T6T Transmitter User Guide

Issue 1

Handbook Title: T6T Transmitter User Guide

Handbook Part Number: 31-360000TX

Issue Number: 1

Date of Issue: November 1999

Published By: Park Air Electronics

Northfields Market Deeping Peterborough England PE6 8UE

Telephone: From UK, 01778 345434

From outside UK, 44 1778 345434

Fax: From UK, 01778 342877

From outside UK, 44 1778 342877

Page ii

Handbook Amendment Record

Amendments to this handbook, originated by Park Air Electronics, are listed in the following table.

Amendment

Number

Date Brief Details

PAE Change

Note Number

Equipment Modification Record

Modifications to the T6T transmitter are detailed in the following table.

The equipment’s modification label shows modifications embodied in the equipment.

Modification

Number

Date Brief Details

PAE Change

Note Number

Page iii

List of Abbreviations

The following abbreviations are used in this user guide:

Page iv

A amp

AM amplitude modulation

BIT built-in test

dB decibel

DSP digital signal processing

ETI elapsed time indicator

ICAO international civil aviation organisation

kg kilogram

kHz kilo Hertz

LCD liquid crystal display

mA milliamp

MARC multi-access remote control system

MHz mega Hertz

mm millimetre

ppm parts per million

PSK phase shift keying

rms root mean square

RSSI receiver signal strength indication

V volt

VFP virtual front panel

VHF very high frequency

T6T Transmitter User Guide

Section 1

General Information

Section 1 T6T Transmitter User Guide Page 2

Section 1 Contents

Chapter 1. Overview

Introduction to the T6T Transmitter 3 T6T Handbooks 3 Operational Settings 4

Virtual Front Panel 5 Built-In Tests 5 Transmitter Variants 6 Configuring the T6T Transmitter 6

Chapter 2. Specification

Dimensions and Weight 9 RF Characteristics 9 Environmental 10 Power Requirements 10

Chapter 3. Controls, Indicators, and Connectors

Front Panel 11

Transmit Indicator 11

Alarm Indicator 11

Ready Indicator 11

Standby Indicator 12

Reference Connector 12

Microphone/Diagnostics Connector 12

Scroll/Select Switch and LCD 13 Rear Panel 14

Power Switch 14

AC Input Connector 14

DC Input Connector 15

Fuse F1 15

Chassis Stud Connection 15

Facilities Connector CN5 15

MARC Port CN6 16

Computer Port CN7 16

Antenna Connector 16

Chapter 4. Installation Procedures

Introduction 21 Initial Inspection of the Transmitter 22 Fitting the Correct AC Input Fuse 22 Selecting the Correct AC Input Tap 23 Selecting the Keying Method 24 Fitting a Radio into an Equipment Rack 25 Connecting Remote Facilities 25 Chassis Stud Connection 26 AC Supply Connection 26 DC Supply Connection 27 Connecting an Antenna 27 Switching On 27

Page

Chapter 1. Overview

This chapter provides an introduction to the T6T transmitter, briefly describes the features, and

shows how the radio is configured for operational use.

INTRODUCTION TO THE T6T TRANSMITTER

Park Air Electronics (PAE) T6T is a VHF multi-mode air-traffic control transmitter compatible with analogue (AM) and digital (D8PSK) modulation modes. Current models are supplied programmed for AM voice operation in the frequency range 118 to 136.975 MHz using 25 kHz or 8.33 kHz channel spacing. Future software upgrades will allow D8PSK operation.

The transmitter produces a 50 watt carrier output that can be reduced, in 1 watt steps, to 5 watts. The output power, and the majority of operational settings, can be selected at the front panel, using the virtual front panel (VFP) or through a compatible control and data system such as the PAE multi-access remote control (MARC) system.

A multi-channel feature allows up to 100 frequency channels to be stored and recalled by channel number.

The transmitter is designed to be fitted in an industrial 19 inch (483 mm) equipment rack. Operation is from either a standard ac mains supply, or from a low voltage dc supply. When both input supplies are connected, the dc supply acts as a back-up if the mains supply fails.

Comprehensive continuous and interruptive Built-In Tests (BIT) provide confidence of the transmitter's serviceability.

T6T HANDBOOKS

This user guide describes the T6T transmitter and gives complete installation and setting up procedures. The user guide is split into sections as follows:

Section 1. Section 1 (this section) provides general information that is common to all

operating modes.

Section 2. Section 2 provides information that is specific to operating the T6T transmitter

in AM-voice mode.

Section 3. Section 3 onwards will, when available, describe the digital operating modes.

A maintenance kit (PAE part number 70-6350MKIT) is also available. A maintenance handbook, included in the kit, contains fault finding guides to module level and details VFP operation. The VFP can be used for setting up, maintenance purposes, and for loading new software.

The maintenance kit includes a CD-ROM containing the VFP software and a lead for connecting the radio to a Personal Computer (PC). The CD-ROM also contains the software as loaded into the T6T at the time of sale. This enables the original software to be re-loaded if the transmitter's Digital Signal Processing (DSP) module is ever replaced.

Both the user guide and maintenance handbook are available on CD ROM. Contact PAE for details.

T6T General Information Section 1

Page 3

T6T transmitter maintenance should not be attempted without reference

to the maintenance handbook

OPERATIONAL SETTINGS

Operational settings for the T6T transmitter are configured at the front panel, through the VFP, or through an associated MARC system (or compatible control and data system). At the transmitter, operational settings are selected and displayed using the front panel Scroll/Select switch and the LCD.

The settings are selected through a series of menus. Full details are given in the section of this user guide applicable to the operating mode. Two example selection menus, Set Frequency menu and Channel Storage menu, are shown below.

121 .500MHz

C ance l OK

Ch1 00 121 . 500MHz

Cance l

Stor e

Store and End

During normal transmitter operation, the Main screen, shown below, is displayed. The screen shows the operating frequency, the channel number (if the channel store facility is used), the carrier offset (if used in AM-voice mode), and displays a graphical representation of instantaneous peak power.

Fr eq 123 . 000MHz

Chan 1

Of fset +5.0kHz

Pwr IIIIIIIIIIII

Section 1 T6T Transmitter User Guide Page 4

Freq 123.000MHz Chan 1 Offset +5.0kHz Pwr lllllllllll

Example Main Screen

Example Set Frequency Menu

Example Channel Storage Menu

Virtual Front Panel

As an alternative to setting up the transmitter from the front panel, the T6T's virtual front panel (VFP) software can be used. To use the VFP, an IBM™ compatible PC must be connected to the transmitter (see Fig. 1-1). Using the VFP offers several advantages over setting up from a transmitter's front panel. These are:

When set up using the VFP, a profile of the transmitter's operational settings can be created. The profile can then be used to automatically set up other radios within a system, or to reset a radio should its DSP module ever be replaced.

When using the VFP, the transmitter's front panel can be locked. This means that a transmitter's settings cannot inadvertently be changed by tampering with the front panel controls.

A print-out of a transmitter's profile (all the operational settings) can be made from the VFP.

Instructions on VFP usage is outside the scope of this user guide. Reference, therefore, should be made to the T6T maintenance handbook that is supplied with a CD-ROM containing the VFP software.

BUILT-IN TESTS

The transmitter continuously self monitors key internal parameters without affecting normal operation. If a BIT fault is detected, the front panel Alarm indicator lights, the Ready indicator becomes unlit, and the transmitter becomes inoperable.

Additionally, a BIT warning, as opposed to a BIT fault may be indicated. A BIT warning is shown by the front panel Alarm indicator flashing; the Ready indicator remains lit and the transmitter remains operational, but at reduced power.

Apart from continuous monitoring, an interruptive BIT test can be initiated locally at the front panel, or remotely. When initiated, test signals are injected that key the transmitter allowing parameters to be monitored in their active state.

The results of continuous monitoring, and of interruptive testing, are available at the front panel LCD. When the transmitter is used with a MARC system (or other compatible data and control system) the results are also sent, in the form of a data message, to the monitoring facility. A full description of the BIT facilities is given in the section applicable to the required operating mode. The following two illustrations show example front panel BIT displays.

T6T General Information Section 1

Page 5

VSWR PASS

PA Temp 8 0°C

Syn t h Lock Pass

<< >>

RF D r i v e PASS

Fwd Powe r 2 5W

Rf l Power 2W

<< >>

TRANSMITTER VARIANTS

Two variants of the T6T transmitter are available:

B6350. This model operates in all modes except in AM-voice when using a 5-carrier offset. The frequency stability of this model is 1 ppm.

B6350OPT1. This model operates in all modes including AM-voice when using a 5-carrier offset. The frequency stability of this model is 0.25 ppm.

CONFIGURING THE T6T TRANSMITTER

Fig. 1-1 shows the signal connectors fitted to the transmitter's front and rear panels. The connectors used to configure the transmitter depend on the required operating mode. The purpose of each connector is briefly described in the following paragraphs and fully detailed in chapter 3 starting on page 11.

Antenna Connector

Used in all operating modes to connect the 50 ohm antenna feeder cable.

Microphone/Diagnostics Connector

This is a dual purpose connector. A microphone/headset (complete with integral PTT switch) can be connected to enable local AM-voice operation.

Alternatively, a PC can be connected to allow use of the VFP. The VFP can be used to set the transmitter's operational settings, or to download new software.

Reference Connector

Used in all operating modes to check and reset the transmitter's reference frequency.

Facilities Connector Used primarily to connect remote signals when using AM-voice mode

when the transmitter does not form part of a MARC system.

Some auxiliary signals available at this connector, for example the 24 volt (nominal) unregulated output supply, can be utilized irrespective of the operating mode.

MARC Port The MARC port is used to connect remote signals when the transmitter

forms part of a MARC system, or other compatible control and data system.

Computer Port

The computer port is used in digital communication modes to connect the transmitter to a control computer.

Section 1 T6T Transmitter User Guide Page 6

T6T General Information Section 1

Page 7

Fig. 1-1. T6T Transmitter Configuration

T6T Transmitter

Antenna

Connector

Microphone/Diagnostics

Connector

Microphone/headset for local AM operation.

PC to allow use of the VFP and to download new software.

Reference Connector

Frequency counter for

maintenance purposes.

Facilities Connector

Remote Signals.

Computer Port

Signals to/from a control

computer. Used when

operating in digital

communication modes.

MARC Port

Signals to/from an

RSE 2 equipment. Used

when the radio forms

part of a MARC system.

Intentionally Blank

Section 1 T6T Transmitter User Guide Page 8

Chapter 2. Specification

This chapter contains the T6T transmitter's specification that is common to all operating modes.

Specifications relevant to specific operating modes are contained in the section applicable to the

required operating mode.

DIMENSIONS AND WEIGHT

The dimensions and weight of the T6T transmitter are:

Width 483 mm (19 inches).

Height 88.9 mm (3.5 inches). The height occupies 2U of

equipment cabinet space.

Depth (front panel to rear panel) 430 mm (16.9 inches).

Depth (front panel to rear of fan) 450 mm (17.7 inches).

Weight 15.6 kg (34.4 pounds)

RF CHARACTERISTICS

Frequency range 118 to 136.975 MHz.

Output carrier power The output power is adjustable between 5 and 50 watts.

Number of channels The transmitter has a multi-channel capability.

100 channels can be stored and recalled.

Frequency accuracy Better than 1 ppm for transmitter B6350.

Better than 0.25 ppm for transmitter B6350OPT1.

Protection Excessive VSWR. The transmitter will transmit at full

power into a VSWR of up to 2.5 :1. At a higher VSWR

the output power will be reduced by 10 dB ± 1 dB, if

necessary, in order to protect the transmitter.

Provision is made via the facilities port to allow an external VSWR signal to be monitored. This is required when isolators are employed which shield the transmitter from a VSWR fault at the antenna.

PA Overheating. If the RF PA temperature exceeds 80

C, the output power is reduced by 6 dB ± 1 dB and a

BIT warning indicated.

If the RF PA temperature exceeds 90°C the transmitter de-keys and a BIT alarm is indicated.

T6T General Information Section 1

Page 9

Control Loop Error. If the cartesian control loop goes out of limits, for example, due to low supply volts, the output power gradually reduces by up to 3 dB until the loop regains stability. If this fails to stabilise the loop the transmitter de-keys and a BIT alarm is indicated.

Harmonic outputs Harmonic outputs are below -36 dBm.

ENVIRONMENTAL

Temperature range The transmitter operates to specification at temperatures

between -20 and +55°C and at a relative humidity

between 5% and 90% (non-condensing).

Duty cycle 100%.

Warm up time The transmitter is fully operational 5 seconds after

switch on.

Storage The transmitter can be stored at temperatures between

-30 and +70°C without causing damage.

Cooling The transmitter has an integral cooling fan.

POWER REQUIREMENTS

The transmitter operates from an ac input supply, or a dc input supply. When both supplies are connected, the dc input acts as an automatic backup supply for the ac mains.

ac input supply The transmitter operates from a 48 to 62 Hz

single-phase ac supply.

The input voltage, measured at the equipment, can be

110/120/220/230/240 V ac (± 10%). The correct ac input tap must be selected to suit the input voltage. Additionally, the correct ac input fuse F2 must be fitted. See installation detail on page 23.

ac power consumption Typically 330 VA. 500 VA maximum.

dc input supply Between 21.6 and 32 V. Full output power capability is

maintained with a dc input between 24 and 32 V. From 24 down to 21.6 V the output power gradually decreases.

dc supply current 15 amp (maximum) with a 28 volt dc input supply.

Section 1 T6T Transmitter User Guide Page 10

Chapter 3. Controls, Indicators, and Connectors

This chapter details the purpose of all controls, indicators, and connectors

fitted to the transmitter's front and rear panels.

FRONT PANEL

The front panel's controls, indicators, and connectors are shown below and described in the following paragraphs.

Transmit Indicator

An amber indicator that lights when the transmitter is keyed and producing output power.

Alarm Indicator

A red indicator that either flashes, or lights, when a BIT fault has been detected. BIT indications are classified as either warnings or faults.

If a warning is detected, the Alarm indicator flashes, the Ready indicator remains lit, and the transmitter remains operational. A BIT warning is indicated if:

a high PA temperature is sensed

a high VSWR is sensed.

If a fault is detected, the Alarm indicator lights and the Ready indicator becomes unlit; the transmitter cannot be used.

Ready Indicator

A green indicator that lights when the transmitter is ready for use and no BIT faults have been detected.

T6T General Information Section 1

Page 11

Freq 123.000MHz Chan 1 Offset +5.0kHz Pwr lllllllllll

Standby Indicator

A red indicator that lights when the transmitter is in standby mode. When in standby mode, most of the transmitter's circuits are inactive, the front panel LCD is blanked, and the transmitter cannot be keyed.

Standby mode is selected and deselected using the front panel Scroll/Select switch and LCD, by initiating an instruction through a MARC system, or through the VFP. Details of front panel selection and deselection are given in the section of this user guide applicable to the particular operating mode.

Reference Connector

An SMB jack socket that allows a high impedance frequency counter to monitor the transmitter's reference frequency. This connector is used only for maintenance purposes. The instructions for checking and adjusting the reference frequency are given in the T6T maintenance handbook.

Microphone/Diagnostics Connector

A dual purpose connector that allows either a dynamic microphone (and headset if sidetone is required) or a PC to be connected to the transmitter. The connector is a 7-pin self locking DIN socket.

A microphone/headset with integral PTT switch can be fitted to this connector to enable the transmitter to be operated in local mode. The connections are detailed in table 1-1. A PC can also be connected to allow the VFP to be displayed. Using the VFP is detailed in the T6T maintenance handbook. The connections at the transmitter are shown in table 1-2.

Table 1-1. Microphone/Headset Connections

Headset/Diagnostics

Connector Pin Number

Signal Notes

1 Microphone ground 0 volt.

3 Microphone PTT 0 volt = PTT. 5 V pull-up = not PTT.

5 Sidetone to headset

200 ohm output impedance. Maximum = 3 volt peak-to-peak.

6 Microphone input 6.8 kohm, 5 mV sensitivity.

Section 1 T6T Transmitter User Guide Page 12

Fig. 1-2.

Microphone/Diagnostics

Connector Pin-Out

(DEV083-05)

Table 1-2. Diagnostics PC Connections

Headset/Diagnostics

Connector Pin Number

Signal Notes

2 Transmit data RS232

4 Receive data RS232

7 Ground 0 volt

Scroll/Select Switch and LCD

The Scroll/Select switch is used in conjunction with the LCD to select most of the transmitter's operational settings. Use of the switch and LCD is fully detailed in the section of this user guide applicable to the particular operating mode. During normal operation, the LCD shows the operating frequency, the channel number (if the channel store facility is used), the carrier offset (if used), and displays a graphical representation of instantaneous peak power.

The example LCD screen below shows the transmitter operating on 123.000 MHz; the frequency has been preset as channel 8; and no offset is used.

Fr eq 123 . 000MHz

Chan 8

Pwr IIIIIIIIIIII

T6T General Information Section 1

Page 13

REAR PANEL

The rear panel's controls, indicators, and connectors are shown in Fig. 1-3 and described in the following paragraphs.

Power Switch

A 2-way rocker switch used to switch on, and switch off, power to the transmitter's circuitry.

l =On

WARNING!

When the POWER SWITCH is set to the Off position, lethal voltages are still present in the transmitter's internal power supply circuitry. To ensure safe working, the ac and dc input supplies must be disconnected from the transmitter.

AC Input Connector

A 3-pole IEC chassis plug for connecting the ac input supply. The plug has an integral 20 mm fuse (F2) that protects the Line (L) input circuit. The fuse is rated at 4 amps. Detailed instructions regarding fuse types, and connecting the ac supply are given in the installation chapter on page 26.

Caution!

Before connecting an ac input supply to the transmitter, the ac input taps must be set to suit the local mains supply (see page 22).

Section 1 T6T Transmitter User Guide Page 14

(DEV083-02)

Fig. 1-3. Rear Panel

= Off

Fig. 1-4. AC Mains Connector

(SA3536)

DC Input Connector

A 3-pole chassis plug for connecting the dc input supply. Detailed instructions for connecting the dc supply are given in the installation chapter of this handbook on page 27.

Fuse F1

Fuse F1 protects the dc input positive supply circuit. It is a Size 0 fuse rated at 15 amps. The PAE part number of the fuse is: 29-01350201.

Chassis Stud Connection

The chassis stud is used to provide a common earth point between the transmitter and the associated equipment rack, or the transmitter and the user's system earth. The stud must not be used as a safety earth. Connection details are given on page 26.

Facilities Connector CN5

A 15-way D-type socket used primarily to connect remote signals when the transmitter operates in AM mode and does not form part of a MARC (or similar) system. The pin-out of this connector is given in table 1-3 on page 17.

Apart from allowing connection of remote signals, this connector makes some auxiliary signals available to the user. For example, a 24 volt (nominal) unregulated output supply. The auxiliary signals can be employed by the user as and when required irrespective of the operating mode.

Facilities connector CN5 as seen when looking at the rear panel. Connections should be made using a 15-way D-type plug PAE part number: 20-01150100 (plug), and 20-09150101 (cover). These are supplied with the transmitter as item 3 (see page 22).

T6T General Information Section 1

Page 15

Fig. 1-5. DC Connector

(DEV083-06)

Fig. 1-6. Facilities Connector

CN5 Pin-Out

MARC Port CN6

A 9-way D-type socket used to connect remote signals to a MARC system or other compatible control and data system. The pin-out of this connector is given in table 1-4 on page 18.

Computer Port CN7

A 25-way D-type socket used to connect the transmitter to a control computer when the transmitter is operated in digital communication modes. The pin-out of this connector is given in table 1-5 on page 19.

Antenna Connector

An N-type 50 ohm coaxial socket used to connect the antenna's feeder cable.

Section 1 T6T Transmitter User Guide Page 16

Fig. 1-7 MARC Port CN6 Pin-Out

MARC connector CN6 as seen when looking at the rear panel. Connections should be made using a 9-way D-type plug PAE part number: 20-01090100 (plug), and 20-09090101 (cover).

Fig. 1-8 Computer Port CN7 Pin-Out

Computer port CN7 as seen when looking at the rear panel. Connections should be made using a 25-way D-type plug PAE part number: 20-01250100 (plug), and 20-09250101 (cover).

Table 1-3. Facilities Connector CN5 Pin-Out

Number

Signal Name Description

1 Ground 0 volt.

2 Line In (+) Pins 2 and 3 present a 600 ohm balanced audio input to the

transmitter for use in AM modes. The input level is adjustable between -40 dBm and 0 dBm. Phantom keying can be superimposed on the audio lines. See ‘Selecting the Applicable Keying Method’ in section 2 on page 10.

3 Line In (-)

4 External VSWR

An input signal to the transmitter to indicate a VSWR fault in the antenna circuit. When this signal is active, the transmitter's output power is reduced by 10 dB and a VSWR warning is indicated. This is a TTL input pulled-up to 5 V; the active signal is 0 volt.

Antenna Change-Over

An output signal that can be used to control an antenna change-over relay when the transmitter is used in conjunction with a T6R receiver. Antenna change-over is a grounding output; the active (transmitter keyed) polarity is always the same as the PTT output signal on pin 6. Maximum current sink is 100 mA.

6 PTT Output

This output, when active, indicates the transmitter is keyed. It is a grounding output. The active polarity is set from the front panel. Maximum current sink is 100 mA.

7 Remote PTT

An input signal used to key the transmitter. The active signal can be 0 volt, or a dc level between +10 and +50 volt, or a dc level between

-10 and -50 volt. Internal jumpers JP8 and JP9 must be correctly set to suit the required keying potential (see ‘Remote Keying Configurations’ in section 2 on page 11). The active polarity is set from the front panel.

8 Ground 0 volt.

9 Unregulated Supply

A dc output supply between 21.6 and 32 volt. The supply is fused at 500 mA.

10 Tx Inhibit

This input signal, when active, prevents the radio from being keyed. This is a TTL input pulled-up to 5 V; the active polarity is set from the front panel.

11 BIT Interruptive Test

An input signal that initiates a BIT interruptive test. This is a TTL input pulled-up to 5 V. The active polarity of this signal is set from the front panel. The input signal must be active for a minimum of 300 ms; the signal cannot then be activated again for at least 3 seconds.

12 Not Used

Pin 12 is internally connected. Do not make any connections to this pin.

13 Ready Output

This output is active when the radio is ready to transmit and no faults have been detected by the BIT circuitry. It is an open collector output. The active polarity is set from the front panel.

14 Tape Output

An audio output for connection to a recording system. The output is nominally -10 dBm into 100 ohm.

15 Not Used -

T6T General Information Section 1

Page 17

Table 1-4. MARC Connector CN6 Pin-Out

Number

Signal Name Description

1 Ground 0 volt.

2 Line In (+) Pins 2 and 3 present a 600 ohm balanced audio input to the

3 Line In (-)

4 PTT

An input signal used to key the transmitter. The active signal can be 0 volt, or a dc level between +10 and +50 volt, or a dc level between -10 and -50 volt. Internal jumpers JP8 and JP9 must be correctly set to suit the required keying potential (see ‘Remote Keying Configurations’ in section 2 on page 11). The active polarity is set from the front panel.

5 Unregulated Supply

A dc output supply between 21.6 and 32 volt. The supply, which is fused at 500 mA, is used as the power source for the MARC RSE 2 equipment.

6 Data In (+) RS422 data line.

7 Data In (-) RS422 data line.

8 Data Out (+) RS422 data line.

9 Data Out (-) RS422 data line.

Section 1 T6T Transmitter User Guide Page 18

Table 1-5. Computer Port CN7 Pin-Out

CN7 Pin Number Signal Name Level Input or Output

1 Ground 0 volt -

2 Serial 0 TXA RS422 Output

3 Serial 0 TXB RS422 Output

4 Serial 0 RXA RS422 Input

5 Serial 0 RXB RS422 Input

6 Serial 0 CLA RS422 Output

7 Serial 0 CLB RS422 Output

8 Serial 1 TXA RS422 Output

9 Serial 1 TXB RS422 Output

10 Serial 1 RXA RS422 Input

11 Serial 1 RXB RS422 Input

12 Serial 1 CLA RS422 Output

13 Serial 1 CLB RS422 Output

14 Input A RS 232 Input

15 Input B RS232 Input

16 Input C RS232 Input

17 Input D RS232 Input

18 Output A RS232 Output

19 Output B RS232 Output

20 Output C RS232 Output

21 Output D RS232 Output

22 Ground 0 volt -

23 Not used - -

24 Not used - -

25 Not used - -

T6T General Information Section 1

Page 19

Intentionally Blank

Section 1 T6T Transmitter User Guide Page 20

Chapter 4. Installation Procedures

This chapter details the installation procedures for a T6T transmitter that are necessary irrespective of

which operating mode is to be used.

WARNING. LETHAL VOLTAGES!

The instructions given in this chapter involve connecting lethal voltages to the transmitter. The instructions detailed in this chapter must be carried out only by suitably qualified personnel.

WARNING. ANTENNA RADIATION!

The antenna used with the transmitter must be installed such that the resultant radiated field strength is below 10 W/m² in areas normally accessible to personnel.

WARNING. BERYLLIUM/BERYLLIA!

The equipment covered by this handbook contains components containing the highly toxic material Beryllium and/or its oxide Beryllia. These materials are particularly hazardous if:

1. Beryllium materials are absorbed into body tissues through the skin, mouth, or wound.

2. The dust created by breakage of Beryllia is inhaled.

3. Toxic fumes are inhaled from Beryllia/Beryllium involved in a fire.

The components containing Beryllia/Beryllium are: TR5, TR6 and TR9 in the PA module.

WARNING. UNAUTHORIZED MODIFICATIONS!

Changes or modifications made to this equipment that are not expressly approved by Park Air Electronics, or parties authorized by Park Air Electronics, could void the user’s authority to operate the equipment.

CAUTION. ESSDs!

The T6T transmitter's circuitry contains Electrostatic Sensitive Devices (ESSDs). Personnel must be aware of the precautions necessary to prevent damage to such devices. During installation all precautions necessary to prevent ESSD damage must be taken.

INTRODUCTION

The procedures in this chapter describe how to install a T6T transmitter. The procedures necessary during installation are listed in table 1-5 and should be completed in the order shown.

T6T General Information Section 1

Page 21

Table 1-5 Installation Procedures

Procedure Reference

1 Perform an initial inspection of the transmitter. Page 22

2 Fit the correct ac input fuse. Page 22

3 Select the correct ac input tap. Page 23

4 Selecting the keying method (AM-voice only) Page 24

5 Fit the transmitter into an equipment rack. Page 25

6 Connecting remote facilities Page 25

7 Connect the chassis stud to the rack or system earth. Page 26

8 Connect the ac input supply (if applicable). Page 26

9 Connect the dc input supply (if applicable). Page 27

10 Connect an antenna. Page 27

INITIAL INSPECTION OF THE TRANSMITTER

On receipt of the transmitter from PAE, remove all transit packaging and check that there is no transit damage. If damage is evident, contact PAE immediately and retain the original transit packaging.

The following items should be included with the transmitter:

Item 1. One copy of the T6T User Guide (this handbook).

Item 2. An unterminated IEC mains connector.

Item 3. An unterminated 15-way D-type plug (for use with the rear panel Facilities

connector CN5).

FITTING THE CORRECT AC INPUT FUSE

The mains input fuse F2 is an integral part of the rear panel ac connector (the connector and fuse are shown in Fig. 1-4 on page 14). The fuse type must be correct for the local mains supply. Check the fuse fitted conforms to that detailed in Table 1-6.

Table 1-6 Input AC Fuse Rating

Mains Input Supply Fuse PAE Part Number

110/120 V T4A 125 V UL 29C11120102S

220/230/240 V T4A 250 V IEC 127 HBC 29E01120108S

Section 1 T6T Transmitter User Guide Page 22

SELECTING THE CORRECT AC INPUT TAP

The correct tap on the input ac transformer must be selected to suit the local mains supply. The taps are selected by configuring connections on the AC Terminal Block. To set the correct tap:

a. Release the M3 captive screws that secure the transmitter's top cover. Remove the cover. Refer

to Fig. 1-9 and identify the AC Terminal Block. Refer to Fig. 1-10 and identify the configuration that is required for the local ac mains supply.

b. Remove the two screws that secure the terminal block bracket as shown in Fig. 1-9.

c. Connect the ac wires (brown = Line, and blue = Neutral) to the correct terminals. Connect link(s)

as shown in Fig. 1-10.

d. If the transmitter is to be operated in AM-voice mode, go to the next procedure. If operating in

other modes, refit the top cover.

T6T General Information Section 1

Page 23

Factory default setting. The transmitter is set for a 230 V ac input unless specified

otherwise at the time of ordering.

DEV083-08

Fig. 1-9. Location of Input Tap Terminal Block

SELECTING THE KEYING METHOD

This procedure is applicable only to AM-voice mode.

A number of different ‘remote’ or ‘phantom’ keying configurations are possible with the T6T transmitter. Internal jumpers must be correctly set to suit the required configuration. To do this, refer to section 2, chapter 3, of this user guide and follow the procedure ‘Selecting the Applicable Keying Method’.

Section 1 T6T Transmitter User Guide Page 24

0 110 120 0 110 120

Blue

Brown

Link

240 V ac Input220 V ac Input

0 110 120 0 110 120

Link

Blue Brown

230 V ac Input

0 110 120 0 110 120

Link

Blue Brown

Blue

Brown

0 110 120 0 110 120

Blue Link

Brown Link

110 V ac Input

0 110 120 0 110 120

Blue Link

Brown Link

Blue

Brown

120 V ac Input

Fig. 10. Input Tap Selection

FITTING A RADIO INTO AN EQUIPMENT RACK

CAUTION!

It is essential that the chosen mechanical installation provides adequate support along the depth (front to rear) of the unit. The transmitter must not be supported by the front panel; doing so can cause damage.

The transmitter can be installed on telescopic slides, or on fixed runners, within a standard 483 mm (19 inch) equipment rack. M4 tapped holes, each 10 mm deep (see Fig. 1-11) are provided on each side of the equipment to accept the slides. Details of suitable telescopic slides and fixed runners are available from PAE.

When fitted in the rack, the transmitter's front panel must be secured to the racks chassis using four M6 x 16 mm screws and plastic washers.

CONNECTING REMOTE FACILITIES

Remote facilities connections depend on the transmitter's operating mode. To determine the required remote connections, refer to chapter 3 of the section applicable to the operating mode.

T6T General Information Section 1

Page 25

Fig. 1-11. Telescopic Slide Fixing Points

(DEV083-09)

CHASSIS STUD CONNECTION

WARNING. CHASSIS EARTH!

A chassis stud is fitted to the transmitter's rear panel. This stud is used to connect the equipment to the equipment rack, or to the user's system earth point. The stud must not be used as the safety earth.

In order not to compromise the transmitter’s Electromagnetic Compatibility (EMC) the chassis stud, marked and fitted to the rear panel (see Fig. 1-3 on page 14) must be connected to the equipment rack (if a rack is being used) or to the user's system earth point. The connection should be made using a single tri-rated, green-and-yellow cable having a cross-sectional area of 2.5 mm

. The cable should have CSA and UL1015 approval, and be connected to the chassis stud through an M6 eyelet (for example, PAE part number 20-08010103).

Failure to comply with this instruction could result in non-compliance with the European

Commission EMC Directive 89/336/EEC.

AC SUPPLY CONNECTION

WARNING. LETHAL VOLTAGES!

The equipment is permanently connected to the mains supply when the mains connector is attached. Switching the rear panel Power switch to off does not isolate all internal circuits from the mains supply. For this reason, a mains isolating switch should be fitted close to, and easily accessible from, the transmitter's position.

WARNING. EARTH CONNECTION!

This equipment must be earthed. The earth terminal of the AC connector should be used as the safety earth.

An ac input connector (see Fig. 1-4 on page 14) is fitted to the equipment’s rear panel. The cable used to connect between the equipment and the user’s ac power source should be 3-core (to IEC 227) rated 250 V ac at 8 amps, and have a minimum cross-sectional area of 1.0 mm² per core. PAE recommends the use of polyvinyl chloride (PVC) insulated cable. The cable must be fitted with the IEC approved equipment connector (PAE part number 20-02030102) supplied with the transmitter, and conform to the following specification:

If PVC insulated, be not lighter than ordinary polyvinyl chloride sheathed flexible cord according to IEC publication 227 (designation H05 VV-F, or H05 VVH2-F).

If rubber insulated, be of synthetic rubber and not lighter than ordinary tough rubber-sheathed flexible cord according to IEC publication 245 titled ‘Rubber Insulated Cables of Rated Voltages up to and Including 450/750 V (designation H05 RR-F)’.

The T6T transmitter is a Class 1 equipment. The ac supply cable should have a green-and-yellow protective earthing conductor electrically connected to the protective earthing terminal of the equipment connector and the mains plug. PAE recommends the ac supply cable is colour coded in accordance with the electrical appliance (colour code) regulations for the UK. That is:

The core that is coloured green-and-yellow must be connected to the terminal in the plug that is marked with the letter E or by the earth symbol or coloured green-and-yellow.

The core that is coloured blue must be connected to the terminal that is marked with the letter N or coloured black.

The core that is coloured brown must be connected to the terminal that is marked with the letter L or coloured red.

Section 1 T6T Transmitter User Guide Page 26

DC SUPPLY CONNECTION

The transmitter operates from either an ac, or a dc input supply. When both ac and dc are connected, operation from the ac supply takes priority; automatic change-over to the dc supply occurs if the ac supply fails. On restoration of the ac supply, the equipment reverts to ac operation.

A dc input supply connector (see Fig. 1-5 on page 15) is fitted to the equipment's rear panel. The recommended minimum rating of the dc supply cable is: 2-core having a cross-sectional area of 1.5 mm

per core. The supply cable should be fitted with an XLR3 connector (PAE part number 20-01030106).

CONNECTING AN ANTENNA

The antenna feeder cable connects to the transmitter’s rear panel N-type antenna connector (see Fig. 1-3 on page 14).

SWITCHING ON

When installation is complete, the transmitter should be switched on at the rear panel Power switch (see page 14).

T6T General Information Section 1

Page 27

T6T Transmitter User Guide

Section 2

AM-Voice Mode

Section 2 T6T AM-Voice Operation Page 2

Section 2 Contents

Chapter 1. AM-Voice Overview

Introduction to AM-voice mode 3 Carrier Offset Operation 3 Operational Settings 4 Basic Configuration 4

Local Operation 4 Remote Operation 5

Configuration for Operation with MARC 6

Chapter 2. AM-Voice Specification

RF Characteristics 7 Modulation Characteristics 7

Chapter 3. AM-Voice Installation

Introduction 9 Selecting the Applicable Keying Method 10 Remote Keying Configurations 11 Phantom Keying Configurations 12 Connecting the Remote Facilities 14 Connecting to MARC Equipment 14

Chapter 4. AM-Voice Operational Settings

Introduction 17

Normal Operation 17

Using the Scroll/Select Switch 17 Screen Protocol 18 Menu Lock Screen 20 Notes for Setting Up the Transmitter 21

Front Panel Display for 25 kHz and 8.33 kHz Channel Spacing 21

Line Level 22 To Enter Standby Mode 23 To Exit Standby Mode 24 AM Voice Settings Procedure 25 General Transmitter Settings 29 Setting the Operating Frequency 34 Allocating Channel Numbers to Specified Frequencies 35 To Recall Channel Frequencies 36 To initiate an Interruptive BIT Test 37 To View BIT Pages and Advise Screen 38 Elapsed Time Indicator 39 Displaying the Transmitter's Internal Reference Frequency Screen 40 Software Versions Screen 41

Page

Chapter 1. AM-Voice Overview

This chapter provides an introduction to using the T6T transmitter in AM-voice mode.

INTRODUCTION TO AM-VOICE MODE

In AM-voice mode, the T6T transmitter operates in the frequency range 118 to 136.975 MHz using 25 kHz or 8.33 kHz channel spacing. The transmitter produces a 50 watt carrier output that can be reduced, in 1 watt steps, to 5 watts. The output power, and the majority of operational settings, can be selected at the front panel or through a compatible control and data system such as the PAE Multi-Access Remote Control (MARC) system.

A multi-channel feature allows up to 100 frequency channels to be stored and recalled by channel number. In AM voice mode, and when 25 kHz channel spacing is used, the transmitter can operate with a 2, 3, 4, or 5 carrier-offset frequency in accordance with ICAO Annex 10.

CARRIER OFFSET OPERATION

In AM voice mode the transmitter can offset the carrier frequency to provide 2, 3, 4, or 5-carrier offset to meet the requirements of ICAO Annex 10. Offsets are selected using the front panel Scroll/Select control and the LCD display. The offsets are:

2-carrier offset: carriers are spaced at ±5 kHz. 3-carrier offset: carriers are spaced at zero, and ±7.3 kHz. 4-carrier offset: carriers are spaced at ±2.5 kHz and ±7.5 kHz 5-carrier offset: carriers are spaced at zero, ±4 kHz and ±8 kHz

Note ... For 5-carrier offset operation, transmitter variant B6350OPT1 must be used.

T6T AM-Voice Operation Section 2

Page 3

OPERATIONAL SETTINGS

Operating frequency

Selecting a carrier offset

Selecting the channel spacing

Channel allocation and recall

Setting the line level

Setting the output power

Standby mode to on or off

Setting inhibit to on or off

Setting the MARC baud rate

Setting the PTT input signal polarity

Setting the PTT output signal polarity

Setting the inhibit input signal polarity

Setting the BIT initiate signal polarity

Setting the Ready output signal polarity

Setting the antenna change-over signal polarity

PTT test facility

Setting the PTT timeout

Setting the modulation depth

q Mute enable or disable q Vogad enable or disable

Adjusting the sidetone volume

Setting the LCD backlight

BASIC CONFIGURATION

Fig. 2-1 shows the basic T6T transmitter connections for AM voice operation. If the transmitter is part of a MARC system, or other compatible control and data system, refer to ‘Configuration for Operation with MARC’ on page 6.

Local Operation

In its simplest configuration, the transmitter can be operated in Local mode. This involves plugging a microphone with integral PTT switch into the front panel Microphone/Diagnostics connector. The transmitter is then operated from the front panel.

Section 2 T6T AM-Voice Operation Page 4

Remote Operation

For remote operation signals are connected from the control equipment, through a suitable communication link, to the transmitter's rear panel Facilities connector. Essential connections are an audio input and a keying input. For the keying input, the Remote PTT connection can be used, or phantom keying can be superimposed on the audio lines (see ‘Selecting the Applicable Keying Method’ in chapter 3). Other remote signals can be connected to suit the particular application. The remote signals are fully described in section 1 on page 17.

In the basic configuration, the rear panel MARC and Computer Port connectors are not used. The front panel Reference connector is used to check the transmitter's internal reference frequency during scheduled maintenance. The front panel Microphone/Diagnostics connector has two purposes: a microphone/headset is connected for local operation, or, a PC is connected for maintenance purposes.

Maintenance using a PC connected to the Headset/Diagnostics connector is outside the scope of this user guide. Full information is contained in the T6T maintenance handbook.

T6T AM-Voice Operation Section 2

Page 5

Fig. 2-1. T6T Transmitter - Basic Configuration

Audio

Remote PTT

External VSWR

Tx Inhibit

BIT Test

Antenna Changeover

PTT Status Signal

Unregulated Supply

Ready Signal

Tape Output

T6T Transmitter

Facilities Connector

Antenna

Connector

Microphone/Diagnostics

Connector

Reference Connector

Remote Signals

Microphone/Headset for Local Operation

PC for maintenance purposes

Frequency Counter for

maintenance purposes

CONFIGURATION FOR OPERATION WITH MARC

When the T6T transmitter is used with a MARC system or other compatible control and data system, the remote signals are connected through the rear panel MARC connector (see Fig. 2-2). In this configuration, the rear panel Facilities and Computer Port connectors are not used unless some auxiliary signals available at the Facilities connector are required.

Section 2 T6T AM-Voice Operation Page 6

Fig. 2-2. T6T Transmitter - Configuration for Use with MARC

Microphone/Headset for Engineering Use

PC for maintenance purposes

Frequency Counter for maintenance purposes

Audio

Remote PTT

Control Information

Status Information

Unregulated Supply

MARC

RSE 2

has 8

equipment connectors allowing up

to 8 radios

to be

connected

Equipment

Connector

T6T Transmitter

Antenna

Connector

Microphone/Diagnostics

Connector

Reference Connector

MARC Connector

Chapter 2. AM-Voice Specification

This chapter gives the transmitter's specification applicable to AM-voice operation.

RF CHARACTERISTICS

Channel spacing 25 kHz, or 8.33 kHz across the frequency band 118 to

136.975 MHz.

Spurious outputs Spurious outputs are below -46 dBm. Spurious outputs

are measured greater than 500 kHz from the carrier frequency and with a modulation index below m = 0.9.

Transmitter rise time 90% of full power is reached within 20 ms of keying the

transmitter.

Transmitter decay time The output power decays by at least 20 dB 5 ms after

the keying potential is removed.

MODULATION CHARACTERISTICS

Modulation depth Adjustable up to 100%.

Hum and noise Greater than 45 dB below the signal level. Measured

within a 15 kHz bandwidth with the carrier modulated by a 1 kHz signal and at a modulation depth of 90%.

Frequency response With 25 kHz channel spacing the variation in frequency

response, with reference to a 1 kHz signal, is within +1 dB and -3 dB across the frequency range 300 Hz to

3.4 kHz. The response is better than -20 dB at 100 Hz, and less than -30 dB at 5 kHz.

With 8.33 kHz channel spacing the variation in frequency response, with reference to a 1 kHz signal, is within +2 dB and -4 dB across the frequency range 350 Hz to 2.5 kHz. Frequencies above 3.2 kHz are attenuated by at least 25 dB.

Distortion With a 90% modulation depth, distortion is less than 5%

at frequencies between 300 Hz and 3.4 kHz.

Residual FM With a 1 kHz signal set at 80% modulation applied to the

transmitter's audio input, the unwanted frequency modulation is less than 500 Hz.

VOGAD The VOGAD has an operational range of 30 dB with the

threshold set relative to the line level setting. Within the VOGAD range, the modulation depth is maintained within 10% of the set level.

VOGAD has an attack time between 20 and 50 ms measured with a 10 dB step to 15 dB into VOGAD, and a decay time greater than 2 seconds.

T6T AM-Voice Operation Section 2

Page 7

Intentionally Blank

Section 2 T6T AM-Voice Operation Page 8

Chapter 3. AM-Voice Installation

This chapter details the installation procedures that are applicable only to AM-voice operation.

WARNING. LETHAL VOLTAGES!

The instructions given in this chapter involve connecting lethal voltages to the transmitter. The instructions detailed in this chapter must be carried out only by suitably qualified personnel.

WARNING. ANTENNA RADIATION!

The antenna used with the transmitter must be installed such that the resultant radiated field strength is below 10W/m² in areas normally accessible to personnel.

WARNING. BERYLLIUM/BERYLLIA!

The equipment covered by this handbook contains components containing the highly toxic material Beryllium and/or its oxide Beryllia. These materials are particularly hazardous if:

1. Beryllium materials are absorbed into body tissues through the skin, mouth, or wound.

2. The dust created by breakage of Beryllia is inhaled.

3. Toxic fumes are inhaled from Beryllia/Beryllium involved in a fire.

The components containing Beryllia/Beryllium are: TR5, TR6 and TR9 in the PA module.

WARNING. UNAUTHORIZED MODIFICATIONS!

CAUTION. ESSDs!

INTRODUCTION

The procedures in this chapter that allow a T6T transmitter to be installed for AM-voice operation are:

Selecting the applicable keying method

Connecting remote facilities.

T6T AM-Voice Operation Section 2

Page 9

SELECTING THE APPLICABLE KEYING METHOD

The transmitter can be remotely keyed through the Facilities connector CN5 using either the Remote PTT input, or by using Phantom Keying on the audio lines. The chosen method, and the required keying potential is selected by the position of two jumpers (JP8 and JP9) fitted on the transmitter's DSP module.

To access the jumpers, remove the M3 captive screws that secure the transmitter's top cover (if not already removed). Remove the cover and identify the links by referring to Fig. 2-3. Set the links to the required positions as detailed under the next two headings: "Remote Keying" and "Phantom Keying". When the jumpers have been configured, refit the transmitter's top cover.

Section 2 T6T AM-Voice Operation Page 10

Fig. 2-3 Location of Jumpers JP8 and JP9

T6T Transmitter with top cover removed showing position of DSP module and jumpers JP8 and JP9

Front Panel

DSP Module

Phantom Keying

Remote Keying

28V

JP8 JP9

Factory default setting. The transmitter is set for remote 0 volt keying unless specified

otherwise at the time of ordering.

REMOTE KEYING CONFIGURATIONS

During installation jumpers JP8 and JP9 must be set to suit the remote keying potential. The keying potentials are 0 volt, a dc voltage between +10 and +50 V, or a dc voltage between -10 and -50 V.

The following illustrations show the PTT signal, the settings of jumpers JP8 and JP9, and the ‘PTT in polarity’ that must be set at the front panel when completing the ‘Operational Settings’ procedures.

T6T AM-Voice Operation Section 2

Page 11

Phantom Keying

Remote Keying

28V

JP8 JP9

T6T Transmitter

[Front panel PTT Polarity = POS]

PTT Switch

0 volt

Remote PTT

0 Volt Keying

[Factory default setting]

+10 to +50 Volt Keying with Positive Going Active Signal

Phantom Keying

Remote Keying

28V

JP8 JP9

T6T Transmitter

[Front panel PTT Polarity = POS]

+10 to +50 V

PTT

Phantom Keying

Remote Keying

28V

JP8 JP9

T6T Transmitter

[Front panel PTT Polarity = NEG]

PTT

+10 to +50 V

+10 to +50 Volt Keying with Negative Going Active Signal

PHANTOM KEYING CONFIGURATIONS

Phantom keying can be used with the transmitter. This involves superimposing a dc potential on the audio lines at the control equipment. The potential can be 0 volt, or between 10 and 50 volts as shown in the illustrations on the opposite page.

To use phantom keying, the PTT switch at the control equipment must connect to a centre-tap on the 600 ohm audio transformer. The keying potential is connected to the centre-tap.

At the transmitter, jumpers JP8 and JP9, fitted to the DSP module, must be correctly set for phantom keying.

Note that the audio lines in the illustrations connect to the transmitter's Facilities connector CN5. If phantom keying is required when using a MARC, or compatible control and data system, the lines connect to the MARC connector CN6 pins 2 and 3.

Section 2 T6T AM-Voice Operation Page 12

Phantom Keying

Remote Keying

28V

JP8 JP9

T6T Transmitter

[Front panel PTT Polarity = POS]

-10 to -50 V

PTT

Phantom Keying

Remote Keying

28V

JP8 JP9

T6T Transmitter

[Front panel PTT Polarity = NEG]

PTT

-10 to -50 V

-10 to -50 Volt Keying with Negative Going Active Signal

-10 to -50 Volt Keying with Positive Going Active Signal

T6T AM-Voice Operation Section 2

Page 13

Fig. 2-4. Phantom Keying Arrangements

Phantom Keying

Remote Keying

28V

JP8 JP9

Phantom Keying

Remote Keying

28V

JP8 JP9

[Front panel PTT Polarity = POS]

CONNECTING THE REMOTE FACILITIES

If the transmitter is being used in the ‘Basic Configuration’ (see Fig. 2-1 on page 5) remote signals are terminated on the rear panel Facilities connector CN5. For configurations where the T6T transmitter is being used with a MARC system, or other compatible data and control system, this procedure should be ignored; instead, refer to ‘Connecting to MARC Equipment’.

The remote facilities available at CN5 are listed in section 1 on page 17. Essential connections, unless the transmitter is being used only in local mode, are the audio input (pins 2 and 3) and a keying input. The keying input can be the Remote PTT connection on pin 7, or Phantom Keying can be used on the audio lines. The chosen method must correspond to the settings of internal jumpers JP8 and JP9 (see page 10).

Make any other connections to CN5 as required.

When making connections to the Facilities connector CN5, and in order not to compromise the transmitter's Electromagnetic Compatibility (EMC) users must:

Use a D-type connector that has a screened cover

Use screened multi-way cable, with the cable's screen connected to the Facilities connector's shell or body.

Failure to comply with this instruction could result in non-compliance with

the European Commission EMC Directive 89/336/EEC

CONNECTING TO MARC EQUIPMENT

If the transmitter is being used with a MARC system, or compatible control and data system, remote connections are made through the rear panel MARC connector CN6.

The pin-out of CN6 is shown in section 1 on page 18. If connecting to a MARC RSE 2 equipment, the connections between CN6 and one of RSE 2's Equipment Connectors is pin-to-pin as shown in table 2-1.

When making connections to the Facilities connector CN6, and in order not to compromise the transmitter's Electromagnetic Compatibility (EMC) users must:

Use a D-type connector that has a screened cover

Use screened multi-way cable, with the cable's screen connected to the Facilities connector's shell or body.

Failure to comply with this instruction could result in non-compliance with

the European Commission EMC Directive 89/336/EEC

Section 2 T6T AM-Voice Operation Page 14

Table 2-1 MARC Connector CN6 to RSE 2 Equipment Connector

T6T Transmitter RSE 2 Equipment Connector

Number

Signal Name

Number

Signal Name

1 Ground 1 0 Volt

2 Line In (+) 2 Audio Line L1

3 Line In (-) 3 Audio Line L2

4 PTT 4 PTT

5 Unregulated Supply 5 Unregulated Supply Input

6 Data In (+) 6 Data Out (+)

7 Data In (-) 7 Data Out (-)

8 Data Out (+) 8 Data In (+)

9 Data Out (-) 9 Data In (-)

T6T AM-Voice Operation Section 2

Page 15

Intentionally Blank

Section 2 T6T AM-Voice Operation Page 16

Chapter 4. AM-Voice Operational Settings

This chapter details how the T6T transmitter is set up for AM voice operation from the front panel.

It also details how to set the transmitter in and out of standby mode.

The transmitter can also be set up through a MARC system, or by using the VFP. Both of

these methods are outside the scope of this handbook; users should refer to the MARC

User Guide and the T6T Maintenance Handbook.

INTRODUCTION

Selecting most of the transmitter's operational settings is carried out using the front panel Scroll/Select switch and the LCD (see the illustration below). Table 2-2 on page 19 shows a list of the operational settings. No attempt to set up the transmitter should be made until the transmitter has been installed as per the Installation Procedures given in section 1 of this user guide.

Normal Operation

During normal operation, the LCD displays the Main screen. This screen shows the operating frequency, the channel number (if the channel store facility is used), the carrier offset (if used), and displays a graphical representation of output power when the transmitter is keyed. If the transmitter has been set to Standby mode, which is shown by the front panel STANDBY indicator being lit, the LCD is blanked.

Using the Scroll/Select Switch

The SCROLL/SELECT switch (referred to throughout this chapter as the ‘Switch’) is used to leave the Main screen and display the Options menu. Further use of the Switch displays various selection menus and allows the required parameters to be set. The switch has three actions: it can be turned clockwise, anti-clockwise, or momentarily pushed in.

T6T AM-Voice Operation Section 2

Page 17

Freq 123.000MHz Chan 1 Offset +5.0kHz Pwr lllllllllll

SCREEN PROTOCOL

The following protocol is applicable to all screens described in this chapter.

Main Screen During normal transmitter operation, the Main screen, an example of which is

shown below, is displayed.

Fr eq 123 . 000MHz

Chan 1

Of fset +5.0kHz

Pwr IIIIIIIIIIII

Switch Refers to the front panel Scroll/Select switch. The switch is turned clockwise to

scroll through fields from left to right, and from top to bottom. The switch is turned anti-clockwise to scroll through fields from right to left, and from bottom to top. The switch is pressed to make a selection.

Timeout If during any setting up procedure the Scroll/Select switch is not operated for

30 seconds, the display returns to the Main screen. If editing any parameter has not been completed, the transmitter stays on the original setting.

>> Indicates more fields are available other than those currently displayed. To

access those fields, turn the switch clockwise through the last displayed field.

<< Indicates more fields are available other than those currently displayed. To

access those fields, turn the switch anti-clockwise through the first displayed field.

Back When Back is selected, you are returned to the previous menu.

Exit When Exit is selected, you are returned to the Main screen.

Section 2 T6T AM-Voice Operation Page 18

Table 2-2 Operational Settings

Parameter

Adjustment Range

Factory Default

Setting

Further Reference

Menu Lock screen Locked or Unlocked Unlocked Page 20

To enter Standby mode On or Off Off Page 23

To exit Standby mode - - Page 24

Set mode of operation AM voice AM-voice

Part of AM Voice Settings Procedure starting on page 25.

PTT test facility On or Off Off

PTT timeout 2 s to 510 s, or off 180 s

Modulation depth 0 to 100% 85%

Tx mute On or off On

Vogad On or Off On

Carrier offset

0, ±2.5, ±4, ±5, ±7.3, ±7.5, or ±8 kHz

0 (no offset)

Adjust sidetone volume 0 to 100% 30%

Front panel frequency step size 8.33, 25 kHz, or both 25 kHz

LCD backlight timeout 15 s to 120 s, Off, or On 30 s

Part of General Transmitter Settings starting on page 29.

PTT inhibit On or Off Off

Line input level -40 dBm to 0 dBm -13 dBm

Output power 5 watt to 50 watt 50 W

MARC port baud rate 300 to 9600 baud 9600

PTT input signal polarity Positive or negative Pos

PTT output signal polarity Positive or negative Pos

Inhibit input signal polarity Positive or negative Pos

BIT initiate input signal polarity Positive or negative Pos

Ready output signal polarity Positive or negative Pos

Operating frequency 118 to 136.975 MHz 118.000 MHz Page 34

Store frequency channels 1 to 100 118.000 MHz Page 35

Recall frequency channels 1 to 100 - Page 36

Initiate a BIT test - - Page 37

View BIT pages and advise screen - - Page 38

Elapsed time indication - Page 39

Display internal reference frequency screen

- - Page 40

Software versions - Page 41

T6T AM-Voice Operation Section 2

Page 19

MENU LOCK SCREEN

A security facility available only from the VFP allows the transmitter's front panel to be ‘locked’. When this facility is active, no operational settings can be made from the front panel until an ‘unlock’ command is sent from the VFP.

The following screen is displayed when ‘lock’ is active, and the front panel switch is pressed.

S ECUR I TY MESSAG E

System Locked

To exit the system lock screen:

Turn the switch to highlight OK, then press the switch. You are returned to the main screen.

or,

Wait for the 30 second timeout to expire. You are returned to the main screen.

Section 2 T6T AM-Voice Operation Page 20

NOTES FOR SETTING UP THE TRANSMITTER

The following notes should be read before setting up the transmitter. They advise on the special frequency display when using 8.33 kHz channel spacing, and give guidance on the optimum line level setting.

Front Panel Display for 25 kHz and 8.33 kHz Channel Spacing

When setting the operating frequency of the transmitter and 8.33 kHz channel spacing is selected, the displayed frequency differs from the actual channel frequency. Table 2-3 shows the pattern used for 25 kHz and 8.33 kHz spaced channel frequencies from 118.000 MHz to 118.1916 MHz. The pattern is the same for any frequency within the transmitter's frequency range. The display conforms to ICAO convention for 8.33 kHz operation.

Table 2-3 25 kHz and 8.33 kHz Channel Spacing Displays

Actual Frequency

(to 4 decimal places)

Channel Spacing

Displayed Frequency

at Transmitter's Front Panel

118.0000 MHz

118.0083 MHz

118.0166 MHz

118.0250 MHz

118.0333 MHz

118.0416 MHz

118.0500 MHz

118.0583 MHz

118.0666 MHz

118.0750 MHz

118.0833 MHz

118.0916 MHz

118.1000 MHz

118.1083 MHz

118.1166 MHz

118.1250 MHz

118.1333 MHz

118.1416 MHz

118.1500 MHz

118.1583 MHz

118.1666 MHz

118.1750 MHz

118.1833 MHz

118.1916 MHz

25 kHz

8.33 kHz

25 kHz

8.33 kHz

25 kHz

8.33 kHz

25 kHz

8.33 kHz

25 kHz

8.33 kHz

25 kHz

8.33 kHz

25 kHz

8.33 kHz

25 kHz

8.33 kHz

118.000 MHz

118.005 MHz

118.010 MHz

118.015 MHz

118.025 MHz

118.030 MHz

118.035 MHz

118.040 MHz

118.050 MHz

118.055 MHz

118.060 MHz

118.065 MHz

118.075 MHz

118.080 MHz

118.085 MHz

118.090 MHz

118.100 MHz

118.105 MHz

118.110 MHz

118.115 MHz

118.125 MHz

118.130 MHz

118.135 MHz

118.140 MHz

118.150 MHz

118.155 MHz

118.160 MHz

118.165 MHz

118.175 MHz

118.180 MHz

118.185 MHz

118.190 MHz

T6T AM-Voice Operation Section 2

Page 21

Line Level

The line level, setting displayed on the front panel is equivalent to the average speech level with a peak-to-average ratio of 13 dB. This corresponds to the level specified for the lines.

When testing the transmitter using a sine wave, the line input level should be set to 10 dB above the line level setting.

The VOGAD and mute thresholds are preset at 10 dB and 15 dB respectively below the line level setting.

Table 2-4 Relationship between Line Level, Vogad, and Mute Threshold

Line Level

Setting

(dBm)

Average Speech

Level

(dBm)

Sine Wave Level

(dBm)

Vogad

Threshold

Mute Threshold

0 0 +10 -10 -15

-5 -5 +5 -15 -20

-10 -10 0 -20 -25

-15 -15 -5 -25 -30

-20 -20 -10 -30 -35

-25 -25 -15 -35 -40

-30 -30 -20 -40 -45

-35 -35 -25 -45 -50

-40 -40 -30 -50 -55

Section 2 T6T AM-Voice Operation Page 22

TO ENTER STANDBY MODE

Standby mode is a power saving feature that can be used for non-operational transmitters. When in standby mode, most of the transmitter's circuits are inactive, the LCD is blanked, and the transmitter cannot be keyed. To put the transmitter into standby mode, use the following procedure.

1. From the Main screen, press the switch to display the Options menu. Ensure that Configure is highlighted. Press the switch.

2. Ensure the Configure menu is displayed. Turn the switch until Standby is highlighted, then press the switch.

3. Check that the Standby menu is displayed. Turn the switch until Yes is highlighted, then press the switch. [To abandon this procedure, select No instead of Yes and then press the switch.]

4. Check that the LCD blanks, and the front panel STANDBY indicator lights.

5. The transmitter is now in standby mode. To exit standby, see the next procedure.

T6T AM-Voice Operation Section 2

Page 23

Frequency

Channe l

Con f i gu r e

BIT Exi t

Se t t i ngs

S/W Versions

St andby

Back Ex i t

Put radio into

St andby mode ?

YES NO

TO EXIT STANDBY MODE

Standby mode is indicated by the front panel STANDBY indicator being lit and the LCD being blanked. To exit this mode, use the following procedure.

1. Press the switch and check that the Exit menu is displayed.

2. Turn the switch until YES is highlighted, then press the switch. [To abandon this procedure, select No instead of Yes and then press the switch.]

3. Check that the transmitter's Main screen is displayed and that the front panel STANDBY indicator is unlit.

4. The transmitter is now ready for normal use.

Section 2 T6T AM-Voice Operation Page 24

Ex i t S t andby

Mod e

YES NO

Fr eq 123. 000 MHz

Pw r

AM VOICE SETTINGS PROCEDURE

During this procedure, the following parameters, applicable to AM voice operation, will be set:

Mode of operation

PTT test facility

PTT timeout

Modulation depth

Mute enable or disable

Vogad enable or disable

Selecting a carrier offset

Adjusting the sidetone volume

Selecting the channel spacing.

1. From the Main screen, press the switch to display the Options menu. Turn the switch until Configure is highlighted. Press the switch.

2. Ensure the Configure menu is displayed. Turn the switch until Settings is highlighted, then press the switch.

3. Check that the Function menu is displayed. Ensure Mode is highlighted. Press the switch.

4. Setting the Mode of Operation.

Check that AM Voice is displayed. If any other mode is displayed, press the switch until AM Voice is shown.

Turn the switch clockwise until Settings is highlighted. Then press the switch to display the mode specific Settings menu.

T6T AM-Voice Operation Section 2

Page 25

Frequency

Channe l

Con f i gu r e

BIT Exi t

Options Menu

Mod e

Reference Freq

Display

Function Menu

Mod e : AM V o i c e

Se t t i ngs

Cance l OK

Se t t i ngs

S/W Versions

St andby

Back Ex i t

Configure Menu

5. Setting the PTT Test Facility.

[Factory default setting: Off]

The PTT test facility can be set to Off or On.

When Off is selected, the transmitter is keyed only when the PTT signal is active.

When On is selected, the transmitter keys, and remains keyed until the display times out.

To set the PTT facility, ensure PTT is highlighted. Press the switch to toggle between Off and On. When the required setting is displayed, turn the switch clockwise to highlight PTT Timeout.

6. Setting the PTT Timeout.

[Factory default setting: 180 s]

The PTT timeout can be set to a value between 2 and 510 seconds (in two second steps), or it can be set to Off. This setting affects the transmitter when keyed by a front panel microphone, or through the remote lines.

To set the timeout ensure that PTT Timeout is highlighted and press the switch. Turn the switch clockwise to increment the time in seconds, or anti-clockwise to decrement the time in seconds. Note that the fully anti-clockwise position switches the PTT timeout to Off. When the required time, or Off, is displayed press the switch. Turn the switch clockwise to highlight Mod Depth.

7. Setting the Modulation Depth.

[Factory default setting: 85%]

The transmitter's modulation depth can be set between 0 and 100% in increments of 1%.

To set the required value, ensure that Mod Depth is highlighted and press the switch. Turn the switch clockwise or anti-clockwise to increment or decrement the value. When the required value is displayed, press the switch. Turn the switch clockwise until the next screen is displayed and Mute is highlighted.

Section 2 T6T AM-Voice Operation Page 26

PTT OFF

PTT T imeou t 30s

Mod Depth 90%

Mode Specific Settings Menu

PTT OFF

PTT T imeou t 30s

Mod Depth 90%

PTT OFF

PTT T imeou t 30s

Mod Depth 90%

8. Setting Mute On or Off.

[Factory default setting: On]

The transmitter's mute facility can be enabled or disabled.

To enable or disable the mute, ensure that Mute Disable is highlighted. Press the switch to toggle between On and Off. On = Mute Disabled; Off = Mute enabled. When the required setting is highlighted, turn the switch clockwise to highlight Vogad.

9. Switching Vogad On or Off.

[Factory default setting: On]

The transmitter's Vogad facility can be set to On or Off.

To enable or disable the Vogad, ensure that Vogad is highlighted. Press the switch to toggle between On and Off. When the required setting is highlighted, turn the switch clockwise to highlight Offset.

10. Setting the Carrier Offset.

[Factory default setting: 0]

A carrier offset can be used with the transmitter. The available offsets are ±2.5 kHz, ±4.0 kHz, ±5 kHz, ±7.3 kHz, ±7.5 kHz, and ±8 kHz.

Note that transmitter type B6350OPT1 must be used if selecting an 8 kHz carrier offset, and a separate setting up procedure must be completed. This procedure, which involves the use of external test equipment, is detailed in the T6T transmitter maintenance handbook.

To select the required offset (0.0 kHz must be selected if no offset is used) ensure that Offset is highlighted and press the switch. Turn the switch to display the required value, then press the switch. Turn the switch clockwise, through >> to highlight Headset.

T6T AM-Voice Operation Section 2

Page 27

Mu t e OFF

Vogad OFF

Of fset 0.0kHz

<< >>

Mu t e OFF

Vogad OFF

Of fset 0.0kHz

<< >>

Mu t e OFF

Vogad OFF

Of fset 0.0kHz

<< >>

11. Adjusting the Sidetone Volume.

[Factory default setting: 30%]

The transmitter's sidetone volume through the headset is adjusted from this screen. To do this, ensure Headset is highlighted and press the switch.

Check that the Volume setting is highlighted. Turn the switch clockwise to increase volume, or anti-clockwise to decrease volume. The volume increments or decrements in 5% steps. When the required setting is displayed, press the switch. Highlight OK, and press the switch to teurn to the mode specific settings menu.

Turn the switch clockwise, through >> to highlight Channel Spacing.

12. Setting the Front Panel Frequency Step Size.

[Factory default setting: 25 kHz]

The transmitter's channel spacing can be 25 kHz, or 8.33 kHz. The radio automatically sets the correct channel spacing for the frequency that is entered at the front panel. This setting, which is only for the user's convenience, alters front panel frequency step size.

q If all channels to be selected or stored are 25 kHz spaced channels, then 25 should be

selected.

If all channels to be selected or stored are 8.33 kHz spaced channels, then 8.3 should be selected.

If a mixture of the two are required, both 25 and 8.3 should be selected.

To select the required spacing, ensure that Channel Spacing is highlighted and press the switch.

Check that the Channel Spacing menu is displayed and that Spacing is highlighted.

Press the switch to change between 25 kHz,

8.3 kHz, and both. When the required value is displayed, turn the switch to highlight OK, then press the switch again. You will be returned to the Mode Specific Settings menu.

13. To exit the AM Voice Settings Procedure, turn the switch to highlight OK, then press the switch. You are returned to the Main screen. When this procedure is complete, go to the General Transmitter Settings procedure starting on the next page.

Section 2 T6T AM-Voice Operation Page 28

Spac i ng 25kHz

Cance l OK

Headse t

Channe l Spac i ng

Back

Ex i t

Headse t

Channe l Spac i ng

Back

Ex i t

Volume 030%

GENERAL TRANSMITTER SETTINGS

During this procedure the following parameters are set:

Setting the LCD backlight

Setting inhibit to on or off

Setting the input line level

Setting the output power

Setting the MARC baud rate

Setting the PTT input signal polarity

Setting the PTT output signal polarity

Setting the inhibit input signal polarity

Setting the BIT initiate signal polarity

Setting the Ready output signal polarity

Setting the antenna change-over signal polarity

1. From the Main screen, press the switch to display the Options menu. Turn the switch until Configure is highlighted. Press the switch.

2. Ensure the Configure menu is displayed. Turn the switch until Settings is highlighted, then press the switch to display the Function menu.

3. Ensure the Function menu is displayed. Turn the switch until Display is highlighted.

T6T AM-Voice Operation Section 2

Page 29

Frequency

Channe l

Con f i gu r e

BIT Exi t

Options Menu

Se t t i ngs

S/W Versions

St andby

Back Ex i t

Configure Menu

Mod e

Reference Freq

Display

Function Menu

4. Setting the LCD Backlight.

[Factory default setting: 30 s]

The LCD's backlight can be set to off, permanently on, or timed to stay on for a period between 15 and 120 seconds (adjustable in 15 second steps) after the Scroll/Select switch was last operated.

Check that the Function menu is displayed and ensure Display is highlighted. Press the switch.

Ensure the Backlight menu is displayed and the Backlight setting is highlighted. Rotation of the switch displays the full range of settings. When the required setting is highlighted, press the switch. Turn the switch until OK is highlighted, then press the switch. You are returned to the Function menu.

5. Setting Inhibit.

[Factory default setting: Off]

Inhibit can be set to either On or Off. When set to on, the transmitter cannot be keyed; when set to off the transmitter operates normally. Note that a separate Inhibit function is available on the Facilities connector CN5 (see pin-out in section 1 on page 17).

From the Function menu, turn the switch clockwise until Inhibit is highlighted, then press the switch.

Check that the Inhibit menu is displayed and Inhibit is highlighted. Pressing the switch toggles between On and Off. When the correct setting is displayed turn the switch clockwise to highlight OK, then press the switch. You are returned to the Function menu.

Section 2 T6T AM-Voice Operation Page 30

Mod e

Reference Freq

Display

Back l i gh t OFF

Cance l OK

Inhibi t

Line Level

Powe r

<< >>

Inhibi t ON

Cance l OK

6. Setting the Line Level.

[Factory default setting: -13 dBm]

The audio line level can be set to any value between -40 dBm and 0 dBm. Some notes regarding the optimum line level are given on page 22.

From the Function menu, turn the switch clockwise until Line Level is highlighted, then press the switch.

Check that the Line Level menu is displayed and that Line Lvl is highlighted, then press the switch.

Turn the switch clockwise or anti-clockwise to increase or decrease the value. When the required value is displayed, press the switch. Turn the switch to highlight OK and then press the switch. You are returned to the Function menu.

7. Setting the Output Power.

[Factory default setting: 50 W]

The transmitter's output power can be set to any value between 5 watts and 50 watts (in one watt steps).

From the Function menu, turn the switch clockwise until Power is highlighted, then press the switch.

Ensure that the Power menu is displayed and that Power is highlighted.

Press the switch. Turn the switch clockwise to increase the power, or anti-clockwise to decrease the power. When the required value is displayed, press the switch. Turn the switch clockwise until OK is highlighted, then press the switch. You are returned to the Function menu.

T6T AM-Voice Operation Section 2

Page 31

Inhibi t

Line Level

Powe r

<< >>

Line Lvl - 13dBm

Cance l OK

Inhibi t

Line Level

Powe r

<< >>

Powe r 50W

Cance l OK

8. Setting the MARC Baud Rate.

[Factory default setting: 9600]

The baud rate must be set when the T6T transmitter is connected to a MARC system (or other compatible data and control system). The rate can be set to 300, 600, 1200, 2400, 4800, or 9600 baud. The standard setting for MARC systems is 9600 baud.

From the Function menu, turn the switch clockwise until MARC is highlighted, then press the switch.

Ensure that the MARC menu is displayed and that the Baud Rate is highlighted. Press the switch.

Turn the switch until the required value is displayed, then press the switch. Turn the switch clockwise until OK is highlighted, then press the switch. You are returned to the Function menu.

9. Polarity Settings.

The polarity of the following input and output and output signals is set using the Polarity menu:

q PTT input signal

PTT output signal

Inhibit input signal

BIT initiate input signal

Ready output signal.

In addition to the signals listed, the polarity of the Antenna Change-Over signal is determined from this menu. It is always the same polarity as the PTT output signal.

To establish the required polarity for the PTT input signal, refer to the illustrations starting on page 11 under the heading ‘Remote Keying Configurations’. Note that internal links must also be correctly configured to obtain the required input PTT configuration.

To establish the required polarity for the other input and output signals, refer to table 2-5.

To set the required polarity, turn the switch to highlight the required parameter, then press the switch to toggle between NEG and POS.

Section 2 T6T AM-Voice Operation Page 32

MARC

Po l a r i t y

Back

Ex i t <<

Baud Ra t e 9600

Cance l OK

PTT I n NEG

PTT Ou t POS

Inhibi t NEG

BIT Ini t NEG

Ready Out POS

Back

Ex i t <<

Polarity Menu

Table 2-5 Signal Polarities

Signal Description

State when Polarity is

set to NEG

State when Polarity is

set to POS

PTT output

This output, when active, indicates the transmitter is keyed. It is a grounding output.

Output is a high impedance when the transmitter is keyed, and 0 volt when not keyed.

Output is 0 volt when the transmitter is keyed, and a high impedance when not keyed.

Transmitter inhibit

This input signal, when active, prevents the radio from being keyed. This is a TTL input pulled-up to 5V.

A 5 volt input inhibits the transmitter.

A 0 volt input inhibits the transmitter.

BIT initiate

An input signal that initiates a BIT interruptive test. This is a TTL input pulled-up to 5 V. The input signal must be active for a minimum of 300 ms; the signal cannot then be activated again for at least 3 seconds.

A 5 volt input initiates a BIT test.

A 0 volt input initiates a BIT test.

Ready output

This output is active when the radio is ready to transmit and no faults have been detected by the BIT circuitry. It is an open collector output.

Output is a high impedance when the transmitter is ‘ready’, and 0 volt when not ‘ready’.

Output is 0 volt when the transmitter is ‘ready’, and a high impedance when not ‘ready’.

Antenna change-over

An output signal that can be used to control an antenna change-over relay when the transmitter is used in conjunction with a T6R receiver. Antenna change-over is a grounding output.

This signal cannot be independently set. It is always the same polarity as the PTT output signal.

10. To exit the General Transmitter Settings Procedure, turn the switch to highlight Exit, then press the switch. You are returned to the Main screen. When this procedure is complete, go to Setting the Operating procedure starting on the next page.

T6T AM-Voice Operation Section 2

Page 33

SETTING THE OPERATING FREQUENCY

To set the transmitter's operating frequency, use the following procedure. If a frequency is to be stored as one of the 100 available preset channels, ignore this procedure and go to ‘Allocating Channel Numbers to Specified Frequencies’ on page 35. Before setting the operating frequency, the required channel spacing should be set (see page 28).

1. From the Main screen, press the switch to display the Options menu. Ensure that Frequency is highlighted. Press the switch.

2. Ensure the Set Frequency menu is displayed and that the MHz digits are highlighted. Press the switch.

3. Turn the switch clockwise to increase frequency, or anti-clockwise to decrease frequency. The MHz value increments/decrements in 1 MHz steps. Stop when the required value is shown. Press the switch.

4. Turn the switch clockwise to highlight the kHz digits and press the switch. Turn the switch clockwise to increase frequency, or anti-clockwise to decrease frequency (note that continuous scrolling of the kHz value will increment or decrement the MHz value). Stop when the required value is shown. Press the switch. Note that if 25 kHz channel spacing is selected, the kHz value increments/decrements in 25 kHz steps; if 8.33 kHz channel spacing is selected, the kHz value increments/decrements in the pattern detailed in ‘table 2-3, Front Panel Display for 25 kHz and

8.33 kHz Channel Spacings’ on page 21. If both is selected, the display shows the 25 kHz and

8.33 kHz channels.

5. Turn the switch clockwise until either Cancel or OK is highlighted. Then press the switch. If cancel is selected, the new frequency entered in this procedure is ignored. If OK is selected, the transmitter operates on the new frequency.

Section 2 T6T AM-Voice Operation Page 34

Frequency

Channe l

Con f i gu r e

BIT Exi t

121 . 500MHz

C ance l OK

ALLOCATING CHANNEL NUMBERS TO SPECIFIED FREQUENCIES

Up to 100 frequency channels can be stored in the transmitter. Use the following procedure to allocate frequency channels.

1. From the Main screen, press the switch to display the Options menu. Turn the switch until Channel is highlighted. Press the switch.

2. Ensure the Channel menu is displayed. Turn the switch until Set is highlighted. Press the switch.

3. Ensure the Channel screen is displayed and turn the switch until the channel number is highlighted. Press the switch, then turn the switch until the required channel number is displayed. When it is, press the switch.

4. Turn the switch to highlight the MHz value, then press the switch. Turn the switch until the required value is displayed, then press the switch. Repeat for the kHz value.

5. When the correct frequency for the displayed channel number is displayed, turn the switch until Store is highlighted, then press the switch.

6. Repeat steps 3 to 5 for all frequency channels that are to be stored. When the required number of frequency channels have been stored, highlight Store and End and press the switch. You will be returned to the Main screen.

T6T AM-Voice Operation Section 2

Page 35

Ch001 119. 100MHz

Reca l l

Store

Store and End

Ch001 119. 100MHz

Reca l l

Store

Store and End

Ch007 123. 450MHz

Reca l l

Se t

Back

Frequency

Channe l

Con f i gu r e

BIT Exi t

The process of allocating frequency channels can be simplified by using the VFP.

The VFP software is contained in the T6T transmitter's maintenance kit.

TO RECALL CHANNEL FREQUENCIES

Frequency channels that have been stored in the transmitter can be recalled by channel number as follows.

1. From the Main screen, press the switch to display the Options menu. Turn the switch until Channel is highlighted. Press the switch.

2. Ensure the Channel menu is displayed. Turn the switch until the channel number is highlighted. Press the switch. Turn the switch until the required channel number is displayed. Then press the switch.

3. Turn the switch until Recall is highlighted, then press the switch.

4. The Main screen will then be displayed showing the transmitter's selected channel number and corresponding operating frequency.

Section 2 T6T AM-Voice Operation Page 36

Frequency

Channe l

Con f i gu r e

BIT Exi t

Ch007 123. 450MHz

Reca l l

Se t

Back

Ch007 123. 450MHz

Reca l l

Se t

Back

Fr eq 123 . 450MHz

Chan 7

Pw r

TO INITIATE AN INTERRUPTIVE BIT TEST

Use the following procedure to initiate an interruptive BIT test from the transmitter's front panel. A BIT test cannot be initiated while the transmitter is keyed.

1. From the Main screen, press the switch to display the Options menu. Turn the switch until BIT is highlighted. Press the switch.

2. Ensure the BIT menu is displayed. Turn the switch until BIT Initiate is highlighted, then press the switch.

3. During the test, which takes approximately two seconds, the Testing screen is displayed.

4. When the test has finished, check that the transmitter's front panel Alarm indicator is not lit. After a BIT test, BIT screens are automatically displayed. The screens are shown on the next page.

T6T AM-Voice Operation Section 2

Page 37

Frequency

Channe l

Con f i gu r e

BIT Exi t

BIT Ini t iate

BIT View

Back Ex i t

Test ing

Pl ease Wa i t

During an interruptive BIT test, the transmitter radiates a modulated carrier wave. Users

should therefore obtain the necessary authority before initiating a test.

Users should ensure a load is connected to the transmitter's antenna connector,

and note that the BIT circuits apply a signal to the audio input lines during a test.

TO VIEW BIT PAGES AND ADVISE SCREEN

Use the following procedure to view the BIT page displays. Note that after a BIT interruptive test, the BIT screens are automatically displayed.

1. From the Main screen, press the switch to display the Options menu. Turn the switch until BIT is highlighted. Press the switch.

2. Ensure the BIT menu is displayed. Turn the switch until BIT View is highlighted, then press the switch.

3. A series of pages is shown displaying certain transmitter parameters. Some examples are shown here.

A full list of BIT screens along with appropriate explanations is given in the T6T transmitter maintenance handbook.

4. Note that the last BIT screen allows Advise to be highlighted and selected by pressing the switch. If any BIT faults have been detected, the advise screen recommends the remedial action, in order of priority, to be taken.

Further detail regarding the Advise screen is given in the T6T transmitter maintenance handbook.

Section 2 T6T AM-Voice Operation Page 38

Frequency

Channe l

Con f i gu r e

BIT Exi t

BIT Ini t iate

BIT View

Back Ex i t

AC Supp l y ON

DC Supp l y OFF

Supp l y 31V

Example BIT Screen

Syn t h Lock PASS

PA Temp 3 0

PA Temp PASS

<< >>

Example BIT Screen

Advise

Back

Last BIT Screen

Pl ease Check

1:Antenna

2:PA Ctr l .

Example Remedial Advise Screen

ELAPSED TIME INDICATOR

An elapsed time indicator (ETI) shows the number of hours the transmitter has been powered up since manufacture. To view the ETI:

1. From the Main screen, press the switch to display the Options menu. Turn the switch until BIT is highlighted. Press the switch.

2. ETI can be seen measured in hours and minutes.

T6T AM-Voice Operation Section 2

Page 39

Frequency

Channe l

Con f i gu r e

BIT Exi t

BIT Ini t iate

BIT View

ET I 00123:59

Back Ex i t

DISPLAYING THE TRANSMITTER'S INTERNAL REFERENCE FREQUENCY SCREEN

To display the transmitter's internal reference frequency screen, use the following procedure.

1. From the Main screen, press the switch to display the Options menu. Turn the switch until Configure is highlighted. Press the switch.

2. Ensure the Configure menu is displayed. Turn the switch until Settings is highlighted, then press the switch.

3. Check that the Function menu is displayed and turn the switch until Reference Freq is highlighted. Press the switch.

4. Ensure the Reference menu is displayed.

5. To exit the screen, wait for 30 seconds when the display automatically reverts to the Main screen, or select Cancel.

Section 2 T6T AM-Voice Operation Page 40

Frequency

Channe l

Con f i gu r e

BIT Exi t

Se t t i ngs

S/W Versions

St andby

Back Ex i t

Mod e

Reference Freq

Display

Ref Freq 50.0%

Cance l OK

Caution!

This procedure is included only for informational purposes. The reference frequency setting must not be altered unless following the procedure given in the T6T maintenance handbook. External test equipment is required to set this parameter.

Failure to comply with this caution may render the transmitter inoperable.

SOFTWARE VERSIONS SCREEN

The software versions screen allows the user to view the version of various software modules installed in the transmitter. To view the software versions, use the following procedure.

1. From the Main screen, press the switch to display the Options menu. Ensure that Configure is highlighted. Press the switch.

2. Ensure the Configure menu is displayed. Turn the switch until S/W Versions is highlighted, then press the switch.

3. Check the Software Versions screen is displayed. Select Boot, Flash, or Fills and press the switch to display the installed version. The example shows the Boot software.

4. Select OK, then press the switch to return to the Software Versions screen. View the other software modules as required.

T6T AM-Voice Operation Section 2

Page 41

Frequency

Channe l

Con f i gu r e

BIT Exi t

Options Menu

Se t t i ngs

S/W Versions

St andby

Back Ex i t

Configure Menu

Boo t

Flash

Fills

Back Ex i t

Software Versions Screen

Boot Version

S0271V0001

Boot Version Screen

Park Air T6T User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
