Parrot PF724102, PF724100, PF724101 User manual

Jumping Night Drone

BUZZ DIESEL

MARSHALL

User Guide

Table Of Contents

Before getting started

Control

.......................................................................................................................................................4

...........................................................................................................................................................................................................4Charging the battery

.......................................................................................................................................................6

Settings

Roadmap

.......................................................................................................................................................13

.......................................................................................................................................................16

Academy Drone

Updates

General information

.......................................................................................................................................................19

.......................................................................................................................................................21

.......................................................................................................................................................22

Before getting started

Charging the battery

1. Insert the battery into the compartment provided (photos A and B). The small triangle on the battery indicates which side should be on top. The direction the triangle is pointing in shows which way the battery should be inserted.

2. Plug in the MiniDrone (photos C and D):

When using a charger with a minimum power rating of 2.4A, charging time is approximately 25 minutes.

When charging through a computer using the USB cable, charging time is approximately 1 hour and 30 minutes.

> The LED next to the On/Off button lights up red to indicate the MiniDrone is charging. Once fully charged, the LED will turn green.

To remove the battery:

1. Gently lift up the plastic component surrounding the battery.

Before getting started

2. Pull the battery out using the hooks on its back.

In order to keep the battery for the MiniDrone in optimum condition, never leave it half-inserted in its compartment.

Downloading the application

Connect to the App StoreSM or Google PlayTM and download the free FreeFlight3 application.

Turning the Jumping Night Drone on/off

Insert the battery into the slot or press the On/Off button to turn the MiniDrone on. The On/Off button can be found on the head of the MiniDrone, next to the LED. Press the On/Off button to turn the MiniDrone off. The light-up eyes will switch off.

Connecting a smartphone to the MiniDrone

1. Search for available Wi-Fi® networks on your smartphone:

If you're using an iPhone or iPad, go to Settings > Wi-Fi.

If you're using an AndroidTM smartphone, go to

Networks > Wi-Fi

2. Select the MiniDrone network.

3. Wait for your smartphone to establish a connection to the MiniDrone Wi-Fi network. The Wi-Fi symbol will usually appear on your smartphone when connection is complete.

4. Launch the FreeFlight3 app.

> The MiniDrone will connect to your smartphone automatically. A pop-up window saying "Sending status" and then "Connected" will appear. The MiniDrone will turn back on itself and emit a series of beeps.

If your phone doesn't automatically connect to the MiniDrone, press and then select the name of your MiniDrone from the list. Refer to the Settings > Wi-Fi section for more information.

Settings > Wireless and

Before getting started

Control

1. Launch the FreeFlight3 app. > The main screen will appear.

2. Press MiniDrone in through your MiniDronesection.

Press < at any time to return to the main menu.

Free Drive

> The control screen will appear.

to drive your MiniDrone. Press

Walkie-Talkie

mode. For more information, go to the Talking

Voice Transmission

to drive the

Control

Description of the control screen

No.

Description

No.

Description

Return to previous screen

Long jump

Settings

Right joystick

Stop current action

MiniDrone position

Walkie-Talkie (

Voice Transmission

mode

only)

Pre-programmed acrobatics

Video recording

Wi-Fi signal


Light effects

Left joystick

Headset connected or disconnected

High jump

Battery level

Control

Wheel position

Before starting, choose the control mode for your MiniDrone:

By bringing the wheels closer together, you are opting for responsive controls and a smoother driving experience.

Moving the wheels further apart provides greater stability.

MiniDrone positions

Press the button to switch between the Jumper and Kicker positions. Hold the

button down for 2 seconds to switch to Auto-Balance position.

Press once to return to normal mode. The Jumper position lets you perform high and long jumps.

To switch to Kicker mode, press The Kicker position is used to push objects out of your way while driving. The Auto- Balance position allows you to overcome certain obstacles more easily. To prevent excessive wear to the rubber pad, the Auto-Balance position should be used when you are driving over rough surfaces.

once.

Driving

Use the left joystick to move the MiniDrone forwards or backwards. Hold down the left joystick and tilt your smartphone left or right to move the MiniDrone to the left or right.

On the screen, drag your finger from the middle of the joystick to the or to make a quarter turn to the left or right.

Drag your finger from the middle of the

Jumping

Control

joystick to the to make a half turn to the right. Drag your finger from the middle to the top to perform the selected pre- programmed trick. For more information, go to the Pre-programmed acrobatics section.

Set your MiniDrone to the Jumper position to perform jumps, then:

Press to perform a high jump.
