The Omnia Wireless Receiver Module (OMN-RCV3) allows you to add up to 8 fully
supervised Omnia wireless motion detectors and/or door contacts, and up to 8
programmable remote controls to the Spectra system.
1.1 TECHNICAL SPECIFICATIONS
• Di-pole antenna
• Error Correction Algorithm
• Code-Hopping Technology
• Frequency: 433 MHz
• Range (line of sight): PIRs & door contacts = 500ft (150m)
remote controls = 300ft (100m)
• Sensitivity: -120 dBm
• Current consumption: 50 mA
• Dimensions (no antenna): 15cm H x 16cm L x 3cm W
(6in H x 6.5in L x 1.1in W)
• Operating temperature: 0°C to 50°C (32°F to 122°F)
• Operating humidity: 85%
• Approvals:
1.2 SYSTEM FEATURES
• Auto-Panel Recognition
• Add 8 wireless motion detectors and/or door contacts to the Spectra system
• Add 8 remote controls to the Spectra system
• Reflow design
• On-board tamper switch
• Full system supervision (check-in, low battery and tamper)
• Transmitter signal strength indicator
Omnia 3
The following sections will detail how to mount and connect the Omnia Wireless
Receiver Module (OMN-RCV3).
2.1 LOCATION
Mount the Omnia Wireless Receiver on a wall allowing at least 5cm (2”) around the
module to permit adequate ventilation and heat dissipation. Select a site that is not
susceptible to drastic temperature changes. Avoid installation near or in the path of
strong RF fields (i.e. neon lights, computers), on or near metal objects, circuit
breaker boxes, air conditioners, and heater ducts since they may cause interference
and reduce the module’s sensitivity. We recommend installing the module in a
centralized location on the main floor. Avoid installing the module in the basement.
Refer to the appropriate Spectra Reference & Installation Manual for maximum
allowable distances between the control panel and the Wireless Receiver Module.
2.2 CONNECTIONS AND MOUNTING
Firmly screw the antenna into the connector marked "
as shown in Figure 2.1 on page 5. Using a drill or screwdriver, punch out the four
mounting holes on the back of the plastic case. Align the six holes of the printed
circuit board with the six pins on the bac k plastic mounting c ase and s nap int o plac e.
If placed correctly, the antenna will lean directly over the groove in the mounting
case.
ANT
" on the Receiver Module
Do not cut, bend, or alter the antenna.
Module near or on metal as this may affect the module’s sensitivity.
Do not connect more than one OMN-RCV3 module to the control panel.
The OMN-RCV3 does not function with the 1758/1758EX Spectra
control panel.
The Omnia Wireless Receiver Module is connected to the Spectra control panel's
communication bus in a star or daisy chain configuration. Refer to Figure 2.1 on
page 5.
4 Reference & Installation Manual
Avoid mounting the Receiver
Figure 2.1: Connecting the OMN-RCV3 to the control panel
Omnia 5
To successfully install an Omnia wireless system to your Spectra system, ensure
that the following steps are completed:
1. Install the Omnia Receiver. Connect the Omnia Receiver to the Spectra control
panel and power up.
2. Assign the remote controls if necessary.
3. Assign the transmitters (door contacts and motion detectors), and program t heir
zones.
4. Install the transmitters. Insert the batteries, and close the transmitter cover .
5. Wait for the control panel to be in “ready” mode. The status light on the keypad
will be green when the control panel is ready.
6. In order to ensure proper synchronization between the transmitters and receiver,
open and close the transmitters’ covers and zones.
3.1 HOW TO ENTER PROGRAMMING MODE
Programming of the OMN-RCV3 is done in Programming Mode through any keypad
connected to the Spectra control panel.
How to ente r programmi ng mode.
ENTER
]
1. Press the
2. Enter your
3. Enter the
[
[
SECTION NUMBER
[
4. Enter the required
button.
INSTALLER CODE
DATA
[
].
]
(default = 000000).
]
you wish to program.
The OMN-RCV3’s programming guide can be found in the appropriate
Spectra Programming Guide.
3.2 WIRELESS TRANSMITTER PROGRAMMING
The programming of the wireless transmitters (detectors and door contacts) is
accomplished in two steps:
1. Assigning the detectors and door contacts to the Wireless Receiver Module.
2. Programming the zones in the Spectra control panel.
6 Reference & Installation Manual
3.2.1 A
SSIGNING DETECTORS AND DOOR CONTACTS TO THE RECEIVER
SECTIONS
[601]
TO
[608]
In Spectra systems, up to 8 wireless transmitters (detectors and door
contacts) can be assigned to each Receiver Module. Section [601] to [608]
represent expansion inputs 1 to 8 respectively. For example, section
assigned to expansion input 1, section
[602]
is assigned to expansion input 2,
etc. (refer to Table 3.1). Each Expansion Input represents a specific zone in
the system depending on the type of Spectra control panel being used and
whether the ATZ option is enabled (refer to the appropriate Spectra control
panel Programming Guide).
T ab le 3.1: Sections and Expansion Inputs
Section # 6-digit Serial Number Expansion Input
[601]
[602]
[603]
[604]
[605]
[606]
[607]
[608]
___/___/___/___ /___/_ __ Input 1
___/___/___/___ /___/_ __ Input 2
___/___/___/___ /___/_ __ Input 3
___/___/___/___ /___/_ __ Input 4
___/___/___/___ /___/_ __ Input 5
___/___/___/___ /___/_ __ Input 6
___/___/___/___ /___/_ __ Input 7
___/___/___/___ /___/_ __ Input 8
[601]
is
How to assign detectors & door contacts to the receiver module.
In step 3 in section 3.1 on page 6:
1. Enter the desired
SECTION NUMBER
[
]
(601 to 608).
2. Enter the 6-digit serial number of the detector or door contact.
Do not assign detection devices from different modules to the same
expansion input. Fo r e x ample , do not assign a wir eles s t ransm itte r
to section [601], then c onnect a det ection devi ce to inpu t Z1 of the
APR3-ZX8.
Omnia 7
The serial number is located on the ins ide of the tr ansm itte r or y ou
can use the Unknown Serial Number Display method (refer to
section 3.4 on page 10) to determine its serial number.
The transmitters must be activated once having been ass igned to
the Receiv er . T o ac tivat e a trans mitt er , inser t the batte ries an d clos e
the cover. To ensure proper synchronization between the receiver
and the transmitter, open and close t he zon e correspondi ng to t he
transmitter.
3.2.2 D
ELETING THE DETECTORS AND DOOR CONTACTS
SECTIONS
[601]
TO
[608]
How to delete the assigned transmitters.
In step 3 in section 3.1 on page 6:
1. Enter the desired
2. Press the
3.2.3 P
ROGRAMMING THE ZONES IN THE SPECTRA CONTROL PANEL
FORCE
[
SECTION NUMBER
[
]
button six times to clear the serial number.
]
(601 to 608).
The zones allocated to the wireless transmitters must be programmed in the
Spectra control panel. Refer to the appropriate Spectra Reference &
Installation Manual for instructions on programming the zones.
3.3 VIEWING THE TRANSMITTER SIGNAL STRENGTH
SECTIONS
Once the detectors and/or door contacts have been installed and assigned to t he
Receiver Module, the signal strength of each transmitter can be verified in sections
[631] to [638]. Each section represents the signal strength viewer for a specific
device. For example, section
section
feature will only work with wireless transmitters that have already been assigned to
an Expansion Input (zone) as described in section 3.2.1 on page 7. A reading of 1 is
the weakest and a reading of 8 is the strongest. An average reading of 3 and up is
[631]
[638]
[638]
TO
[631]
is the viewer for the device in section
is the viewer for the device in section
[608]
. Please note that this
[601]
and
8 Reference & Installation Manual
acceptable. Sometimes moving the transmitter or receiver by a small amount will
greatly increase the signal reception.
How to view a transmitter’s signal strength.
In step 3 in section 3.1 on page 6:
1. Enter the desired
SECTION NUMBER
[
]
(631 to 638).
2. Press the transmitter’s tamper switch, or open the corresponding zone.
On an LED keypad:
The keypad will illuminate numbers 1 to 8.
On an LCD keypad:
The keypad will display from 1 to 8 characters on the
screen. For example, in the figure below the LCD screen shows a signal
strength reading of 5.
After entering the desired sect ion, ignore the first reading as it will not be
accurate.
You can also use the OMN-RCV3’s beep sequence feature to verify a transmitter’s
signal strength. When you press a transmitter’s tamper switch, beep tones
emanating from all the keypads connected to the communication bus will advise you
of the transmitter’s signal strength.
How to attain a transmitter’s signal strength using the beep sequence.
1. Press the transmitter’s tamper switch.
2. Listen for the beep tones:
If the signal strength is less than 3 = One beep
If the signal strength is between 3 and 6 = Two beeps
If the signal strength is greater than 6 = Three beeps
Omnia 9
3.4 VIEWING UNKNOWN SERIAL NUMBERS
ECTION
S
[630]
This feature will display the serial number of any Omnia motion detector or door
contact on any Spectra keypad.
How to view unknown transmitter serial numbers.
In step 3 in section 3.1 on page 6:
1. Enter section
[630]
.
2. Press the tamper switch of any Omnia wireless motion detector or door
contact. When the signal has been received, the keypad will emit a
confirmation beep (“Beep-Beep-Beep-Beep-Beep”).
On an LED Keypad:
3.
The serial number digits will appear one at a time by
illuminating the corresponding LED light. To view the next digit press the
ENTER
[
]
On an LCD Keypad:
ENTER
[
the
button.
The first 3 digits of the serial number will appear. Press
]
button 3 times to view the next 3 digits.
3.5 SYSTEM RESET
Refer to the appropriate Spectra Reference and Installation Manual.
4.1 CHECK-IN SUPERVISION
ECTION
S
[610]
Option [1] enables the Check-in Supervision feature. The Wireless Receiver Module
waits for each of its assigned detectors and/or door contacts to send a status signal
within a specified time period (as programmed in section 4.2) to confirm their
presence and functionality. If a device has not sent a signal within that time period,
the Wireless Receiver Module will transmit a supervision loss signal to the control
panel. The control panel can then generate a trouble, an alarm, and/or c an transmit
10 Reference & Installation Manual
: O
PTION
[1]
a report code to the monitoring station. For details refer to the appropriate Spectra
Reference & Installation Manual
.
How to enable check-in supervision.
In step 3 in section 3.1 on page 6:
1. Enter section
2. Enable or disable option
[610]
Option [1]
.
[1]
.
OFF
= Check-In Supervision disabled (default)
Option [1] ON = Check-In Supervision enabled
4.2 CHECK-IN SUPERVISION TIMER SETTINGS
ECTION
S
[610]
Options [2] and [5] define the time period that must elapse before the Omnia
transmitters send a status signal to the Wireless Receiver M odule. For example, if
the timer is set to 12 min (opt ion [ 5]=off ; option [ 2]= on), the transmitters will send a
status signal every 12 minutes to the Receiver Module. If the OMN-RCV3 does not
receive a signal from one of its wireless transmitters within the period defined here, it
can send a Supervision Loss signal to the cont rol panel. R efer to section 4.1 for
instructions on enabling check-in supervision.
How to set the check-in supervision timer.
In step 3 in section 3.1 on page 6:
1. Enter section
2. Enable or disable options
: O
PTIONS
[610]
[2]
.
AND
[5]
[2] & [5]
Option [2]
OFF
= hours (default)
Option [2] ON = minutes
Option [5]
OFF
= 12 (default)
Option [5] ON = 6
.
The assign ed tr an smitters must be set to the same C h eck-In timer setting
as the Receiver. For example, if the Receiver Check-In timer is set at 12
hours, the transmitters’ Check-In timers must also be 12 hours.
Omnia 11
4.3 LOW BATTERY SUPERVISION
When the battery voltage of an Omnia wireless transmitter (motion detector or door
contact) drops to less than 3.1V, the Spectra control panel will send a low battery
report code to the monitoring station, and a trouble will appear in the keypad’s
trouble display.
4.4 ON-BOARD MODULE TAMPER SUPERVISION ZONE ASSIGNMENT
ECTION
S
The OMN-RCV3 comes equipped with an on-board tamper switch. This feature will
allow a module tamper to report through one of the module’s Expansion Inputs
(zone). When a tamper is detected on the module, it will send a Zone Tamper report
code to the control panel via the communication bus. The Zone Tamper report code
will originate from the zone defined by the Expansion Input (
programmed in section
programmed (refer to the appropriate Spectra Reference & Installation Manual for
more details).
For example, when you program 003 (Expansion Input 3) in section
Spectra 1728 panel with the ATZ feature enabled, and a tamper occurs on the OMNRCV3 module, the control panel will transmit the Zone Tamper report code as
originating from zone 15
[615]
:
001-008
[615]
. Please note that the corresponding zone must be
) you have
[615]
of a
.
If you Enable the OMN-RCV3’s tamper switch in section [615], the tamper
switch will occupy one of the zones.
How to assign the Receiver’s tamper switch to a zone.
In step 3 in section 3.1 on page 6:
1. Enter section
2. Enter an
[615]
.
INPUT NUMBER
[
]
(001-008).
000=Disabled (default)
12 Reference & Installation Manual
The Omnia Wireless Receiver Module accepts up to eight fully programmable
remote controls. Programming the remote controls is accomplished in three steps:
1. The remote controls must be assigned to the Wireless Receiver Module.
2. The remote controls from the Wireless Receiver Module must be assigned to
User Access Codes.
3. The buttons on the remote controls must be programmed.
In Spectra systems, sections
[718]
are all interrelated. For example, when assigning a remote control to the
Receiver Module:
1. The remote control is assigned using the Automatic Learning method in sec tions
[721]/[731]
2. The remote control is assigned to User Access Codes in sections
3. The remote control’s buttons are programmed in sections
The remote control will transmit a signal for only 1 second when a button is
pressed. This is done to conserve the remote control’s batteries.
[728]/[738]
to
[721]/[731]
.
[728]/[738], [701]
to
to
[711]
[708]
to
, and
[701]
[718]
to
.
[711]
[708]
to
5.1 ASSIGNING A REMOTE CONTROL TO THE RECEIVER MODULE
ECTIONS
S
Remote controls are assigned to the module using the Automatic Learning method.
Depending on which Spectra system version you are using, the automatic learning
method differs.
For installations using a Spectra control panel version 1.23 or lower:
How to assign a remote control to the receiver module (V1.23 and lower).
In step 3 in section 3.1 on page 6:
1. Enter the desired
2. Enter
3. Press any button on the remote control twice, or until you hear three
[721] / [731]
[111111]
consecutive rejection beeps (“Beeeeeeeeeeeeeeep”).
[728] / [738]
TO
SECTION NUMBER
[
. A rejection beep will sound, and it will exit the section.
]
(721 to 728).
.
Omnia 13
For installations using a Spectra control panel version 2.0 or higher:
How to assign a remote control to the receiver module (V2.0 and higher).
In step 3 in section 3.1 on page 6:
1. Enter desired
SECTION NUMBER
[
]
(731 to 738).
2. Press any button on the remote control twice, or until the confirmation beep
sounds (“Beep-Beep-Beep-Beep-Beep”).
If you are having trouble a ssigning the remote control, the environment
may be too noisy. Therefore, we re commend that you ass ign the remote
controls before installing the detectors and door contacts.
5.2 ASSIGNING THE REMOTE CONTROLS TO USER ACCESS CODES
ECTIONS
S
Each remote control must be assigned to a User Access Code. All User Access Codes
are given a User Number from 001 to 048. E nter the des ired U s er Number in a section
from
[728]/[738]
in section [731] will be assigned to the User Access Code designated in section [701].
How to assign a remote control to a user access code.
In step 3 in section 3.1 on page 6:
1. Enter the desired
2. Enter the User Number to be assigned to the remote control (001 to 048).
[701]
[701] to [708]
[708]
TO
:
that represent the remote control assigned in sections
(refer to section 5.1 on page 13). For example, the remote control assigned
SECTION NUMBER
[
]
(701 to 708).
[721]/[731]
to
5.3 PROGRAMMING THE REMOTE CONTROL BUTTONS
ECTIONS
S
Each remote control can be programmed to send a signal to the control panel to perform
up to 8 different actions. Each digit in sections [711] to [718] represents a button or
combination of buttons (refer to Table5.1 on page 15). When a user arms or disarms
using the remote control, the control panel will ar m or disarm
the User Access Code. For example, you arm with a remote control whose User Access
Code is assigned to areas 1 and 2, the control panel will attempt to arm areas 1 and 2.
14 Reference & Installation Manual
[711]
TO
[718]
all
the areas assigned to
Sections
[731]
the remote control assigned in section
[711] to [718]
[728]/[738]
to
represent the remote controls assigned to sections
(refer to section 5.1 on page 13). For example, the buttons for
[731]
will be programmed in section
How to program the remote control buttons:
In step 3 in section 3.1 on page 6:
1. Enter the desired
SECTION NUMBER
[
]
(711 to 718).
2. Enter the hexadecimal value (0 to D) of the desired options from T able5.2 on
page 16 in the appropriate space (refer to Table 5.1 on page 15). If you do
not wish to program all the buttons or button combinations, simply press the
ENTER
]
[
button at any time to save and exit.
FORCE
[
Note: Press the
]
button 8 times, that is, once for every button or
button combination.
T ab le 5.1: Remote Control Button Programming
Remote Control Button Programming (refer to Table 5.2)
Section
[711] ____/____/____/____/____/____/____/____
A B C D A+B C+D A+C B+D
[712] ____/____/____/____/____/____/____/____
A B C D A+B C+D A+C B+D
[713] ____/____/____/____/____/____/____/____
A B C D A+B C+D A+C B+D
[714] ____/____/____/____/____/____/____/____
A B C D A+B C+D A+C B+D
[715] ____/____/____/____/____/____/____/____
A B C D A+B C+D A+C B+D
[716] ____/____/____/____/____/____/____/____
A B C D A+B C+D A+C B+D
[717] ____/____/____/____/____/____/____/____
A B C D A+B C+D A+C B+D
[718] ____/____/____/____/____/____/____/____
A B C D A+B C+D A+C B+D
remote control #1
remote control #2
remote control #3
remote control #4
remote control #5
remote control #6
remote control #7
remote control #8
[721]
[711]
/
.
Omnia 15
T ab le 5.2: Button Options
[0] = Not used [7] = Regular Arm and Disarm
[1] = Regular Arm [8] = Generate a Panic 1 Alarm (Police)
[2] = Stay Arm [9] = Generate a Panic 2 Alarm (Medical)
[3] = Instant Arm [A] = Generate a Panic 3 Alarm (Fire)
[4] = Force Arm [B] = Activates any PGMs that have Event Group #07 as
their Activation Event
[5] = Disarm [C] = Activates any PGMs that have Event Group #08 as
their Activation Event
[6] = Disarm when
there is no alarm
[D] = Activates any PGMs that have Event Group #09 as
their Activation Event
Table 5.3: Decimal & Hexadecimal Programming Tab le
Value or Action
What Do I
Press?
Values 1 to 9 [1] to [9]
10-Zone LE D 16-Zone LE D LCD
[1] to [9] [1] to [9] [1] to [9]
What Do I See?
A (hexa only) [0] [0 (10)] [10] 0
B (hexa only) [
C (hexa only) [
D (hexa only) [
E (hexa only) [
F (hexa only) [
TBL
PG
Exit Without
Saving
Insert Blank
STAY
][
BYP
][
MEM
][
TRBL
] / [
] / [
CLEAR
[
FORCE
[
][
FNC
1] [PG] [15] F
][
] Displays next digit or next section
STAY
][11] B
BYP
] [12] C
MEM
] [13] D
TBL
] [14] E
ENTER
flashes
]
STAY
[
ARM
[
1] &
1] flash
“SECTION [ ]”
Digit
ENTER
Save Data [
] Advances to the next section
16 Reference & Installation Manual
Figure 5.4: Remote Control Button Identification
The User Code assigned to the remote control (refer to section 5.2 on page
14) must h ave the same User Opti o n s enabled. For example, if you e n ab l e
the Force Arming button option, you must enable the app ropriate Force
Arming user option. Also, if y ou enable any Panic button options, you
must enable the Panic options in the Spectra con trol panel (refer to the
appropriate Spectra Reference & Installation Manual).
5.4 DELETING REMOTE CONTROLS
ECTIONS
S
For installations using a Spectra control panel version 1.23 or lower:
How to delete a remote control (Spectra version 1.23 or lower):
In step 3 in section 3.1 on page 6:
1. Enter the desired
2. Enter
[721]/[731]
[000000]
[728]/[738]
TO
SECTION NUMBER
[
.
]
(721 to 728).
Omnia 17
For installations using a Spectra control panel version 2.0 or higher:
How to delete a remote control (Spectra version 2.0 or higher):
In step 3 in section 3.1 on page 6:
1. Enter the desired
FORCE
2. Press the
[
SECTION NUMBER
[
]
button.
]
(731 to 738).
5.5 REPLACING THE REMOTE CONTROL BATTERIES
How to replace the remote control batteries.
1. Remove the two screws from the back of the remote control and remove the
back cov e r.
2. Remove the old batteries from inside the remote control.
3. Replace with two 3V lithium batteries (CR2016) ensuring proper polarit y. The
positive of the batteries is inserted face down.
4. Set the back cover in place, and fasten it with the two screws.
18 Reference & Installation Manual
Section Description
[601]
[631]
[701]
[711]
[721]
[731]
to
[610]
[615]
[630]
to
to
to
to
to
[608]
[638]
[708]
[718]
[728]
[738]
- Assigning detectors and door contacts to the receiver
- Deleting the detectors and door contacts
Option [1]: Check-in supervision
Option [2]: Check-in supervision base time
Option [5]: Check-in supervision time value
On-board module tamper supervision zone assignment
Viewing unknown serial numbers
Viewing the detector and door contact signal strengths
Assigning the remote controls to user access codes
Programming the remote control buttons
- Assigning a remote control to the receiver
For Spectra versions 1.23 or lower
For Spectra versions 2.0 or higher
-
Deleting a remote control
Omnia 19
WARRANTY
The Seller warrants its products to be free from defects in materials and
workmanship under normal use for a period of one year. Except as specifically
stated herein, all express or implied warranties whatsoever, statutory or otherwise,
including without limitation, any implied warranty of merchantability and fitness for a
particular purpose, are expressly excluded. Because Seller does not install or
connect the products and because the products may be used in conjunction with
products not manufactured by Seller, Seller cannot guarantee the performance of
the security system. Seller obligation and liability under this warranty is expressly
limited to repairing or replacing, at Seller's option, any product not meeting the
specifications. In no event shall the Seller be liable to the buyer or any other person
for any loss or damages whether direct or indirect or consequential or incidental,
including without limitation, any damages for lost profits, stolen goods or claims by
any other party caused by defective goods or otherwise arising from the improper,
incorrect or otherwise faulty installation or use of the merchandise sold.
20 Reference & Installation Manual
Loading...
