PCE Instruments PCE-CRC 10 User Manual

PCE-CRC 10 Adhesion Tester
User Manual
français, italiano, español, português, nederlands,
türk, polski, русский, 中文) can be downloaded here:
www.pce-instruments.com
Last change: 20 December 2016
v1.0
English
© PCE Instruments
Contents
1 Safety notes ........................................................................................... 1
2 Test procedure ...................................................................................... 2
3 Analysis ................................................................................................. 3
4 Warranty ................................................................................................. 4
5 Disposal ................................................................................................. 4
© PCE Instruments
1 Safety notes
Please read this manual carefully and completely before you use the device for the first time. The device may only be used by qualified personnel and repaired by PCE Instruments personnel. Damage or injuries caused by non-observance of the manual are excluded from our liability and not covered by our warranty.
The device must only be used as described in this instruction manual. If used
otherwise, this can cause dangerous situations for the user and damage to the meter.
The device must only be used with accessories from PCE Instruments or equivalent.
Otherwise, PCE Instruments does not grant any warranty or assume any liability for defects or damage.
Do not make any technical changes to the device.  Non-observance of the safety notes can cause damage to the device and injuries to
the user. We do not assume liability for printing errors or any other mistakes in this manual. We expressly point to our general guarantee terms which can be found in our general terms of
business. If you have any questions please contact PCE Instruments. The contact details can be found at
the end of this manual.
© PCE Instruments
1
2 Test procedure
1. Place the cross-cut tester on the test object, apply soft pressure and pull the device towards yourself in even movements in order to make parallel cuts with a length of approx. 20 mm. Apply enough pressure to make sure that you reach the next layer or carrier material.
2. Place the cutting tool on the sample at 90° to the first cut and repeat step 1 to create a lattice pattern on the coating (Figure
1).
3. Use a brush to remove dirt from the
lattice and inspect to ensure the cuts have penetrated all the way through the coating (Figure 2).
4. Remove and discard two complete turns of adhesive tape. Remove an additional length of tape at a steady rate and cut a piece approximately 75 mm from this length.
5. Place the turns in the middle of the lattice and use a pencil eraser to straighten the adhesive tape. (Image 3)
6. Remove the adhesive tape carefully in a 180 ° angle. (Image 4)
7. Analysieren the result.
8. Repeat the test in two more positions.
Note: If you would like more information on this test method, please have a look at the relevant standard (ISO/ASTM).
Figure 1
Figure 2
Figure 3
Figure 4
© PCE Instruments
2
3 Analysis
The edges of the cuts are completely smooth; none of the squares of the lattice is detached.
0
5B
Detachment of flakes of the coating at the intersections of the cuts. A cross cut area not significantly greater than 5% is affected.
1
4B
The coating has flaked along the edges and/or at the intersections of the cuts. A cross cut area significantly greater than 5%, but not significantly greater than 15% is affected.
2
3B
The coating has flaked along the edges of the cuts partly or wholly in large ribbons, and/or it has flaked partly or wholly on different parts of the squares. A cross cut area significantly greater than 15%, but not significantly greater than 35%, is affected.
3
2B The coating has flaked along the
edges of the cuts in large ribbons and/or some squares have detached partly or wholly. A cross cut area significantly greater than 35%, but not significantly greater than 65%, is affected.
4
1B
Any degree of flaking that cannot be classified even by classification 4 (1B).
5
0B
Coating adhesion can be assessed by comparing the lattice of cuts with ASTM or Corporate Standards. The ASTM standards are reproduced in the following table.
© PCE Instruments
3
4 Warranty
You can read our warranty terms in our General Business Terms which you can find here:
https://www.pce-instruments.com/english/terms.
5 Disposal
In order to comply with the EU directive 2012/19/EU we take our devices back. We either re-use them or give them to a recycling company which disposes of the devices in line with law.
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations.
If you have any questions, please contact PCE Instruments.
© PCE Instruments
4
