Digiplex DGP-848 - 1 - Programming Guide
Security and Access Control (DGP-848)
Programming Guide
Software Version 4.10
Default Installer Code
000000 (see section [800] on page 39)
Default System Master code
123456
How Do I Enter Programming Mode?
1. Press and hold the [0] key.
2. Enter your [
INSTALLER CODE].
3. Enter 3-digit [
SECTION].
4. Enter required [
DATA].
Decimal and Hexadecimal Programming Table
Certain sections may require the entry of one or more Hexadecimal values from 0 to F.
For LCD keypads:
For Grafica keypads:
[0] to [9] = values 0 to 9 respectively [DISARM] = D
[
STAY] = A [BYP] = E
[FORCE] = B [MEM] = F
[
ARM] = C [CLEAR] = Exit section without saving
[
ENTER] = Save current data and advance to next section
[0] to [9] = values 0 to 9 respectively Right Action Key (Exit) = Exit section without saving
[#]
= A to F (press the [#] key until the desired letter
appears)
Center Action Key (Save) =Save current data and advance to next
section
DGP-848
Digiplex DGP-848 - 2 - Programming Guide
Table of Contents
Serial Number List...................................................................................................................... ... .... ... ... ... ... ........................ 3
Zone Programming . ... ... .......................................... .... ... .......................................... ... ... ................................................. ....... 5
Keyswitch Programming....................................................................................................................... ... ... ... ........................ 8
Access Control .................................................................................................................................................................... 11
Programmable Outputs ....................................................................................................................................................... 14
Other Settings...................... ....................................... ... ... ... ... .... ... ... ................................................................................... 17
Zone Labels.................................. .... ... ... ... .... ... ....................................... ... ... ... .... ... ... ... ...................................................... 17
System Options................................................................................................................................................................... 18
Partition 1: Options.............................................................................................................................................................. 20
Partition 2: Options.............................................................................................................................................................. 21
Partition 3: Options.............................................................................................................................................................. 22
Partition 4: Options.............................................................................................................................................................. 23
Dialer Options...................................................................................................................................................................... 24
Partition 1: Event Call Direction........................................................................................................................................... 25
Partition 2: Event Call Direction........................................................................................................................................... 26
Partition 3: Event Call Direction........................................................................................................................................... 27
Partition 4: Event Call Direction........................................................................................................................................... 28
System Event Call Direction................................................................................................................................................ 29
Global Access Control Features.................................... ... ... ... .... ... ... ................................................................................... 29
Communication Settings...................................................................................................................................................... 30
Report Codes ...................................................................................................................................................................... 31
Other Settings and Modes................................................................................................................................................... 39
Power Unit Consumption..................................................................................................................................................... 42
Hardware Connections........................................................................................................................................................ 43
Trouble Display............................. .... ... ................................................................................................................................ 48
Digiplex DGP-848 - 3 - Programming Guide
Serial Number List
All modules connected to the control panel’s combus have an 8-d igit serial number. Remove the extra serial number sticker
from the modules’ PC board and affix in the appropriate spaces provided below (Max. 95 Modules).
Module Type & Details Serial # Module Type & Details Serial #
1:_________________________ ___________ 24:________________________ ___________
2:_________________________ ___________ 25:________________________ ___________
3:_________________________ ___________ 26:________________________ ___________
4:_________________________ ___________ 27:________________________ ___________
5:_________________________ ___________ 28:________________________ ___________
6:_________________________ ___________ 29:________________________ ___________
7:_________________________ ___________ 30:________________________ ___________
8:_________________________ ___________ 31:________________________ ___________
9:_________________________ ___________ 32:________________________ ___________
10:________________________ ___________ 33:________________________ ___________
11:________________________ ___________ 34:________________________ ___________
12:________________________ ___________ 35:________________________ ___________
13:________________________ ___________ 36:________________________ ___________
14:________________________ ___________ 37:________________________ ___________
15:________________________ ___________ 38:________________________ ___________
16:________________________ ___________ 39:________________________ ___________
17:________________________ ___________ 40:________________________ ___________
18:________________________ ___________ 41:________________________ ___________
19:________________________ ___________ 42:________________________ ___________
20:________________________ ___________ 43:________________________ ___________
21:________________________ ___________ 44:________________________ ___________
22:________________________ ___________ 45:________________________ ___________
23:________________________ ___________ 46:________________________ ___________
Digiplex DGP-848 - 4 - Programming Guide
47:________________________ ___________ 72:________________________ ___________
48:________________________ ___________ 73:________________________ ___________
49:________________________ ___________ 74:________________________ ___________
50:________________________ ___________ 75:________________________ ___________
51:________________________ ___________ 76:________________________ ___________
52:________________________ ___________ 77:________________________ ___________
53:________________________ ___________ 78:________________________ ___________
54:________________________ ___________ 79:________________________ ___________
55:________________________ ___________ 80:________________________ ___________
56:________________________ ___________ 81:________________________ ___________
57:________________________ ___________ 82:________________________ ___________
58:________________________ ___________ 83:________________________ ___________
59:________________________ ___________ 84:________________________ ___________
60:________________________ ___________ 85:________________________ ___________
61:________________________ ___________ 86:________________________ ___________
62:________________________ ___________ 87:________________________ ___________
63:________________________ ___________ 88:________________________ ___________
64:________________________ ___________ 89:________________________ ___________
65:________________________ ___________ 90:________________________ ___________
66:________________________ ___________ 91:________________________ ___________
67:________________________ ___________ 92:________________________ ___________
68:________________________ ___________ 93:________________________ ___________
69:________________________ ___________ 94:________________________ ___________
70:________________________ ___________ 95:________________________ ___________
71:________________________ ___________
Module Type & Details Serial # Module Type & Details Serial #
Digiplex DGP-848 - 5 - Programming Guide
Zone Programming
Zone Description Module Section 8-digit Serial Number Input# Section Define Assign Zone Options
1
________________ __________
[001]
__/__/__/__/__/__/__/__ __/__/__
[101]
___ ___
1 2 3 4 5 6 7 8
2
________________ __________
[002]
__/__/__/__/__/__/__/__ __/__/__
[102]
___ ___
1 2 3 4 5 6 7 8
3
________________ __________
[003]
__/__/__/__/__/__/__/__ __/__/__
[103]
___ ___
1 2 3 4 5 6 7 8
4
________________ __________
[004]
__/__/__/__/__/__/__/__ __/__/__
[104]
___ ___
1 2 3 4 5 6 7 8
5
________________ __________
[005]
__/__/__/__/__/__/__/__ __/__/__
[105]
___ ___
1 2 3 4 5 6 7 8
6
________________ __________
[006]
__/__/__/__/__/__/__/__ __/__/__
[106]
___ ___
1 2 3 4 5 6 7 8
7
________________ __________
[007]
__/__/__/__/__/__/__/__ __/__/__
[107]
___ ___
1 2 3 4 5 6 7 8
8
________________ __________
[008]
__/__/__/__/__/__/__/__ __/__/__
[108]
___ ___
1 2 3 4 5 6 7 8
9
________________ __________
[009]
__/__/__/__/__/__/__/__ __/__/__
[109]
___ ___
1 2 3 4 5 6 7 8
10
________________ __________
[010]
__/__/__/__/__/__/__/__ __/__/__
[110]
___ ___
1 2 3 4 5 6 7 8
11
________________ __________
[011]
__/__/__/__/__/__/__/__ __/__/__
[111]
___ ___
1 2 3 4 5 6 7 8
12
________________ __________
[012]
__/__/__/__/__/__/__/__ __/__/__
[112]
___ ___
1 2 3 4 5 6 7 8
When option [7] in section [502] is enabled for
PGM1 to act as a zone input for two-wire smoke
detectors, the control panel will recognize PGM1
as input number 255.
Zone Numbering
Sections [001] to [048] represent zones 1 through
48. This feature tells the control panel where the
detection device is connected and which of the 48
zones is assigned to that device.
Enter 3-digit [
INPUT NUMBER] of the
Module to which the hardwired
detection device is connected.
NOTE: No input number is required
for Addressable Motion Detectors,
Keypad Zones or the Access Control
Module (DGP2-ACM1P).
Enter a 8-digit [
SERIAL NUMBER] of
the Addressable Detector or
Module to which the hardwired
detection device is connected.
Zone Definitions
0 - Disabled (Default)
1- Entry Delay 1 8- 24Hr Burglary
2- Entry Delay 2 9- Delayed 24Hr Fire
3- Entry Delay 3 A- Standard 24Hr Fire
4- Entry Delay 4 B- Stay Delay 1
5- Follow C- Stay Delay 2
6- Instant D- Stay Delay 3
7- 24Hr Buzzer E- Stay Delay 4
Zone Partition Assignment
1- Zone Assigned to Partition1 (Default)
2- Zone Assigned to Partition 2
3- Zone Assigned to Partition 3
4- Zone Assigned to Partition 4
Zone Options
[1] Auto Zone Shutdown Enabled
[2] Bypass Enabled (Default)
[3] Stay Zone
[4] Force Zone
[5] [6] Zone Alarm Type
off off Steady Alarm
off on Pulsed Alarm
on off Silent Alarm
on on Report Only
[7] Intellizone
[8] Delay before transmission
Zone Parameters
Sections [101] to [148] represent zones 1 through 48. This
feature defines the type of zone, its partition assignment and
the zone’s options.
Digiplex DGP-848 - 6 - Programming Guide
13
________________ __________
[013]
__/__/__/__/__/__/__/__ __/__/__
[113]
___ ___
1 2 3 4 5 6 7 8
14
________________ __________
[014]
__/__/__/__/__/__/__/__ __/__/__
[114]
___ ___
1 2 3 4 5 6 7 8
15
________________ __________
[015]
__/__/__/__/__/__/__/__ __/__/__
[115]
___ ___
1 2 3 4 5 6 7 8
16
________________ __________
[016]
__/__/__/__/__/__/__/__ __/__/__
[116]
___ ___
1 2 3 4 5 6 7 8
17
________________ __________
[017]
__/__/__/__/__/__/__/__ __/__/__
[117]
___ ___
1 2 3 4 5 6 7 8
18
________________ __________
[018]
__/__/__/__/__/__/__/__ __/__/__
[118]
___ ___
1 2 3 4 5 6 7 8
19
________________ __________
[019]
__/__/__/__/__/__/__/__ __/__/__
[119]
___ ___
1 2 3 4 5 6 7 8
20
________________ __________
[020]
__/__/__/__/__/__/__/__ __/__/__
[120]
___ ___
1 2 3 4 5 6 7 8
21
________________ __________
[021]
__/__/__/__/__/__/__/__ __/__/__
[121]
___ ___
1 2 3 4 5 6 7 8
22
________________ __________
[022]
__/__/__/__/__/__/__/__ __/__/__
[122]
___ ___
1 2 3 4 5 6 7 8
23
________________ __________
[023]
__/__/__/__/__/__/__/__ __/__/__
[123]
___ ___
1 2 3 4 5 6 7 8
24
________________ __________
[024]
__/__/__/__/__/__/__/__ __/__/__
[124]
___ ___
1 2 3 4 5 6 7 8
25
________________ __________
[025]
__/__/__/__/__/__/__/__ __/__/__
[125]
___ ___
1 2 3 4 5 6 7 8
26
________________ __________
[026]
__/__/__/__/__/__/__/__ __/__/__
[126]
___ ___
1 2 3 4 5 6 7 8
27
________________ __________
[027]
__/__/__/__/__/__/__/__ __/__/__
[127]
___ ___
1 2 3 4 5 6 7 8
28
________________ __________
[028]
__/__/__/__/__/__/__/__ __/__/__
[128]
___ ___
1 2 3 4 5 6 7 8
29
________________ __________
[029]
__/__/__/__/__/__/__/__ __/__/__
[129]
___ ___
1 2 3 4 5 6 7 8
30
________________ __________
[030]
__/__/__/__/__/__/__/__ __/__/__
[130]
___ ___
1 2 3 4 5 6 7 8
31
________________ __________
[031]
__/__/__/__/__/__/__/__ __/__/__
[131]
___ ___
1 2 3 4 5 6 7 8
32
________________ __________
[032]
__/__/__/__/__/__/__/__ __/__/__
[132]
___ ___
1 2 3 4 5 6 7 8
33
________________ __________
[033]
__/__/__/__/__/__/__/__ __/__/__
[133]
___ ___
1 2 3 4 5 6 7 8
34
________________ __________
[034]
__/__/__/__/__/__/__/__ __/__/__
[134]
___ ___
1 2 3 4 5 6 7 8
Zone Description Module
Section 8-digit Serial Number Input# Section Define Assign Zone Options
Digiplex DGP-848 - 7 - Programming Guide
To clear a zone’s numbering (sections [001] to [048]):
For LCD keypads:
1.Enter a section number between [001] and [048].
2.Press [0] and then [
ENTER] to save and exit.
For Grafica keypads:
1.Enter a section number between [001] and [048].
2.Press [0] to clear the serial number.
3.Using Grafica’s scroll keys, highlight the input number and then press [0] to clear the data.
4.Press Grafica’s center action key (Save) to save and exit.
35
________________ __________
[035]
__/__/__/__/__/__/__/__ __/__/__
[135]
___ ___
1 2 3 4 5 6 7 8
36
________________ __________
[036]
__/__/__/__/__/__/__/__ __/__/__
[136]
___ ___
1 2 3 4 5 6 7 8
37
________________ __________
[037]
__/__/__/__/__/__/__/__ __/__/__
[137]
___ ___
1 2 3 4 5 6 7 8
38
________________ __________
[038]
__/__/__/__/__/__/__/__ __/__/__
[138]
___ ___
1 2 3 4 5 6 7 8
39
________________ __________
[039]
__/__/__/__/__/__/__/__ __/__/__
[139]
___ ___
1 2 3 4 5 6 7 8
40
________________ __________
[040]
__/__/__/__/__/__/__/__ __/__/__
[140]
___ ___
1 2 3 4 5 6 7 8
41
________________ __________
[041]
__/__/__/__/__/__/__/__ __/__/__
[141]
___ ___
1 2 3 4 5 6 7 8
42
________________ __________
[042]
__/__/__/__/__/__/__/__ __/__/__
[142]
___ ___
1 2 3 4 5 6 7 8
43
________________ __________
[043]
__/__/__/__/__/__/__/__ __/__/__
[143]
___ ___
1 2 3 4 5 6 7 8
44
________________ __________
[044]
__/__/__/__/__/__/__/__ __/__/__
[144]
___ ___
1 2 3 4 5 6 7 8
45
________________ __________
[045]
__/__/__/__/__/__/__/__ __/__/__
[145]
___ ___
1 2 3 4 5 6 7 8
46
________________ __________
[046]
__/__/__/__/__/__/__/__ __/__/__
[146]
___ ___
1 2 3 4 5 6 7 8
47
________________ __________
[047]
__/__/__/__/__/__/__/__ __/__/__
[147]
___ ___
1 2 3 4 5 6 7 8
48
________________ __________
[048]
__/__/__/__/__/__/__/__ __/__/__
[148]
___ ___
1 2 3 4 5 6 7 8
Zone Description Module
Section 8-digit Serial Number Input# Section Define Assign Zone Options
Digiplex DGP-848 - 8 - Programming Guide
Keyswitch Programming
Keyswitch Location Module Section 8-digit Serial Number Input# Section Define Assign
Keyswitch
Options
1
_______________ __________
[049]
__/__/__/__/__/__/__/__ __/__/__
[149]
___ ___
14 5 6 7 8
2
_______________ __________
[050]
__/__/__/__/__/__/__/__ __/__/__
[150]
___ ___
14 5 6 7 8
3
_______________ __________
[051]
__/__/__/__/__/__/__/__ __/__/__
[151]
___ ___
14 5 6 7 8
4
_______________ __________
[052]
__/__/__/__/__/__/__/__ __/__/__
[152]
___ ___
14 5 6 7 8
5
_______________ __________
[053]
__/__/__/__/__/__/__/__ __/__/__
[153]
___ ___
14 5 6 7 8
6
_______________ __________
[054]
__/__/__/__/__/__/__/__ __/__/__
[154]
___ ___
14 5 6 7 8
7
_______________ __________
[055]
__/__/__/__/__/__/__/__ __/__/__
[155]
___ ___
14 5 6 7 8
8
_______________ __________
[056]
__/__/__/__/__/__/__/__ __/__/__
[156]
___ ___
14 5 6 7 8
Keyswitch Numbering
Sections [049] to [056] represent keyswitches 1 to 8
respectively. This feature tells the control panel where
the keyswitch is connected and which of the 8
keyswitch locations is assigned to that device.
Enter 3-digit [INPUT NUMBER] of the
Module to which the keyswitch is
connected.
Enter 8-digit [
SERIAL NUMBER] of the
Module to which the keyswitch is
connected.
Keyswitch Parameters
Sections [149] to [156] represent keyswitches 1 to 8
respectively. This feature defines the keyswitch’s
partition assignment and arming method.
Keyswitch Partition Assignment
1- Keyswitch Assigned to Partition 1
2- Keyswitch Assigned to Partition 2
3- Keyswitch Assigned to Partition 3
4- Keyswitch Assigned to Partition 4
Keyswitch Definitions
1- Momentary Keyswitch
2- Maintained Keyswitch
3- Generates Utility Key Event on
Open only
4- Generates Utility Key Event on
Open & Close
Keyswitch Options
[4] Stay/Instant Disarm
[5] On = Arm Only
Off = Arm/Disarm
[6] *Stay Arming
[7] *Force Arming
[8] *Instant Arming
* Select only one. If all are off
keyswitch will regular arm
Digiplex DGP-848 - 9 - Programming Guide
System Timers
Section # Decimal Value (000 to 255) Description Default
[200] ___/___/___ seconds (min. = 10sec.)
INTELLIZONE DELAY 10sec.
[201]
___/___/___ x 20 msec. INPUT SPEED 001=PANEL TERMINAL 1 600 msec.
[202]
___/___/___ x 20 msec. INPUT SPEED 002=PANEL TERMINAL 2 600 msec.
[203]
___/___/___ x 20 msec. INPUT SPEED 003=PANEL TERMINAL 3 600 msec.
[204]
___/___/___ x 20 msec. INPUT SPEED 004=PANEL TERMINAL 4 600 msec.
[205]
___/___/___ x 20 msec. INPUT SPEED 005=PANEL TERMINAL 5 600 msec.
[206]
___/___/___ x 20 msec. INPUT SPEED 006=PANEL TERMINAL 6 600 msec.
[207]
___/___/___ x 20 msec. INPUT SPEED 007=PANEL TERMINAL 7 600 msec.
[208]
___/___/___ x 20 msec. INPUT SPEED 008=PANEL TERMINAL 8 600 msec.
[209]
___/___/___ x 20 msec. INPUT SPEED 009=PANEL DOUBLER 1 600 msec.
[210]
___/___/___ x 20 msec. INPUT SPEED 010=PANEL DOUBLER 2 600 msec.
[211]
___/___/___ x 20 msec. INPUT SPEED 011=PANEL DOUBLER 3 600 msec.
[212]
___/___/___ x 20 msec. INPUT SPEED 012=PANEL DOUBLER 4 600 msec.
[213]
___/___/___ x 20 msec. INPUT SPEED 013=PANEL DOUBLER 5 600 msec.
[214]
___/___/___ x 20 msec. INPUT SPEED 014=PANEL DOUBLER 6 600 msec.
[215]
___/___/___ x 20 msec. INPUT SPEED 015=PANEL DOUBLER 7 600 msec.
[216]
___/___/___ x 20 msec. INPUT SPEED 016=PANEL DOUBLER 8 600 msec.
[217]
___/___/___ (max.=15) AUTO ZONE SHUTDOWN Disabled
[218]
___/___/___ (max.=15) AUTO TROUBLE SHUTDOWN Disabled
[219]
___/___/___ seconds RECENT CLOSING DELAY Disabled
[220]
___/___/___ tries # OF INVALID CODE BEFORE LOCKOUT Disabled
[221]
___/___/___ minutes (000 = report only) KEYPAD LOCKOUT DURATION Report Only
[222]
___/___/___ x15 minutes NO MOVEMENT TIMER PARTITION 1 Disabled
[223]
___/___/___ x15 minutes NO MOVEMENT TIMER PARTITION 2 Disabled
[224]
___/___/___ x15 minutes NO MOVEMENT TIMER PARTITION 3 Disabled
[225]
___/___/___ x15 minutes NO MOVEMENT TIMER PARTITION 4 Disabled
[226]
___/___/___ seconds EXIT DELAY PARTITION 1 60 sec.
[227]
___/___/___ seconds EXIT DELAY PARTITION 2 60 sec.
[228]
___/___/___ seconds EXIT DELAY PARTITION 3 60 sec.
[229]
___/___/___ seconds EXIT DELAY PARTITION 4 60 sec.
[230]
___/___/___ seconds ENTRY/STAY DELAY 1 30 sec.
[231]
___/___/___ seconds ENTRY/STAY DELAY 2 60 sec.
[232]
___/___/___ seconds ENTRY/STAY DELAY 3 90 sec.
[233]
___/___/___ seconds ENTRY/STAY DELAY 4 120 sec.
[234]
___/___/___ minutes BELL CUT-OFF TIMER PARTITION 1 4 min.
[235]
___/___/___ minutes BELL CUT-OFF TIMER PARTITION 2 4 min.
[236]
___/___/___ minutes BELL CUT-OFF TIMER PARTITION 3 4 min.
[237]
___/___/___ minutes BELL CUT-OFF TIMER PARTITION 4 4 min.
Digiplex DGP-848 - 10 - Programming Guide
[238]
___/___/___ zone(s) MAX. BYPASS ENTRIES PARTITION 1 Unlimited
[239]
___/___/___ zone(s) MAX. BYPASS ENTRIES PARTITION 2 Unlimited
[240]
___/___/___ zone(s) MAX. BYPASS ENTRIES PARTITION 3 Unlimited
[241]
___/___/___ zone(s) MAX. BYPASS ENTRIES PARTITION 4 Unlimited
[242]
___/___/___ minutes RECYCLE DELAY PARTITION 1 Disabled
[243]
___/___/___ minutes RECYCLE DELAY PARTITION 2 Disabled
[244]
___/___/___ minutes RECYCLE DELAY PARTITION 3 Disabled
[245]
___/___/___ minutes RECYCLE DELAY PARTITION 4 Disabled
[246]
___/___/___ recycle(s) # OF RECYCLES PARTITION 1 Unlimited
[247]
___/___/___ recycle(s) # OF RECYCLES PARTITION 2 Unlimited
[248]
___/___/___ recycle(s) # OF RECYCLES PARTITION 3 Unlimited
[249]
___/___/___ recycle(s) # OF RECYCLES PARTITION 4 Unlimited
[250]
___/___/___ see section [503] PGM1 DELAY 5 sec.
[251]
___/___/___ see section [503] PGM2 DELAY 5 sec.
[252]
___/___/___ see section [503] PGM3 DELAY 5 sec.
[253]
___/___/___ see section [503] PGM4 DELAY 5 sec.
[254]
___/___/___ see section [503] PGM5 DELAY 5 sec.
[255]
___/___/___ x2 sec. (min. = 32sec.) TLM FAIL TIMER 32 sec.
[256]
___/___/___ seconds DELAY ALARM TRANSMISSION TIMER Instant
[257]
___/___/___ attempts MAXIMUM DIALING ATTEMPTS 8 attempts
[258]
___/___/___ seconds DELAY BETWEEN DIALING ATTEMPTS 20 sec.
[259]
___/___/___ seconds (max. 60 sec.) PAGER DELAY BEFORE DATA TRANSMISSION Disabled
[260]
___/___/___ minutes DELAY POWER FAILURE REPORT 30 min.
[261]
___/___/___ days AUTO TEST REPORT Disabled
[262]
___/___/___ 001 to 255 days; 000 = disabled CLOSING DELINQUENCY TIMER PARTITION 1 Disabled
[263]
___/___/___ 001 to 255 days; 000 = disabled CLOSING DELINQUENCY TIMER PARTITION 2 Disabled
[264]
___/___/___ 001 to 255 days; 000 = disabled CLOSING DELINQUENCY TIMER PARTITION 3 Disabled
[265]
___/___/___ 001 to 255 days; 000 = disabled CLOSING DELINQUENCY TIMER PARTITION 4 Disabled
Hours (00 to 23) & Minutes (00 to 59)
[270] ___/___:___/___
AUTO TEST REPORT TIME OF DAY
[271] ___/___:___/___ AUTO ARM TIME PARTITION 1
[272] ___/___:___/___
AUTO ARM TIME PARTITION 2
[273] ___/___:___/___
AUTO ARM TIME PARTITION 3
[274] ___/___:___/___
AUTO ARM TIME PARTITION 4
Section # Decimal Value (000 to 255) Description Default
Digiplex DGP-848 - 11 - Programming Guide
Access Control
Assigning the Door to an Access Control Module
These doors are used to program the Access Level in sections [341] to [355]. If you want an Access door to be linked to the
alarm system, install a door contact and assign it to a zone through Zone Programming.
Section Door Description Access Module Serial Number
[301] 01
____________________________________________ __/__/__/__/__/__/__/__
[302] 02
____________________________________________ __/__/__/__/__/__/__/__
[303] 03
____________________________________________ __/__/__/__/__/__/__/__
[304] 04
____________________________________________ __/__/__/__/__/__/__/__
[305] 05
____________________________________________ __/__/__/__/__/__/__/__
[306] 06
____________________________________________ __/__/__/__/__/__/__/__
[307] 07
____________________________________________ __/__/__/__/__/__/__/__
[308] 08
____________________________________________ __/__/__/__/__/__/__/__
[309] 09
____________________________________________ __/__/__/__/__/__/__/__
[310] 10
____________________________________________ __/__/__/__/__/__/__/__
[311] 11
____________________________________________ __/__/__/__/__/__/__/__
[312] 12
____________________________________________ __/__/__/__/__/__/__/__
[313] 13
____________________________________________ __/__/__/__/__/__/__/__
[314] 14
____________________________________________ __/__/__/__/__/__/__/__
[315] 15
____________________________________________ __/__/__/__/__/__/__/__
[316] 16
____________________________________________ __/__/__/__/__/__/__/__
[317] 17
____________________________________________ __/__/__/__/__/__/__/__
[318] 18
____________________________________________ __/__/__/__/__/__/__/__
[319] 19
____________________________________________ __/__/__/__/__/__/__/__
[320] 20
____________________________________________ __/__/__/__/__/__/__/__
[321] 21
____________________________________________ __/__/__/__/__/__/__/__
[322] 22
____________________________________________ __/__/__/__/__/__/__/__
[323] 23
____________________________________________ __/__/__/__/__/__/__/__
[324] 24
____________________________________________ __/__/__/__/__/__/__/__
[325] 25
____________________________________________ __/__/__/__/__/__/__/__
[326] 26
____________________________________________ __/__/__/__/__/__/__/__
[327] 27
____________________________________________ __/__/__/__/__/__/__/__
[328] 28
____________________________________________ __/__/__/__/__/__/__/__
[329] 29
____________________________________________ __/__/__/__/__/__/__/__
[330] 30
____________________________________________ __/__/__/__/__/__/__/__
[331] 31
____________________________________________ __/__/__/__/__/__/__/__
[332] 32
____________________________________________ __/__/__/__/__/__/__/__
Digiplex DGP-848 - 12 - Programming Guide
Door Access Mode
Each door can be programmed to grant access only to cards assigned to all the door’s assigned partitions (“AND” Door
Access Mode) or to cards assigned to at least one of the door’s partitions (“OR” Door Access Mode). Enable the option
corresponding to the door to be set in “OR” Door Access Mode. Options that remain disabled represent doors set in the
“AND” Door Access Mode
.
Programming Access Levels
Each Access Level is a combination of Access Control doors. Use Feature Select Programming (page 14) to enable or
disable options. For example, if option [1] in the First Screen is enabled in section [341], Level 01 will allow access only to
Door 01. Access Level 00 = access to all doors.
Schedule Programming
Each Schedule determines when users are permitted access. Holidays are programmed in sections [381] to [392]. Schedule
00 = access granted at all times.
Section Door Access Mode (turn ON for “OR” Door Access Mode):
First Screen
Doors 01 to 08
Second Screen
Doors 09 to 16
Third Screen
Doors 17 to 24
Fourth Screen
Doors 25 to 32
[340] 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
Section Level Access to Doors (turn ON or OFF access):
First Screen
Doors 01 to 08
Second Screen
Doors 09 to 16
Third Screen
Doors 17 to 24
Fourth Screen
Doors 25 to 32
[341] 01 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
[342] 02 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
[343] 03 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
[344] 04 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
[345] 05 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
[346] 06 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
[347] 07 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
[348] 08 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
[349] 09 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
[350] 10 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
[351] 11 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
[352] 12 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
[353] 13 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
[354] 14 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
[355] 15 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
Section Schedule Intervals Start Time (from) End Time (to) Days (turn ON or OFF)
S M T W T F S H
[361] 01
Interval A ___ ___: ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Interval B ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
[362] 02
Interval A ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Interval B ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
[363] 03
Interval A ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Interval B ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
[364] 04
Interval A ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Interval B ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
[365] 05
Interval A ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Interval B ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Digiplex DGP-848 - 13 - Programming Guide
The Start and End Time of an Interval cannot cross over into another day. For example, to program a shift
from 10:00 p.m. one day to 6:00 a.m. the next morning, you must program Interval 1A: Start Time 22:00 and
End Time 23:59 then program Interval 1B Start Time 00:00 and End Time 06:00. The schedule will not be
interrupted between 23:59 and 00:00.
Holiday Programming
The holidays are determined in these sections. When [H] is enabled in sections [361] to [375], access is permitted to users
during the days programmed in sections [381] to [392].
*
option not used in this screen
[366] 06
Interval A ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Interval B ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
[367] 07
Interval A ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Interval B ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
[368] 08
Interval A ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Interval B ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
[369] 09
Interval A ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Interval B ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
[370] 10
Interval A ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Interval B ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
[371] 11
Interval A ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Interval B ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
[372] 12
Interval A ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Interval B ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
[373] 13
Interval A ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Interval B ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
[374] 14
Interval A ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Interval B ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
[375] 15
Interval A ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Interval B ___ ___ : ___ ___ ___ ___ : ___ ___ 1 2 3 4 5 6 7 8
Section Month Days Programmed (turn ON or OFF access):
First Screen
Days 01 to 08
Second Screen
Days 09 to 16
Third Screen
Days 17 to 24
Fourth Screen
Days 25 to 31
[381] January 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 *
[382] February 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 * * *
[383] March 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 *
[384] April 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 * *
[385] May 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 *
[386] June 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 * *
[387] July 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 *
[388] August 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 *
[389] September 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 * *
[390] October 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 *
[391] November 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 * *
[392] December 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 *
Section Schedule Intervals Start Time (from) End Time (to) Days (turn ON or OFF)
S M T W T F S H
Digiplex DGP-848 - 14 - Programming Guide
Programmable Outputs
The control panel deactivates an activated PGM in one of two ways (also see sections [502] and [503]):
Section [502]: Option OFF = Follow Activation Event:
If the first digit of the PGM Activation Event is set at 1, 2, 3, 4, or 7, the PGM will remain activated until the PGM Activation
Event has ended. It will ignore the PGM Deactivation Event. If the first digit of the PGM Activation Event is set at 8, 9, A, B, C,
D, E, or F, the PGM will remain activated until the PGM Deactivation Event occurs.
Section [502]: Option ON = Follow PGM Delay Timer:
After activating the PGM, the control panel will start the PGM delay timer and the PGM will deactivate only when the PGM
delay timer has elapsed regardless of the PGM Deactivation Event.
NOTE 1*:
0 = Occurs in all partitions enabled in the system (see section [500]).
1 = Partition 1 3 = Partition 3
2 = Partition 2 4 = Partition 4
8 = Occurs in at least one partition enabled in the system.
† : If you select a group and set all options to OFF, all users/zones/selections of that group will be enabled (result is “ANY” of
that group). For example, if you select A0 and set all 8 options to OFF, the PGM will activate/deactivate whenever a user
between 1 and 8 arms the system.
Section PGM
Event Group
(First Digit)
Event Group
(Second Digit)
Event Selection
(on/off)†
[400] PGM1 Activation Event
___ ___
1 2 3 4 5 6 7 8
[401] PGM1 Deactivation Event
___ ___
1 2 3 4 5 6 7 8
[402] PGM2 Activation Event
___ ___
1 2 3 4 5 6 7 8
[403] PGM2 Deactivation Event
___ ___
1 2 3 4 5 6 7 8
[404] PGM3 Activation Event
___ ___
1 2 3 4 5 6 7 8
[405] PGM3 Deactivation Event
___ ___
1 2 3 4 5 6 7 8
[406] PGM4 Activation Event
___ ___
1 2 3 4 5 6 7 8
[407] PGM4 Deactivation Event
___ ___
1 2 3 4 5 6 7 8
[408] PGM5 Activation Event
___ ___
1 2 3 4 5 6 7 8
[409] PGM5 Deactivation Event
___ ___
1 2 3 4 5 6 7 8
First Digit
Second
Digit
Feature Select Programming †
12345678
0 = PGM Disabled N/A N/A N/A N/A N/A N/A N/A N/A N/A
1 = Status 1
Note 1* Any Arming
Method
Force
Arm
Stay
Arm
Instant
Arm
Strobe
(until alarm is
cancelled)
Silent
Alarm
(until alarm is
cancelled or
bell is cut off)
Audible
Alarm
(until alarm is
cancelled or
bell is cut off)
Fire Alarm
(until alarm is
cancelled or
bell is cut off)
2 = Status 2
Note 1* Ready
Status
Exit Delay Entry Delay Trouble Alarm
Memory
Zone
Bypassed
(armed or not)
Master or
Installer
Programming
Keypad
Lockout
3 = Status 3
Note 1* Intellizone Fire Delay Auto Arm
Delay
N/A Any Tamper Zone Low
Battery
Fire Loop Zone
Supervision
Digiplex DGP-848 - 15 - Programming Guide
First Digit
Second
Digit
Feature Select Programming
12345678
4 = Status 4
0Chime
Partition 1
Chime
Partition 2
Chime
Partition 3
Chime
Partition 4
Siren
Partition 1
Siren
Partition 2
Siren
Partition 3
Siren
Partition 4
1N/AN/AN/AN/ASmoke
Reset
Ground
Start
Kissoff N/A
2System
Trouble
Dialer
Trouble
Module
Trouble
Combus
Trouble
N/A N/A N/A Timer Loss
3 AC Fail Battery fail Aux. Limit Bell Limit No Bell ROM Error N/A N/A
4 TLM Fail to
Com1
Fail to
Com2
Fail to
Com3
Fail to
Com4
Fail to
Com PC
N/A N/A
5 Module
Tamper
Module
ROM Error
Module
TLM
Module Fail
to Com
Phone#
Printer Fault Module AC
Fail
Module
Battery Fail
Module Aux.
fail
6 Missing
Keypad
Missing Any
Module
N/A N/A N/A
Global Com-
bus Failure
Combus
Overload
Module Combus Com Fail
7 = At the
Selected Time
0 00:00 00:15 00:30 00:45 01:00 01:15 01:30 01:45
1 02:00 02:15 02:30 02:45 03:00 03:15 03:30 03:45
2 04:00 04:15 04:30 04:45 05:00 05:15 05:30 05:45
3 06:00 06:15 06:30 06:45 07:00 07:15 07:30 07:45
4 08:00 08:15 08:30 08:45 09:00 09:15 09:30 09:45
5 10:00 10:15 10:30 10:45 11:00 11:15 1 1:30 1 1:45
6 12:00 12:15 12:30 12:45 13:00 13:15 13:30 13:45
7 14:00 14:15 14:30 14:45 15:00 15:15 15:30 15:45
8 16:00 16:15 16:30 16:45 17:00 17:15 17:30 17:45
9 18:00 18:15 18:30 18:45 19:00 19:15 19:30 19:45
A 20:00 20:15 20:30 20:45 21:00 21:15 21:30 21:45
B 22:00 22:15 22:30 22:45 23:00 23:15 23:30 23:45
8 = Utility Keys†
0 Utility Key 1 Utility Key 2 Utility Key 3 Utility Key 4 Utility Key 5 Utility Key 6 Utility Key 7 Utility Key 8
1 Utility Key 9 Utility Ke y 10 Utility Key 11 Utility Key 12 Utility Key 13 Utility Key 14 Utility Key 15 Utility Key 16
9 = Access
Granted
0 Door 01 Door 02 Door 03 Door 04 Door 05 Door 06 Door 07 Door 08
1 Door 09 Door 10 Door 11 Door 12 Door 13 Door 14 Door 15 Door 16
2 Door 17 Door 18 Door 19 Door 20 Door 21 Door 22 Door 23 Door 24
3 Door 25 Door 26 Door 27 Door 28 Door 29 Door 30 Door 31 Door 32
9 = User Code
Entered
8 Code # 01 Code # 02 Code # 03 Code # 04 Code # 05 Code # 06 Code # 07 Code # 08
9 Code # 09 Code # 10 Code # 11 Code # 12 Code # 13 Code # 14 Code # 15 Code # 16
A Code # 17 Code # 18 Code # 19 Code # 20 Code # 2 1 Code # 22 Code # 23 Code # 24
B Code # 25 Code # 26 Code # 27 Code # 28 Code # 2 9 Code # 30 Code # 31 Code # 32
C C ode # 33 Code # 34 Code # 35 Code # 36 Code # 37 Code # 38 Code # 39 Code # 40
D C ode # 41 Code # 42 Code # 43 Code # 44 Code # 45 Code # 46 Code # 47 Code # 48
E Code # 49 Code # 50 Code # 51 Code # 52 Code # 5 3 Code # 54 Code # 55 Code # 56
F Code # 57 Code # 58 Code # 59 Code # 60 Code # 61 Code # 62 Code # 63 Code # 64
A = Arming
0 Code # 01 Code # 02 Code # 03 Code # 04 Code # 05 Code # 06 Code # 07 Code # 08
1 Code # 09 Code # 10 Code # 11 Code # 12 Code # 13 Code # 14 Code # 15 Code # 16
2 Code # 17 Code # 18 Code # 19 Code # 20 Code # 21 Code # 22 Code # 23 Code # 24
3 Code # 25 Code # 26 Code # 27 Code # 28 Code # 29 Code # 30 Code # 31 Code # 32
4 Code # 33 Code # 34 Code # 35 Code # 36 Code # 37 Code # 38 Code # 39 Code # 40
5 Code # 41 Code # 42 Code # 43 Code # 44 Code # 45 Code # 46 Code # 47 Code # 48
6 Code # 49 Code # 50 Code # 51 Code # 52 Code # 53 Code # 54 Code # 55 Code # 56
7 Code # 57 Code # 58 Code # 59 Code # 60 Code # 61 Code # 62 Code # 63 Code # 64
A = Disarming
8 Code # 01 Code # 02 Code # 03 Code # 04 Code # 05 Code # 06 Code # 07 Code # 08
9 Code # 09 Code # 10 Code # 11 Code # 12 Code # 13 Code # 14 Code # 15 Code # 16
A Code # 17 Code # 18 Code # 19 Code # 20 Code # 2 1 Code # 22 Code # 23 Code # 24
B Code # 25 Code # 26 Code # 27 Code # 28 Code # 2 9 Code # 30 Code # 31 Code # 32
C C ode # 33 Code # 34 Code # 35 Code # 36 Code # 37 Code # 38 Code # 39 Code # 40
D C ode # 41 Code # 42 Code # 43 Code # 44 Code # 45 Code # 46 Code # 47 Code # 48
E Code # 49 Code # 50 Code # 51 Code # 52 Code # 5 3 Code # 54 Code # 55 Code # 56
F Code # 57 Code # 58 Code # 59 Code # 60 Code # 61 Code # 62 Code # 63 Code # 64
† See Utility Key Event Generation Table on page 17.
Digiplex DGP-848 - 16 - Programming Guide
First Digit
Second
Digit
Feature Select Programming
12345678
B = Zone is OK
0 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
1 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
2 Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
3 Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
4 Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
5 Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
B = Zone is Open
8 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
9 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
A Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
B Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
C Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
D Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
C = Auto Zone
Shutdown
0 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
1 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
2 Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
3 Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
4 Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
5 Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
C = Zone Bypass
(when system
is armed)
8 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
9 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
A Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
B Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
C Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
D Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
D = Zone Fault
(Tamper / Fire
Loop)
0 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
1 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
2 Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
3 Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
4 Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
5 Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
D = RF Zone Fault
(Low battery
Supervision)
8 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
9 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
A Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
B Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
C Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
D Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
E = Fire /Burglar
Alarms
0 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
1 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
2 Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
3 Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
4 Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
5 Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
E = Fire/Burglar
Restore
8 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
9 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
A Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
B Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
C Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
D Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
F = Module
Troubles
0 Combus
Fault
Tamper ROM Error TLM Fail to
Comm.
Printer Fault AC Fail Battery Fail
1 Auxiliary
Output Fail
N/A N/A N/A N/A N/A N/A N/A
8 Combus
Fault
Restore
Tamper
Restore
ROM Error
Restore
TLM
Restore
Fail to
Comm.
Restore
Printer Fault
Restore
AC Fail
Restore
Battery Fail
Restore
9 Auxiliary Fail N/A N/A N/A N/A N/A N/A N/A
Digiplex DGP-848 - 17 - Programming Guide
Table 1: Utility Key Event Generation Table
† You must program a remote control button with a Utility Key option; see Omnia Reference and Installation
Manual for more details.
Other Settings
Zone Labels
For instructions on how to enter letters and special characters when using an LCD or Grafica keypad, refer to the LCD
keypad’s Installation Manual or Grafica’s User Manual. A complete Grafica user manual is available on our website at
www.paradox.ca.
Event Name
Using Keyswitch
Definition 3
Using Keyswitch
Definition 4
Using Keypad
Buttons
Using Remote
Control
Utility Key 1 Key switch 001 opens Keyswitch 001 opens [1] + [2] Utility Key 1†
Utility Key 2 Key switch 002 opens Keyswitch 001 closes [4] + [5] Utility Key 2†
Utility Key 3 Key switch 003 opens Keyswitch 002 opens [7] + [8] Utility Key 3†
Utility Key 4 Key switch 004 opens Keyswitch 002 closes [
CLEAR] + [0] or [*] + [0] Utility Key 4†
Utility Key 5 Key switch 005 opens Keyswitch 003 opens [2] + [3] Utility Key 5†
Utility Key 6 Key switch 006 opens Keyswitch 003 closes [5] + [6] Utility Key 7 Ke y switch 007 opens Keyswitch 004 opens [8] + [9] Utility Key 8 Key switch 008 opens Keyswitch 004 closes [0] + [
ENTER] or [0] + [#] -
Utility Key 9 - Keyswitch 005 opens - Utility Key 10 - Keyswitch 005 closes - Utility Key 11 - Keyswitch 006 opens - Utility Key 12 - Keyswitch 006 closes - Utility Key 13 - Keyswitch 007 opens - Utility Key 14 - Keyswitch 007 closes - Utility Key 15 - Keyswitch 008 opens - Utility Key 16 - Keyswitch 008 closes - -
Section # Decimal Value (00 to 15) Description Default
[440]
___/___ 00 to 04 (00 = all enabled partitions) CONTROL PANEL PARTITION ASSIGNMENT 00
[441]
___/___ x4 sec. ANSWERING MACHINE OVERRIDE DELAY 32 sec.
[442]
___/___ x1 Ring NUMBER OF RINGS 8 rings
Section Zone # Zone Label Section Zone # Zone Label
[451] Zone 1
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[475] Zone 25
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[452] Zone 2
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[476] Zone 26
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[453] Zone 3
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[477] Zone 27
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[454] Zone 4
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[478] Zone 28
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[455] Zone 5
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[479] Zone 29
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[456] Zone 6
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[480] Zone 30
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[457] Zone 7
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[481] Zone 31
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[458] Zone 8
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[482] Zone 32
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[459] Zone 9
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[483] Zone 33
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[460] Zone 10
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[484] Zone 34
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[461] Zone 11
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[485] Zone 35
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[462] Zone 12
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[486] Zone 36
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[463] Zone 13
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[487] Zone 37
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[464] Zone 14
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[488] Zone 38
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
Digiplex DGP-848 - 18 - Programming Guide
System Options
Bold = Default setting
[465] Zone 15
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[489] Zone 39
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[466] Zone 16
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[490] Zone 40
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[467] Zone 17
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[491] Zone 41
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[468] Zone 18
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[492] Zone 42
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[469] Zone 19
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[493] Zone 43
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[470] Zone 20
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[494] Zone 44
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[471] Zone 21
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[495] Zone 45
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[472] Zone 22
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[496] Zone 46
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[473] Zone 23
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[497] Zone 47
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[474] Zone 24
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
[498] Zone 48
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
Section [500]: System Options
Option OFF ON
[1] Partition 1 N Disabled N Enabled
[2] Partition 2 N Disabled N Enabled
[3] Partition 3 N Disabled N Enabled
[4] Partition 4 N Disabled N Enabled
[5] Bell/Siren Output in Partition 1 N Disabled N Enabled
[6] Bell/Siren Output in Partition 2 N Disabled N Enabled
[7] Bell/Siren Output in Partition 3 N Disabled N Enabled
[8] Bell/Siren Output in Partition 4 N Disabled N Enabled
Section [501]: System Options
Option OFF ON
[1]&[2]
N see table
N see table
N see table
N see table
[3]
Generate Supervision Failure if detected on a
Bypassed Wireless Zone
N Yes N No
[4]
Restrict Arming on Wireless Transmitter
Supervision Failure
N Disabled N Enabled
Wireless Transmitter Supervision Options
[1] [2]
OFF OFF Disabled (default)
ON OFF When disarmed: GENERATES TROUBLE ONLY
When armed: Follows Zone Alarm T ypes (page 5)
OFF ON GENERATES TROUBLE ONLY (armed or disarmed)
ON ON When disarmed: GENERATES AUDIBLE ALARM
When armed: Follows Zone Alarm T ypes (page 5)
Digiplex DGP-848 - 19 - Programming Guide
Bold = Default setting
[5]&[6]
N see table
N see table
N see table
N see table
[7] Generate Tamper if detected on Bypassed Zone N Yes N No
[8] Restrict Arming on Tamper Trouble N Disabled N Enabled
Section [502]: PGM & Other Options
Option OFF ON
[1] PGM 1 Deactivation Type N Follows Event N Follows Timer
[2] PGM 2 Deactivation Type N Follows Event N Follows Timer
[3] PGM 3 Deactivation Type N Follows Event N Follows Timer
[4] PGM 4 Deactivation Type N Follows Event N Follows Timer
[5] PGM 5 Deactivation Type N Follows Event N Follows Timer
[6] Auto adjust panel clock for Daylight Savings N Disabled N Enabled
[7] PGM 1 = 2-wire smoke detector input (255) N Disabled N Enabled
[8] No bell cut-off during fire alarm N Disabled N Enabled
Section [503]: PGM & Other Options
Option OFF ON
[1] PGM 1 Timer (see section [250]) N Seconds N Minutes
[2] PGM 2 Timer (see section [251]) N Seconds N Minutes
[3] PGM 3 Timer (see section [252]) N Seconds N Minutes
[4] PGM 4 Timer (see section [253]) N Seconds N Minutes
[5] PGM 5 Timer (see section [254]) N Seconds N Minutes
[6] Battery charge current * N 350mA N 850mA
[7] AC failure does not appear in Trouble Display N Disabled N Enabled
[8] Restrict arming on battery/AC failure N Disabled N Enabled
* A 40VA transformer is required when selecting the 850mA battery charge current. Using a 20VA
transformer with a battery charge current of 850mA may damage the system.
Section [504]: Keypad & Other Options
Option OFF ON
[1] Multiple Actions in User Menu N Disabled N Enabled
[2] User Code length N Fixed (see option [3] below) N Flexible (1 to 6 digits)
[3] User Code length N 4-digits (if option [2] = off) N 6-digits (if option [2] = off)
[4] Power Save Mode N Disabled N Enabled
[5] Bypass not displayed while system is armed N Disabled N Enabled
[6] Trouble Latch N Disabled N Enabled
[7] EOL resistor on hardwire inputs N Disabled N Enabled
[8] ATZ (Zone Doubling) N Disabled N Enabled
Section [501]: System Options
Zone & Module Tamper Recognition Options
[5] [6]
OFF OFF Disabled (default)
ON OFF When disarmed: GENERATES TROUBLE ONLY
When armed: Follows Zone Alarm Types (page 5)
OFF ON GENERATES TROUBLE ONLY (armed or disarmed)
ON ON When disarmed: GENERATES AUDIBLE ALARM
When armed: Follows Zone Alarm Types (page 5)
Digiplex DGP-848 - 20 - Programming Guide
Partition 1: Options
Bold = Default setting
* If the keypad is assigned to more than one partition, the feature must be enabled in all the keypad’s partitions.
Section [505]: Partition 1 Options
Option OFF ON
[1] Switch to Stay Arming (if no delay zone opened) N Disabled N Enabled
[2] Partition 1 arms & disarms with Partition 2 N Disabled N Enabled
[3] Partition 1 arms & disarms with Partition 3 N Disabled N Enabled
[4] Partition 1 arms & disarms with Partition 4 N Disabled N Enabled
[5] Timed Auto-Arming N Disabled N Enabled
[6] “No Movement” Auto-Arming N Disabled N Enabled
[7] Arming method for auto arming N Force Arming N Stay Arming
[8] Exit Delay termination N Disabled N Enabled
Section [506]: Partition 1 Options
Option OFF ON
[1] Panic 1 (keys [1] and [3]) N Disabled N Enabled
[2] Panic 2 (keys [4] and [6]) N Disabled N Enabled
[3] Panic 3 (keys [7] and [9]) N Disabled N Enabled
[4] Panic 1 alarm type N Report Only N Audible Alarm
[5] Panic 2 alarm type N Report Only N Audible Alarm
[6] Panic 3 alarm type N Report Only N Fire Alarm
[7] Report Disarming Options N Always report disarming N Report disarming only after alarm
[8] Always Force Arm When Regular Arming N Disabled N Enabled
Section [507]: Partition 1 Options
Option OFF ON
[1] Bell Squawk upon Disarming N Disabled N Enabled
[2] Bell Squawk upon Arming N Disabled N Enabled
[3] Bell Squawk upon Auto-Arming N Disabled N Enabled
[4] Bell Squawk during Exit Delay N Disabled N Enabled
[5] Bell Squawk during Entry Delay N Disabled N Enabled
[6] Bell Squawk upon Remote Arming/Disarming N Disabled N Enabled
[7] Ring Back: bell squawk if disarmed after alarm N Disabled N Enabled
[8] Ring Back: keypad beeps if disarmed after alarm N Disabled N Enabled
Section [508]*: Partition 1 Options
Option OFF ON
[1] One-Touch Regular Arming N Disabled N Enabled
[2] One-Touch St ay Arming N Disabled N Enabled
[3] One-Touch Instant Arming N Disabled N Enabled
[4] One-Touch Force Arming N Disabled N Enabled
[5] One-Touch St ay or Instant Disarming N Disabled N Enabled
[6] One-Touch Bypass Programming N Disabled N Enabled
[7] One-Touch Event Display N Disabled N Enabled
[8] No Exit Delay when arming with remote control N Disabled N Enabled
Digiplex DGP-848 - 21 - Programming Guide
Partition 2: Options
Bold = Default setting
* If the keypad is assigned to more than one partition, the feature must be enabled in all the keypad’s partitions.
Section [509]: Partition 2 Options
Option OFF ON
[1] Partition 2 arms & disarms with Partition 1 N Disabled N Enabled
[2] Switch to Stay Arming (if no delay zone opened) N Disabled N Enabled
[3] Partition 2 arms & disarms with Partition 3 N Disabled N Enabled
[4] Partition 2 arms & disarms with Partition 4 N Disabled N Enabled
[5] Timed Auto-Arming N Disabled N Enabled
[6] “No Movement” Auto-Arming N Disabled N Enabled
[7] Arming method for auto arming N Force Arming N Stay Arming
[8] Exit Delay termination N Disabled N Enabled
Section [510]: Partition 2 Options
Option OFF ON
[1] Panic 1 (keys [1] and [3]) N Disabled N Enabled
[2] Panic 2 (keys [4] and [6]) N Disabled N Enabled
[3] Panic 3 (keys [7] and [9]) N Disabled N Enabled
[4] Panic 1 alarm type N Report Only N Audible Alarm
[5] Panic 2 alarm type N Report Only N Audible Alarm
[6] Panic 3 alarm type N Report Only N Fire Alarm
[7] Report Disarming Options N Always report disarming N Report disarming only after alarm
[8] Always Force Arm When Regular Arming N Disabled N Enabled
Section [511]: Partition 2 Options
Option OFF ON
[1] Bell Squawk upon Disarming N Disabled N Enabled
[2] Bell Squawk upon Arming N Disabled N Enabled
[3] Bell Squawk upon Auto-Arming N Disabled N Enabled
[4] Bell Squawk during Exit Delay N Disabled N Enabled
[5] Bell Squawk during Entry Delay N Disabled N Enabled
[6] Bell Squawk upon Remote Arming/Disarming N Disabled N Enabled
[7] Ring Back: bell squawk if disarmed after alarm N Disabled N Enabled
[8] Ring Back: keypad beeps if disarmed after alarm N Disabled N Enabled
Section [512]*: Partition 2 Options
Option OFF ON
[1] One-Touch Regular Arming N Disabled N Enabled
[2] One-Touch St ay Arming N Disabled N Enabled
[3] One-Touch Instant Arming N Disabled N Enabled
[4] One-Touch Force Arming N Disabled N Enabled
[5] One-Touch St ay or Instant Disarming N Disabled N Enabled
[6] One-Touch Bypass Programming N Disabled N Enabled
[7] One-Touch Event Display N Disabled N Enabled
[8] No Exit Delay when arming with remote control N Disabled N Enabled
Digiplex DGP-848 - 22 - Programming Guide
Partition 3: Options
Bold = Default setting
* If the keypad is assigned to more than one partition, the feature must be enabled in all the keypad’s partitions.
Section [513]: Partition 3 Options
Option OFF ON
[1] Partition 3 arms & disarms with Partition 1 N Disabled N Enabled
[2] Partition 3 arms & disarms with Partition 2 N Disabled N Enabled
[3] Switch to Stay Arming (if no delay zone opened) N Disabled N Enabled
[4] Partition 3 arms & disarms with Partition 4 N Disabled N Enabled
[5] Timed Auto-Arming N Disabled N Enabled
[6] “No Movement” Auto-Arming N Disabled N Enabled
[7] Arming method for auto arming N Force Arming N Stay Arming
[8] Exit Delay termination N Disabled N Enabled
Section [514]: Partition 3 Options
Option OFF ON
[1] Panic 1 (keys [1] and [3]) N Disabled N Enabled
[2] Panic 2 (keys [4] and [6]) N Disabled N Enabled
[3] Panic 3 (keys [7] and [9]) N Disabled N Enabled
[4] Panic 1 alarm type N Report Only N Audible Alarm
[5] Panic 2 alarm type N Report Only N Audible Alarm
[6] Panic 3 alarm type N Report Only N Fire Alarm
[7] Report Disarming Options N Always report disarming N Report disarming only after alarm
[8] Always Force Arm When Regular Arming N Disabled N Enabled
Section [515]: Partition 3 Options
Option OFF ON
[1] Bell Squawk upon Disarming N Disabled N Enabled
[2] Bell Squawk upon Arming N Disabled N Enabled
[3] Bell Squawk upon Auto-Arming N Disabled N Enabled
[4] Bell Squawk during Exit Delay N Disabled N Enabled
[5] Bell Squawk during Entry Delay N Disabled N Enabled
[6] Bell Squawk upon Remote Arming/Disarming N Disabled N Enabled
[7] Ring Back: bell squawk if disarmed after alarm N Disabled N Enabled
[8] Ring Back: keypad beeps if disarmed after alarm N Disabled N Enabled
Section [516]*: Partition 3 Options
Option OFF ON
[1] One-Touch Regular Arming N Disabled N Enabled
[2] One-Touch St ay Arming N Disabled N Enabled
[3] One-Touch Instant Arming N Disabled N Enabled
[4] One-Touch Force Arming N Disabled N Enabled
[5] One-Touch St ay or Instant Disarming N Disabled N Enabled
[6] One-Touch Bypass Programming N Disabled N Enabled
[7] One-Touch Event Display N Disabled N Enabled
[8] No Exit Delay when arming with remote control N Disabled N Enabled
Digiplex DGP-848 - 23 - Programming Guide
Partition 4: Options
Bold = Default setting
* If the keypad is assigned to more than one partition, the feature must be enabled in all the keypad’s partitions.
Section [517]: Partition 4 Options
Option OFF ON
[1] Partition 4 arms & disarms with Partition 1 N Disabled N Enabled
[2] Partition 4 arms & disarms with Partition 2 N Disabled N Enabled
[3] Partition 4 arms & disarms with Partition 3 N Disabled N Enabled
[4] Switch to Stay Arming (if no delay zone opened) N Disabled N Enabled
[5] Timed Auto-Arming N Disabled N Enabled
[6] “No Movement” Auto-Arming N Disabled N Enabled
[7] Arming method for auto arming N Force Arming N Stay Arming
[8] Exit Delay termination N Disabled N Enabled
Section [518]: Partition 4 Options
Option OFF ON
[1] Panic 1 (keys [1] and [3]) N Disabled N Enabled
[2] Panic 2 (keys [4] and [6]) N Disabled N Enabled
[3] Panic 3 (keys [7] and [9]) N Disabled N Enabled
[4] Panic 1 alarm type N Report Only N Audible Alarm
[5] Panic 2 alarm type N Report Only N Audible Alarm
[6] Panic 3 alarm type N Report Only N Fire Alarm
[7] Report Disarming Options N Always report disarming N Report disarming only after alarm
[8] Always Force Arm When Regular Arming N Disabled N Enabled
Section [519]: Partition 4 Options
Option OFF ON
[1] Bell Squawk upon Disarming N Disabled N Enabled
[2] Bell Squawk upon Arming N Disabled N Enabled
[3] Bell Squawk upon Auto-Arming N Disabled N Enabled
[4] Bell Squawk during Exit Delay N Disabled N Enabled
[5] Bell Squawk during Entry Delay N Disabled N Enabled
[6] Bell Squawk upon Remote Arming/Disarming N Disabled N Enabled
[7] Ring Back: bell squawk if disarmed after alarm N Disabled N Enabled
[8] Ring Back: keypad beeps if disarmed after alarm N Disabled N Enabled
Section [520]*: Partition 4 Options
Option OFF ON
[1] One-Touch Regular Arming N Disabled N Enabled
[2] One-Touch St ay Arming N Disabled N Enabled
[3] One-Touch Instant Arming N Disabled N Enabled
[4] One-Touch Force Arming N Disabled N Enabled
[5] One-Touch St ay or Instant Disarming N Disabled N Enabled
[6] One-Touch Bypass Programming N Disabled N Enabled
[7] One-Touch Event Display N Disabled N Enabled
[8] No Exit Delay when arming with remote control N Disabled N Enabled
Digiplex DGP-848 - 24 - Programming Guide
Dialer Options
Bold = Default setting
* For UL installations, option [5] must be set to ON.
Section [521]: Dialer Options
Option OFF ON
[1]&[2]
N see table
N see table
N see table
N see table
[3] Dialer (reporting to monitoring station) N Disabled N Enabled
[4] Dialing Method N Pulse N Tone (DTMF)
[5] Pulse Ratio N 1:2 (Europe) N 1:1.5 (North America)
[6] Busy Tone Detection N Disabled N Enabled
[7] Switch to pulse dialing on 5th attempt N Disabled N Enabled
[8]
Bell/Siren upon Communication Failure if
system is armed
N Disabled N Enabled
Section [522]: Dialer Options
Option OFF ON
[1] Call Back N Disabled N Enabled
[2] Automatic Event Buffer Transmission N Disabled N Enabled
[3] Hourly Test Transmission N Disabled N Enabled
[4] Shabbat Feature N Disabled N Enabled
[5] Clear Bell Limit Trouble* N On Restore N Manually
[6] Alternate Dial N Disabled N Enabled
[7] Dial Tone Delay N Force dial if no dial tone N Hang-up if no dial tone
[8] Report zone restore options N On bell cut-off N On zone closure
Telephone Line Monitoring (TLM) Options
[1] [2]
OFF OFF Disabled (default)
OFF ON When armed: GENERATES AUDIBLE ALARM
ON OFF
When armed: GENERATES TROUBLE ONLY
ON ON TLM silent alarm: BECOMES AUDIBLE ALARM
Digiplex DGP-848 - 25 - Programming Guide
Partition 1: Event Call Direction
Bold = Default setting
Section [523]: ARMING AND DISARMING REPORT CODES (PARTITION 1)
Option OFF ON
[1] Call Telephone Number 1 (see section [561]) N Disabled N Enabled
[2] Call Telephone Number 2 (see section [562]) N Disabled N Enabled
[3] Call Telephone Number 3 (see section [563]) N Disabled N Enabled
[4] Call Telephone Number 4 (see section [564]) N Disabled N Enabled
[5] Backup on Telephone Number 1 N Disabled N Enabled
[6] Backup on Telephone Number 2 N Disabled N Enabled
[7] Backup on Telephone Number 3 N Disabled N Enabled
[8] Backup on Telephone Number 4 N Disabled N Enabled
Section [524]: ALARM AND ALARM RESTORE REPORT CODES (PARTITION 1)
Option OFF ON
[1] Call Telephone Number 1 (see section [561]) N Disabled N Enabled
[2] Call Telephone Number 2 (see section [562]) N Disabled N Enabled
[3] Call Telephone Number 3 (see section [563]) N Disabled N Enabled
[4] Call Telephone Number 4 (see section [564]) N Disabled N Enabled
[5] Backup on Telephone Number 1 N Disabled N Enabled
[6] Backup on Telephone Number 2 N Disabled N Enabled
[7] Backup on Telephone Number 3 N Disabled N Enabled
[8] Backup on Telephone Number 4 N Disabled N Enabled
Section [525]: TAMPER AND TAMPER RESTORE REPORT CODES (PARTITION 1)
Option OFF ON
[1] Call Telephone Number 1 (see section [561]) N Disabled N Enabled
[2] Call Telephone Number 2 (see section [562]) N Disabled N Enabled
[3] Call Telephone Number 3 (see section [563]) N Disabled N Enabled
[4] Call Telephone Number 4 (see section [564]) N Disabled N Enabled
[5] Backup on Telephone Number 1 N Disabled N Enabled
[6] Backup on Telephone Number 2 N Disabled N Enabled
[7] Backup on Telephone Number 3 N Disabled N Enabled
[8] Backup on Telephone Number 4 N Disabled N Enabled
Digiplex DGP-848 - 26 - Programming Guide
Partition 2: Event Call Direction
Bold = Default setting
Section [526]: ARMING AND DISARMING REPORT CODES (PARTITION 2)
Option OFF ON
[1] Call Telephone Number 1 (see section [561]) N Disabled N Enabled
[2] Call Telephone Number 2 (see section [562]) N Disabled N Enabled
[3] Call Telephone Number 3 (see section [563]) N Disabled N Enabled
[4] Call Telephone Number 4 (see section [564]) N Disabled N Enabled
[5] Backup on Telephone Number 1 N Disabled N Enabled
[6] Backup on Telephone Number 2 N Disabled N Enabled
[7] Backup on Telephone Number 3 N Disabled N Enabled
[8] Backup on Telephone Number 4 N Disabled N Enabled
Section [527]: ALARM AND ALARM RESTORE REPORT CODES (PARTITION 2)
Option OFF ON
[1] Call Telephone Number 1 (see section [561]) N Disabled N Enabled
[2] Call Telephone Number 2 (see section [562]) N Disabled N Enabled
[3] Call Telephone Number 3 (see section [563]) N Disabled N Enabled
[4] Call Telephone Number 4 (see section [564]) N Disabled N Enabled
[5] Backup on Telephone Number 1 N Disabled N Enabled
[6] Backup on Telephone Number 2 N Disabled N Enabled
[7] Backup on Telephone Number 3 N Disabled N Enabled
[8] Backup on Telephone Number 4 N Disabled N Enabled
Section [528]: TAMPER AND TAMPER RESTORE REPORT CODES (PARTITION 2)
Option OFF ON
[1] Call Telephone Number 1 (see section [561]) N Disabled N Enabled
[2] Call Telephone Number 2 (see section [562]) N Disabled N Enabled
[3] Call Telephone Number 3 (see section [563]) N Disabled N Enabled
[4] Call Telephone Number 4 (see section [564]) N Disabled N Enabled
[5] Backup on Telephone Number 1 N Disabled N Enabled
[6] Backup on Telephone Number 2 N Disabled N Enabled
[7] Backup on Telephone Number 3 N Disabled N Enabled
[8] Backup on Telephone Number 4 N Disabled N Enabled
Digiplex DGP-848 - 27 - Programming Guide
Partition 3: Event Call Direction
Bold = Default setting
Section [529]: ARMING AND DISARMING REPORT CODES (PARTITION 3)
Option OFF ON
[1] Call Telephone Number 1 (see section [561]) N Disabled N Enabled
[2] Call Telephone Number 2 (see section [562]) N Disabled N Enabled
[3] Call Telephone Number 3 (see section [563]) N Disabled N Enabled
[4] Call Telephone Number 4 (see section [564]) N Disabled N Enabled
[5] Backup on Telephone Number 1 N Disabled N Enabled
[6] Backup on Telephone Number 2 N Disabled N Enabled
[7] Backup on Telephone Number 3 N Disabled N Enabled
[8] Backup on Telephone Number 4 N Disabled N Enabled
Section [530]: ALARM AND ALARM RESTORE REPORT CODES (PARTITION 3)
Option OFF ON
[1] Call Telephone Number 1 (see section [561]) N Disabled N Enabled
[2] Call Telephone Number 2 (see section [562]) N Disabled N Enabled
[3] Call Telephone Number 3 (see section [563]) N Disabled N Enabled
[4] Call Telephone Number 4 (see section [564]) N Disabled N Enabled
[5] Backup on Telephone Number 1 N Disabled N Enabled
[6] Backup on Telephone Number 2 N Disabled N Enabled
[7] Backup on Telephone Number 3 N Disabled N Enabled
[8] Backup on Telephone Number 4 N Disabled N Enabled
Section [531]: TAMPER AND TAMPER RESTORE REPORT CODES (PARTITION 3)
Option OFF ON
[1] Call Telephone Number 1 (see section [561]) N Disabled N Enabled
[2] Call Telephone Number 2 (see section [562]) N Disabled N Enabled
[3] Call Telephone Number 3 (see section [563]) N Disabled N Enabled
[4] Call Telephone Number 4 (see section [564]) N Disabled N Enabled
[5] Backup on Telephone Number 1 N Disabled N Enabled
[6] Backup on Telephone Number 2 N Disabled N Enabled
[7] Backup on Telephone Number 3 N Disabled N Enabled
[8] Backup on Telephone Number 4 N Disabled N Enabled
Digiplex DGP-848 - 28 - Programming Guide
Partition 4: Event Call Direction
Bold = Default setting
Section [532]: ARMING AND DISARMING REPORT CODES (PARTITION 4)
Option OFF ON
[1] Call Telephone Number 1 (see section [561]) N Disabled N Enabled
[2] Call Telephone Number 2 (see section [562]) N Disabled N Enabled
[3] Call Telephone Number 3 (see section [563]) N Disabled N Enabled
[4] Call Telephone Number 4 (see section [564]) N Disabled N Enabled
[5] Backup on Telephone Number 1 N Disabled N Enabled
[6] Backup on Telephone Number 2 N Disabled N Enabled
[7] Backup on Telephone Number 3 N Disabled N Enabled
[8] Backup on Telephone Number 4 N Disabled N Enabled
Section [533]: ALARM AND ALARM RESTORE REPORT CODES (PARTITION 4)
Option OFF ON
[1] Call Telephone Number 1 (see section [561]) N Disabled N Enabled
[2] Call Telephone Number 2 (see section [562]) N Disabled N Enabled
[3] Call Telephone Number 3 (see section [563]) N Disabled N Enabled
[4] Call Telephone Number 4 (see section [564]) N Disabled N Enabled
[5] Backup on Telephone Number 1 N Disabled N Enabled
[6] Backup on Telephone Number 2 N Disabled N Enabled
[7] Backup on Telephone Number 3 N Disabled N Enabled
[8] Backup on Telephone Number 4 N Disabled N Enabled
Section [534]: TAMPER AND TAMPER RESTORE REPORT CODES (PARTITION 4)
Option OFF ON
[1] Call Telephone Number 1 (see section [561]) N Disabled N Enabled
[2] Call Telephone Number 2 (see section [562]) N Disabled N Enabled
[3] Call Telephone Number 3 (see section [563]) N Disabled N Enabled
[4] Call Telephone Number 4 (see section [564]) N Disabled N Enabled
[5] Backup on Telephone Number 1 N Disabled N Enabled
[6] Backup on Telephone Number 2 N Disabled N Enabled
[7] Backup on Telephone Number 3 N Disabled N Enabled
[8] Backup on Telephone Number 4 N Disabled N Enabled
Digiplex DGP-848 - 29 - Programming Guide
System Event Call Direction
Bold = Default setting
Global Access Control Features
*
Since “Request for Exit” events can occur often, the Event Buffer may fill up quickly.
Section [535]: SYSTEM TROUBLES AND TROUBLE RESTORES
Option OFF ON
[1] Call Telephone Number 1 (see section [561]) N Disabled N Enabled
[2] Call Telephone Number 2 (see section [562]) N Disabled N Enabled
[3] Call Telephone Number 3 (see section [563]) N Disabled N Enabled
[4] Call Telephone Number 4 (see section [564]) N Disabled N Enabled
[5] Backup on Telephone Number 1 N Disabled N Enabled
[6] Backup on Telephone Number 2 N Disabled N Enabled
[7] Backup on Telephone Number 3 N Disabled N Enabled
[8] Backup on Telephone Number 4 N Disabled N Enabled
Section [536]: SPECIAL REPORTING
Option OFF ON
[1] Call Telephone Number 1 (see section [561]) N Disabled N Enabled
[2] Call Telephone Number 2 (see section [562]) N Disabled N Enabled
[3] Call Telephone Number 3 (see section [563]) N Disabled N Enabled
[4] Call Telephone Number 4 (see section [564]) N Disabled N Enabled
[5] Backup on Telephone Number 1 N Disabled N Enabled
[6] Backup on Telephone Number 2 N Disabled N Enabled
[7] Backup on Telephone Number 3 N Disabled N Enabled
[8] Backup on Telephone Number 4 N Disabled N Enabled
Section [537]: ACCESS CONTROL
Option OFF ON
[1] Access Control Feature N Disabled N Enabled
[2] Log “Request for Exit” in Event Buffer* N Disabled N Enabled
[3] Log “Door Left Open Restore” in Event Buffer N Disabled N Enabled
[4] Log “Door Forced Restore” in Event Buffer N Disabled N Enabled
[5] Burglar Alarm on Forced Door N Disabled N Enabled
[6] Skip Exit Delay when Arming with Card N Disabled N Enabled
[7] Burglar Alarm on Door Left Open N Disabled N Enabled
[8]
Access to Doors During Clock Loss and Clock
Resetting
N
Granted to all users N Granted Only to Masters
Digiplex DGP-848 - 30 - Programming Guide
Communication Settings
Only SIA formats support the “0” digit in its account numbers. For account numbers that use another reporting format,
you must replace the “0” with an “A”. To enter an “A”, press the [STAY] key on LCD keypads or the [#] key on Grafica
keypads. When using the SIA Format, the control panel will only use Partition Account Number 1 programmed in section
[551], but the report code will include the partition number.
For North American installations using either SIA or Contact ID reporting formats, enter *70 and then either P (4-second
pause) or W (wait for second dial tone) before the phone number in sections [560] to [564] to disable call-waiting
.
Table 2: Special Telephone Number Keys
Section # Description
[550]
___ ___ ___ ___
REPORTING FORMATS FOR TELEPHONE NUMBERS 1 TO 4
Section # Hexa Value (0-FFFF) Description
If less than 4 digits, press [
ENTER]
[551]
___/___/___/___ PARTITION 1: ACCOUNT NUMBER
[552]
___/___/___/___ PARTITION 2: ACCOUNT NUMBER
[553]
___/___/___/___ PARTITION 3: ACCOUNT NUMBER
[554]
___/___/___/___ PARTITION 4: ACCOUNT NUMBER
[555]
___/___/___/___ PANEL IDENTIFIER (FOR WINLOAD SOFTWARE)
[556]
___/___/___/___ PC PASSWORD (FOR WINLOAD SOFTWARE)
[560]
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
PC TELEPHONE NUMBER FOR WINLOAD SOFTWARE (press [ENTER] if less than 32 digits)
[561]
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
MONITORING STATION/PAGER TELEPHONE NUMBER 1 (press [ENTER] if less than 32 digits)
[562]
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
MONITORING STATION/PAGER TELEPHONE NUMBER 2 (press [ENTER] if less than 32 digits)
[563]
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
MONITORING STATION/PAGER TELEPHONE NUMBER 3 (press [ENTER] if less than 32 digits)
[564]
__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__
MONITORING STATION/PAGER TELEPHONE NUMBER 4 (press [ENTER] if less than 32 digits)
Function LCD Grafica Function LCD Grafica
*
[STAY]
[#]
(press key until desired
letter/symbol appears)
Clear
[
CLEAR] Left action key (Clear)
# [
FORCE] Delete [TRBL] —
Switch to Tone Dialing (T) [
ARM] Delete from cursor to the end [ACC] —
Wait for second dial tone (W) [
DISARM] Insert space [MEM] —
4-second pause (P) [
BYP]
USE THE SAME FORMAT FOR EACH NUMBER.
ONLY THE PAGER FORMAT CAN BE USED
WITH OTHER REPORTING FORMATS.
For more information refer to Automatic
Report Code Programming on page 35.
Digiplex DGP-848 - 31 - Programming Guide
Report Codes
Each section from [600] to [718] contains up to four reportable event s as defined on the following pages.
Ademco slow, Silent Knight fast, SESCOA, Ademco express or Pager formats:
Key-in desired 1 or 2-digit hexa values from 0 to FF.
Ademco format:
Use sections [790] to [795] to program a set of default Ademco report codes from the Automatic Report Code List on page
36. Then to program the remaining report codes or to change some of the defaults, enter the individual sections and key-in
the desired 2-digit hexa values found in the Conta ct ID Report Code List on page 38.
SIA format:
Use sections [790] to [795] to program a set of default SIA report codes from the Automatic Report Code List on page 36.
Codes that have not been set to default can be set to default manually by entering FF in the appropriate section. To disable
reporting of an event, enter 00 in the appropriate section.
Arming Report Codes
[600]: __ /__ Access code 1
__ /__ Access code 2
__ /__ Access code 3
__ /__ Access code 4
[601]: __ /__ Access code 5
__ /__ Access code 6
__ /__ Access code 7
__ /__ Access code 8
[602]: __ /__ Access code 9
__ /__ Access code 10
__ /__ Access code 11
__ /__ Access code 12
[603]: __ /__ Access code 13
__ /__ Access code 14
__ /__ Access code 15
__ /__ Access code 16
[604]: __ /__ Access code 17
__ /__ Access code 18
__ /__ Access code 19
__ /__ Access code 20
[605]: __ /__ Access code 21
__ /__ Access code 22
__ /__ Access code 23
__ /__ Access code 24
[606]: __ /__ Access code 25
__ /__ Access code 26
__ /__ Access code 27
__ /__ Access code 28
[607]: __ /__ Access code 29
__ /__ Access code 30
__ /__ Access code 31
__ /__ Access code 32
[608]: __ /__ Access code 33
__ /__ Access code 34
__ /__ Access code 35
__ /__ Access code 36
[609]: __ /__ Access code 37
__ /__ Access code 38
__ /__ Access code 39
__ /__ Access code 40
[610]: __ /__ Access code 41
__ /__ Access code 42
__ /__ Access code 43
__ /__ Access code 44
[611]: __ /__ Access code 45
__ /__ Access code 46
__ /__ Access code 47
__ /__ Access code 48
[612]: __ /__ Access code 49
__ /__ Access code 50
__ /__ Access code 51
__ /__ Access code 52
[613]: __ /__ Access code 53
__ /__ Access code 54
__ /__ Access code 55
__ /__ Access code 56
[614]: __ /__ Access code 57
__ /__ Access code 58
__ /__ Access code 59
__ /__ Access code 60
[615]: __ /__ Access code 61
__ /__ Access code 62
__ /__ Access code 63
__ /__ Access code 64
[616]: __ /__ Access code 65
__ /__ Access code 66
__ /__ Access code 67
__ /__ Access code 68
[617]: __ /__ Access code 69
__ /__ Access code 70
__ /__ Access code 71
__ /__ Access code 72
[618]: __ /__ Access code 73
__ /__ Access code 74
__ /__ Access code 75
__ /__ Access code 76
[619]: __ /__ Access code 77
__ /__ Access code 78
__ /__ Access code 79
__ /__ Access code 80
[620]: __ /__ Access code 81
__ /__ Access code 82
__ /__ Access code 83
__ /__ Access code 84
[621]: __ /__ Access code 85
__ /__ Access code 86
__ /__ Access code 87
__ /__ Access code 88
[622]: __ /__ Access code 89
__ /__ Access code 90
__ /__ Access code 91
__ /__ Access code 92
[623]: __ /__ Access code 93
__ /__ Access code 94
__ /__ Access code 95
__ /__ Access code 96
Digiplex DGP-848 - 32 - Programming Guide
Arming Report Codes (con’t)
Disarming Report Codes
[624]: __ /__ Keyswitch 1
__ /__ Keyswitch 2
__ /__ Keyswitch 3
__ /__ Keyswitch 4
[625]: __ /__ Keyswitch 5
__ /__ Keyswitch 6
__ /__ Keyswitch 7
__ /__ Keyswitch 8
SPECIAL ARMING CODES
[626]: __ /__ Auto-Arming
__ /__ PC/Remote Arming
__ /__ Late to close
__ /__ No Movement
[627]: __ /__ Partial Arming
__ /__ Quick Arming
__ /__ Closing Delinquency
__ /__ N/A
[628]: __ /__ Access code 1
__ /__ Access code 2
__ /__ Access code 3
__ /__ Access code 4
[629]: __ /__ Access code 5
__ /__ Access code 6
__ /__ Access code 7
__ /__ Access code 8
[630]: __ /__ Access code 9
__ /__ Access code 10
__ /__ Access code 11
__ /__ Access code 12
[631]: __ /__ Access code 13
__ /__ Access code 14
__ /__ Access code 15
__ /__ Access code 16
[632]: __ /__ Access code 17
__ /__ Access code 18
__ /__ Access code 19
__ /__ Access code 20
[633]: __ /__ Access code 21
__ /__ Access code 22
__ /__ Access code 23
__ /__ Access code 24
[634]: __ /__ Access code 25
__ /__ Access code 26
__ /__ Access code 27
__ /__ Access code 28
[635]: __ /__ Access code 29
__ /__ Access code 30
__ /__ Access code 31
__ /__ Access code 32
[636]: __ /__ Access code 33
__ /__ Access code 34
__ /__ Access code 35
__ /__ Access code 36
[637]: __ /__ Access code 37
__ /__ Access code 38
__ /__ Access code 39
__ /__ Access code 40
[638]: __ /__ Access code 41
__ /__ Access code 42
__ /__ Access code 43
__ /__ Access code 44
[639]: __ /__ Access code 45
__ /__ Access code 46
__ /__ Access code 47
__ /__ Access code 48
[640]: __ /__ Access code 49
__ /__ Access code 50
__ /__ Access code 51
__ /__ Access code 52
[641]: __ /__ Access code 53
__ /__ Access code 54
__ /__ Access code 55
__ /__ Access code 56
[642]: __ /__ Access code 57
__ /__ Access code 58
__ /__ Access code 59
__ /__ Access code 60
[643]: __ /__ Access code 61
__ /__ Access code 62
__ /__ Access code 63
__ /__ Access code 64
[644]: __ /__ Access code 65
__ /__ Access code 66
__ /__ Access code 67
__ /__ Access code 68
[645]: __ /__ Access code 69
__ /__ Access code 70
__ /__ Access code 71
__ /__ Access code 72
[646]: __ /__ Access code 73
__ /__ Access code 74
__ /__ Access code 75
__ /__ Access code 76
[647]: __ /__ Access code 77
__ /__ Access code 78
__ /__ Access code 79
__ /__ Access code 80
[648]: __ /__ Access code 81
__ /__ Access code 82
__ /__ Access code 83
__ /__ Access code 84
[649]: __ /__ Access code 85
__ /__ Access code 86
__ /__ Access code 87
__ /__ Access code 88
[650]: __ /__ Access code 89
__ /__ Access code 90
__ /__ Access code 91
__ /__ Access code 92
[651]: __ /__ Access code 93
__ /__ Access code 94
__ /__ Access code 95
__ /__ Access code 96
Digiplex DGP-848 - 33 - Programming Guide
Disarming Report Codes (con’t)
Alarm Report Codes
Alarm Restore Report Codes
Special Alarm Report Codes
[652]: __ /__ Keyswitch 1
__ /__ Keyswitch 2
__ /__ Keyswitch 3
__ /__ Keyswitch 4
[653]: __ /__ Keyswitch 5
__ /__ Keyswitch 6
__ /__ Keyswitch 7
__ /__ Keyswitch 8
SPECIAL DISARMING CODES
[654]: __ /__ Cancel Auto-arm
__ /__ Quick Disarm
__ /__ PC/Remote Disarm
__ /__ Cancel Alarm
[655]: __ /__ Zone 1
__ /__ Zone 2
__ /__ Zone 3
__ /__ Zone 4
[656]: __ /__ Zone 5
__ /__ Zone 6
__ /__ Zone 7
__ /__ Zone 8
[657]: __ /__ Zone 9
__ /__ Zone 10
__ /__ Zone 11
__ /__ Zone 12
[658]: __ /__ Zone 13
__ /__ Zone 14
__ /__ Zone 15
__ /__ Zone 16
[659]: __ /__ Zone 17
__ /__ Zone 18
__ /__ Zone 19
__ /__ Zone 20
[660]: __ /__ Zone 21
__ /__ Zone 22
__ /__ Zone 23
__ /__ Zone 24
[661]: __ /__ Zone 25
__ /__ Zone 26
__ /__ Zone 27
__ /__ Zone 28
[662]: __ /__ Zone 29
__ /__ Zone 30
__ /__ Zone 31
__ /__ Zone 32
[663]: __ /__ Zone 33
__ /__ Zone 34
__ /__ Zone 35
__ /__ Zone 36
[664]: __ /__ Zone 37
__ /__ Zone 38
__ /__ Zone 39
__ /__ Zone 40
[665]: __ /__ Zone 41
__ /__ Zone 42
__ /__ Zone 43
__ /__ Zone 44
[666]: __ /__ Zone 45
__ /__ Zone 46
__ /__ Zone 47
__ /__ Zone 48
[667]: __ /__ Zone 1
__ /__ Zone 2
__ /__ Zone 3
__ /__ Zone 4
[668]: __ /__ Zone 5
__ /__ Zone 6
__ /__ Zone 7
__ /__ Zone 8
[669]: __ /__ Zone 9
__ /__ Zone 10
__ /__ Zone 11
__ /__ Zone 12
[670]: __ /__ Zone 13
__ /__ Zone 14
__ /__ Zone 15
__ /__ Zone 16
[671]: __ /__ Zone 17
__ /__ Zone 18
__ /__ Zone 19
__ /__ Zone 20
[672]: __ /__ Zone 21
__ /__ Zone 22
__ /__ Zone 23
__ /__ Zone 24
[673]: __ /__ Zone 25
__ /__ Zone 26
__ /__ Zone 27
__ /__ Zone 28
[674]: __ /__ Zone 29
__ /__ Zone 30
__ /__ Zone 31
__ /__ Zone 32
[675]: __ /__ Zone 33
__ /__ Zone 34
__ /__ Zone 35
__ /__ Zone 36
[676]: __ /__ Zone 37
__ /__ Zone 38
__ /__ Zone 39
__ /__ Zone 40
[677]: __ /__ Zone 41
__ /__ Zone 42
__ /__ Zone 43
__ /__ Zone 44
[678]: __ /__ Zone 45
__ /__ Zone 46
__ /__ Zone 47
__ /__ Zone 48
[679]: __ /__ Emergency Panic
__ /__ Auxiliary Panic
__ /__ Fire Panic
__ /__ Recent Closing
[680]: __ /__ N/A
__ /__ Auto Zone Shutdown
__ /__ N/A
__ /__ Duress
Digiplex DGP-848 - 34 - Programming Guide
Zone Tamper Report Codes
Zone Tamper Restore Report Codes
Special Tamper Report Codes
[681]: __ /__ Zone 1
__ /__ Zone 2
__ /__ Zone 3
__ /__ Zone 4
[682]: __ /__ Zone 5
__ /__ Zone 6
__ /__ Zone 7
__ /__ Zone 8
[683]: __ /__ Zone 9
__ /__ Zone 10
__ /__ Zone 11
__ /__ Zone 12
[684]: __ /__ Zone 13
__ /__ Zone 14
__ /__ Zone 15
__ /__ Zone 16
[685]: __ /__ Zone 17
__ /__ Zone 18
__ /__ Zone 19
__ /__ Zone 20
[686]: __ /__ Zone 21
__ /__ Zone 22
__ /__ Zone 23
__ /__ Zone 24
[687]: __ /__ Zone 25
__ /__ Zone 26
__ /__ Zone 27
__ /__ Zone 28
[688]: __ /__ Zone 29
__ /__ Zone 30
__ /__ Zone 31
__ /__ Zone 32
[689]: __ /__ Zone 33
__ /__ Zone 34
__ /__ Zone 35
__ /__ Zone 36
[690]: __ /__ Zone 37
__ /__ Zone 38
__ /__ Zone 39
__ /__ Zone 40
[691]: __ /__ Zone 41
__ /__ Zone 42
__ /__ Zone 43
__ /__ Zone 44
[692]: __ /__ Zone 45
__ /__ Zone 46
__ /__ Zone 47
__ /__ Zone 48
[693]: __ /__ Zone 1
__ /__ Zone 2
__ /__ Zone 3
__ /__ Zone 4
[694]: __ /__ Zone 5
__ /__ Zone 6
__ /__ Zone 7
__ /__ Zone 8
[695]: __ /__ Zone 9
__ /__ Zone 10
__ /__ Zone 11
__ /__ Zone 12
[696]: __ /__ Zone 13
__ /__ Zone 14
__ /__ Zone 15
__ /__ Zone 16
[697]: __ /__ Zone 17
__ /__ Zone 18
__ /__ Zone 19
__ /__ Zone 20
[698]: __ /__ Zone 21
__ /__ Zone 22
__ /__ Zone 23
__ /__ Zone 24
[699]: __ /__ Zone 25
__ /__ Zone 26
__ /__ Zone 27
__ /__ Zone 28
[700]: __ /__ Zone 29
__ /__ Zone 30
__ /__ Zone 31
__ /__ Zone 32
[701]: __ /__ Zone 33
__ /__ Zone 34
__ /__ Zone 35
__ /__ Zone 36
[702]: __ /__ Zone 37
__ /__ Zone 38
__ /__ Zone 39
__ /__ Zone 40
[703]: __ /__ Zone 41
__ /__ Zone 42
__ /__ Zone 43
__ /__ Zone 44
[704]: __ /__ Zone 45
__ /__ Zone 46
__ /__ Zone 47
__ /__ Zone 48
[705]: __ /__ Keypad Lock Out
__ /__ N/A
__ /__ N/A
__ /__ N/A
Digiplex DGP-848 - 35 - Programming Guide
System Trouble Report Codes
System Trouble Restore Report Codes
Special Report Codes
Automatic Report Code Programming
When using Contact ID or SIA Reporting formats (section [550] page 30), default report codes can be programmed
automatically. After automatic defaults are set, they can be changed and the remaining report codes can be set manually.
Section # Description
Sets all the report codes in the following sections to the
default values from the “Automatic Report Codes List”:
[790]
ALL CODES [600] to [718]
[791]
ARMING & DISARMING CODES [600] to [654]
[792]
ALARM & ALARM RESTORE CODES [655] to [680]
[793]
TAMPER & TAMPER RESTORE CODES [681] to [705]
[794]
TROUBLE & TROUBLE RESTORE CODES [706] to [716]
[795] S
PECIAL CODES [717] to [718]
[706]: __ /__ N/A
__ /__ AC Failure
__ /__ Battery Failure
(disconnect or low)
__ /__ Auxiliary Supply
[707]: __ /__ Bell Output (disconnect
or overload)
__ /__ Timer Loss
__ /__ Fire Loop Trbl.
__ /__ N/A
[708]: __ /__ Combus Fault
__ /__ Module tamper
__ /__ Module ROM check
error
__ /__ Module TLM Fail
[709]: __ /__ Module fail to com.
__ /__ Printer fault
__ /__ Module AC failure
__ /__ Module battery failure
[710]: __ /__ Module auxiliary failure
__ /__ Low battery wireless tx.
__ /__ Wireless transmitter
supervision trouble
__ /__ N/A
[711]: __ /__ Tel# 1 fail to com.
__ /__ Tel# 2 fail to com.
__ /__ Tel# 3 fail to com.
__ /__ Tel# 4 fail to com.
[712]: __ /__ TLM restore
__ /__ AC restore
__ /__ Battery failure restore
(disconnect or low)
__ /__ Aux. supply restore
[713]: __ /__ Bell output (disc on n ec t
or overload) restore
__ /__ Timer programmed
__ /__ Fire loop restore
__ /__ N/A
[714]: __ /__ Combus fault restore
__ /__ Module tamper restore
__ /__ Module ROM check
error restore
__ /__ Module TLM restore
[715]: __ /__ N/A
__ /__ Printer fault restore
__ /__ Module AC restore
__ /__ Module battery restore
[716]: __ /__ Module aux. restore
__ /__ Wireless transmitter
battery restore
__ /__ Wireless transmitter
supervision restore
__ /__ N/A
[717]: __ /__ Cold start (sys. shutdown)
__ /__ Warm start (sys. reset)
__ /__ Test report
__ /__ N/A
[718]: __ /__ N/A
__ /__ PC access finished
__ /__ Installer in
__ /__ Installer out
Digiplex DGP-848 - 36 - Programming Guide
Automatic Report Code List
System Event
Default Contact ID Report Code
when using sections [790] to [795]
Default SIA Report Code
when using sections [790] to [795]
Arming with Master Code (##) 3 4A1 - Close by user CL - Closing Report
Arming with User Code (##) 3 4A1 - Close by user CL - Closing Report
Arming with Keyswitch (##) 3 4A9 - Keyswitch Close CS - Closing Keyswitch
Auto Arming 3 4A3 - Automatic Close CA - Automatic Closing
Arm with PC software 3 4A7 - Remote arm/disarm CL - Closing Report
Late To Close 3 4A4 - Late to Close OT - Late to Close
No Movement 3 4A4 - Late to Close NA - No Activity
Partial arming 1 574 - Group bypass CG - Close Area
Quick arming 3 408 - Quick arm CL - Closing Report
Closing Delinquency 1 654 - System Inactivity CD - System Inactivity
Disarm with Master Code (##) 1 4A1 - Open by user OP - Opening Report
Disarm with User Code (##) 1 4A1 - Open by user OP - Opening Report
Disarm with Keyswitch (##) 1 4A9 - Keyswitch Open OS - Opening Keyswitch
Disarm after alarm* with Master Code (##) 1 4A1 - Open by user OP - Opening Report
Disarm after alarm* with User Code (##) 1 4A1 - Open by user OP - Opening Report
Disarm after alarm* with Keyswitch (##) 1 4A1 - Keyswitch Open OS - Opening Keyswitch
Cancel alarm** with Master Code (##) 1 4A6 - Open by User OR - Disarm from Alarm
Cancel alarm** with User Code (##) 1 4A6 - Open by User OR - Disarm from Alarm
Cancel alarm** with Keyswitch (##) 1 4A6 - Keyswitch Open OS - Opening Keyswitch
Auto Arming Cancellation 1 4A5 - Deferred Open/Close CE - Closing Extend
Disarm with PC software 1 4A7 - Remote arm/disarm OP - Opening Report
Disarm after an alarm with PC software 1 4A7 - Remote arm/disarm OR - Disarm From Alarm
Quick disarm 1 408 - Quick disarm OP - Opening Report
Zone Bypassed (##) 1 57A - Zone bypass UB - Untyped Zone Bypass
Zone alarm (##) 1 13A - Burglary Alarm BA - Burglary Alarm
Fire alarm (##) 1 11A - Fire alarm FA - Fire Alarm
Zone alarm restore (##) 3 13A - Burglary Alarm Restore BH - Burglary Alarm Restore
Fire alarm restore (##) 3 11A - Fire alarm Restore FH - Fire Alarm Restore
Panic 1 - Emergency 1 12A - Panic alarm PA - Panic Alarm
Panic 2 - Medical 1 1AA - Medical alarm MA - Medical Alarm
Panic 3 - Fire 1 115 - Pull Station FA - Fire Alarm
Recent closing 3 4AA - Open/Close CR - Recent Closing
Global zone shutdown 1 574 - Group bypass CG - Close Area
Duress alarm 1 121 - Duress HA - Hold-up Alarm
Zone shutdown (##) 1 57A - Zone bypass UB - Untyped Zone Bypass
Zone tampered (##) 1 144 - Sensor tamper TA - Tamper Alarm
Zone tamper restore (##) 3 144 - Sensor tamper restore TR - Tamper Restoral
Keypad Lockout 1 421 - Access den ied JA - User Code Tamper
* An armed system is or was in alarm and was disarmed by a user.
** A disarmed system is or was in alarm (e.g. 24Hr zone) and was disarm e d by a us er.
Digiplex DGP-848 - 37 - Programming Guide
AC Failure 1 3A1 - AC loss AT - AC Trouble
Battery Failure 1 3A9 - Battery test failure YT - System Battery Trouble
Auxiliary supply trouble 1 3AA - System trouble YP - Power Supply Trouble
Bell output current limit 1 321 - Bell 1 YA - Bell Fault
Bell absent 1 321 - Bell 1 YA - Bell Fault
Clock lost 1 626 - Time/Date inaccurate JT - Time Changed
Fire loop trouble 1 373 - Fire trouble FT - Fire Trouble
TLM trouble restore 3 351 - Telco 1 fault restore LR - Phone Line restoral
AC Failure restore 3 3A1 - AC loss restore AR - AC Restoral
Battery Failure restore 3 3A9 - Battery test restore YR - System Battery Restoral
Auxiliary supply trouble restore 3 3AA - System trouble restore YQ - Power Supply restored
Bell output current limit restore 3 321 - Bell 1 restore YH - Bell Restored
Bell absent restore 3 321 - Bell 1 restore YH - Bell Restored
Clock programmed 3 625 - Time/Date Reset JT - Time Changed
Fire loop trouble restore 3 373 - Fire trouble restore FJ - Fire Trouble Restore
Combus fault 1 333 - Expansion module failure ET - Expansion Trouble
Module tamper 1 145 - Expansion module tamper TA - Tamper Alarm
Module ROM_RAM_error 1 3A4 - Rom checksum bad YF - Parameter Checksum Fail
Module TLM trouble 1 352 - Telco 2 fault LT - Phone Line trouble
Module fail to communicate to monitoring
station.
1 354 - Fail to communicate YC - Communication Fails
Printer fault 1 336 - Local printer failure VT - Printer Trouble
Module AC Failure 1 3A1 - AC loss AT - AC Trouble
Module battery failure 1 3A9 - Battery test failure YT - System Battery Trouble
Module Auxiliary supply trouble 1 3AA - System trouble YP - Power Supply Trouble
Bus fault restore 3 333 - Expansion module failure restore ER - Expansion Restoral
Module tamper restore 3 145 - Expansion module tamper restore TR - Tamper Restoral
Module ROM_RAM_error restore 3 3A4 - Rom checksum bad restore YG - Parameter Changed
Module TLM restore 3 352 - Telco 2 fault restore LR - Phone Line Restoral
Printer fault restore 3 336 - Local printer failure restore VR - Printer Restore
Module AC restore 3 3A1 - AC loss restore AR - AC Restoral
Module battery restore 3 3A9 - Battery test failure restore YR - System Battery Restoral
Module Auxiliary supply restore 3 3AA - System trouble restore YQ - Power Supply Restored
Fail to communicate with monitoring station 1 354 - Fail to communicate YC - Communication Fails
Module RF low battery 1 384 - RF transmitter low battery XT - Transmitter Battery Trouble
Module RF battery restore 3 384 - RF transmitter battery restore XR - Transmitter Battery Restoral
Module RF supervision trouble 1 381 - Loss of supervision - RF US - Untype Zone Supervision
Module RF supervision restore 3 381 - Supervision restore - RF UR - Untyped Zone Restoral
Cold Star t 1 3A8 - System shutdown RR - Power Up
Warm Start 1 3A5 - System reset YW - Watchdog Reset
Test Report engaged 1 6A2 - Periodic test report TX - Test Report
PC software communication finished 1 412 - Successful - download access RS - Remote Program Success
Installer on site 1 627 - Program mode Entry LB - Local Program
Installer programming finished 1 628 - Program mode Exit LS - Local Program Success
System Event
Default Contact ID Report Code
when using sections [790] to [795]
Default SIA Report Code
when using sections [790] to [795]
Digiplex DGP-848 - 38 - Programming Guide
Contact ID Report Code List
If using the Ademco Contact ID format, key in the 2-digit hexadecimal value ( PROG. VALUE) to program the desired report
codes into sections [600] to [718].
CID# Reporting Code
Prog.
Value
CID# Reporting Code
Prog.
Value
CID# Reporting Code
Prog.
Value
MEDICAL ALARMS - 100 204 Low Water Level 2F 403 Automatic O/C 5D
100 Medical Alarm 01 205 Pump Activated 30 404 Late to O/C 5E
101 Pendant Transmitter 02 206 Pump Failure 31 405 Deferred 5F
102 Fail to Report In 03 SYSTEM TROUBLES - 300 & 310 406 Cancel 60
FIRE ALARMS - 110 300 System Trouble 32 407 Remote Arm/Disarm 61
110 Fire Alarm 04 301 AC Loss 33 408 Quick Arm 62
111 Smoke 05 302 Low System Battery 34 409 Keyswitch O/C 63
112 Combustion 06 303 RAM Checksum Bad 35 REMOTE ACCESS - 410
113 Water Flow 07 304 ROM Checksum Bad 36 411 Callback Request Made 64
114 Heat 08 305 System Reset 37 412 Success - Download Access 65
115 Pull Station 09 306 Panel Program Changed 38 413 Unsuccessful Access 66
116 Duct 0A 307 Self-Test Failure 39 414 System Shutdown 67
117 Flame 0B 308 System Shutdown 3A 415 Dialer Shutdown 68
118 Near Alarm 0C 309 Battery Test Failure 3B ACCESS CONTROL - 420
PANIC ALARMS - 120 310 Ground Fault 3C 421 Access Denied 69
120 Panic Alarm 0D SOUNDER/REL AY TROUBLES - 320 422 Access Report By User 6A
121 Duress 0E 320 Sounder Relay 3D SOUNDER RELAY DISABLES - 520
122 Silent 0F 321 Bell 1 3E 520 Sounder/Relay Disabled 6B
123 Audible 10 322 Bell 2 3F 521 Bell 1 Disable 6C
BURGLAR ALARMS - 130 323 Alarm Relay 40 522 Bell 2 Disable 6D
130 Burglary 11 324 Trouble Relay 41 523 Alarm Relay Disable 6E
131 Perimeter 12 325 Reversing 42 524 Trouble Relay Disable 6F
132 Interior 13 SYSTEM PERIPHERAL TROUBLES - 330 & 340 525 Reversing Relay Disable 70
133 24-Hour 14 330 System Peripheral 43 COMMUNICATION DISABLES - 550 & 560
134 Entry/Exit 15 331 Polling Loop Open 44 551 Dialer Disabled 71
135 Day/Night 16 332 Polling Loop Short 45 552 Radio xmitter Disabled 72
136 Outdoor 17 333 Exp. Module Failure 46 BYPASSES - 570
137 Tamper 18 334 Repeater Failure 47 570 Zone Bypass 73
138 Near Alarm 19 335 Local Printer Paper Out 48 571 Fire Bypass 74
GENERAL ALARMS - 140 336 Local Printer Failure 49 572 24-Hour Zone Bypass 75
140 General Alarm 1A COMMUNICATION TROUBLES - 350 & 360 573 Burg. Bypass 76
141 Polling Loop Open 1B 350 Communication 4A 574 Group Bypass 77
142 Polling Loop Short 1C 351 Telco Fault 1 4B TEST/MISC. - 600
143 Expansion Module Failure 1D 352 Telco Fault 2 4C 601 Manual Trigger Test 78
144 Sensor Tamper 1E 353 Long Range Radio 4D 602 Periodic Test Report 79
145 Expansion Module Tamper 1F 354 Fail to Communicate 4E 603 Periodic RF Xmission 7A
24-HOUR NON-BURGLARY - 150 & 160 355 Loss of Radio Supervision 4F 604 Fire Test 7B
150 24-Hour Non-Burg lary 20 356 Loss of Central Polling 50 605 Status Report to Follow 7C
151 Gas Detected 21 PROTECTION LOOP TROUBLES - 370 606 Listen-in to Follow 7D
152 Refrigeration 22 370 Protection Loop 51 607 Walk Test Mode 7E
153 Loss of Heat 23 371 Protection Loop Open 52 621 Event Log Reset 7F
154 Water Leakage 24 372 Protection Loop short 53 622 Event Log 50% Full 80
155 Foil Break 25 373 Fire Trouble 54 623 Event Log 90% Full 81
156 Day Trouble 26 SENSOR TROUBLES - 380 624 Event Log Overflow 82
157 Low Bottled Gas Level 27 380 Sensor Trouble 55 625 Time/Date Reset 83
158 High Temp 28 381 Loss of Super. -RF 56 626 Time/Date Inaccurate 84
159 Low Temp 29 382 Loss of Super. - RPM 57 627 Program Mode Entry 85
161 Loss of Air Flow 2A 383 Sensor Tamper 58 628 Program Mode Exit 86
FIRE SUPERVISORY - 200 & 210 384 RF xmtr. Low Battery 59 631 Exception Schedule Change 87
200 Fire Supervisory 2B OPEN/CLOSE - 400
201 Low Water Pressure 2C 400 Open/Close 5A
202 Low CO2 2D 401 O/C by User 5B
203 Gate Valve Sensor 2E 402 Group O/C 5C
Digiplex DGP-848 - 39 - Programming Guide
Other Settings and Modes
Section # Data Description Default
[800]
___/___/___/___/___/___ INSTALLER CODE 000000
[801] to [896]
The instructions that follow detail how to program access codes when using an LCD keypad. For instructions
on how to program users when using a Grafica keypad, refer to Grafica’s User Manual. A complete Grafica
user manual is available on our website at www.paradox.ca.
Program User Code Options, Partition
Assignment and Access Control features for users 001 to 096. Refer to the appr opriate keyp ad User’s Manual
for instructions on how certain users can also program these values.
To program user labels, refer to the LCD Keypad System Manager’s Manual.
Press and hold
the [0] key
Enter the
Installer Code
Enter the
[
SECTION]
User Code Options
Feature Select
Programming
User Partition
Assignment
Feature Select
Programming
Access Level and
Schedule Assignment
Enter digits
Access Control User
Options
Feature Select
Programming
Enter
Access Card
Press the [
ENTER] or [S] key to
save and advance to next section
Press the [S] key
Press the [S] key
Press the [S] key
Set desired
options
Set desired
options
Set desired
options
Where sections [801] to [896]
represent User #s 01 to 96.
User Code Options (Bold = default setting)
[1] [2] Feature
off Master Feature Disabled
on off User can program user access codes
on on User can program user access codes, options & assignment
[3] Duress [6] Stay & Instant
[4] Bypass [7] Force
[5] Arm only [8] off = access keypad’s partitions only
on = access any partition assigned to user
*Note: all users can regular arm the system
User Code Partition Assignment †
[1] User Code Has Access to Partition 1
[2] User Code Has Access to Partition 2
[3] User Code Has Access to Partition 3
[4] User Code Has Access to Partition 4
† The default setting depends on th e programming user’s assigned partitions. For
example, when a user (with master feat ure) that is assigned to partitions 1 and 2
programs a user code, par tit ions 1 an d 2 w ill b e t he de faul t set ting f or the n ew user.
Access Level and Schedule Assignment
First brackets
Access Level = enter level from 00 (default) to 15 (00 = access to all doors)
Second brackets
Schedule = enter level from 00 (default) to 15 (00 = access granted at all times)
Access Control User Options (default: all options Off)
[1] Access Card is activated
[2] Can disarm with Access Card
[3] Access Card with Extended Unlocked Period
[4] [5] [6] [7] Feature
on off off off Can Regular Arm with Access Card
on on off off Can Stay Arm with Access Card
on off on off Can Instant Arm with Access Card
on off off on Can Force Arm with Access Card
[8] Can open armed Access Control Doors
Access Card Assignment
Enter Access Card’s serial number or present Card to the reader
Digiplex DGP-848 - 40 - Programming Guide
Paradox Memory Key
Download Memory Key to Control Panel
1. Remove AC and battery power from the control panel you want to program.
2. Insert the Memory Key onto the control panel’s connector labelled “
DIGIPLEX KEY”.
3. Re-apply AC and battery power.
4. To download the contents of the Memory Key except sections [001] to [048] (device serial
numbers) and [049] to [056] (Keyswitch serial numbers), enter installer programming mode, then enter section [961].
To download the contents of the Memory Key including sections [001] to [048] and [049] to [056], enter installer
programming mode, then enter section [962].
5. When the keypad emits a confirmation beep, wait 10 seconds and remove the Memory Key.
Copy Control Panel to Memory Key
1. Remove AC and battery power from the control panel you want to copy.
2. Insert Memory Key onto the control panel’s connector labelled “
DIGIPLEX KEY”. Ensure the write
protect jumper is on.
3. Re-apply AC and battery power.
4. To copy the contents to the Memory Key except sections [001] to [048] (device serial numbers)
Section # Description
[900] Display Serial Number of Control Panel and All Modules Connected to the Combus:
After entering section [900], the keypad will display the 8-digit serial number of the control panel:
For LCD Keypads: Use the [S] and [T] keys to scroll throug h the serial number of each module on the combus.
For Grafica keypads: Press the center action key (Next) to scroll through the serial number of each module on
the combus.
[950] Reset System Master Code:
To reset the System Master Code to 123456 and reset the options to default, put the “reset” jumper to on and
enter section [950]. You do not have to remove power from the control panel.
[951] Module Reset:
Reset a module’s programmed contents to default by entering its serial number.
[952] Locate/Unlocate Module:
Locate a specific module (e.g. detector, zone expander, etc.) connected to the combus by entering the
module's serial number. The green “
LOCATE” LED on the module will begin to flash until the serial number is re-
entered or the appropriate “tamper” or “unlocate” switch on the module is pressed.
[953] Module Programming Mode:
Enter the serial number of the module you wish to program.
[954] Module Broadcast:
Copy the contents of all programming sections from one module to one or more modules of the same type.
Enter the serial number of the source module, followed by the serial numbers of the modules you wish to
program. To begin transferring data, press [
ACC] on LCD keypads or the center action key (Start) on Grafica
keypads.
PLEASE NOTE: The Module Broadcast feature will only work when a module is broadcasting its data to a
module or to modules of the same type and model number. For example, an APR-PRT1 (Printer Module)
cannot broadcast to an APR3-PRT1. Likewise, a DGP module cannot broadcast to a DGP2 module.
[955] Remove Modules:
After entering the section, the control panel will scan all modules connected to the combus. If any missing
modules are detected (i.e. detector removed from the combus), the control panel will erase the module's serial
number, removing the module from the control panel's memory.
[961] Download from the Memory Key to control panel except sections [001] to [056].
[962] Download from the Memory Key to control panel including sections [001] to [056].
[965] Copy the control panel sections to the Memory Key except sections [001] to [056].
[966] Copy the control panel sections to the Memory Key including sections [001] to [056].
Digiplex DGP-848 - 41 - Programming Guide
and [049] to [056] (Keyswitch serial numbers), enter installer programming mode, then enter section [965].
To copy the contents to the Memory Key including sections [001] to [048] and [049] to [056], enter section [966].
5. After the confirmation beep, wait 10 seconds and remove the Memory Key. Remove th e Memory Key’ s jump er if you do
not wish to accidentally overwrite its contents.
Software Reset
Performing a software reset will set certain parameters to default values. To do so:
1. Make sure the
RESET jumper on the control panel is on.
2. Enter Programming Mode (see page 1).
3. Enter the 3-digit [
SECTION] corresponding to the software reset you wish to perform:
Installer Quick Function Keys
To access the installer functions, press and hold the [0] key, enter the [INSTALLER CODE], and then:
For LCD keypads: press the key indicated in the list below that corresponds to the function you wish to activate.
For Grafica keypads: press the center action key (Options), highlight the desired function and then press the left action key
(Select).
Section # Description
[970]
Entering this section will reset all programmable sections from [001] to [896] (except sections [451] to [498],
[555], [556], [560], [790] to [795], and [800]) to default values. The Zone Labels, Panel ID, PC Password, PC
Telephone Number, Installer Code, System Master Code, Event Buffer, and Automatic Report Codes will not
be reset.
[974]
Entering this section resets the following Access Control sections: [301] to [332], [340] to [355], [361] to [375],
[381] to [392], and [537].
[975]
Entering this section will reset all Zone and Keyswitch programming sections from [001] to [056], and [101] to
[156] to default values.
[976]
Entering this section will reset the following sections to default values: [200] to [261], [270] to [274], [400] to
[409], and [440] to [442].
[977] Entering this section will reset sections from [500] to
[522] to default values.
[978]
Entering this section will reset the following communication sections to default values: [521] to [536], [550] to
[554], [561] to [564], and [600] to [718].
[979] Entering this section will reset all user code sections from [801] to [896] to default values.
Section # Data Description Default
[990] ___/___/___ (147=lock, 000=unlock)
LOCK INSTALLER CODE 000
[
STAY]
Test Report: Sends the “Test Report” report code programmed in section [717] to the monitoring station.
[
FORCE] Call WinLoad Software: Will dial the PC telephone number programmed in section [560] in order to initiate
communication with a computer using the WinLoad Upload/Download software.
[
ARM] Answer WinLoad Software: Will force the control panel to answer a call made by the monitoring station that is
using the WinLoad upload/download software.
[
DISARM] Cancel Communication: Cancels all communication with the WinLoad Software or with the monitoring st ation
until the next reportable event.
[
MEM] Installer Test Mode: The installer test mode will allow you to perform walk tests where the bell or siren will
squawk to indicate opened zones. Press [
MEM] again to exit. Partitions can not be armed if the Installer Test
Mode is enabled.
[
TRBL]
Start Module Scan: The keypad will display the serial number of each module on the bus.
[
ACC] For LCD Keyp ads (DGP2-641) only
Combus Voltmeter: Verify if the combus is supplying sufficient power. A reading of 12.3V indicates that the
voltage is too low. The voltage may drop during the control panel battery test.
Digiplex DGP-848 - 42 - Programming Guide
Power Unit Consumption
1. Using Table 3, calculate the total number of power units (PU) req uired by each device, module, and accessory in the
system. Please take into account devices connected to the control panel’s PGM outputs. Since the
BELL output has its
own power supply, do not include the sirens connected to it in the calculation.
2.
If the Grand Total is less than 700PU, go to step 3. If the value is greater, you will require an external power s upply (see
External Power Supply on page 44
) to provide the additional power needed. Proceed with step 3.
3. Due to the degradation of a power signal over long distances, EACH length or run of wire in the system can supp ort o nly
a specific number of power units (PU). Using Table 4, determine how many power units each length of wire can support.
Please note that the total number of power units (PU) can never surpass 700PU.
Table 3: Power Unit Consumption Table
Description QTY. PU used by each Total PU
Grafica Graphic LCD Keypads (DNE-K07): _______ X 130PU = __________ PU
LCD Keypads (DGP2-641): _______ X 60PU = __________ PU
LED Keypads (DGP2-648): _______ X 45PU = __________ PU
Motion Detector Modules (DGP2-50/60/70): _______ X 16PU = __________ PU
Door Contact Modules (DGP2-ZC1): _______ X 14PU = __________ PU
1-Zone Expansion Modules (DGP2-ZX1): _______ X 15PU = __________ PU
4-Zone Expansion Modules (APR3-ZX4): _______ X 20PU = __________ PU
8-Zone Expansion Modules (APR3-ZX8): _______ X 40PU = __________ PU
Omnia Wireless Expansion Modules (OMN-RCV3): _______ X 50PU = __________ PU
1-PGM Expansion Modules (APR3-PGM1): _______ X 50PU = __________ PU
4-PGM Expansion Modules (APR3-PGM4): _______ X 150PU = __________ PU
Printer Modules (APR3-PRT1): _______ X 40PU = __________ PU
DVACS Module (DGP2-DVAC): _______ X 40PU = __________ PU
InTouch Voice-Assisted Arm/Disarm Modules (APR3-ADM2): _______ X 70PU = __________ PU
Access Control Module (DGP2-ACM1P):
Note: The DGP2-ACM1P consumes 165PU from its own power supply.
_______ X 165PU = __________ PU
Other devices such as hardwired motion detectors (1mA = 1PU) __________ PU
Maximum available power units = 700PU GRAND TOTAL __________ PU
Table 4: Power Unit (PU) Limitations For Each Run of Wire
Gauge: 18AWG Surface: 0.823mm
2
Gauge: 22AWG Surface: 0.326mm
2
Gauge: 24AWG Surface: 0.205mm
2
Length of each
run of wire
Available Power
Units (PU)
Length of each
run of wire
Available Power
Units (PU)
Length of each
run of wire
Available Power
Units (PU)
100ft. (30m) 700 100ft. (30m) 70 0 100ft. (30m) 700
200ft. (61m) 700 200ft. (61m) 68 2 200ft. (61m) 429
300ft. (91m) 700 300ft. (91m) 45 4 300ft. (91m) 286
400ft. (122m) 700 400ft. (122m) 341 400ft. (122m) 214
500ft. (152m) 690 500ft. (152m) 273 500ft. (152m) 171
600ft. (183m) 575 600ft. (183m) 227 600ft. (183m) 143
700ft. (213m) 493 700ft. (213m) 195
800ft. (244m) 431 800ft. (244m) 170
900ft. (274m) 383 900ft. (274m) 151
1000ft. (305m) 345 1000ft. (305m) 136
1500ft. (457m) 230
2000ft. (610m) 172
2500ft. (762m) 138
3000ft. (914m) 115
Digiplex DGP-848 - 43 - Programming Guide
Hardware Connections
SINGLE ZONE INPUTS
ATZ - Double Zone Inputs
Digiplex DGP-848 - 44 - Programming Guide
Connections
External Power Supply
Power Units required by devices connected to a power supply do not draw power from the control panel’s auxiliary output.
Do not use the same transformer for the control panel and the external power supplies. Modules should
never be installed more than 914m (3000 ft) from the control panel.
Connecting the Combus in Noisy Environments
When installing the combus wires in proximity to high electrical interference such as neon lights, motors, high-voltage wiring,
transformers, or if connecting the combus across separate buildings, you must use shielded cables. Connect the shielded
cable as follows:
Within the Same Building: Strip the outer jacket at one end of the shielded cable to expose the shield and connect the
shield to the control panel ground (n ot the dialer ground), while l eaving the sh ield at the other end of the cable o pen (floating).
Across Separate Buildings: Strip the outer jacket at one end of the shielded cable to expose the shield. In the same
building that houses the control panel, connect the exposed shield to a cold water pipe or any other earth ground available,
while leaving the shield at the other end of the cable open (floating). The same configuration applies for any subsequent
building.
Option [7] in section [502] must be enabled
PGM1 becomes control panel input #255
When using ESL smoke detectors with the
CleanMe™ feature, do not connect more
than 20 detectors in parallel.
SINGLE FIRE ZONE CONNECTIONS ONLY
If the ATZ feature is enabled, do not use the
extra input (i.e. in the above example, input
009 cannot be used as a zone).
*Note: It is recommended that all 2-wire and
4-wire smoke detectors be connected in a
daisy chain configuration.
152m (500ft) from control panel
152m (500ft) from control panel’s AUX. output
Therefore this run = max. 273PU
610m (2000ft) from control panel
152m (500ft) from power supply
Therefore this run = max. 273PU
Digiplex DGP-848 - 45 - Programming Guide
PCB Layout
For UL and C-UL warnings, refer to the Warnings section in the Digiplex Reference and Installation Manual.
For the hardwire
connections, refer to
"Hardware Connections"
on page 43.
This equipment must be installed and maintained
by qualified service personnel only.
“STATUS” LED:Short flash = Panel OK
Long flash = TLM Fault
Constant = Dialer on-line
OFF = Panel error/off-line
Charging and battery test LED
(every 64 seconds)
Reset jumper
Four pin connector can be
used for quick installation of
a Digiplex keypad or module.
Warning:
Disconnect the
battery before
replacing the fuse.
Warning:
Disconnect
telephone line
before servicing
Optional
connector can be
used to recharge
another battery
in the system.
PGM5
(optional 5A
relay)
PGM1: 100mA
PGM2: 50mA
PGM3: 50mA (opt.)
PGM4: 50mA (opt.)
BELL OUTPUT will
shut down if current
exceeds 3A.
Ground
clamp
Cold
water pipe
grounding
T o met allic
enclosure
AWG#14 single
conductor solid
copper wire
To provide maximum lightning
protection we strongly
recommend having separate
earth connections for the dialer
and zone ground terminals.
COMBUS
Warning: Improper connection may
result in damage to the system.
Warning: During power up, the panel will
perform a module scan that lasts
between 30 and 120 seconds.
AUX POWER
Refer to transformer requirements below for Auxiliary Power Output.
Also, refer to Calculating Power Requirements (on page 42). To
connect additional wiring to auxiliary power , use the red (+) and bla ck
(-) keypad connectors. Auxiliary power will shut down if current
exceeds 1.1A.
When installing the combus wires in a noisy
environment, or when connecting the combus
across separate buildings, you must use a shielded
cable. Refer to Connecting the Combus in Noisy
Environments on page 44.
The combus supports a maximum of 95 modules.
Although external power supplies can be used to
provide power to modules connected far from the
control panel, the final modules on the combus
should not be more than 914m (30 000ft) away.
If multiple runs of wire are being used, the total
distance of all the runs combined cannot exceed
1000m (30 000ft). For example, if ten runs of wire
each measuring 304m (1000ft) were connected, the
total distance would be 3048m (10 000 ft) and
therefore exceeds the system’s capacity.
Before adding any module to the control
panel make sure you shutdown the panel
by removing AC power and the battery.
Transformer Requirements: minimum 16VAC 20VA *
Auxiliary Supply can provide: typical: 600mA
max.: 700mA
Usable Battery Charge Currents: 350mA
* A 40V transformer is required when selecting
the 850mA battery charge current. Using a 20VA
transformer with a battery charge current of
850mA may damage the system.
Digiplex DGP-848 - 46 - Programming Guide
Warranty
Paradox Security Systems Ltd. (“Seller”) warrants its products to be free from defects in materials and workmanship under
normal use for a period of one year. Except as specifically stated herein, all express or implied warranties whatsoever,
statutory or otherwise, including without limitation, any implied warranty of merchantability and fitness for a particular
purpose, are expressly excluded. Because Seller does not install or connect the products and because the products may be
used in conjunction with products not manufactured by Seller, Seller cannot guarantee the performance of the security
system and shall not be responsible for circumstances resulting from the product’s inability to operate. Seller obligation and
liability under this warranty is expressly limited to repairing or replacing, at Seller's option, any product not meeting the
specifications. Returns must include proof of purchase and be within the warranty period. In no event shall the Seller be liable
to the buyer or any other person for any loss or damages whether direct or indirect or consequential or incidental, including
without limitation, any damages for lost profits stolen goods, or claims by any other party, caused by defective goods or
otherwise arising from the improper, incorrect or otherwise faulty installation or use of the merchandise sold.
Notwithstanding the preceding paragraph, the Seller’s maximum liability will be strictly limited to the purchase price of the
defective product. Your use of this product signifies your acceptance of this warranty.
BEWARE: Dealers, installers and/or others selling the product are not authorized to modify this warranty or make additional
warranties that are binding on the Seller.
© 2003-2004 Paradox Security Systems Ltd. All rights re served. Specifications may change without prior notice. One or more
of the following US patents may apply: 6215399, 6111256, 5751803, 5721542, 5287111, 5119069, 507754 9, 5920259 and
5886632. Canadian and international patents may also apply.
Digiplex, Grafica, InTouch, Omnia, and WinLoad are trademarks or registered trademarks of Paradox Security Systems Ltd.
or its affiliates in Canada, the United States and/or other countries.
Digiplex DGP-848 - 47 - Programming Guide
Notes
Printed in Canada - 10/2004 DGP848-EP04
Trouble Display
To view the Trouble Display on LCD or LED keypads:
1. Press the [
TRBL] key.
2. For LEDs: Press the Numerical Symbol corresponding to the Group heading to view the specific trouble.
For LCDs: Press the number representing the trouble and use the [S] and [T] keys to view the specific trouble.
To view the Trouble Display on Grafica Keypads:
1. Enter your [
ACCESS CODE].
2. Using the scroll keys, highlight Trouble and then press the center action key (Ok). The trouble(s) will appear by Trouble
Group.
3. If more than one Trouble Grou p appears, highlight the desired group before pressing the center action key (View) to view
the specific trouble.
For technical support in Canada or the U.S., call 1-800-791-1919 for English or 1-866-912-0600 for French, Monday to Friday
from 8:00 a.m. to 8:00 p.m. EST . Fo r technical support outside Cana da and the U.S., call 00-1-450-491- 7444, Monday to Friday
from 8:00 a.m. to 8:00 p.m. EST. Please feel free to visit our website at www.paradox.ca.
TROUBLE GROUP [1]: SYSTEM TROUBLE GROUP [2]: COMMUNICATOR
[1] AC Failure [4] Bell Current Limit
[2] Battery Trouble [5] Bell Absent
[3] Aux. Current Limit [6] ROM Check Error
[1] TLM [4] Fail to Com. 3
[2] Fail to Com. 1 [5] Fail to Com. 4
[3] Fail to Com. 2 [6] Fail to Com. PC
TROUBLE GROUP [3]: MODULE TROUBLE TROUBLE GROUP [4]: COMBUS TROUBLES
[1] Module Tamper [5] Printer Trouble
[2] Module ROM Check Error [6] Module AC Failure
[3] Module TLM Trouble [7] Module Battery Failure
[4] Module Fail to Com. [8] Module Supply Output
[1] Missing Keypad [6] General Failure
[2] Missing Module [7] Combus Overload
[8] Combus Com. Error
TROUBLE GROUP [5]: ZONE TAMPER TROUBLE GROUP [6]: ZONE LOW BATTERY
Press the [5] button to display the tampered zone or zones.
Press the [6] button to display the zone(s) assigned to
wireless devices with low batteries.
TROUBLE GROUP [7]: ZONE FAULT TROUBLE GROUP [8]: CLOCK LOSS
Press the [7] button to display the zone(s) experiencing a
communication, a fire loop or CleanMe
TM
trouble.
Press the [8] button to re-program the time.
Loading...
