Pantech PG-3500 User Manual
www.pantech.com
Made in Korea
06
PG-3500
USER’S MANUAL
5U010000828 REV06
Welcome
USER’S MANUAL
PG-3500
Thank you for choosing Pantech PG-3500 and welcome to
wireless mobile communication networking with the PG3500, our tri-band GSM mobile phone.
Pantech is delighted to introduce this brand new portable
phone which will always keep you connected to the network.
This user manual explains in detail its unique features and
how to use them.
NOTE:
Some of the contents in this User Manual could vary from your
phone. It may vary depending on the S/W version and the network
provider you subscribed to.
We recommend you to use Micro-SD card (64MB, 128MB,
256MB) made by Kingmax and Trans-Flash card (64MB,
128MB, 256MB, 512MB) made by Sandisk. Memory cards
not listed above may not work properly.
1
Specification Specification
Display
Dual clamshell 262,144 TFT LCD internal and 65,536 TFT
LCD external.
• 30.096 mm x 37.62 mm display for 1.9” internal LCD
• 18.144 mm x 24.192 mm display for 1.2” external LCD
• Supports up to 262K colors within 176 x 220 pixels internal and
65K colors 96 x 128 pixels external
• 9 lines for text in basic mode with 18-pixel font
• Two Soft keys, four-way navigation and selection ([
o
]) keys
Melody
MP3, AAC, AAC+, AMR, G-MIDI, SP-MIDI, C-MIDI, SMF, XMF,
RTTTL, i-Melody
Camera
Integrated SXGA(1.3M) CMOS Camera.
• Resolution up to 1280 x 1024 (1,310,720 pixels)
• Mpeg4 Video recording/playing up to 30f/s(QCIF size)
• Mpeg4 Video size Max QVGA
• Self timer function (5 sec or 10 sec)
• Phone display used as a viewfinder
• Photo album in Gallery
• Photo Gallery for image storing and editing
• 3 image quality options: Fine, Normal, Low
• Flash light supported
Dimension & Weight
• Weight: 75 g
• Dimensions: 92.7 mm x 45 mm x 16.8 mm
Operating Frequency
• EGSM: 900Mhz, DCS: 1800Mhz, PCS: 1900Mhz networks in
Europe, Africa, Asia-Pacific, North America, and South America
where these networks are supported
• Automatic band switching
2
3
Views
Views
Left Soft key
4-way Menu
Navigation
Special Menu
Short key
DiaI key
Call Accept
Voicemail
Alphanumeric
key
Vibration
Mode
Microphone
Earpiece
Internal LCD
Right Soft key
WAP Access key
Select/Menu
Confirm key
Power On/Off
Menu exit key
Cancel/Back
Text Clear/Edit
exit key
Phone Lock/
Unlock
Flash Light
Camera
Headset key
Camera key
4 5
Quick & Easy Quick & Easy
Key Function
[
(Left/Right)
n
o
c
s
e
1
Soft Keys
]
Performs the context sensitve function shown at
the bottom line of the display.
Navigation Keys
Scrolls through the menu options in Menu mode.
In standby mode,
Left key (
Right key (
Up key (
Down key (d): Contacts menu
OK key
Opens the WAP (Wireless Application Protocol)
menu list if pressed shortly in standby mode.
Launches the WAP browser directly, if pressed and
held in standby mode.
Make your selection inside the menu.
Back/Clear key
Deletes characters from the display, or returns to
previous menu.
Opens Calendar view if pressed shortly in standby.
Send key
Make or receives a call.
Shows the recent call list in standby mode.
Re-dials the last call number if pressed and held in
standby mode.
End/Power key
End the call.
Turns on/off the phone if pressed and held.
Cancels user input and returns to standby mode
while in Menu mode.
Press and hold to access the voice mail server in
standby mode.
l
): Favorite list
r
): Messages menu
u
): Sound Settings menu
Key Function
Enters numbers, letters or special characters.
~
Goes to the dial screen if pressed in standby
9
0
*
0
#
()
k
mode.
Activate and deactivate Vibration mode if pressed
and held in standby mode.
In text input mode, show the symbol input screen,
view the next matching word if the highlighted word
is not matched in T9 input mode.
Enters an international dialling prefix.
Enters the space character in text input mode.
Locks or unlocks the phone if pressed and held in
standby mode.
Changes the text input modes if pressed and held
at the text-editing screen.
Volume keys
Adjusts the earpiece volume during a call, and
moves the cursor upwards or downwards in the
menu.
Controls the key tone volume in standby mode if
the phone flip is opened,
Camera key
Press to access camera capture mode and press
long to access video capture mode.
76
Safety Precautions Safety Precautions
Using a phone while driving is prohibited.
Please check local laws and regulations with regard to the
prohibition of phone usage while driving, and comply with them.
• Use of your mobile phone while you are driving may disturb your
concentration and consequently cause accidents. Please turn it
off as soon as possible.
• Should you use your phone in an emergency, please make use
of the hands free device built in your car, or pull your car over to
a safe place for your utmost safety.
• The electronic wave energy emitting from your phone may affect
the electronic devices built in your car. Please be aware of this
characteristic.
Mobile Phone Use Restriction Area
Make sure to turn your phone off in a phone usage restricted area.
Using a Phone in an Explosive or Dangerous Area is
not Permitted
Please turn your phone off in areas with explosive or dangerous
materials (such as fuel, fuel stations, or places with chemical
goods) and abide by any instructions or signals. Never try to
detach your mobile phone battery from the phone in such areas.
Boarding an Aircraft
• Please turn your phone off when you are on the aircraft. The
electronic wave from your phone may affect the electronic
navigation device in the aircraft.
Using Medical Equipment
• Please turn your phone off while you are in a hospital.
• Please abide by the regulations or rules of the hospital.
• Please turn off your phone when using medical equipment for
private purposes if possible. You should consult with the
manufacturer or an expert regarding phone usage near medical
equipment.
Installing a Vehicle Hands Free Device
• Please keep the vehicle hands free device away from the
steering, and air bag expansion range, or otherwise injury may
result.
Effect of Mobile Phone and Electronic Devices
Some electronic devices may be affected by the electronic wave
emitting from the mobile phone in service. Please be careful.
8
9
Menu Tree
Menu Tree
1 Messages
1.1 Write New
1.1.1 Text Msg.
1.1.2 Multimedia Msg
1.1.3 E-mail
1.2 Inbox
1.3 Outbox
1.4 Draft Box
1.5 Sent Box
1.6 Templates
1.7 Settings
1.7.1 Text Msg.
1.7.1.1 Message Centre
1.7.1.2 Message Lifetime
1.7.1.3 Message Type
1.7.1.4 Receive to
1.7.1.5 Save Message
1.7.1.6 Delivery Report
1.7.2 Multimedia Msg.
1.7.2.1 MMS Profile
1.7.2.2 Message Lifetime
1.7.2.3 Auto Download
1.7.2.4 Save Message
1.7.2.5 Read Report
1.7.2.6 Delivery Report
1.7.3 E-mail
1.7.3.1 Max. Message
Download Size
1.7.3.2 Email Accounts
1.7.3.3 Save Message
1.7.3.4 Saving Memory
1.7.4 CB Msg.
1.7.4.1 Language
1.7.4.2 Info. Subjects
1.7.4.3 Receive
1.7.5 Voice Mail
1.7.5.1 Call
1.7.5.2 Voice Mail Number
1.8 Memory Info.
2 Contacts
2.1 Search
2.1.1 Name Search
2.1.2 Group Search
2.1.3 Service Number*
2.2 Add Contact
2.3 Speed Dial
2.4 Groups
2.5 Business Card
2.6 Memory in Use
2.7 Copy All
2.7.1 Phone SIM
2.7.2 SIM to Phone
2.8 Delete All
2.8.1 Phone
2.8.2 SIM Card
2.9 Memory Info.
3 Call Logs
3.1 Missed Calls
3.2 Received Calls
3.3 Dialled Calls
3.4 Recent Calls
3.5 Delete Call Logs
3.5.1 Missed Calls
3.5.2 Received Calls
3.5.3 Dialled Calls
3.5.4 All Calls
3.6 Call Timer
3.6.1 Last Call Time
3.6.2 Received Call Time
3.6.3 Dialled Call Time
3.6.4 Total Call Time
3.6.5 Reset Call Times
3.7 Call Cost **
3.7.1 Last Call Cost
3.7.2 Total Call Cost
3.7.3 Clear Logs
3.7.4 Max. Cost
3.7.5 Cost Unit
3.8 GPRS Info.
3.8.1 Current Info.
3.8.2 Last Info.
3.8.3 Total Info.
3.8.4 Clear Logs
4 Media Gallery
4.1 External Memory
4.2 Photo Gallery
4.3 Video Gallery
4.4 Image Gallery
4.5 Sound Gallery
4.6 Other Files
4.7 Memory Info.
4.7.1 Phone Memory
4.7.2 External Memory
5 Multimedia
5.1 Camera
5.1.1 Take a Photo
5.1.2 Take a Video
5.1.3 Photo Gallery
5.1.4 Video Gallery
5.1.5 Settings
5.1.5.1 Image Size
5.1.5.2 Image Quality
5.1.5.3 Video Size
5.1.5.4 Video Quality
5.1.5.5 Flash
5.1.5.6 White Balance
5.1.5.7 Multi-Shot
5.1.5.8 Pattern Shot
5.1.5.9 Self Timer
5.1.5.10 Time Stamp
5.1.5.11 Shutter Sound
5.1.5.12 Audio Record
5.1.5.13 Memory in Use
5.1.5.14 Auto Save
5.2 MP3 Player
5.2.1 Player
5.2.2 Music Album
5.2.3 File Manager
5.2.4 Settings
5.3 Java
5.3.1 Games
5.3.2 Memory Info.
6 Settings
6.1 Display Settings
6.1.1 Main Screen
6.1.1.1 Wallpaper
6.1.1.2 Wallpaper Type
6.1.2 Sub Screen
6.1.2.1 Wallpaper
6.1.3 Greeting
6.1.4 LCD Brightness
6.1.5 Back Light
6.2 Sound Settings
6.2.1 Ring Tone
* SIM Dependent ** Network Dependent
10 11
Menu Tree
Menu Tree
6.2.2 Bell Sound
6.2.3 Message Alert
6.2.4 Key Tone
6.2.5 Flip Open Tone
6.2.6 Sound Effect
6.2.7 Profile Name
6.2.8 Reset
6.3 Call Settings
6.3.1 Call Divert **
6.3.1.1 All Calls
6.3.1.2 When Busy
6.3.1.3 On No Answer
6.3.1.4 When not Found
6.3.1.5 Cancel All
6.3.2 Answer Type
6.3.3 Auto Answer
6.3.3.1 Auto Answer
6.3.3.2 Recorded Message
6.3.3.3 Response Message
6.3.3.4 Response Time
6.3.3.5 User Message
6.3.4 Auto Redial
6.3.5 Call Waiting**
6.3.5.1 Activate
6.3.5.2 Deactivate
6.3.5.3 Status
6.3.6 Send Caller ID**
6.3.7 Own Number
6.4 Language
6.5 Time & Date
6.6 Favorite
6.7 Network Selection
6.8 Security Settings
6.8.1 SIM Lock *
6.8.2 Change PIN *
6.8.3 Phone Lock
6.8.4 Change Password
6.8.5 Application Lock
6.8.6 Call Barring
6.8.6.1 Handset Barring
6.8.6.2 Network Barring**
6.8.7 CUG**
6.8.8 Fixed Dialling*
6.8.9 Change PIN2*
6.8.10 System Reset
6.9 Software Version
7 Organiser
7.1 Alarm
7.2 Calendar
7.3 Memo
7.3.1 Text Memo
7.3.2 Voice Memo
7.4 World Time
7.5 Calculator
7.6 Converter
7.7 Stop Watch
7.8 Timer
8 Connectivity
8.1 WAP
8.1.1 Home
8.1.2 Resume
8.1.3 Bookmarks
8.1.4 Push Messages
8.1.4.1 Inbox
8.1.4.2 Receive Mode
8.1.5 Go to URL
8.1.6 Profiles
8.1.7 Cache
8.1.7.1 Cache Mode
8.1.7.2 Clear Cache
8.1.8 Security Cert
8.1.9 Version
8.2 USB Mass Storage
8.3 Bluetooth
8.4 Saving Memory
8.4.1 Bluetooth
9 SIM Toolkit*
* SIM Dependent
** Network Dependent
12 13
* SIM Dependent
Table of Contents
Table of Contents
Getting Started
Package Contents....................................................................... 20
Internal & External Displays........................................................ 21
SIM Card .................................................................................... 26
Using the battery......................................................................... 27
New Functions
Video Caller ID............................................................................ 32
Setting Video for Idle Screen....................................................... 34
OTA Settings Service.................................................................. 35
DRM/ Forward Lock .................................................................... 36
Basic Functions
Switching the Phone On or Off.................................................... 38
• Switching the Phone On [1.1].................................................... 38
• Switching the Phone Off [1.2].................................................... 38
Making a Call............................................................................... 39
• Making a Call [2.1] .................................................................... 39
• Ending a Call [2.2]..................................................................... 39
• Using Call Logs [2.3]................................................................. 39
• Using Contacts [2.4].................................................................. 40
• Making an International Call [2.5].............................................. 40
• Speed-dialling from Contacts [2.6]............................................ 41
• Making an Emergency Call [2.7] .............................................. 41
Answering a Call ......................................................................... 42
• Answering a Call [3.1]............................................................... 42
• Viewing Missed Calls [3.2]........................................................ 42
• Rejecting a Call [3.3]................................................................. 43
• Adjusting the Calling Volume [3.4]............................................ 43
Calling Options ........................................................................... 44
• Switching the Microphone Off (Mute)[4.1]................................. 44
• Holding a Call [4.2].................................................................... 44
• Answering a Second Call [4.3].................................................. 45
• Searching for a Number in Contacts [4.4]................................. 45
• Using DTMF Tones [4.5]........................................................... 46
• Transferring a Call [4.6]............................................................. 46
• Using the Message Service [4.7] ...............................................47
• Making a Multi-party Call [4.8]................................................... 47
• Retrieving Call in Headset/Handsfree/Phone [4.9].................... 49
Using the Headset....................................................................... 50
Using the Speaker Phone ........................................................... 51
Selecting Menu Functions........................................................... 52
• Entering into Menu Functions [7.1] ........................................... 52
• Using the Shortcut Key in Standby Mode [7.2] ......................... 53
Entering Text............................................................................... 54
• Input Mode [8.1]........................................................................ 54
• Changing Text Input Mode [8.2]................................................ 55
• Using T9 Mode [8.3].................................................................. 57
• ABC Mode [8.4]........................................................................ 57
• Using 123 Mode [8.5]............................................................... 59
• Using Symbol Mode [8.6]......................................................... 59
Applications
Messages.................................................................................... 62
• Write New [1.1].......................................................................... 63
• Inbox [1.2] ................................................................................. 68
• Outbox [1.3]............................................................................... 71
• Draft Box [1.4]........................................................................... 71
• Sent Box [1.5]............................................................................ 72
• Templates [1.6] ......................................................................... 72
• Settings [1.7]............................................................................. 73
• Memory Info. [1.8]..................................................................... 78
Contacts.......................................................................................79
• Adding a New Contact [2.1] ...................................................... 79
• Editing Contacts [2.2]................................................................ 79
• Searching a Name/Group [2.3] ................................................. 79
• Group Setting [2.4].................................................................... 80
• Speed Dial Setting [2.5] .............................................................81
• Delete All [2.6]........................................................................... 81
• Memory Info. [2.7]..................................................................... 81
• Service Number [2.8] ................................................................ 81
• Business Card [2.9]....................................................................82
• Memory In Use [2.10].................................................................82
• Copy All [2.11]........................................................................... 82
Call Logs ..................................................................................... 83
• Missed Calls [3.1]...................................................................... 83
• Received Calls [3.2].................................................................. 84
• Dialled Calls [3.3]...................................................................... 84
1514
Table of Contents
Table of Contents
• Recent Calls [3.4].......................................................................85
• Delete Call Logs [3.5]................................................................ 85
• Call Timer [3.6].......................................................................... 85
• Call Cost [3.7]............................................................................ 86
• GPRS Info. [3.8]........................................................................ 86
Media Gallery.............................................................................. 87
• External Memory [4.1]............................................................... 87
• Photo Gallery [4.2] .................................................................... 90
• Video Gallery [4.3]..................................................................... 91
• Image Gallery [4.4].................................................................... 92
• Sound Gallery [4.5] ................................................................... 93
• Other Files [4.6]......................................................................... 93
• Memory Info. [4.7]..................................................................... 94
Multimedia................................................................................... 95
• Camera [5.1] ............................................................................. 95
• MP3 Player [5.2]...................................................................... 100
• Java [5.3]................................................................................. 102
Settings ..................................................................................... 104
• Display Settings [6.1] .............................................................. 104
• Sound Settings [6.2].................................................................105
• Call Settings [6.3].................................................................... 108
• Language [6.4]........................................................................ 111
• Time & Date [6.5].................................................................... 111
• Favorite [6.6]............................................................................111
• Network Selection [6.7]........................................................... 112
• Security Settings [6.8]............................................................. 112
• Software Version [6.9]............................................................. 115
Organiser................................................................................... 116
• Alarm [7.1]............................................................................... 116
• Calendar [7.2].......................................................................... 117
• Memo [7.3].............................................................................. 119
• World Time [7.4]...................................................................... 121
• Calculator [7.5]........................................................................ 121
• Converter [7.6] .........................................................................122
• Stop Watch [7.7]...................................................................... 122
• Timer [7.8]............................................................................... 123
Advanced Functions
WAP.......................................................................................... 126
• Navigating the WAP Browser [1.1]...........................................126
• Entering Text in the WAP Browser [1.2].................................. 126
• Home [1.3]............................................................................... 126
• Resume [1.4]........................................................................... 127
• Bookmarks [1.5]...................................................................... 127
• Push Messages [1.6]............................................................... 127
• Go to URL [1.7]....................................................................... 128
• Profiles [1.8]............................................................................ 128
• Cache [1.9].............................................................................. 130
• Security Cert [1.10] ................................................................. 130
• Version [1.11].......................................................................... 130
USB Mass Storage.................................................................... 131
Bluetooth................................................................................... 132
• Bluetooth [4.1]......................................................................... 133
• Paired Device [4.2].................................................................. 133
• Business Card [4.3]................................................................. 135
• Outgoing call device [4.4]........................................................ 136
• Visibility [4.5]........................................................................... 136
• Name [4.6]............................................................................... 137
• Address [4.7]........................................................................... 137
Saving Memory ......................................................................... 138
• Bluetooth [5.1]......................................................................... 138
SIM Toolkit ................................................................................ 139
Appendix
Access Code............................................................................. 142
Check List.................................................................................. 144
Performance and safety ........................................................... 147
Glossary.................................................................................... 148
Memo ........................................................................................ 151
16 17
Getting Started
1. Package Contents
2. Internal & External Displays
3. SIM Card
4. Using the battery
1
18
19
Package Contents Internal & External Displays
This phone has 2 displays (internal and external) and icons
on the top of the display indicate the phone status.
Internal Display [2.1]
Icons Area
Text and Graphic Area
Display in standby screen with information
• Area Information through cell broadcast
service
• Network Name
• Time and Date
Soft key Indication
Phone Battery
User’s Manual
The contents can be vary by regions.
*
20
Travel Charger
Icon(s) Description
Shows received signal strength.
The greater the number of bars, the stronger the signal.
A call is being made.
Outside the coverage area, you cannot make or receive
a call.
You have a new voice message.
You have a message. If the text message memory is
full, the icon will look like . If the multimedia message
memory is full, the icon will look like . If the email
memory is full, the icon will look like .
Roaming indicator
Within the GPRS range. When a GPRS session is in
progress, the icon will look like .
Call diverting feature is activated
21
Internal & External Displays Internal & External Displays
Icon(s) Description
You have set the alarm.
The Infrared port is activated. During data transmission
through the Infrared port, the icon will look like .
You have set the alert type for incoming call to ring only.
You have set the alert type for incoming call to ring
ascent.
You have set the alert type for incoming call to ring and
vibrate.
You have set the alert type for incoming call to vibrate
then ring.
You have set the alert type for incoming call to vibrate
only.
You have set the alert type for all tones to quiet and for
all rings to vibrate only.
Headset is connected.
Auto-answering feature is activated.
Battery level. The bar indicates the available battery
charge. If your battery charge is low, this icon will look
like .
This becomes set when Bluetooth function is activated.
This becomes set when Bluetooth Headset/Handsfree
are connected.
You have received one or more files via Bluetooth.
Display Off Mode.
If you do not press any key within a minute while the internal
and external displays are dimmed, the internal display goes
into Off Mode to save power. Press any key to restore the
display.
Selecting Functions and Options.
The phone provides several customisation functions, which
are arranged in menus and sub-menus. You can access
these functions using the two Soft keys ([] and []] key).
Each menu and sub-menu allows you to view and change
the settings of the particular function.
The Soft key function varies depending on the current
context; the labels or icons at the bottom line of the display
indicate the current function.
To view various functions/options available or select the one
that is required:
1
Press the appropriate Soft key.
2
To select the function displayed or option highlighted, press
the [[] Soft key or the [o] key.
3
To highlight the next option on a list, press the Up key or Down
key.
4
To move back to the previous function or option on a list, press
the [c] key.
5
To return to Standby Mode, press the [e] key.
In some functions, you may be prompted for a password or
o
PIN. Enter the required code and press the [
22
] key.
23
Internal & External Displays
Internal & External Displays
External Display [2.2]
You can use several menus even though the folder is
closed. The following section describes the external display
screen and easy-to-control external menus and their
functions.
• Adjusts the earpiece volume and moves the cursor up in the
menu during a call.
Side Up
Side Down
Extra Key
k
• Mutes the ring tone if pressed upon an incoming call.
• Rejects the incoming call if pressed upon an incoming call.
• Turns the flash on if pressed and held.
(
• Starts scrolling if pressed while in the external menu screen.
• Increases the volume in MP3.
• Zooms in with the camera.
• Adjusts the earpiece volume and moves the cursor down in
the menu during a call.
• Mutes the ring tone if pressed upon an incoming call.
• Rejects the incoming call if pressed upon an incoming call.
• Starts scrolling if pressed in the external menu screen.
• Goes to the external menu screen if pressed and held (Shown
)
with MP3/Camera)
• Decreases the volume in MP3.
• Zooms out with the camera.
• Turns Camera Mode on if pressed and held.
• Works as a camera shutter in the capture mode.
• Selects a menu or moves to the sub-menu, if pressed while in
the external menu.
• Exits from the menu screen and returns to the standby screen
if pressed and held while in the external menu screen.
External Menu List
Press and hold the side volume [)] key in standby mode.
• MP3: Allows you to play MP3.
• Camera: Allows you to select Camera in order to take pictures.
• Exit: Allows you to exit External Menu.
Side Key Special Functions.
1
Snap Shot
Close the folder to initiate the camera function.
k
Press and hold the side [
Press the [
taken will be displayed on the screen. At this time, press the [
key to save the picture with auto naming. In the View mode, press
the [
Press and hold the [k] key to activate the video mode when
folder open.
2
You can use the phone as an emergency light.
Press and hold the Side volume [
The camera flash is lit automatically for 10 seconds. Press the
[
k
k
] key again to take a photo. And then, the image
(/)
] side key to return to the camera capture mode.
Flashlight on
] key or the [(/)] key to turn the flash off
] key to activate the camera mode.
k
(
] key in standby mode.
]
24
25
SIM Card
Using the battery
SIM Card [3.1]
When you subscribe to your network operator, you will get a
SIM (Subscriber Identity Module) card containing your
registration information. (PIN), the existence of additional
service, etc.
Like a credit card, it should be kept secure and handled
carefully.
Do not bend, scratch or expose it to moisture.
Avoid static electricity.
To avoid memory corruption of your SIM card, always
switch off your phone before removing or inserting your SIM
card.
Installing/Removing the SIM card [3.2]
1
Remove the battery from the unit.
2
If the SIM slot is empty, insert the
SIM card into the slot.
3
If you want to remove the SIM
card, pull the SIM card holder as
the arrow direction, pull the SIM
card in the arrow direction as
shown in the picture.
Installing the battery [4.1]
Put the contacts of the battery into
the hole located at the bottom of the
unit, as shown in the figure below.
Press the upper side of the battery
until you hear a “click” sound.
Removing the battery [4.2]
Push the battery lock button up
and remove the battery.
Charging the battery [4.3]
This phone uses a Li-ion battery.
Make sure to use an authorised
battery and charger only. For more
details, please inquire at your
nearest dealer.
You can use the phone during
battery recharging.
When the battery is mounted within
the phone, open the cover located
at the bottom of the phone and
connect the adapter. An adapter is
provided with the phone.
2726
Using the battery
Using the battery
If recharging is completed,
detach the adapter connection
from the outlet.
Tip:
Your phone is powered by a Lithium Ion (Li-ion) battery.
You can use the following Li-ion battery types for your phone. (Contact
your local dealer for more information.)
Standard-type battery.
Precautions while Using the Battery
• Do not use a damaged battery or charger.
• Use the battery for the specified purpose only.
• The closer you are to the base station, the longer the phone
usage time because less battery power is consumed for the
connection.
• Battery charging time varies depending on the remaining battery
capacity and the battery and charger type in use.
• Battery life is shortened as time passes by.
• Use an authorised battery and charger only.
• Since overcharging may shorten battery life, remove the battery
from its charger once it is fully charged. Unplug the charger, once
charging is complete. Leaving the battery in hot or cold places,
especially inside a car in summer or winter, may reduce the
capacity and life of the battery. Always keep the battery within
[4.4]
normal temperatures.
• Do not earth the battery. Earthing may occur when the battery is
in contact with a conductive object. An earthed phone may also
damage the battery.
• Dispose and recycle used batteries in accordance with local
regulations.
• Do not dispose of the batteries in a fire.
• Do not use an unauthorised charger.
• In order to prevent injury or burns, ensure that metal objects do
not come into contact with the + and – terminals of the battery.
2928
2
New Functions
1. Video Caller ID
2. Setting Video for Idle Screen
3. OTA Settings Service
4. DRM/ Forward Lock
30 31
Video Caller ID
Video Caller ID
Save the video clip of a contact or other video clips. Select
and set a video clip to the corresponding contact in the
address book.
When a call is received from the contact, the corresponding
video clip will be played on the screen.
You can use one of two setting methods.
Contacts [1.1]
1
Select ‘Menu>2.Contacts>2.Add Contact’.
2
Select ‘2.Phone’ option under ‘Save to’ option and input the
appropriate information in all the fields.
3
Press the [r] navigation key in the image saving menu, and
the ‘Add Contact’ popup will appear.
4
Select ‘3.Take a Video’ (For further details, see Applications
Menu 5.1.4) or ‘4.Video Gallery’ (For further details, see
Applications Menu 4.3) to specify the video file.
5
The selected video will play when a call is received from the
corresponding contact.
Multimedia [1.2]
1
Select ‘Menu>5.Multimedia>1.Camera>2.Take a Video’ and
save the video. (For further details, see Applications Menu
5.1.4)
2
Select ‘Menu>5.Multimedia>1.Camera>4.Video Gallery’ or
‘Menu>4.Media Gallery>3.Video Gallery’. (For further details,
see Applications Menu 4.3)
3
Select the Video Album and press the [Option] Soft key [[]
and select [Set as].
4
Select ‘2.Contact’ when the ‘Set as’ pop up appears, and
select the target person and press the [
one person should have been already stored in Contacts.)
5
The selected video will appear when a call is received from the
corresponding number.
o
] button. (At least
3332
Setting Video for Idle Screen OTA Settings Service
You can set a video file to play on the screen when the
phone is idle.
1
Select ‘Menu>5.Multimedia>1.Camera>2.Take a Video’ and
save the video. (For further details, see Applications Menu
5.1.4)
2
Select ‘Menu>5.Mutlimedia>1.Camera>4.Video Gallery’ or
‘Menu>4.Media Gallery>3.Video Gallery’. (For further details,
see Applications Menu 4.3)
3
Select the Video Album and press the [Option] Soft key [[]
and select ‘Set as’.
4
Select ‘1.Wallpaper’ when the ‘Set as’ pop up appears.
5
The selected video will play on the screen when the phone is
idle.
WAP/ OTA Provisioning
[3.1]
In order to use the WAP Browser, you need to have proper
connection settings on your phone.
You may add and/or edit the WAP Profile manually or receive
the settings directly as a configuration message according to
the operators and/or service providers, at the latter case you
need to save them on your phone.
Please note that there should be some on-screen steps you
need to follow to save and activate the settings.
Please also note that the compatibility to Ericsson/Nokia WAP
Provisioning OTA has been made.
3534
DRM/ Forward Lock
DRM/ Forward Lock
Your phone supports a Digital Rights Management (DRM)
system to protect acquired content. A piece of content, for
example ring tones, wall papers, etc. can be protected by
Forward Lock, which means the protected contents cannot be
forwarded to other devices including other phones and
desktops.
Please note that you should and shall be informed by the
service provider before and/or when you try to download such
protected contents.
[4.1]
3
Basic Functions
1. Switching the Phone On or Off
2. Making a Call
3. Answering a Call
4. Calling Options
5. Using the Headset
6. Using the Speaker Phone
7. Selecting Menu Functions
8. Entering Text
3736
Switching the Phone On or Off Making a Call
Switching the Phone On [1.1]
1
Open the folder.
2
Press the [e] key until the phone switches on.
3
If the phone requests you to input a PIN, enter the PIN and
press the [
Menu 6.8)
o
] Soft key. (For further details, see Applications
Your phone starts to search for an available network and
the current date and time will appear on the internal and
external displays. Once connected to the network, you can
send or receive a call.
If a malfunction occurs while using the phone or it is not
turned on, remove the battery and install it again after 5 or
10 seconds.
NOTE:
To change the language, use the Language menu option (For
further details, see Applications Menu 6.4)
Switching the Phone Off [1.2]
To switch the phone off, press the [e] key until the poweroff animation displays.
Making a Call [2.1]
Enter the area code and the phone number to make a call in
standby mode, and press the [s] key.
NOTE:
If you have set the Auto Redial option (For further details, see
Applications Menu 6.3.4) to [On], the phone will attempt to make a call
automatically for up to 10 times if it is not connected.
To clear the last digit displayed, press the [c] key.
To clear the all digits displayed, press and hold the [c]
key.
Ending a Call [2.2]
When you want to finish your call, press the [e] key or
close the folder.
Once the call is completed, a call summary (Recipient Name
or Number, Service Time) will be displayed.
Using Call Logs
The phone stores dialled, received or missed calls. The last call
is saved in the first position.
1
Press the [s] key to see the all recent call list
chronologically.
2
Press the [u/d] key to highlight.
3
Press the [s] key for dialling.
(For further details, see Applications Menu 3)
NOTE:
Press and hold the [s] key to redial the last number in the call
log.
[2.3]
3938
Making a Call
Making a Call
Using Contacts [2.4]
You can store frequently used names and phone numbers in the
SIM card or the phone memory, which are called Contacts. You
therefore do not have to remember all your phone numbers;
simply select the name to recall the associated number.
1
Press the []] key and the [d] key in the standby screen to
access the ‘View Names’ List and ’2.Contacts’ Menu
respectively
2
Select a number from ‘View Names’.
3
Press the [s] key for dialling. (For further details, see
Applications Menu 2)
Making an International Call [2.5]
1
Press and hold the [0] key for the international prefix until the
‘+’ character appears on the display or enter the outgoing
national code.
2
Enter the country code, area code and phone number you
want to make a call to.
3
Press the [s] key.
Speed-dialling from Contacts [2.6]
Press and hold the ‘Speed Dial’ number to make a call
using the number you have saved. For example, press the
“5” key longer or press the “5” key then press the [s] key
to dial a number which has been saved as “5” in Speed Dial
List.
(For further details, see Applications Menu 2.5)
Making an Emergency Call [2.7]
You can make an emergency call without the SIM.
Enter 'Emergency Number'.
Then press the [s] key, or, press the [SOS] Soft key if no
SIM Card is available.
40
41
Answering a Call Answering a Call
Answering a Call
When you receive a call, the phone rings (or vibrates) and
the screen will display the name or the number of the caller
(if the network supports the function and you have
subscribed to it).
If the caller can be identified, the caller’s phone number or
name will be displayed if it is stored in your Contacts.
1
To answer a call, open the folder.
2
If it is already open, press the [s] key.
Tip:
If the answer type is set as Any Key, you can answer a call by
pressing any key except the [
e
] key.
Viewing Missed Calls
If the incoming call could not be answered, a missed call
message will appear on the screen to remind you of the call
you have missed (Network and subscription dependent
feature, not necessarily available in all areas).
To reply to the missed call;
1
Keep the folder open.
2
Press the [View] Soft key to display a list of missed calls.
3
If necessary, scroll to the number you want by pressing the
[u/d] keys.
4
Press the [s] key to call the missed call.
Press the [c] or [e] key to close the missed call
notification message.
[3.1]
[3.2]
Rejecting a Call [3.3]
Press the [e] key or the [Reject] Soft key when the folder
is open. If the [Reject] Soft key is pressed, the caller will
receive a busy line tone.
When the folder is closed, press and hold the [(/)] key
during an incoming call.
Adjusting the Calling Volume [3.4]
If you wish to adjust the earpiece volume during a call, use
the volume keys on the left side of the phone.
Press the [(] key to increase the volume level and the [)]
key to decrease it.
In standby mode with the folder open, you can adjust the
key tone volume using the [(/)] keys.
42
43
Calling Options Calling Options
During a call, press the [[] key to show the call options.
Switching the Microphone Off (Mute)
You can temporarily switch your phone’s microphone off so
that the person you talk to on the phone cannot hear you.
For example, you may wish to say something to another
person in the room but do not want the person calling to
hear you.
Press the [Mute] Soft key, or select ‘Mute’ in the Options
menu.
To switch the microphone back on:
Press the [Sound] Soft key.
[4.1]
Holding a Call [4.2]
You can place a current call on hold whenever you want.
You can make another call while you have a call in progress
if your network service provider supports this service. Of
these two calls, one is active and the other is on hold and
you can switch between the calls.
To place a call on hold, simply select ‘Hold’ in the [Option]
menu or press the [s] key.
You can reactivate the call whenever you want by selecting
[Option] followed by [Retrieve].
Once a call is held, the name and icon of the caller will fade
to grey.
To make a call while you have a call in progress:
1
Enter the phone number that you want to dial or look it up in
Contacts.
2
Press the [s] key to dial the second call. The first call is
automatically put on hold.
To switch between two calls, simply press the [Swap] Soft
key.
The current call is placed on hold and the call on hold is
reactivated so that you can continue your conversation with
the other person.
If you want to finish, complete each call normally by
pressing the [e] key.
Answering a Second Call [4.3]
You can answer an incoming call while you have a call in
progress, if your network service provider supports this
service and you have activated the Call waiting option (For
further details, see Applications Menu 6.3.5). You will be
notified of an incoming call by a call waiting tone.
To answer a call while you have another call in progress:
1
Press the [s] key to answer the incoming call.
2
The first call is automatically put on hold.
3
To switch between two calls, press the [Swap] Soft key.
To end the current call, press the [e] key.
Press [s] key to reconnect the call on hold.
Searching for a Number in Contacts
You can search for a number in your Contacts during a call.
1
Press the [Option] Soft key.
2
Select [Contacts] option.
3
Select the preferred search types like Name, Group.
[4.4]
4544
Loading...
