Patton SmartNode 5400 Series Quick Start Manual

SmartNode 5400 Series

Enterprise Session Border Router

Quick Start Guide

This is a Class A device and is not intended for use in a residential environment.

Part Number: 07MSN5400-QS, Rev. B
Revised: February 6, 2012

Sales Office: [phone]

Technical Support: [phone]

E-mail: [e-mail]

WWW: www.patton.com

WARNING

• Do not open the device when the power cord is connected. For sys­tems without a power switch and without an external power
adapter, line voltages are present within the device when the power
cord is connected.

• For devices with an external power adapter, the power adapter shall
be a listed Limited Power Source The mains outlet that is utilized to
power the device shall be within 10 feet (3 meters) of the device,
shall be easily accessible, and protected by a circuit breaker in compli­ance with local regulatory requirements.

• For AC powered devices, ensure that the power cable used meets all
applicable standards for the country in which it is to be installed.

• For AC powered devices which have 3 conductor power plugs (L1, L2
& GND or Hot, Neutral & Safety/Protective Ground), the wall outlet
(or socket) must have an earth ground.

• For DC powered devices, ensure that the interconnecting cables are
rated for proper voltage, current, anticipated temperature, flammabil­ity, and mechanical serviceability.

• WAN, LAN & PSTN ports (connections) may have hazardous voltages
present regardless of whether the device is powered ON or OFF.
PSTN relates to interfaces such as telephone lines, FXS, FXO, DSL,
xDSL, T1, E1, ISDN, Voice, etc. These are known as “hazardous net­work voltages” and to avoid electric shock use caution when working
near these ports. When disconnecting cables for these ports, detach
the far end connection first.

WARNING

WARNING

• Do not work on the device or connect or disconnect cables during periods

of lightning activity.

This device contains no user serviceable parts. This device can only be
repaired by qualified service personnel.

This device is NOT intended nor approved for connection to the PSTN. It
is intended only for connection to customer premise equipment.

In accordance with the requirements of council directive 2002/96/EC on Waste of
Electrical and Electronic Equipment (WEEE), ensure that at end-of-life you separate
this product from other waste and scrap and deliver to the WEEE collection system in
your country for recycling.

2 SmartNode 5400 Series Quick Start Guide

Electrostatic Discharge (ESD) can damage equipment and impair electrical
circuitry. It occurs when electronic printed circuit cards are improperly
handled and can result in complete or intermittent failures. Do the follow-

CAUTION

ing to prevent ESD:

• Always follow ESD prevention procedures when removing and replac­ing cards.

• Wear an ESD-preventive wrist strap, ensuring that it makes good
skin contact. Connect the clip to an unpainted surface of the chassis
frame to safely channel unwanted ESD voltages to ground.

• To properly guard against ESD damage and shocks, the wrist strap
and cord must operate effectively. If no wrist strap is available,
ground yourself by touching the metal part of the chassis.

1.0 Power up the SmartNode

1. Connect the SmartNode to the mains (AC) power source with the power cable.

2. Wait until the Power LED stops blinking and remains constantly lit. Now the SmartNode is ready

to configure.

2.0 Connecting the SmartNode to your laptop PC

The interconnecting cables shall be acceptable for external use and shall be rated for
the proper application with respect to voltage, current, anticipated temperature, flam­mability, and mechanical serviceability.

CAUTION

–

+

1

2

V

,

AC

1

.
2

T

5

A

LAN (connect to ETH 0/1)

Ethernet

Laptop PC

L
IN

K

E

T
H

0

/
1

E

T
H

0

/
0

C
o

n

s

Reset

o
l

e

R

S

­2

3
2

SmartNode 5400 Series Quick Start Guide 3

Figure 1. Connecting to the PC

1. Connect the PC’s Ethernet port to LAN (ETH 0/1) port of the SmartNode 5400. The SmartNode 5400

Series is equipped with Auto-MDX Ethernet ports, so you can use straight-through or cross-over Ethernet
cables for host or hub/switch connections. (See figure 1.)

2. The SmartNode comes with a built-in DHCP server to simplify configuration. Therefore, to automatically

configure the PC for IP connectivity to the SmartNode, configure the laptop PC for DHCP. The SmartNode
will provide the PC with an IP address. Note that only Full Duplex operation is supported. Use auto nego­tiation for best results.

3. Check the connection to the SmartNode by executing the ping command from the PC command window

as follows:

ping 192.168.1.1

3.0 Configuring the desired IP address

3.1 Factory-default IP settings

The factory default configuration for the Ethernet interface IP addresses and netmasks are listed in table 1.
Both Ethernet interfaces are activated upon power-up. LAN interface ETH 0/1 (LAN) provides a default DHCP
server. The WAN interface uses DHCP client to get the IP address and netmask automatically from the
service provider.

Table 1. Factory default IP address and network mask configuration

Item IP Addresss Network Mask

WAN interface Ethernet 0 (ETH 0/0) DHCP DHCP
LAN interface Ethernet 1 (ETH 0/1) 192.168.1.1 255.255.255.0
DHCP server address range (LAN) 192.168.1.10-192.168.1.99 255.255.255.0

If these addresses match with those of your network, go to section 4.0 “Connecting the SmartNode to the

network” on page 5. Otherwise, continue with the following sections to change the addresses and

network masks.

3.2 Login

1. To access the SmartNode, start the Telnet application on your PC. Type the default IP address into the

address field: 192.168.1.1. Accessing your SmartNode via a Telnet session displays the login screen.
Type the factory default login: administrator and leave the password empty. Press the Enter key after the
password prompt.

login:administrator
password:<Enter>

192.168.1.1>

2. After you log in, your SmartNode will be running in operator execution mode (indicated by > character

in the command line prompt). To enter configuration mode, use the commands enable and configure.

192.168.1.1>enable

4 SmartNode 5400 Series Quick Start Guide

192.168.1.1#configure

192.168.1.1(cfg)#

3.3 Changing the WAN IP address

1. To modify IP configuration settings, you must enter context IP mode. Enter the following command:

192.168.1.1(cfg)#context ip router

192.168.1.1(ctx-ip)[router]#

2. Now you can set your IP address and network mask for the interface ETH 0/0(WAN). In this example a

network 172.16.1.0/24 is assumed. The IP address in example is set to 172.16.1.99. (You should set it
to the IP address that the network provider has given you.)

Note The examples in this guide use a private IP network with the network address 172.16.1.0/24.

192.168.1.1(ctx-ip)[router]#interface WAN

192.168.1.1(if-ip)[WAN]#ipaddress 172.16.1.99 255.255.255.0
2002-10-29T00:09:40 : LOGINFO : Link down on interface WAN.
2002-10-29T00:09:40 : LOGINFO : Link up on interface WAN.

172.16.1.99(if-ip)[WAN]#

3. Copy this modified configuration to your new start-up configuration. This will store your changes in non-

volatile memory. On the next start-up the system will initialize itself using the modified configuration.

172.16.1.99 (if-ip)[WAN]#copy running-config startup-config

172.16.1.99 (if-ip)[WAN]#

The SmartNode can now be connected to your network.

4.0 Connecting the SmartNode to the network

The interconnecting cables shall be acceptable for external use and shall be rated for
the proper application with respect to voltage, current, anticipated temperature, flam­mability, and mechanical serviceability.

CAUTION

In general, the SmartNode will connect to the network via the WAN (ETH 0/0) port. This enables the SmartNode
to offer routing services to the PC hosts on LAN (ETH 0/1) port. The SmartNode 5400 Series provides an auto-

SmartNode 5400 Series Quick Start Guide 5

MDX feature for both Ethernet ports, so you can use a straight-through or cross-over cable to connect to a host or
a switch (see figure 2).

–

+

12V, 1.25A

A
C

T

L

I
N

K

E
T

H

0

/
1

E
T

H

0

/
0

C
o

n

Reset

s
o

l
e

LAN

R

S

­2
3

2

LAN (ETH 0/1)

WAN (ETH 0/0)

Straight-through wired or crossover cable

Network

Figure 2. Connecting the SmartNode to the network

1. You can check the connection with the ping command from the SmartNode to another host on the

local LAN.

172.16.1.99(if-ip)[WAN]#ping <IP Address of the host>

Note If the WAN address is not set to DHCP, to ping a device outside your local LAN you must first configure

the default gateway. (For information on configuring the default gateway, refer to section “Set IP
addresses” in Appendix C, “Command Summary” of the SmartNode Series SmartWare Software Config-
uration Guide.)

5.0 Loading the configuration (optional)

Patton provides a collection of configuration templates on the support page at www.patton.com/smart­node—one of which may be similar enough to your application that you can use it to speed up configuring the

SmartNode. Simply download the configuration note that matches your application to your PC. Adapt the config­uration as described in the configuration note to your network (remember to modify the IP address) and copy
the modified configuration to a TFTP server. The SmartNode can now load its configuration from this server.

Note If your application is unique and not covered by any of Patton’s configuration templates, you can man-

ually configure the SmartNode instead of loading a configuration file template. In that case, refer to the
SmartWare Software Configuration Guide for information on configuring the SmartNode device.

In this example we assume an TFTP server resides on the host with the IP address 172.16.1.11 and the configu­ration file named SN.cfg resides in the root directory of the TFTP server.

172.16.1.99(if-ip)[WAN]#copy tftp://172.16.1.11/SN.cfg startup­config

Download...100%

6 SmartNode 5400 Series Quick Start Guide

172.16.1.99(if-ip)[WAN]#

After you reboot the SmartNode the new startup configuration will become active.

When you issue the reload command, the SmartNode will ask if you want to copy the
running configuration to the startup configuration. Since you just downloaded a con­figuration file to the startup configuration you must answer this question with NO.

IMPORTANT

172.16.1.99(if-ip)[WAN]#reload
Running configuration has been changed.
Do you want to copy the 'running-config' to the 'startup-config'?
Press 'yes' to store, 'no' to drop changes : no
Press 'yes' to restart, 'no' to cancel : yes
The system is going down

Otherwise, the downloaded configuration will be overwritten and lost!

6.0 Additional Information

For detailed information about configuring and operating guidance, set up procedures, and troubleshooting,
refer to the SN5400 User Manual available online at www.patton.com/manuals/SN5400.pdf and the
SmartWare Software Configuration Guide available online at www.patton.com/smartnode.

A.0 Customer and Technical Support

Online support: www.patton.com
E-mail support: [e-mail]—answered within 1 business day
Telephone support:

•

Standard: [phone] (USA), Monday–Friday: 8:00 am to 5:00 pm EST (1300 to
2200 UTC/GMT)

•

Alternate: [phone] (Switzerland), Monday–Friday: 8:00 am to 5:00 pm CET (0900 to 1800
UTC/GMT)

Fax: [phone] (USA) or [phone] (Switzerland)

B.0 Compliance Information

B.1 Compliance

EMC Compliance:

SmartNode 5400 Series Quick Start Guide 7

•

EN55022, Class A

•

EN55024

Safety Compliance:

•

IEC/EN 60950-1, 2nd edition

PSTN Regulatory Compliance:

•

This device is not intended nor approved for connection to the PSTN

B.2 CE Declaration of Conformity

Patton Electronics, Inc declares that this device is in compliance with the essential requirements and other rele­vant provisions of Directive 1999/5/EC. The Declaration of Conformity may be obtained from Patton Electron­ics, Inc. at www.patton.com/certifications.

The safety advice in the documentation accompanying this device shall be obeyed. The conformity to the above
directive is indicated by CE mark on the device.

B.3 Authorized European Representative

D R M Green
European Compliance Services Limited.
Avalon House, Marcham Road
Abingdon,Oxon OX14 1UD, UK

Copyright statement

Copyright © 2012, Patton Electronics Company. All rights reserved.
The information in this document is subject to change without notice. Patton Electronics assumes no

liability for errors that may appear in this document.

Trademarks statement

The term SmartNode is a trademark of Patton Electronics Company. All other trademarks presented in this docu-
ment are the property of their respective owners.

Warranty, Trademark, & Compliance Information

For warranty, trademark and compliance information, refer to the SmartNode 5400 User Manual located online
at www.patton.com/manuals.
