Patton electronics NanoServ Setup Manual

NanoServ™

Thin System/Ultra-Thin System

Setup Guide

1.0 What’s included with the NanoServ™

The following items are included with the NanoServ™:

1.

NanoServ™

2.

AC Power Adaptor

3.

CD-ROM with User’s Manual

4.

This Setup Guide

Note

Refer to the User Manual on the CD-ROM for complete information on installation.

2.0 Steps for setting up the NanoServ™

Note

This is a fanless system, so it must be properly mounted to allow for proper cooling. Be sure to use the
metal stand to hold the system upright with the blue LED on top, or mount the system at least 1 or 2
inches away from the flat side surfaces of the system. This will help keep the NanoServ™ cool and
within operating limits.

1.

Verify that the power supply switch is off (located on the back of the NanoServ™).

2.

Plug the monitor into the VGA port.

3.

Plug the keyboard into the PS/2 keyboard port.

4.

Plug the mouse into the PS/2 mouse port.

5.

Plug the printer into the DB-25 printer port (only available on the Thin NanoServ™ system).

6.

Connect the power adaptor to the mains power.

7.

Turn on the power supply switch located on the back of the NanoServ™.

Document Number: 09407U7-001, Rev. A
Part Number: 07M6070-QS
Revised:

August 2, 2006

Sales Office: [phone]

Technical Support: [phone]

E-mail: [e-mail]

WWW: www.patton.com

3.0 NanoServ™ Ultra-Thin System

Front panel

Power LED
The power LED lights up when the system is
turned on.

HDD LED
The HDD LED flashes when the system is working.
Please do not turn off the system when HDD
starts running.

Power Switch
Depress the switch to turn on and turn off the
system.

USB Port
The USB port is for a connection to external
devices with a USB interface (keyboard, mouse,
HDD, CD-ROM, Memory Stick, ect.)

DC-IN 5V

POWER SW

Figure 1.

Ultra-Thin System - Front panel

Back panel

Audio Line-Out

Mic-In

VGA Port

RJ-45 10/100 Ethernet Jack

USB Port

PS/2 Mouse (6-pin)

PS/2 Keyboard & Mouse (6-pin)

DC Power Jack (3-pin)

Power supply switch

2

Figure 2.

Ultra-Thin System - Back panel

NanoServ Setup Guide
