MODEL 2036 and
2037
Parallel to Serial/
Serial to Parallel
Interface Converters
An ISO-9001
Certified Company
Dear Valued Customer,
Thank you for purchasing Patton Electronics products! We do
appreciate your business. I trust that you find this user manual helpful.
We manufacture one of the widest selections of data
communications products in the world including CSU/DSU's, network
termination units, powered and self-powered short range modems, fiber optic
modems, interface converters, baluns, electronic data switches, data-line surge
protectors, multiplexers, transceivers, hubs, print servers and much more. We
produce these products at our Gaithersburg, MD, USA, facility, and can
custom manufacture products for your unique needs.
We would like to hear from you. Please contact us in any of the
following ways to tell us how you like this product and how we can meet your
product needs today and in the future.
Web: http://www.patton.com
Sales E-mail: sales@patton.com
Support E-mail: support@patton.com
Phone - Sales (301) 975-1000
Phone - Support (301) 975-1007
Fax: (301) 869-9293
Mail: Patton Electronics Company
7622 Rickenbacker Drive
Gaithersburg, MD 20879 USA
We are committed to a quality product at a quality price. Patton
Electronics is BABT and ISO 9001 certified. We meet and exceed the highest
standards in the industry (CE, UL, etc.).
It is our business to serve you. If you are not satisfied with any
aspect of this product or the service provided from Patton Electronics or its
distributors, please let us know.
Thank you.
Burton A.Patton
Executive Vice President
P.S. Please tell us where you purchased this product.
________________________________________________________
________________________________________________________
________________________________________________________
________________________________________________________
________________________________________________________
________________________________________________________
________________________________________________________
_______
1.0 WARRANTY INFORMATION
Patton Electronics warrants all Model 2036 and 2037
components to be free from defects, and will—at our option—repair or
replace the products should they fail within one year from the first date
of shipment.
This warranty is limited to defects in workmanship or materials, and
does not cover customer damage, abuse or unauthorized modification.
If these products fail or do not perform as warranted, your sole recourse
shall be repair or replacement as described above. Under no condition
shall Patton Electronics be liable for any damages incurred by the use
of these products. These damages include, but are not limited to, the
following: lost profits, lost savings and incidental or consequential
damages arising from the use of or inability to use this product. Patton
Electronics specifically disclaims all other warranties, expressed or
implied, and the installation or use of this product shall be deemed an
acceptance of these terms by the user.
1.1 RADIO AND TV INTERFERENCE
The Model 2036 and Model 2037 generate and use radio
frequency energy, and if not installed and used properly—that is, in
strict accordance with the manufacturer's instructions—may cause
interference to radio and television reception. They have been tested
and found to comply with the limits for Class A computing devices in
accordance with the specifications in Subpart J of Part 15 of FCC rules,
which are designed to provide reasonable protection from such
interference in a commercial installation. However, there is no
guarantee that interference will not occur in a particular installation. If
they do cause interference to radio or television reception, which can
be determined by disconnecting the RS-232 interface, the user is
encouraged to try to correct the interference by one or more of the
following measures: moving the computing equipment away from the
receiver, re-orienting the receiving antenna and/or plugging the
receiving equipment into a different AC outlet (such that the computing
equipment and receiver are on different branches).
1.2 CE NOTICE
The CE symbol on your Patton Electronics equipment indicates
that it is in compliance with the Electromagnetic Compatibility (EMC)
directive and the Low Voltage Directive (LVD) of the Union European
(EU). A Certificate of Compliance is available by contacting Technical
Support.
1
1.3 SERVICE
All warranty and non-warranty repairs must be returned freight
prepaid and insured to Patton Electronics. All returns must have a
Return Materials Authorization number on the outside of the shipping
container. This number may be obtained from Patton Electronics
Technical Support: (301) 975-1007, http://www.patton.com, or;
support@patton.com..
NOTE: Packages received without an RMA number will not be
accepted.
Patton Electronics' technical staff is also available to answer any
questions that might arise concerning the installation or use of your
Model 2036 or Model 2037. Technical Support hours: 8AM to 5PM
EST, Monday through Friday.
2
3.0 CONFIGURATION
The Model 2036 and 2037 are simple to install and designed for
excellent reliability. The following instructions will help you set up and
install your converter properly. If you have any questions, please call
Patton Technical Support at (301) 975-1007.
3.1 CONFIGURATION SWITCHES
The Model 2036 and 2037 each use a set of eight external DIP
switches (see Figure 1) that allow configuration to a wide range of
applications. Because all eight switches are in one externally
accessible DIP switch package, there is no need to open the case for
configuration. The configuration switches allow you to select data
rates, parity, word length and flow control selection. The following
section describes all switch locations, positions and functions.
The Model 2036 and 2037 each use a
miniature
configuration
switch package. To configure your unit, use a small screwdriver and
gently push each switch to its proper setting. The ON and OFF
positions are shown in Figure 2. Default settings for the DIP switches
are shown in the table on the following page. Detailed settings follow
the table.
2.0 GENERAL INFORMATION
Thank you for your purchase of this Patton Electronics product.
This product has been thoroughly inspected and tested and is
warranted for One Year parts and labor. If any questions or problems
arise during installation or use of this product, please do not hesitate to
contact Patton Electronics Technical Support at (301) 975-1007.
2.1 FEATURES
• Converts parallel data to serial data or vice versa
• Automatically selects parallel-to-serial or serial-to-parallel operation
• Automatically selects DCE/DTE modes
• Serial data rates to 115,200 bps
• No AC power required
• Supports both software and hardware flow control
• A five-state LED monitors status and diagnostics
• External configuration switches
• Ultra-miniature size
• Made in the USA
2.2 DESCRIPTION
The Patton Model 2036 and 2037 Parallel to Serial Converter
automatically convert RS-232 serial data to parallel data format or vice
versa. Incorporating advanced microprocessor technology, the Model
2036 and 2037 automatically sense and select parallel and serial
modes, as well as DCE/DTE modes. Requiring no AC power, the
Model 2036 and 2037 support serial data rates to 115,200 kbps.
For easy configuration, the Model 2036 and 2037 feature a
convenient set of external configuration switches. These accessible
configuration switches allow the user to control baud rate, parity, word
length and flow control. An easy-to-read LED indicator displays status
and operating condition.
Housed in an ultra-miniature ABS plastic case, the Model 2036
comes equipped with a DB-25 female or male connector on the serial
side and a Centronics™ 36 pin male connector on the parallel side.
The Model 2037 is housed in the same convenient case and comes
equipped with a DB-25 female connector on the serial side and male
or
female connector on the parallel side.
3 4
Figure 1. The location of the configuration switches:
the Model 2036 (left) and the Model 2037 (right)
Figure 2. The miniature configuration switch package
Configuration
Switches
12345678
OFF
DHS-8
12345678
OFF
DHS-8
12345678
OFF
DHS-8
Switch 3 through 5: Data, Parity and Stop Bit
Switches 3 through 5 are used to specify the data, parity and stop
bits. The following table shows the settings that may be used:
Switches 6 through 8: Frequency and Data Rate
Switches 6 through 8 determine the frequency and data rate. The
following chart shows the settings that may be used:
3.2 DETAILED SWITCH SETTINGS
This section provides detailed information about the function of
each DIP switch and lists all possible settings.
Switch 1: Hardware/Software Control
The setting for Switch 1 determines whether these interface
converters will control either hardware or software flow control.
Switch 2: Enable/Disable LED Indicator
The setting for Switch 2 determines whether the LED indicator is
enabled or disabled.
5 6
1200 OFF OFF ON
2400 ON OFF ON
4800 ON ON OFF
9600 OFF ON ON
19200 ON ON ON
38400 OFF OFF OFF
57600 ON OFF OFF
115200 OFF ON OFF
Model 2036 and 2037
Data Rate SW6 SW7 SW8
Flow Control SW1
Hardware OFF
Software ON
LED SW2
Enabled ON
Disabled OFF
7B EP 1S ON ON ON
7B OP 1S OFF ON ON
7B NP 2S ON OFF ON
7B EP 2S OFF OFF ON
7B OP 2S ON ON OFF
8B EP 1S OFF ON OFF
8B OP 1S ON OFF OFF
8B NP 1S OFF OFF OFF
Stop
Data Parity Bit SW3 SW4 SW5
DIP SWITCH SUMMARY TABLE
Position Function Factory Default
SW1 Flow Control Off
SW2 LED Indicator On
SW3 Data, Parity, Stop Bits Off
SW4 Data, Parity, Stop Bits Off
SW5 Data, Parity, Stop Bits Off
SW6 Data Rate Off
SW7 Data Rate Off
SW8 Data Rate Off
Hardware
Enabled
8B, NP, 1S
38400 bps
}
}
5.0 OPERATION
Once your interface converter is properly configured and installed,
it should operate transparently—as if it were a standard cable
connection. Operating power is derived from the RS-232 data and
control signals; there is no “ON/OFF” switch.
5.1 LED STATUS MONITORS
The Model 2036 and 2037 feature an easy-to-read LED that shows
the operating status of the Model 2036. Figure 1 (page 4) shows the
location of these LEDs. The following chart describes the LED’s status
codes.
Please refer to the following key to interpret the above status
codes:
4.0 INSTALLATION
The Patton Model 2036 and 2037 are very simple to install. Once
you have configured the DIP switches, just plug your converter in to a
standard cable and you’re ready to go. Figure 3 illustrates the proper
connections for the Model 2036 and 2037. If you have special-ordered
a non-standard connector, your connections may be different.
7 8
LED Codes
● ● — ● ——— ● ● — ● ——— Computer is sending data
● ——— ● ——— ● ——— Serial device is connected; computer is
not sending data
● ● ——— ● ● ——— Both serial and parallel devices are
connected; computer not sending
data
● — ● ——— ● — ● ——— Printer not ready, data held in buffer
● ● ● ● ———● ● ● ● Computer ignoring flow control, data lost
Key:
● Blink
— Short pause
——— Long pause
Figure 3. Installing the Model 2036
Model 2036 or 2037
PC
Printer
Your cable
APPENDIX A
PATTON MODEL 2036 AND 2037 SPECIFICATIONS
Interface: Asynchronous., RS-232C compatible
Connectors: (Model 2036)
Serial: DB-25 male or female;
Parallel: Centronics 36 pin male
(Model 2037)
Serial: DB-25 female;
Parallel: DB-25 male or female
Data Rates: 1200, 2400, 4800, 9600, 19200, 38400,
57600, and 115200 bps
LED: LED displays status and operating condition
Power Supply: Uses power from RS-232 interface; 9Vdc
maximum typical current = 20mA; Typical
maximum power consumption = 100mW @
5V (20mA)
Data Format: 7 or 8 data bits; 1 or 2 stop bits; even, odd
or no parity
Temperature Range: 0-60
°
C (32-140°F)
Altitude: 0-10,000 feet
Humidity: 5 to 95% noncondensing
Dimensions: 3.37” x 2.43” x 0.76” (Model 2036);
3.13” x 2.12” x 0.73” (Model 2037)
Weight: 2 oz. (56.8 grams)
APPENDIX B
PATTON MODEL 2036 AND 2037 INTERFACE CONNECTIONS
36 PIN CENTRONICS PARALLEL PORT CONNECTIONS
Note: All other pins are unconnected
DB-25 PORT CONNECTIONS
Note: All other pins are unconnected
9 10
Pin Description Direction
Serial to Parallel Parallel to Serial
1 Strobe Output Input
2 Data Bit 0 Output Input
3 Data Bit 1 Output Input
4 Data Bit 2 Output Input
5 Data Bit 3 Output Input
6 Data Bit 4 Output Input
7 Data Bit 5 Output Input
8 Data Bit 6 Output Input
9 Data Bit 7 Output Input
10 Acknowledge Input Output
11 Busy Input Output
12 Paper End (to ground through resistor) Input Output
13 Select Input Output
14 To +5V through resistor
15 Error Input Output
16 To +5V through resistor
17 To +5V through resistor
18
19
20
21
22
23
24
25
Ground
Pin #
Signal
Name
Description
Connected to DTE Connected to DCE
1
FG
Frame Ground
2
TD
Transmit Data Input & Power Source Output
3
RD
Receive Data Output Input & Power Source
4
RTS
Request to Send Input & Power Source Output
5
CTS
Clear to Send Output Input & Power Source
6
DSR
Data Set Ready Output Input & Power Source
7
SG
Signal Ground
8
CD
Carrier Detect Output Input & Power Source
9
V+
External Power Source Input for Power Input for Power
20
DTR
Data Terminal Ready Input & Power Source Output
APPENDIX B
(continued)
SIGNAL DIRECTIONS
APPENDIX D
PATTON MODEL 2036 BLOCK DIAGRAM
12
Converter
Function
Serial Port
Connected
Serial Data
Flow
Serial Software Flow
Ctrl. Signal
(XON/XOFF)
Serial Hardware
Flow Ctrl Signal
(DTR, CTS, DSR)
Serial to Parallel DTE TD
RD CTS, DSR
Serial to Parallel DCE RD
TD DTR
Parallel to Serial DTE RD
TD DTR
Parallel to Serial DCE TD
RD CTS, DSR
11
APPENDIX D
PATTON MODEL 2037 BLOCK DIAGRAM
13
Loading...
