Paoluy Silicone Technology BKB76F User Manual

BL-BKB76F Bluetooth Keyboard Manual

Packing Include:

1,A Bluetooth keyboard

2,A list of manual

3,USB charging cable

Product Features:

1, With Broadcom20730 as main control chip , with Bluetooth 3.0 interface .

2, Use industry-leading Bluetooth solution, WIDCOMM BTW Bluetooth software which is

Microsoft official.

3, Buit-in power management software, It can automatically show the available capacity in the Microsoft Windows

Silence design, It will not affect other people’s rest

4,

5, Architecture design provides comfortable handing fell.

6, Work with PC and commerical mobile , It will be convenient to work .

7, Working temperaturer :-20℃-55 humidity:20%℃ -50%

8.Built-in lithium battery, you do not need to frequently change battery

specified software by

Specifications

1, Executive standard: Bluetooth V3.0

2，Working distance: 10 meters

3, Modulation system: FHSS 2.4G

4, Transmitting power: Class 2

5, Operating voltage: 3.7V

6, Work current: <3.0MA

7, Standby current: 2.0MA

8, Sleeping current: <60UA

9, Charging current:> 100MA

10, Standby time: 200days

11, Theory of working Time: 22 days

12, Uninterrupted working time: 90 hours

13, Charging time: 2.5-3.5 hours

14, Li-ion battery Capacity: Minimum 280MAH

15, Lithium battery life: 3 years

16, Lithium battery Specifications: 3.0 * 24 * 47MM

17, Key strength: 60± 40g

18, Key life: 500 million

19, Operating temperature: -20 - +60 ℃

20, Storage temperature: -30 - +70 ℃

Note: When you switch on the keyboard, the power light and Bluetooth light will be on in three seconds , at this

time the keyboard do not connnect with any device.,But the LED light will automatically be off if the keyboard

still do not connected to any device after the Led keep lighting for 5 seconds. The keyboard can connect when

you switch on after your first successfully use ,the power light will keep lighting ,but the bluetooth light will be

off after it successfully connect to device .

Install Bluetooth Keyboard

1, How to install bluetooth keyboard into IPAD

(1), As shown, Turn on the toggle switch ,power light and Bluetooth light will be on in 3 seconds , But after keep

lighting for 5 seconds , it will be off .At this time the keyboard is in working situation .

(2),Press the connect button ,the Bluetooth light will be flashing , Power light will be lighting ,so the keyboard is

in connecting situation .

（3) Click setting of the screen of the Ipad .Ipad will in setting area , then choose Bluetooth , open the

bluetooth ., Ipad is in searching bluetooth keyboard working situation .

(4): Enter the password and connect
