Paxton Access 337520A VR Panel datasheet
Net2 Entry - VR Panel
System specifcations
DS1060
Power over Ethernet (PoE)
Ethernet bandwidth requirement
Panels per system
TCP/IP ethernet extension limit
Cable type
Token compatibility
Features
Audio system
Camera system
Back-lit LCD
PIN/Code entry
Proximity and PIN/Code entry
Vandal resistant
IDC connector
Environment
Operating temperature
Moisture resistance
Vandal Resistance
Yes
- IEEE 802.3af class 0
1Mb/s multicast per panel during call
100
100m/328ft
CAT5
Paxton
EM
MIFARE ®
Two way
Full colour
Yes
Yes
Yes
- only in conjunction with Net2 software
Yes
Optional
-20°C - +50°C
-4°F - +122°F
IPX5
IK10
The Net2 Entry panel is a robust door entry panel incorporating
both door entry and access control functions. It is powered using power over Ethernet (PoE) and communicates with the other elements of the system using IPv6, providing 'plug and play'
installation. Each panel is associated with a Net2 Entry control
unit which is the interface to the door hardware.
The panel is equipped with a keypad and a proximity token
reader. A resident can use either the keypad or a token to gain
entry. Installers gain access to the menu options using an engineer code or an engineer token.
Net2 software is used to administer the access control functions.
Decide how the units are to be connected. You can either run
your own wired network or (with the owner’s permission) share
the buildings existing data network. If using the owners network, the system uses IPv6 protocol and PoE (Power over Ethernet) so the network must support this switch type.
Dimensions
DS1060
11.6”
295 mm
110 mm
4.3”
35 mm
1.4”
336
13”
151 mm
6”
3 mm
0.14”
12”
300 mm
115 mm
4.5”
62.5 mm
2.5”
45 mm
1.8”
35 mm
1.4”
