Patching Panda HATZ User Manual

HATZ

CH OHEXT IN

TRIG

TRIG

ACC

FREQ

FREQ HOLD

DECAY

DECAY

FREQFREQ

EXT LVL

ACC LVL METALS

HATZ

USER MANUAL

INTRODUCTION:

Hatz is a 2-channel analog hit-hat creation module combining 2 kinds of
sound source – white noise and metallic.

The module is designed to give you a closed hat on one channel and
open on the other. Each channel has a 2-pole Voltage-Controlled
State Variable BP Filter with individual and variable control over decay
curve from linear to exponential.

Hatz features an accent input and choke functionality with CV controlled
decay over the open hatz.

The external input allows you design your own percussion sounds
depending on what you feed in, while the Hold input manually opens the
envelope via gates or CV.

SNR = 80dB

INSTALLATION:

* Disconnect your synth from the power source.
* Double check polarity from the ribbon cable, unfortanetly if you damage
the module by powering in the wrong direction it will not be covered by
the warranty.
* After connecting the module check again you have connected the right
way, the red line should be on the -12V.
