Patton electronics MODEL 552, 552 Series User Manual

USER
MANUAL

MODEL 552 Series

High Speed Telco Surge
Protectors

SALES OFFICE
[phone]
TECHNICAL SUPPORT
[phone]
http://www.patton.com

Part# 07M552-E
Rev. G
Revised 01/27/10

CERTIFIED

CERTIFIED

An ISO-9001

Certified Company

1.0 WARRANTY INFORMATION

Patton Electronics warrants all Model 552 components to be free

from defects, and will—at our option—repair or replace the product
should it fail within one year from the first date of shipment.

This warranty is limited to defects in workmanship or materials, and
does not cover customer damage, abuse or unauthorized modification.
If this product fails or does not perform as warranted, your sole
recourse shall be repair or replacement as described above. Under no
condition shall Patton Electronics be liable for any damages incurred
by the use of this product. These damages include, but are not limited
to, the following: lost profits, lost savings and incidental or
consequential damages arising from the use of or inability to use this
product. Patton Electronics specifically disclaims all other warranties,
expressed or implied, and the installation or use of this product shall be
deemed an acceptance of these terms by the user.

1.1 SERVICE

All warranty and non-warranty repairs must be returned freight
prepaid and insured to Patton Electronics. All returns must have a
Return Materials Authorization number on the outside of the shipping
container. This number may be obtained from Patton Electronics
Technical Service at: [phone]; http://www.patton.com; or,

[e-mail].

NOTE: Packages received without an RMA number will not be

accepted.

Patton Electronics' technical staff is also available to answer any
questions about the installation or use of your Model 552. Technical
Service hours are: 8AM to 5PM EST, Monday through Friday.

1.2 CE NOTICE

The CE symbol on your Patton Electronics equipment indicates
that it is in compliance with the Electromagnetic Compatibility (EMC)
directive and the Low Voltage Directive (LVD) of the Union European
(EU). A Certificate of Compliance is available by contacting Technical
Support.

1.3 FCC COMPLIANCE

The 552 Series of surge protectors have been tested and found to
comply with FCC Parts 15 and 68. A label on the device bears the
Part 68 registration number.

1

1. This equipment complies with Part 68 of the Federal
Communications Commission Rules. On the outside surface of this
equipment is a label that contains, among other information, the
FCC registration number. This information must be provided to the
telephone company.

2. If this equipment causes harm to the telephone network, the
telephone company will notify you in advance that temporary
discontinuance of service may be required. But, if advance notice
is not practical, the telephone company will notify the customer as
soon as possible. Also, you will be advised of your right to file a
compliant with the FCC if you believe it is necessary.

3. The telephone company may make changes in its facilities,
equipment, operations, or procedures that could affect the
operation of the equipment. If this happens, the telephone
company will provide advance notice in order for you to make
necessary modifications in order to maintain uninterrupted service.

4. If trouble is experienced with any of the Model 552 Series, please
contact Patton Electronics Company at 301-975-1000. If the
equipment is causing harm to the network, the telephone company
may request you to remove the equipment from the network until
the problem is resolved.

5. Repairs are to be made only by Patton Electronics Company or its
licenses. Unauthorized repairs void registration and warranty.

6. This equipment cannot be used on public coin service provided by
the telephone company. Connection to Party Line Service is subject
to state tariffs. (Contact the state public utility commission, public
service commission or corporation commission for information).

1.4 INDUSTRY CANADA NOTICE

NOTICE: The Industry Canada label identifies certified equipment.

This certification means that the equipment meets telecommunications
network protective, operational and safety requirements as prescribed
in the appropriate Terminal Equipment Technical Requirements
document(s). The Department does not guarantee the equipment will
operate to the user’s satisfaction.

Before installing this equipment, users should ensure that it is

permissible to be connected to the facilities of the local
telecommunications company. The equipment must also be installed
using an acceptable method of connection. The customer should be
aware that compliance with the above conditions may not prevent
degradation of service in some situations.

2

1. This equipment complies with Part 68 of the Federal
Communications Commission Rules. On the outside surface of this
equipment is a label that contains, among other information, the
FCC registration number. This information must be provided to the
telephone company.

2. If this equipment causes harm to the telephone network, the
telephone company will notify you in advance that temporary
discontinuance of service may be required. But, if advance notice
is not practical, the telephone company will notify the customer as
soon as possible. Also, you will be advised of your right to file a
compliant with the FCC if you believe it is necessary.

3. The telephone company may make changes in its facilities,
equipment, operations, or procedures that could affect the
operation of the equipment. If this happens, the telephone
company will provide advance notice in order for you to make
necessary modifications in order to maintain uninterrupted service.

4. If trouble is experienced with any of the Model 552 Series, please
contact Patton Electronics Company at 301-975-1000. If the
equipment is causing harm to the network, the telephone company
may request you to remove the equipment from the network until
the problem is resolved.

5. Repairs are to be made only by Patton Electronics Company or its
licenses. Unauthorized repairs void registration and warranty.

6. This equipment cannot be used on public coin service provided by
the telephone company. Connection to Party Line Service is subject
to state tariffs. (Contact the state public utility commission, public
service commission or corporation commission for information).

1.4 INDUSTRY CANADA NOTICE

NOTICE: The Industry Canada label identifies certified equipment.

This certification means that the equipment meets telecommunications
network protective, operational and safety requirements as prescribed
in the appropriate Terminal Equipment Technical Requirements
document(s). The Department does not guarantee the equipment will
operate to the user’s satisfaction.

Before installing this equipment, users should ensure that it is

permissible to be connected to the facilities of the local
telecommunications company. The equipment must also be installed
using an acceptable method of connection. The customer should be
aware that compliance with the above conditions may not prevent
degradation of service in some situations.

Repairs to certified equipment should be coordinated by a
representative designated by the supplier. Any repairs or alterations
made by the user to this equipment, or equipment malfunctions, may
give the telecommunications company cause to request the user to
disconnect the equipment.

Users should ensure for their own protection that the electrical
ground connections of the power utility, telephone lines and internal
metallic water pipe system, if present, are connected together. This
precaution may be particularly important in rural areas. Caution: Users
should not attempt to make such connections themselves, but should
contact the appropriate electric inspection authority, or electrician, as
appropriate.

3

Thank you for your purchase of this Patton Electronics product.
This product has been thoroughly inspected and tested and is
warranted for One Year parts and labor. If you have any questions while
installing or using this product, please do not hesitate to contact Patton
Electronics Technical Support at [phone].

2.1 FEATURES

• Uses a multi-stage hybrid circuit for the best possible protection

• Handles surge energy up to 1.5 kW

• Conforms to the UL497A telco specification (except E1 versions)

• Available for ISDN-U (8-wire), ISDN-ST (4-wire), T1, E1, ISDN

• Diverts surges directly to chassis ground through braided metal

• Equipped with two RJ-45 jacks or four BNC connectors

• Easy to install

• Made in the U.S.A.

2.2 DESCRIPTION

The potential threats to ISDN and Telco hardware are vast:
lightning, AC power induction, electrostatic discharge, ground potential
differences, EMI/RFI interference and more. The Patton Model 552 has
been designed to greatly reduce these risks. Just attach one unit to
each of your telco ports and rest easy.

The Model 552 connects directly between twisted pair telco cables
and their respective I/O ports. Grounding is accomplished using an
external ground strap that provides a separate unit-ground to chassis-
ground connection. By shunting threatening voltages directly to chassis
ground, the Model 552 insures data integrity and protects connected
equipment from damage.

The Model 552 uses a solid state design and sophisticated
multistage hybrid circuits to achieve maximum protection without
performance loss. Eight versions are available: Model 552-ST, 552-D8,
and 552-L8 protect all 8 pins; Model 552-D6 protects six pins; Models
552-DDS, 552-D4, 552-U, 552-L4, 552-E1, 552-E1 CX, and 552-T1
protect four pins; and, Model 552-D2 protects two pins. All versions
provide up to 1500 Watts of data line protection.

NOTE: Model 552-L8 may be used to protect Leased Line, DDS,

T1, E1, ISDN PRI, and ISDN BRI “U” and “ST” interfaces.

WARNING!: This product will not provide complete protection

should your equipment or building be subject to a direct lightning hit.

2.0 GENERAL INFORMATION

Thank you for your purchase of this Patton Electronics product.
This product has been thoroughly inspected and tested and is
warranted for One Year parts and labor. If you have any questions while
installing or using this product, please do not hesitate to contact Patton
Electronics Technical Support at [phone].

2.1 FEATURES

• Uses a multi-stage hybrid circuit for the best possible protection

• Handles surge energy up to 1.5 kW

• Conforms to the UL497A telco specification (except E1 versions)

• Available for ISDN-U (8-wire), ISDN-ST (4-wire), T1, E1, ISDN
PRI, DDS, leased line and dial up configurations

• Diverts surges directly to chassis ground through braided metal
ground strap

• Equipped with two RJ-45 jacks or four BNC connectors

• Easy to install

• Made in the U.S.A.

2.2 DESCRIPTION

The potential threats to ISDN and Telco hardware are vast:
lightning, AC power induction, electrostatic discharge, ground potential
differences, EMI/RFI interference and more. The Patton Model 552 has
been designed to greatly reduce these risks. Just attach one unit to
each of your telco ports and rest easy.

The Model 552 connects directly between twisted pair telco cables
and their respective I/O ports. Grounding is accomplished using an
external ground strap that provides a separate unit-ground to chassis­ground connection. By shunting threatening voltages directly to chassis
ground, the Model 552 insures data integrity and protects connected
equipment from damage.

The Model 552 uses a solid state design and sophisticated
multistage hybrid circuits to achieve maximum protection without
performance loss. Eight versions are available: Model 552-ST, 552-D8,
and 552-L8 protect all 8 pins; Model 552-D6 protects six pins; Models
552-DDS, 552-D4, 552-U, 552-L4, 552-E1, 552-E1 CX, and 552-T1
protect four pins; and, Model 552-D2 protects two pins. All versions
provide up to 1500 Watts of data line protection.

NOTE: Model 552-L8 may be used to protect Leased Line, DDS,

T1, E1, ISDN PRI, and ISDN BRI “U” and “ST” interfaces.

WARNING!: This product will not provide complete protection

should your equipment or building be subject to a direct lightning hit.

4

3.0 INSTALLATION

Patton's Model 552 is easy to install and should give you years of
trouble-free service. Here are a few simple instructions to help you get
things hooked up right.

1. Unplug (disconnect) the existing connection between the network
cable and the equipment’s I/O port.

2. Install the Model 552 between the incoming network cable and the
protected equipment using the 6 inch (15.2cm.) modular patch
cable (supplied). Place the surge protector as close as possible to
the device being protected.
NOTE:To ensure proper operation of the Model 552, make sure
that your equipment is connected to the protected side of the
Model 552. See Figure 1 below.
NOTE:The Model 552-E1 CX has two pairs of BNC jacks that
connect one to one through the device. See Figure 2 below.

3. Connect the braided ground strap directly to a chassis ground
connection on the protected device. If you are not sure where to
locate a chassis ground connection on your equipment, consult the
equipment's user manual or contact the manufacturer. Correct
ground connection is critical for proper operation of the Model 552.

Series Resistance: 0.340 Ohms
In Line Fuse Rating: 250V, 3/4A, 2.95 (A

Approvals: CE (EMC Directive/EN 50082-1)
Connectors: Two female RJ-45 or 4 BNC jacks

Pins Protected: Pins 1, 2, 7, 8
Clamping Voltage: 62 Volts in 500 nsec
Surge Capacity: 1500 Watts for 1 msec;

Protection Mode: Common Mode Pins 1, 2, 7, 8 to shielding
Differential Mode: Pins 1, 2, 7, 8

Pins Protected: Pins 4, 5 on the RJ-45 Interface;
Clamping Voltage: 310 Volts in 500 nsec

Surge Capacity: 1500 Watts for 1 msec;
Protection Mode: Common Mode Pins 4, 5 to shielding
Differential Mode: Pins 4, 5

Pins Protected: Pins 3, 4, 5, 6 on the RJ-45 Interface
Clamping Voltage: 310 Volts in 500 nsec

Surge Capacity: 1500 Watts for 1 msec;
Protection Mode: Common Mode Pins 3, 4, 5, 6 to shielding
Differential Mode: Pins 3, 4, 5, 6

5

UNPROTECTED

PROTECTED

Figure 1. How to Connect the Model 552

Figure 2. Model 552-E1CX One to One Connection

TX and
RX from
network

TX and RX to

protected

equipment

Output to protected

equipment

Input from

network

Connection to

frame ground

APPENDIX A

MODEL 552 SPECIFICATIONS

General

Series Resistance: 0.340 Ohms
In Line Fuse Rating: 250V, 3/4A, 2.95 (A

2

sec) Nominal Melting

Point

Approvals: CE (EMC Directive/EN 50082-1)
Connectors: Two female RJ-45 or 4 BNC jacks

Model 552-DDS

Pins Protected: Pins 1, 2, 7, 8
Clamping Voltage: 62 Volts in 500 nsec
Surge Capacity: 1500 Watts for 1 msec;

400A with an 8/20 μsec pulse

Protection Mode: Common Mode Pins 1, 2, 7, 8 to shielding

braid

Differential Mode: Pins 1, 2, 7, 8

Model 552-D2

Pins Protected: Pins 4, 5 on the RJ-45 Interface;

Pins 3, 4 on the RJ-11 Interface

Clamping Voltage: 310 Volts in 500 nsec
Surge Capacity: 1500 Watts for 1 msec;

250A with an 8/20 μsec pulse

Protection Mode: Common Mode Pins 4, 5 to shielding

braid

Differential Mode: Pins 4, 5

Model 552-D4

Pins Protected: Pins 3, 4, 5, 6 on the RJ-45 Interface

Pins 2, 3, 4, 5 on the RJ-11 Interface

Clamping Voltage: 310 Volts in 500 nsec
Surge Capacity: 1500 Watts for 1 msec;

250A with an 8/20 μsec pulse

Protection Mode: Common Mode Pins 3, 4, 5, 6 to shielding

braid

Differential Mode: Pins 3, 4, 5, 6

6

Model 552-D6

Pins Protected: Pins 2, 3, 4, 5, 6, 7 on the RJ-45 Interface

Pins 1, 2, 3, 4, 5, 6 on the RJ-11 Interface

Clamping Voltage: 310 Volts in 500 nsec
Surge Capacity: 1500 Watts for 1 msec;

250A with an 8/20 μsec pulse

Protection Mode: Common Mode Pins 2, 3, 4, 5, 6, 7 to

shielding braid

Differential Mode: Pins 2, 3, 4, 5, 6, 7

Model 552-D8

Pins Protected: Pins 1, 2, 3, 4, 5, 6, 7, 8
Clamping Voltage: 310 Volts in 500 nsec
Surge Capacity: 1500 Watts for 1 msec;

250A with an 8/20 μsec pulse

Protection Mode: Common Mode Pins 1, 2, 3, 4, 5, 6, 7, 8 to

shielding braid

Differential Mode: Pins 1, 2, 3, 4, 5, 6, 7, 8

Model 552-T1 and 552-E1

Pins Protected: Pins 1, 2, 4, 5
Clamping Voltage: 62 Volts in 500 nsec
Surge Capacity: 1500 Watts for 1 msec;

400A with an 8/20 μsec pulse

Protection Mode: Common Mode Pins 1, 2, 4, 5 to shielding

braid

Differential Mode: Pins 1, 2, 4, 5

Model 552--E1 CX

Pins Protected: All shields and center pins
Clamping Voltage: 62 Volts in 500 nsec
Surge Capacity: 1500 Watts for 1 msec;

400A with an 8/20 μsec pulse

Protection Mode: Common Mode Center Pins and Shield to

shielding braids

Differential Mode: Center Pins to Shields

7

Pins Protected: Pins 3, 4, 5, 6
Clamping Voltage: 62 Volts in 500 nsec
Surge Capacity: 1500 Watts for 1 msec;

Protection Mode: Common Mode pins 3, 4, 5, 6 to shielding
Differential Mode: Pins 3, 4 5, and 6

Pins Protected: Pins 1, 2, 3, 4, 5, 6, 7, 8
Clamping Voltage: 62 Volts in 500 nsec
SurgeCapacity: 1500 Watts for 1 msec

Protection Mode: Common Mode pins 1, 2, 3, 4, 5, 6, 7, 8 to
Differential Mode: Pins 1, 2, 3, 4, 5, 6, 7, 8

*NOTE: In addition to protecting leased line modem interfaces, the
Model 552-L8 may also be used to protect DDS, T1, E1, ISDN PRI,
and ISDN BRI “U” and “ST” interfaces.

Pins Protected: 552-GS2 Pins 4, 5
Clamping Voltage: 18 Volts in 500 nsec

Surge Capacity: 600 Watts for 1 msec;
Protection Mode: Common Mode Pins 4, 5 (GS2);
Differential Mode: Pins 4, 5 (GS2); Pins 3, 4, 5, 6 (GS4)

Model 552-L4 and 552-U

Pins Protected: Pins 3, 4, 5, 6
Clamping Voltage: 62 Volts in 500 nsec
Surge Capacity: 1500 Watts for 1 msec;

400A with an 8/20 μsec pulse

Protection Mode: Common Mode pins 3, 4, 5, 6 to shielding

braid

Differential Mode: Pins 3, 4 5, and 6

Model 552-L8* and 552-ST

Pins Protected: Pins 1, 2, 3, 4, 5, 6, 7, 8
Clamping Voltage: 62 Volts in 500 nsec
SurgeCapacity: 1500 Watts for 1 msec

400 A with an 8/20 μsec pulse

Protection Mode: Common Mode pins 1, 2, 3, 4, 5, 6, 7, 8 to

shielding braid

Differential Mode: Pins 1, 2, 3, 4, 5, 6, 7, 8

*NOTE: In addition to protecting leased line modem interfaces, the
Model 552-L8 may also be used to protect DDS, T1, E1, ISDN PRI,
and ISDN BRI “U” and “ST” interfaces.

Model 555-GS2 and 552-GS4

Pins Protected: 552-GS2 Pins 4, 5

552-GS4 Pins 3, 4, 5, 6

Clamping Voltage: 18 Volts in 500 nsec
Surge Capacity: 600 Watts for 1 msec;

400A with an 8/20 μsec pulse

Protection Mode: Common Mode Pins 4, 5 (GS2);

Pins 3, 4, 5, 6 (GS4) to shielding braid

Differential Mode: Pins 4, 5 (GS2); Pins 3, 4, 5, 6 (GS4)

Copyright © 1997, 2001, 2009-2010.

Patton Electronics Company

All Rights Reserved
