Installation Manual

D190 Mobile payment terminal

PAX TECHNOLOGY LIMITED

PAX TECHNOLOGY LIMITED

1. Contents Checklist

Please check the components after unpacking. If any one of them is missing, or if there is a page

missing from the product manual,ect., please contact the deale.

Name Qty.

D190 Mobile payment terminal 1

AC Power Adapter 1

USB Cable 1

Battery 1

Product Manual 1

2. Installation

SAM/SIM Card：

1) Remove the battery cover.

2) Remove the battery.

3) Insert the SAM/SIM card to the corresponding card slot (PS: The default hardware

configuration only support SIM1 slot).

Battery:

Alignment battery tip side to battery tip in terminal and insert.

3. Instructions

1) Power ON/OFF

Power on: Plug in power adapter or insert the battery, Press button for 3 seconds

until the PAX LOGO display on LCD.

Power off: Press button for 3 seconds until the “Power off ” display on the

LCD ,then press “ENTER”, then the POS terminal is being turned off.

2) IC Card

Put IC card chip side upward, push-in IC card slot and to bottom.

3) Contactless Card

The card read area is above the LCD, Put the card above the LCD.

4) Battery Charge display

Connecting USB port with external adapter can charge the battery. And there are charging

display.

5) Battery Charge style

Please use the original adapter, if you need to charge.

Working Environment Temperature: 0℃～50℃(32℉～122℉)

Humidity: 10%～93%( non-condense)

Storage Environment Temperature:-20℃～70℃(-4℉～158℉)

Humidity.:5%～95% (non-condense)

PAX TECHNOLOGY LIMITED

4. Installation and Usage Tips

1) Avoid putting the terminal in direct sunlight, high temperature, moist, or dusty environment.

2) Forbid non-professional to repair the terminal.

3) Before insert the card, please check internal and around of IC card slot. if you found some

suspicious objects , must report to related administrator.

5. Lithium Ion Battery Usage Tips

WARNING:
1）Don't use the battery in sunlight or smoke, dust environment.
2）Prohibited to strike, squeeze and tread on battery or throw it into the liquid and fire.
3） If battery is impressive, deformed, damaged or exothermic seriously, please stop using

immediately and replace it!

4）If the continuous working time is only half of new one, the battery life may be end. Please

replace it!

5）Must use the specified battery model and charger, otherwise there will be explosion
6）Charging time can not exceed 24 hours. If the battery is out of power, please recharge in time.

Avoid damaging the battery in over-charge and over-discharge.

7）If be non-use for long time, please recharge the battery per 6 months to avoid shortening its life.
8）Suggest to replace it when the battery have been used for 2 years.
9）Be sure to follow the instructions to dispose the wasted batteries.

FCC Regulations:

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

This device has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiated radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

PAX TECHNOLOGY LIMITED

measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

-Consult the dealer or an experienced radio/TV technician for help.

Caution: Changes or modifications not expressly approved by the party responsible for

compliance could void the user‘s authority to operate the equipment.

FCC RF Exposure Information (SAR)

This device is designed and manufactured not to exceed the emission limits for exposure

to radio frequency (RF) energy set by the Federal Communications Commission of the

United States.

During SAR testing, this device is set to transmit at its highest certified power level in all

tested frequency bands, and placed in positions that simulate RF exposure in usage near

the body. Although the SAR is determined at the highest certified power level, the actual

SAR level of the while operating can be well below the maximum value. This is because

the device is designed to operate at multiple power levels so as to use only the power

required to reach the network. In general, the closer you are to a wireless base station

antenna, the lower the power output.

The exposure standard for wireless employs a unit of measurement known as the Specific

Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg.

The FCC has granted an Equipment Authorization for this model device with all reported

SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR

information on this model device is on file with the FCC and can be found under the

Display Grant section of www.fcc.gov/oet/ea/fccid after searching on

FCC ID: V5PD190

For this device, the highest reported SAR value for usage near the body is 0.41 W/kg.

While there may be differences between the SAR levels of various devices and at various

positions, they all meet the government requirement.

PAX TECHNOLOGY LIMITED

ISED Notice

This device complies with Innovation, Science and Economic Development Canada

license-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may cause

undesired operation of the device.

Le présent appareil est conforme aux CNR Innovation, Sciences et Développement

économique Canada applicables aux appareils radio exempts de licence. L'exploitation

est autorisée aux deux conditions suivantes:

(1) l'appareil ne doit pas produire de brouillage, et

(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le

brouillage est susceptible d'en

IC: 11689A-D190

ISED Radiation Exposure Statement

This EUT is in compliance with SAR for general population/uncontrolled exposure limits in

ISED RSS-102 and had been tested in accordance with the measurement methods and

procedures specified in IEEE 1528 and IEC 62209. This device and its antenna(s) must

not be co-located or operating in conjunction with any other antenna or transmitter.

Cet appareil est conforme aux limites d'exposition DAS incontrôlée pour la population

générale de la norme CNR-102 science de l’innovation et le développement économique

Canada et a été testé en conformité avec les méthodes de mesure et procédures

spécifiées dans IEEE 1528 et IEC 62209. Cet appareil et sa ou ses antennes ne doivent

pas être co-localisés ou fonctionner en conjonction avec tout autre antenne ou

transmetteur.

PAX TECHNOLOGY LIMITED

PAX TECHNOLOGY LIMITED reserves the right to change

product technology specifications without notifying.

PAX TECHNOLOGY LIMITED

Manufacturer: PAX Computer Technology (Shenzhen) Co.,Ltd.
Address:4/F, No.3 Building, Software Park, Second Central Science-Tech Road,
High-Tech Industrial Park, Shenzhen, Guangdong, P.R.C.
Tel: [phone] Fax: [phone]
Website: http://www.pax.com.cn
Responsible Party: PAX Technology, Inc.
8880 Freedom Crossing Trail, Building 400, 3rd Floor Suite 300, Jacksonville ,
Florida, 32256
Tony Fernandez
[phone]
