PCI Technical Manual
www.pci-suntektech.com
PCI-NVR2108-S/Switch
PCI-NVR2108-S/Switch
PCI-NVR2108-S/Switch
PCI-NVR2108-S/Switch 、 PCI-NVR2108-S/P
PCI-NVR2108-S/P
PCI-NVR2108-S/P
PCI-NVR2108-S/P O
O
O
O E
E
E
E
Features
Features
Features
Features
Step on the Internet ： With XM cloud service, easy to achieve a variety of network
penetration ,one step to remote monitoring.
Ideal Compression algorithm ： H.264 High Profile compression algorithm ， 30% decrease
of stream due to advanced space-time filtering technology.
Playback quality:Full real-time synchronously playback.
Video access ： 8ch1080P/8ch 720P/16ch D1 etc.
Mo-bite monitor: Support various mobile monitoring （ iPhone ， Windows Mobile ，
Black-Berry ， Symbion ， Android ） .
Display ： Support TV,HD VGA and HDMI output simultaneously(VGA 、 HDMI support
1080P HD output),overturn traditional monitoring thoroughly.
Operation interface ： Similar to CMS operating style, easy to get started with powerful
mouse right-click function.
Network ： Powerful network services (support DHCP, PPPOE,
FTP,
DNS, DDNS, NTP,
UPNP, EMAIL, IP permissions, IP searches, Alarm Center, etc.) and perfect support (WEB,
Client, SDK), easy to achieve interoperability.
Page 2
PCI Technical Manual
www.pci-suntektech.com
Browsers ： Support IE 、 Chrome 、 Firefox 、 Safari browsers.
Remote Access ： With its own domain name service functions (ARSP), and one key to
remote monitoring,monitoring becomes easy and enjoyable. 3322 (Greek network),
dyneins , oary (peanut shells), myq-see and other Domain Name Services are also
provided.
Device port ： support 2
SATA
ports ， 1 pieces of 4T HDD ， 2 USB2.0 ports ， easy to carry
out USB mouse, backup, burning, upgrading and other operations.
Differentiation: Boot screen free replacement, more than twenty languages, over 10 sets
of GUI interface, ten kinds of remote control, available in dozens of button panel, which
make our products different from others.
Others ： Perfect circuit protection, unique triple watchdog function, ensure that the
equipment never crashes. With unique black box technology, the whole process can be
monitored, which greatly reduces maintenance costs.
Page 3
PCI Technical Manual
www.pci-suntektech.com
Specifications
Specifications
Specifications
Specifications
model
model
model
model PCI-NVR2108-S/Switch
PCI-NVR2108-S/Switch
PCI-NVR2108-S/Switch
PCI-NVR2108-S/Switch PCI-NVR2108-S/P
PCI-NVR2108-S/P
PCI-NVR2108-S/P
PCI-NVR2108-S/P O
O
O
O E
E
E
E
System
System
System
System
main processor Hi3520D
operating system embedded Linux
system
resources
Simultaneous multi-channel real-time recording,
playback, network operation ， USB backup
Interface
Interface
Interface
Interface
user interface
support 16-bit true color graphical menu interface
and mouse operation
preview screen 1/4/9
video
video
video
video
Video standards PAL （ 625line ， 50f/s ）； NTSC （ 525line ， 60f/s ）
Video
compression
H.264(Main Profile)
display quality
monitor ： D1 ； VGA ， HDMI ： HD
（ support 1920*1080,
1280*720,1440*900,1280*1024, 1024*768 、
800*600 ）
play quality 1080P/720P/960H/D1/HD1/CIF/QCIF
decode capacity 1ch 1080P real-time
motion detect support
Audio
Audio
Audio
Audio
audio
compression
G.711A
Bidirectional talk NO supported
Record&
Record&
Record&
Record&
playback
playback
playback
playback
record mode manual>alarm>motion detection>timing
local playback
1/2ch(1080P) ； 4ch(720P)
search mode Time/calendar/event/channel search
Storage&
Storage&
Storage&
Storage&
backup
backup
backup
backup
space
occupation
Video: 1080p 80G/day/ch, 720p 26G/day/ch, 960H
24G/day/ch,
D1 16~20G/day/ch ; Audio: 691.2M/day/channel
record storage HDD,network
Page 4
PCI Technical Manual
www.pci-suntektech.com
backup mode
Network backup,USB HDD,USB writer,SATA
writer
interface
interface
interface
interface
video input 8ch 1080P/8ch 720P/16ch D1
video output
1ch BNC(1.0Vp-p,75 Ω ) ， 1ch VGA 、 1ch HDMI HD
output
Loop-through
output
Not supported
audio input no
audio output 1ch
alarm input no
alarm output no
net interface
5*RJ45 10M/100M
(optional poe)
5*RJ45 10M/100M ,
support poe
PTZ control 1*RS485 ， support 18 kinds of PTZ protocols
USB 2*USB2.0 （ reserve 2 front-end interface ）
HDD
2* SATA （ max.4T per one ）
others
others
others
others
Power supply 12V/3A
12V/3A ，
48V/1.5A(POE)
Working
temperature
0 ℃ - ＋ 55 ℃
Working humidity
10% － 90%
Atmospheric
pressure
86kpa － 106kpa
dimension 350mm* 295mm* 45mm
ONVIF support
