Patton electronics SMART NODE 4950-NCE, SmartNode 4950-NCE Series Getting Started Manual
For Quick
Start Installation
SmartNode 4950-NCE Series
Multi-Port T1/E1/PRI VoIP
Enterprise Gateway Router
Getting Started Guide
Sales Office: +1 (301) 975-1000
Technical Support: +1 (301) 975-1007
E-mail: support@patton.com
WWW: www.patton.com
Part Number: 07MSN4950-NCE-GS, Rev. A
Revised: August 31, 2011
Patton Electronics Company, Inc.
7622 Rickenbacker Drive
Gaithersburg, MD 20879 USA
Tel: +1 (301) 975-1000
Fax: +1 (301) 869-9293
Support: +1 (301) 975-1007
Web: www.patton.com
E-mail: support@patton.com
Trademark Statement
The terms SmartNode and SmartWare are trademarks of Patton Electronics Company.
All other trademarks presented in this document are the property of their
respective owners.
Copyright © 2008-2011, Patton Electronics Company. All rights reserved.
The information in this document is subject to change without notice. Patton Electronics assumes no liability for errors that may appear in this document.
Important Information
To use virtual private network (VPN) and/or AES/DES/3DES encryption capabilities
with the SmartNode 4950-NCE, you may need to purchase additional licenses, hardware, software, network connection, and/or service. Contact sales@patton.com or
+1 (301) 975-1000 for assistance.
Warranty Information
The software described in this document is furnished under a license and may be used
or copied only in accordance with the terms of such license. For information about the
license, see Appendix F, "End user license agreement" on page 63 or go to
www.patton.com.
Patton Electronics warrants all SmartNode router components to be free from defects,
and will—at our option—repair or replace the product should it fail within one year
from the first date of the shipment.
This warranty is limited to defects in workmanship or materials, and does not cover
customer damage, abuse or unauthorized modification. If the product fails to perform
as warranted, your sole recourse shall be repair or replacement as described above.
Under no condition shall Patton Electronics be liable for any damages incurred by the
use of this product. These damages include, but are not limited to, the following: lost
profits, lost savings and incidental or consequential damages arising from the use of or
inability to use this product. Patton Electronics specifically disclaims all other warranties, expressed or implied, and the installation or use of this product shall be deemed
an acceptance of these terms by the user.
Summary Table of Contents
1 General information...................................................................................................................................... 13
2 Applications overview.................................................................................................................................... 20
3 SmartNode installation.................................................................................................................................. 22
4 Initial configuration ...................................................................................................................................... 27
5 G.SHDSL Basic Configuration ..................................................................................................................... 36
6 Contacting Patton for assistance ................................................................................................................... 41
A Compliance information .............................................................................................................................. 44
B Specifications ................................................................................................................................................ 46
C Cabling ......................................................................................................................................................... 53
D Port pin-outs ................................................................................................................................................ 58
E SmartNode 4950-NCE factory configuration ............................................................................................... 61
F End user license agreement ........................................................................................................................... 63
3
Table of Contents
Summary Table of Contents ........................................................................................................................... 3
Table of Contents ........................................................................................................................................... 4
List of Figures ................................................................................................................................................. 7
List of Tables .................................................................................................................................................. 8
About this guide ............................................................................................................................................. 9
Audience................................................................................................................................................................. 9
Structure................................................................................................................................................................. 9
Precautions........................................................................................................................................................... 10
Safety when working with electricity ...............................................................................................................11
General observations .......................................................................................................................................12
Typographical conventions used in this document................................................................................................ 12
General conventions .......................................................................................................................................12
1 General information...................................................................................................................................... 13
SmartNode 4950-NCE overview...........................................................................................................................14
SN4950-NCE model codes .............................................................................................................................15
SN4951-NCE model codes .............................................................................................................................16
SmartNode 4950-NCE rear panel .........................................................................................................................16
SmartNode 4950-NCE front panel .......................................................................................................................18
2 Applications overview.................................................................................................................................... 20
Introduction..........................................................................................................................................................21
Application—Multi-service ISDN Internet telephony IAD ...................................................................................21
3 SmartNode installation.................................................................................................................................. 22
Planning the installation ........................................................................................................................................23
Site log ............................................................................................................................................................23
Network information ......................................................................................................................................23
Network Diagram ...........................................................................................................................................23
IP related information .....................................................................................................................................23
Software tools .................................................................................................................................................24
AC Power Mains .............................................................................................................................................24
Location and mounting requirements .............................................................................................................24
Installing the gateway router..................................................................................................................................24
Placing the SmartNode ...................................................................................................................................24
Installing cables ...............................................................................................................................................24
Connecting the PRI ..................................................................................................................................25
Connecting the 10/100/1000Base-T Ethernet LAN and WAN cables ......................................................25
Installing the DSL WAN cable ...........................................................................................................25
Connecting the power supply ....................................................................................................................26
4 Initial configuration ...................................................................................................................................... 27
Introduction..........................................................................................................................................................28
4
SmartNode 4950-NCE Getting Started Guide Table of Contents
1. Connecting the SmartNode to your laptop PC..................................................................................................28
2. Configuring the desired IP address ....................................................................................................................29
Factory-default IP settings ...............................................................................................................................29
Login ..............................................................................................................................................................29
Changing the WAN IP address .......................................................................................................................29
3. Connecting the SmartNode to the network .......................................................................................................30
4. Loading the configuration (optional).................................................................................................................31
Bootloader.............................................................................................................................................................32
Start Bootloader ..............................................................................................................................................32
Start-up with factory configuration .................................................................................................................32
Load a new application image (SmartWare) via TFTP ....................................................................................32
Load a new application image (SmartWare) via the serial link .........................................................................34
Additional information..........................................................................................................................................35
5 G.SHDSL Basic Configuration ..................................................................................................................... 36
Introduction..........................................................................................................................................................37
Line Setup .............................................................................................................................................................37
Configuring PPPoE...............................................................................................................................................37
Configuration Summary........................................................................................................................................38
Setting up permanent virtual circuits (PVC)..........................................................................................................39
Using PVC channels in bridged Ethernet mode ..............................................................................................39
Using PVC channels with PPPoE ...................................................................................................................39
Diagnostics .....................................................................................................................................................40
Troubleshooting DSL Connections .......................................................................................................................40
6 Contacting Patton for assistance ................................................................................................................... 41
Introduction..........................................................................................................................................................42
Contact information..............................................................................................................................................42
Patton support headquarters in the USA .........................................................................................................42
Alternate Patton support for Europe, Middle East, and Africa (EMEA) ..........................................................42
Warranty Service and Returned Merchandise Authorizations (RMAs)...................................................................42
Warranty coverage ..........................................................................................................................................42
Out-of-warranty service .............................................................................................................................43
Returns for credit ......................................................................................................................................43
Return for credit policy .............................................................................................................................43
RMA numbers ................................................................................................................................................43
Shipping instructions ................................................................................................................................43
A Compliance information .............................................................................................................................. 44
Compliance ...........................................................................................................................................................45
PSTN Regulatory ............................................................................................................................................45
B
Specifications ................................................................................................................................................ 46
Voice connectivity .................................................................................................................................................47
Data connectivity ..................................................................................................................................................47
Voice processing (signalling dependent) ................................................................................................................47
5
SmartNode 4950-NCE Getting Started Guide Table of Contents
Fax and modem support........................................................................................................................................47
Voice signalling .....................................................................................................................................................48
Voice routing—session router................................................................................................................................48
IP services..............................................................................................................................................................48
Management .........................................................................................................................................................49
System...................................................................................................................................................................49
Physical .................................................................................................................................................................49
G.SHDSL Daughter Card (if applicable)...............................................................................................................50
Identification of the SmartNode devices via SNMP...............................................................................................51
C Cabling ......................................................................................................................................................... 53
Introduction..........................................................................................................................................................54
Console .................................................................................................................................................................54
Ethernet ................................................................................................................................................................55
E1 PRI ..................................................................................................................................................................56
T1 PRI ..................................................................................................................................................................57
D Port pin-outs ................................................................................................................................................ 58
Introduction..........................................................................................................................................................59
Console port..........................................................................................................................................................59
Ethernet ................................................................................................................................................................59
PRI port ................................................................................................................................................................60
G.SHDSL port......................................................................................................................................................60
E SmartNode 4950-NCE factory configuration ............................................................................................... 61
Introduction..........................................................................................................................................................62
F End user license agreement ........................................................................................................................... 63
End User License Agreement.................................................................................................................................64
1. Definitions ..................................................................................................................................................64
2. Title ............................................................................................................................................................64
3. Term ...........................................................................................................................................................64
4. Grant of License ..........................................................................................................................................64
5. Warranty ....................................................................................................................................................64
6. Termination ................................................................................................................................................65
7. Other licenses .............................................................................................................................................65
6
List of Figures
1 SmartNode 4950-NCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2 SN4950-NCE rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3 SmartNode 4950-NCE front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4 Internet telephony IAD application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5 Power connector location on rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6 Connecting the SmartNode to your laptop PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7 Connecting the SmartNode to the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8 Configuring the G.SHDSL card for PPPoE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
9 Connecting a serial terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
10 Typical Ethernet straight-through cable diagram for 10/100Base-T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
11 Typical Ethernet straight-through cable diagram for 1000Base-T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
12 Connecting an E1 PRI port to an NT1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
13 E1 PRI port crossover cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
14 Connecting a T1 PRI port to an NT device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
15 T1 PRI crossover cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
16 EIA-561 (RJ-45 8-pin) port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
7
List of Tables
1 General conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2 SmartNode 4950-NCE PRI Ports and Voice Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3 SmartNode 4950-NCE models with integrated G.SHDSL interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4 Rear panel ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5 SN4950-NCE Front and Rear panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6 Sample site log entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
7 Factory default IP address and network mask configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8 PVC Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
9 PVC channels in bridged Ethernet mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
10 PVC channels in PPPoE mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
11 Diagnostics commans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
12 G.SHDSL Daughter Card Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
13 SmartNode Models and their Unique sysObjectID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
14 RJ45 socket 10/100Base-T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
15 RJ45 socket 1000Base-T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
16 RJ-45 socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
17 RJ-45 connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
8
About this guide
This guide describes the SmartNode 4950-NCE hardware, installation and basic configuration. For detailed
software configuration information refer to the SmartWare Software Configuration Guide and the available
Configuration Notes.
Audience
This guide is intended for the following users:
• Operators
• Installers
• Maintenance technicians
Structure
This guide contains the following chapters and appendices:
• Chapter 1 on page 13 provides information about router features and capabilities
• Chapter 2 on page 20 contains an overview describing router operation and applications
• Chapter 3 on page 22 provides hardware installation procedures
• Chapter 4 on page 27 provides quick-start procedures for configuring the SmartNode router
• Chapter 5 on page 36 provides information on G.SHDSL basic configuration
• Chapter 6 on page 41 contains information on contacting Patton technical support for assistance
• Appendix A on page 44 contains compliance information for the router
• Appendix B on page 46 contains specifications for the routers
• Appendix C on page 53 provides cable recommendations
• Appendix D on page 58 describes the router’s ports and pin-outs
• Appendix E on page 61 lists the factory configuration settings for SmartNode 4950-NCE
• Appendix F on page 63 provides license information that describes acceptable usage of the software pro-
vided with the SmartNode 4950-NCE
For best results, read the contents of this guide before you install the router.
9
SmartNode 4950-NCE Getting Started Guide
Precautions
Notes, cautions, and warnings, which have the following meanings, are used throughout this guide to help you
become aware of potential problems. Warnings are intended to prevent safety hazards that could result in personal injury. Cautions are intended to prevent situations that could result in property damage or
impaired functioning.
Note
IMPORTANT
CAUTION
CAUTION
WARNING
WARNING
A note presents additional information or interesting sidelights.
The alert symbol and IMPORTANT heading calls attention to
important information.
The alert symbol and CAUTION heading indicate a potential hazard. Strictly follow the instructions to avoid property damage.
The shock hazard symbol and CAUTION heading indicate a
potential electric shock hazard. Strictly follow the instructions to
avoid property damage caused by electric shock.
The alert symbol and WARNING heading indicate a potential safety hazard.
Strictly follow the warning instructions to avoid personal injury.
The shock hazard symbol and WARNING heading indicate a potential electric
shock hazard. Strictly follow the warning instructions to avoid injury caused
by electric shock.
10
SmartNode 4950-NCE Getting Started Guide
Safety when working with electricity
•
Do not open the device when the power cord is connected. For systems
without a power switch and without an external power adapter, line volt-
WARNING
ages are present within the device when the power cord is connected.
•
For devices with an external power adapter, the power adapter shall be a
listed Limited Power Source The mains outlet that is utilized to power the
device shall be within 10 feet (3 meters) of the device, shall be easily
accessible, and protected by a circuit breaker in compliance with local regulatory requirements.
•
For AC powered devices, ensure that the power cable used meets all applicable standards for the country in which it is to be installed.
•
For AC powered devices which have 3 conductor power plugs (L1, L2 &
GND or Hot, Neutral & Safety/Protective Ground), the wall outlet (or
socket) must have an earth ground.
•
For DC powered devices, ensure that the interconnecting cables are rated
for proper voltage, current, anticipated temperature, flammability, and
mechanical serviceability.
•
WAN, LAN & PSTN ports (connections) may have hazardous voltages
present regardless of whether the device is powered ON or OFF. PSTN
relates to interfaces such as telephone lines, FXS, FXO, DSL, xDSL, T1, E1,
ISDN, Voice, etc. These are known as “hazardous network voltages” and
to avoid electric shock use caution when working near these ports. When
disconnecting cables for these ports, detach the far end connection first.
•
Do not work on the device or connect or disconnect cables during periods of
lightning activity
WARNING
This device contains no user serviceable parts. This device can only be
repaired by qualified service personnel.
In accordance with the requirements of council directive 2002/
96/EC on Waste of Electrical and Electronic Equipment (WEEE),
ensure that at end-of-life you separate this product from other
waste and scrap and deliver to the WEEE collection system in
your country for recycling.
11
SmartNode 4950-NCE Getting Started Guide
Always follow ESD prevention procedures when removing and
replacing cards.
CAUTION
Wear an ESD-preventive wrist strap, ensuring that it makes good
skin contact. Connect the clip to an unpainted surface of the
chassis frame to safely channel unwanted ESD voltages
to ground.
To properly guard against ESD damage and shocks, the wrist
strap and cord must operate effectively. If no wrist strap is available, ground yourself by touching the metal part of the chassis.
General observations
• Clean the case with a soft slightly moist anti-static cloth
• Place the unit on a flat surface and ensure free air circulation
• Avoid exposing the unit to direct sunlight and other heat sources
• Protect the unit from moisture, vapors, and corrosive liquids
Typographical conventions used in this document
This section describes the typographical conventions and terms used in this guide.
General conventions
The procedures described in this manual use the following text conventions:
Table 1. General conventions
Convention Meaning
Garamond blue type
Futura bold type Commands and keywords are in boldface font.
Futura bold-italic type Parts of commands, which are related to elements already named by the user, are
Italicized Futura type Variables for which you supply values are in italic font
Futura type Indicates the names of fields or windows.
Garamond bold type Indicates the names of command buttons that execute an action.
< > Angle brackets indicate function and keyboard keys, such as <SHIFT>, <CTRL>,
[ ] Elements in square brackets are optional.
{a | b | c} Alternative but required keywords are grouped in braces ({ }) and are separated
screen
node The leading IP address or nodename of a SmartNode is substituted with node in
SN The leading SN on a command line represents the nodename of the SmartNode
# An hash sign at the beginning of a line indicates a comment line.
Indicates a cross-reference hyperlink that points to a figure, graphic, table, or section heading. Clicking on the hyperlink jumps you to the reference. When you
have finished reviewing the reference, click on the Go to Previous View
button in the Adobe® Acrobat® Reader toolbar to return to your starting point.
in boldface italic font.
<C>, and so on.
by vertical bars ( | )
Terminal sessions and information the system displays are in
boldface italic font.
screen font
.
12
Chapter 1 General information
Chapter contents
SmartNode 4950-NCE overview...........................................................................................................................14
SN4950-NCE model codes .............................................................................................................................15
SN4951-NCE model codes .............................................................................................................................16
SmartNode 4950-NCE rear panel .........................................................................................................................16
SmartNode 4950-NCE front panel .......................................................................................................................18
13
SmartNode 4950-NCE Getting Started Guide 1 • General information
SmartNode 4950-NCE overview
The SmartNode 4950-NCE T1/E1 PRI VoIP Router (see figure 1) combines Universal SIP Trunking, IP
routing, VPN/Security, and Quality of Service with high-quality Voice over IP (VoIP) delivered on 1 to 4 Primary Rate Interfaces (PRI T1/E1). This combination paves the way for enterprises’ migration to unified communications by integrating legacy telephone systems with PSTN and VoIP networks.
Figure 1. SmartNode 4950-NCE
The SmartNode 4950-NCE Gateway-Router performs the following major functions:
• Up to 120 VoIP Calls—Up to 120 simultaneous voice or T.38 fax calls with one to four T1/E1/PRI ports
and dual Gigabit Ethernet ports. Use any CODEC or fax on any port, any time.
• Unified Communications Agent™—Provides any-to-any multi-path switching with VoIP and data sur-
vivability, VoIP-over-VPN security with AES/DES strong encryption, Internet Key Exchange (IKE), and
SIP Registrar
• Universal SIP and T.38 Support—Softswitch-certified signaling support between all T1 RBS CAS, ISDN
PRI, Q.SIG, SIP and H.323.
• Secure Toll-Quality VoIP—Patton’s DownStreamQoS™ and Voice-over-VPN with adaptive traffic
management and shaping for maximum voice quality and secure voice communication.
• IP Routing—RIP v1/v2, VRRP, policy-based routing, and loopback interface
• Transparent Telephony Features—Complex number manipulation and mapping for seamless integration
with existing infrastructures, CLIP, CLIR, hold, transfer and much more.
• Management & Provisioning—Web-based management, SNMP, Command Line Interface. Automated
provisioning for easy large-scale deployments.
• Optional High Precision Clock—Delivers DECT PBX interoperability with reliable fax performance.
• G.SHDSL.bis Broadband Access—Complete Access Router with integrated G.SHDSL.bis WAN inter-
face delivers symmetrical throughput up to 11.4 Mbps over four wires or up to 5.7 Mbps over two wires.
Supports ATM QoS with multiple PVCs and outstanding DSLAM interoperability.
SmartNode 4950-NCE overview 14
SmartNode 4950-NCE Getting Started Guide 1 • General information
SN4950-NCE model codes
The SmartNode 4950-NCE series consists of several models. They differ in the number of PRI ports and voice
channels supported. All models come equipped with two 10/100/1000Base-T Ethernet ports. The SmartNode
4950-NCE PRI ports and voice channels are listed in table 2. The SmartNode 4950-NCE G.SHDSL models
are listed in table 3.
Table 2. SmartNode 4950-NCE PRI Ports and Voice Channels
Model PRI Ports Voice Channels
SN4950NCE/1E24V/EUI
SN4950NCE/1E30V/EUI
SN4950NCE/4E24V/EUI
SN4950NCE/4E30V/EUI
SN4950NCE/4E48V/EUI
SN4950NCE/4E60V/EUI
SN4950NCE/4E96V/EUI
SN4950NCE/4E120V/EUI
1 24
1 30
4 24
4 30
4 48
4 60
4 96
4 120
Table 3. SmartNode 4950-NCE models with integrated G.SHDSL interface
Model PRI Ports Voice Channels
SN4950NCE/1E24V2GS/EUI
SN4950NCE/1E30V2GS/EUI
SN4950NCE/4E24V2GS/EUI
SN4950NCE/4E30V2GS/EUI
SN4950NCE/4E48V2GS/EUI
SN4950NCE/4E60V2GS/EUI
SN4950NCE/4E96V2GS/EUI
SN4950NCE/4E120V2GS/EUI
SmartNode 4950-NCE overview 15
1 24
1 30
4 24
4 30
4 48
4 60
4 96
4 120
SmartNode 4950-NCE Getting Started Guide 1 • General information
SN4951-NCE model codes
The high precision SmartNode 4951-NCE models have a Stratum III clock. The Stratum III clock provides a
clock source of < 5 ppm. For PBXs that used to rely on PSTN for accurate clock source, the SmartNode 4951
can provide a PSTN-equivalent high precision clock. The popular DECT PBX needs such high precision
clocks.
Note
For high precision clock models, replace SN4950-NCE with SN4951
in the model code.
SmartNode 4950-NCE rear panel
The SmartNode 4950-NCE rear panel ports are described in table 4.
0
/
3
0
/2
0
/1
T
0
1
/0
/E
1
E
Power
T
H
0
/1
E
T
H
0
/0
C
o
n
s
Reset
o
le
R
S
2
3
2
SN4950/1E30V
SmartNode 4950-NCE rear panel 16
0/0
T1/E1
T1/E1
PRI port 0/0
0/00/10/20/3
T1/E1
T1/E1
PRI ports 0/3–0/0
10/100/1000Base-T port
ETH 0/0
10/100/1000Base-T port
Figure 2. SN4950-NCE rear panel
ETH 0/1
ConsoleETH 0/0ETH 0/1
Reset
RS-232
SN4950/4E120V
ConsoleETH 0/0ETH 0/1
Reset
RS-232
Console
RS-232 port
RESET
button
SmartNode 4950-NCE Getting Started Guide 1 • General information
Table 4. Rear panel ports
Port Description
WAN ETH 0/0
LAN ETH 0/1
PRI 0/0 RJ-45 connector providing E1 (2.048Mbps) or T1(1.533 Mbps) PRI interface, meet-
PRI 0/1 RJ-45 connector providing E1 (2.048Mbps) or T1(1.533 Mbps) PRI interface, meet-
PRI 0/2 RJ-45 connector providing E1 (2.048Mbps) or T1(1.533 Mbps) PRI interface, meet-
PRI 0/3 RJ-45 connector providing E1 (2.048Mbps) or T1(1.533 Mbps) PRI interface, meet-
Console
DC power input
Reset
G.SHDSL port
(option)
Auto-MDX Gigabit-Ethernet port, RJ-45 (see
WAN device (for example, a cable modem, DSL modem, or fiber modem). Note:
Only full duplex modes are supported.
Auto-MDX Gigabit-Ethernet port, RJ-45 (see
LAN (for example, a PC, printer, or wireless bridge). Note: Only full duplex modes
are supported.
ing all requirements of ITU-T recommendations for G.703. Use a shielded E1 or T1
interface cable for 120 Ohm balanced connections to connect the SmartNode with
an NT or ET, e.g. a PBX or LE.
ing all requirements of ITU-T recommendations for G.703. Use a shielded E1 or T1
interface cable for 120 Ohm balanced connections to connect the SmartNode with
an NT or ET, e.g. a PBX or LE.
ing all requirements of ITU-T recommendations for G.703. Use a shielded E1 or T1
interface cable for 120 Ohm balanced connections to connect the SmartNode with
an NT or ET, e.g. a PBX or LE.
ing all requirements of ITU-T recommendations for G.703. Use a shielded E1 or T1
interface cable for 120 Ohm balanced connections to connect the SmartNode with
an NT or ET, e.g. a PBX or LE.
Used for service and maintenance, the Console port (see
connector, connects the product to a serial terminal such as a PC or ASCII terminal
(also called a dumb terminal).
Electricity supply socket. (see
The reset button (see
•
Restart the unit with the current startup configuration—Press (for less than 1 second)
and release the Reset button to restart the unit with the current startup configuration.
•
Restart the unit with factory default configuration—Press the Reset button for
5 seconds until the Power LED (see
the unit with factory default configuration.
•
Restart the unit in bootloader mode (to be used only by trained SmartNode technicians)—Starting with the unit powered off, press and hold the Reset button as
you apply power to the unit. Release the Reset button when the Power LED starts
blinking so the unit will enter bootloader mode.
Provides symmetrical throughput up to 11.4 Mbps over four wires or 5.7 Mbps over
two wires. Supports ATM QoS with multiple PVCs and outstanding DSLAM interoperability. The G.SHDSL LEDs are located on either side of the DSL port. ACT (when lit
or blinking) shows Activity, and LINK (when lit) shows that the DSL port is connected.
figure 2
figure 2
) has three functions:
).
figure 3
figure 2
figure 2
), connects the unit to an Ethernet
), connect the unit to an Ethernet
figure 2
on page 18) starts blinking to restart
), an RS-232 RJ-45
SmartNode 4950-NCE rear panel 17
SmartNode 4950-NCE Getting Started Guide 1 • General information
SmartNode 4950-NCE front panel
Figure 3 shows SmartNode 4950-NCE front panel LEDs, the LED definitions are listed in table 5.
rt 0
o
P
1
/E
1
1
T
rt
o
P
1
/E
1
T
rt 2
o
P
1
/E
1
T
t 3
r
o
P
1
/E
1
T
M
u
lt
i-
P
o
r
SmartNode 4950 VoIP IAD
t
T
1
/
E
1
/
P
R
I
V
o
I
P
E
n
t
e
r
p
r
i
s
e
G
a
t
e
w
a
y
R
o
u
te
r
SN4950/1E30V
SmartNode 4950 VoIP IAD
Multi-Port T1/E1/PRI VoIP Enter prise Gateway Router
Power
Activity
VoIP
Ethernet 0/0
Link
Ethernet 0/0
100
T1/E1 Port 0
Ethernet 0/1
Activity
Ethernet 0/0
1000
Ethernet 0/0
Activity
Ethernet 0/1
Link
T1/E1 Port 0
Ethernet 0/1
1000
Ethernet 0/1
100
T1/E1 Port 1
T1/E1 Port 0
T1/E1 Port 2
T1/E1 Port 3
T1/E1 Port 3
T1/E1 Port 1 T1/E1 Port 2
Figure 3. SmartNode 4950-NCE front panel
SN4950/4E120V
SmartNode 4950 VoIP IAD
Multi-Port T1/E1/PRI VoIP Enter prise Gateway Router
SmartNode 4950-NCE front panel 18
SmartNode 4950-NCE Getting Started Guide 1 • General information
Table 5. SN4950-NCE Front and Rear panel LEDs
LED Description
Note If an error occurs, all LEDs will flash once per second.
Power When lit, indicates power is applied.
Run When lit, the unit is in normal operation. Flashes once per second during
boot (startup).
VoIP Link
Ethernet Link
Ethernet Speed
10/100
Ethernet Speed
1000
Ethernet Activity
PRI Link/Status
•
On indicates the gateway is registered to an H.323 gatekeeper/SIP server, or,
in the case of direct routing, has at least one active VoIP connection.
•
Off indicates the unit is not configured or registered, or has no active directrouted VoIP connection.
•
Flashing green indicates that the unit is attempting to register or has failed
to register.
•
On when the Ethernet connection on the corresponding port has a
link indication.
When the Ethernet Link LED is on, then:
•
On when the Ethernet is connected to a 100Mb network.
•
Off when the Ethernet is connected to a 10Mb network.
•
On when the Ethernet is connected to a 1000Mb network.
•
Flashes when data is received or transmitted at the corresponding Ethernet port.
•
On = in frame, no errors
G.SHDSL ACT
(Rear panel)
G.SHDSL LINK
(Rear panel)
•
Flash = Error
•
Fast Flash = Signal detected but no frame synchronization or aquisition is in
process
•
Slow Flash = Framing synchronized, Signaling not established
•
Flashes when data is received or transmitted
•
Off = No activity
•
On when the G.SHDSL connection on the corresponding port has a
link indication.
•
Off = No G.SHDSL connection
SmartNode 4950-NCE front panel 19
Chapter 2 Applications overview
Chapter contents
Introduction..........................................................................................................................................................21
Application—Multi-service ISDN Internet telephony IAD ...................................................................................21
20
Loading...
