PCE Instruments PCE-BPD-RK Users guide

User’s Manual

PCE-BPD-RK

Remote keypad PCE-BPD-RK

Accessories for industrial big panel displays. Remote keypad for operator remote access to menu

funcons and front keys.

5542r00

www.pce-instruments.com

PCE Instruments

1. Remote keypad PCE-BPD-RK

Industrial keypad with 3 push buons to connect to big panel
displays from PCE-BPD. It allows to replicate the front keypad
of the instrument to a remote locaon.

A PCE-BPD-RK remote keypad allows the operator to access
the advanced control funcons from the big panel displays,
such as fast access to alarm setpoints, preset value modi­caon, access to maximum and minimum reading values,
signal
unlock, ...

tare for load applicaons, front reset, manual alarm

All these features are accessible while maintaining the main
feature of these instruments, which is the installaon in
heights for long distance reading.

The PCE-BPD-RK remote keypad is provided with an in-

dustrial IP65 protected housing, with cable gland output,
aligne

d with the technical specicaons of the big panel dis­plays. The PCE-BPD-RK remote keypad can be easily installed
against wall. The push buons are 25 mm size for easy use
even with protecon gloves.

The PCE-BPD-RK remote keypad is provided with labeled

push buons and does not included cable.

Normal buon state open
Recommended wire 0.25 mm2
Protecon IP65
Output by cable gland
Mounng accepts wall mount
Color grey
Material plasc
Weight 200 gr

GND

(<)

SQ

UP

(5)

LE

(3)

Connect the wire to the 4 pole terminal located close to the
input signal module. Connect 4 wires for keys ‘SQ’ (<), ‘UP’
(5), ‘LE’ (3) and common. Pass the wires through the cable
gland idened as ‘remote keypad’ (see Figure 2) and connect
the other end to the internal PCE-BPD-RK push buons.

2

181 mm

75 mm

PCE Instruments | www.pce-instruments.com

GND
SQ

(<)

UP

(5)

LE

(3)

Figure 1 - Connecons from PCE-BPD-RK to the internal 4 pole terminal

Power

Opon 3 Opon 2

Remote keypad

SignalOpon 1

Figure 2 - instrument front view (top), rear view (middle) and internal view (boom). Format with 6 digits.
