Paxton Access
18/03/2008
Ins-30071-US Net2 desktop reader, proximity and magstripe USB
Technical Support
1 800 672 PAXT
Technical help is available: Monday - Friday from 5am - 5pm PST / 8am - 8pm EST
Other documentation on all Paxton products can be found on our web site - http://www.paxton-access.com/
support@paxton.co.uk
USB desktop reader
The desktop reader is designed to sit next to the PC. It is used for adding tokens to a Net2 system. It can also be used for
identifying lost cards. Additional workstations can also have desktop readers.
If a new token is presented to the desktop reader then the new user wizard will appear with the appropriate card number. The
name and details of the new user can be entered and the token issued.
If a token which is already known to the system is presented to the desktop reader, then the relevant users’ record will appear.
Installation
Plug the reader into a convenient USB port on the PC with the supplied USB cable.
Restart the PC and the device will now be available to the Net2 program.
This ensures that which ever version of Net2 you are running, the new device will be correctly congured for that server type.
No other software conguration is then required.
NOTE: This unit requires Net2 v3.09 or later software. Please call Technical Support if you require advice or a software upgrade.
Specications
Environment
Operating temperatures - all items
Waterproof
Electrical
Voltage
Current
Dimensions
Min
0 °C ( 32 °F )
Min
4.75V DC 5.25V DC
Width
5 3/4 inches 3 1/2 inches
Max
55 °C ( 131 °F )
Max
100 mA
Depth
No
USB certied
Height
1 1/2 inches
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Changes or modications not expressly approved by
the party responsible for compliance could void the user’s authority to operate the equipment.
Paxton Access
18/03/2008
Ins-30071-US Net2 desktop reader, proximity and magstripe USB
Technical Support
1 800 672 PAXT
Technical help is available: Monday - Friday from 5am - 5pm PST / 8am - 8pm EST
Other documentation on all Paxton products can be found on our web site - http://www.paxton-access.com/
support@paxton.co.uk
USB desktop reader
The desktop reader is designed to sit next to the PC. It is used for adding tokens to a Net2 system. It can also be used for
identifying lost cards. Additional workstations can also have desktop readers.
If a new token is presented to the desktop reader then the new user wizard will appear with the appropriate card number. The
name and details of the new user can be entered and the token issued.
If a token which is already known to the system is presented to the desktop reader, then the relevant users’ record will appear.
Installation
Plug the reader into a convenient USB port on the PC with the supplied USB cable.
Restart the PC and the device will now be available to the Net2 program.
This ensures that which ever version of Net2 you are running, the new device will be correctly congured for that server type.
No other software conguration is then required.
NOTE: This unit requires Net2 v3.09 or later software. Please call Technical Support if you require advice or a software upgrade.
Specications
Environment
Operating temperatures - all items
Waterproof
Electrical
Voltage
Current
Dimensions
Min
0 °C ( 32 °F )
Min
4.75V DC 5.25V DC
Width
5 3/4 inches 3 1/2 inches
Max
55 °C ( 131 °F )
Max
100 mA
Depth
No
USB certied
Height
1 1/2 inches
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Changes or modications not expressly approved by
the party responsible for compliance could void the user’s authority to operate the equipment.
