ADI-Q
Application:
Active Sound system Direct interface for:
Guitars
Bass Guitars
Instrument amplifier Preamp output
Description:
The ADI-Q combines the features of a phantom-powered active Direct Interface with a 3-band
EQ in a compact package. The ADI-Q allows the instrumentalist to control the EQ sent to the
sound system and if desired, to their local amplifier. The ADI-Q is especially useful when the
musician is not using an instrument amplifier but playing directly through the sound system and
monitors. The ADI-Q can also be used as an EQ unit without using the sound system connection
by using an external 15VDC supply. This allows the ADI-Q to be used in a guitar stomp box
chain or combined with the ADI-C as when both EQ and dynamics are required.
So far we have only discussed the applications. But the EQ is the real story. The sweepable mid
EQ control allows precise adjustment over the critical frequency range of most instruments. The
high frequency control has an advantage over most standard treble controls. It allows the highs
to be boosted without emphasizing the real high harsh sounds. The bass control frequency is set
to control the low end without becoming boomy. As always, using EQ to cut offending
frequencies is often the most effective approach. The ADI-Q has 10 dB of boost but a full 15 dB
of cut.
Features:
Active High impedance Input
Bass Control (Shelving)
Mid Sweep EQ control (Sweepable 120 Hz-4 kHz)
High EQ (Broad bandwidth)
Local amplifier output
Local output Processed or Unprocessed switch
Balanced Mic level output
Ground lift switch
Phantom power or external 15VDC operation (external power supply optional)
Rugged construction
Connections and Controls:
¼” Instrument Input
¼” Local Amplifier Output
Local output Processed or Unprocessed switch
Male XLR Output
Bass control
Mid EQ Level
Mid EQ Frequency
Treble
Ground Lift Switch
Page 2
Processed/Not processed local output switch
15VDC Input for optional external power supply
Specifications:
Frequency Response:
Flat 20 Hz to 20 kHz
Input Impedance:
220k Ohms
Attenuation XLR:
-17 dB into 2.2k Ohm input
Attenuation 1/4" amplifier output:
0 dB
EQ Controls:
Low: +15 / -15 dB @ 80 Hz
Mid: +/- 15 dB @ 120 Hz to 4 kHz
High: +15 / -15 dB @ 10 kHz
Noise: XLR < -104 dBu (22 Hz to 22 kHz BW)
¼” < -88 dBu (22 Hz to 22 kHz BW)
THD + Noise:
< 0.015% at 1 kHz
Power Requirement:
Phantom supply: +48V 3 mA
External supply: +15V 3 mA
Use Peavey 30901986 (Optional)
Dimensions:
1.6 x 4 x 4 inches (H x W x D)
41 x 104 x 104 mm (H x W x D)
Weight:
10 Ounces
0.29 kg
