PASCO PS-2134 User Manual

Type K Temperature Sensor
PS-2134
Type K sensor box
Sensor Specifications
Sensor/Probe tip range:
Probe insulation range:
Accuracy:
Resolution:
Default sample rate:
Maximum sample rate:
Sensing element:
Type K probe
-200ºC to +1000ºC
-73ºC to +482ºC
±3ºC or 3% of reading, which- ever is greater
0.1ºC
2 samples per second
10 samples per second
chromel and alumel thermocouple
CARD 1A
Type K Sensor Quick Start
The PS-2134 Type K Temperature Sensor measures high temperatures of gases, open flames, or objects ranging from -200 to +1000 degrees Celsius.
Additional Equipment Needed
PASPORTTM interface (USB Link, PowerLink, Xplorer, etc.)
EZscreen or DataStudio
Equipment Setup
1. Connect the PASPORT interface to a USB port on your computer or to a USB hub.
2. Plug the cable of the Type K probe into the Type K sensor box.
3. Connect the Type K Sensor to the PASPORT interface.
4. The software launches when it detects a PASPORT sensor. From the PASPORTAL window, select a point of entry.
®
software (version 1.8.5 or later)
1
3
2
4
®
800-772-8700 • 916-786-3800 • techsupp@pasco.com • www.pasco .com
Type K Temperature Sensor
PS-2134
Type K sensor box
Sensor Specifications
Sensor/Probe tip range:
Probe insulation range:
Accuracy:
Resolution:
Default sample rate:
Maximum sample rate:
Sensing element:
Type K probe
-200ºC to +1000ºC
-73ºC to +482ºC
±3ºC or 3% of reading, which- ever is greater
0.1ºC
2 samples per second
10 samples per second
chromel and alumel thermocouple
012-08453B
CARD 1A
Type K Sensor Quick Start
The PS-2134 Type K Temperature Sensor measures high temperatures of gases, open flames, or objects ranging from -200 to +1000 degrees Celsius.
Additional Equipment Needed
TM
PASPORT
EZscreen or DataStudio
Equipment Setup
1. Connect the PASPORT
2. Plug the cable of the Type K probe into the Type K sensor box.
3. Connect the Type K Sensor to the PASPORT interface.
4. The software launches when it detects a PASPORT sensor. From the PASPORTAL window, select a point of entry.
interface (USB Link, PowerLink, Xplorer, etc.)
®
software (version 1.8.5 or later)
TM
interface to a USB port on your computer or to a USB hub.
1
3
2
4
®
800-772-8700 • 916-786-3800 • techsupp@pasco.com • www.pasco.com
012-08453B
Calibrating the Type K Temp. Sensor
CARD 2A
Note: Calibration of the Type K Temp. Sensor is not required. However, if you wish
to calibrate for better accuracy, follow the instructions below.
CAUTION:
designed for use in chemical solutions, other than water. probe with an optional Teflon® sleeve*, you can use the probe in chemicals. never place the Type K sensor box in liquids, a heating element, or fire. Placing the sensor box in liquids or an open flame will permanently damage the sensor. PASCO will not replace or cover the costs of a damaged sensor due to negligent or improper use.
The probe of the PS-2134 Type K Temperature Sensor was not
(
However, if you cover the
*)
Also,
DataStudio Calibration
Equipment required: Type K Temperature Sensor, boiling wat er , cold water, thermometer, two beakers or plastic containers
Procedure (two-point calibration)
1. Plug the Type K sensor box into a PASPORT USB interface connected to your computer. Plug the Type K probe into the sensor box.
2. In DataStudio, click on the Setup button to open the PASPORT Setup window.
3. In the P ASPORT box and click the Calibrate button. (Note: The software is set to use 0°C and 100°C as the two points for calibration. You may choose to enter different values and use a thermometer as a reference.)
4. Place the Type K probe in the beaker filled with 0°C water (or water at your first temperature point).
5. In the Calibration window, click the Set button.
6. Repeat steps 4-5 for a beaker filled with 100°C water (or water at your second temperature point).
7. Click the OK button to save the calibration values.
TM
Setup window, scroll to the Type K Temperature Sensor
PASPORT Xplorer Calibration
Equipment required: Type K Temperature Sensor, boiling w ater , cold water, thermometer , tw o beak ers or plastic containers
Procedure:
1. Plug in the Type K Sensor (with probe attached) into an Xplorer.
2. Turn on the Xplorer.
3. Press Display ( ) until the calibrate screen appears.
4. Press the Check ( ) button.
5. Press the Tab ( ) button to move through the digits.
6. Use the Plus (+) or Minus (-) buttons to increase or decrease each digit until the display matches the value of the selected standard sample.
7. Place the Type K probe in the beaker filled with 0°C water (or water at your first temperature point). (Note: The software is set to use 0°C and 100°C as the two points for calibration. You may choose to enter different values and use a thermometer as a reference.)
8. Press the Check ( ) button.
9. Repeat steps 7-8 for the beaker filled with 100°C water (or other water temperature for your second point).
*
Teflon sensor covers are available from PASCO. If you plan to
frequently use the Type K Temperature S ensor with che micals, y ou can order a package of 10 Telfon covers using part no. CI-6549.
Teflon® is a registered trademark of DuPont.
012-08453B
Calibrating the Type K Temp. Sensor
Note: Calibrat ion of the Type K Temp. Sensor is not required. However, if you wish to calibrate for better accuracy, follow the instructions below.
CAUTION:
designed for use in chemical solutions, other than water. probe with an optional Teflon® sleeve*, you can use the probe in chemicals. never place the Type K sensor box in liquids, a heating element, or fire. Placing the sensor box in liquids or an open flame will permanently damage the sensor. PASCO will not replace or cover the costs of a damaged sensor due to negligent or improper use.
DataStudio Calibration
Equipment required: T y pe K Temperature Sensor , boili ng w ater, cold water, thermometer, two beakers or plastic containers
Procedure (two-point calibration)
1. Plug the Type K sensor box into a PASPORT USB interface connected to your computer. Plug the Type K probe into the sensor box.
2. In DataStudio, click on the Setup button to open the PASPORT Setup window.
3. In the P ASPOR T box and click the Calibrate button. (Note: The software is set to use 0°C and 100°C as the two points for calibration. You may choose to enter different values and use a thermometer as a reference.)
4. Place the Type K probe in the beaker filled with 0°C water (or water at your first temperature point).
5. In the Calibration window, click the Set button.
6. Repeat steps 4-5 for a beaker filled with 100°C water (or water at your second temperature point).
7. Click the OK button to save the calibration values.
The probe of the PS-2134 Type K Temperature Sensor was not
TM
Setup window, scroll to the Type K Temperature Sensor
(
However, if you cover the
*)
Also,
CARD 2A
PASPORT Xplorer Calibration
Equipment required: T ype K Temperature Sensor, boi ling water , cold water, thermometer , two beakers or plastic containers
Procedure:
1. Plug in the T y pe K Sensor (with probe attached) into an Xplorer.
2. Turn on the Xplorer.
3. Press Display ( ) until the calibrate screen appears.
4. Press the Check ( ) button.
5. Press the Tab ( ) button to move through the digits.
6. Use the Plus (+) or Minus (-) buttons to increase or decrease each digit until the display matches the value of the selected standard sample.
7. Place the Type K probe in the beaker filled with 0°C water (or water at your first temperature point). (Note: The software is set to use 0°C and 100°C as the two points for calibration. You may choose to enter different values and use a thermometer as a reference.)
8. Press the Check ( ) button.
9. Repeat steps 7-8 for the beaker filled with 100°C water (or other water temperature for your second point).
*
Teflon sensor covers are available from PASCO. If you plan to frequently use the Type K Temperature Sensor with chemicals, you can order a package of 10 Telfon covers using part no. CI-6549.
Teflon® is a registered trademark of DuPont.
012-08453B
CARD 1B
Comparing Temperatures in Diff erent Parts of a Candle Flame
DataStudio/DataStudio Lite Task: Procedure:
Change units of measurement:
Scale to fit the data:
Scale the axes:
View data statistics:
In the PASPORT Sensor window, scroll to
the Type K sensor. Use the down arrow to
select degrees C, F, or K.
Click the Scale-to-Fit ( ) button.
With your mouse, click on the x-axis and
drag left or right; click on the y-axis and
drag up and down.
Click the Statistics ( ) button and
select Minimum, Maximum, or Mean.
Type K Activity - Mapping the Temperature of a Candle Flame
Equipment required: PS-2134 Type K Sensor, PASPORT interface, USB­compatible computer, DataStudio software (version 1.8.5 or later), candle with glass holder, matches.
SAFETY WARNING: When working with candles or other hot objects,
always follow standard fire and health safety precautions in your classroom. Do not touch the Type K probe with your hands, f ingers, or an y other body part. When the probe is put in a hot flame and remov ed, the probe will be hot (between 400 to 1400 degrees Celsius). Touching or mishandling the probe could cause severe burns or permanent bodily injury .
Procedure:
1. Connect the Type K T emperature Sensor to a PASPORT interface connected to your computer (See CARD 1A for instructions).
2. Light a candle and place it in a glass holder.
3. Open a Graph display in DataStudio and click the Start button.
4. (Before performing the next fe w steps, please read the safety warning above.) Slowly insert just the tip of the Type K probe into the red, inner core of the candle flame to take a reading.
5. After about 30 seconds, click the Stop button. Slowly remove the probe , being careful not to touch the probe with your hand or to an y ot her body parts.
6. Allow the probe to cool to room temperature on a metal surface.
7. Repeat steps 5 and 6 for the orange, yellow, and blue colors in the flame. (Note: Move the probe directly across, not up and down the flame.) Compare your results. Explain why different colors of the flame have diff erent temperatures. Is the temper ature higher in the inner core or the outer part of the flame? Why?
Typ e K probe
Figure 1
Comparing T emperatur es in Different P arts of a Candle Flame
DataStudio/DataStudio Lite Task: Procedure:
Change units of measurement:
Scale to fit the data:
Scale the axes:
View data statistics:
In the PASPORT Sensor window, scroll to
the Type K sensor. Use the down arrow to
select degrees C, F, or K.
Click the Scale-to-Fit ( ) button.
With your mouse, click on the x-axis and
drag left or right; click on the y-axis and
drag up or down.
Click the Statistics ( ) button and select
Minimum, Maximum, or Mean.
CARD 1B
Type K Activity - Mapping the Temperature of a Candle Flame
Equipment required: PS-2134 Type K Sensor, PASPORT interf ace, USB­compatible computer, DataStudio software (v ersion 1. 8.5 or later), candle wit h glass holder, matches.
SAFETY WARNING: When working with candles or other hot objects,
always follow standard fire and health safety precautions in your classroom. Do not touch the Type K probe with your hands , fi ngers, or an y other body part. When the probe is put in a hot flame and remo v ed, t he probe wil l be hot (between 400 to 1400 degrees Celsius). Touching or mishandling the probe could cause severe burns or permanent bodily injury.
Procedure:
1. Connect the Type K T emperat ure Sensor to a PASPORT interface connected to your computer (See CARD 1A for instructions).
2. Light a candle and place it in a glass holder.
3. Open a Graph display in DataStudio and click the Start button.
4. (Before performing the next fe w steps, please read the safety warning above.) Slowly insert just the tip of the Type K probe into the red, inner core of the candle flame to take a reading.
5. After about 30 seconds, click the Stop button. Slowly remove the probe, being careful not to touch the probe with your hand or t o any ot her body parts.
6. Allow the probe to cool to room temperature on a metal surface.
7. Repeat steps 5 and 6 for the orange, yellow, and blue colors in the flame. (Note: Move the probe directly across, not up and down the flame.) Compare your results. Explain why different colors of the flame have diff erent temperatures . I s the t emperature higher in the i nner core or the outer part of the flame? Why?
Typ e K probe
Figure 1
