PASSTECH HP100 User Manual
RFID LOCKER LOCK
USER GUIDE
(model : HP100)
Version 1.2 - 1 - 2010-10-06
Table of Contents
1. Understanding HP-100 RFID lock
2. Type of Lock Operation
3. Basic operation of the Lock
ANNEX A Beep & LED Table
ANNEX B Trouble Shooting
................................................................................. 3
1.1 What is HP100 RFID Locks? .......................................................................... 3
1.2 Card Ty pe and Functions ................................................................................. 3
................................................................................................. 4
2.1 Free Selection (Day Use) ................................................................................... 4
............................................................................................. 5
3.1 OWNER CARD .............................................................................................. 5
3.2 MASTER CARD ............................................................................................ 5
3.2.1 Functions of the Master Card ................................................................... 5
3.2.2 Replacing old Master cards with New Master cards ............................. 6
3.2.3 How do I add new Master card? ............................................................ 6
3.2.4 What can I do with Master card? ........................................................... 7
3.2.5 Can I set the Master cards to open all locks or specific group of locks
only? .................................................................................................................. 7
3.3 User Card......................................................................................................... 7
3.3.1 Free Selection ........................................................................................ 7
3.3.2 Replacing old User card with New User card .......................................... 8
3.4 Low Battery warning and battery change ....................................................... 8
3.5 Audit Trail ....................................................................................................... 9
.......................................................................................... 10
............................................................................................. 11
Version 1.2 - 2 - 2010-10-06
1. Understanding HP-100 RFID lock
1.1 What is HP1 00 RFID Locks?
- ZP100 RFID lock is a locker lock operated by 13,56 Mhz RF keys such as card,
tag, key ring or wr i stband.
1.2 Card Type and Functions
Key Card : Load Key to the lock.
Owner Card : Delete Master card registration in the lock for new
Master card registration.
Master Card :Each of the following function can be set
① Alarm Off, User card delete and Locker open.
② Alarm Off and Locker open and close (no user card
delete)
Time/Master card : ① Set t he Time of the lock.
Change ② New master card registration
User Card : Two types of User Cards can be set by Locker
Management System.
① User card for Fixed Mode
② User Card for Free Selection
Audit Trail Card : Collect the latest 18 access log data from the Locks.
Version 1.2 - 3 - 2010-10-06
2. Type of Lock Operation
HP-100 RFID lock are designed to work for the various operation requirements by
simple set up process. Following operation modes can be programmed before or after
lock installation.
2.1 Free Selection (Day Use)
- User can select any empty locker.
- Red LED lamp is blinked to show the locker is in
use (Option. In-use lamp off is recommended
to save battery).
- Programmable to use multiple locks with
one User card (max. 5 lockers)
- Programmable for Time based operation
Version 1.2 - 4 - 2010-10-06
