CEL-2A

™

Dual Compressor/Expander/Limiter Operating Manual

2

Intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

Intended to alert the user of the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the product.

CCAAUUTTIIOONN::

Risk of electrical shock — DO NOT OPEN!

CCAAUUTTIIOONN::

To reduce the risk of electric shock, do not remove cover. No user serviceable parts inside.

Refer servicing to qualified service personnel.

WWAARRNNIINNGG::

To prevent electrical shock or fire hazard, do not expose this appliance to rain or moisture.

Before using this appliance, read the operating guide for further warnings.

Este símbolo tiene el propósito, de alertar al usuario de la presencia de “(voltaje) peligroso” sin
aislamiento dentro de la caja del producto y que puede tener una magnitud suficiente como para
constituir riesgo de descarga eléctrica.

Este símbolo tiene el propósito de alertar al usario de la presencia de instruccones importantes sobre la
operación y mantenimiento en la información que viene con el producto.

PPRREECCAAUUCCIIOONN::

Riesgo de descarga eléctrica ¡NO ABRIR!

PPRREECCAAUUCCIIOONN::

Para disminuír el riesgo de descarga eléctrica, no abra la cubierta. No hay piezas útiles

dentro. Deje todo mantenimiento en manos del personal técnico cualificado.

AADDVVEERRTTEENNCCIIAA::

Para evitar descargas eléctricas o peligro de incendio, no deje expuesto a la lluvia o

humedad este aparato Antes de usar este aparato, Iea más advertencias en la guía de operación.

Ce symbole est utilisé dans ce manuel pour indiquer à l’utilisateur la présence d’une tension dangereuse
pouvant être d’amplitude suffisante pour constituer un risque de choc électrique.

Ce symbole est utilisé dans ce manuel pour indiquer à l’utilisateur qu’il ou qu’elle trouvera d’importantes
instructions concernant l’utilisation et l’entretien de l’appareil dans le paragraphe signalé.

AATTTTEENNTTIIOONN::

Risques de choc électrique — NE PAS OUVRIR!

AATTTTEENNTTIIOONN::

Afin de réduire le risque de choc électrique, ne pas enlever le couvercle. Il ne se trouve à
l’intérieur aucune pièce pouvant être reparée par l’utilisateur. Confiez I’entretien et la réparation de
l’appareil à un réparateur Peavey agréé.

AAVVEERRTTIISSSSEEMMEENNTT

: Afin de prévenir les risques de décharge électrique ou de feu, n’exposez pas cet
appareil à la pluie ou à l’humidité. Avant d’utiliser cet appareil, lisez attentivement les avertissements
supplémentaires de ce manuel.

Dieses Symbol soll den Anwender vor unisolierten gefährlichen Spannungen innerhalb des Gehäuses
warnen, die von Ausreichender Stärke sind, um einen elektrischen Schlag verursachen zu können.

Dieses Symbol soll den Benutzer auf wichtige Instruktionen in der Bedienungsanleitung aufmerksam
machen, die Handhabung und Wartung des Produkts betreffen.

VVOORRSSIICCHHTT::

Risiko — Elektrischer Schlag! Nicht öffnen!

VVOORRSSIICCHHTT::

Um das Risiko eines elektrischen Schlages zu vermeiden, nicht die Abdeckung enfernen. Es
befinden sich keine Teile darin, die vom Anwender repariert werden könnten. Reparaturen nur von
qualifiziertem Fachpersonal durchführen lassen.

AACCHHTTUUNNGG::

Um einen elektrischen Schlag oder Feuergefahr zu vermeiden, sollte dieses Gerät nicht dem

Regen oder Feuchtigkeit ausgesetzt werden. Vor Inbetriebnahme unbedingt die Bedienungsanleitung lesen.

3

IIMMPPOORRTTAANNTT SSAAFFEETTYY IINNSSTTRRUUCCTTIIOONNSS

WWAARRNNIINNGG::

When using electrical products, basic cautions should always be followed, including the following:

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any of the ventilation openings. Install in accordance with manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including
amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades and a third grounding plug. The wide blade or third
prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the
point they exit from the apparatus.

11. Note for UK only: If the colors of the wires in the mains lead of this unit do not correspond with the terminals in your
plug‚ proceed as follows:

a) The wire that is colored green and yellow must be connected to the terminal that is marked by the letter E‚ the
earth symbol‚ colored green or colored green and yellow.

b) The wire that is colored blue must be connected to the terminal that is marked with the letter N or the color black.
c) The wire that is colored brown must be connected to the terminal that is marked with the letter L or the color red.

12. Only use attachments/accessories provided by the manufacturer.

13. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When
a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

14. Unplug this apparatus during lightning storms or when unused for long periods of time.

15. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in

any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

16. Never break off the ground pin. Write for our free booklet “Shock Hazard and Grounding.” Connect only to a power
supply of the type marked on the unit adjacent to the power supply cord.

17. If this product is to be mounted in an equipment rack, rear support should be provided.

18. Exposure to extremely high noise levels may cause a permanent hearing loss. Individuals vary considerably in
susceptibility to noise-induced hearing loss, but nearly everyone will lose some hearing if exposed to sufficiently
intense noise for a sufficient time. The U.S. Government’s Occupational and Health Administration (OSHA) has
specified the following permissible noise level exposures:

Duration Per Day In Hours Sound Level dBA, Slow Response

890
692
495
397
2 100

1 1⁄

2

102

1 105

1

⁄

2

110

1

⁄4or less 115

According to OSHA, any exposure in excess of the above permissible limits could result in some hearing loss. Ear plugs or protectors to the
ear canals or over the ears must be worn when operating this amplification system in order to prevent a permanent hearing loss, if exposure
is in excess of the limits as set forth above. To ensure against potentially dangerous exposure to high sound pressure levels, it is
recommended that all persons exposed to equipment capable of producing high sound pressure levels such as this amplification system be
protected by hearing protectors while this unit is in operation.

SSAAVVEE TTHHEESSEE IINNSSTTRRUUCCTTIIOONNSS!!

4

CCEELL--22AA

™™

Dual Compressor/Expander/Limiter

Thank you for purchasing the CEL-2A. You’ll find plenty of features and versatility in this single-rack space‚ dual
compressor. The CEL-2A can be operated as either two independent compressors or as a linked‚ stereo compressor with
true RMS summing. High-quality‚ voltage-controlled amplifier (VCA) and RMS-rectifier integrated circuits are used to
maintain low distortion and excellent noise performance.

This unit has fully-balanced inputs and outputs‚ with XLR and 1/4" jack connections. A special “one cable” in/out 1/4"
TRS jack has also been provided to allow the use of a standard 1/4" stereo cable to directly connect the CEL-2A to an
insert jack of a mixer.

Soft-knee topology is used for the compressor and expander functions to provide smooth transition curves. (When the
circuits become active‚ the gain change is phased in rather than instantaneously applied.) This causes the dynamic
changes to be less obvious and more aesthetically pleasing as well as being easier to adjust for the desired result.

The “downward” expander section has threshold and ratio adjustments to allow it to be used for noise reduction (slight
ratio) or a gate (high ratio). An LED lights when it is active. The compressor has attack and release controls in addition to
threshold and ratio controls for complete versatility. Any level lost due to compression can be made up by the gain
control. The limiter is an infinite ratio compressor that keeps the output from exceeding a level set by its threshold
control and has only one adjustment. It is totally independent of the compressor’s settings and can be used to stop
peaks from getting through when only mild compression (a low ratio setting in the compressor section) is desired. It has
its own LED to indicate when it has been activated.

Each section (expander‚ compressor or limiter) can be set so that it is disabled either by a threshold or ratio adjustment.
A side-chain insert (with its own enable switch) in the detector path allows manipulation or replacement of the detector
signal. Built into the side-chain are two selectable filters: a low-cut filter which reduces low frequency modulation from
the detector path and a “de-ess” filter‚ which will assist in removing sibilance (overstressing of the s‚ c and k consonants).
These functions can be used simultaneously‚ either by themselves or with an external signal applied at the rear jack.

A dual-mono/stereo link switch sums the RMS detected signal levels of each channel together to accurately represent
the stereo signal’s amplitude. This voltage is used to control both VCAs. In this mode‚ only the controls associated with
Channel A function. The gain meter of Channel B follows Channel A’s.

There is a twelve-segment LED array that shows the amount of gain reduction and a ten-segment array to indicate either
the output or input levels. By watching the gain reduction meter and the output meter‚ adjustments are readily apparent
and easy to set.

A bypass switch disengages all functions and passes the input signal to the output without processing it. It is configured
to allow the unit to be used as an unbalanced to balanced converter even when bypassed‚ so power is always required.

Please read this guide carefully to ensure your personal safety as well as the safety of your equipment.

FFeeaattuurreess

·· ccoommpprreessssoorr‚‚ lliimmiitteerr aanndd eexxppaannddeerr ffuunnccttiioonnss ssiimmuullttaanneeoouussllyy aavvaaiillaabbllee

·· ooppeerraatteess aass ttwwoo‚‚ iinnddeeppeennddeenntt ccoommpprreessssoorrss oorr aa lliinnkkeedd sstteerreeoo ccoommpprreessssoorr wwiitthh ttrruuee RRMMSS ssuummmmiinngg

·· oonnee ccaabbllee ((ppeerr cchhaannnneell)) ooppeerraattiioonn wwiitthh mmiixxeerr TTRRSS iinnsseerrttss

·· ffuullll ggaaiinn rreedduuccttiioonn mmoonniittoorriinngg ooff eexxppaannddeerr‚‚ ccoommpprreessssoorr aanndd lliimmiitt pprroocceessssoorrss

·· ffuullllyy bbaallaanncceedd iinnppuuttss aanndd oouuttppuuttss ((XXLLRR aanndd TTRRSS 11//44""))

·· ssoofftt--kknneeee ttooppoollooggyy pprroovviiddiinngg ssmmooootthh ttrraannssiittiioonn ccuurrvveess

·· eexxppaannddeerr sseeccttiioonn iinncclluuddeess tthhrreesshhoolldd aanndd rraattiioo aaddjjuussttmmeennttss

·· ssiiddee--cchhaaiinn iinnsseerrtt

·· bbuuiilltt--iinn ddee--eesssseerr aanndd llooww--ccuutt ssiiddee cchhaaiinn ffiilltteerrss

·· llooww nnooiissee cciirrccuuiittrryy

EENNGGLLIISSHH

5

((11)) LLooww--ccuutt ffiilltteerr

An 18 dB filter with a cut-off frequency of 200 Hz in the side chain (only)‚ does not filter the audio path. This
filter is used to prevent low frequency modulation (which often appears as pumping and breathing) by reducing
the affects of wind‚ stage and handling noise. If it is used with bass-only program material‚ it could prevent the
compressor from seeing the source. It does not require the external side-chain to be enabled.

((22)) DDee--eesssseerr ffiilltteerr

This filter is named after its function—it helps remove the hissing in the “sss.” By increasing the
compressor’s sensitivity to high frequency components (as in the s‚ c and k consonants) it acts more
aggressively on these sounds without lowering normal speech levels. For this circuit to function properly‚
the compressor’s attack and release controls must be set to respond very quickly (minimum settings) and
a mid- to high-compression ratio must be used. It does not require the external side-chain to be enabled.

((33)) BByyppaassss

To disable signal processing each channel of the CEL2A can be bypassed. The internal circuitry maintains
input and output isolation even when bypassed‚ allowing the unit to function as an unbalanced to
balanced converter if needed. To provide this feature‚ power must be on even when the unit is bypassed. A
two-color status LED is provided to show the channel’s condition. When the unit is operating the LED is
green (processing happening)‚ when the LED is red‚ the unit is bypassed.

((44)) EExxtteerrnnaall SSiiddee--cchhaaiinn EEnnaabbllee

The side-chain is an insert loop inserted into the detector path so that the signal sent to the detector can
be rerouted through an external device or replaced altogether. This switch enables the rear panel jack and
external processing. It has no affect on the side-chain low-cut or de-ess filters‚ which operate
independently‚ but any signal applied to the external jack will pass through them if they are enabled.

((55)) EExxppaannddeerr TThhrreesshhoolldd

This sets the level at which the downward expander begins operation. If the input signal drops below
the thresholds set point‚ the expander fades it out according to the slope (ratio) set by the ratio control.
The soft-knee design smooths the transition from off to active by dynamically shifting the slope through
the transition point. The attack and release times are preset. An LED has been provided to show
expansion activity.

((66)) EExxppaannddeerr RRaattiioo ((GGaattee))

The expander ratio is determined by dividing the input level by the output level. A ratio of 1:5 signifies
that the output level has dropped five times as fast as the input (downward expanded). Ratios of 1:1.2 to
1:2 are typically used to eliminate background noise and to dampen room reverberations. Higher ratios are
used when gating is required. Expansion is eliminated when the ratio is set to 1:1.

FF RR OO NN TT PP AA NN EE LL

6

((77)) CCoommpprreessssoorr TThhrreesshhoolldd

This sets the point that compression action begins. Any signal above this threshold will be compressed at
the amount set by the ratio control. If it drops below this point‚ the compressor has no affect. At the
maximum setting‚ the compressor will be out of circuit for all signals except very high peaks. At the
minimum setting‚ the source will be continuously compressed.

((88)) CCoommpprreessssoorr RRaattiioo

This varies the amount of compression. It is the ratio of the input level to the output level. A ratio of 4:1
signifies that the input level has increased four times as fast as the output (the dynamic range is
compressed by a factor of 4). If the ratio is 1:1 the output exactly tracks the input and there is no
compression. Ratios of 2:1 to 4:1 are typically used for vocals and musical instruments. High ratios
provide a soft limiting function‚ since the compressor uses a soft-knee design. To disable compression‚
set the ratio to 1:1.

((99)) CCoommpprreessssoorr AAttttaacckk

Sets the speed at which the compressor circuit responds to an increase in the input level. Minimum
settings allow it to act quickly so that fast transients do not get through. High settings slow down the
response time to let the signal settle before acting upon it. (Useful for those situations when you want
percussive attacks but still need compression.)

((1100)) CCoommpprreessssoorr RReelleeaassee

Sets the time which the compressor circuit takes to track the input after a drop in level. Low settings will
cause the compressor to follow the signal closely so that rapid input changes will not be lost during
compression. Higher settings smooth out compression effects.

((1111)) LLiimmiitteerr TThhrreesshhoolldd

The limiter is an infinite ratio compressor. The threshold control defines the point that absolute limiting
begins. The limit LED will light when this threshold has been exceeded. To disable limiting‚ set this
control to maximum.

((1122)) GGaaiinn

Adjusts the post-processing gain to make up for compression loss. It does not adjust the input level. The
input levels should be set by the source equipment to 0 dBu or +4 dBu for best noise performance. The
input and output levels are monitored by an LED meter so that gain can be applied to the signal. A twelve­segment LED array tells how much gain reduction is being applied to the signal. If this meter is not active
there is no change to the input signal. It is very useful for making adjustments‚ since the action of all
controls is easily seen.

((1133)) IInnppuutt//OOuuttppuutt LLeevveell MMeetteerr SSwwiittcchh

This is a peak indicating meter that is connected to either the output or the input. When in the out
position‚ the LEDs display the output and when depressed‚ the LEDs display the input.

((1144)) SStteerreeoo LLiinnkk

If the compressor is to be used with stereo signals‚ the link switch should be pressed. This gives true
RMS summing for an accurate representation of the levels of Channel A and B and locks them together to
maintain the stereo image during processing. When the link switch is pressed‚ Channel A’s controls
become the masters and affect both channels. The controls for Channel B are disabled. The meters of
Channel B will still reflect the VCA and input/output levels‚ just as in the dual-mono mode.

((1155)) PPoowweerr SSwwiittcchh

Power is applied to the unit when this switch is pressed.

7

RR EE AA RR PP AA NN EE LL

((1188)) AACC MMaaiinnss IInnppuutt

Connect the appropriate line cord to this connector to provide power to the unit. Damage to the equipment
may result if improper line voltage is used. Operate only with the specified AC input voltage applied.

((1199‚‚ 2200‚‚ 2266‚‚ 2277)) BBaallaanncceedd OOuuttppuuttss

XLR and 1/4" TRS‚ servo-balanced‚ line level outputs. Pin 2 (tip) is the positive phase‚ pin 3 (ring) is the
negative phase. If unbalanced outputs are used the negative phase must be grounded. The XLR and 1/4"
TRS jacks are wired directly in parallel.

((2211‚‚ 2288)) IInnppuutt//OOuuttppuutt

This unbalanced 1/4" TRS jack has both input and output signals. It is configured so that a standard (not
cross wired) stereo shielded cable can be used to plug into the TRS insert of a mixer. (The tip is input‚ ring
is output‚ which match the insert jack wiring of all current Peavey mixers.)

((2222‚‚ 2233‚‚ 2299‚‚ 3300)) BBaallaanncceedd IInnppuuttss

XLR and 1/4" TRS balanced inputs for line level inputs. Pin 2 (tip) is the positive phase‚ pin 3 (ring) is the
negative phase. If unbalanced inputs are used the negative phase must be grounded. The XLR and 1/4"
jacks are wired directly in parallel.

((2244‚‚ 2255)) DDeetteeccttoorr SSiiddee--cchhaaiinn IInnsseerrtt

A 1/4" stereo (TRS) jack which allows an external device to be inserted into the detector’s signal path or
an alternate signal can be brought in to be used as a key. The tip has the send signal and the ring is the
return input. A switch in the jack normally connects the return (ring) to the send (tip) until a plug is
inserted. To use as a ducker‚ apply the controlling signal to the ring connection and adjust the compressor
controls to set the amount and threshold.

8

SSeettttiinngg tthhee CCoonnttrroollss

If you are starting from scratch or have something out of whack and do not know exactly what to adjust‚
begin by setting the controls so that all functions are disabled. Here are the control positions for this:

EExxppaannddeerr

Threshold
Ratio

CCoommpprreessssoorr

Threshold
Ratio
Attack
Release
Limit
Gain
Low Cut
De-ess

min (off)
min (1:1)

max (+20 dB)
min (1:1)
center (50 mSec)
center (.5 sec)
max (off)
min (0 dB)
out (off)
out (off)

Naturally‚ the controls that need to be adjusted depend on what you want to accomplish. Below are some
suggestions to get you up and running. Follow the order listed and leave the controls in the disabled
positions if that particular function is not required.

1. Determine the maximum output level and adjust the

LLiimmiitt TThhrreesshhoolldd

so that‚ at the loudest
peaks‚ the output level never exceeds this point. (The action of the limiter can be seen on the
GGaaiinn RReedduuccttiioonn MMeetteerr

. If it never activates‚ there will be no LED activity.) One way to do this is
to deliberately increase the input to the compressor until the desired maximum level is
exceeded‚ then turn the

LLiimmiitt TThhrreesshhoolldd

control counter-clockwise until it limits it to the correct
gain. Reset the input level to the nominal setting (0 dBu average). An alternate method is to
turn down the

LLiimmiitt TThhrreesshhoolldd

until gain reduction has just occurred. Then‚ adjust the output
level control to set the desired output level. If the limit is set too low‚ the signal will lose its
dynamic range and the sound will be squashed.

2. To set up a noise gate‚ first turn the

EExxppaannddeerr RRaattiioo

control fully clockwise (1:5). During quiet
passages of the source (between songs‚ when the mics are not being used‚ etc.) adjust the
EExxppaannddeerr TThhrreesshhoolldd

clockwise until gain reduction is indicated (a reduction of -9 dB is a good

starting point). Re-adjust the

EExxppaannddeerr RRaattiioo

to set the desired gating action when the source
changes from noise to signal. A setting of 1:1.2 has little action and can tolerate higher
threshold settings without coloring the sound; 1:5 will cause an abrupt turn on and off when
the signal changes and will probably need a lower threshold setting to prevent the signal from
dropping off when you don’t want it to. You may need to go back and adjust the threshold after
the ratio has been changed since the soft-knee circuitry has more affect at lower ratios‚ making
the transition point less obvious.

3. For typical voice compression‚ set the

CCoommpprreessssoorr RRaattiioo

control to 4:1 (a range of 2:1 to 6:1 is

common) and adjust the

CCoommpprreessssoorr TThhrreesshhoolldd

until the desired amount of gain reduction is
seen on the meter. This is a personal preference but continuous gain reduction greater than -9
dB (especially with higher ratios) could be excessive and create pumping/breathing artifacts as
the signal rises and falls. Lower ratios will have a more gentle affect. Adjust the

AAttttaacckk

control
to low values to suppress leading-edge spikes or to high values to let them through (often used
to pass through the click of a drum hit). The

RReelleeaassee

control is adjusted to smooth the
transition as it comes out of compression. Too quick a release will cause the signal to sound
artificial. A fast attack and a short release time will cause the compressor to track the signal
very closely (and keep the dynamic range very limited)‚ but can severely impact the sound. (A
50 millisecond attack and a .5 second release time are good starting points.)

9

4. To use as a de-esser‚ engage the side-chain

DDee--eessss

filter. Set the

AAttttaacckk

and

RReelleeaassee

controls at

minimum and the

CCoommpprreessssoorr RRaattiioo

to 4:1. Speak or sing a phrase with heavy sibilance (lots of

“Ss”) and adjust the

CCoommpprreessssoorr TThhrreesshhoolldd

until 6–9 dB of gain reduction occurs at the peaks.
This will get you close to where you need to be. Modify the settings for more or less reduction.
If the ratio is too high or the threshold is too low the compression may be exaggerated‚ causing
the material to drop excessively in volume (duck) during sibilance.

5. When heavy bass or low frequency noise causes the compressor to drop levels unnecessarily‚
the side-chain

LLooww--ccuutt

filter can be used. When activated‚ the

CCoommpprreessssoorr TThhrreesshhoolldd

should be
reset since a large portion of the signal usually contains low frequency components. The bass
will have less affect on the compressor and the signal will sound more natural. If the source
contains only bass frequencies‚ this may prevent the compressor from working at all and the
bass will pass through unchanged.

6. After all the settings are made‚ adjust the

GGaaiinn

control for a 0 dBu (or +4 dBu) average on the

output meter.

10

CCEELL--22AA

SSPPEECCIIFFIICCAATTIIOONNSS

CCoonnttrrooll AAddjjuussttmmeenntt RRaannggee

Expander Threshold -80 dBu to +10 dBu

Expander Ratio 1:1 (off) to 1:5 (gate)

Expander Attack .5 mSec (fixed)

Expander Release 200 mSec (fixed)

Compressor Threshold -40 dBu to +20 dBu

Compressor Ratio 1:1 (off ) to infinite:1 (limit)

Compressor Attack .5 mSec to 100 mSec

Compressor Release .05 sec to 2 sec

Limiter Threshold 0 dBu to +20 dBu (off )

Limiter Attack .5 mSec (fixed)

Limiter Release 50 mSec (fixed)

Gain Recovery 0 dB to +20 dB

IInnppuutt IImmppeeddaannccee CCoonnnneeccttoorr

XLR (balanced) 20K oHms XLR

Pin 1 = ground
Pin 2 = positive phase
Pin 3 = negative phase

TRS (balanced) 20K oHms

1

⁄4"
Sleeve = ground
Tip = positive phase
Ring = negative phase

1

⁄4" In/Out Phone (unbalanced) 10K oHms

1

⁄4" phone
tip = input
ring = output
(see control functions above)

TTHHDD::

Less than 0.1%‚ 20 Hz–20 kHz (10 Hz–80 kHz BW)

SSiiggnnaall--ttoo--nnooiissee::

97 dB (0 dBu reference level)

FFrreeqquueennccyy RReessppoonnssee::

20 Hz–64 kHz (+0 dB/-1 dB)

OOuuttppuutt IImmppeeddaannccee::

100 oHms (XLR and

1

⁄4")

MMeetteerrss::

Two 12-segment LED arrays‚ two 10-segment LED arrays‚ two activity LEDs

DDiimmeennssiioonnss::

19" W x 9.25" D x 1.75" H

WWeeiigghhtt::

7.2 lbs (3.3 kg)

PPoowweerr RReeqquuiirreemmeennttss::

Domestic: 100–120 VAC 50/60 Hz (15 watts nominal); Export: 230 VAC 50/60 Hz

(15 watts nominal)

11

LLeeaadd VVooccaall

Less is more here, with the primary job of the CEL-2A being a non-invasive massaging of the vocalist’s dynamic
range so it fits within the system and venue capacities. Thus, the compressor’s threshold can be set high
enough (-5) to give the vocalist complete dynamic freedom for most of the song, engaging the unit only during
loud passages and sharp transients. A ratio of 3:1 should suffice, but gifted vocalists may need more clamping
at 4:1. Setting the attack control to 50mS will allow the singer’s unique timbre to punch through while keeping
attacks from becoming destructive. Conversely, a release setting around .4S will smooth phrases without
removing their vitality. For the expander, it may be wise to leave it disengaged since soft passages may be lost if
the background noise forces a high threshold setting. However, it is worth an attempt to engage the gate to
bring the vocalist mentally closer to the audience with reduced room encroachment. Try setting the threshold
while the mic is silent by raising its value until its LED lights, indicating it is shut. Next, place the expansion
gate control at the nominal 1:2 position and watch the LED ladder above for a reduction around -6 (gentle
shutting) to -12 (hard slam). During soundcheck, reduce or increase the expansion setting so the gate shuts
enough between passages to prevent background noise from entering the mic while still allowing soft passages
to be heard. If the vocalist is using a hyper-cardioid condenser mic, there may be excessive sibilance
(overstressing of the “s”and “c” consonants) in the system. The CEL-2A features a new de-essing circuit that is
engaged by a simple press of the associated switch. This circuit is designed to remove the annoying sibilance
without destroying the articulation necessary for comprehension. At the lower end of the frequency scale, the
low-cut filter should be activated when the vocal in use contains little bass information, such as a soprano, alto,
tenor or lead. Removing unneeded information will dramatically improve the quality of the vocal and make the
engineer’s job much easier. The final adjustment is to the limiter, the safety valve of the signal. For lead vocals,
set the control to 15, then sit back and enjoy the show (at least until the next round of feedback occurs).

BBaacckkggrroouunndd VVooccaall

Like a lead vocalist, the background vocalists (or BGV) may need some level control assistance. Unlike lead
vocalists, however, BGV benefit from higher compression due to the desire for consistent levels among
themselves and “one-notch-down” settings behind the lead vocalist. Therefore, a ratio from 4:1 up to 6:1 is not
uncommon with the threshold set to -10. For the attack, a quick-response time of 35mS will deliver the
smoothness necessary and a release time of .75S will keep the level right at the end of each phrase. Expansion
gate settings are similar to lead vocalists’ with a threshold setting of -25 and a ratio of 1:2, dependent on
ambient stage levels. The limiter may be set lower than the lead at 12, if conditions permit. If the BGV contain
baritone or bass, leave the low-cut filter out and start the session with the de-esser disengaged to keep the
sparkle in the song.

KKeeyybbooaarrddss

Current hard and soft synths produce a bewildering array of sounds, each varying in tone and level. Creating
consistent volume across the presets can be accomplished inside the keyboard, but is seldom done, leaving
the audio engineer with the duty of level control. If the keyboard in question is an electronic synthesizer, the
expansion gate can be combined with the compressor to achieve an excellent signal to noise ratio. With the
expansion threshold set about -20 and the ratio at 2.5:1, the residual noise of the keyboard can be kept at
bay. If this setting masks some soft string or pad patches, reduce the threshold to -30. For compression,
listen to the sounds the keyboardist is favoring. Organ and string patches typically have slower attacks and
require appropriate attack and release values around 50mS and .6S, respectively. Percussive sounds like
acoustic piano and bell need quicker response times of 30mS and .4S to follow their envelope. A compressor
threshold of -10 and a ratio of 3:1 should keep the majority of keyboard tones within a usable range. Finally,
the limiter can be set at 15 and the low-cut and de-esser circuits left out to preserve as much of the
keyboardist’s tone as possible.

CCEELL--22AA AApppplliiccaattiioonn GGuuiiddee

The key to successfully using a compressor is to visualize the signal’s envelope and then create a scheme that closely tracks
that flow. Thus, a kick drum, with its sharp attack and fast decay, requires a tracing envelope with a quick attack, somewhat
heavy clamping, and fast release of the compressed signal. The CEL-2A has enough parameter control to “dial-in” almost any
desired configuration. With the unique architecture of the CEL-2A, the gate, compressor and limiter act independently on the
signal, then return the processed signal to the output, thereby insuring the shortest, cleanest path. These settings typically
work best on individual instruments brought into the CEL-2A and returned through a channel insert. It is worth noting, personal
taste is an integral part of any audio endeavor, including compression, so feel free to adjust these settings for preference.

12

AAccoouussttiicc GGuuiittaarr

If the guitar is mic’d, it will usually have a darker tone than a signal derived through a built-in pickup. To address the
tone of a mic’d acoustic, the key is to allow enough of the initial percussive phase of the tone to pass intact. At the
same time, enough control must be exercised to prevent the tail of the signal from overlapping the next strum. If the
ambient noise is low, leave the expansion gate out of the path. However, if the background is distracting, set the
expansion threshold at -40 and the ratio at 1:2. While this will not yield a studio-level noise floor, it will reduce the
noise to some extent without chopping off the ring of the instrument. On the compressor, try setting the threshold
at -5 and the ratio at 2:1 for a light touch on the peaks. If the guitarist uses a pick, place the attack control around
35mS and the release at .5S. For finger picking, use a slower attack of 50mS and a release of .4S. The limiter can be
set at 15 with the de-esser off. If the guitar is a Dreadnought or other bass heavy style, the low-cut filter can be left
out unless the sound becomes boomy, then engaged on a trial basis. For smaller instruments, the low-cut filter may
be more appropriate, especially if other instrumentation is present in the mix. Acoustic guitars with built-in bridge
pickups may use the above settings with slightly quicker attack times and a higher 3:1 compression ratio.

EElleeccttrriicc GGuuiittaarr

It is usually unwise to alter the sustain characteristics of electric guitars since sustain is such an integral part of
the guitarist’s tone. The CEL-2A can best serve as a noise gate for tube amps and floor-based effects processors
and as a final limiter for unforeseen incidents. To that end, the expansion gate threshold may be placed at -30 with
a gate ratio of 1:3. The compressor can be left out of the signal path, unless the guitarist cannot or will not control
the dynamic range. A limiter setting of 12 will allow enough room for screaming leads, but with the assurance
things won’t get out of control.

BBaassss GGuuiittaarr

Neck-through bodies and innovative tensioning systems have made today’s basses capable of incredible sustain.
However, for even more sustain, a little compression can go a long way. If the bass and amp are quiet, the expansion
can be bypassed, but may be brought in as with the electric guitar if necessary. Maintaining consistent volume
among all the strings is made easier with the CEL-2A. Start by setting the downward expander threshold at -35 and
the ratio at 1:2.5. The compressor’s threshold can be placed at -10, the ratio at 3:1, attack at 30mS and release at .5S.

KKiicckk DDrruumm

Allowing the initial phase of the beater/head contact to pass unaltered is a key component in maintaining peace with
the drummer. Compression can begin after the aural signature of the kick drum is past. Set the compressor’s threshold
at -5, the ratio at 4:1, the attack at 20mS, and the release at .2S and the limiter at 15. For the expander, try a threshold
setting of -30 and the ratio at 1:2 to keep the passages between beats quiet. For toms, a similar arrangement can be
made with some tweaking probably necessary on the expander to keep ambient noise out of each mic.

RReeccoorrddiinngg

Sometimes there is nothing worse than a recording made directly from a board mix. A compressor can improve the
situation by reducing the excessive dynamic range of a live event to a manageable level and by preventing
overshoots onto tape. If recording to cassette, a compressor can also keep the recording out of the noise floor.
Set the expander threshold to -30 with a ratio of 1:2. The compressor’s threshold can be positioned at -15, with a
ratio of 4:1, an attack around 20mS and a release of .5S.

MMoonniittoorr WWoorrlldd

If individual channels can be used, detailed control over monitors is possible. The key is to set the threshold high but
hit the signal hard to prevent feedback instead of increasing feedback, as compressors can sometimes do. The
expander must be set low, with a threshold of -40 and a ratio of 1:1.5 to 2. The compressor’s threshold must be set at
0, with a strong ratio of 5:1 or higher, a quick attack of 25mS and a release of .3S. If the vocalists push harder against
the compressor, feedback and frustration can occur, making the bypass switch a handy tool in monitor world.

BBrrooaaddccaasstt

Keeping as much level as hot as possible for as long as possible is the goal. To that end, the expander can be
ignored or set nominally at -45 threshold and 1:1.5 ratio. The compressor’s ratio, however, can be set at 6:1, with a
threshold of -20 and an attack of 15mS and a release time of .6S.

13

DEUTSCH

CEL-2A

Dualer Kompressor/Expander/Limiter

Wir möchten uns bei Ihnen dafür bedanken, dass Sie sich für den CEL-2A entschieden haben! Dieser nur eine Rack-Höhe
messende duale Kompressor bietet Ihnen zahlreiche Funktionen und große Vielseitigkeit. Der CEL-2A kann entweder als
zwei unabhängige Kompressoren oder als verknüpfter Stereokompressor mit echter RMS-Summierung betrieben werden.
Hochwertige, spannungsgeregelte Verstärker- und integrierte RMS-Gleichrichterschaltkreise gewährleisten geringe
Verzerrung und hervorragendes Rauschverhalten.

Das Gerät ist mit vollständig symmetrierten Ein- und Ausgängen mit XLR- und 1/4"-Klinkenanschlüssen ausgestattet.
Daneben verfügt der CEL-2A über eine spezielle 1/4"-TRS-"Ein-Kabel"-Eingangs- und Ausgangsklinke, sodass das Gerät
mit einem genormten 1/4"-Stereokabel direkt an die Eingangsklinke eines Mischpults angeschlossen werden kann.

Dank der Soft-Knee-Topologie zeichnen sich Kompressor- und Expanderfunktionen durch gleichmäßige Übergangskurven
aus. (Werden die Schaltkreise aktiviert, erfolgt die Veränderung der Verstärkung allmählich anstatt plötzlich.)
Dynamikwechsel erfolgen daher weniger unvermittelt und bieten damit ein angenehmeres Hörerlebnis, und sie lassen
sich leichter justieren, um das gewünschte Ergebnis zu erzielen.

Die „abwärts gerichtete" Expanderstufe verfügt über Schwellen- und Verhältnisjustierungen, so dass sie zur
Rauschverringerung (niedriges Verhältnis) oder als Gate bzw. Sperre (hohes Verhältnis) eingesetzt werden kann. Wird sie
aktiviert, leuchtet eine LED auf. Neben Schwellen- und Verhältnisregelung (Attack und Release) verfügt der Kompressor
auch über Einschwing- und Auslöseregelung, sodass er umfassende Vielseitigkeit bietet. Kompressionsbedingte
Pegelverluste können durch die Gain-Regelung wieder ausgeglichen werden. Der Limiter ist ein Kompressor mit
unendlichem Verhältnis, der verhindert, dass die Leistung einen durch die Schwellenregelung festgelegten Pegel
überschreitet, und der über nur eine Einstellung verfügt. Er ist völlig unabhängig von den Einstellungen des Kompressors
und kann dazu eingesetzt werden, Spitzen zu verhindern, wenn lediglich eine geringe Kompression (eine niedrige
Verhältniseinstellung in der Kompressorstufe) erwünscht ist. Eine spezielle LED zeigt an, wenn er aktiviert ist.

Jede Stufe (Expander, Kompressor oder Limiter) kann so eingestellt werden, dass sie durch Schwellen- oder
Verhältnisjustierung deaktiviert werden kann. Ein Sidechain-Insert (mit eigenem Aktivierungsschalter) im Detektorweg
ermöglicht Veränderung oder Austausch des Detektorsignals. In die Sidechain eingebaut sind zwei wählbare Filter: Ein
Tiefpassfilter, der die Niederfrequenzmodulation vom Detektorweg verringert, sowie ein „De-Ess"-Filter, der die
Beseitigung von Zischen (Überbetonung der Konsonanten s, c, z und k) unterstützt. Diese Funktionen können gleichzeitig
genutzt werden, und zwar unabhängig oder mit einem externen Signal über die Klinke auf der Rückseite.

Ein Dual-Mono/Stereo-Verbindungsschalter summiert die RMS-ermittelten Signalpegel jedes Kanals und gibt so präzise
die Amplitude des Stereosignals wieder. Mit dieser Spannung werden beide spannungsgeregelten Verstärker geregelt. In
diesem Modus arbeiten nur die mit Kanal A verbundenen Regler. Der Gain-Messer von Kanal B richtet sich nach dem
Gain-Messer von Kanal A.

Ein Feld mit zwölf LED-Anzeigen zeigt die Stärke der Gain-Verringerung, ein Feld mit zehn LED-Anzeigen zeigt Ausgangs­oder Eingangspegel an. Durch Beobachten des Gain-Verringerungsmessers und des Ausgangspegelmessers lassen sich
Justierungen rasch und problemlos durchführen.

Ein Bypass-Schalter deaktiviert sämtliche Funktionen und leitet das Eingangssignal zum Ausgang, ohne es zu
verarbeiten. Er ist so konfiguriert, dass das Gerät selbst im Bypass-Modus als unsymmetrierter oder symmetrierter
Wandler eingesetzt werden kann, weshalb es immer mit Strom versorgt werden muss.

Lesen Sie sich diese Anleitung bitte sorgfältig durch, damit sowohl Ihre Sicherheit als auch die Ihrer Ausrüstung
gewährleistet ist.

MMeerrkkmmaallee

·

KKoommpprreessssoorr--,, LLiimmiitteerr-- uunndd EExxppaannddeerrffuunnkkttiioonneenn kköönnnneenn gglleeiicchhzzeeiittiigg ggeennuuttzztt wweerrddeenn..

·· BBeettrriieebb aallss zzwweeii uunnaabbhhäännggiiggee KKoommpprreessssoorreenn ooddeerr aallss vveerrkknnüüppfftteerr SStteerreeookkoommpprreessssoorr mmiitt eecchhtteerr RRMMSS--SSuummmmiieerruunngg
mmöögglliicchh

·· BBeettrriieebb mmiitt eeiinneemm KKaabbeell ((pprroo KKaannaall)) mmiitt MMiisscchhppuulltt--TTRRSS--IInnsseerrttss

14

((11)) TTiieeffppaassssffiilltteerr

Ein 18 dB Filter mit einer Grenzfrequenz von 200 Hz in der Sidechain (nur hier), der den Audioweg nicht
filtert. Mit diesem Filter wird die Niederfrequenzmodulation verhindert (die häufig als Pumpen und Atmen
wahrnehmbar ist), indem die Wirkung von Wind sowie Geräuschen auf der Bühne bzw. durch die
Handhabung verringert wird. Wird er mit reinem Bassprogrammmaterial eingesetzt, könnte dies
verhindern, dass die Quelle trotz Kompressor durchdringt. Ein Aktivieren der externen Sidechain ist nicht
erforderlich.

((22)) ““DDee--EEssss””--FFiilltteerr

Der Filter ist nach seiner Funktion benannt – er unterstützt die Beseitigung von Zischen. Durch Steigern
der Empfindlichkeit des Kompressors gegenüber hochfrequenten Komponenten (wie in den Konsonanten
s, c, z und k) reagiert er stärker auf diese Klänge, ohne dass der normale Sprechpegel gesenkt werden
muss. Damit diese Schaltung korrekt funktioniert, müssen die Einschwing- und Auslöseregler des
Kompressors so eingestellt sein, dass sie sehr rasch ansprechen (minimale Einstellungen), und es muss
ein mittleres bis hohes Kompressionsverhältnis verwendet werden. Ein Aktivieren der externen Sidechain
ist nicht erforderlich.

((33)) BByyppaassss

Zum Deaktivieren der Signalbearbeitung kann jeder Kanal des CEL-2A umgangen werden. Durch die
interne Schaltung werden Eingang und Ausgang selbst im Bypass-Modus isoliert, sodass das Gerät bei
Bedarf als unsymmetrierter oder auch symmetrierter Wandler genutzt werden kann. Um diese Funktion
nutzen zu können, muss der Strom eingeschaltet sein, selbst wenn das Gerät umgangen wird. Eine
zweifarbige Status-LED zeigt den Zustand des Kanals an. Ist das Gerät in Betrieb, leuchtet die LED grün
(eine Verarbeitung erfolgt), wird das Gerät umgangen, leuchtet die LED rot.

((44)) EExxtteerrnnaall SSiiddee--cchhaaiinn EEnnaabbllee

Die Sidechain ist eine Insert-Schleife, die in den Detektorweg eingeschleift wird, sodass das an den
Detektor gesendete Signal durch ein externes Gerät umgeleitet oder insgesamt ausgetauscht werden
kann. Mit diesem Schalter werden die Klinke auf der Rückseite und externe Effektgeräte aktiviert. Er hat
keine Auswirkungen auf Sidechain-Tiefpass- oder „De-Ess"-Filter, die unabhängig arbeiten, aber jedes an
die externe Klinke gesendete Signal wird durch sie geleitet, wenn sie aktiviert sind.

Funktionen an der Vorderseite

·· VVoollllssttäännddiiggee ÜÜbbeerrwwaacchhuunngg ddeerr GGaaiinn--VVeerrrriinnggeerruunngg vvoonn EExxppaannddeerr--,, KKoommpprreessssoorr-- uunndd LLiimmiitteerr--PPrroozzeessssoorreenn

·· VVoollllssttäännddiigg ssyymmmmeettrriieerrttee EEiinn-- uunndd AAuussggäännggee ((XXLLRR uunndd TTRRSS 11//44""))

·· SSoofftt--KKnneeee--TTooppoollooggiiee ggeewwäähhrrlleeiisstteett gglleeiicchhmmääßßiiggee ÜÜbbeerrggaannggsskkuurrvveenn

·· EExxppaannddeerrssttuuffee mmiitt SScchhwweelllleenn-- uunndd VVeerrhhäällttnniissjjuussttiieerruunngg

·· SSiiddeecchhaaiinn--IInnsseerrtt

·· EEiinnggeebbaauuttee „„DDee--EEssss""-- uunndd TTiieeffppaassss--SSiiddeecchhaaiinn--FFiilltteerr

·· GGeerrääuusscchhaarrmmee SScchhaallttuunngg
