PeakTech® 4130 PeakTech® 4135 PeakTech® 4140

Operation manual

Digital Spectrum Analyzer

Content

1. Safety introduction

1.1. Safety terms and symbols

1.2. Safety Symbols on the product

1.3. Maintenance and cleaning

2. Brief introduction of Digital Spectrum Analyzer

Chapter 1 Getting started

Chapter 2 Basic operation

3. Basic Settings

4. SPAN

5. Sweep and Function Settings

6. Sweep

7. Trigger

8. Trace

9. Marker Measurement

10. Peak Search

11. Marker->

12. AUTO Tune

13. Display

14. Preset

15.System Setup

16. Source

17. Measure

Chapter 3 Remote control

18. Specifications

Chapter 4 Appendix

Overview

Chapter 1: Getting started

This chapter introduces the front and rear panels, user interface and notes for first operation of the Spectrum Analyer.

Chapter 2: Front and Rear panel operation

This chapter describes the functions of the keys on the front panel, and introduces menu functions of each key in detail.

Chapter 3: Remote Control

This chapter introduces remote control methods of the Spectrum Analyzer.

Chapter 4: Appendix

This chapter provides the accessories list and service and support information of the Spectrum Analyzer.

1. Safety introduction

This product complies with the requirements of the following European Community Directives: 2004/108/EC (Electromagnetic Compatibility) and 2006/95/EC (Low Voltage) as amended by 2004/22/EC (CE-Marking).

To ensure safe operation of the equipment and eliminate the danger of serious injury due to shortcircuits (arcing), the following safety precautions must be observed.

Damages resulting from failure to observe these safety precautions are exempt from any legal claims whatever.

Before operating this instrument, read the following safety precautions to avoid injury and prevent damage to this product or any products connected to it. For safe operation, be sure to operate this instrument in accordance with the provisions.

 Use proper power cord

Only power cord that is recognized by the country where this instrument is located is allowed.

 Reliable grounding

This product is grounded through the grounding wire of the power cord. To avoid electrical shock, before connecting any input or output terminal of the product, make sure reliable connection between the grounding terminal of the power cord of this product and protective earth terminal.

 Check all terminal ratings

Check all ratings and markings on the product to avoid the impact of fire and excessive current, please consult the manual for further ratings information before any connections.

 Overvoltage protection

Ensure that no excessive voltage (such as voltage caused by lightning or other large voltage) reach the product. Otherwise the operator may have a risk of electric shock.

 Do not operate without cover

Do not operate the Spectrum Analyzer with covers or panels removed.

 Use proper fuse

Only fuse specified by the Spectrum Analyzer is allowed.

 Do not expose circuit

Do not touch exposed connectors and components when the unit is powered.

 Do not operate with suspected failures  If you suspect a failure of this product, please contact PEAKTECH authorized maintenance

personnel to detect. Any maintenance, adjustment or parts replacement must be performed by PeakTech® authorized maintenance personnel.

 Keep proper ventilation

Try to ensure good ventilation, bad ventilation will cause temperature increase of the instrument, thereby causing damage to it. Keep good ventilation when operating, check the vents and fan regularly.

-1-

 Operation environment

To avoid internal short circuit or electric shock, do not operate the instrument in a damp environment. Do not operate in an explosive atmosphere. To avoid equipment damage or personal injury, do not operate the instrument in an explosive atmosphere.

 Clean and dry

Keep product surface’s clean and dry to avoid dust or air moisture affecting the performance of the instrument.

 Electrostatic protection

It may cause damage to the instrument if interface is with static electricity, so operate at antistatic area as much as possible to avoide static electricity when handling and operating. Ground the inner and outer conductors of interface briefly to discharge static electricity before connecting cable to the instrument.

 Handling

To avoid instrument sliping down during handling which may damage the keys, knob or interfaces and other parts on the panel, please pay attention to handling safty

1.1. Safety terms and symbols

Terms in this guide. The following terms may appear in the guide:

Caution

Caution statement indicate the conditions and behaviors that may cause product damage or loss of data.

Warning! Warning statement indicate the conditions and behaviors that may endanger the lives and safety of the operating personnel.

1.2. Safety Symbols on the product

The following terminologies may appear on this product:

 Danger!

Indicates an immediate injury once you carry out this operation.

 Warning!

Indicates a probable damage to this product or other devices that is connected with it once you carry out this operation.

 Caution!

Indicates a protential hazard once you carry out this operation.

The following symbols may appear on the product:

-2-

1.3. Maintenance and cleaning

Maintenance:

Do not place the instrument in the sunlight for a long time.

Clean:

Clean the instrument regularly according to using status. Method is as follows:

1. To avoid electric shock, disconnect power before cleaning work.

2. Wipe the loose dust on the outside of the instrument with soft moist but not dripping cloth (use mild detergent or water, but not dissolved thinner, otherwise it will damage the designation strip or plastic parts). Be careful not to scratch the LCD protector when cleaning instruments with LCD screen.

Caution: Do not let any corrosive liquid stain the instrument to avoid damage.

Warning: Before re-energizing, make sure the instrument is completely dry

to avoid short circuit even personal injury caused by moisture.

-3-

2. Brief introduction of Digital Spectrum Analyzer

The PeakTech® 4130 / 4135 / 4140 is a Spectrum Analyzer with compact design, easy handling, high cost – performance ratio and various functions. It has a keyboard layout which is easy to operate, high-definition color LCD screen and various remote communication interfaces. It can be widely used in many fields including education science, enterprise R & D and industrial production etc.

Main Features:  Frequency range: 9 kHz to 3.0 GHz (P4140)

2.2 GHz (P4135)

1.5 GHz (P4130)

 Display Average Noise Level (DANL)-135 dBm (Typical value)  Phase noise: -80 dBc/Hz (offset 10 kHz)  Full-amplitude precision: ±1.0 dB  Resolution Bandwidth (RBW): 10 Hz  Various measurement function and auto-setting function  Multi-window display, accurate measurement  Equipped with preamplifier and AM / FM demodulation function  Tracking generator included  High stablility oscillator  7 inch high-definition screen (800×480 pixels), the image interface is simple and clear which

makes operation easy

 Equipped with various interfaces, such as LAN, USB Host, USB Device, RS232  Compact design, weights only 6.0kg

Format specification:

1. Keys：

This guide usually uses “text box+text (bold)” to indicate a key on front panel, such as FREQ indicates FREQ key.

2. Menu：

This guide usually uses “character shading+text (bold)” to indicate a menu, such as “center frequency” indicates the center frequency menu option under FREQ key.

3. Connectors：

This guide usually uses "brackets + text (bold)," to indicate a connector on the front or rear panel. For example: [GEN OUTPUT 50Ω].

4. Operating steps：

This guide usually uses an arrow “” to indicate the next step. For example: FREQ center

frequency indictes pressing FREQ function key on the front panel then pressing “center frequency”  menu softkey.

-4-

Chapter 1 Getting started

This chapter introduces the front and rear panels, user interface and notes for first operation of the Spectrum Analyer.

The contents of this chapter are as follows:

 Initial inspect  Outlook and dimensions  Front panel  Rear panel  Parameter setting

-5-

Data

Spectrum Analyzer 9kHz-3.0GHz

RF INPUT 50Ω

MAX +30dBm/50V DCMAX 50V DC

GEN OUTPUT 50Ω

kHz

1 2 3

-dBm

MHz

4 5 6

+dBm

GHz

Peak

Auto Tune

Single

Display

Trigger

Sweep

Marker

Source

CAL

Setup

System

Recall

Preset

Save

Meas

t Trace

cto

Demod

Count

Freq

Marker

AMPT

SPAN

FREQ

sec

Control

Marker

Utility

Setting

Initial inspect

1. Inspect the transport package

Check the transport package and verify its contents is complete, keep the package and fill material before testing the analyzer.

2. Inspect the unit Please inspect the unit carefully, if its content is not complete, or the analyzer does not pass the performance test, please contact your dealer or the manufacturer.

3. Check the accessories Check the accessories according to the packing list, if damaged or missing, please contact your PeakTech distributor.

Outlook and dimension:

Unit：mm

-6-

Front view

Peak

Auto Tune

Single

Display

Trigger

Sweep

Marker

Source

CAL

Setup

System

Recall

Preset

Save

Meas

Trace

cto

Demod

Count

Freq

Marker

AMPT

SPAN

FREQ

Control

Marker

Utility

Setting

Prepare for use

Adjust the legs of the instrument

Open the legs of the Analyzer as bracket of the instrument to make it tilted upward before operation, which makes the following operation and observation more convenient. When the instrument is not in use, the user can close the support legs to facilitate placement or removal.

Switching the power on

Connect the Spectrum Analyzer to AC power with the power cord from the accessories, please

refer to the introduction about the requirement of voltage and frequency of AC power in the “Rear

panel” section.

Boot examination

Connect power cord properly, then press the power switch on the front panel to turn on the Spectrum Analyzer. The boot screen displays the boot initialization process information, then displays sweep curve at the end.

Perform self-calibration

Please perform self-calibration after boot. Press CAL Calibration Immediate calibration to process self-calibration for the system with the internal calibration source of the system.

Front panel

① LCD display screen ② Adjusting knob ③Function key area ④ Digit keys ⑤ RF input ⑥Direction keys ⑦ Menu software/ menu control key ⑧USB Host ⑨ Power

Function keys on front panel:

-7-

Function key

Function description

FREQ

Set informations like center frequency, start frequency and end frequency etc.

SPAN

Set the frequency range of sweep.

AMPT

Set parameters like reference level, RF attenuator, scale, Y-axis units etc. Set level offset, the largest mixer and input impedance. Used to perform automatic calibration, automatic range and turn on the preamplifier.

Set resolution bandwidth (RBW) and vedio bandwidth (VBW) and V/R

ratio.

Sweep

Set parameters like sweep time, mode etc.

Trigger

Set informations about trigger

Single

Set “single” trigger of the instrument

Display

Set informations about screen display

Auto Tune

Auto tune of full frequency range

Marker

Read amplide, frequency or sweep time etc. of each point on trace through the marker

Marker—>

Set other system paraters of the instrument with current marker value

Freq Count

Set parameters like frequency count, resolution etc.

Peak Search

Unfold setting menu of peak search, and execute peak search function simultaneously

Demod

Config demodulation function **

Meas

Select and control measurement function **.

Source

Set tracking source*.

CAL

Set information about the auto calibration of the instrument .

Trace

Set parameters of trace.

Detector

Set detection mode of detector.

System Setup

Set parmaters of system.

Triger

Set information about trigger.

Save

File save and read function.

Recall

Recall saved data and information.

Preset

Reset system to factory default state or user-defined state.

Table 1-2 Description of function keys on front panel

-8-

Rear panel

1. VGA port

This port provides VGA vedio signal output, connect this interface with VGA cable

2. RS-232 port

This port provides serial data output, connect this interface with RS-232 cable

3. TRIGGER IN

When the Spectrum Analyzer is under external trigger mode, this connector receives an external trigger signal. The external trigger signal is input to the Spectrum Analyzer through BNC cable

4.10MHz IN/OUT

Realize reference clock input/ output through BNC cable

5. AC Power Connector

The AC power specifications that this instrument supports is: 100 V - 240 V, 45 Hz - 440 Hz

6.USB Device

The Spectrum Analyzer could connect with external USB device as “slave device”

7.LAN

This interface is used to connect the spectrum analyzer to the LAN to realize remote control.

-9-

Parameter setting

Realize parameter input with numeric keys, adjusting knob or direction keys. This section introducs thress parameter setting methods with an example (set center frequency to 1500 MHz).

1. Use numeric keys

1) Press FREQ  Center frequency;

2) Use numeric keys to input value “750”;

3) Select desired unit “MHz” from the unit menu that pops up.

2. Use adjusting knob

In the parameters editable state, turn the knob to increase (clockwise) or decrease (counter-

clockwise) parameters at specified steps.

1) Press FREQ Center frequency;

2) Turn the knob to get desired parameter value (750 MHz).

3. Use direction keys

In the parameter editable state, the direction keys can be used for the progressive increment or

decrement of the parameter value according to a certain step.

1) Press FREQ  Center frequency;

2) Press the up / down direction key to get desired parameter value (750 MHz).

-10-

Chapter 2: Basic operation

The contents of this chapter are as follows:

 Basic Settings  Sweep and Functions Settings  Measurement Settings  The using and function settings of Marker  Shortcut  System Settings

-11-

Parameter

Description

Default

0.75GHz (P4130); 1.1GHz (P4135); 1.5GHz (P4140)

Range

0Hz ~ 1.5GHz (P4130); 0Hz ~ 2.2GHz (P4135) 0Hz ~ 3.0GHz (P4140)

Unit

GHz, MHz, kHz, Hz

Knob Step

Span>0, step=span/200 Span=0, step=RBW/100, Min=1 Hz

Arrow Keys Step

CF step

3. Basic Settings

3.1. FREQ

Set the frequency parameter of analyzer. The analyzer sweeps within a specified range, and the sweep will start once you change this parameter. The frequency range of current channel can be expressed by either of two groups of paramenters: Start Frequency/Stop Frequency （ f

（ f

center/fspan

） . If any one of them is adjusted, other three parameters will be changed

start/fstop

accordingly to ensure their coupling relationship.

center

span

=（f

= f

start-fstop

stop

- f

）/2

start

3.2. Center Frequency

Enable the center frequency function, to allow a frequency displays in center be selected. When pressed, the frequency mode is switched to Center Frequency/Span for input. In this mode, parameters you specified are always shown at the lower right and left side of the display grid.

Key points:

 The start and stop frequencies vary with the center frequency when span is constant.  Changing the center frequency horizontally shifts the current sweep channel and the

adjustment is limited by the specified range in datasheet.

 In the Zero Span mode, start frequency, stop frequency and center frequency are always

equal.

 User can modify this parameter by numeric keys, knob and arrow keys.

Table 2-1 Center Frequency

） , or center Frequency/Span

-12-

Parameter

Description

Default

0 GHz

Range

0 Hz ~ 1.5GHz (P4130) 0 Hz ~ 2.2GHz (P4135) 0 Hz ~ 3.0GHz (P4140)

Unit

GHz, MHz, kHz, Hz

Knob Step

Span>0, step=span/200 Span=0, step=RBW/100, Min=1 Hz

Arrow Keys Step

CF step

Parameter

Description

Default

1.5 GHz (P4130) ; 2.2 GHz (P4135); 3.0 GHz (P4140)

Range*

0Hz ~ 1.5GHz (P4130); 0Hz ~ 2.2GHz (P4135) 0Hz ~ 3.0GHz (P4140)

Unit

GHz, MHz, kHz, Hz

Knob Step

Span>0, step=span/200 Span=0, step=RBW/100, Min=1 Hz

Arrow Keys Step

CF step

3.3. Start Freq

Set the start frequency of current channel, displays at the left scale. When pressed, the frequency mode is switched to Start Frequency/Stop Frequency for input. In this mode, parameters you specified are always shown at the lower left and right side of the grid.

Key points:

 The span and center frequency are changed automatically according to the start frequency.

The change of the span would have influence on other system parameters. For more details, please refer to “Span”.

 In Zero Span mode, the start frequency, stop frequency and center frequency are always

equal.

 You can modify this parameter using the numeric keys, knob, or arrow keys. Table 2-2 Start Frequency

3.4. Stop Freq

Set the stop frequency of current channel, displays at the right scale. When pressed, the frequency mode is switched to Start Frequency/Stop Frequency for input. In this mode, parameters you specified are always shown at the lower left and right side of the grid.

Key points:

 The span and center frequency are changed automatically according to the stop frequency. The

change of the span would have influence on other system parameters. For more details, please refer to “Span”.

 You can modify this parameter using the numeric keys, knob, or direction keys. Table 2-3 Stop Frequency

*Note：The range is from 100 Hz to 3.0GHz in non-zero span.

-13-

+ 35 hidden pages

PEAKTECH 4130, 4140, 4135 Instructions

Specifications and Main Features

Frequently Asked Questions

User Manual
