Paoluy Silicone Technology KB6007I User Manual

KB6007I User manual

1、Contents

1.1、Bluetooth keyboard 1PCS

1.2、Instruction manual 1PCS

1.3、USB Charging cable 1PCS
2、Product Features

2.1、use Broadcom20730 main control chip, have Bluetooth3.0 interface.

2.2、industry leading bluetooth solutions, WIDCOMM BTW (Microsoft officially designated
software) bluetooth software.

2.3、built-in power management software, can be in Microsoft's Windows system automatically
usable capacity.

2.4、With folding design, keyboard can be carried easily.

2.5、Mute design: effectively avoid disturbing other sleeping person (especially for one room with
several person).

2.6、Architecture design, provides comfortable handling feel.

2.7、Support Iphone, Mac, Windows and Android system etc. It’s more convenient for you.

3、Specifications

3.01、executive standard: bluetooth V3.0

3.02、maximum operating distance: 10 meters

3.03、modulation mode: 2.4 G FHSS

3.04、transmit power: Class 2 levels

3.05、working voltage: 3.7V

3.06、working current: 2.0 mA

3.07、standby current: 1.0mA

3.08、sleep current: 52uA

3.09、charging current: 150mA

3.10、standby time: 120days

3.11、theoretical use time: 20days

3.12、continuous uninterrupted use time: 85hours

3.13、theoretical charging time: 1.5-2 hours

3.14、lithium battery capacity: 170mAh

3.15、lithium battery life span: three years

3.16、

the lithium battery type: 302530

3.17、the key dynamics: 60 + 10g

3.18、buttons life: 5 million times

3.19、operation temperature: 0-55 ℃

3.20、storage temperature: - 20-60℃

1．4、Bluetooth keyboard installation
2．Keyboard pair with iPad procedure:
3．(1)、Turn on the swith”ON”, the blue indicator light 5 seconds then extinguished which advise

you the keyboard be turned on. Please see below instruction picture.

(2) 、 Press “Connect”button,”Status” indicator twinkle which advise you is pairing.

（3）、Click the setting button of IPAD and IPHONE, Then choose the General and bluetooth. Turn
on the bluetooth, then the IPAD will searching bluetooth device .

（4）、After the IPAD and IPHNE find out the bluetooth device and connect the bluetooth
keyboard(see blow picture), IPAD will advise you input the password. Then press “Enter”key.
