PAX Technology PX5W User Manual

PAX TE CHNOLOG Y INC.

Product Description

Stylu s pen

Touch scr een and Conta ctless reade r area

Magne tic strip e reader

Priva cy shield

Keypa d

Smart c ard reade r

Cable r etentio n cover p late

Commu nicatio n ports - l ocated under c over plat e

Speak ers

Regul atory lab el

Part nu mber/ seria l number la bel

Commu nicatio n modul e

MAC add ress labe l

Commu nicatio n ports a re labe led and c olor- coded :

White Red Yel low Black Green Blue

PAX TE CHNOLOG Y INC.

Communication Module

P terminals that include a default communication module come standard with one Ethernet port and RS232, USB, and PUSB network capabilities. However, if the default communication module is replaced with an optional communication module, your choice of these additional network capabilities are available:

• A second Et hernet po rt

• Power ove r Etherne t

• An Etherne t hub

The commu nicatio n module is l ocated on t he unders ide of the termi nal.

WARNING:

Power down and remove all power from the terminal before removing or installing a communication module. A communication module must be installed before power can be applied to the terminal.

• Wi-Fi and Bl uetoot h LE

• Wi-Fi and Ce llular GS M

Commu nicatio n modul e

Power Connections

Power can be supplied via the power port or a single data cable that carries power. This power can be provided via a “powered cable” where the connected POS terminal provides the power (i.e. PUSB or Power over Ethernet) or by connecting a P power supply directly to the data cable (i.e. RS232 or USB).

1) Power Port Insert the power connector into the green POWER port. Turn the power connector, locking the tab behind the short plastic wall. Dress the cable through the retention clips. A separate data cable is also required.

2) POS Cable Insert the cable connector into the appropriate port on the terminal. Dress the cable through the retention clips opposite the port. Connect power supply to cable as required. The cash register could also supply power to terminal.

3) Power over Ethernet (PoE) Power is available over the red LAN1 port when the optional PoE communication module is installed. Cable Retention Cover Plate After power and data cables are connected and dressed through retention clips, install the cable retention cover plate and secure with captive screw.

Working Environment: Temperature -10°C～50°C (14°F～122°F) R.H.: 10%～93% (non-condensing) Storage Environment: Temperature -20°C～60°C (-4°F～140°F) R.H.: 5%～95% (non-condensing)

Screw

PAX TE CHNOLOG Y INC.

Stylus Holder and Pen

1) Mou nting Loc ation s

2) St ylus P ort

Privacy Shield

3) Ret entio n Cli ps

Privacy Shield

1) Align stylus holder over metal screw openings at left side or top of terminal. Insert tabs into indentations along edge. Attach with captive screws.

2) Insert connector end of stylus pen into stylus port on left side of terminal.

3) Use enclosed plastic card to press stylus cord into retention clips on left side of terminal.

Insert tabs and snap shield firmly in place to left and right of keypad. Not designed to be removable. Removing the shield breaks the retention tabs and the ability to remotely track the status of the shield is lost.

Decorative Plug – If a privacy shield is not

installed, a non-removable decorative plug may be installed in its place. This plug does not provide any PIN entry privacy.

CAUTION: If the privacy shield is not installed,

you must use PCI-approved alternative methods to secure the PIN pad.

1Privac y Shield

Decorat ive Plug

Plugs

1) Stylus Holder Plug If required, to prevent stylus pen from being inserted vertically into stylus holder, firmly insert plug into opening in holder, aligning with curve of stylus holder.

2) Smart Card Reader Plug If required, insert smart card reader plug into smart card receptacle slot. To remove, if required, gently pry out the plug using a small screwdriver in the slit along top of plug.

3) Ethernet Plug An Ethernet plug is included in case you want to block an inactive LAN port. Align plug so that it matches the shape of the port and gently push into opening. To remove, if required, gently pry off using a small screwdriver in the slit along the top of the plug.

Note: LAN2 port is enabled only when Ethernet hub or PoE and Ethernet hub communication module is installed.

3) Et herne t Plu g

1) Stylus Holder Plug

2) Smart Card Reader Plug

PAX TE CHNOLOG Y INC.

Reset Button and Audio Jack

If required, restart the terminal by pressing in and holding the reset button for 2-3 seconds

If required, a visually disabled person can connect a headphone to the terminal for audio prompting using the

3.5mm output audio jack.

Cable Lock

If required, insert customer-provided cable lock into K-Slot®. Loop cable around permanent object to secure in place.

Res et Button

Stylu s Por t

Audio J ack

Stand Installation

If required, the P terminal may be mounted to a stand. Instructions may vary depending on stand specifications.

Carefully route the required cables up through the stand pipe and out the top. Connect the cables to the

P terminal ports.

Insert the three mounting slots on the underside of the terminal into the three metal prongs on the stand base.

Slide the terminal firmly into position, locking the terminal in place on the stand. Secure with fastening screw or locking device as required.

Route

Cables

Mounting

Slots

P/N:20031 20 00000224

This do cumen t is provi ded to yo u for inf ormational purp oses only. All fea tures an d speci ficat ions are s ubjec t to chan ge witho ut noti ce. PAX's name and PAX's l ogo are regis tered

trade marks o f PAX Tec hnolo gy Inc. All ri ghts res erved .

PAX Tech nolog y Inc.

4901 Belfort Roa d, Suite 130 Jacksonville , FL 32256, US A T: 877-859-0099 W: www.pax.us E: sales@p ax.u s

PAX TE CHNOLOG Y INC.

Cleaning the Device

WARNING:

Do not use industrial strength or abrasive cleaner as it may damage or scratch the screen. Do not immerse device in water (or liquid.) Do not spray water or cleaner into the MSR slot, Smart Card Reader or ports. To clean screen, apply distilled water or mild glass cleaner onto a soft, lint-free cloth and gently wipe terminal screen. To clean terminal, apply distilled water or plastic-safe cleaner onto a soft, lint-free cloth and gently wipe terminal.

Available Accessories

RS232 Cable

200204020000140

Requires Power Supply

USB Cable

200204020000141

Requires Power Supply

Power Supply

200310110000070

Requires Power Cord

Stylus Pen

200209090000929

Privacy Shield

200209060000040

Power Cord

200311020000023

Requires Power Supply

Stylus Holder Plug

200209090000930

Decorative Privacy

Shield Plug

2002090900001037

FCC Regulations:

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiated radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Increa se the sepa ration be tween the e quipmen t and receive r.

-Connec t the equip ment into a n outlet on a c ircuit

diffe rent from t hat to whic h the recei ver is conn ected.

-Consul t the deale r or an exper ienced ra dio/T V technic ian for hel p.

11 12

Caution : Changes o r modific ations no t express ly approve d by the part y respons ible for co mplianc e could

void the us er's auth ority to op erate the e quipm en t.

RF Exposure Information

This devi ce meets th e governm ent's req uiremen ts for exposur e to radio wa ves.Thi s device is d esigned a nd manufac tured not t o exceed th e emissio n limits fo r exposur e to radio fr equency ( RF) energ y set by the Federal C ommunic ations Co mmissio n of the U.S. Governm ent.

This devi ce compli es with FCC r adiatio n exposur e limits set forth f or an uncon trolled e nvironm ent. In ord er to avoid the p ossibil ity of exce eding the F CC radio frequen cy exposu re limits , human pro ximity to t he

antenna s hall not be l ess than 20 cm (8 inche s) during normal op eration .
