PB S-6C User Manual

Congratulations on your purchase of Powerbass Autosound speakers. You now own a
speaker of uncompromising design and engineering from a factory that truly believes in
the relentless pursuit of perfection. Incorporating the highest quality parts and
state-of-the-art materials, these speakers display the ultimate balance between high
fidelity, performance and long-lasting reliability.

At PowerBass USA, Inc. we are confident you will have many years of outstanding
enjoyment from this great SPEAKER investment. For maximum performance we
recommend that you have your new PowerBass Autosound product installed by an
Authorized PowerBass Autosound Dealer.

To learn more about PowerBass, please visit us on the World Wide Web at

http:/www.powerbassusa.com

∆ Warning ∆

Continuous exposure to sound pressure levels in excess of 100 dB can cause permanent hearing
loss. PowerBass Autosound Speakers are capable of producing sound pressure levels well over
170 dB. Please observe all local sound ordinances while listening to your PowerBass Autosound
system. PowerBass USA, Inc. accepts no liability for hearing loss, bodily injury, or property damage

Thank you and Congratulations

POWERBASS AUTOSOUND S COMPONENT FEATURES

Stamped Powder Coated Black Basket: These rigid baskets are designed to give the
moving parts of the speaker the solid, corrosion free platform that they need to perform
for even the most discriminating listener.

Proprietary 2-layer paper, DDC (Dynamic Damping Coating) cone: The choice of
cone materials has everything to do with the difference between good and great sound.
Paper delivers one of the warmest sounds available along with the DDC finish to give
your music uncompromised fidelity.

Double Pressed Treated Rolled Foamed Surround: The high damping, double rolled
foam surround on these speakers ensure linear travel throughout the entire frequency
range resulting in more bass output and higher efficiency while reducing distortion.

Balanced Pure Silk Soft Dome Tweeter: These hand treated silk dome tweeters
incorporate a neodymium motor structure and edge wound ribbon wire voice coil to
provide a wide bandwidth.

High Power, Multi-Layer ASV Voice Coil: Aluminum is a high temperature voice coil
former that is light weight and designed for greater efficiency and increased power
handling that gives you that loud and clear sound that you are listening for.

Crossover Network: The included crossover networks were designed specifically for
our speakers to recreate the frequencies within a precise range ensuring the tweeter does
not receive low bass notes and the mid bass driver does not receive high frequencies. A
Poly Switch current limiter has been added to the crossover circuit to protect the
tweeters against overload.

Tweeter Mounting Kit: Flush, surface and angle-mounting cups allows multiple
mounting options for custom tailored high frequency dispersion.

Additional Features: Acoustically transparent speaker grills, professional mounting
hardware and speaker wires adds further value to your investment.

SPECIFICATIONS FOR POWERBASS S COMPONENTS

(Due to Constant Improvements, Specifications and Parameters are subject to change without notice.)

Model # Size

Nominal

Impedance

Frequency

Response

Sensitivity

1W/1M

Magnet

Size

Mounting

Depth

S-5C 5.25" 4-ohm 65Hz - 20kHz 89 dB 10 oz. 2.0" 50W/150W

S-6C

6.5"

4-ohm

60Hz - 20kHz

90 dB

10 oz.

2.3" 70W/210W

INSTALLATION EXPERIENCE

Installation of PowerBass Autosound Speakers requires experience with a variety of
mechanical and electrical procedures. This manual only provides general installation and
operation instructions. If you have any reservations about your installation skills or lack
