32-Zone Wireless Transceiver Control Panel
MG5000
MG32LED
MG10LEDH
MG32LRF
MG10LEDV
User’ s Guide
Access Codes
How do I program Access Codes?
1. Press the [] key. Enter your [SYSTEM MASTER CODE] or either [MASTER CODE].
2. The [] key will flash. When a zone LED or zone key is lit (not flashing), the user is already programmed.
3. Select a user by entering a 2-digit user number (i.e. [0]+[9] for user 9) or use the scroll keys and then press [
corresponding to the user number (i.e. [9] for user 9).
4. Enter a new 4- or 6-digit [
5. Confirm the code.
6. Press a button on the designated remote or press [
7. (Partitioned system only) Press [1] and/or [2] to assign the user to a partition. Press [
For security reasons, write only the user’s name and not his or her access code. 4-Digit Codes N 6-Digit Codes N
User # and Name Partition 1 or 2 Byp Stay Force Arm Only PGM Only Duress
ACCESS CODE].
ENTER] to skip if there is no remote to program.
ENTER], the menu will now jump to the next available user.
ENTER]. For the MG10LEDV/H, press the key
001: Master_______________________________ 1 & 2
002: Master1______________________________ 1
003: Master2______________________________ 2
004:_____________________________________ ____ NNNNNDuress: Y N N N
005:______________________________________ ____ NNNNNDuress: Y N N N
006:______________________________________ ____ NNNNNDuress: Y N N N
007:______________________________________ ____ NNNNNDuress: Y N N N
008:______________________________________ ____ NNNNNDuress: Y N N N
009:______________________________________ ____ NNNNNDuress: Y N N N
010:______________________________________ ____ NNNNNDuress: Y N N N
011:_______________________________________ ____ NNNNNDuress: Y N N N
012:______________________________________ ____ NNNNNDuress: Y N N N
013:______________________________________ ____ NNNNNDuress: Y N N N
014:______________________________________ ____ NNNNNDuress: Y N N N
015:______________________________________ ____ NNNNNDuress: Y N N N
016:______________________________________ ____ NNNNNDuress: Y N N N
017:______________________________________ ____ NNNNNDuress: Y N N N
>>>
>>>
>>>
018:______________________________________ ____ NNNNNDuress: Y N N N
019:______________________________________ ____ NNNNNDuress: Y N N N
020:______________________________________ ____ NNNNNDuress: Y N N
021:______________________________________ ____ NNNNNDuress: Y N N N
022:______________________________________ ____ NNNNNDuress: Y N N N
023:______________________________________ ____ NNNNNDuress: Y N N N
024:______________________________________ ____ NNNNNDuress: Y N N N
025:______________________________________ ____ NNNNNDuress: Y N N N
026:______________________________________ ____ NNNNNDuress: Y N N N
027:______________________________________ ____ NNNNNDuress: Y N N N
028:______________________________________ ____ NNNNNDuress: Y N N N
029:______________________________________ ____ NNNNNDuress: Y N N N
030:______________________________________ ____ NNNNNDuress: Y N N N
031:______________________________________ ____ NNNNNDuress: Y N N N
032:______________________________________ ____ NNNNNDuress: Y N N N
N
Table of Contents
PGM Keys (Programmable Outputs) ............ 10
Power Save Mode........................................... 11
Access Codes............................................................... 0
Overview................................................................. 2
Basic Operations............................................. 2
Auditory Feedback........................................................ 2
Visual Feedback....................................................... .. .. 2
Overview of the Magellan Series Keypads................... 2
Partitioning.................................................................... 3
Access Codes........................................................ 4
Programming Access Codes.......................... 4
System Master Code (Default: 123456) ....................... 4
Master Codes......................... ... ................................... 4
Duress Code................................................................. 4
Programming Access Codes........................................ 4
Arming & Disarming.............................................. 5
Regular Arming................................................ 5
Sleep Arming.................................................... 5
Stay Arming...................................................... 5
Trouble Display .............................................. 11
Trouble List............... ................................................. 11
Advanced Features...............................................
12
Quick Function Keys...................................... 12
Test Report................................................................ 12
Call PC....................................................................... 12
Answer PC................................................................. 12
Cancel Communication.............................................. 12
Testing & Maintenance .................................. 12
System Checklist............................................ 13
Zone Description........................................................ 13
Special Keys and Features........................................ 14
Panic Alarms................................. ... .......................... 14
PGMs......................................................................... 15
PGM Utility Keys........................................................ 15
System Timers........................................................... 15
Other Information....................................................... 15
Delays........................................................................ 17
Communicator............................................................ 17
System Options.......................................................... 17
One-Touch Arming .......................................... 6
One-Touch Regular Arming.......................................... 6
One-Touch Stay Arming............................................... 6
One-Touch Sleep Arming............................................. 6
One-Touch Bypass Programming................................ 6
Fast Exit........................................................................ 6
Auto-Arming..................................................... 7
Timed Auto Arming....................................................... 7
No Movement Auto Arming........................................... 7
Disarming & Deactivating an Alarm............... 7
Manual Bypass Programming....................................... 7
Bypass Recall Feature ................................................. 8
System Features.................................................... 9
Display Mode.................................................... 9
Alarm Display................................................... 9
Fire Alarms....................................................... 9
Minimizing Fire Hazards............................................... 9
Fire Safety Tips ............................................................ 9
Providing a Fire Warning System................................. 9
Panic Alarms.................................................... 9
Master Quick Menu MG5000.......................... 18
Overview.................................................................... 18
User ........................................................................... 18
Programming Chime Zones.......................... 10
Keypad Muting............................................... 10
Keypad Backlight........................................... 10
Overview
Thank you for selecting the Magellan Security System from Paradox Security Systems Ltd. This advanced technology security system
provides you with reliable security protection and powerful features that anyone can use without memorizing complex and confusing
codes. The system consists of the Magellan control panel, one or more Magellan keypad modules, various input devices (i.e. motion
detectors, door contacts, etc.) and various output devices (i.e. bells, sirens, lights, etc.).
The elegant and user-friendly Magellan MG10LEDV/H, MG32LED, and MG32LRF keypad modules allow you to easily access your
security system's functions and provide you with an easy-to-understand display of your security system's alarm and operational status.
All of the actions performed in your security system will be executed and displayed through the keypad. Therefore, before using your
security system, we highly recommend that you read this manual carefully and have your installer explain basic system operation to you.
Basic Operations
Auditory Feedback
When you enter information on the keypad, it will guide you with beep tones that communicate acceptance or rejection of your
entries. You should be familiar with these two keypad beep tones:
Confirmation Beep: When an operation (i.e. arming/disarming) is successfully entered on the keypad or when the system switches
to a new status/mode, the keypad produces an intermittent beep tone (“
Rejection Beep: When the system reverts to its previous status or when an operation is incorrectly entered on the keypad, it will emit
a continuous beep tone (“
BEEEEEEEEP”).
Visual Feedback
Keypad Indicator Lights: All Magellan keypads include coloured lights which convey the current status of your system. The state of
each light represents a specific condition in your system.
BEEP-BEEP-BEEP-BEEP”).
Many of the features in your system must be enabled by the installer. If the feature is not programmed, the keypad will emit a
rejection beep and the action will be cancelled. Refer to System Checklist on page 13 and 14 for details.
Overview of the Magellan Series Keypads
The numbers and keys of the Magellan series keypad’s screen communicate your system’s status.
Figure 1: MG10LEDV (10-zone LED Keypad Module)
Off Light (red):
On = Disarmed
Off = System armed
Fast Flash = Disarmed system in
AC Light
On = Power on
Off = Power off
alarm (e.g. 24hr. zone)
= Press once + [MASTER
CODE] for Quick Menu
Programming)
[TBL] Trouble display
ON = Trouble(s) occurring
[MEM] Alarm memory display
ON = Alarm(s) occurred
[BYP] Bypass programming
ON = Zone(s) bypassed
Partition 1 Status Partition 2 Status
Future use
Arm (red), Sleep (yel), Stay (grn):
On = Partition armed
Off = Partition disarmed
Flash = Exit Delay
Fast Flash* = Exit Delay (final 10 sec.)
Fast Flash* = Partition i n a la r m
* Audible Indicators:
Continuous beep = Alarm
Variable beep = Fire alarm
Intermittent beep = Beginning of exit delay
Fast beep = Final 10 sec. of exit delay
Zone Display:
The keypad [1] to [0(10)] correspond to
zones 1 to 10 respectively.
Open or entry delay zones are illuminated,
and flash in alarm.
2 User Guide
Figure 1: MG32LED (32-zone LED Keypad Module)
Zone Display:
The numbers [1] to [32] correspond to zones 1 to 32 respectively.
Open or entry delay zones are illuminated, and flash in alarm.
Partition 1 Status Partition 2 Status
Off Light (red):
On = Disarmed
Off = System armed
Fast Flash = Disarmed system in alarm
AC Light
On = Power on
Off = Power off
(e.g. 24hr. zone)
Arm (red), Sleep (yel), Stay (grn):
On = Partition armed
Off = Partition disarmed
Flash = Exit Delay
Fast Flash* = Exit Delay (final 10 sec.)
Fast Flash* = Partition in ala r m
* Audible Indicators:
Continuous beep = A l arm
Variable beep = Fire alarm
Intermittent beep = Beginning of exit delay
Fast beep = Final 10 sec. of exit delay
[TBL] Trouble display
ON = Trouble(s) occurring
FUTURE USE
= Press once + [
CODE] for Quick Menu
Programming
Figure 3: MG32LRF (32-zone Wireless LED Keypad Module)
Off Light (red):
ON = Disarmed
OFF = System armed
Fast Flash = Disarmed system in alarm
Power and RX/TX Light
ON = Power on
OFF = Power off
FLASH = Communication failure
FAST
FLASH = Transmission/reception in
(e.g. 24hr. zone)
with panel/keypad not
learned
progress
MASTER
Zone Display:
The numbers [1] to [32] correspond to zones 1 to 32 respectively.
Open or entry delay zones are illuminated, and flash in alarm.
Partition 1 Status Partition 2 Status
ON = Alarm(s) occurred
[BYP] Bypass programming
ON = Zone(s) bypassed
Arm (red), Sleep (yel), Stay (grn):
On = Partition armed
Off = Partition disarmed
Flash = Exit Delay
Fast Flash* = Exit Delay (final 10 sec.)
Fast Flash* = Partition in alarm
* Audible Indicators:
Continuous beep = Alarm,
Variable beep = Fire alarm
Intermittent beep = Beginning of exit delay
Fast beep = Final 10 sec. of exit delay
lnfo Key
Refresh display to see all open zones (see
Display Mode on page 9)
[TBL] Trouble display
[MEM] Alarm memory display
FUTURE USE
ON = Trouble(s) occurring
[MEM] Alarm memory display
= Press once + [
CODE] for Quick Menu
Programming
MASTER
ON = Alarm(s) occurred
[BYP] Bypass programming
ON = Zone(s) bypassed
Partitioning
Your Magellan system is equipped with a partitioning feature that can divide your alarm system into two distinct areas identified as
Partition 1 and Partition 2. Partitioning can be used in installations where shared security systems are more practical, such as a
home office or warehouse building. When partitioned, each zone, each user code and many of your system's features can be
assigned to either Partition 1, Partition 2, or both partitions.
If the system is not partitioned, all zones, user codes, and features will be recognized as belonging to Partition 1.
Magellan 3
Access Codes
Programming Access Codes
Access codes are personal identification numbers that allow you to enter certain programming modes, arm or disarm your system as well
as activate or deactivate PGMs. The Magellan security system supports the following:
• 1 System Master Code
• 2 Master Codes
• 29 User Access Codes
For information on how each access code can arm or disarm the system refer to the System Checklist on page 13 and 14.
System Master Code (Default: 123456)
The System Master Code can arm or disarm any partition using any of the methods described in this section and can create, modify
or delete any user access code (see Programming Access Codes below).
Master Codes
Master Code 1 is permanently assigned to Partition 1 and can be used to create, modify or delete user access codes (see
Programming Access Codes below) that are assigned to Partition 1.
Master Code 2 is permanently assigned to Partition 2 (except when partitioning is disabled, Master Code 2 will be assigned to
Partition 1) and can be used to create, modify or delete user access codes that are assigned to the same partition.
Master Codes cannot modify or delete user access codes assigned to both partitions. Only the System Master Code can modify or delete
user access codes assigned to both partitions.
Duress Code
If you are forced to arm or disarm your system, entering the access code with the duress option enabled will arm or disarm the
system and immediately transmit a silent alert (Duress Code) to the monitoring station.
Must be enabled by your installer.
Programming Access Codes
Y our system can use either 4- or 6-digit access codes, where each digit can be any value from 0 to 9. Six-digit codes are considered
more difficult to “crack” and therefore, more secure. Avoid programming simple or obvious access codes, such as your telephone
number, address or codes such as 1234. Also, see the Master Quick Menu at the end of the manual (page 17-18).
How do I program Access Codes?
1. Press the [] key.
2. Enter your [
3. The [] key will flash. When a zone LED or zone key is lit (not flashing), the user is already programmed.
4. Select a user by entering a 2-digit user number (i.e. [0]+[9] for user 9) or use the scroll keys and then press [
MG10LEDV/H, press the key corresponding to the user number (i.e. [9] for user 9).
5. Enter a new 4- or 6-digit [
6. Confirm the code.
7. Press a button on the designated remote or press [
8. (Not available for non-partitioned system) Press [1] and/or [2] to assign the user to a partition. Press [
now jump to the next available user, if you choose to continue.
How do I delete Access Codes?
1. Press the [] key.
2. Enter your [
3. Select a user by entering a 2-digit user number (i.e. [0]+[9] for user 9). For the MG10LEDV/H, enter a 1-digit user number (i.e. [9] for user 9).
4. Press the [
SYSTEM MASTER CODE] or either [MASTER CODE].
ENTER]. For the
ACCESS CODE].
ENTER] to skip if there is no remote to program.
ENTER], the menu will
SYSTEM MASTER CODE] or either [MASTER CODE].
SLEEP] key until you hear the confirmation beep.
4 User Guide
Loading...
