Model 2292 & 2294
Leased-Line Extenders over IP
Getting Started Guide
Sales Office: +1 (301) 975-1000
Technical Support: +1 (301) 975-1007
E-mail: support@patton.com
WWW: www.patton.com
Part Number: 07M2292-GS, Rev. A
Revised: April 13, 2009
:
Patton Electronics Company, Inc.
7622 Rickenbacker Drive
Gaithersburg, MD 20879 USA
tel: +1 (301) 975-1000
fax: +1 (301) 869-9293
support: +1 (301) 975-1007
web: www.patton.com
e-mail: support@patton.com
Trademark Statement
The terms SmartWare and SmartView are trademarks of Patton Electronics Company.
All other trademarks presented in this document are the property of their respective
owners.
Copyright © 2009, Patton Electronics Company. All rights reserved.
The information in this document is subject to change without notice. Patton Electronics assumes no liability for errors that may appear in this document.
Warranty Information
The software described in this document is furnished under a license and may be used
or copied only in accordance with the terms of such license.
Patton Electronics warrants all SmartNode extender components to be free from
defects, and will—at our option—repair or replace the product should it fail within
one year from the first date of the shipment.
This warranty is limited to defects in workmanship or materials, and does not cover
customer damage, abuse or unauthorized modification. If the product fails to perform
as warranted, your sole recourse shall be repair or replacement as described above.
Under no condition shall Patton Electronics be liable for any damages incurred by
the use of this product. These damages include, but are not limited to, the following:
lost profits, lost savings and incidental or consequential damages arising from the use
of or inability to use this product. Patton Electronics specifically disclaims all other
warranties, expressed or implied, and the installation or use of this product shall be
deemed an acceptance of these terms by the user.
Summary Table of Contents
1 General information...................................................................................................................................... 14
2 Applications overview.................................................................................................................................... 19
3 Hardware installation.................................................................................................................................... 21
4 Getting started with the SmartNode.............................................................................................................. 32
5 LEDs status and monitoring ......................................................................................................................... 36
6 Contacting Patton for assistance ................................................................................................................... 38
A Compliance information .............................................................................................................................. 41
B Specifications ................................................................................................................................................ 43
C Cabling ......................................................................................................................................................... 46
D Port pin-outs ................................................................................................................................................ 50
E Installation checklist .................................................................................................................................... 52
3
Table of Contents
Summary Table of Contents ........................................................................................................................... 3
Table of Contents ........................................................................................................................................... 4
List of Figures ................................................................................................................................................. 6
List of Tables .................................................................................................................................................. 7
About this guide ............................................................................................................................................. 8
Safety when working with electricity ...............................................................................................................10
Preventing electrostatic discharge damage .......................................................................................................11
General observations .......................................................................................................................................11
General conventions .......................................................................................................................................12
1 General information...................................................................................................................................... 14
SmartNode Series Leased-Line Extenders overview................................................................................................15
SmartNode 2292 and 2294 Leased-Line Extenders .........................................................................................16
2 Applications overview.................................................................................................................................... 19
Typical application ................................................................................................................................................20
Leased-line extension ......................................................................................................................................20
3 Hardware installation.................................................................................................................................... 21
Planning the installation........................................................................................................................................22
Installation checklist ........................................................................................................................................23
Site log ............................................................................................................................................................24
Network information ......................................................................................................................................24
IP related information .....................................................................................................................................24
Software tools .................................................................................................................................................24
Power source ...................................................................................................................................................24
Location and mounting requirements .............................................................................................................25
Installing the SmartNode extender ........................................................................................................................25
Mounting the SmartNode extender ................................................................................................................25
Connecting cables ...........................................................................................................................................25
4 Getting started with the SmartNode.............................................................................................................. 32
Introduction..........................................................................................................................................................33
Configure the IP address........................................................................................................................................34
Power connection and default configuration ...................................................................................................34
Connect with the serial interface .....................................................................................................................34
Login ..............................................................................................................................................................35
5 LEDs status and monitoring ......................................................................................................................... 36
Status LEDs...........................................................................................................................................................37
6 Contacting Patton for assistance ................................................................................................................... 38
Introduction..........................................................................................................................................................39
Contact information..............................................................................................................................................39
Warranty Service and Returned Merchandise Authorizations (RMAs)...................................................................39
4
5
Model 2292 & 2294 Series Getting Started Guide
Table of Contents
Warranty coverage ..........................................................................................................................................39
RMA numbers ................................................................................................................................................40
A Compliance information .............................................................................................................................. 41
Compliance ...........................................................................................................................................................42
EMC ...............................................................................................................................................................42
Safety ..............................................................................................................................................................42
CE Declaration of Conformity ..............................................................................................................................42
B Specifications ................................................................................................................................................ 43
Capacity ................................................................................................................................................................44
Audio connectivity ................................................................................................................................................44
Data Services .........................................................................................................................................................44
Quality of Service ..................................................................................................................................................44
Voice Signaling......................................................................................................................................................44
Voice Processing....................................................................................................................................................45
Management .........................................................................................................................................................45
System...................................................................................................................................................................45
Temperature..........................................................................................................................................................45
Humidity ..............................................................................................................................................................45
C Cabling ......................................................................................................................................................... 46
Introduction..........................................................................................................................................................47
Serial console.........................................................................................................................................................47
Ethernet 10Base-T and 100Base-T ........................................................................................................................48
Analog FXS ...........................................................................................................................................................49
D Port pin-outs ................................................................................................................................................ 50
Introduction..........................................................................................................................................................51
Console port..........................................................................................................................................................51
Ethernet 10Base-T and 100Base-T port.................................................................................................................51
Voice port..............................................................................................................................................................51
E Installation checklist .................................................................................................................................... 52
Introduction..........................................................................................................................................................53
List of Figures
1 SmartNode extender (SmartNode 2294 shown) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2 Examples of SmartNode 2292 and 2294 Series rear panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3 SmartNode 2294 power input connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4 SmartNode 2292 and 2294 front panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5 Leased-line extension application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6 Rear view showing location of Ethernet connectors and voice ports (SmartNode 2294 shown) . . . . . . . . . . . . 26
7 Analog connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
8 Analog connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
9 RJ-11 pinout diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
10 Connecting a SmartNode 2294 Series device to a hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
11 Connecting to a host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
12 Power connector location on rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
13 SmartNode extender front panel LEDs and Console port locations (SmartNode 2294 shown) . . . . . . . . . . . . . 31
14 Steps for setting up a new SmartNode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
15 Connecting to the terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
16 Examples of SmartNode 2292 and 2294 Series front panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
17 Connecting a serial terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
18 Ethernet cross-over . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
19 Ethernet straight-through . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
20 Connecting an FXS device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
21 EIA-561 (RJ-45 8-pin) port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
6
List of Tables
1 General conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2 Rear panel ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3 Installation checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4 Sample site log entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5 RJ-11 socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6 Ethernet 10/100Base-T (RJ-45) port pin-outs (SmartNode 2294 Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7 Factory default IP address and network mask configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8 SmartNode LED Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
9 RJ-45 socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
10 RJ-11 socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
11 Installation checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
7
About this guide
This guide describes the SmartNode 2294 and 2292 Series hardware, installation and basic configuration. For
detailed software configuration information refer to the SmartWare Software Configuration Guide and the available Configuration Notes.
Audience
This guide is intended for the following users:
• Operators
• Installers
• Maintenance technicians
Structure
This guide contains the following chapters and appendices:
• Chapter 1 on page 14 provides information about extender features and capabilities
• Chapter 2 on page 19 contains an overview describing extender operation and applications
• Chapter 3 on page 21 provides quick start hardware installation procedures
• Chapter 4 on page 32 describes getting started with the SmartNode extender
• Chapter 5 on page 36 contains definitions for the LED status indicators
• Chapter 6 on page 38 contains information on contacting Patton technical support for assistance
• Appendix B on page 43 contains specifications for the extenders
• Appendix C on page 46 provides cable recommendations
• Appendix D on page 50 describes the extender’s ports and pin-outs
• Appendix E on page 57 lists the factory configuration settings for SmartNode 2294 Series devices
• Appendix F on page 59 lists the factory configuration settings for SmartNode 2292 Series devices
• Appendix E on page 52 lists the tasks for installing a SmartNode 2292 or 2294 Series extender
For best results, read the contents of this guide before you install the extender.
8
About this guide
Model 2292 & 2294 Series Getting Started Guide
Precautions
Notes and cautions, which have the following meanings, are used throughout this guide to help you become
aware of potential extender problems. Warnings relate to personal injury issues, and Cautions refer to potential
property damage.
Note
Calls attention to important information.
The shock hazard symbol and WARNING heading indicate a potential electric
shock hazard. Strictly follow the warning instructions to avoid injury caused
by electric shock.
The alert symbol and WARNING heading indicate a potential safety hazard.
Strictly follow the warning instructions to avoid personal injury.
The shock hazard symbol and CAUTION heading indicate a
potential electric shock hazard. Strictly follow the instructions to
avoid property damage caused by electric shock.
The alert symbol and CAUTION heading indicate a potential hazard. Strictly follow the instructions to avoid property damage.
9
10
Model 2292 & 2294 Series Getting Started Guide
Safety when working with electricity
•
This device contains no user serviceable parts. The equipment shall be
returned to Patton Electronics for repairs, or repaired by qualified service
personnel.
•
Mains Voltage: Do not open the case when the power cord is connected. For
systems without a power switch, line voltages are present within the
power supply when the power cord is connected.
•
The external power adapter shall be a listed Limited Power Source. Ensure
that the power cable used meets all applicable standards for the country in
which it is to be installed, and that it is connected to a wall outlet which has
earth ground. The mains outlet that is utilized to power the devise shall be
within 10 feet (3 meters) of the device, shall be easily accessible, and protected by a circuit breaker.
•
Hazardous network voltages are present in WAN ports regardless of
whether power to the SmartNode is ON or OFF. To avoid electric shock, use
caution when near WAN ports. When detaching cables, detach the end
away from the SmartNode first.
•
Do not work on the system or connect or disconnect cables during periods of
lightning activity.
•
Before opening the chassis, disconnect the telephone network cables to
avoid contact with telephone line voltages.
About this guide
In accordance with the requirements of council directive 2002/
96/EC on Waste of Electrical and Electronic Equipment (WEEE),
ensure that at end-of-life you separate this product from other
waste and scrap and deliver to the WEEE collection system in
your country for recycling.
About this guide
Model 2292 & 2294 Series Getting Started Guide
Preventing electrostatic discharge damage
When starting to install interface cards place the interface card on its shielded plastic bag if you lay it on your bench.
Electrostatic Discharge (ESD) can damage equipment and impair
electrical circuitry. It occurs when electronic printed circuit cards
are improperly handled and can result in complete or intermittent failures. Do the following to prevent ESD:
Always follow ESD prevention procedures when removing
•
and replacing cards.
•
Wear an ESD-preventive wrist strap, ensuring that it makes
good skin contact. Connect the clip to an unpainted surface
of the chassis frame to safely channel unwanted ESD voltages
to ground.
•
To properly guard against ESD damage and shocks, the wrist
strap and cord must operate effectively. If no wrist strap is
available, ground yourself by touching the metal part of the
chassis.
General observations
• Clean the case with a soft slightly moist anti-static cloth
• Place the unit on a flat surface and ensure free air circulation
• Avoid exposing the unit to direct sunlight and other heat sources
• Protect the unit from moisture, vapors, and aggressive liquids
11
12
SN
Model 2292 & 2294 Series Getting Started Guide
About this guide
Typographical conventions used in this document
This section describes the typographical conventions and terms used in this guide.
General conventions
The procedures described in this manual use the following text conventions:
Table 1. General conventions
Convention Meaning
Garamond blue type
Futura bold type
Futura bold-italic type Parts of commands, which are related to elements already named by the user, are
Italicized Futura type
Futura type Indicates the names of fields or windows.
Garamond bold type
< > Angle brackets indicate function and keyboard keys, such as <SHIFT>, <CTRL>,
[ ] Elements in square brackets are optional.
{a | b | c} Alternative but required keywords are grouped in braces ({ }) and are separated
blue screen
screen
node
# An hash sign at the beginning of a line indicates a comment line.
Indicates a cross-reference hyperlink that points to a figure, graphic, table, or section heading. Clicking on the hyperlink jumps you to the reference. When you
have finished reviewing the reference, click on the Go to Previous View
button
Commands and keywords are in boldface font.
in boldface italic font.
Variables for which you supply values are in italic font
Indicates the names of command buttons that execute an action.
<C>, and so on.
by vertical bars ( | )
Information you enter is in blue screen font.
Terminal sessions and information the system displays are in screen font .
The leading IP address or nodename of a SmartNode is substituted with node in
boldface italic font.
The leading SN on a command line represents the nodename of the SmartNode
in the Adobe® Acrobat® Reader toolbar to return to your starting point.
13
About this guide
Model 2292 & 2294 Series Getting Started Guide
Chapter 1
Chapter contents
SmartNode Series Leased-Line Extenders overview................................................................................................15
SmartNode 2292 and 2294 Leased-Line Extenders .........................................................................................16
Ports descriptions ......................................................................................................................................17
Reset button behavior ...............................................................................................................................17
General information
14
15
Model 2292 & 2294 Series Getting Started Guide
1 • General information
SmartNode Series Leased-Line Extenders overview
The SmartNode 2292 and 2294 Series Leased-Line Extenders (see figure 1) combine IP routing, VPN/Security, and Quality of Service for up to 4 transparent voice channels and FAX calls over any IP or PSTN network.
Leverage low-cost IP services with packet-voice for complete branch office voice and data connectivity.
Figure 1. SmartNode extender (SmartNode 2294 shown)
The SmartNode 2292 and 2294 Leased-Line Extenders, equipped with two 10/100Base-T Ethernet ports provide; voice over IP (VoIP) and Internet telephony plus Internet access routing, VPN and firewall functions,
and extensive Quality of Service (QoS) functions.
The SmartNode 2292 and 2294 Leased-Line Extenders perform the following major functions:
• Voice over IP via 2 or 4 analog analogleased line voice ports.
• Standard compliant VoIP conversion in accordance with SIP and H.323 protocols.
• Internet access and IP Routing with IP Quality of Service (QoS) support for mixed voice and data traffic.
SmartNode Series Leased-Line Extenders overview
Model 2292 & 2294 Series Getting Started Guide 1 • General information
SmartNode 2292 and 2294 Leased-Line Extenders
The SmartNode 2292 and 2294 models are compact Leased-Line Extenderss over IP that support two or four
VoIP channels, depending on the number of ports (see figure 2).
Model 2292
Ports
Reset
, 1.25A
Model 2294
ETH 0/1 ETH 0/0
Ports
, 1.25A
, 1.25A
Reset
ETH 0/1
ETH 0/0
Reset
ETH 0/1 ETH 0/0
Ports
Figure 2. Examples of SmartNode 2292 and 2294 Series rear panels
The following base models (each equipped with two 10/100Base-T Ethernet ports) are available:
• SmartNode 2292/EUI (2 VoIP leased line channels)
• SmartNode 2294/EUI (4 VoIP leased line channels)
The port combinations are indicated in the extension of the model code. T he following model code conventions apply:
• The last number in the model code stands for the number of voice ports.
• EUI stands for external universal input power supply (see figure 3)
For example, the model code 2294/EUI describes a SmartNode configured as follows:
• 4 voice ports
• External power supply
Note For a complete listing of available models, refer to the SmartNode
VoIP page at http://www.patton.com/voip/.
SmartNode Series Leased-Line Extenders overview 16
Model 2292 & 2294 Series Getting Started Guide 1 • General information
External power supply connector (accepts 12 VDC, 1.25 A, from external AC adapter)
Ports
, 1.25A
Reset
ETH 0/1 ETH 0/0
, 1.25A
Reset
ETH 0/1
ETH 0/0
Ports
Figure 3. SmartNode 2294 power input connectors
Ports descriptions
The SmartNode 2292 Series rear panel ports are described in table 2.
Table 2. Rear panel ports
Port Location Description
10/100 Ethernet
ETH 0/0 & ETH 0/1
Analog voice port Rear panel
Rear panel
RJ-45 connectors (see figure 6 on page 26) that connect the extender to an
Ethernet device (e.g., a cable or DSL modem, LAN hub or switch).
FXS RJ-11(6 position, 4 wire) connectors (see figure 6 on page 26) that
connect the extender with an analog terminal.
Power Rear panel The gateway is available in a DC or AC power input version (see
figure 3), labeled as follows:
• AC version (Internal power supply): 100–240 VAC, 50/60 Hz, 200 mA
• DC version: 12 VDC, 1.25 A
Console Front panel
Used for service and maintenance, the Console port (see figure 4 on page 18),
an RS-232 RJ-45 connector, connects the extender to a serial terminal such as a
PC or ASCII terminal (also called a dumb terminal).
Reset button behavior
The SmartNode devices have a Reset button on the rear panel. It is used as follows:
• To restart the unit with the current startup configuration—Press for less than 1 second and release the Reset
button. The SmartNode will restart with the current startup configuration.
• To restart the unit with factory default configuration—Press the Reset button for 5 seconds until the Power
LED starts blinking. The unit will restart with factory default configuration.
SmartNode Series Leased-Line Extenders overview 17
Model 2292 & 2294 Series Getting Started Guide 1 • General information
• To restart the unit in bootloader mode (to be used only by trained SmartNode technicians)—Start with the
unit powered off. Press and hold the Reset button while applying power to the unit. Release the Reset button
when the Power LED starts blinking so the unit will enter bootloader mode.
Model 2292
SmartNode 2292
Leased-Line Extender Over IP
Link
100M
Power
Run
VoIP Link
Activity
Link
Enet 0 Ports
Enet 1
Model 2294
Link
100M
Power
Run
VoIP Link
4
9
2
2
P
I
e
r
d
e
o
v
O
N
t
r
r
e
a
d
n
m
e
t
S
x
E
e
n
i
L
-
d
e
s
a
e
L
Console
0/3
0/2
0/1
0/0
Ports
Activity
100M
Link
Enet 1
Activity
100M
Link
Enet 0
VoIP Link
Run
Power
Activity
Link
Enet 0 Ports
Enet 1
100M
100M
Activity
Activity
0/0
0/1
Console
SmartNode 2294
Leased-Line Extender Over IP
0/0
0/1
0/2
0/3
Console
Figure 4. SmartNode 2292 and 2294 front panels
Note For LED descriptions, refer to chapter 5, “LEDs status and monitor-
ing” on page 36.
SmartNode Series Leased-Line Extenders overview 18
Chapter 2 Applications overview
Chapter contents
Typical application ................................................................................................................................................20
Leased-line extension ......................................................................................................................................20
19
Model 2292 & 2294 Series Getting Started Guide 2 • Applications overview
Typical application
Leased-line extension
The SmartNode 2292 and 2294 Series Leased-Line Extenders allow you to save big on leased line costs. Using
only one extender on each side, audio information on up to four leased-lines can be transported over a packetbased network. This essentially ensures that with just Internet access at two locations, four leased lines between
these two locations can be established.
Combine this with IP routing, VPN/Security, and Quality of Service for up to 4 transparent voice channels
and FAX calls over any IP or PSTN network, the 2292/2294 leverages low-cost IP services with packet-voice
for complete branch office voice and data connectivity.
Figure 5. Leased-line extension application
Typical application 20
Chapter 3 Hardware installation
Chapter contents
Planning the installation........................................................................................................................................22
Installation checklist ........................................................................................................................................23
Site log ............................................................................................................................................................24
Network information ......................................................................................................................................24
Network Diagram .....................................................................................................................................24
IP related information .....................................................................................................................................24
Software tools .................................................................................................................................................24
Power source ...................................................................................................................................................24
Location and mounting requirements .............................................................................................................25
Installing the SmartNode extender ........................................................................................................................25
Mounting the SmartNode extender ................................................................................................................25
Connecting cables ...........................................................................................................................................25
Installing an interface cable on the extender’s voice ports ..........................................................................26
Installing the Ethernet cable ......................................................................................................................28
Connecting to external power source .........................................................................................................30
21
Model 2292 & 2294 Series Getting Started Guide 3 • Hardware installation
Planning the installation
Before you start the actual installation, it is strongly recommended that you gather all the information needed
to install and setup the device. See table 3 for an example of what pre-installment checks you might need to
carry out. Having carried out the pre-installation checks enables you to install and set up your SmartNode
extender into an existing infrastructure with confidence.
The mains outlet that is utilized to power the equipment must be
within 1 foot (0.3048 meters) of the device and shall be easily
accessible.
Note When setting up your SmartNode extender consider cable length limita-
tions, and potential electromagnetic interference (EMI) as defined by the
applicable local and international regulations. Ensure that your site is properly prepared before beginning installation.
Before installing the SmartNode extender device, the following tasks should be completed:
• Create a network diagram (see section “Network information” on page 24)
• Gather IP related information (see section “IP related information” on page 24 for more information)
• Install the hardware and software needed to configure the SmartNode. (See section “Software tools” on
page 24)
• Verify power source reliability (see section “Power source” on page 24).
When you finish preparing for SmartNode extender installation, go to section “Installing the SmartNode
extender” on page 25 to install the device.
Planning the installation 22
Model 2292 & 2294 Series Getting Started Guide 3 • Hardware installation
Installation checklist
The installation checklist (see table 3) lists the tasks for installing a SmartNode 2292 or 2294 Series extender.
Make a copy of this checklist and mark the entries as you complete each task. For each SmartNode 2292 or
2294 Series extender, include a copy of the completed checklist in your site log.
Table 3. Installation checklist
Task Verified by Date
Network information available & recorded in site log
Environmental specifications verified
Site power voltages verified
Installation site pre-power check completed
Required tools available
Additional equipment available
All printed documents available
SmartWare release & build number verified
Rack, desktop, or wall mounting of chassis completed
Initial electrical connections established
ASCII terminal attached to console port
Cable length limits verified
Initial configuration performed
Initial operation verified
Planning the installation 23
Model 2292 & 2294 Series Getting Started Guide 3 • Hardware installation
Site log
Patton recommends that you maintain a site log to record all actions relevant to the system, if you do not
already keep such a log. Site log entries should include information such as listed in table 4.
Table 4. Sample site log entries
Entry Description
Installation Make a copy of the installation checklist and insert it into the site log
Upgrades and maintenance Use the site log to record ongoing maintenance and expansion history
Configuration changes Record all changes and the reasons for them
Maintenance Schedules, requirements, and procedures performed
Comments Notes, and problems
Software Changes and updates to SmartWare software
Network information
Network connection considerations that you should take into account for planning are provided for several
types of network interfaces are described in the following sections.
Network Diagram
Draw a network overview diagram that displays all neighboring IP nodes, connected elements and telephony
components.
IP related information
Before you can set up the basic IP connectivity for your SmartNode 2292 or 2294, you should have the following information:
• IP addresses used for Ethernet LAN and WAN ports
• Subnet mask used for Ethernet LAN and WAN ports
• IP addresses of central H.323 Gatekeeper (if used)
• IP addresses of central PSTN Gateway for H.323 and/or ISoIP based calls
• IP addresses of central TFTP Server used for configuration upload and download
Software tools
You will need a PC (or equivalent) with a VT-100 emulation program (e.g. HyperTerminal) to configure the
software on your SmartNode extender.
Power source
If you suspect that your AC power is not reliable, for example if room lights flicker often or there is machinery
with large motors nearby, have a qualified professional test the power. Install a power conditioner if necessary.
Planning the installation 24
Model 2292 & 2294 Series Getting Started Guide 3 • Hardware installation
Location and mounting requirements
The SmartNode extender is intended to be placed on a desktop or similar sturdy, flat surface that offers easy
access to the cables. Allow sufficient space at the rear of the chassis for cable connections. Additionally, you
should consider the need to access the unit for future upgrades and maintenance.
Installing the SmartNode extender
SmartNode extender installation consists of the following:
• Placing the device at the desired installation location (see section “Mounting the SmartNode extender” on
page 25)
• Installing the interface and power cables (see section “Connecting cables” on page 25)
When you finish installing the SmartNode, go to chapter 4, “Getting started with the SmartNode” on page 32.
Mounting the SmartNode extender
Place the extender on a desktop or similar sturdy, flat surface that offers easy access to the cables. The extender
should be installed in a dry environment with sufficient space to allow air circulation for cooling.
Note For proper ventilation, leave at least 2 inches (5 cm) to the left, right, front,
and rear of the SmartNode extender.
Connecting cables
Do not work on the system or connect or disconnect cables during periods of
lightning activity.
The Interconnecting cables shall be acceptable for external use and shall be
rated for the proper application with respect to voltage, current, anticipated
temperature, flammability, and mechanical serviceability.
Installing extender cables takes place in the following order:
1. Installing the RJ-11 voice port cable or cables (see “Installing an interface cable on the extender’s voice
ports” on page 26)
2. Installing the 10/100 Ethernet port cable or cables (see “Installing the Ethernet cable” on page 28)
3. Installing the power input (see “Connecting to external power source” on page 30)
Installing the SmartNode extender 25
Model 2292 & 2294 Series Getting Started Guide 3 • Hardware installation
Installing an interface cable on the extender’s voice ports
The SmartNode extender comes with at least two voice ports (see figure 6) located on the back of the extender.
The voice ports are connected to analog devices via cables (see figure 7) terminated with RJ-11 connectors (see
figure 9 and table 5 on page 27 for pin-out information).
Voice ports
Ports
, 1.25A
Ethernet connectors
ETH 0/1 ETH 0/0
Reset
, 1.25A
Reset
ETH 0/1
ETH 0/0
Ports
Figure 6. Rear view showing location of Ethernet connectors and voice ports (SmartNode 2294 shown)
, 1.25A
Reset
ETH 0/1 ETH 0/0
Ports
RJ-11, male RJ-11, male
Figure 7. Analog connection
Installing the SmartNode extender 26
Model 2292 & 2294 Series Getting Started Guide 3 • Hardware installation
, 1.25A
Reset
ETH 0/1 ETH 0/0
PSTN
wall plate
Ports
RJ-11, male RJ-11, male
Figure 8. Analog connection
4
9
2
2
P
I
e
r
d
e
o
v
O
N
t
r
r
e
a
d
n
m
e
t
S
x
E
e
n
i
L
-
d
e
s
a
e
L
Console
0/3
0/2
0/1
0/0
Ports
Activity
100M
Link
Enet 1
Activity
100M
Link
Enet 0
VoIP Link
Run
Power
654321
Socket
123456
Plug
Figure 9. RJ-11 pinout diagram
Table 5. RJ-11 socket
Pin Signal
3 Ring (-)
4 Tip (+)
Note Unit must not connect directly to telecom network voltage (TNV).
Installing the SmartNode extender 27
Model 2292 & 2294 Series Getting Started Guide 3 • Hardware installation
Installing the Ethernet cable
The SmartNode 2292 Series has automatic MDX (auto-cross-over) detection and configuration on the Ethernet ports. Any of the two ports can be connected to a host or hub/switch with a straight-through wired cable
(see figure 10 on page 28). Ethernet devices (10Base-T or 100Base-T) are connected to the SmartNode’s Ethernet ports (see table 6 for port pin-out listing) via a cable terminated with RJ-45 plugs. Because the SmartNode
2294 Series does not have the MDX feature, a cross-over cable is required when connecting SmartNode 2294
Series devices to a host (see figure 11 on page 29).
Table 6. Ethernet 10/100Base-T (RJ-45) port pin-outs (SmartNode 2294 Series)
Pin Signal
1 TX+
2 TX3 RX+
6 RX-
Note Pins not listed are not used.
, 1.25A
Reset
ETH 0/1 ETH 0/0
Ports
Hub
Straight-through cable
RJ-45, male
1
Tx+
2
Tx-
3
Rx+
6
Rx-
RJ-45, male
1 Rx+
2 Rx3 Tx+
6 Tx-
Figure 10. Connecting a SmartNode 2294 Series device to a hub
Installing the SmartNode extender 28
Model 2292 & 2294 Series Getting Started Guide 3 • Hardware installation
,
, 1.25A
Reset
ETH 0/1
ETH 0/0
Ports
Host
Cross-over cable
Twisted pair 1
Twisted pair 2
RJ-45, male
1
Tx+
2
Tx-
3
Rx+
6
Rx-
RJ-45
1 TX+
2 TX3 RX+
6 RX-
Figure 11. Connecting to a host
Installing the SmartNode extender 29
Model 2292 & 2294 Series Getting Started Guide 3 • Hardware installation
Connecting to external power source
The extender comes with an external power supply. This section describes installing the power cord into the
extender. Do the following:
Note Do not connect the power cord to the power outlet at this time.
1. Insert the barrel type connector end of the AC power cord into the external power supply connector (see
figure 12).
External power supply connector (accepts 12 VDC, 1.25 A, from external AC adapter)
Ports
, 1.25A
Reset
ETH 0/1 ETH 0/0
, 1.25A
Reset
ETH 0/1
ETH 0/0
Ports
Figure 12. Power connector location on rear panel
The extender power supply automatically adjusts to accept an
input voltage from 100 to 240 VAC (50/60 Hz).
Verify that the proper voltage is present before plugging the
power cord into the receptacle. Failure to do so could result in
equipment damage.
2. Verify that the AC power cord included with your extender is compatible with local standards. If it is not,
refer to “Contacting Patton for assistance” on page 38 to find out how to replace it with a compatible
power cord.
3. Connect the male end of the power cord to an appropriate power outlet.
Installing the SmartNode extender 30
Model 2292 & 2294 Series Getting Started Guide 3 • Hardware installation
SmartNode 2294
Leased-Line Extender Over IP
Console
3
/
0
2
/
0
1
/
0
0
y
/
t
i
0
v
i
orts
t
c
M
0
A
0
k
1
n
y
i
t
i
L
v
i
t
net 1
c
M
E
0
A
k
0
k
1
in
in
L
L
P
I
o
Enet 0 P
V
r
n
e
u
w
R
o
P
SmartNode 2294
Leased-Line Extender Over IP
Link
100M
Power
Run
VoIP Link
Activity
Link
100M
Activity
0/0
0/1
0/2
0/3
Console
Voice
Power VoIP Link
Run
Enet 0
100M
Enet 1
100M
Voice
Port 0/0
Voice
Port 0/2
Port 0/3
Console
port
Voice
Enet 0
Link
Enet 0
Activity
Enet 1
Link
Enet 1
Activity
Port 0/1
Figure 13. SmartNode extender front panel LEDs and Console port locations (SmartNode 2294 shown)
4. Verify that the green Power LED is lit (see figure 13).
Congratulations, you have finished installing the SmartNode extender! Now go to chapter 4, “Getting started
with the SmartNode” on page 32.
Installing the SmartNode extender 31
Chapter 4 Getting started with the SmartNode
Chapter contents
Introduction..........................................................................................................................................................33
Configure the IP address........................................................................................................................................34
Power connection and default configuration ...................................................................................................34
Connect with the serial interface .....................................................................................................................34
Login ..............................................................................................................................................................35
32
Model 2292 & 2294 Series Getting Started Guide 4 • Getting started with the SmartNode
Introduction
This chapter leads you through the basic steps to set up a new SmartNode and to download a configuration.
Patton SmartNodes can be used for a wide variety of IP-based network applications. To support and ease the
configuration of the SmartNodes configuration, templates for the most important applications are available on
the Patton server at www.patton.com/voip.
The main steps for setting up a new SmartNode are shown in figure 14.
Configure IP address
1
4
9
2
2
P
I
e
r
d
Activity
100M
Link
1
t
e
n
E
Activity
100M
Link
0
t
e
n
E
VoIP Link
Run
Power
Connect the SmartNode to the network
2
0/3
0/2
0/1
0/0
s
t
r
o
P
e
o
v
O
N
t
r
r
e
a
d
n
m
e
t
S
x
E
e
n
i
L
d
e
s
a
e
L
Console
Console port
Serial
interface
PC or workstation
with VT-100
emulation terminal
Load configuration
3
Ethernet interface
ETH0
4
9
2
2
P
I
e
r
d
e
o
v
O
N
t
r
r
e
a
d
n
m
e
t
S
x
E
e
n
i
L
d
e
s
a
e
L
Console
0/3
0/2
0/1
0/0
s
t
r
o
P
Activity
100M
Link
1
t
e
n
E
Activity
100M
Link
0
t
e
n
E
VoIP Link
Run
Power
4
9
2
2
P
I
e
r
d
e
o
v
O
N
t
r
r
e
a
d
n
m
e
t
S
x
E
e
n
i
L
d
e
s
a
e
L
Console
0/3
0/2
0/1
0/0
s
t
r
o
P
Activity
100M
Link
1
t
e
n
E
Activity
100M
Link
0
t
e
n
E
VoIP Link
Run
Power
Note
You can manually configure the
SmartNode. You do not have to load a
configuration file.
Figure 14. Steps for setting up a new SmartNode
PC or workstation
or VT-100 emulation
terminal
2. Modify configuration
3. Load configuration
1. Download configuration example
Internet
Patton Web server
with configuration examples
Introduction 33
Model 2292 & 2294 Series Getting Started Guide 4 • Getting started with the SmartNode
Configure the IP address
Power connection and default configuration
First the SmartNode must be connected to the mains power supply with the power cable. Wait until the 'Run'
LED stops blinking and lights constantly. Now the SmartNode is ready.
The factory default configuration for the Ethernet interface IP addresses and network masks are listed in table 7.
Table 7. Factory default IP address and network mask configuration
IP Address Network Mask
Interface Ethernet 0 (ETH0) DHCP DHCP
Interface Ethernet 1 (ETH1) 192.168.1.1 255.255.255.0
Both Ethernet interfaces are activated upon power-up.
Connect with the serial interface
The Console port is wired as an EIA-561, RS-232 port. Use the included Model 16F-561 adapter and cable (see
figure 15) between the SmartNode’s Console port and a PC or workstation’s RS-232 serial interface. Activate the
terminal emulation program on the PC or workstation that supports the serial interface (e.g. HyperTerm).
Link
Activity
100M
Link
0
t
e
n
E
VoIP Link
Run
Power
Figure 15. Connecting to the terminal
Terminal emulation program settings:
• 9600 baud
• no parity
• 8 bit
• 1 stop bit
• 1 start bit
• No flow control
P
I
r
e
v
O
r
e
d
n
e
t
SmartNode 2294
x
E
e
n
i
L
-
d
e
s
a
e
L
Console
0/3
0/2
0/1
0/0
s
t
r
o
P
Activity
100M
1
t
e
n
E
Serial Terminal
Note A Patton Model 16F-561 RJ45 to DB-9 adapter is included with
each SmartNode Series device
Configure the IP address 34
Model 2292 & 2294 Series Getting Started Guide 4 • Getting started with the SmartNode
Login
1. Accessing your SmartNode via the local console port (or via a Telnet session) causes the login screen to dis-
play. Type the factory default login: administrator and leave the password empty. Press the Enter key after
the password prompt.
login:administrator
password: <Enter>
172.16.40.1>
2. After you have successfully logged in you are in the operator execution mode, indicated by > as command
line prompt. With the commands enable and configure you enter the configuration mode.
172.16.40.1>enable
172.16.40.1#configure
172.16.40.1(cfg)#
3. Enter the following commands for the first SmartNode 229x device in the pair:
Copy nvram:a-side-config startup-config
Copy running-config startup-config
4. Follow the same procedure for the other SmartNode 229x device in the pair:
Copy nvram:b-side-config startup-config
Copy running-config startup-config
Note The configuration above is only a sample configuration that you may use as
an example. You should specify your own parameters such as your IP address
and other related parameters as required. For detailed information about
configuring and operating your SmartNode, set-up procedures, and troubleshooting, refer to the SmartNode Series SmartWare Software Configuration
Guide on the CD-ROM that came with your unit.
5. Reboot both units and connect them back-to-back through their Ethernet 0/1 ports. Voice connections
will automatically be set up between the units.
The steps above will configure the IP addresses as well as the required configurations for voice connections.
Configure the IP address 35
Chapter 5 LEDs status and monitoring
Chapter contents
Status LEDs...........................................................................................................................................................37
36
Model 2292 & 2294 Series Getting Started Guide 5 • LEDs status and monitoring
Status LEDs
This chapter describes SmartNode VoIP extender front panel LEDs. Figure 16 shows SmartNode 2292 and
2294 Series LEDs. LED definitions are listed in table 8 on page 37.
SmartNode 2294
Leased-Line Extender Over IP
Console
3
/
0
2
/
0
1
/
0
0
y
/
t
i
0
v
i
t
c
M
0
A
0
k
1
y
in
t
i
L
v
i
t
c
M
Enet 1
0
A
k
0
k
n
1
i
n
i
L
L
P
I
o
Enet 0 Ports
V
r
n
e
u
w
R
o
P
SmartNode 2294
Leased-Line Extender Over IP
Link
100M
Power
Run
VoIP Link
Activity
Link
100M
Activity
0/0
0/1
0/2
0/3
Console
Voice
Power VoIP Link
Run
Enet 0
100M
Enet 1
100M
Voice
Port 0/0
Voice
Port 0/2
Port 0/3
Console
port
Voice
Enet 0
Link
Enet 0
Activity
Enet 1
Link
Enet 1
Activity
Port 0/1
Figure 16. Examples of SmartNode 2292 and 2294 Series front panels
Table 8. SmartNode LED Indications
LED Description
Note If an error occurs, all LEDs will flash once per second.
Power When lit, indicates power is applied. Off indicates no power applied.
Run When lit, indicates normal operation. Flashes once per second during boot (startup).
VoIP Link When lit, indicates the gateway is registered on a gatekeeper, media gateway con-
troller, associated to a remote unit, or has an active VoIP connection. Off indicates the
unit is not configured or registered and has no active VoIP connection. Flashing green
indicates that the unit is attempting or has failed to associate/register
Voice port Solid when leased line channel is operational. Should not be off or blinking.
Ethernet (each port) • Link: Lit when Ethernet link is up.
• 100M: On when 100-Mbps Ethernet is selected.
• Activity: Flashes when data is received or transmitted from the unit to the LAN.
Status LEDs 37
Chapter 6 Contacting Patton for assistance
Chapter contents
Introduction..........................................................................................................................................................39
Contact information..............................................................................................................................................39
Warranty Service and Returned Merchandise Authorizations (RMAs)...................................................................39
Warranty coverage ..........................................................................................................................................39
Out-of-warranty service .............................................................................................................................39
Returns for credit ......................................................................................................................................39
Return for credit policy .............................................................................................................................40
RMA numbers ................................................................................................................................................40
Shipping instructions ................................................................................................................................40
38
Model 2292 & 2294 Series Getting Started Guide 6 • Contacting Patton for assistance
Introduction
This chapter contains the following information:
• “Contact information”—describes how to contact Patton technical support for assistance.
• “Warranty Service and Returned Merchandise Authorizations (RMAs)”—contains information about the
RAS warranty and obtaining a return merchandise authorization (RMA).
Contact information
Patton Electronics offers a wide array of free technical services. If you have questions about any of our other
products we recommend you begin your search for answers by using our technical knowledge base. Here, we
have gathered together many of the more commonly asked questions and compiled them into a searchable
database to help you quickly solve your problems:
• Online support—available at www.patton.com
• E-mail support—e-mail sent to support@patton.com will be answered within 1 business day
• Telephone support—standard telephone support is available five days a week—from 8:00 am to 5:00 pm
EST (1300 to 2200 UTC)—by calling +1 (301) 975-1007
Warranty Service and Returned Merchandise Authorizations (RMAs)
Patton Electronics is an ISO-9001 certified manufacturer and our products are carefully tested before shipment. All of our products are backed by a comprehensive warranty program.
Note If you purchased your equipment from a Patton Electronics reseller, ask your
reseller how you should proceed with warranty service. It is often more convenient for you to work with your local reseller to obtain a replacement.
Patton services our products no matter how you acquired them.
Warranty coverage
Our products are under warranty to be free from defects, and we will, at our option, repair or replace the product should it fail within one year from the first date of shipment. Our warranty is limited to defects in workmanship or materials, and does not cover customer damage, lightning or power surge damage, abuse, or
unauthorized modification.
Out-of-warranty service
Patton services what we sell, no matter how you acquired it, including malfunctioning products that are no
longer under warranty. Our products have a flat fee for repairs. Units damaged by lightning or other catastrophes may require replacement.
Returns for credit
Customer satisfaction is important to us, therefore any product may be returned with authorization within 30
days from the shipment date for a full credit of the purchase price. If you have ordered the wrong equipment or
you are dissatisfied in any way, please contact us to request an RMA number to accept your return. Patton is
not responsible for equipment returned without a Return Authorization.
Introduction 39
Model 2292 & 2294 Series Getting Started Guide 6 • Contacting Patton for assistance
Return for credit policy
• Less than 30 days: No Charge. Your credit will be issued upon receipt and inspection of the equipment.
• 30 to 60 days: We will add a 20% restocking charge (crediting your account with 80% of the purchase price).
• Over 60 days: Products will be accepted for repairs only.
RMA numbers
RMA numbers are required for all product returns. You can obtain an RMA by doing one of the following:
• Completing a request on the RMA Request page in the Support section at www.patton.com
• By calling +1 (301) 975-1007 and speaking to a Technical Support Engineer
• By sending an e-mail to returns@patton.com
All returned units must have the RMA number clearly visible on the outside of the shipping container. Please use
the original packing material that the device came in or pack the unit securely to avoid damage during shipping.
Shipping instructions
The RMA number should be clearly visible on the address label. Our shipping address is as follows:
Patton Electronics Company
RMA#: xxxx
7622 Rickenbacker Dr.
Gaithersburg, MD 20879-4773 USA
Patton will ship the equipment back to you in the same manner you ship it to us. Patton will pay the return
shipping costs.
Warranty Service and Returned Merchandise Authorizations (RMAs) 40
Appendix A Compliance information
Chapter contents
Compliance ...........................................................................................................................................................42
EMC ...............................................................................................................................................................42
Safety ..............................................................................................................................................................42
CE Declaration of Conformity ..............................................................................................................................42
41
Model 2292 & 2294 Series Getting Started Guide A • Compliance information
Compliance
EMC
• EN55022, Class A
• EN55024
Safety
• EN60950
CE Declaration of Conformity
This equipment conforms to the requirements of Council Directive 1999/5/EC on the approximation of the
laws of the member states relating to Radio and Telecommunication Terminal Equipment and the mutual recognition of their conformity.
The safety advice in the documentation accompanying this product shall be obeyed. The conformity to the
above directive is indicated by CE sign on the device.
The signed Declaration of Conformity can be downloaded at www.patton.com/certifications.
Compliance 42
Appendix B Specifications
Chapter contents
Capacity ................................................................................................................................................................44
Audio connectivity ................................................................................................................................................44
Data Services .........................................................................................................................................................44
Quality of Service ..................................................................................................................................................44
Voice Signaling......................................................................................................................................................44
Voice Processing....................................................................................................................................................45
Management .........................................................................................................................................................45
System...................................................................................................................................................................45
Temperature..........................................................................................................................................................45
Humidity ..............................................................................................................................................................45
43
Model 2292 & 2294 Series Getting Started Guide B • Specifications
Capacity
2 audio lines (2292)
4 audio lines (2294)
Audio connectivity
2-wire RJ-11
Bandwidth 4kHz, Impedance 600-ohm
Narrow Band FXS style hybrid transmit/receive
Data Services
Two 10/100 Ethernet ports
Complete IP access router
DHCP Client & server
Packet fragmentation
Static firewall, NAT, NAPT RFC 1631 access control lists
DMZ port
IPsec, IKE, AES/DES/3DES Encryption
Quality of Service
Audio priority
DownStreamQoS™
Traffic management, shaping and policing
IEEE 802.1p, TOS, DiffServ labeling
IEEE 802.1Q, VLAN tag insertion/deletion (simultaneous support of multiple VLANs)
Voice Signaling
H.323v4, SIPv2 (B2BUA
capable, multi-instance, simultaneous
support of multiple registrars and direct
IP dialing) • SIP call transfer, redirect
DTMF in-band & out-of-band
Capacity 44
Model 2292 & 2294 Series Getting Started Guide B • Specifications
Voice Processing
CODEC G.711 a-law/mu-law, G.723, G.729ab,
G.726, G.727. T.38 fax relay (9.6 k, 14.4k)
G.711 transparent fax and bypass
Management
Web/HTTP, CLI with local console and remote Telnet access
TFTP configuration & firmware loading
SNMP MIB II and product MIB
Secure Mass provisioning for both firmware and unit configuration
Built-in diagnostic tools (trace, debug, call generator)
System
CPU Motorola MPC875 @66MHz
Memory 32MB SDRAM/8MB Flash
Power 100–240 VAC (50/60Hz)
Power dissipation 4-8W, model dependent
Temperature
32–104°F (0–40°C)
Humidity
5–80%, non-condensing
Voice Processing 45
Appendix C Cabling
Chapter contents
Introduction..........................................................................................................................................................47
Serial console.........................................................................................................................................................47
Ethernet 10Base-T and 100Base-T ........................................................................................................................48
Analog FXS ...........................................................................................................................................................49
46
Model 2292 & 2294 Series Getting Started Guide C • Cabling
Introduction
This section provides information on the cables used to connect the SmartNode and the interface cards to the
existing network infrastructure and to third party products.
Serial console
The SmartNode can be connected to a serial terminal over its serial console port, as depicted in figure 17.
4
9
2
2
P
I
e
r
d
e
o
v
O
tN
r
r
e
a
d
n
m
e
t
S
x
E
e
n
i
L
-
d
e
s
a
e
L
Console
0/3
0/2
0/1
0/0
rts
o
P
Activity
100M
Link
t 1
e
n
E
Activity
100M
Link
t 0
e
n
E
VoIP Link
Run
Power
Note A Patton Model 16F-561 RJ45 to DB-9 adapter is included with
each SmartNode Series device
Serial Terminal
Figure 17. Connecting a serial terminal
Note See section “Console port” on page 51 for console port pin-outs.
Introduction 47
Model 2292 & 2294 Series Getting Started Guide C • Cabling
Ethernet 10Base-T and 100Base-T
Ethernet devices (10Base-T/100Base-T) are connected to the SmartNode over a cable with RJ-45 plugs. Use a
cross-over cable to a host, or a straight cable to a hub. See figure 18 (host) and figure 19 on page 49 (hub) for
the different connections.
Note The SmartNode 2292 Series is equipped with Auto-MDX Ethernet ports.
Use straight-through wired cables for host or hub/switch connections
, 1.25A
Reset
ETH 0/1
ETH 0/0
Ports
Twisted pair 1
Twisted pair 2
RJ-45, male
1
Tx+
2
Tx-
3
Rx+
6
Rx-
Host
Cross-over cable
RJ-45,
1 TX+
2 TX3 RX+
6 RX-
Figure 18. Ethernet cross-over
Ethernet 10Base-T and 100Base-T 48
Model 2292 & 2294 Series Getting Started Guide C • Cabling
, 1.25A
Reset
ETH 0/1 ETH 0/0
Ports
Hub
Straight-through cable
RJ-45, male
1
Tx+
2
Tx-
3
Rx+
6
Rx-
RJ-45, male
1 Rx+
2 Rx3 Tx+
6 Tx-
Figure 19. Ethernet straight-through
Analog FXS
Applicable to SmartNodes equipped with FXS ports. The FXS ports are connected to analog terminals
(phones, fax machines, answering machines) via cables terminated with RJ-11 connectors (see section “Voice
port” on page 51 for details on port pinouts).
, 1.25A
Reset
ETH 0/1 ETH 0/0
Ports
RJ-11, male RJ-11, male
Figure 20. Connecting an FXS device
Analog FXS 49
Appendix D Port pin-outs
Chapter contents
Introduction..........................................................................................................................................................51
Console port..........................................................................................................................................................51
Ethernet 10Base-T and 100Base-T port.................................................................................................................51
Voice port..............................................................................................................................................................51
50
Model 2292 & 2294 Series Getting Started Guide D • Port pin-outs
Introduction
This section provides pin-out information for the ports of the SmartNode.
Console port
Figure 21. EIA-561 (RJ-45 8-pin) port
Note Pins not listed are not used.
Ethernet 10Base-T and 100Base-T port
Table 9. RJ-45 socket
Pin Signal
1 TX+
2 TX-
3 RX+
6 RX-
Note Pins not listed are not used.
Voice port
The voice ports use an RJ-11 connector with 6 positions. The midle two positions 3 and 4 are used according
to table 10.
Table 10. RJ-11 socket
Pin Signal
3 Ring (-)
4 Tip (+)
Note Pins not listed are not used.
Introduction 51
Appendix E Installation checklist
Chapter contents
Introduction..........................................................................................................................................................53
52
Model 2292 & 2294 Series Getting Started Guide E • Installation checklist
Introduction
This appendix lists the tasks for installing a SmartNode 2292 or 2294 Series extender (see table 11) . Make a
copy of this checklist and mark the entries as you complete each task. For each SmartNode 2292 or 2294 Series
extender, include a copy of the completed checklist in your site log.
Table 11. Installation checklist
Task Verified by Date
Network information available & recorded in site log
Environmental specifications verified
Site power voltages verified
Installation site pre-power check completed
Required tools available
Additional equipment available
All printed documents available
SmartWare release & build number verified
Rack, desktop, or wall mounting of chassis completed
Initial electrical connections established
ASCII terminal attached to console port
Cable length limits verified
Initial configuration performed
Initial operation verified
Introduction 53
Loading...
