PCE Instruments PCE-S 41 Users guide

© PCE Instruments

Electronic Stethoscope PCE-S 41

User Manual

User manuals in various languages (français,

italiano, español, português, nederlands, türk, polski,

русский, 中文) can be found by using our

product search on: www.pce-instruments.com

Last change: 25 February 2022

v1.0

English

Contents

1 Safety notes ........................................................................................... 1

2 Technicalspecifications ....................................................................... 2

3 Measurement ......................................................................................... 2

4 Battery replacement.............................................................................. 2

5 Contact ................................................................................................. 2

6 Disposal ................................................................................................. 2

© PCE Instruments

© PCE Instruments

1

1 Safety notes

Please read this manual carefully and completely before you use the device for the first time. The
device may only be used by qualified personnel and repaired by PCE Instruments personnel.
Damage or injuries caused by non-observance of the manual are excluded from our liability and
not covered by our warranty.

• The device must only be used as described in this instruction manual. If used otherwise,
this can cause dangerous situations for the user and damage to the meter.

• The instrument may only be used if the environmental conditions (temperature, relative

humidity, …) are within the ranges stated in the technical specifications. Do not expose

the device to extreme temperatures, direct sunlight, extreme humidity or moisture.

• Do not expose the device to shocks or strong vibrations.

• The case should only be opened by qualified PCE Instruments personnel.

• Never use the instrument when your hands are wet.

• You must not make any technical changes to the device.

• The appliance should only be cleaned with a damp cloth. Use only pH-neutral cleaner,

no abrasives or solvents.

• The device must only be used with accessories from PCE Instruments or equivalent.

• Before each use, inspect the case for visible damage. If any damage is visible, do not

use the device.

• Do not use the instrument in explosive atmospheres.

• The measurement range as stated in the specifications must not be exceeded under

any circumstances.

• Non-observance of the safety notes can cause damage to the device and injuries to
the user.

We do not assume liability for printing errors or any other mistakes in this manual.
We expressly point to our general guarantee terms which can be found in our general terms of

business.
If you have any questions please contact PCE Instruments. The contact details can be found at

the end of this manual.

2 Technicalspecifications

Frequency range

100 Hz … 10 kHz

Volume

adjustable

Power

9V battery

Housing material

ABS

Operating temperature

-10 ... 55 °C / 14 ... 131 °F

Dimensions

206 x 50 x 32 mm / 8.11 x 1.9 x 1.2 in

Length of sensors (attachable)

1 mm x 290 mm; 1 mm x 70mm

0.04 in x 11.4 in ; 0.04 in x 2.8 in

Sensor material

Steel

Weight

240 g / 0.53 lbs with battery

3 Measurement

Open the battery compartment cover on the underside of the housing and insert the battery.
Now screw the required probe tip onto the device.
Insert the headphones at the bottom of the housing and put them on. Use the wheel on the outside
to switch on the instrument and adjust the volume. After switching on the instrument, the LED
indicator at the front lights up. Now hold the probe tip on the object to be tested.

Attention:
Keep the probe and the headphone cable away from freely rotating objects to avoid accidents.

4 Battery replacement

1) Switch off the meter.

2) Remove the battery compartment cover.

2) Remove the old battery and insert the new battery (1 x 9 V block battery).

3) Close the battery compartment cover.

5 Contact

If you have any questions, suggestions or technical problems, please do not hesitate to contact

us. You will find the relevant contact information at the end of this user manual.

6 Disposal

For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament
applies. Due to the contained pollutants, batteries must not be disposed of as household waste.
They must be given to collection points designed for that purpose.

In order to comply with the EU directive 2012/19/EU we take our devices back. We either re-use
them or give them to a recycling company which disposes of the devices in line with law.

For countries outside the EU, batteries and devices should be disposed of in accordance with
your local waste regulations.

If you have any questions, please contact PCE Instruments.
