Page 1
PBM
ELECTRONIC CASH REGISTER
NE-2
OPERATION MANUAL
Date: Dec 7, 2005
Version: 002
PBM NE-2 operation ManualPBM NE-2 operation ManualPBM NE-2 operation ManualPBM NE-2 operation Manual
Page 2
1
1. MAIN FEATURES
1.1. Hardware & Software Features
Standard Hardware
z Printer
2-station fast, quiet thermal printer
100 mm/second
21 columns for receipt/ journal
z Display
10-digit VFD display for operator and customer.
z 5- position control lock or Software lock
z 38 keys with key caps
z Communications Ports: 2 RS232
Optional Hardware
z External terminal printer:
-- Epson TM-88 (POS series) thermal printer (PBM POSⅢ -01/02)
-- Epson TM-U210
-- Citizen IDP-3100 dot-matrix printer
z Barcode scanner
z Cash drawer
z External PS/2 keyboard for more 120 keys
Software Features
z Up to large (9999) Price Look Ups (PLUs) (The total number of PLUs available values
by memory allocation)
z Standard 6 max. 50 departments
z Up to 15 clerks with name and password
z 12 characters programmable descriptors for PLU/department and functions
z Tax function
6 tax rates with Value –Added Tax (VAT)
3 tax rates with Add-on Tax
z Void, Error Correct, Return Merchandise, Void all transaction functions etc
z Electronic journal capability
Sale journal/ R.M. journal/ discount journal
z Cash, Misc, 4 preset cash and 5 check/charge tender functions
z 10 built-in logos & 1 user-defined
z 6-line programmable welcome and trailer message
z Redefine each key location
z Training Mode for new clerks
