg. Stiffener Pl. 1 43 K0070 Flat Washer SS 1 44 J0254 3/16" x 3/16". x 3/4" Key 1 45 A1839 3-Blade Impeller Assy. 1 46 K1171 5/16"-24 LH x 7/8" HHCS GR. 5 w/ Patch Coating 1

EXPLODED PARTS VIEW

SAFETY DECALS

To promote safe operation, New PECO, Inc. supplies safety decals on all products manufactured. Damage can occur to safety decals either through shipment, use or reconditioning. Contact your local Service Center for replacement decals.

PUSH HANDLE

DISENGAGE

DISENGAGEDISENGAGE

Part# R0022

Designed & Built

PULL HANDLE

ENGAGE

ENGAGEENGAGE

Part #: R1100

Engage-Disengage Label

R1100

Danger - Never Use Hands

In The USA

Part #: R2007

Part #: R1054

Important - Hose Wear

Part #: R4037

Warning: Hot Surface Label

Part #: R1069

Warning - Turn Off Blower

Part #: R2008

Danger - Rotating Blades

Part #: R1057 - (2)

Red Reflectors

Part #: R1051

Warning - Hearing Protection

Part # R0025

Danger - Rotating

Blades

Part #: R1052

Small Warning:

Turn Off Blower Label

Problem

Possible Cause

Corrective Action

Abnormal Vibration

— Cutting blades are bent or unbalanced

— Loose blower pulley or pulley assembly

— Impeller blade out of balance

— Install new cutting blade

— Tighten the pulley

— Contact dealer to replace

Reduced collection system performance

— Low engine speed

— Plugged screen

— Loose belt

— Full collection bags

— Always operate collection

system at full throttle

— Remove debris, leaves, or

grass clippings from the screen

— Replace/tighten belt

— Empty the collection bags

Blower and hoses plugging too frequently

— Collection bags are too full

— Low engine speed

— Grass is too wet

— Grass is too long

— Ground speed is too fast

— Worn belt

— Loose belt

— Dump more frequently

— Always operate collection

system at full throttle

— Cut grass when it is dry

— Cut the grass several times

— Drive slower at full throttle

— Replace belt

— Adjust the pulley and tighten

belts

Debris blowout

— Collection bags are too full

— Plug/clog in the collection

system

— Ground speed is too fast

— Dump more frequently

— Clean the collection system

— Drive more slowly at full

throttle

Impeller doesn’t rotate freely

— Plug in the blower housing

— Worn impeller blade

— Shaft bearings bad/failing

— Clean the blower housing

— Contact dealer to replace

Troubleshooting

Collection System Performance

NOTES

PECOPECOPECOPECOPECOPECO

PECOPECO

New PECO, Inc.

10 Walden Dr | Arden, North Carolina 28704

Phone: 1-800-438-5823 | 828-684-1234

Fax: 828-684-0858

Email: peco@lawnvac.com

Website: www.lawnvac.com

Peco Pro2B+ 23120910, Pro2B+ 23120911 Operator's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
