Patton 547 User Manual

USER
MANUAL

MODELS 546 and
547

V.35 Data Line
Surge Protectors

SALES OFFICE
[phone]
TECHNICAL SUPPORT
[phone]
http://www.patton.com

Part# 07M546-C
Doc# 074290UC
Revised 10/29/98

An ISO-9001

Certified Company

1.0 WARRANTY INFORMATION

Patton Electronics warrants Model 546 and Model 547
components to be free from defects, and will—at our option—repair or
replace the product should it fail within one year from the first date of
shipment.

This warranty is limited to defects in workmanship or materials, and
does not cover customer damage, abuse or unauthorized modification.
If this product fails or does not perform as warranted, your sole
recourse shall be repair or replacement as described above. Under no
condition shall Patton Electronics be liable for any damages incurred
by the use of this product. These damages include, but are not limited
to, the following: lost profits, lost savings and incidental or
consequential damages arising from the use of or inability to use this
product. Patton Electronics specifically disclaims all other warranties,
expressed or implied, and the installation or use of this product shall be
deemed an acceptance of these terms by the user.

1.1 SERVICE

All warranty and non-warranty repairs must be returned freight
prepaid and insured to Patton Electronics. All returns must have a
Return Materials Authorization number on the outside of the shipping
container.

This number may be obtained from Patton Electronics Technical
Service at: [phone]; http://www.patton.com: or,

[e-mail].

Note: Packages received without an RMA number will not be

accepted.

Patton Electronics' technical staff is also available to answer any
questions that might arise concerning the installation or use of your
Model 546 or Model 547. Technical Service hours: 8AM to 5PM EST,

Monday through Friday.

1.2 CE NOTICE

The CE symbol on your Patton Electronics equipment indicates
that it is in compliance with the Electromagnetic Compatibility (EMC)
directive and the Low Voltage Directive (LVD) of the Union European
(EU). A Certificate of Compliance is available by contacting Technical
Support.

1

2.0 GENERAL INFORMATION

Thank you for your purchase of this Patton Electronics product.
This product has been thoroughly inspected and tested and is
warranted for One Year parts and labor. If any questions or problems
arise during installation or use of this product, please do not hesitate to
contact Patton Electronics Technical Support at [phone].

2.1 FEATURES

• Bidirectional transient protection

• Model 546: 1 male M/34 and 1 female M/34 connector

• Model 547: 1 male M/34 and 1 LFH60 male connector

• Supports data rates up to 20 Mbps

• 1500 Watts of self-resetting surge capacity

• Diverts surges to chassis ground through a braided metal ground
strap

• Complies with IEC 801-5, Level 3, 2kV (surge)

• Failsafe design guards equipment in case of overvoltage

• Made in the U.S.A.

2.2 DESCRIPTION

The Patton Model 546 and Model 547 data line surge protector

guards V.35 data ports against damage and data loss due to transient
surges. Three versions are available. Model 546MF protects 19 lines,
Model 546/34MF protects all 34 lines, and Model 547MM protects 18
lines. Whether due to nearby lightning strikes, electric motors,
florescent lights or the normal operation of AC power protection
equipment, data line transients can be hazardous to V.35 hardware.
The Model 546 and the Model 547 protectors are equipped with a
heavy duty braided metal strap to shunt harmful overvoltages safely to
ground.

The Model 546 and Model 547 surge protectors are CE marked for

EMC directive 89/336/EEC and IEC 801-5.

WARNING: Should your equipment or building be subject to
direct lightening strike, this product will not provide complete
protection.

2

4.0 INSTALLATION

APPENDIX A

There are 4 steps to installing the Patton Models 546 and 547.
NOTE:Failure to follow these instructions could render the current

limiting feature inoperable. If you have any questions,
contact us at: [phone]; http://www.patton.com;
or, [e-mail]. Read the relevant section(s)
of your manufacturer’s user manual before beginning any
work.

Model 546

1. Turn off power to your V.35 device and disconnect the power
cord(s) from the wall outlet(s).

2. Unplug the existing connection between the V.35 cable and

your equipment.

3. Install the Model 546 between your equipment and your cable.

4. Connect the metal ground strap to your equipment’s ground.

Model 547

1. Turn off power to the router (or other device) and the network
termination equipment and disconnect the power cord(s) from
the wall outlet(s).

2. Unplug any existing connection between the V.35 cable and
your equipment.

3. Plug the LFH60 to the router(or other device) and the V.35
(M/34) to the network termination equipment.

4. Connect the metal ground strap to the equipment’s ground.

MODEL 546 AND 547 SPECIFICATIONS

Electrical: 546:CCITT/ITU V.35

547: CCITT/ITU V.35, DTE Orientation on

the LFH60 connector

Connectors: 546:1 male M/34, 1 female M/34

547:1 male M/34, 1 LFH60 male

Surge Capacity: 1500 Watts for 1msec, 400A (8/20 µS pulse)
Approvals: CE marked for EMS directive 89\336\EEC

(ESD.EFT) Compliant with IEC 801-5
(surge)

Clamp Voltage: +/- 19V/19V Differential in 500nS
Size: 3" x 1.7" x .8" (7.62 x 4.318 x 20.32 cm)

Model 546MF and Model 547MM

546 Lines Protected: 19 lines (B, C, D, E, F, H, L, M, N, P, R, S,

T, U, V, W, X, Y, AA)

547 Lines Protected: 18 lines (A, B, C, D, E, F, H, K, P, R, S, T, U,

V, W, X, Y, AA)

WARNING!: The Model 546 and the Model 547 are
secondary devices, and are designed for inside use only.
Moreover, do not attempt to connect these surge protectors
during a lightning storm. Patton Electronics Company
accepts no liability for damage or injury associated with the
use of these products.The protected device should also have
an AC suppression device to prevent transients from entering
the system via the incoming AC power connection. (These
transients also can show up as failures on the
communication link.)

3 4

Protection: Common Mode Pin to Braid

Differential Line to Line

Model 546/34MF

Lines Protected: All 34 Lines
Protection: Common Mode Pin to Braid

Differential Line to Line

APPENDIX B

MODEL 547 PIN ASSIGNMENTS

V.35
M/34 Male LFH60 Male
Signal Pin No. Pin No. Signal

FG A -----------------------------------------46 FG
SG B ----------------------------------------- 45 SG
RTS C -----------------------------------------42 RTS
CTS D -----------------------------------------35 CTS
DSR E -----------------------------------------34 DSR
RLSD F ----------------------------------------- 33 RLSD
DTR H -----------------------------------------43 DTR
LT K -----------------------------------------44 LT
SD+ P ----------------------------------------- 18 SD+
SD- S -----------------------------------------17 SD­RD+ R -----------------------------------------28 RD+
RD- T -----------------------------------------27 RD­SCTE+ U -----------------------------------------20 SCTE+
SCTE- W ---------------------------------------- 19 SCTE­SCR+ V -----------------------------------------26 SCR+
SCR- X -----------------------------------------25 SCR­SCT+ Y -----------------------------------------24 SCT+
SCT- AA---------------------------------------- 23 SCT-

48
49
50
51
52
53
54
55
56

NOTE: The Patton Model 546 pin assignments have a one to one

relationship (example: pin 1 connects to pin 1, pin 2
connects to pin 2, etc.)

Copyright © 1998

Patton Electronics Company

All Rights Reserved

5
