Chapter 1 Introduction

This section provides a functional description of the PRV-0414.

Functional Description

The PRV-0414 PC/104 Double Height Adapter is a low-cost interconnection board that gives embedded PC/104
computer systems a method for connecting circuit board modules taller than the prescribed PC/104 specification
height. The adapter is especially useful for high-profile PC/104 CPU, power supply and hard drive modules that
incorporate onboard fans or heatsinks for thermal management, as these types of boards co mmonly exceed the
PC/104 form factor height of 0.60” and take up two card slots. Overcoming PC/104 height infringement can also
be especially useful during prototype development when placing a prototype card at the end of a card stack
becomes impractical.

Measuring only 3.550" x 0.550" in size, the PC/104 Double Height Adapter provides clearance for tall board
components in a card stack, while offering a 16-bit pass-through header for all standard PC/1 04 bus signals and
a 10-pin power connector for power/grounding through the PC/104 bus. The adapter also has standard PC/104
board mounting holes and can be placed on top or bottom of any PC/104 module with its 104-pin and socket
connector.

Included with the adapter is also a set of nylon stand-off spacers for board mounting and a second, smaller
(3.550" x 0.40") circuit board used to maintain proper spacing on the other side of the PC/104 slot. Stand-offs
can be inserted into mounting holes for the adapter and adjacent PC/104 modules, or alternatively, the PC/104
card stack can be securely mounted in a PC/104 railed card cage without any standoffs required.

Features

 16-Bit PC/104 (ISA) bus
 Set of 8 Plastic Board Stand-offs (with Nuts and Screws)
 Standard PC/104 Mounting Holes
 10-Pin Power Header (Dual Row 0.100 inch)

About PC/104

The PC/104 specification is characterized by its small form-factor (3.550" x 3.775"), stackable 104-pin/socket
ISA bus connector, and reduced bus signal drive, making PC/104's size, durability, expandability, reliability,
quality, and power consumption ideal for embedded computing. PC/104 technology leverages the same readily
available development tools used with personal desktop computers to dramatically improve time-to-market for
embedded systems development. The full PC/104 specification can be found at the PC/104 Consortium Web
site: http://www.pc104.org/technology/pc104_tech.html

Page 4 of 14

MNL-0337-01 RevH3 REF. ECO-3163 Effective: 01 Feb 10

PRV-0414 User Manual

Chapter 2 Quick Start-up

This section describes the installation of the PRV-0414. It then describes power-up of the assembly.

Installation

Installing the PC/104 Double Height Adapter

Remove the PC/104 Double Height Adapter from the anti-static bag. There are two pieces; One piece (PART 1),
contains the stack-through connector(s) for the PC/104 bus. The other piece (PART 2) acts as a spa cer for the
other side of the stack to maintain PC/104 card spacing requirements. Install the section contai ning the PC/104
connector(s) onto the top or bottom side of the board requiring extra height, and install two spacers, if they are to
be used, to secure the adapter. Place PART 2 onto the remaining spacers, and install two spacers to secure
PART 2 to the stack. Assemble the next card on top of the stack adapter using standard mounting hardware.
