GPS™SERIES

POWER AMPLIFIERS

Congratulations on your purchase of the new GPS Series amplifier by Peavey Electronics. Years of power amp design and testing have produced a totally refined, dynamic power amp product line. The GPS Series consists of the GPS 900, GPS 1500, GPS 2600, GPS 3400 and GPS 3500. Each model features tunnel cooling, two variable-speed fans, initialization protection and DDT

™

speaker protection. There are, however, differences between the various models such as output power and connections. This guide will describe each feature of your GPS Series amplifier and note the features common to specific models. The chart below offers a quick reference.

ENGLISH

GPS™Series Power Amps

SPECIFICATIONS

OUTPUT POWER

Stereo mode, both channels driven

2 ohms, 1 kHz, 0.1% THD 4 ohms, 1 kHz, 0.1% THD 8 ohms, 1 kHz, 0.1% THD

Bridge mode, mono

4 ohms, 1 kHz, 0.1% THD 8 ohms 1 kHz, 0.1% THD

RATED OUTPUTPOWER:

Stereo mode, both channels driven

4 ohms, 20 Hz to 20 kHz, 0.03% THD 8 ohms, 20 Hz to 20 kHz, 0.02% THD 4 ohms, 20 Hz to 20 kHz, 0.1% THD 8 ohms, 20 Hz to 20 kHz, 0.08% THD

SLEW RATE:(Typical value)

Stereo mode, each channel Bridge mode, mono

INPUT SENSITIVITY& IMPEDANCE:

@ rated output power, 4 ohms unbalanced, 1/4" phone jack Balanced, XLR (polarity selectable) Overall system gain per channel

FREQUENCYRESPONSE:

Stereo mode, both channels driven

+0m -1 dB @ 1 WRMS, 4 ohms +0, -0.2 dB @ rated output, 4 ohms

DAMPING FACTOR: (Typical value)

Stereo mode, both channels driven

8 ohms

Hum & Noise:

Stereo mode, both channels driven

Below rated output power, 4 ohms

GPS

™

900

450W RMS per channel 330W RMS per channel 200W RMS per channel

900W RMS 660W RMS

300W RMS per channel 1700W RMS per channel

40 Volts per µsec 80 Volts per µsec

0.87V RMS 20 k ohms 10 k ohms per leg 40X (+32 dB)

5 Hz to 50 kHz 20 Hz to 20 kHz

Greater than 400

100 dB, unweighted

GPS

™

1500

750W RMS per channel 550W RMS per channel 320W RMS per channel

1500W RMS 1100W RMS

500W RMS per channel 280W RMS per channel

40 Volts per µsec 80 Volts per µsec

1.12V RMS 20 k ohms 10 k ohms per leg 40X (+32 dB)

5 Hz to 50 kHz 20 Hz to 20 kHz

Greater than 400

100 dB, unweighted

GPS

™

2600

1300W RMS per channel 950W RMS per channel 620W RMS per channel

2600W RMS 1900W RMS

900W RMS per channel 600W RMS per channel

40 Volts per µsec 80 Volts per µsec

1.54V RMS 20 k ohms 10 k ohms per leg 40X (-32 dB)

5 Hz to 100 kHz 10 Hz to 30 kHz

Greater than 700

100 dB, unweighted

GPS

™

3500

1700W RMS per channel 1200W RMS per channel 775W RMS per channel

3500W RMS 2400W RMS

1050W RMS per channel 750W RMS per channel

40 Volts per µsec 80 Volts per µsec

1.62V RMS 20 k ohms 10 k ohms per leg 40X (+32 dB)

5 Hz to 100 kHz 10 Hz to 30 kHz

Greater than 325

100 dB, unweighted

Specifications subject to change without notice.

Please read this guide in its entirety. Pay close attention to the various warnings within as they pertain to the safety of you and your product. Each section will begin with a short description of the information you can expect to obtain within. This should help you to locate the material you are looking for in a timely manner. Once again, congratulations and thank you for buying Peavey!

UNPACKING/REGISTRATION

Inspect the amplifier during unpacking. If you find any damage, notify your dealer immediately. Be sure to save the carton and all packing materials. Should you ever need to ship the unit back to Peavey Electronics, one of its service centers, or the dealer, use only the original factory packing. Please fill out your registration card at this time. It is important that you complete the entire form and mail it to Peavey Electronics in order for your warranty to apply.

INST ALLATION AND MOUNTING

GPS Series amplifiers are 2-rack-space units that mount in a standard 19-inch rack. On all amplifiers, four front panel mounting holes are provided. Refer to the specifications for your specific model in this manual.

QUICK START

The following section lists the steps for basic usage. This is only a quick reference. It is very important that you read the entire manual in order to ensure the safe and optimum operation of your GPS Series amplifier.

TO SET UP THE AMPLIFIER FOR BASIC USAGE:

1. Rack mount the amplifier in the location where it is to be used, remembering to allow for adequate

access and cooling space. For more information, see the section on Cooling Requirements.

2. Make input connections, balanced or unbalanced, to the combination input connector on the rear panel.

See the sections on The INs and OUTs of MODE SELECTION for more information.

3. Connect speakers to the output jacks or binding posts. Be sure to make the correct output connections

for stereo or bridged mono configuration. See the section on The INs and OUTs of MODE SELECTION for more information.

4. Make power connections, allowing for proper current draw. See the section on AC Mains Circuit Size

Requirements for more information.

5. Turn down (fully counterclockwise) the two gain attenuators on the front panel. Turn the front panel

AC switch to “ON,” and bring up the gain attenuators to the desired levels.

AC POWER

The following section will describe the AC power features of your GPS Series amplifier. AC power is a critical element in power amplification. Please read this section carefully, paying special attention to any warning signs. Refer to the diagram below and on page 8 to locate these features. Refer to page 7 for operation notes regarding AC power.

NOTE: Always make connections to your GPS Series amplifier while the unit is turned off.

1. REMOVABLE AC POWER CORD (Located on the rear of the unit)

This receptacle is for the IEC line cord (included), which provides AC power to the unit. Connect the line cord to this connector and to a properly grounded AC supply. Damage to the equipment may occur if an improper line voltage is used. (See voltage marking on unit.) Never remove or cut the ground pin of the line cord plug. This unit is supplied with a properly rated line cord. When lost or damaged, replace this cord with one of the proper ratings.

2. AC POWER SWITCH (Located on the front of the unit. See diagram on page 9.)

A two-position power switch is on the right side of the front panel. With the top portion of the switch pushed to the “IN” position the amplifier is “ON”. Press the bottom portion of the switch to the “IN” position to turn the unit “OFF”.

3. POWER LED (Located on the front of the unit. See diagram on page 9.)

The Power LEDs illuminate to indicate the amplifier is turned on.

REAR PANEL

THE INS AND OUTS OF MODE SELECTION

Once you have provided proper AC power to the amplifier, you may now connect to the inputs and outputs. Remember to do this while the power to the unit is turned off (Power LED are not lit). The rear panel of your GPS Series amplifier provides a central location for all input and output connections. Regardless of the GPS model, all input connections are located at the bottom-center portion of the rear panel and all output connections are located at the top-center portion. In addition, your amplifier can operate in either stereo or bridged (mono) mode. All GPS Series amplifiers have DDT compression. However, only GPS models 900 and 1500 have a switch to defeat this feature. This section will describe these areas of your GPS Series amplifier in detail.

MODE SELECTION

4. MODE SWITCH

This switch determines which mode your amplifier will operate in. Before connecting your input signal and speaker cables to the amp, you must determine how you want the amp to function. Two modes of operation are offered on your amplifier, stereo or bridged (seperate).

STEREO:

When we use the term “stereo” we are referring to two channels, not necessarily left and right. Therefore, in “stereo” mode there are essentially two power amps regardless of input type. You may use a stereo input, one stereo input to each channel of the GPS, or you may send two mono inputs to the GPS in the same manner. A good example of two separate inputs would be the use of one channel for mono mains and one channel for mono monitor signals. In order to select the “stereo” mode of operation you must place the Mode Switch in the “out” position. In this mode, Channel AOutput is supplied by the Channel AInput. Channel B Output is supplied by Channel B Input.

BRIDGED OR MONO:

In the “bridge” mode the two channels of the amplifier combine to form a single mono channel. The benefit of using your amplifier in this mode is that the power is doubled. Refer to the specifications in this manual for detailed output power specs on your specific model. To use the GPS Series amp in

6 7 5

“bridge” mode, place the Mode Switch to the “in” position where the switch remains down. The amp is now a mono amplifier and only requires a single input. Plug your input signal into Channel Aonly for “bridge” mode operation. Channel B input must not have anything connected.

NOTE FOR GPS 900 AND 1500:

When these models are switched to “bridge” mode, the Power LED (3) for Channel B will no longer illuminate.

NOTE: Refer to the Outputs section for an explanation of how the Mode Switch affects the speaker outputs.

INPUTS

5. CHANNELA COMBINATION INPUT

GPS 900 AND 1500

These GPS Series amplifiers offer both XLR electronic balanced and phone jack quasi-balanced inputs for each channel using Neutrik

’s new “combo” connector to save panel space.

The female XLR inputs are connected to dual OP AMP circuitry which offers very low noise and extremely high common mode rejection ratio to minimize outside interference!

The female 1/4" phone jack input in the center of the “combo” connectors are also connected to a unique “quasi-balanced” input circuitry. When used, these 1/4" jacks are not “chassis grounded” but connected to ground through a relatively low impedance circuit which is part of a "ground loop" elimination circuit associated with the input. This will normally allow "hum free" operation when relatively short 1/4" cable patches are made to this input by various outputs from other equipment that share the same rack with this amp. This “quasi-balanced” circuit is “automatic”, and is virtually invisible in normal usage. It cannot be defeated. Use only a two-conductor (TS) phone plug when connecting to the 1/4" input of this connector.

GPS 2600, 3400 AND 3500

These GPS Series amplifiers offer both XLR electronic balanced and phone jack balanced/unbalanced inputs for each channel using Neutrik's new “combo” connector to save panel space.

The female 1/4" phone jack input in the center of the “combo” connectors is also connected to a unique balanced/unbalanced input circuitry. When used, these 1/4" jacks can accept both unbalanced two-conductor (TS) and balanced three-conductor (TRS) inputs. Balanced operation is always recommended for optimum signal-to-noise. If unbalanced operation is a required, always keep the input cable to a minimum length to avoid excessive noise.

6. CHANNEL B COMBINATION INPUT

This connector is identical to the Channel ACombination Input (5) except it is not used during “bridge” mode [See Mode Switch (4).]

7. INPUT POLARITY

Located between the Channel Aand Channel B Inputs is a recessed Input Polarity switch (7) that allows the user to select the desired polarity (phase) of the XLR inputs. This switch is a push-push type and a small diameter “tool” is required to select the desired position. Set to the out (default) position, the polarity is pin #3 positive, pin #2 negative, and pin #1 ground. This is the polarity found on most Peavey power amplifiers. Although this is not the world “standard” (IEC) polarity, it was chosen by Peavey more than 20 years ago, and thus we offer this polarity to be consistent with products both past and present. If this amplifier is used with other competitive products which use the IEC standard polarity, then the “in” position of switch (7) should be selected yielding pin #2 positive, pin #3 negative, and pin #1 ground. As with any electronic gear, polarity (phasing) is important because the

loudspeaker enclosures associated with this power amplifier must be in phase with any other loudspeaker enclosures associated with other power amps. If one loudspeaker system were to “push” while the other “pulls”, a serious sound “cancellation” could result. Changing the setting of the polarity switch has the same effect as reversing the polarity of the loudspeaker connections at the output.

8. THRU

Each channel has a female phone jack (8) labeled “thru”. This Thru jack offers very flexible patching capability. When the XLR input of the combination connectors (5 and 6) are used, this THRU jack is the output of the electronic balanced input circuitry, and as such can be used as a “line out” to connect to the other input jack on this amplifier or other amps in the same rack. Thus, one balanced mixer feed can be connected to the amp via the XLR connector and then further distributed (unbalanced) locally via the THRU jack. Alternatively, when the 1/4" phone jack input of the combination connectors (5 and 6) is used as the input, the THRU jack becomes a “bridged” input to it (similar to a Y-cord), again allowing this input signal to be patched to the other input jack on this amplifier or other amps in the system. IMPORTANT: The THRU jack is not intended to be an “input”, and inadvertent usage as such will result in excessive loading of the input source. Although not a catastrophic mistake, it will cause a significant reduction in “system gain” due to the loading, and will seriously limit the overall system performance.

OUTPUTS

9. SPEAKER OUTPUT CONNECTORS

Each GPS Series amplifier offers two separate output sections featuring parallel outputs. The type of output jack differs from model to model. Find the model and AC supply voltage of your unit to identify which description is applicable to your product.

GPS 900 OR GPS 1500 120 VAC (DOMESTIC) MODELS:

These two models feature 1/4" output jacks located on the top-center of the rear panel. There are two parallel 1/4" jacks per channel which are labeled either “CHANNEL A” or “CHANNEL B”. In addition to the 1/4" output jacks, Binding Posts (10) are also provided for each channel.

All other GPS models:

These models offer dual Speakon

Quick Connectors. The Speakon®is a four-wire connector with the connections labeled as 1+, 1-, 2+ and 2-. The Speakon connectors found on your GPS Series amplifier are connected with pins 1+ and 2+ wired in parallel to the positive output. Pins 1- and 2- are wired in parallel to the negative output. This is typical for each channel.

NOTE: Consult your loud speaker specifications to determine the wiring configuration that will best suit your system. The diagrams on pages 13 and 14 display the recommended hookup for your GPS Series amplifier. In addition to the Speakon

Quick Connectors, Binding Posts (10) are also provided

for each channel.

10. BINDING POST OUTPUT CONNECTORS

Five-way binding post speaker outputs can be found on each channel regardless of model. For each channel, the outputs are in parallel, hence the speaker connection cables can be terminated with banana plugs or stripped wires for use in the binding post terminals as well as the output connectors (9). For sustained high power applications, the use of the binding post terminals is recommended; however, care must be exercised to assure the correct speaker polarity. The red binding posts are the signal outputs from each channel, and the black binding posts are chassis ground. The red binding post should be connected to the positive inputs of the associated loudspeakers. For “bridge” mode operation, only the red binding posts are used, and the associated loudspeaker load is connected between the two red binding posts. The red binding post associated with Channel A should be considered the positive output for the system and thus should be connected to the positive input of the associated loudspeaker system.

WARNING: Regardless of what connections are used, the minimum parallel speaker load should always be limited to 2 ohms per channel or 4 ohms “bridge” mode for any application. Operation at loads of 4 ohms per channel or 8 ohms “bridge” mode is more desirable for sustained operation applications due to the fact that the amplifier will run much cooler at this loading. Operation above 4 ohms per channel and even open circuit conditions can always be considered safe; however, sustained operation at loads below 2 ohms could result in temporary amplifier shut down due to the thermal limits fault circuitry.

DDT COMPRESSION

11. DDT DEFEAT This switch is used to defeat the DDT compression used to protect against signal clipping. Only the GPS 900 and 1500 models offer this feature. It is recommended to leave the DDT compression

enabled at all times to protect your speakers from damaging square waves. The DDT function is disabled when the switch is pressed to the “in” position. The DDT LEDs (12) will illuminate when DDT compression is occurring in that particular channel.

FRONT PANEL CONTROLS/INDICATORS

The following section describes the controls and indicators found on the front panel of your GPS Series amplifier. The Power Switch and LED are explained in a previous section, AC Power.

12. DDT LEDs

The DDT LEDs will illuminate when signal compression is occurring in that channel. If you have a GPS 900 or 1500 and you have the DDT compression defeated, these LED will indicate the channel is clipping.

13. SIGNAL LEDs

Each channel has a Signal LED, which comes on when the amplifier channel output exceeds 1 volt.

14. INPUT GAIN

Each channel has an Input Gain control used to adjust the gain of the input signal. Maximum power amplifier input gain (minimum sensitivity) is achieved at the full clockwise setting (30 dB or 40x). This setting yields maximum mixer/system headroom. Asetting of less than full clockwise will yield lower system noise at the expense of headroom.

15. FAN GRILL (located on front and rear panel)

Two continuously variable-speed DC fans supply cool air to the amplifier.

GPS 900 AND 1500

The fans operate at a quiet, low speed when the unit is turned on. The speed of the fans increase as the amplifier heatsinks require cooling. (See Operation Notes.)

GPS 2600, 3400 AND 3500

The fans do not operate when the unit is first turned on. The operation and speed of the fans are temperature dependent and change as the amplifier heatsinks require cooling. (See Operation Notes.)

DO NOT BLOCK THIS EXHAUST PORT! During the operation of your GPS Series amplifier, it will require fresh air intake in order for the tunnel cooling to function properly. Blocking this air exhaust port or the air intake ports on the rear could result in thermal shutdown of your amplifier.

OPERATION NOTES

AC MAINS CIRCUIT SIZE REQUIREMENTS.

Power requirements for the GPS Series amplifiers are rated at “typical” music conditions. The maximum power current draw rating is limited by the amplifier’s circuit breaker. Consult the specification sheet for the current that each amplifier will demand. AC mains voltage must be the same as that indicated on the back of the amplifier. Damage caused by connecting the amplifier to improper AC voltage is not covered by any warranty.

13 3

LINE CORD

For your safety, we have incorporated a removable 3-wire line (mains) cable with proper grounding

facilities. It is not advisable to remove the ground contact under any circumstances. If it is necessary to use the equipment without proper grounding facilities, suitable grounding adapters should be used. Less noise and greatly reduced shock hazard exists when the unit is operated with the proper grounded receptacles.

NOTE: Always turn off the amplifier before making audio connections. As an extra precaution, have the input attenuator turned down during power-up.

COOLING REQUIREMENTS (GPS 900 and 1500)

These GPS Series amplifiers use a forced-air cooling system to maintain a low, even operating temperature. Cooling air is drawn by synchronized, variable-speed fans mounted on the back panel, and exhausts through slots on the front panel. The fans will remain at low speed until internal operating temperature rises above 45

C. Make sure that there is enough space around the back of the amplifier to allow air to enter. The normal operating temperature is 550C. This is a very cool temperature when compared to most amplifier standards. What this means to you is a noticeable increase in product life. On the GPS 900 and 1500 models, the fans will turn on simultaneously when temperature activated.

COOLING REQUIREMENTS (All models except GPS 900 and 1500)

These GPS Series amplifiers use a forced-air cooling system to maintain a low, even operating temperature. Cooling air is drawn by continuously variable speed fans mounted on the back panel, and exhausts through slots on the front panel. The fan will remain inactive until internal operating temperature rises above 45

NOTE: If the amplifier is rack-mounted, do not use doors or covers on the front or back while the unit is

in operation. Whatever type of rack you are using, make sure that heated air can escape freely, and that there is no resistance to the intake of cool air through the back grill. Intake and exhaust air must flow without resistance.

INPUT CONNECTIONS

The input connector accepts balanced and unbalanced audio signals. For use with an unbalanced source, tie the inverting (-) input to ground by installing a jumper to the signal ground connection. If the inverting input is left floating, a 6 dB loss in gain will result.

SIGNAL MODE CONFIGURATION

GPS Series amplifiers are configured for two-channel (stereo) or bridged mode operation at the input connectors and via Mode Switch. To send the same signal to both channels, connect the input signal to Channel Avia the input connector. Run a jumper from the Thru jack of Channel A to the input of Channel B. Both channels then share Channel A’s input signal, but will operate independently. Speakers are connected as in two-channel (stereo) mode.

Bridged mode converts the amplifier into a single-channel unit with a power rating equal to the sum of both channels’ power ratings, and at a load rating of twice that of the single-channel rating. In bridged mode, the channels operate at opposite polarity of each other so that one channel “pushes” and the other “pulls” equally. Signal is connected to the Channel AInput connector. The speakers are connected only to the designated “+” output terminals. Never ground either side of the speaker cable when the amplifier is in bridged mode, as both sides are “hot”. For GPS Series amplifiers, the minimum nominal load impedance in bridged mode is 4 ohms; this is the equivalent of driving both channels at 2 ohms. Driving loads of less than 4 ohms may activate the thermal protect circuitry.

NOTE: Regardless of operating mode, NEVER connect amplifier outputs together! SPEAKER OUTPUT CONNECTIONS

Speakers are connected using the output connectors on the rear of your amplifier. Make sure the amplifier is turned off before you change any output connections. Refer to the diagram on page 14 to view the wiring configuration of the Speakon connectors if your model utilizes them. Consult the Wire Gauge Chart on page 14 to find a suitable wire gauge and minimize losses of power in the speaker cables. Also, make sure that the load impedance is not lower than that rated for the amplifier.

PROTECTION FEATURES

The GPS Series incorporates protection features derived from Peavey’s extensive experience with reliability. The amplifiers are ruggedly built from high quality components and feature comprehensive protection circuits to protect your amplifier from those “real world” occurrences.

DDT

At the amplifier’s full power, or clipping point, the channel gain will automatically be reduced, guarding the loudspeakers against damaging high power and continuous square waves that would otherwise be produced. This is indicated by illumination of the DDT LED. Operation is virtually transparent in use and full signal bandwidth is maintained. However, if you have a GPS 900 or 1500 and choose to defeat the DDT compression function, this will not apply and clipping may occur.

LOAD FAULT CORRECTION

™

LFC™(Load Fault Correction™) is an innovative circuit that will instantaneously reduce channel gain to allow the amplifier to operate at a safe level into an abnormal load. Moderate activation of LFC is inaudible in normal use. In addition, if extreme low impedance or a short circuit is encountered during high signal level conditions, the amplifier’s output relay will open.

INITIALIZATION PROTECTION

™

(IP™)

IP™operates every time the amplifier is turned on, or after a protect condition. During turn-on, the amplifier goes into protect mode and leaves the speaker load disconnected until the amplifier determines that the operating status is normal. The IP

™

circuit attenuates the signal during the initial turn-on or protect operation. After relay release, channel gain gradually increases to the attenuator setting to avoid unnecessary stress on the loudspeakers.

THERMAL PROTECTION

If the heatsink temperature or power transformer reaches an abnormally high temperature, the amplifier will protect itself by disconnecting the speaker load until the amplifier returns to a normal temperature. During this time, the Power LEDs will not illuminate for that particular channel, and the cooling fan(s) will operate at maximum speed.

SHORT CIRCUIT

If an output is shorted, the LFC

™

, speaker relay and thermal circuits will automatically protect the amplifier. The LFC™circuit senses the short circuit as an abnormal load condition and reduces the channel gain to a safe level for the load. In extreme or severe conditions, the speaker relays will disconnect the load and initiate a power-on start-up sequence.

DC VOLTAGE PROTECTION

If an amplifier channel detects DC voltage or subsonic signals at its output terminals, the speaker relay will immediately open to prevent loudspeaker damage.

Neutrik®is a registered trademark of Neutrik AG

Speakon®is a registered trademark of Neutrik AG.

GPS™ Series Amplifiers

Recommended Connection for Stereo Mode

SP™ 7G

GPS 900/1500 150VAC Units Only

T o Additional Amplifier Input

Channel B Input Source

Channel A Input Source

T o Additional Amplifier Input

™

NOTE: Minimum Load Impedance is 2 Ohms.

1/4" jacks are wired in parallel with binding post. Tip = Positive Ring = Negative

All other GPS Models

T o Additional Amplifier Input

Channel B Input Source

Channel A Input Source

T o Additional Amplifier Input

NOTE: Always use a balanced input source if available.

DTH® 4215F

NOTE: Minimum Load Impedance is 2 Ohms.

Speaker connectors are wired in parallel with binding posts. Pins (1+) and (2+) are wired positive. Pins (1-) and (2-) are wired negative.

GPS™ Series Amplifiers

Recommended Connection for Bridged Mode

GPS 900/1500 150VAC Units Only

Switch “in” for Bridge Mode

Input Source

(-)

(+)

To negative input terminal of speaker

To positive input terminal of speaker

NOTE: Minimum Load Impedance is 4 Ohms.

T o Additional Amplifier Input

All other GPS Models

Switch “in” for Bridge Mode

Input Source

(-)

(+)

To negative input terminal of speaker

To positive input terminal of speaker

NOTE: Minimum Load Impedance is 4 Ohms.

T o Additional Amplifier Input

NOTE: Always use a balanced input source if available.

WIRE GAUGE CHART

Stranded Power Power Power Cable Wire Loss Loss Loss Length Gauge Into Into Into (Feet)

WG) 8 ohms 4 ohms 2 ohms

5' 18 AWG .79% 1.58% 3.16%

16 .05 1.0 2.0

14 .31 .62 1.24

12 .20 .40 .80

10 .125 .25 .50 10' 18 AWG 1.58% 3.16% 6.32%

16 1.0 2.0 4.0

14 .62 1.25 2.50

12 .40 .80 1.6

10 .25 .50 1.0 40' 18 AWG 8% 12.6% 25.2%

16 4.0 8.0 16.0

14 2.5 5.0 10

12 1.60 3.2 6.4

10 1.0 2.0 4.0

8 .625 1.25 2.50 80' 16 AWG 8.0% 16.0% 32.0%

14 5.0 10.0 20.0

12 3.2 6.4 12.8

10 2.0 4.0 8.0

GPS™900 SPECIFICATIONS

OUTPUT POWER: (Typical value) Stereo mode, both channels driven

2 ohms, 1 kHz, .1 THD - 450 WRMS per channel 4 ohms, 1 kHz, .1 THD - 330 WRMS per channel 8 ohms, 1 kHz, .1 THD - 200 WRMS per channel

Bridge mode, mono

4 ohms, 1 kHz, .1 THD - 900 WRMS 8 ohms, 1 kHz, .1 THD - 660 WRMS

RATED OUTPUT POWER: Stereo mode, both channels driven

4 ohms, 20 Hz to 20 kHz,0.03% THD - 300 WRMS per channel 8 ohms, 20 Hz to 20 KHz,0.02% THD - 170 WRMS per channel

SLEW RATE: (Typical value)

Stereo mode, each channel - 40 Volts per usec Bridge mode, mono - 80 Volts per usec

INPUT SENSITIVITY AND IMPEDANCE:

Input attenuator set @ FCW

@ rated output power, 4 ohms - 0.90 VRMS (-1 dBV) Unbalanced, 1/4" phone jack - 20 k ohms Balanced, XLR (phase selectable) - 10 k ohms per leg Overall system gain per channel - 40X (+32 dB)

FREQUENCY RESPONSE: (Typical) Stereo mode, both channels driven

+0,-1 dB, 1 WRMS, 4 ohms - 5 Hz to 50 kHz +0,-0.2 dB @ rated output, 4 ohms - 20 Hz to 20 kHz

DAMPING FACTOR: (Typical value) Stereo mode, both channels driven

8 ohms, 1 kHz - Greater than 400

HUM AND NOISE: Stereo mode, both channels driven

Below rated output power, 4 ohms - 100 dB @ 120 volts

POWER CONSUMPTION: Stereo mode, both channels driven

@ 1/8 rated power @ 2 ohms - 540 watts @ 120 VAC

WEIGHT: - 35.8 lbs. (16.2 kg)

Specifications subject to change without notice.

GPS™1500 SPECIFICATIONS

OUTPUT POWER: (Typical value) Stereo mode, both channels driven

2 ohms, 1 kHz, .1 THD - 750 WRMS per channel 4 ohms, 1 kHz, .1 THD - 550 WRMS per channel 8 ohms, 1 kHz, .1 THD - 320 WRMS per channel

Bridge mode, mono

4 ohms, 1 kHz, .1 THD - 1,500 WRMS 8 ohms, 1 kHz, .1 THD - 1,100 WRMS

RATED OUTPUT POWER:

Stereo mode, both channels driven

4 ohms, 20 Hz to 20 kHz,0.03% THD - 500 WRMS per channel 8 ohms, 20 Hz to 20 kHz,0.02% THD - 280 WRMS per channel

SLEW RATE: (Typical value)

Stereo mode, each channel - 40 Volts per usec Bridge mode, mono - 80 Volts per usec

INPUT SENSITIVITY and IMPEDANCE:

Input attenuator set @ FCW

@ rated output power, 4 ohms - 1.17 VRMS (+1 dBV) Unbalanced, 1/4" phone jack - 20 k ohms Balanced, XLR (phase selectable) - 10 k ohms per leg Overall system gain per channel - 40X (+32 dB)

FREQUENCY RESPONSE: (Typical)

Stereo mode, both channels driven

+0,-1 dB, 1 WRMS, 4 ohms - 5 Hz to 50 kHz +0,-0.2 dB @ rated output, 4 ohms - 20 Hz to 20 kHz

DAMPING FACTOR: (Typical value) Stereo mode, both channels driven

8 ohms, 1 kHz - Greater than 400

HUM AND NOISE: Stereo mode, both channels driven

Below rated output power, 4 ohms - 100 dB, unweighted

POWER CONSUMPTION: Stereo mode, both channels driven

@ 1/8 rated power @ 2 ohms - 1080 watts @ 120 VAC

WEIGHT: - 39.2 lbs. (17.9 kg)

Specifications subject to change without notice.

GPS™2600 SPECIFICATIONS

Rated Power (2 x 2 ohms) - 1,300 watts @ 1 kHz both channels driven at <0.15% T.H.D. Rated Power (2 x 4 ohms) - 950 watts @ 1 kHz both channels driven at <0.1% T.H.D. Rated Power (2 x 8 ohms) - 650 watts @ 1 kHz both channels driven at <0.1% T.H.D. Rated Power (1 x 2 ohms) - 1,500 watts @ 1 kHz at <0.1% T.H.D Rated Power (1 x 4 ohms) - 1,000 watts @ 1 kHz at <0.1% T.H.D Rated Power (1 x 8 ohms) - 700 watts @ 1 kHz at <0.05% T.H.D Minimum Load Impedance - 2 ohms Maximum RMS Voltage Swing - 93 volts Frequency Response - 10 Hz - 100 kHz; +0, -.3 dB at 1 watt Power Bandwidth - 10 Hz - 40 kHz; +0, -3 dB at rated power T.H.D. (2 x 2 ohms) - <0.15% @ 1050 watts from 20 Hz to 20 kHz with both channels driven T.H.D. (2 x 4 ohms) - <0.1% @ 900 watts from 20 Hz to 20 kHz with both channels driven T.H.D. (2 x 8 ohms) - <0.1% @ 600 watts from 20 Hz to 20 kHz with both channels driven Input CMRR - > - 65d B @ 1 kHz Voltage Gain - x 40 (32 dB) Crosstalk - > -75 dB @ 1 kHz at rated power @ 8 ohms Hum and Noise - > -110 dB, “A” weighted referenced to rated power @ 8 ohms Power Consumption - > 1200 watts Slew Rate - > 40V/us Damping Factor (8 ohms) - > 700:1 @ 20 Hz to 1 kHz SMPTE IMD - <0.1% 60 Hz and 7 kHz, 900W @ 4 ohms Input Sensitivity (x 40) - 1.54 volts for 4 ohm rated power, 1.27 volts for 2 ohm rated power Input Impedance - 20 k ohms, balanced Current Draw @ 1/8 power@ 2 ohms - 10 A@ 120 volts

Cooling - Two 80 mm DC fans, off until heatsinks reach 45

C, then temperature dependant

variable speed

Controls - Two front panel attenuators Indicator LEDs - Two Clip, two Signal, two Active Protection - Thermal, DC, turn-on bursts, subsonic, incorrect loads Connectors - XLR input, 6.3 mm phone type output patch, Speakon and Binding Post speaker

output, IEC mains input

Construction - 16 ga. steel reinforced with 12 ga.rack ears Dimensions - 133 mm x 483 mm x 432 mm, 400 mm behind rear mounting ears

(5.23" x 19" x 17", 15.75" behind rack ears)

Weight - 45.7 lbs. (20.7 kg)

Specifications subject to change without notice.

GPS 3400 SPECIFICATIONS

Rated Power (2 x 2 ohms): 1,700 watts @ 1 kHz both channels driven at <0.15% T.H.D. Rated Power (2 x 4 ohms): 1,200 watts @ 1 kHz both channels driven at <0.1% T.H.D. Rated Power (2 x 8 ohms): 750 watts @ 1 kHz both channels driven at <0.1% T.H.D. Rated Power (1 x 2 ohms): 1,800 watts @ 1 kHz at <0.1% T.H.D Rated Power (1 x 4 ohms): 1,350 watts @ 1 kHz at <0.1% T.H.D Rated Power (1 x 8 ohms): 825 watts @ 1 kHz at <0.05% T.H.D T.H.D. (2 x 2 ohms): <0.15% @ 1350W from 20 Hz to 20 kHz with both channels driven T.H.D. (2 x 4 ohms): <0.1% @ 1000W from 20 Hz to 20 kHz with both channels driven T.H.D. (2 x 8 ohms): <0.08% @ 700W from 20 Hz to 20 kHz with both channels driven Input CMRR: > - 65 dB @ 1 kHz Voltage Gain: x 40 (32 dB) Crosstalk: > -75 dB @ 1 kHz at rated power @ 8 ohms Hum and Noise: > -115 dB, “A” weighted referenced to rated power @ 8 ohms Power Consumption: > 1400 watts Slew Rate: > 40V/us Damping Factor (8 ohms): > 325:1 @ 20 Hz - 1 kHz SMPTE IMD: <0.1% 60Hz and 7 kHz, 950W @ 4 ohms Input Sensitivity (x 40): 1.7 volts for 4 ohm rated power, 1.4 volts for 2 ohm rated power Input Impedance: 20 k ohms, balanced Current Draw @ 1/8 rated

power @ 2 ohms: 11.66 A @ 120 volts Cooling: Two 80 mm DC fans, off until heatsinks reach 45

C, then temperature dependent variable speed

Controls: Two front panel attenuators Indicator LEDs: Two DDT/Clip, 2 Signal, 2 Power Protection: Thermal, DC, turn-on bursts, subsonic, incorrect loads Connectors: XLR input, 6.3mm phone type output patch, Speakon and Binding Post speaker output, IEC mains input Construction: 16 ga. steel reinforced with 12 ga.rack ears Dimensions: 133 mm x 483 mm x 432 mm, 400 mm behind rear mounting ears (5.23" x 19" x 17", 15.75" behind rack ears) Weight: 49.8 lbs. (23.3 kg)

GPS 3500 SPECIFICATIONS

Rated Power (2 x 2 ohms): 1750 watts @ 1 kHz both channels driven at <0.15% T.H.D. Rated Power (2 x 4 ohms): 1200 watts @ 1 kHz both channels driven at <0.1% T.H.D. Rated Power (2 x 8 ohms): 775 watts @ 1 kHz both channels driven at <0.1% T.H.D. Rated Power (1 x 2 ohms): 1,850 watts @ 1 kHz at <0.1% T.H.D Rated Power (1 x 4 ohms): 1,350 watts @ 1 kHz at <0.1% T.H.D Rated Power (1 x 8 ohms): 850 watts @ 1 kHz at <0.05% T.H.D Minimum Load Impedance: 2 ohms Maximum RMS Voltage Swing: 89 volts Frequency Response: 10 Hz - 100 kHz; +0, -.3d B at 1 watt Power Bandwidth: 10 Hz - 40 kHz; +0, -3 dB at rated power T.H.D. (2 x 2 ohms): <0.15% @ 1400W from 20 Hz to 20 kHz with both channels driven T.H.D. (2 x 4 ohms): <0.1% @ 1050W from 20 Hz to 20 kHz with both channels driven T.H.D. (2 x 8 ohms): <0.08% @ 750W from 20 Hz to 20 kHz with both channels driven Input CMRR: > - 65 dB @ 1 kHz Voltage Gain: x 40 (32 dB) Crosstalk: > -75 dB @ 1 kHz at rated power @ 8 ohms Hum and Noise: > -115 dB, “A” weighted referenced to rated power @ 8 ohms Power Consumption: > 1400 watts Slew Rate: > 40V/us Damping Factor (8 ohms): > 325:1 @ 20 Hz - 1 kHz SMPTE IMD: <0.1% 60Hz and 7 kHz, 950W @ 4 ohms Input Sensitivity (x 40): 1.7 volts for 4 ohm rated power, 1.4 volts for 2 ohm rated power Input Impedance: 20 k ohms, balanced Current Draw @ 1/8 rated

power @ 2 ohms: 11.66 A @ 120 volts Cooling: Two 80 mm DC fans, off until heatsinks reach 45

C, then temperature dependent variable speed

Specifications subject to change without notice.

ESPAÑOL

Serie GPS

™

Amplificadores de Potencia

Felicidades por tu compra del nuevo amplificador de potencia de la serie GPS de Peavey Electronics. Años de diseño y pruebas han producido una línea de amplificadores dinámicos completamente refinada. La serie GPS consiste de los modelos GPS 900, GPS 1500, GPS 2600, GPS 3400 y GPS 3500. Cada modelo incluye enfriamiento por túnel, ventiladores variables de dos velocidades, protección de iniciación y protección de bocinas DDT‘. Pero también hay diferencias entre los modelos, como las diferencias de potencia y conexiones. Esta guía describirá todas las características de tu modelo GPS, y también hará nota de las características comunes entre los otros modelos GPS. La gráfica inferior ofrece una guía de referencia rápida.

SPECIFICATIONS

OUTPUT POWER

Stereo mode, both channels driven

2 ohms, 1 kHz, 0.1% THD 4 ohms, 1 kHz, 0.1% THD 8 ohms, 1 kHz, 0.1% THD

Bridge mode, mono

4 ohms, 1 kHz, 0.1% THD 8 ohms 1 kHz, 0.1% THD

RATED OUTPUTPOWER:

Stereo mode, both channels driven

4 ohms, 20 Hz to 20 kHz, 0.03% THD 8 ohms, 20 Hz to 20 kHz, 0.02% THD 4 ohms, 20 Hz to 20 kHz, 0.1% THD 8 ohms, 20 Hz to 20 kHz, 0.08% THD

SLEW RATE:(Typical value)

Stereo mode, each channel Bridge mode, mono

INPUT SENSITIVITY& IMPEDANCE:

@ rated output power, 4 ohms unbalanced, 1/4" phone jack Balanced, XLR (polarity selectable) Overall system gain per channel

FREQUENCYRESPONSE:

Stereo mode, both channels driven

+0m -1 dB @ 1 WRMS, 4 ohms +0, -0.2 dB @ rated output, 4 ohms

DAMPING FACTOR: (Typical value)

Stereo mode, both channels driven

8 ohms

Hum & Noise:

Stereo mode, both channels driven

Below rated output power, 4 ohms

GPS

™

900

450W RMS per channel 330W RMS per channel 200W RMS per channel

900W RMS 660W RMS

300W RMS per channel 1700W RMS per channel

40 Volts per µsec 80 Volts per µsec

0.87V RMS 20 k ohms 10 k ohms per leg 40X (+32 dB)

5 Hz to 50 kHz 20 Hz to 20 kHz

Greater than 400

100 dB, unweighted

GPS

™

1500

750W RMS per channel 550W RMS per channel 320W RMS per channel

1500W RMS 1100W RMS

500W RMS per channel 280W RMS per channel

40 Volts per µsec 80 Volts per µsec

1.12V RMS 20 k ohms 10 k ohms per leg 40X (+32 dB)

5 Hz to 50 kHz 20 Hz to 20 kHz

Greater than 400

100 dB, unweighted

GPS

™

2600

1300W RMS per channel 950W RMS per channel 620W RMS per channel

2600W RMS 1900W RMS

900W RMS per channel 600W RMS per channel

40 Volts per µsec 80 Volts per µsec

1.54V RMS 20 k ohms 10 k ohms per leg 40X (-32 dB)

5 Hz to 100 kHz 10 Hz to 30 kHz

Greater than 700

100 dB, unweighted

GPS

™

3500

1700W RMS per channel 1200W RMS per channel 775W RMS per channel

3500W RMS 2400W RMS

1050W RMS per channel 750W RMS per channel

40 Volts per µsec 80 Volts per µsec

1.62V RMS 20 k ohms 10 k ohms per leg 40X (+32 dB)

5 Hz to 100 kHz 10 Hz to 30 kHz

Greater than 325

100 dB, unweighted

Por favor lee esta guía completamente. Presta especial atención a las varias advertencias incluidas, ya que éstas son para tu protección y la de tu equipo. Cada sección comenzará con una pequeña descripción de la información que puedes esperar recibir en ella. Esto te servirá para localizar rápidamente la información que requieres. Una vez más, ¡felicidades y gracias por comprar productos Peavey!

DESENPAQUE/REGISTRO

Inspecciona el amplificador durante el desempaque. Si encuentras averías, avísale a tu distribuidor inmediatamente. Asegúrate de guardar el cartón y todos los materiales de empaque. Si alguna vez tienes que mandar el equipo a Peavey o a un centro de servicio o distribución autorizado, usa sólo los materiales de empaque originales. Por favor llena la tarjeta de registro en este momento. Es importante que la llenes en su totalidad y la envíes a Peavey Electronics para que tu garantía sea aplicable.

INSTALACIÓN Y MONTURAS

La serie de amplificadores GPS usa dos espacios de rack, montables en un rack estándar de 19 pulgadas. En todos los amplificadores encontrarás cuatro agujeros para tornillos en la parte frontal. Busca las especificaciones de tu modelo en particular.

COMIENZO RÁPIDO

La siguiente sección abarca los pasos para el uso básico. Esto es sólo una guía de rápida referencia. Es muy importante que leas el manual entero para conseguir la operación óptima y más segura de tu amplificador de la serie GPS.

PARA PREPARAR ELAMPLIFICADOR PARA USO BÁSICO:

1. Instala el amplificador en el rack que le corresponde, recordando mantener suficiente espacio para que

se pueda ventilar y enfriar. Para más información consulta la sección requisitos de enfriamiento.

2. Haz las conexiones adecuadas, balanceadas o no, la entrada de combinación (combination input) en la

parte trasera. Lee la sección de Las Entradas y Salidas de Selección de Modo para más información.

3. Conecta las bocinas a las conexiones de salida o puertos de conexión. Asegúrate de hacer las

conexiones correctas para estéreo o configuración de puente mono. Lee la sección de Las Entradas y Salidas de Selección de Modo para más información.

4. Haz las conexiones de poder, permitiendo la suficiente corriente al amplificador. Lee la sección de

Requisitos de Tamaño de Circuito Main CA para más información.

5. Baja (completamente en contra de las manecillas del reloj) los dos atenuadores del panel frontal.

Enciende el interruptor de poder (posición “ON”), y sube los atenuadores de ganancia hasta los niveles deseados.

Poder CA

La siguiente sección describe las características referentes a poder de CA de tu amplificador GPS. El poder de CA es un elemento crítico en la amplificación de potencia. Por favor lee esta sección cuidadosamente, prestando especial atención a los avisos de cuidado. Puedes referirte al diagrama aquí abajo, o en la página 8 para localizar las diferentes partes. Has referencia a la página 7 para información sobre poder de CA.

NOTA: Siempre lleva a cabo las conexiones a tu amplificador GPAcuando la unidad esté apagada.

1. CABLE DE PODER DE CA REMOVIBLE (LOCALIZADO EN LA PARTE TRASERA DE LA

UNIDAD)

Este receptáculo es para un cable IEC (incluido), que provee poder de CA a la unidad. Conecta el cable a este conector y a un conector de pared correctamente aterrizado. El equipo puede sufrir daños si se le aplica el voltaje equivocado. (Ver marca de voltaje en la unidad). Nunca cortes o dobles la aguja de tierra del cable. Esta unidad incluye un cable apropiado para la unidad. En caso de pérdida o daño, reemplázalo con un cable apropiado.

2. INTERRUPTOR DE PODER DE CA (localizado en la parte frontal de la unidad. Ver diagrama en

página 9)

Un interruptor de dos posiciones se encuentra en la parte derecha del panel frontal e la unidad. Con la parte superior del interruptor oprimida, el amplificador está en posición encendida (“ON”). Oprime la parte inferior del interruptor para apagar la unidad (posición “OFF”).

3. LED DE PODER (localizada en la parte frontal de la unidad. Ver diagrama en página 9)

El LED de poder se iluminará cuando la unidad esté encendida (“ON”).

PANEL TRASERO

LAS ENTRADAS Y SALIDAS DE SELECCIÓN DE MODO

Una vez que le has dado poder de CA al amplificador, puedes conectar las entradas y salidas. Recuerda hacer esto cuando el poder está apagado (“OFF”), con el LED de poder no iluminado. El panel trasero de tu amplificador GPS provee una localización central desde la cual podrás llevar a cabo todas las conexiones de salida y entrada de la unidad. Sin importar el modelo de GPS, todas las conexiones de entrada están localizadas en la parte central inferior del panel trasero, y todas las conexiones de salida están localizadas en la parte central superior del panel trasero. Además, tu amplificador puede operar tanto en estéreo como en modo mono (puente). Todos los amplificadores de la serie GPS cuentan con compresión DDT. Pero sólo los modelos GPS 900 y 1500 cuentan con un interruptor para apagarlo. Esta sección cubrirá estas áreas de tu amplificador GPS en detalle.

SELECCIÓN DE MODO

4. INTERRUPTOR DE MODO

Este interruptor controla el modo de operación de tu amplificador. Antes de conectar la señal de entrada y los cables de bocinas al amplificador, debes determinar la forma en que quieres que el amplificador funcione. Puedes elegir entre dos modos de operación en tu amplificador: estéreo y puenteado (separado).

ESTÉREO

Cuando usamos el término estéreo, nos referimos a dos canales, no necesariamente derecho e izquierdo. Por lo que en “estéreo” hay dos amplificadores, independientemente del tipo de entrada. Puedes usar una entrada estéreo, una entrada estéreo para cada canal del amplificador, o puedes mandar dos entradas mono al GPS de la misma forma. Un buen ejemplo de esto es como puedes usar una de las entradas para la sala (mono) y el otro canal para los monitores (mono). Para seleccionar el modo de operación estéreo, tienes que poner el interruptor en la posición ‘afuera’. De esta forma , la entrada del canal Aes la salida del canal A y la salida del canal B es la entrada del canal B.

MONO (O PUENTE)

En el modo ‘puente’ (bridged) los dos canales del amplificador se combinan para crear una señal mono única. El beneficio de usar el amplificador de esta forma es que la potencia es doblada. Lee las especificaciones de este manual para descripciones detalladas del poder de tu modelo específico. Para usar tu amplificador GPS en modo ‘puente’, oprime el interruptor de modo a la posición “adentro” con el interruptor abajo. El amplificador ahora es mono y sólo requiere una entrada. Conecta tu entrada al canal Apara operación en este modo. La entrada B no debe tener nada conectado.

6 7 5

+ 50 hidden pages
