Peavey DeltaFex Twin User Manual

Specifications and Main Features

  • Model: DeltaFex™ Twin
  • Frequency Response:
  • Dry signal: 20 Hz – 20 kHz
  • Effect signal: 20 Hz – 15.6 kHz
  • A/D And D/A Conversion:
  • Rate: 31.25 kHz
  • Quantization: 16 bit
  • S/N Signal ratio:
  • Dry Signal: 108 dB (unweighted) minimum.
  • Effect Signal: 85 dB (unweighted) minimum.
  • Inputs:
  • Left/Mono Right: 1M (ohm) : Impedance.
  • Outputs:
  • Left/Mono Right: 1K (ohm) Impedance - 20 (dBV) Headroom minimum, +10 (dBV) maximum.
  • Clip Level: From maximum minus 6 dB
  • Dimensions: 1.75H x 19W x 5.25D
  • Weight: 3.50 Pounds
  • Power Supply: 16.5 volt AC, 1100 mA external power supply input.
  • Effects:
  • Covers 16 presets ranging from Chamber simulation, Plate to Room, Cathedral and many more as listed in Effects Legend.
  • Controls:
  • Power LED, level and clip led, power switch, Input level control, wet dry mix control, output control level, parameter controls, select preset dial.

Frequently Asked Questions

Q: What kinds of effects can the DeltaFex™ Twin create?

A: DeltaFex™ Twin is capable of generating several effects, such as Chamber, Plate, Room, Cathedral, Spring, Delay + Reverb, as well as different types of delays, chorus, phaser, flange and rotary speaker effects.

Q: How does one go about selecting the preset effect?

A: The Preset Select Dial (8) located at the front panel is used to select any of the 16 preset selections available.

Q: What measures should I take in the event that the Clip LED is on?

A: A steady Clip LED light means that there is likelihood of distortion and/or a drop in DSP capacity. It is recommended that the input range be modified in order to manage this.

Q: Is it possible to utilize this appliance for its mono function?

A: Yes, the use of the Left/Mono inputs and the outputs is sufficient for mono functioning.

Q: What is the power supply for the DeltaFex™ Twin?

A: The supplied 16.5 V ac 1100 mA external power supply needs to be utilized.

Q: In what manner is the wet/dry mix controlled

A: The Wet/Dry Mix Control (5) permits users to set to all dry by shifting full counterclockwise or all wet by rotating full clockwise and anywhere in between.

Q: Can the DeltaFex™ Twin be used for live sound applications?

A: DeltaFex™ Twin is a very versatile unit intended for live sound as well as home studio use.
