PeakTech
®
1206 - 1212
User Manual
2 CH & 4 CH
Tablet Oscilloscopes
Table of content
1. Safety precautions…............................................................................................................ 3
2. Safety symbols and terms………......................................................................................... 5
3. Quick start guide................................................................................................................... 7
3.1 Front………….……………………………………………………………………………………. 8
3.2 Side view………………………………………………………………………………………..… 10
3.3 Upper side……..………………………………………………………………………………….. 11
4. Introduction to the user interface ……………………………………………………............... 12
5. Check before commissioning………………….………………………………………………... 13
5.1 Functional test…................................................................................................................ 14
5.2 Probe compensation……………………………………………………………………………. 15
5.3 Setting the probe attenuation factor…………………………………………………………. 15
5.4 Self - calibration………………………………………………………………………………….. 17
5.5 Introduction to the vertical system…………………………………………………………… 17
5.6 Introduction to the horizontal system….......................................................................... 18
5.7 Introduction to the trigger system……………………………………………………………. 19
5.8 Introduction to the touchscreen operation…………………………….…………………… 20
5.8.1 Change menu..................................................................................................…............. 20
5.8.2 Value setting in the menu…………………………….……………………………………….. 20
5.8.3 Calling up the main menu……………………………………….…………………………….. 21
5.8.4 Selection of the active channel……………………………………………………………….. 21
5.8.5 Adjustment of the horizontal and vertical…………………………………………….……… 22
5.8.6 Setting the trigger level………………………………………………………………………… 22
5.8.7 Setting the time base and voltage division………………………………...………………... 23
5.8.8 Measurements using the Cursor……………………………………………………………… 23
6. User instructions (for advanced users)……………………………………............................ 24
6.1 Set the vertical system...................................................................................................... 25
6.1.1 Setting the channel coupling………………………………………………………………….. 26
6.1.2 Setting the probe attenuation…………………………………………………………………. 26
6.1.3 Current measurement…………………………………………………………………………. 26
6.1.4 Invert a waveform………………………………………………………………………. ……... 26
6.1.5 Setting the bandwidth limit……………………………………………………………………..27
6.2 Set the horizontal system….............................................................................................. 27
6.3 Waveform zoom function………………………………………………………………………. 27
6.4 Operation oft he function menu…………………………………………………………..…... 28
6.5 Set the trigger system…………………………………………………………………………... 28
6.5.1Single Trigger…………………………………………………………………………………… 28
6.5.2 Edge Trigger……………………………………………………………………………………. 29
6.5.3 Video Trigger…………………………………………………………………………………… 30
6.5.4 Pulse Width Trigger……………………………………………………………………………. 31
6.5.5 Slope Trigger………………………………………………………………………………...…. 31
6.5.6 Runt Trigger…………………………………………………………………………………….. 33
6.5.7 Window Trigger……………………………………………………………………………….... 34
6.5.8 Timeout Trigger………………………………………………………………………………… 35
6.5.9 Nth Edge Trigger……………………………………………………………………………….. 36
6.5.10 Logic Trigger…………………………………………………………………………………... 37
6.5.11 Bus Trigger……………………………………………………………………………………. 38
7. Sampling setup………………………………………………………………...…………………... 41
8. Implementation of the function setting for the auxiliary system………………………….. 43
8.1 Set the display system………………………………………………………………………….. 45
8.1.1 Persist…………………………………………………………………………………………… 45
8.1.2 Color……………………………………………………………………….…………………….. 46
8.1.3 Counter…………………………………………………………………………………….……. 46
- 1 -
8.2 Save and recall a waveform…........................................................................................... 47
8.2.1 Save and recall the waveform……………………………….……………………………….. 48
8.2.2 Save the current screen image…..................................................................................... 49
8.2.3 Requirements of the USB storage device…………………………………………………… 49
8.2.4 Use system provided function to format the USB device…............................................. 49
8.2.5 Record and playback waveforms…................................................................................. 51
8.2.6 Clone and recall a waveform……………………………………………………………….…. 54
8.2.7 Data format description of OTA waveform file………………………………………………. 56
9. Measurement functions…….…………………………………………………………………….. 57
9.1 Measure automatically……………………………..…………………………………………... 57
9.1.1 Measure…………………………………..…………………………………………………….. 58
9.1.2 Automatic measurement of the voltage parameters……………………..……………….... 59
9.1.3 Automatic measurement of the time parameters …………………….………………......... 60
9.1.4 Other measurement functions…….………………………………………………………….. 61
9.1.5 Adjustment of the automatic measurement…………………………………………………. 61
9.2 Measure with the cursor…..……………………………………………………………………. 62
9.2.1 Cursor measurements in FFT mode………………………………………………………… 64
9.3 Mathematical manipulation function…………………………………………….…………… 64
9.4 User defined function…………………………………………………………………………… 66
9.5 Digital filter……………………………………………………………………………………….. 67
9.6 Autoscale function............................................................................................................ 67
9.7 FFT function……………………………………………………………………………………… 69
9.7.1 Select the FFT window…................................................................................................. 70
9.8 XY mode…………………………………………………………………………..……………..... 71
9.9 Pass/Fail…………………………………………………………………………………………… 71
10. Executive buttons………………………………………………………………………………... 73
10.1 Print the screen image…………………………………………………………………..……. 74
11. Using the multimeter…………………………………………………………………………….. 75
11.1 Connections of the multimeter…………………………….………………………………... 75
11.2 Menu of the multimeter………….……………………………………………………………. 75
11.3 DMM information window................................................................................................ 77
11.4 Measurements with the multimeter………………………………………………..……….. 78
11.4.1 AC/DC voltage measurement…………………………..…………………………………… 78
11.4.2 AC/DC current measurement……………………………………………………………….. 78
11.4.3 Resistance measurement…………………………………………………………………… 78
11.4.4 Testing diodes……………………………………...…………………………………………. 79
11.4.5 Capacitance measurement…...……………………………………………………………... 79
11.4.6 Continuity test……………….………………………………………………………………... 79
11.5 Multimeter features…………………………………………………………………………….. 80
11.5.1 Data – Hold Mode………..…………………………………………………………………… 80
11.5.2 Information display……..…………………………………………………………………….. 80
11.5.3 Auto or manual range…………………….………………………………………………….. 80
11.5.4 Relative measurements…………………..………………………………………………….. 80
11.6 Multimeter recorder......................................................................................................... 81
12. Communication with PC………………………………………………………...………………. 83
12.1 USB port…………………………………………………………………………………………. 83
12.2 LAN port…………………………………………………………………………………………. 84
13. Specification........................................................................................................................ 87
13.1 Trigger……………………………………………………………………………………………. 90
13.2 Multimeter……………………………………………………………………………………….. 92
14. General specifications…………………………………………….…………………………….. 93
- 2 -
1. Safety precautions
This product complies with the requirements of the following directives of the European Union for
CE conformity: 2014/30/EU (electromagnetic compatibility), 2014/35/EU (low voltage), Overvoltage
category II; Pollution degree 2.
To ensure the operational safety of the device and to avoid serious injuries from current or voltage
flashovers or short circuits, the following safety instructions for operating the device must be
observed.
Only connect the device to sockets with a grounded protective conductor
Damages caused by non-observance of these instructions are excluded from claims of any kind.
* This device must not be used in high-energy circuits.
* Before connecting the device to a socket, check that the voltage setting on the device
corresponds to the existing mains voltage
* Only connect the device to sockets with a grounded protective conductor
* Do not place the device on a damp or wet surface.
* Do not operate the device in the vicinity of strong magnetic fields (motors, transformers, etc.)
* Do not exceed the maximum permissible input values under any circumstances (risk of serious
injury and / or destruction of the device)
* The specified maximum input voltages must not be exceeded. If it cannot be ruled out
unequivocally that these voltage peaks are exceeded due to the influence of transient interference
or for other reasons, the measurement voltage must be pre-damped accordingly (10: 1).
* Before switching to another measuring function, disconnect test leads or probe from the
measuring circuit.
* Check the device, test leads and other accessories for possible damage or bare or kinked cables
and wires before commissioning. If in doubt, do not take any measurements.
* Only carry out measurements in dry clothing and preferably in rubber shoes or on an insulating
mat.
* Do not touch the measuring tips of the test leads.
* Strictly observe the warning notices on the device.
* The device should not be operated unsupervised
* Do not expose the device to extreme temperatures, direct sunlight, extreme humidity or moisture.
* Avoid strong vibration.
* Keep hot soldering guns away from the immediate vicinity of the device.
* Before starting the measuring operation, the device should be stabilized to the ambient
temperature (important when transporting from cold to warm rooms and vice versa)
* Do not exceed the set measuring range with any measurement. This will prevent damage to the
device.
* Clean the housing regularly with a damp cloth and a mild detergent. Do not use any caustic
abrasives.
* Avoid any proximity to explosive and flammable materials.
* Opening the device and maintenance and repair work may only be carried out by qualified service
technicians.
* Do not place the device face down on the workbench or work surface to avoid damaging the
controls.
* Do not make any technical changes to the device.
* -Measuring devices do not belong in the hands of children-
- 3 -
Warning!
If the oscilloscope is connected to an input signal of more than 42V peak (30Veff) or to circuits with
more than 4800VA, please observe the instructions below to avoid fire or electric shock:
- Use only insulated probes and test leads.
- Check all accessories before use and replace them if damaged. If in doubt, do not take
any measurements.
- Remove the USB cable that connects the oscilloscope to the computer.
- Never exceed the maximum specified input voltages. Since the voltage is transmitted
directly to the oscilloscope with the aid of the probe, the device can be damaged or there
is a risk of injury from electric shocks.
- Do not use exposed BNC or banana plugs.
- Do not insert any metal objects into the connections.
Cleaning the device:
Before cleaning the device, pull the plug out of the socket. Only clean the device with a damp, lint-
free cloth. Use only commercially available detergents.
When cleaning, make sure that no liquid gets inside the device. This could lead to a short circuit
and the destruction of the device.
- 4 -
2. Safety symbols and terms
Danger: High
voltage
See user
manual
Protective
conductor
terminal
Device
grounding
Earth clamp
(Ground)
Ground Clip
Signal Input
Electrical Outlet
Probe
Oscilloscope AC Adapter
You can find the following symbols in these operating instructions or on the measuring
device.
Warning!
„Warning” indicates conditions and operating steps that pose a risk to the operator.
Attention!
„Attention” indicates conditions and operating steps that can cause damage to the
product or other objects.
In order to avoid physical damage and damage to the measuring device and the measuring
objects, you should read the following paragraph carefully and always pay attention to it during
future use. This device may only be used for the intended areas of application.
Warning:
The channels of the oscilloscope are not electrically isolated from one another. Therefore,
the measuring channels should be on a common ground during a measurement. To avoid
short circuits, the earth terminals must not be connected to different, non-isolated DC
levels.
Internal Ground (GND) Wiring Diagram:
Due to the internally connected earth terminals between the BNC socket, USB port and IEC
connector, the mains voltage should not be measured when the oscilloscope is operated
with mains voltage in conjunction with a PC operated with mains voltage. In the event of a
fault, a voltage flashover could occur across the GND of the PC.
- 5 -
Internal ground (GND) wiring diagram when the oscilloscope is connected to a PC:
Warning:
To avoid fire or electric shock, please observe the following points
when the connected oscilloscope input signal is greater than 42 Vpp
(30 Vrms) or circuits greater than 4800 VA:
1. Use only insulated measuring probes and measuring lines
2. Check the accessories for damage and functionality before use
3. Remove the test leads and any accessories after measurement
/ use
4. Remove the USB cable from the oscilloscope before each
measurement
5. Make sure that the voltage to be measured does not exceed the
maximum input voltage of the device, as the measuring voltage
is transmitted directly from the measuring probe to the
oscilloscope
6. Do not use damaged connection cables, e.g. damaged BNC
plugs
7. Do not insert any bare metal objects into the connections of the
device
Ground Clip
Signal Input
Oscilloscope
(Battery-power)
PC Electrical OutletProbe
USB/LAN Cable
- 6 -
3. Quick start guide
This chapter covers the following topics:
Structure of the oscilloscope
Introduction to the user interface
Check before commissioning
Functional test
Probe compensation
Probe attenuation
Safety by using the probe
Performing the self calibration
Introduction to the vertical system
Introduction to the horizontal system
Introduction to the trigger system
Introduction to touchscreen operation
Structure oft he oscilloscope
When you get a new oscilloscope, the first thing to do is familiarize yourself with its control panel.
This chapter provides a simple description of the operation and functionality of the oscilloscope
control panel so that you can quickly become familiar with its use.
- 7 -
3.1 Front
10
1 3
4
7
12
11
9
6
2
5
8
Function keys and rotary switches are built into the front of the oscilloscope, which can be used to
navigate through the menu or to select function applications. Furthermore, the tablet oscilloscope
has a touchscreen, which means that the respective functions can also be selected.
Figure 1.0 Front view (4 channel oscilloscope)
- 8 -
10
1 3
4
7
12
11
9
6
2
5
8
13
Figure 1.1 Front view (2 channel oscilloscope)
1. LCD Touchscreen
2. 4CH Oscilloscope: CH buttons CH 1 – CH 4 /
2CH Osciloscope: buttons CH 1 + CH 2
3. Main switch for switching the device on and off
4. When a channel button lights up, the vertical position of the channel is set with the rotary
button. When the HOR button is lit, the horizontal position of the channels is set (including
math operations)
5. The HOR key is used to adjust the horizontal position of the various channels using the
rotary knobs.
6. The trigger button is used to set the respective trigger level for the various channels. To do
this, the lower rotary knob is used after activating the trigger button.
7. Rotary knob for setting the trigger level and the horizontal position of the measurement
voltage
8. Using the Copy button, it is possible to save the current measurement
9. Button for restoring the factory settings. When pressed, you will be asked to press the
button again to restore the factory settings
10. Autoset button for quick configuration of the oscilloscope to the current measurement signal
11. With the single button you are able to apply the trigger individually to a channel
12. Activates or deactivate the sampling of the input signal
13. Activates and deactivate the multimeter function
- 9 -
3.2 Side view
1
2
3
4
5
6
Figure 1.2 Side view
1. Probe compensation: output of the 5V / 1kHz measuring signal
2. Output connection for the trigger and the pass / fail function (output type can be changed in
the menu Tool Function output output)
3. USB device connection for transferring saved data e.g. to a PC
4. USB port for direct storage of data, e.g. on a USB stick
5. LAN port for connection to a PC
6. Charging connection socket for the enclosed charging adapter
- 10 -
3.3 Upper side
Input connectors of channels
Input connectors of multimeter
Input connectors of four channels
Figure 1.3 Upper side of the 2 channel oscilloscope (PeakTech 1206, 1207)
Figure 1.4 Upper side of the 4 channel oscilloscope (PeakTech 1211, 1212)
- 11 -
4. Introduction to the user interface
Figure 2.0 User interface
1. Display range of the measured values
2. Start / stop the measurement (measurement activated / deactivated)
3. Display of the selected mode
4. Automatic setting for displaying the measured value
5. Representation of the vertical position of the cursor measurement
6. Display of the current trigger position of the bandwidth
7. Display of the horizontal trigger position
8. Display of the current trigger value and the location of the internal memory
9. Option to lock the touchscreen operation
10. Time display
11. Wifi display
12. Display when an external USB device is connected
13. Battery level indicator
14. Display of the multimeter function
15. Channel 1 waveform
16. Display of the trigger position of the channel
17. Display of the horizontal position of the measuring cursor
18. Channel 2 waveform
- 12 -
19. Display of the frequency of the triggered signal
20. Display of the current trigger type
21. Selection to display the submenu items
22. Display of the measured type of the corresponding channel
23. Display of the recording length of the measured values
24. Display of the current sampling rate
25. Display of voltage division, zero point position and bandwidth limit, as well as symbol for
coupling type
26. Display of the set main time base
27. Window to show the absolute measured values of the respective channel
28. Position of the zero point position of the channel 2 waveform
29. Position of the zero point position of the channel 1 waveform
5. Check before commissioning
After receiving a new oscilloscope, it is recommended that you test the device as follows:
1. Check whether the device has been damaged in transit.
If you note that the cardboard packaging or the protective foam padding are badly damaged, keep
them until the entire device and its accessories have passed the electrical and mechanical test.
2. Check the accessories
heck that the accessories are complete. If any accessories are missing or damaged, please
contact your dealer.
3. Check the device
If you note any damage to the exterior of the device, or if the device is not working properly or if
the performance test does not pass, please contact your dealer. If the device has been damaged
during transport, please keep the outer packaging and also inform your dealer about the damage.
- 13 -
5.1 Functional test
Check the meter is working properly as follows
1. Switch on the device with the main switch " " by pressing and holding the button.
The device performs a self-test and displays the PeakTech logo. If desired, press the “Default”
button to reset the oscilloscope to the factory settings. The default value for the probe
attenuation in the menu is 10X.
2. Set an attenuation of 10x on the probe and connect the probe to the CH1
Align the slot on the probe with the channel 1 BNC connector and rotate the probe clockwise to
secure it in place.
Connect the tip of the probe and the earth terminal to the plug of the task head compensator.
3. Press the “Autoset“ button
The square wave signal with a frequency of 1 KHz and a 5V SS value is displayed after a few
seconds
Figure 3.0 Display of the compensation square wave signal
- 14 -
5.2 Probe compensation
The first time you connect the probe to an input channel, you must match the probe to the input
channel. A probe that is not or incorrectly compensated results in measurement errors. Perform
the probe compensation as follows:
1. Set the attenuation factor of the probe to 10X in the menu, set the switch on the probe to 10X
and connect the probe to channel 1. When using the hook tip, make sure it stays securely
attached to the probe. Connect the probe tip to the signal connector of the probe compensator
and connect the terminal of the reference cable to the ground terminal of the probe
compensator; then press the AUTOSET button.
2. Check the displayed waveforms and adjust the probe until correct compensation is achieved
Overcompensated Correct compensation Undercompensated
Abbildung 3.1 Tastkopfkompensation
3. Repeat the procedure if necessary in order to obtain an image that is as even as possible.
5.3 Setting the probe attenuation factor
The probe has several probe attenuation factors that affect the oscilloscope's vertical scale factor.
If the setted probe attenuation factor should be changed or checked, press the key for the function
menu of the respective channel and then the selection key corresponding to the probe until the
correct value is displayed.
- 15 -
This setting remains in effect until it is changed again.
Warning:
To avoid electric shock, you should always keep your fingers behind
the safety ring on the probe.
To protect you from electric shock, do not touch any conductive metal
part of the probe tip when it is connected to a power source.
Before any measurements are carried out, always first connect the
probe to the oscilloscope and then the earth terminal to the housing of
the device under test.
Note: The attenuation factor of the probe is in the menu presetted to 10x.
Make sure that the value set on the probe's attenuation switch corresponds to the
attenuation value set on the oscilloscope.
The values that can be set with the switch on the probe are 1X and 10X (see picture).
Note: When the attenuation switch is set to 1X, the probe limits the bandwidth of the
oscilloscope to 5 MHz. You need to set the switch to 10X if you want to take
advantage of the full bandwidth of the oscilloscope.
Safety instrucstion for using the probe head
The protective ring around the probe head handle prevents unintentional reaching over or slipping
and thus contact with any metal parts that may be live (see error! Reference source could not be
found).
Handle protection
- 16 -
5.4 Self - calibration
With the auto-calibration, the oscilloscope can be quickly put in the optimal state for high-precision
measurements. You can run this program at any time, but you must do it if the ambient
temperature varies by more than 5 ° C. Remove all probes and cables from the input jacks before
performing the auto calibration. Press the symbol, press the “Utility” button, then press the
Function area and then press “Adjust”, finally press SelfCal. A window now appears which asks
you to press the SelfCal button again to start the self-calibration.
5.5 Introduction to the vertical system
As shown in Figure 3.2, there are some buttons and buttons in the vertical control elements that
are used to operate the oscilloscope.
Press one of the channel buttons CH1 or CH2 to open the corresponding channel menu. To
deselect the channel, press the button again.
If you want to adjust the vertical position and the vertical scaling of a channel, first press the
corresponding channel button to select the desired channel.
Now use the rotary knobs to set the vertical position or the vertical scaling of the channel.
Figure 3.2 Setting the vertical parameters
- 17 -
1. Press the control panel button CH1 or CH2 to select the desired channel
Upper knob: adjust horizontal position
When the HOR
button is lit
Lower knob: adjust horizontal scale
2. When one of the channel buttons is lit, you can use the upper knob to display the selected
channel waveform in the center of the waveform window. The top knob controls the vertical
display position of the selected channel waveform. When the top knob is turned, the pointer
of the grounding point of the selected channel is moved to move up and down the
waveform and the position report in the center of the screen changes accordingly.
3. You can change the vertical scale setting. You can read the resulting status information on
the display. Use the information in the status bar at the bottom of the waveform window to
determine the vertical scaling factor of the channel. Turn the lower knob and change the
"Vertical Scaling Factor (Voltage Division)" of the selected channel. The display shows that
the scaling factor of the selected channel has been changed accordingly in the status bar
5.6 Introduction to the horizontal system
As shown in Figure 3.3, there is a button and two buttons in the horizontal control elements, which
are used to operate the oscilloscope. The following steps explain how the horizontal settings are
made.
Figure 3.3 Setting the horizontal parameters
- 18 -
1. With the HOR button lit, press the HOR button to toggle between normal mode and
Upper knob: adjust trigger level
When the Trigger button is lit
wave zoom mode.
2. With the HOR button lit, rotate the lower knob to change the horizontal timebase
setting and observe the resulting change in status information. Rotate the lower knob
to change the horizontal time base. It can be seen that the horizontal time base
displayed in the status bar changes accordingly.
3. When the HOR button is lit, use the upper knob to adjust the horizontal position of
the signal in the waveform window. The upper button is used to control the trigger
offset of the signal or for other special applications. When used to trigger the shift,
the waveform can be observed to move horizontally as the top knob is turned. By
pressing the upper rotary knob, it is possible to reset the set offset to 0.
5.7 Introduction to the trigger system
As shown in Figure 3.4, it is possible to manage the trigger control using a button and a rotary
knob. The following steps explain how the trigger settings are made.
Figure 3.4 Setting the trigger
Press the symbol and open the trigger menu. In this submenu it is possible to adjust the signal
by setting the trigger for the display.
- 19 -
Press repeatedly to
switch the options
Click to increase the
value of cursor position
Move the cursor
Click to decrease the
value of cursor position
1. Press the symbol and open the trigger menu. In this submenu it is possible to
adjust the signal by setting the trigger for the display.
2. To set the trigger, press the trigger button that it lights up. You are now able to adjust
the trigger level of the previously selected channel using the upper rotary knob for
the required display.
5.8 Introduction to the touchscreen operation
The oscilloscope can be controlled and adjusted using the push buttons and rotary knobs. But it is
also possible to make the respective setting using the touchscreen.
A symbol is permanently displayed in the upper right corner of the display, which shows whether
the touchscreen is locked or available ( or ). When the lock is open, you can adjust the
settings using the touchscreen. When it is closed, no settings can be made via the touchscreen.
Briefly press the symbol to lock or unlock the touchscreen.
The following explains each of the oscilloscope displays:
5.8.1 Change menu
To change menu options, press the area of the menu item to be changed. Touch the
corresponding key to switch, see Figure 3.5:
Figure 3.5 Menu options
5.8.2 Value setting in the menu
use the crosshairs to set the desired measuring rate of the measured value (Figure 3.6):
Figure 3.6 Cursor for setting the measuring rate
- 20 -
5.8.3 Calling up the main menu
Channel is off
Channel is on and selected
To call up the main menu, press the symbol in the lower right corner of the screen ( ). The menu
is shown in Figure 3.7.
Figure 3.7 Main menu
5.8.4 Selection of the active channel
The available channels are displayed in the lower left corner. By activating the respective channels
it is possible to activate or deactivate them. Each active channel is illuminated on the button.
When a channel is deactivated, the associated button is darkened (see Figure 3.8).
Figure 3.8 Display of the channels
- 21 -
5.8.5 Adjustment of the horizontal and vertical
By simply pressing the touchscreen on the left-hand side, the arrow keys appear for setting the
horizontal and vertical of the selected channel. By pressing the free area of the touchscreen again,
the arrows are hidden. In order to be able to make fine adjustments, press directly on the P in the
arrow.
Figure 3.9 Adjustment of the horizontal and vertical
To make fine adjustments, press the P in the arrow directly (see Figure 3.10)
Figure 3.10 Fine adjustment
5.8.6 Setting the trigger level
To adjust the trigger level of the channel, press the free area on the right of the touchscreen. Two
arrows appear with which you are now able to change the trigger value (see Figure 3.11).
Figure 3.11 Setting the trigger
- 22 -
5.8.7 Setting the time base and voltage division
To set the time base and the voltage division using the touchscreen, press in the middle of the
touchscreen and arrows appear for setting the values. The time base or the voltage division is set
by simply pressing the arrows (see Figure 3.12).
Figure 3.12 Time base and voltage divider
5.8.8 Measurements using the cursor
You are able to determine a recorded current value with the cursor. To do this, press the menu
key (see Accessing the main menu) and switch on the cursor. Now, as in Figure 3.13, the option of
setting two cursor lines to the measured value appears.
Figure 3.13 Measurements using the cursor
- 23 -
6. User Instructions (for advanced users)
In the previous paragraphs, the user has already been familiarized with the basic functions of the
functional areas, buttons and knobs of the oscilloscope. Based on the introduction of the previous
chapters, the user should already have gained initial knowledge about changing the oscilloscope
settings, selecting and evaluating the status bars and general operation.
The following chapters cover the following subject areas:
Set the vertical system
Set the horizontal system
Set the trigger system
Carry out sampling settings
Implementation oft he auxiliary system
Set the display system
Save and recall waveforms
Record and playback waveforms
Clone and recall a waveform
Supporting system settings
Perform automatic measurements
Setting of automatic measurements
Perform cursor measurements
Using the math function
Use the autoscale function
Use the ececuting buttons
It is recommended that you read this chapter carefully in order to be able to use the various
measurement functions and other operating methods of the touchscreen oscilloscopes.
- 24 -
6.1 Set the vertical system
Function
menu
Settings
Description
Coupling
DC
AC
GROUND
Pass both AC and DC components of the input
signal.
Blocks the DC component in the input signal
Disconnect the input signal.
Inverted
On
Off
Display inverted waveform
Display original waveform
Probe
Attenuation
0.001X
to
1000X
Select a attenuation factor that corresponds to
the probe in order to obtain a correct
representation of the vertical scale factor.
Current
measure ment
Yes
No
If you are measuring current by probing the
voltage drop across a resistor, choose Yes
A/V (mA/V)
V/A (mV/A)
Click or to set the Amps/Volts ratio. The
range is 100 mA/V - 1 KA/V
Amps/Volts ratio = 1/Resistor value
Volts/Amp ratio is automatically calculated
Limit
Full band
20M
Full bandwidth
Limits the channel bandwidth to 20 MHz to
reduce visible noise
The VERTICAL functions include 2 menu buttons such as CH1 ～ CH2 (2CH models) and CH1 ～
CH 4 (4 CH Models) as well as 2 rotary controls for vertical and horizontal setting, to be set for
each measuring channel.
Settings CH1 ～ CH2, CH1 ～ CH4
Each channel has an independent vertical menu with functions based on this channel.
Activate / deactivate waveform display
Pressing the CH1 ～ CH2, CH1 ～ CH4 buttons has the following effect:
• If the waveform is switched off, it is switched on and the channel menu is displayed.
• If the waveform is already switched on, the channel menu is also displayed.
• If the waveform is already switched on and the channel menu is displayed, switch the waveform
and the channel menu off again with this action
- 25 -
6.1.1 Setting the channnel coupling
As an example, let's take a square wave signal on channel 1 that contains a DC bias. Proceed as
follows:
1. Press the CH 1 button to access the CH 1 menu
2. Press pairing in the channel menu
3. Select DC to view the DC and AC components of the signal
4. Select AC to display the AC components of the signal
6.1.2 Setting the probe attenuation
For correct measurement results, the settings of the attenuation factor in the operating menu of
the channel should always correspond to those of the probe (probe compensation page 15). If the
attenuation factor of the probe is 1: 1, the setting for the input channel should also be X1.
Proceed as follows, e.g. to set a attenuation factor of 10: 1 for channel 1:
1. Press the CH 1 button to enter the menu
2. Select the Sensor function. After that select the attenuation factor 10x on the left side of the
display
6.1.3 Current measurement
In order to perform a current measurement with the oscilloscope, you have to perform the voltage
drop on a resistor / shunt. In the following example, the current is measured by the voltage drop
across a resistor that has 1 Ω:
1. Press the CH 1 button to enter the menu
2. Now select the Probe function and switch from No to Yes in the Measurement Current
selection on the right. Now the setting for the V / A display appears. This shows the
respective display ratio of current to voltage. You can change this ratio by pressing the
button using the arrow keys and the + and - keys
6.1.4 Invert a waveform
The inverted waveform rotates the displayed signal 180 degrees from the phase of the ground
potential.
1. To invert the waveform, press the CH1 key
2. Press the Invert button to toggle between the On and Off settings
- 26 -
6.1.5 Setting the bandwidth limit
When the high frequency components of a waveform are not important for your analysis,
bandwidth limiting can be used to suppress frequencies above 20 MHz.
Proceed as follows:
1. Press the CH 1 button to enter the menu
2. Select the limit value function
3. Now select the 20M function to only display frequencies up to 20 MHz
4. Select the Full Band function to measure all frequencies up to the maximum bandwidth
6.2 Set the horizontal system
To set the horizontal system, the HOR function key and the two rotary knobs are used as follows:
- Press the HOR key to activate the horizontal setting
- With the upper rotary knob you are now able to determine the horizontal position of the
respective channels
- The sampling rate of the respective channel is set with the lower rotary knob
- Press the HOR key again to activate the waveform zoom function
6.3 Waveform zoom function
Press the horizontal HOR button twice and enter the horizontal zoom mode for the waveform. The
upper part of the display shows the main window and the lower part the horizontal zoomed
window. The horizontal zoom window is the horizontal enlarged part of the selected area in the
main window.
Figure 4.0 Waveform zoom function
- 27 -
6.4 Operation of the function menu
The operating area of the function menu comprises 13 function menu keys: Trig Menu, Acquire,
Utility, Autoscale, Save, Measure, Cursor, Math, Decode, HOR, FFT, XY, P / F, DMM as well
as 5 immediate selection keys: Autoset, Run / Stop, Single, Copy, default.
6.5 Set the trigger system
The trigger determines when the oscilloscope begins acquiring data and displaying the waveform.
Once properly set, the trigger can convert a fluctuating reading into a meaningful waveform.
When the oscilloscope begins acquiring data, it records enough data to plot the waveform to the
left of the trigger point. The oscilloscope continues to acquire data while it waits for a trigger
condition. When a trigger is detected, the device continues to record enough data to display the
waveform to the right of the trigger point.
The trigger control area consists of 1 rotary knob and 2 menu buttons.
6.5.1 Single trigger
Trigger control
The device provides four types of triggers: single trigger (single), alt trigger, logic trigger and bus
trigger. Each trigger type has different submenus.
There are two ways to get into the trigger mode:
Button operation: Press Menu in the trigger field to open the trigger menu. With H1 you can then
select the extended trigger menu, which you can scroll (turn) and select (press) with the
multipurpose rotary knob.
Touchscreen operation: Press the house symbol to open the touch menu. Select Trig Menu
and then the trigger (Single, Alt, Logic, Bus) in the lower menu. The trigger type can then be
selected under Type in the right image menu.
Single: Uses a single trigger to display a stable waveform on both channels.
Logic trigger: Triggers a signal according tot he conditions of the logic ratio
Bus trigger: Sets bus timing triggers
Trigger description
The single, logic and bus trigger menus are described below:
Edge trigger: Occurs when the trigger input runs through a specific voltage level with the
specified slope.
Video trigger: Trigger on fields or lines for a standard video signal
Slope trigger: The oscilloscope begins to trigger according to the rate of rise or fall of the signal
Pulse trigger: Finds impulses with certain widths
Runt trigger: Trigger pulses that run through one trigger level but not the other trigger level.
- 28 -
Loading...
