Pantech PX 100 User Manual
VERIZON WIRELESS VZACCESS MANAGER
PX-100 User’s Manual
CONTENTS
1. BEFORE USING PC5740
1.1 About this User’s Manual
1.2 Product Overview
1.3 What’s Inside the Product Package
1.4 Introduction to Verizon Wireless PC5740 PC Card
1.5 Product Features
1.6 Product handling
1.7 Configuration
2. INSTALLING PC5740
2.1
Precautions 4
Recommended System Requirements
2.2
2.3
Installing Software 5
2.3.1 Installation 5
2.3.2 Warnings 5
2.3.3 Notes 5
2.3.4 Firmware upgrade 6
2.3.5 Unplugging or ejecting the card 6
1
1
1
1
1
2
3
3
4
4
3. REGULATORY AND SAFETY INFORMATION
3.1 Regulatory notices
3.2 Operating Conditions 8
3.3 Warnings and Cautions 8
3.4 Safety precautions 9
4. LIMITED WARRANTY
8
8
11
CONTENTS
1. BEFORE USING PC5740
1.1 About this User’s Manual
You will find all the information you need to install and use the PC5740 in this user’s
manual. Before using PC5740, you must properly install the PC5740 by closely
following the installation instructions.
1.1.1 Instructions
Install the PC5740 software before inserting the PC5740 card into your laptop.
•
The installation software is included in the product package. Insert the CD into
your CD-ROM drive. Installation may take a few minutes.
• It is highly recommended that you read the safety precautions described in
this manual before using the PC5740.
1.2 Product Overview
Thank you for purchasing Verizon Wireless PC5740 PC Card.
The PC5740 is a 3G wireless card that enables high-speed wireless communication
from your laptop. PC5740 is simple to install and use.
1.3 What’s Inside the Product Package
Following items are included in the product package. If any of the items listed below
is missing, please contact the retail location where you purchased the product.
- PC5740 Wireless PC Card Modem
- Installation CD that contains software and this user’s manual
1.4 Introduction to Verizon Wireless PC5740 PC Card
The Verizon Wireless PC5740 is designed for type II PC card slot, which is available
in most laptop models. PC5740 can be used to access the Internet, your company’s
intranet, or you can use it to send and receive email. It is extremely useful when you
are away from the office, on the road, or where ever a wireline Internet access is not
readily available.
PC5740 User’s Manual
1
1.5 Product Features
- Power management: PC5740 utilizes power management and system overhead
reduction functions provided by the standard 32-bit CardBus electrical interface for
maximum power savings.
- Antenna design: Efficient, innovative design optimizes data transfer rate and
sensitivity to network signals.
- Type II PCMCIA format that supports CardBus I/O interface.
- Supports North American PCS (1900 MHz) and Cellular (800 MHz) bands.
- Utilizes QUALCOMM MSM6500 chip set.
- Supports 3G network technologies.
- Optimized data rate: Maximum 2 Mbps receiving speed and maximum 144 kbps
sending speed.
- Supports Win98SE, ME, 2000 and XP systems with installed host software and
driver.
- Provides Verizon Wireless BroadbandAccess and NationalAccess network
service.
PC5740 User’s Manual
2
1.6 Product handling
1) Do not put any adhesive label on the PC5740 card. It may leave a
sticky residue that can cause problems inside the laptop PC card slot.
2) PC5740 card should easily slide into the PC card slot.
Do not force the PC5740 into the slot as it may cause damage to the
card and/or the slot.
3) Keep PC5740 in a dry and clean place.
(Storage temperature: - 30° to 65°C [86° to 149°F]). Keep your card
away from liquids, dust and excessive heat.
1.7 Configuration
To use the PC5740, you should install the software included in the installation CD
and configure the PC5740 card. See the next section for more infomration on
software installation and PC card configuration.
PC5740 User’s Manual
3
2. INSTALLING PC5740
2.1 Precautions
1) Do not insert the PC5740 before installing the software in laptop
computer. When you complete the software installation, the system
will prompt you to insert the PC5740 into the Type II PC card slot.
2) Once the card has been inserted into the laptop, do not remove it from
your laptop without first completing the unplugging/ejection process.
(See page 6 for more information on this process.)
2.2 Recommended System Requirements
To successfully install and use the PC5740 card in your laptop, the following system
specifications are required.
Item
Operating system
Card slots
Processor
Disk drive
Memory
Disk space
Dial-up networking
Windows®98SE / Windows®Me / Windows®XP / Windows®2000
Required Specification
Type II PC Card slot (CardBus)
Pentium 150MHz or faster
CD-ROM
32 MB
14MB
DUN bound to TCP/IP
* PC5740 is not designed for hand-held or Pocket PC. SMS or voice service is not
also supported.
PC5740 User’s Manual
4
