Safety Instructions 3

Safety Instructions

For your own safety and in order to guarantee a safe operation
of the camera, please read carefully the following information
prior to using the device.

• Never operate the camera at places where water or dust
might penetrate.

• Place the camera on a sufficiently stable basis.
Shocks like e.g. dropping the camera onto the floor, might
cause serious damage to the device. Therefore exclusively
the tripod attachment at the bottom side should be used for
mounting the camera.

• Always unplug the camera before cleaning it. Do not use
cleaning liquids or sprays. Instead, use a dry, soft duster.

• Make sure that the connecting cable is in good condition and
that the link to the socket does not represent an obstacle.

• Detach the camera and contact the customer service in the
following cases:

− When cable or plug are damaged or worn-out.

− When water or other liquids have soaked into the device.

− When the device is not properly working although you

followed all instructions of the user's manual.

− When the camera fell to the floor or the housing has been

damaged.

− When the device shows apparent deviations of normal

operation.

PCO 1999

VMC45-03/99

Contents 5

Contents

1. Video Camera VC45

1.1 Features of the Camera............................................6

Video Standard ...........................................................................6

Shutter Control............................................................................6

Long Exposure............................................................................6

1.2 CCD Sensor..............................................................7

Overview of the used sensors..................................................... 7

Lens-on-chip............................................................................... 7

Spectral Response...................................................................... 8

1.3 Connections..............................................................8

Lens Mount................................................................................. 8

Power Supply..............................................................................8

Video Output...............................................................................8

Pin Assignment...........................................................................9

1.4 Mode Settings.........................................................14

Operating Mode ........................................................................14

Long Exposure in Frame Mode .................................................15

Long Exposure in Field Mode....................................................15

Shutter Mode ............................................................................ 16

Gain Control..............................................................................16

Gamma Setting.........................................................................16

2. Video Module VM45

Pinning of the I/O Connector ST1..............................................17

DIP switches............................................................................. 21

CCD select and standard.......................................................... 22

Gamma Setting.........................................................................23

3. Servicing, Maintenance and Cleaning

Instructions

Servicing, Maintenance and Cleaning Instructions.................... 24

Cleaning Method for the Optical Part.........................................24

4. Appendix

Customer Service......................................................................25

Warranty................................................................................... 25

CE-Certification.........................................................................26

Dimensions and Weight............................................................ 26

Electrical Schematics of the board VMAIN................................27

System Data .............................................................................28

PCO 1999

VMC45-03/99

Operating Instructions VC45/VM45

Version 03/99

Subject to change without prior notice!!
Copyright by PCO, 1999

6 1. Video Camera VC45

VC45 VM45VC45 VM45

This manual contains important information and instructions for
the use of the Video Camera VC45 and the Video Module
VM45.

If you work with a Video Camera VC45, you will find all neces­sary information in Chapter 1.
Chapter 2 includes additional information when working with a
Video Module VM45 (= VC45 without housing).

1. Video Camera VC45

1.1 Features of the Camera

The video camera VC45 is a high performance monochrome
camera, based on a solid state image sensor. The high quality
"lens-on-chip" CCD, combined with an advanced electronics, in­creases sensitivity of the VC45 substantially, compared with
high standard video cameras. An absolute black level is
achieved via special darkened reference pixels, yielding a per­fect linear relation between light input and output signal. A great
number of additional features makes the VC45 suitable for
nearly every application.

Video Standard The VC45 is easy to use. The analog video signal is a CCIR,

respect. a RS170 standard signal and compatible to the whole
video equipment on the market.
With a potentiometer at the rear panel of the camera the gain
can be set externally.

Shutter Control An integrated shutter control allows exposure times from 100µs

to 20ms (CCIR) respect. 16.7ms (RS170). It can be set by DIP
switches, parallel or serial input.

Long Exposure A long exposure time can be generated up to 20s by an external

or serial input. When using the external input a special power
down mode prevents the CCD from additional dark current.
There are two integration modes possible: FRAME interlaced
and FIELD interlaced.

The sensor of the VC45 is absolutely insensitive against over­exposure, i. e. too much light cannot damage the CCD sensor.

PCO 1999

VMC45-03/99

1. Video Camera VC45 7

1.2 CCD Sensor

Overview The following CCD sensors can be used in the camera:

CCIR

format resolution pixel size active sensor

1/2“ 741 x 576 pixel 8.6 x 8.3 µm 6.4 x 4.8 mm
2/3“ 741 x 576 pixel 11.6 x 11.2 µm 8.6 x 6.5 mm

RS170

format resolution pixel size active sensor

1/2“ 756 x 486 pixel 8.4 x 9.8 µm 6.4 x 4.8 mm
2/3“ 756 x 486 pixel 11.6 x 13.5 µm 8.8 x 6.6 mm

Lens-on-chip Each of the used CCD sensors have the “lens-on-chip“ inte-

grated which increases the sensitivity of about factor 2.
The following drawings show the principle function of the lens-

on-chip technical.

PCO 1999

VMC45-03/99

8 1. Video Camera VC45

Spectral Response The following drawing shows the spectral response of the used

sensors. Optional the VC45 is available with an infrared cutting
filter. All wavelength higher than about 680nm will be cut off.

= without filter
= with infrared cutting filter

1.3 Connections

Lens Mount The VC45 uses a C-Mount with a standard back focal length of

17.52mm (distance between the front edge of the C-Mount in-

sert and the focal plane of the CCD sensor). The C-Mount has a
fine adjustment to allow for small variations in the focal length of
instruments.
To adjust to a different back focal length, just loosen the set
screw at the bottom of C-Mount front plate. Rotate the C-Mount
insert to the desired position. (The C-Mount insert has a 0.5
thread suitable for fine adjustment.) Then secure the insert
again by tightening the set screw.

Power Supply The power supply (230V), delivered with the VC44, provides

12V (-5%, +10%). At 12V the power consumption is about
300mA. On the power supply a 12-pin special connector is
mounted.

Video Output The analog video output (BNC socket) supplies a standard

video signal (1Vpp, 0.3V Sync-Level on 75Ω) according to CCIR
or RS170 standard.
The video signal is compatible to all video equipment like re­corder, printer, monitors, ...
Please use only 75Ω cables (e.g. RG59)!
Some monitors need an external Sync-signal. In this case you
need a connection between VIDEO OUT of the monitor and
SYNC IN of the monitor.

PCO 1999

VMC45-03/99

1. Video Camera VC45 9

Pin Assignment The 12 pin socket at the camera rear panel has a standard pin

assignment as follows.
Please note that there are also special pin assignments possi­ble. In this case a separate pin assignment is enclosed.

12 pin socket of the
camera rear panel

pin signal name level function input / output

1 POWER GND ground input
2 POWER +12V +12V DC input power input
3 EXP TTL exposure input
4 EXPD TTL exposure power down input
5 ENB TTL enable shutter input
6 ED0 TTL shutter control input
7 ED1 TTL shutter control input
8 ED2 TTL shutter control input
9 CSYNC TTL composite sync output
10 VSYNC TTL vertical sync output
11 MODE TTL frame / field integration input
12 GENLOCK Video, TTL* genlock input

* signal level from 1 ... 5V is accepted

POWER GND Ground

POWER +12V Input voltage 12V (+10% / -2%)

EXP Long Exposure Control input

TTL level
The exposure time can be prolonged by a low signal.
Typical time range between 40ms ... 10s.

This input is checked at any rising edge of the VSYNC signal (=
end of the VSYNC). When the input is low, the integration time
will be prolonged for the next field/frame.
In the field integration mode multiple of 20ms will be exposed, in
the frame integration mode multiple of 40ms will be exposed.
The input is connected to a pull-up resistance.

PCO 1999

VMC45-03/99

10 1. Video Camera VC45

Remark The Long Exposure Control can only be active when the module

is in the parallel mode and the shutter is off!

DIP switch S1/pin 7 = open
DIP switch S1/pin2 = closed; ENB don’t care
or
DIP switch S1/pin2 = open; ENB = low

EXPD Long Exposure Power Down input

TTL level
For long integration times, the sensor can be set in a power­down mode. This mode avoids the generating of an additional
dark current.
This input can be set parallel with the EXP input but must be re­set at least 200ms before the EXP is reset.

The input is connected to a pull-up resistance.

Remark The Long Exposure Power Down can only be active when the

module is in the parallel mode and the shutter is off!

DIP switch S1/pin 7 = open
DIP switch S1/pin2 = closed; ENB don’t care
or
DIP switch S1/pin2 = open; ENB = low

PCO 1999

VMC45-03/99

1. Video Camera VC45 11

ENB Shutter speed setting, parallel or serial input.
ED0

ED1
ED2

Parallel Input Only the high-speed shutter is used when using parallel input.

(During frame accumulation, low-speed shutter does not oper­ate normally).

Shutter speed table

JP1 ENB ED0 ED1 ED2 shutter speed

X L X X X shutter off
L H H H H 1/60

H H H H H 1/50

1)

1)

L H L H H 1/100

H H L H H 1/120
X H H L H 1/250
X H L L H 1/500
X H H H L 1/1000
X H L H L 1/2000
X H H L L 1/4000
X H L L L 1/10000

1) Accumulation time is as follows regardless of field accumulation / frame
accumulation: JP1 = low (EIA RS170), 1/60s

JP2= high (CCIR), 1/50s
(Pseudo field readout during frame accumulation)

Serial Input The following four modes can be selected according to the

combination of serial data SMD1 and SMD2.
(During frame accumulation, low-speed shutter does not oper­ate normally).

Shutter Mode

mode flickerless high-speed

shutter

low-speed
shutter

no shutter

SMD1 L L H H
SMD2 L H L H

flickerless: eliminates flicker resulting from the frequency of fluorescent light
high-speed shutter: shutter speed higher than 1/50 (CCIR)

low-speed shutter: shutter speed lower than 1/50 (CCIR)

no shutter no shutter operation

shutter speed higher than 1/60 (RS170)
shutter speed lower than 1/60 (RS170)

(does not operate normally during frame accumulation

Input timing when using serial input

PCO 1999

VMC45-03/99

The data on ED2 is latched in the register at the rising edge of
ED1 and is then taken in internally while ED0 is low.

12 1. Video Camera VC45

symbol min: max:

ts2 ED2 setup time against the rising edge of ED1 20ns
th2 ED2 hold time against the rising edge of ED1 20ns
ts1 ED1 rising setup time against the rising edge of ED0 20ns
tw0 ED0 pulse width 20ns 50µs
ts0 ED0 rising setup time against the rising edge of ED1 20ns

Shutter speed calculation

(During frame accumulation, low-speed shutter does not oper­ate normally).

High-speed shutter
... for CCIR: T=[31210-(1FF16-L16)] x 63.56 + 34.78µs
... for RS170: T=[26210-(1FF16-L16)] x 64 + 35.6µs
(L16 = load value)

CCIR RS170

load value shutter

speed

0C8
0CA
0CE
0D6
0E6
1o5
143
149

16

16

16
16
16

16
16
16

1/10000 1/10040 0FA

1/4000 1/4394 0FC
1/2000 1/2068 100
1/1000 1/1004 108

1/500 1/495 118
1/250 1/250 137
1/125 1/125 176
1/100 1/120 196

Low-speed shutter
N = 2 x (1FF16-L16) FLD
However, 1FF cannot be used as the load value.
Maximum 1023 fields à 20ms (= 20 seconds).

load value shutter speed (FLD)

1FE
1FD

... ...

101
100

16
16

16
16

calculated

value

load value shutter

16

16
16
16
16
16
16
16

1/10000 1/10169

1/4000 1/4435
1/2000 1/2085
1/1000 1/1012

2
4

508
510

calculated

speed

value

1/500 1/499
1/250 1/252
1/125 1/125
1/100 1/100

PCO 1999

VMC45-03/99

1. Video Camera VC45 13

CSYNC Composite synchronisation output

TTL level

VSYNC Vertical synchronisation output

TTL level

MODE Switch between field-frame readout and integration

TTL level

mode readout

low field
high frame

GENLOCK External synchronisation

Input to synchronise the camera to an external video device.
A video signal (75Ω) or a TTL signal, consisting of horizontal
and vertical synchronize pulses (composite sync, CSYNC) is
needed. (Internally there is no 75Ω termination.)
The synchronisation is achieved by an internal PLL.

The synchronisation with Genlock can be enabled/disabled by
controlling LSW. This can be done with DIP switch S1:

DIP switch S1/pin 8 = open Genlock disabled
DIP switch S1/pin 8 = closed Genlock enabled

PCO 1999

VMC45-03/99

14 1. Video Camera VC45

FIELD 1

FIELD 2

FRAME

INTERLA-

1

2

Video Out

FIELD 1

FIELD 2

INTERLA-

FIELD

1

2

Video Out

1.4 Mode Settings

Operating Mode The camera runs in two different operating modes:

• FRAME interlaced

• FIELD interlaced

1

2

3

4

5

Integration Time: 2 x 40ms (CCIR)

2 x 33.4ms

Image 1

Image 2

1
2
3
4
5

Integration Time: 2 x 20ms (CCIR)

Image 1

1
2
3
4
5

2 x 16.7ms

Image 2

Hint At continuous illumination the brightness of the image is the

same in FIELD or FRAME mode:

CCIR: 40ms with 1 pixel or 20ms with 2 pixels

RS170: 33ms with 1 pixel or 16.5ms with 2 pixels
However, with externally applied shuttering (e.g. flashlight or la­ser pulse), the FIELD mode generated image has double the
brightness of a FRAME mode generated image.

In the FRAME interlace mode the camera produces two fields
generated with a time shift FIELD 1 and FIELD 2 (odd respect.
even lines). These fields are each integrated for 40ms.

The FIELD interlace mode combines 2 lines (1+2, 3+4, ... in
FIELD 1 and 2+3, 4+5, ... in FIELD 2). FIELD 2 is shifted by one
line in respect to FIELD 1 (line shifting).

PCO 1999

VMC45-03/99

1. Video Camera VC45 15

Long Exposure in Frame Mode

By using the EXP (= exposure) input (pin 3 of the 12-pin socket)
the integration time can be controlled.
In line 10 of the video signal a marker pulse is allocated. If in
this moment the EXP signal is "high", the marker pulse is sup­pressed, the image is not shifted into the shift-register and the
integration time is prolonged.
When operating in the FRAME mode, always 2 x n marker
pulses are suppressed, to achieve two evenly illuminated fields
(40ms). During the integration, black pictures are released from
the camera.

*) *)

*) Marker pulse (in video line 10) is suppressed, thus yielding longer integration time.

Long Exposure in Field Mode

VSYNC

EXP

Integr. ODD

Integr. EVEN

VIDEO OUT

20ms

odd even odd even odd 1 even 1 odd 2 even 2even

odd 1

even 1

black image

odd 2 odd 3

even 2 even 3

Via the EXP signal the integration time can be controlled. In line
10 of the video signal a marker pulse is allocated. If in this mo­ment the EXP signal is "high", the marker pulse is suppressed,
the picture not shifted in the shift register and integration time
prolonged.
The FIELD mode allows integration time prolongation in steps of
20ms. During the integration, black pictures are released from
the camera.

PCO 1999

VMC45-03/99

*) *)

VSYNC

EXP

Integration

VIDEO OUT

20ms

field x field x+1 field x+2

black image

field x field x+1 field x+2

*) Marker pulse (in video line 10) is suppressed, thus yielding longer integration time.

16 1. Video Camera VC45

312

Shutter Mode In the shutter mode, exposure times between 1/50 ... 1/10000 s

can be realized. These shutter times can be achieved by a par­allel and serial programming via external signals (ENB, ED0,
ED1, ED2) or by a parallel setting via internal DIP switches.

Gain Control The gain is externally adjustable with the potentiometer at the

back panel of the camera. It can be selected in the range of ±
12dB.

1 12-pin Socket
2 Gain Potentiometer
3 Analog Video Output

Gamma Setting The gamma correction is preset by factory to "linear".

If you want to change it, internal changes are necessary (see
Chapter 2).

PCO 1999

VMC45-03/99

2. Video Module VM45 17

lower board VMAIN

2. Video Module VM45

The main features of the Video Module VM45 are identical to
these of the Video Camera VC45.
In this Chapter you will find some additional information to the
Video Module VM45.

Please note that there are parallels between the 12-pin socket
at the camera rear panel and the internal connector ST1.

Pinning of the I/O Connector ST1

The connector ST1 is placed on the lower (larger) board. Some
signals has parallel wires to the I/O connector ST1 and to the
DIP switch S1.

When using the external interface (I/O connector ST1) all
DIP switches must be set to off!

ST1

DIP switch S1

pin at internal
connector ST1

1 GND X 1 ground
2 +12V X 2 input power
3 GND X 1 ground
4 +5Vout -- input or output power
5 GND X 1 ground
6 VIDEO -- video out
7 TRIG -- trigger input
8 GAIN ext -- external gain

9 ENB X 5 enable shutter
10 ED0 X 6 shutter control
11 ED1 X 7 shutter control
12 ED2 X 8 shutter control
13 EXPD X 4 exposure power down
14 EXP X 3 exposure
15 CSYNC X 9 composite sync
16 MODE X 11 frame / field integration
17 VSYNC X 10 vertical sync
18 HSYNC -- horizontal sync
19 VR -- vertical reset
20 GENLOCK X 12 genlock

The ‘X’ marked signals are already described in Chapter 1 (see page 9).

signal
name

pin at 12-pin
connector

function

PCO 1999

VMC45-03/99

18 2. Video Module VM45

GND Ground

+12V see Chapter 1, page 9

+5Vout Output of a +5V

Regulated by an internal voltage regulator (7805). When the
voltage regulator is not needed you can also use an external 5V
power supply. In this case the regulator has to be bridged.

VIDEO Video output signal, CCIR or EIA RS170

1Vpp, 0.3V Sync-Level on 75Ω

TRIG Trigger mode

Continuously variable shutter
When using the normal shutter, either leave the TRIG pin open
or connect it to the power supply.
When using the continuous variable shutter, input the clock
pulse to the TRIG pin
When using the TRIG pin to control the exposure time, in order
to broaden the control range it is necessary to use the ED=,
ED1, and ED2 pins to set the shutter speed to 1/10000.

VSYNC

HSYNC

TRIG

XSG

exposure time

From the start of the TRIG input (falling edge) to the XSG pulse
there is a variable exposure time.
The XSG pulse is done in the following lines after the vertical
sync has ended:

CCIR 8 lines odd field

8.5 lines even field

EIA RS170 1.5 lines odd field

1 line even field

PCO 1999

VMC45-03/99

2. Video Module VM45 19

GAIN ext External gain setting

There are three possibilities to control the gain:

• Internally by the potentiometer P2

GND

upper board
VIDEO SPC

P2

• Externally with a voltage range of 0 ... 5V
The gain range is between 5 ... 32 dB.

• Externally with a potentiometer:

+5 V

to GAINext

10kΩ

PCO 1999

VMC45-03/99

20 2. Video Module VM45

ENB see Chapter 1, page 11

ED0 see Chapter 1, page 11

ED1 see Chapter 1, page 11

ED2 see Chapter 1, page 11

EXPD see Chapter 1, page 10

EXP see Chapter 1, page 9

CSYNC Composite synchronisation output (CSYNC)

TTL level

MODE see Chapter 1, page 13

VSYNC see Chapter 1, page 13

HSYNC Horizontal synchronisation output (HSYNC)

TTL level

VR Vertical reset input (TTL level)

A vertical image synchronisation can be made with a vertical
sync signal

GENLOCK External synchronisation

Input to synchronise the camera to an external video device.
A video signal (75Ω) or a TTL signal, consisting of horizontal
and vertical synchronize pulses (composite sync, CSYNC) is
needed.
The synchronisation is achieved by an internal PPL.
A second possibility is to input separately the horizontal sync
and the vertical sync. In this case the horizontal sync must be
connected to the GENLOCK and the vertical sync must be con­nected to the vertical reset (VR).

The synchronisation with Genlock can be enabled/disabled by
controlling LSW. This can be done with DIP switch S1:

DIP switch S1/pin 8 = open Genlock disabled
DIP switch S1/pin 8 = closed Genlock enabled

PCO 1999

VMC45-03/99

2. Video Module VM45 21

lower board VMAIN

DIP switches The 8 DIP switches have the following function:

ST1

DIP switch S1

DIP switch S1 function factory set

1 TRIG open
2 ENB closed
3 ED0 open
4 ED1 open
5 ED2 open
6 Mode open
7 PS (parallel / serial) open
8 Genlock open

PCO 1999

VMC45-03/99

22 2. Video Module VM45

JP2

JP1

CCD select and standard The following jumpers are factory settings and are not allowed

to change!

Pin 1

Pin 1

6 pin connector

CXD 1261

bottom side of lower board VMAIN

JP1: EIA RS170 or CCIR setting

Pin 1

EIA RS170

Pin 1

JP2: 1/2“ sensor or 2/3“ sensor

Pin 1

1/2“ sensor

Pin 1

CCIR

2/3“ sensor

PCO 1999

VMC45-03/99

2. Video Module VM45 23

Gamma Setting The gamma setting can be done with the jumpers JP3, JP4 and

JP5, jumpered on the board "Video SPC".

JP3 JP4 JP5

Linear
Gamma 1
Gamma 2

off on off
off off on
on off on

Other combinations are not allowed !!

upper board
VIDEO SPC

JP5 JP3

GND

JP4

PCO 1999

VMC45-03/99

24 3. Servicing, Maintenance and Cleaning Instructions

3. Servicing, Maintenance and Cleaning
Instructions

Servicing, Maintenance and Cleaning Instructions

The camera is maintenance-free.
Factory settings make any inspection and servicing superfluous.

During use the camera should be protected from hard shocks or
strong vibrations.
Also should the camera be protected from high humidity and
temperature shocks. Avoid exposing to sunlight, since it heats
up the camera housing unnecessarily and prevents the cooling
from reaching its optimum operating temperature.
Keep apertures and slots free to allow air to circulate.

Objective lens or lens adapter should be screwed in gently.
Avoid forcing as it will damage the tread.

Use a soft and dry cloth to clean the housing.

Cleaning Method for the Optical Part

In principle every cleaning method bears the danger of damag­ing an optical surface.
Therefore clean only if it is strictly necessary.

As a first step use dry air to blow out dust particles. Avoid strictly
to wipe on a dry glass surface.
In case dirt cannot be removed by blowing, use special optical
cleaning fluids. Adequate fluids for optical surfaces are: pure
dehydrogenated alcohol, pure acetone or cleaning fluids avail­able in photo shops. Use a soaked cotton tip and take care to
wipe only on glass surfaces, avoiding contact to metal surfaces,
e.g. C-Mount thread, otherwise microscopic dirt and metallic
chips are released, causing irreparable scratches on the glass
surface.

Never use aggressive cleaning substances, e.g. benzine, spirit,
nitro solvents, etc. commonly found in labs. Such substances
may destroy or damage the surface on which they are applied.
The best is to avoid any dirt on optical parts, e.g. by replacing
immediately the black protection cap when removing the objec­tive lens. Do not leave the camera’s optical input window open,
without lens or protecting cap.

Our warranty does not cover damaged optical surfaces caused
by improper cleaning methods.

PCO 1999

VMC45-03/99

4. Appendix 25

4. Appendix

Customer Service

Having a problem or a question about matters not handled in
these operating Instructions, we recommend to contact us :

... by phone +9441 / 2005-0
... by fax +9441 / 2005-20
...by email [e-mail]

For a quicker reply we need following information:

• Short description of the problem

Typ: VC45

S/N: ....

• experiment conditions

• Camera serial-number (on the label placed on the bottom of

the camera)

Warranty

PCO grants a 12 month warranty period for the camera. The
warranty period starts on day of delivery ex-factory. In case of
defect within the warranty period replacement or repair will be
made (at PCO’s discretion) free of charge. The device shall be
returned on customer’s expenses to PCO, preferably in the
original package.
PCO is not liable for consequential damages.

Before returning the camera, contact PCO via any of the Cus­tomer Services.

Pay attention to use a sufficient package if you have to send the
camera via mail (keep the original package).

Attention Opening of the camera or improper handling (e.g. damage by

electrostatic charge, wrong cleaning method) voids the war­ranty.

PCO 1999

VMC45-03/99

26 4. Appendix

CE-Certification

VC45 complies with the requirements of the „EMC Directions of
the European Communities (089 / 336 / EWG)“ and therefore
bears the CE-Marking.

Dimensions and Weight

BNC

C-Mount

39mm

47mm

12mm

75mm

110mm

130mm

130mm

1/4”-20 UNC

M6

8,3mm

M6

25mm

37mm

50mm

PCO 1999

VMC45-03/99

Weight: about 300g

4. Appendix 27

Electrical Schematics of the board VMAIN

PCO 1999

VMC45-03/99

28 4. Appendix

System Data

Model VC45-C-12 VC45-C-23 VC45-N-12 VC45-N-23

Sensor format 1/2“ sensor 2/3“ sensor 1/2“ sensor 2/3“ sensor
Video Standard CCIR EIA RS170
Pixel Resolution 741 x 576 741 x 576 756 x 486 756 x 486
Pixel Size 8.6 x 8.3µm 11.6 x 11.2µm 8.4 x 9.8µm 11.6 x 13.5µm
Active Sensing Area 6.4 x 4.8mm 8.6 x 6.5mm 6.4 x 4.8mm 8.8 x 6.6mm
Horizontal Scanning Fre­quency
Vertical Scanning Fre­quency
Aspect Ratio 4/3 (hor./ver.) 4/3 (hor./ver.)
max. S/N ratio > 55dB > 55dB
Gamma linear, gamma 1, gamma 2 linear, gamma 1, gamma 2
Shutter Control 100µs ... 20ms 100µs ... 16.7ms
Long Exposure Internal: up to 20s

Gain Control internally or externally internally or externally
Operating Mode FRAME or FIELD interlaced FRAME or FIELD interlaced
Power Supply 12V DC 12V DC
Weight 290g 290g
Dimensions 47(W) x 39(H) x 130(L) mm 47(W) x 39(H) x 130(L) mm

15.625 kHz 15.625 kHz 15.734 kHz 15.734 kHz
50Hz 50Hz 60Hz 60Hz

Internal: up to 20s

External: up to DC

External: up to DC

PCO 1999

VMC45-03/99

Dear Customer,
We hope the VC45 / VM45 will be an always valuable tool for your scientific day

in, day out work.
Comments, suggestions or any new idea on our system are welcome.
We are at your disposal at any time, also after your buying of this camera.

Your PCO Team
