Patton 1000RP User Manual

USER

Part# 07M1000RP-B
Doc# 078011UB
Revised 3/19/96

MANUAL

Model 1000RP Series

AC and DC Rack Mount
Power Supplies

SALES OFFICE
[phone]
TECHNICAL SUPPORT
[phone]

1.0 WARRANTY INFORMATION

2.0 GENERAL INFORMATION

Thank you for your purchase of these Patton Electronics products.
They have been thoroughly inspected and tested and are warranted for
One Year parts and labor. If any questions or problems arise during
installation or use of these products, please do not hesitate to contact
Patton Electronics Technical Support at [phone].

2.1 FEATURES

• Low Profile “Mid-Plane Architecture” Design

• Easily Replaceable Front and Rear Modules

• Front Panel Power Switch and LED Indicator(s)

• Compatible with all Patton Rack Cards

• Compatible with Patton Rack Chassis and Cluster Boxes

• One Power Supply Services up to 16 Rack Cards

• AC Models Available in Domestic/International 120/230V AC and
European (EN60950 Compliant) 120/230V AC Versions

• DC Models Available with 48V, 24V and 12V DC Power Input

2.2 DESCRIPTION

The Patton Model 1000RP Series power supply modules fit in any

Patton rack chassis or Cluster Box, and supply up to sixteen Patton
rack cards with necessary operating power. Like all Patton rack cards,
the Model 1000RP Series uses a mid-plane architecture: Each module
incorporates a front power supply module (with power switch and LEDs)
and rear power entry module (with power source interface).

The Model 1000RP Series is compatible with all Patton Rack

Cards, and is available with an AC or a DC input. There are two
different AC versions available: The first version is CSA and UL (or
equivalent) certified. The second version adds elements that allow it to
comply with the EN 60950 Safety of Information Technology Equipment
standard. Both AC power supplies accept 120 or 220-240V AC.

The 48V DC power module accepts an input voltage of 40-60V

DC. The 24V DC power module accepts an input voltage of 18-36V
DC. The 12V DC power module accepts an input voltage of
10-20V DC. All DC modules use cage clamp terminal blocks that make
wire connection easy. An extra port on the terminal block allows the
user to daisy chain multiple units together. An alarm relay opens when
power is attached and closes when power is disconnected.

Patton Electronics warrants all Model 1000RP Series
components to be free from defects, and will—at our option—repair or
replace the products should they fail within one year from the first date
of shipment. This warranty is limited to defects in workmanship or
materials, and does not cover customer damage, abuse or
unauthorized modification. If these products fail or do not perform as
warranted, your sole recourse shall be repair or replacement as
described above. Under no condition shall Patton Electronics be
liable for any damages incurred by the use of these products. These
damages include, but are not limited to, the following: lost profits, lost
savings and incidental or consequential damages arising from the use
of or inability to use this product. Patton Electronics specifically
disclaims all other warranties, expressed or implied, and the installation
or use of this product shall be deemed an acceptance of these terms by
the user.

1.1 RADIO AND TV INTERFERENCE

The Model 1000RP Series units generate and use radio frequency
energy, and if not installed and used properly—that is, in strict
accordance with the manufacturer's instructions—may cause
interference to radio and television reception. They have been tested
and found to comply with the limits for a Class A computing device in
accordance with the specifications in Subpart J of Part 15 of FCC rules,
which are designed to provide reasonable protection from such
interference in a commercial installation. However, there is no
guarantee that interference will not occur in a particular installation. If
these products do cause interference to radio or television reception,
which can be determined by turning off the unit, the user is encouraged
to try to correct the interference by one or more of the following
measures: moving the computing equipment away from the receiver,
re-orienting the receiving antenna and/or plugging the receiving
equipment into a different AC outlet (such that the computing
equipment and receiver are on different branches).

1.2 SERVICE

All warranty and non-warranty repairs must be returned freight
prepaid and insured to Patton Electronics. All returns must have a
Return Materials Authorization number on the outside of the shipping
container. This number may be obtained from Patton Electronics
Technical Service at [phone]. Packages received without an
RMA number will not be accepted. Patton's technical staff is also
available to answer any questions that might arise concerning the
installation or use of your products. Technical Service hours: 8AM to

5PM EST, Monday through Friday.

3.0 INSTALLATION

Patton’s Model 1000RP Series power supply modules are easy to
install and require no configuration. This section describes the
functions of the Model 1000R16P rack chassis, tells how to install front
and rear power supply cards into the chassis and how to make the
power interface connections.

Caution: To avoid shock hazard, do not connect AC

or DC power cable(s) until power supply module is fully
assembled.

Front (Power Supply) Card Installation

3.1 THE MODEL 1000R16P RACK CHASSIS

The Model 1000R16P Rack Chassis (Figure 1, below) features
sixteen function card slots and one power supply card slot. (Note: refer
to function card user manuals for proper installation of function cards)
Measuring only 3.5” high, the Model 1000R16P is designed to occupy
only 2U in a 19” rack. Sturdy front handles allow the Model 1000R16P
to be extracted and transported conveniently.

Figure 1. Model 1000R16P Rack Chassis with Power Supply

3.2 INSTALLING POWER SUPPLY MODULES

All power supply modules (AC or DC) are comprised of two cards:
the front power supply card and the rear power entry card. These two
cards meet inside the rack chassis and plug into each other by means
of a multipin connector. (The same holds true for all Patton Cluster
Boxes as well.) Use the following steps as a guideline for installing
each power supply module into the Model 1000R16P rack chassis:

1. Make sure the power switch is in the OFF position.

2. Slide the power supply card into the front of the chassis. It should
meet the rear card when it's almost all the way into the chassis.

3. Push the front card gently into the multipin connector on the
rear card.

4. Secure the front card using the thumb screws.

3.3 REAR CARD POWER CONNECTION - AC VERSIONS

The Model 1000RPEM and 1000RPEM-V rear cards are equipped

with a shrouded male IEC-320 AC power interface. This interface
accepts a domestic US power cord (supplied) or any number of
international power cords (see Appendix B).

3.4 REAR CARD POWER CONNECTION - DC VERSION

The Model 1000RPEM-DC rear card comes equipped with a cage

clamp terminal block. The following instructions will tell you how to
install the rear card.

Caution: Connect the equipment to a SELV DC

supply source that is electrically isolated from the AC
power sources. The DC power source should also be
reliably connected to earth ground.

Rear (Power Entry) Card Installation

1. Attach the ground wire using the star washer and the #6-32 nut.
Use a wrench to tighten the nut securely.

2. Slide the power entry card into the back of the chassis along the
metal guide rails provided.

3. Secure the rear card using the #4-40 metal screws provided.

1. Strip back the insulation on each of the wires .25”.

(continued)
