Parasound 5250 User Manual

Model 5250 v.2

Five Channel Amplifier

IMPORTANT SAFETY INSTRUCTIONS

The lightning flash with the arrowhead symbol within an equilateral triangle is intended to alert
the user to the presence of “dangerous voltage” inside the product that may constitute a risk
of electric shock.

The exclamation point within an equilateral triangle is intended to alert the user to the presence
of important operating and maintenance instructions in the literature accompanying the product.

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL

1. Read Instructions — Read all the safety and operating instructions before operating this product.

2. Retain Instructions — Retain safety and operating instructions for future reference.

3. Heed Warnings — Adhere to all warnings on the product and in the operating instructions.

4. Follow Instructions — Follow all operating and use instructions.

5. Cleaning — Unplug this product from the wall outlet before cleaning. Use a damp cloth for cleaning.
Clean the outside of the product only.

6. Attachments — Do not use attachments that are not recommended by the product manufacturer;
they may be hazardous.

7. Water and Moisture — Do not use this product near water.

8. Accessories — Do not place this product on an unstable cart or stand. The product may fall, causing
bodily injury and damage to the product. A product and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the product and cart to overturn.

9. Ventilation — Slots and openings in the cabinet are provided for ventilation to ensure reliable opera-
tion of the product and to protect it from overheating. These openings must not be blocked or
covered. This product should not be placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided.

10. Power Sources — Operate this product only from the type of power source indicated on the label.
If you are not sure of the type of power supply to your home, consult your dealer or local power
company. This product is equipped with a three-prong grounding plug. This plug will only fit into a
grounding power outlet. If you are unable to insert the plug into the outlet, contact your electrician
to replace your obsolete outlet. Do not defeat the safety purpose of the grounding plug.

11. Power Cord Protection — Power supply cords should be routed so that they are not likely to be
walked on or pinched by items placed upon or against them.

12. Lightning — Unplug the unit from the wall outlet for added protection during a lightning storm
and when it is left unattended and unused for long periods of time. This will prevent damage to the
product due to lightning and power line surges.

13. Overloading — Do not overload wall outlets or extension cords. This can result in a fire or electric shock.

14. Inserting Objects into Unit — Never push objects of any kind into this product through any openings;
they may touch dangerous voltage points or short out parts that could result in fire or electric shock.

15. Servicing — Do not attempt to repair or service this product yourself. Opening or removing covers may
expose you to dangerous voltage and other hazards. Refer all servicing to qualified service personnel.

16. Damage Requiring Service — Unplug this product from the wall outlet and refer servicing to quali-
fied service personnel under the following conditions: a) If the power-supply cord or plug is damaged.
b) If liquid has been spilled into the product. c) If the product has been exposed to rain or water. d)
If the product does not operate normally by following the operating instructions. e) If the product has
been dropped or damaged in any way. f) If the product exhibits a distinct change in performance.

17. Replacement Parts — When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer. Unauthorized substitutions may result in fire, elec­tric shock, and other hazards.

18.

Safety Check — Upon completion of any service or repairs to this product, ask the service technician
to perform safety checks to determine that the product is in proper operating condition.

19. Wall or Ceiling Mounting — Mount the product to a wall or ceiling only as recommended.

20. Heat — The product should be situated away from heat sources such as radiators, heat registers,
stoves, and other products (including amplifiers) that produce heat.

www.parasound.com

TABLE OF CONTENTS

Introduction .................................................... 2

1

AC Voltage

Ventilation Requirements

Rack Mounting

..................................................... 3

........................................... 3

................................................. 3

Rear Panel Connections and Controls

Front Panel buttons and display

Typical Problems and Remedies

If You Require Assistance

Warranty Repair

................................................. 10

........................................ 8

........................................ 9

............................................ 10

................................... 4

Specifications

.................................................. 11

2

OWNERSHIP REFERENCE INFORMATION

Parasound Serial Number:

Date of Purchase: / /

Name of Dealer:

Dealer Street Address:

Dealer Phone: ( ) -

INTRODUCTION

Congratulations and thank you for your purchase of this precision Parasound audio component.

The Parasound Model 5250 v.2 is the latest generation of popular and proven audio power
amplifiers dating back to 1981. It has been designed for a wide variety of applications, establishing
a new standard for audio performance, user-friendliness and utility in custom installations.

The versatility of the Model 5250 v.2 allows many connection and configuration options, so
please be sure to read this manual thoroughly before you begin installation

Unpacking

Carefully unpack your Model 5250 v.2 and these accessories:

•

Detachable AC power cord

•

Trigger wire with a 3.5 mm mini plug at each end

Please inspect the unit now and contact your Parasound Dealer promptly if you see evidence

of shipping damage. Save the carton and packing inserts in case you move or in the event you
need to ship your amplifier for repair. Before you proceed, locate the serial number on the rear
panel or underside of the unit and record it here for future reference:

AC VOLTAGE, INSTALLATION AND RACK MOUNTING

115v – 230v AC Voltage

110–120V is the typical AC voltage in North America; most other countries supply 220–240V.
The 5250 v.2 is internally wired for either 115V or 230V, according to where you purchased it
and the voltage that is marked on its carton. If you plug a unit that is wired for 115V into a 230V
outlet it can damage it.

Note: Only a qualified repair technician should make AC voltage conversions.
For your own safety, please do not attempt this yourself!

Installation and Ventilation Requirements

Install your Model 5250 v.2 away from heat sources such as heating ducts, radiators, or other
heat producing components. Always position it horizontally.

Observe the following ventilation guidelines when installing the Model 5250 v.2 in an
equipment rack or any other enclosed space:

You should never install the Model 5250 v.2 in an unventilated equipment cabinet or compartment
because hot air will not exhaust adequately to prevent overheating. Air won’t often circulate
adequately in a cabinet or enclosure whose front and back sides are open; pockets of intense
heat can still develop around any heat-producing equipment. Therefore, a ventilation fan is highly
recommended. Allow a few inches of empty space on each side and above the unit and try to
avoid crowding or stacking the Model 5250 v.2 tightly between other components. A ventilation
fan is also recommended where other equipment must be mounted close to the Model 5250 v.2.

Do not place the unit on carpeting or any other material that could obstruct air flow into the
ventilation holes in its chassis bottom.

3

Rack Mounting

The Model 5250 v.2 occupies four rack spaces in a standard 19” equipment rack.

For rack mounting, you must use the Parasound RMK44 rack mounting kit (purchased separately).
We recommend that you use the 8 insulated shoulder washers with the four mounting bolts
which are included with the RMK44. This eliminates metal-to-metal contact between the Model
5250 v.2 chassis, the equipment rack, and the other components in the rack. Position these
washers on both sides so they “sandwich” the front panel before the mounting bolts are
screwed into the rack rail.
