MULTISYNC USER MANUAL

Thank you for choosing the Pantech Multisync, our latest 3G mobile phone.

The Pantech Multisync has many features designed to enhance your

mobile experience. From its sleek, stylish design and QWERTY keypad, we

know you will enjoy the entire Mississippi experience.

This User Guide contains important and useful information that will

maximize your familiarity with all that the Pantech Multisync has to offer.

Specifications

Design

Clamshell with QWERTY keypad

Displays



260k colors TFT LCD with 2.6” internal display



400*240 resolution



5 lines for text in basic mode with 16-point font



Two soft keys and four-way scroll and selection OK keys

Melodies

MP3, MIDI, iMelody, MMF, WAV, SMAF, AAC+

Camera

Integrated 1.3M CMOS Camera



Resolution up to 1280 x 960 (1,228,800 pixels)



Mpeg4 Video recording/playing up to 15f/s(QCIF size)



Self-timer function (5 seconds or 10 seconds)



Photo album and video album

Dimensions & Weight



Weight: 132g/4.66oz (with standard battery)



Dimensions: 106.5 mm x 51.8 mm x 17.7 mm

4.19“ x 2.04“ x 0.7“

Power Management (Performance)

Battery Type Capacity Standby Time Talk Time

Standard

Lithium-Ion

(Li-ion)

Up to 920 mAh Up to 250 hours Up to 3 hours

Operating Frequency

•

GSM 850Mhz, GSM 900Mhz, DCS 1800Mhz, and PCS 1900Mhz

networks in North America, South America, Europe, Africa, and Asia-

Pacific where these networks are supported.

•

Automatic band switching.

Phone overview

End key

End calls, exit menus

Vibrate mode

Microphone International call prefix key

Navigation key

Scroll through the menu options

Left/Right Soft key

Perform the functions shown at

the bottom line of the display.

Camera

Volume Key

Hold Key

Earpiece

Display

NOTE: Holding the device by the internal antenna area might affect

the quality of all calls.

Send key

Use to make and answer

calls.

Charger slot/Ear mic

QWERTY keyboard view

Left/Right Soft key

Perform the functions shown

at the bottom line of the

display.

CAPS/Shift key

To type a single uppercase letter, press

this key then a letter

Function key

To enter a number or a symbol, press

the function key, and press the

corresponding key

Space key

Press to enter a space

Enter key

Press to create new line while writing a message

Delete key

Press to delete a number or letter

Note: To use the QWERTY keyboard, ensure that the Number pad is closed, then hold the phone horizontally and slide the screen up.

Send / OK / End key

Press to delete a number or letter

Camera key

Multi Tasking key Music key

Profiles Key

IM Key

Massage Key

Navigation key

Symbol Key

Using shortcuts

Numbered menu items, such as menus, sub-menus, and options can be

quickly accessed by using their shortcut numbers. In Menu mode, Main

Menus can be accessed by pressing the number keys (1 to 0)

corresponding to their location on the screen.

Example: Accessing the Language menu.

1. Press Menu.

2. Press the [9] for Settings.

3. Press the [4] for Phone.

4. Press the [1] for Language.

5. Press Select for Screen Text.

5. Press the [up] or [down] scroll key to display the list of available

languages.

Menu overview

1 Shortcut

Camera

Bluetooth

Alarms

Recent Calls

My Account

Games

2 Address Book

Contacts

Add Contact

Speed Dial

Groups

My Business Card

Memory in Use

My Phone Number

Used Space

Service Numbers*

10.

FDN List*

3 Messaging

Conversations

Create Message

Mobile Email

Outbox

Drafts

Voice Mail

Settings

Templates

10.

Used Space

4 IM

5 Mobile Email

NOTE: Holding device at internal antenna area might affect call quality

reception.

Internal antenna

6 Mobile Web

7 AppCenter

Shop Tones

Shop Games

Shop Graphics

Shop Multimedia

Shop Applications

Shop Videos

MEdia Net

8 AT&T GPS

AT&T Navigator

9 YPmobile

10 My Stuff

Applications

Audio

Games


Tools

Video

Other Files

Used Space

11 AT&T Music

Music Player

Shop Music

MusicID

XM Radio

Music Videos

Make-UR-Tones

Community

Music Apps

12 Mobile Video

13 Settings

Profiles

Display

Call

Phone

Network Connections

Network*

Connectivity

Security*

Software

10.

Reset

11.

TTY

* SIM dependent

** Network dependent

Quick & Easy

Keys Functions

Perform the functions shown at the bottom line of the display by using these soft keys. Scroll through the menu options in Menu mode.

Send or receive a call. Show the recent call list in standby mode. Complete the current call. Turn on/off the phone if pressed and held.

Cancel user input and return to main screen while in Menu

mode.

• ~

Enter numbers, letters or special characters. Go to the dial screen if pressed in standby mode.

Enter or exit from vibrate mode if pressed and held in standby mode.

Show the symbol input screen if pressed in text input

mode.

Enter an international dialing prefix if pressed and held in standby mode.

Enter the space character in text input mode.

Adjust the earpiece volume while making a call.

Control the Ringtone volume, vibrate mode and silent all

mode in standby.

Mute the ringtone of an incoming call.

Contents

Specifications...........................................................3

Phone overview........................................................4

Quick & Easy............................................................9

1. Getting Started...................................................15

SIM card and battery...............................................................................16

Turn phone on/off ...................................................................................17

Keypad lock.............................................................................................17

Essential display indications....................................................................17

Memory card ..........................................................................................18

Assigning the menu ................................................................................19

Updating software...................................................................................19

Using the QWERTY key pad...................................................................19

AppCenter ..............................................................................................20

2. Calls and address book.....................................21

Making, receiving and ending a call........................................................22

Using video share...................................................................................24

Options during a call...............................................................................25

Call settings ............................................................................................27

Settings for video share..........................................................................27

Checking all calls....................................................................................28

Speed dialing..........................................................................................29

Using the address book..........................................................................30

Caller identification..................................................................................31

Using your headset.................................................................................31

Service numbers and fixed dialing..........................................................32

3. Messaging..........................................................33

Entering text............................................................................................34

Messaging...............................................................................................35

Receiving messages ..............................................................................36

Creating and sending text messages......................................................37

Creating a multimedia messages............................................................37

Message templates.................................................................................39

Message settings ...................................................................................39

Voice message setting............................................................................40

Email.......................................................................................................40

Using instant messenger.........................................................................40

4. Multimedia..........................................................41

Camera...................................................................................................42

Photo album............................................................................................44

Video album............................................................................................45

Audio album............................................................................................46

Music Player............................................................................................47

Music player settings...............................................................................49

Media player............................................................................................50

Other files................................................................................................51

Managing memory .................................................................................51

Playing games ........................................................................................51

5. Useful Features..................................................52

Alarm.......................................................................................................53

Calendar.................................................................................................53

Notepad and voice memo.......................................................................54

Calculator, converter and stop watch......................................................54

Business card..........................................................................................55

Memory information................................................................................55

6. Connectivity.......................................................56

Bluetooth.................................................................................................57

Using the browser...................................................................................58

Profile settings ........................................................................................59

7. Settings...............................................................60

Language................................................................................................61

Time and date.........................................................................................61

Touch sense level....................................................................................61

Transition Effect......................................................................................61

Mode transition time................................................................................61

Ringtones ...............................................................................................61

Decorating the display ............................................................................62

Locks.......................................................................................................62

To enable fixed dialing ............................................................................63

Reset.......................................................................................................63

TTY.........................................................................................................63

8. Appendix ............................................................65

Alert message.........................................................................................65

Troubleshooting checklist........................................................................66

Safety information...................................................................................67

Safety precautions..................................................................................67

About the battery usage..........................................................................68

FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless Devices

................................................................................................................69

FCC Regulatory Compliance...................................................................70

Warranty..................................................................................................72

1. Getting Started

SIM card and battery

Turn phone on/off

Keypad lock

Essential display indications

Memory card

Assigning the menu

Updating software

Using the QWERTY key pad

AppCenter

SIM card and battery

About your SIM card

When you subscribe to your network operator, you receive a SIM

(Subscriber Identity Module) card containing your registration information,

PIN code, etc.

Like a credit card, it should be kept secure and handled carefully. Do not

bend, scratch or expose it to moisture. Avoid static electricity.

To avoid corrupting your SIM card’s memory, always switch off your phone

before removing or inserting your SIM card.

About your battery

Your phone uses a Li-Ion battery. Make sure to use an authorized battery

and charger only. For more details, please inquire at your nearest dealer.

NOTE: Your phone is powered by a Lithium Ion (Li-Ion) battery. Unlike

other forms of battery technology, you can recharge your battery while

some charge remains without reducing your phone’s autonomy due to the

“battery memory effect” inherent in those technologies.

Installing/removing SIM card and battery

1. Remove the battery cover from the unit. To fit

the battery cover, put it on the guide rail and

push up.

2. Insert the SIM card into the slot. The gold contacts

of the SIM card should go against the metal

contacts of the phone. Put the contacts of the

battery into the hole located at the bottom of the

unit insert and press the upper side of the battery

until you hear the “click”.

3. To remove the battery push the bottom of the

battery to upwards(1) and remove(2) the battery..

Push the SIM card in the direction of the arrow as

shown.

To charge your battery

1. To charge, open the protective cover on the top right side and

connect the charger adapter.

Make sure you align the connector as the image. If not, it will

damage the charging connector on the phone and will not charge.

2. To remove the adapter connection press the

adapter’s side buttons(1) and pull the adapter

away(2).

Turn phone on/off

To turn on

1. Press and hold [ ].

To turn off

1. Press and hold [ ].

Keypad lock

Locking the keypad

1. Press Menu > press [ ] to lock.

Unlocking the keypad

1. Press Unlock > [ ] to unlock.

Essential display indications

Signal strength. The greater the number of bars, the stronger the signal. When network is in searching mode

is displayed.

A call is being made. When you are in no service area is displayed Call forwarding* is active

Incoming calls set to ring only (Normal) Incoming calls set to Vibrate and Ring Incoming calls set to Vibrate Only Incoming calls set to Silent

Flight Mode is active

Received one or more text messages Received one or more multimedia messages Received one or more WAP push messages Received one or more configuration messages Received one or more voice messages A message is being sent A message is being received An alarm is set Bluetooth is active

1 1

Headset is connected USB is connected TTY is active A GPRS signal is available. It is displayed when there is

an active GPRS session An EDGE signal is available. It is displayed when there is an active EDGE session A 3G signal is available. It is displayed when there is an active 3G session

WAP is connected. When the security is set is

displayed.

When the contents download is in progress, is

displayed.

Battery strength. When the battery charge is low, is displayed

Available, Away, Invisible Status of AIM

Online, Away, Busy, Offline Status of MSN Available, Busy, Invisible Status of YAHOO You have received one or more IM messages

* Network dependent

Memory card

You can use microSD card as a memory card. It gives you more space to

save pictures, videos, music, etc.

Inserting and removing the memory card

1. Open the memory card slot.

2. Insert the card. The [ ] icon will be display.

3. Press the card to remove.

Using memory card

You can save, move and delete the files between your phone and external

memory card. You can also move and copy the files to computer from your

phone.

Resetting the card

1. Press Menu > Settings > Reset.

2. Enter the password > External Memory Reset.

Note: The default password is ‘1234’.

To copy the file to the card

1. Select the file > Options > Copy to External Memory.

2. To copy the file back to phone, press Options > Copy to Phone.

To move the file to the card

1. Select the file > Options > Move to External Memory.

2. To move the file back to phone, press Options > Move to Phone.

To delete the file from the card

1. Select the file from the card > Options > Delete.

To move the file from the card to the computer

1. Connect the data cable with mobile and the computer.

2. Press Menu > Settings > Connectivity.

3. Press Select USB Mode.

4. Select Mass Storage or Ask on Connection.

5. Follow the instruction on your computer screen.

Note: Select Music Player when you want to add music to the playlist in

your device. When you select Ask on Connection, it will ask you to select

either the Music Player or Mass Storage every time you connect your

device with your computer.

Assigning the menu

You can set the most commonly used menu in Options in standby mode.

1. Press Shortcuts in standby mode > select (Unassigned).

2. Press Add.

3. Select the menu and sub menu.

Note: You can assign up to 10 Shortcut.

Updating software

You can update your software without visiting your nearest dealer.

To update the software

1. Press Menu > Settings > Software > Software Update.

2. Press Check for Update > Yes to check whether or not you need to

update the software.

NOTE: After downloading the software, the device will ask you whether to

update the software now or later. If you choose to update the software now,

it will restart the handset. If you postpone updating the software, you can

select between 30 mins, 1 hour or 4 hours in the Options. After selecting

the updating time, you will be sent back to standby mode. If you go to

Software Update while you are in postponing, press Continue Update.

To view the version of software

1. Press Menu > Settings > Software.

2. Press Phone Information and scroll down to Software Version.

Using the QWERTY key pad

Your phone has QWERTY keypad which provides a superior typing

experience on a small handheld for easy and comfortable text writing. You

can use all of the phone functions with the QWERTY keypad opened.

Key Function

Perform the functions shown at the bottom line of the display by using these soft keys. Press to change ab Ab AB at the text editing screen.

Multi-tap

(all small caps / first letter caps / all caps)

Press to change type to alphabet, special character and number, special character and number on lock, at the applicable key pad.

Press + to type a special character that is not placed

on the keypad.

Enter the space character in text input mode.

Insert a carriage return in text input mode.

Delete a character to the left of the text cursor in text editing screen.

Enter characters, symbols or numbers.

Press and hold to enter special symbols or numbers.

AppCenter

Shopping tones

1. Press Menu > AppCenter > Shop Tones.

Shopping Games

1. Press Menu > AppCenter > Shop Games.

Shopping Graphics

1. Press Menu > AppCenter > Shop Graphics.

Shopping Multimedia

1. Press Menu > AppCenter > Shop Multimedia.

Shopping Applications

1. Press Menu > AppCenter > Shop Applications.

Shopping Videos

1. Press Menu > AppCenter > Shop Videos.

MEdia Net home

1. Press Menu > AppCenter > MEdia Net.

2. Calls and address book

Making, receiving and ending a call

Using video share

Options during a call

Call settings

Settings for video share

Checking all calls

Speed dialing

Using the address book

Caller identification

Using your headset

Service numbers and fixed dialing

Making, receiving and ending a call

Using the External Keypad

To unlock touch keypad, long press the Hold Key[ ] on the right side of

the phone.

Making a call

1. Tap the area code and phone number.

2. Tap [ ] key.

Answering a call

1. Tap [ ].

Ending a call

1. Tap [ ].

Once the call is complete, a call summary is displayed.

Rejecting a call

1. Tap [ ] or Ignore.

Making a call using call list

Your phone logs up to 6 dialed, received and missed call numbers.

1. Tap Menu > Recent Calls

2. Select a number to call by tapping the [ / ] key.

3. Tap [ ] to dial the selected number.

NOTE: To redial the last number in the Recent Calls list, tap [ ].

Making a call during a call

1. Tap the phone number or look it up in Address Book.

2. Tap [ ] to dial the second call. The first call is automatically put on

hold.

Switching between two calls

1. Tap Option > Swap

Making an international call

1. Tap and hold [ ] key for the international prefix until the ‘+’ character

appears.

2. Type the country code, area code, and phone number.

3. Tap [ ].

Making an emergency call

You can make emergency calls even if your phone does not have a SIM

card.

1. Tap Emergency Number, if your phone does not have a SIM card.

2. Tap [ ].

Replying to a missed call

1. Tap View to display the list of missed calls.

2. Select a number to call by tapping the [ / ] key.

3. Tap [ ].

Answering a second call**

1. Tap Option > Swap. The first call is automatically put on hold.

2. Tap [ ].

3. Tap Option > End to end the second call.

The call on hold is automatically reconnected.

Using the Internal Keypad

Making a call

3. Enter the area code and phone number.

4. Press [ ] key.

Answering a call

2. Press [ ].

Ending a call

2. Press [ ].

Once the call is complete, a call summary is displayed.

Rejecting a call

2. Press [ ] or Ignore.

Making a call using call list

Your phone logs up to 20 dialed, received and missed call numbers.

1. Press [ ] to display the Recent Calls list.

2. Select All Calls, Missed Calls, Received Calls, or Dialed Calls

pressing the [ / ].

3. Select a number.

4. Press [ ] to dial the selected number.

NOTE: To redial the last number in the Recent Calls list, press [

Making a call during a call

3. Enter the phone number or look it up in Address Book.

4. Press [ ] to dial the second call. The first call is automatically

put on hold.

Switching between two calls

2. Press Swap.

Making an international call

4. Press and hold [ ] key for the international prefix until the ‘+’

character appears.

5. Type the country code, area code, and phone number.

6. Press [ ].

Making an emergency call

You can make emergency calls even if your phone does not have a SIM

card.

3. Press Emergency Number, or press SOS if your phone does not have

a SIM card.

4. Press [ ].

Replying to a missed call

4. Press View to display the list of missed calls.

5. Select a number to call by pressing the [ / ]key.

6. Press [ ].

Answering a second call**

1. Press [ ]. The first call is automatically put on hold.

2. Press [ ] to end the second call.

The call on hold is automatically reconnected.

Using video share

You can share live or recorded video while on a call. You can send or

receive video.

NOTE: Video Share is not available in all markets. Both parties must be in

a 3G service area–a 3G icon must appear by the signal bars prior to a call

being placed, and both parties must remain in the 3G coverage area for the

duration of the Video Share.

Making video share call

1. Enter the area code and phone number > [ ].

2. Press Options > Video Share.

3. Select Live or Recorded.

Note: To use video share in the Recent Calls, press Options > Video

Share.

Turning off the speakerphone

1. Press OK or press Options > Speakerphone Off during video share

mode.

2. Press Options > Mute to mute the sound.

Mute

M u te

FPO

Stopping video share

1. Press Stop to end.

2. To end a call press [ ].

Increasing or decreasing the brightness

1. Press Options > Brightness.

2. Adjust the brightness by pressing [ / ].

Zoom in and out

1. Press Options > Zoom. It ranges from x1 to x3.

Stopping the recording

1. Press Options > Stop Record.

For details on setting for automatic recording, see page 23.

Ending video share

1. Press Stop to end the video share.

2. It will ask you whether you will stop video share > Yes to stop.

Note: Even you end video share, the call will not be ended. Press [

] to end the call. The recorded video will be saved in My Stuff >

Video.

Receiving video share

1. After receiving video share, it will ask you whether to accept or reject

the video share > Yes to accept and No for reject.

2. Press Options > Landscape to landscape the screen.

Options during a call

Microphone off and on

Switching your phone’s microphone off

1. Press Options > Mute [ ].

Switching your phone’s microphone back on

1. Press Options > Unmute.

Talking on speaker

1. Press Speaker Phone [ ].

Putting a call on hold and returning**

Putting a call on hold

1. Press Options > Hold or press [ ].

Returning to a held call

1. Press Options > Unhold or press [ ] again.

Multi-party calls**

You can talk with more than one person or have conference call.

Making a multi-party call

1. Call the first participant.

2. Call the second participant. The first call is automatically put on hold.

3. Press Options > Join.

Having a private conversation with one participant

1. Press Options > Split.

2. Press OK.

3. Select the participant and press OK.

All of the multi-party call participants can now hear each other.

Removing one participant from a multi-party call

1. Press Options > End.

2. Select the participant and press OK.

The call ends with that participant, but you can continue to talk to the other

participants.

Searching for a number in the address book during a call

1. Press [ ] or press Options > View Contacts > Contacts.

2. Select a number > [ ].

Searching for a name or group in the address book

Enter the first letters of the name for Name Search. The entries are

displayed starting with the first entry matching your input.

Finding a name manually in the address book

1. Press the [ / ] key.

Viewing the details of the highlighted entry in the address

book

1. Press OK.

For details on address book, see page 25.

Reading a message during a call

1. Press Options > View Message.

2. Select a message > OK

Writing a message during a call

1. Press Options > Create Message.

For details on creating a text message, see page 31.

Viewing calendar during a call

1. Press Options > View Calendar

Writing a notepad during a call

1. Press Options > Notepad

Voice recording

1. Press Options > Voice Recording

Setting DTMF

1. Press Options > DTMF On or Off

Call settings

Setting auto redial

1. Press Menu > Settings > Call > Auto Redial.

2. Select On or Off.

Answering by pressing any key

1. Press Menu > Settings > Call > Any Key Answer.

2. Select Answer with Any Key.

NOTE: You can answer with any key except [ ] and Ignore.

Limiting incoming calls

1. Press Menu > Settings > Security > Phone Barring.

2. Press Incoming.

3. Select On or Off.

Limiting outgoing calls

1. Press Menu > Settings > Security > Phone Barring.

2. Press Outgoing.

3. Select Bar All, Bar Prefixed or Off.

- Bar All: Barring all outgoing calls.

- Bar Prefixed: Barring prefixed numbers.

- Off: Cancel all the barring including the bar prefixed.

Settings for video share

Turning the alert on/ off

1. Press Menu > Settings > Call > Video Share.

2. Press Alerts.

3. Select On or Off > Select.

Setting for automatic recording

1. Press Menu > Settings > Call > Video Share.

2. Press Auto Record.

3. Select On or Off > Select.

Setting for service

1. Press Menu > Settings > Call > Video Share.

2. Press Service.

3. Select On or Off > Select.

Setting for profile

1. Press Menu > Settings > Call > Video Share.

2. Press Profile

3. Select AT&T IMS or Media Net > Select.

Setting recording location

1. Press Menu > Settings > Call > Video Share.

2. Press Recording Location.

3. Select Phone Memory or External Memory > Select.

Checking all calls

You can view information about all Recent Calls. For more options for all,

missed, received and dialed calls press Shortcut in internal keypad.

You can also view the call history simply by pressing [ ].

Using the External Keypad

Viewing all missed , received and dialed calls

1. Tap Menu > Recent Calls > OK

Using the Internal Keypad

Viewing missed calls

1. Press Shortcut > Recent Calls in standby mode or press Menu > My

Stuff > Tools

2. Press Recent Calls > Missed Calls.

Viewing received calls

1. Press Shortcut > Recent Calls in standby mode or press Menu > My

Stuff > Tools

2. Press Recent Calls > Received Calls.

Viewing dialed calls

1. Press Shortcut > Recent Calls in standby mode or press Menu > My

Stuff > Tools

2. Press Recent Calls > Dialed Calls.

Viewing call ranking

3. Press Shortcut > Recent Calls in standby mode or press Menu > My

Stuff > Tools

4. Press Recent Calls > Call Ranking

Deleting call logs

1. Press Shortcut > Recent Calls in standby mode or press Menu > My

Stuff > Tools

2. Press Recent Calls > Delete Call Logs.

3. Select All Calls > Yes.

Viewing call time

1. Press Shortcut > Recent Calls in standby mode or press Menu > My

Stuff > Tools

2. Press Recent Calls > Call Time.

3. Press [ / ] to view Last Call, Received Calls, Dialed Calls and

Total Calls.

Resetting all call times

1. Press Shortcut > Recent Calls in standby mode or press Menu > My

Stuff > Tools

2. Press Recent Calls > Call Time.

3. Press Reset > Yes.

4. Enter password > OK.

NOTE: The default password is ‘1234’

Viewing data transmitted information

1. Press Shortcut > Recent Calls in standby mode or press Menu > My

Stuff > Tools

2. Press Recent Calls > Packet Counter.

- Current Info: You can view transmitted data in the current session, in

Kbytes. Sent, Received and Total information are also available.

- Last Info: You can view Sent, Received, Total and Duration information

of the previous session’s transmitted in Kbytes.

- Total Info: You can view all the Sent, Received, Total and Duration

transmitted data in Kbytes.

- Clear Logs: The default password is ‘1234’.

Speed dialing

You can dial quickly using speed dialing. Up to 8 phone numbers can be

programmed using numbers 2 to 9.

Using the External Keypad

[ ] : Voice mail

[ ] : Prefix for international call

Using the Internal Keypad

[ ] : Voice mail

[ ] : Prefix for international call

Setting speed dial

1. Press Menu > Address Book > Speed Dial.

2. Select an empty entry and press Add.

3. Select a person and press OK or Select.

Changing speed dialing person

1. Press Menu > Address Book > Speed Dial.

2. Select a number > OK or Options > Change.

3. Select a person > OK or Select.

Removing from speed dial

1. Press Menu > Address Book > Speed Dial.

2. Select a number > Options > Delete.

Using the address book

You can save names, phone numbers, and information on the SIM or

phone. Entries can depend on the capacity of the SIM card.

Using the External Keypad

To unlock touch keypad, long press the Hold Key[ ] on the right side of

the phone.

Viewing the contact list

1. Tap Menu > Address Book

Searching for a phone number

1. Tap Menu > Address Book

2. Input the first letter or two of the person's name and scroll with[ / ]

3. Tap OK to view the detailed information.

4. To update information, press Options > Edit.

Calling from the contact list

1. Tap Menu > Address Book

2. Select a number to call by tapping the [ / ] key.

3. Tap [ ]

Using the Internal Keypad

Viewing the contact list

1. Press [ ] or press Menu > Address Book > Contacts.

Searching for a phone number

5. Press [ ] or press Menu > Address Book > Contacts.

6. Input the first letter or two of the person's name and scroll with[ / ]

7. Press OK to view the detailed information.

8. To update information, press Options > Edit.

Calling from the contact list

1. Press [ ] or press Menu > Address Book > Contacts.

2. Select a person to call.

3. Press [ ]

Forwarding contact details

1. Press [ ] or press Menu > Address Book > Contacts.

2. Select a contact > Options > Send This Card.

3. You can send the information using Multimedia Message or

Bluetooth.

Deleting a contact

1. Press [ ] or press Menu > Address Book > Contacts.

2. Select a contact > Options > Delete.

Adding a contact

1. Press Menu > Address Book > Add Contact.

2. Select Phone or SIM.

3. Input the fields.

4. Press OK or Save.

Making groups

1. Press Menu > Address Book > Groups.

2. You can select Phone Groups or SIM Groups. There will be defaulted

groups.

3. To add new group, press Options > Add Group.

4. To edit group press, Edit Group. You can also set a specific ringtone by

selecting Ringtone > OK > select the ringtone.

5. To delete group press, Delete Group.

Caller identification

Caller identification**

1. Press Menu > Settings > Call > Display My Number.

2. Select Network Default, Show or Hide > Select.

Using your headset

You can send or receive a call using your headset.

When you connect your headset to the jack the button on the headset

works as follows.

Note: You need to use the headset designed for this device, and it is

optional item. Also not every headset has a button.

While in standby mode

1. Press the button once to list recent calls.

2. Press the button twice to redial the last call.

While the phone is closed

1. Press the button once to receive a call.

2. Press the button once to end the call.

Service numbers and fixed dialing

Calling your service numbers*

You can see the service number to reach the service provider.

1. Press Menu > Address Book > Service Numbers.

2. Select a number > press [ ].

Viewing the fixed dialing list

Fixed dialing is a service that limits your access to specific numbers in the

address book list recorded on the SIM. Input the PIN2 to set up or cancel

this service.

1. Press Menu > Address Book > FDN List.

2. Select a number > press [ ].

NOTE: PIN2 must be correctly entered within 3 attempts. If you input the

incorrect code three times in a row the PIN2 code will be blocked. If the

PIN2 code is blocked please contact your service provider. PIN2 code

supplied with the SIM card.

3. Messaging

Entering text

Messaging

Receiving messages

Creating and sending text messages

Creating a multimedia messages

Message templates

Message settings

Voice message setting

Using instant messenger

Entering text

You can enter text with multi-tap, predictive, numeric or symbol.

Useful keys

Using the External Keypad

To unlock touch keypad, long press the Hold Key[ ] on the right side of

the phone.

[ ] Display symbols [ ]

Adding space

[ ]

Press to change capital mode.

Press to change ab Ab AB and press to change

from multi to predictive to Number

Multi-tap (all small caps / first

letter caps / all caps)

Predictive (all small caps / first

letter caps / all caps)

Number

For details on using QWERTY key pad, see page 16.

Key characters by language

Each of the following keys will scroll through these sequential options listed

by language.

key English French Spanish

1 . , - ? ! / ' @ : . , - ? ! / ' @ : . , - ? ! / ' @ : 2 abc ç à ä á ã ç 3 def é è é 4 ghi í 5 jkl 6 mno ô ñ ó ñ 7 pqrs ß 8 tuv ù ü ú ü 9 wxyz

Alphabet input mode

Press the key labeled with the target letter once for the first letter; press it

twice for the second letter, and so on.

1. Tap [ ] to [ ] to input text repeatedly. To write the letter “C”, press [

] 3 times. To write number 2 press [ ] 4 times.

Numeric mode

You can input numbers in this mode.

1. Tap [ ] to [ ] 3 or 4 times to input numeric

2. Or [ ] to [ ] long tap and hold to input numeric.

Symbol mode

You can input symbols.

1. Tap [ ] to view the symbols.

2. Tap [ / ] to select symbol and Insert.

Using the Internal Keypad

[ ] Display symbols [ ] Adding space [ ] Press to change capital mode.

Press to change ab Ab AB and press to change

from multi to predictive to Number

Multi-tap (all small caps / first

letter caps / all caps)

Predictive (all small caps / first

letter caps / all caps)

Number

For details on using QWERTY key pad, see page 16.

Predictive mode

The predictive mode automatically compares your keystrokes with an

internal linguistic dictionary to determine the correct word. It will display the

most commonly used word first. The most commonly used word will appear

first. To save a word not listed in phone's dictionary, press Options >

Predictive Settings > Selection List > On.

1. Press [ ] to change the mode to predictive.

2. Press [ ] to [ ] to input text. For example, to write ‘hello’ press [

] [ ] [ ] [ ] [ ].

Numeric mode

You can input numbers in this mode.

1. Press [ ] to change the mode to 123.

2. Press [ ] to [ ] and [ ] to input numbers.

Symbol mode

You can input symbols.

3. Press [ ] to view the symbols.

4. Press [ / / / ] to select symbol and press Insert.

Messaging

You can send, receive and save the text messages and multimedia

messages.

Managing memory

When the message box is full the messages full icon will appear. All

messages share memory.

When It means

Text message is full ( SIM and Phone messages )

Moving a message to SIM

1. Press Menu > Messaging > Conversations.

2. Select a message > Options > Move to SIM.

Deleting a message in a mailbox

1. Select a message > Options > Delete > Yes.

Replying to a message

1. Select a message > Options > Reply.

Viewing memory space information

1. Press Menu > Messaging > Used Space

2. Press [ / ] to view SIM and Phone memory.

Receiving messages

Using the External Keypad

To unlock touch keypad, long press the Hold Key[ ] on the right side of

the phone.

Using the Internal Keypad

Viewing a new message

1. Press View or press OK.

Reading a message from the conversations box

1. Press Menu > Messaging > Conversations.

2. Select a sender > Open

Saving a number or e-mail from a received message

1. Select a sender number > Open

2. Select a received message > Options > Save.

3. Select New Contact or select Update Contact.

Saving the object in the received multimedia message

1. Open the multimedia message.

2. Select an object.

3. Press Options > Use > Save.

It will be saved in one of the categories in the My Stuff folder.

For details on photo album, see page 39.

Listening to voice message

1. Press and hold [ ] or press Menu > Messaging > Voice Mail.

It will automatically call the voice mail center.

Loading URL using Push message

1. Press Menu > Messaging > Conversations > OK.

2. Press Options > Load URL.

Save connection setting using Configuration message

1. Press Menu > Messaging > Conversations > OK.

2. Press Options > Install.

Creating and sending text messages

Sending new text message

1. Press [ ] or press Menu > Messaging > Create Message.

2. Write the message.

3. Press Options > Send.

4. To view sent message press Menu > Messaging > Conversations.

NOTE: All successfully send messages will be saved in Conversations

while the messages that failed to be sent will save in the Outbox.

Finding all sent messages

1. Press Menu > Messaging > Conversations.

Creating a multimedia messages

You can create new multimedia message. Capacity is 100Kb, 300Kb,

600Kb and an error message will alert you once you exceed the capacity.

Adding a saved picture to the message

1. Press [ ] or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Insert > Picture > Camera > Select a file

4. To preview the current page, press Preview

5. To preview the whole message, press Options > Preview > Whole

Message.

6. To edit the text message, press [ / ] to select the text box.

7. Press Options > Send.

Adding a new picture to the message

1. Press [ ] or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Insert > Take New Picture.

4. Focus on the object > OK.

5. Press Send to.

For the taking picture, see page 38.

Adding a recorded voice memo to the message

1. Press [ ] or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Insert > Sound > Audio > My voice

4. To listen select the recorded memo Options > Play.

5. Press Pause to stop listening.

6. To select other recorded memo press Back and select another memo.

7. Press Send to.

Adding a new voice memo to the message

1. Press [ ] or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Insert > Record New Sound.

4. Press Record to record the sound.

5. To stop and save press Stop.

6. Press Send to.

For the recording voice memo, see page 49.

Adding a saved video to the message

1. Press [ ] or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Insert > Video > Video > Select a video

4. To preview the video, press Play

5. Press Select.

6. To preview the current page, press Options > Preview > Current.

7. To preview the whole message, press Options > Preview > Whole

message.

8. To stop press Stop.

9. Press Send to.

Adding a new video to the message

1. Press [ ] or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Insert > Record New Video.

4. Focus on the object > Record.

5. To stop recording and save press Stop.

6. Press Send to.

For the recording video, see page 38.

Adding other file to the message

1. Press [ ] or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Insert > Other File > Other File.

4. Select the file > Select.

5. Press Send to.

Message templates

When you often use the same phrases, you can save the message under

template messages.

Adding the message as a template

1. Press Menu > Messaging > Templates.

2. Press Options > Add New.

3. Write the frequently used message > Options > Save.

Sending a message with template

1. Press Menu > Messaging > Templates.

2. Select the message > Select

NOTE: You can add a template while writing message. Write a message >

Options > Add Template. Choose Text or Multimedia and select the

message to add.

Message settings

Setting message center

1. Press Menu > Messaging > Settings.

2. Press Text Message.

3. Enter new Center Address.

4. Press Save.

Setting profiles for multimedia message

1. Press Menu > Messaging > Settings.

2. Press Multimedia Message > MMS Profiles.

3. Select a profile.

Setting for sending multimedia message

Press Menu > Messaging > Settings.

Press Multimedia Message > Sending Settings.

You can set the Validity Period, Delivery Time, Priority, Creation

Mode and Max Message Size.

Setting for receiving multimedia message

1. Press Menu > Messaging > Settings.

2. Press Multimedia Message > Receiving Settings.

3. You can set the Automatic Download, Allow Delivery Reply, Allow

Read Reply and Accepted Messages.

Setting e-mail gateway

1. Press Menu > Messaging > Settings.

2. Press Email Gateway.

3. Enter new gateway for receiving e-mail.

4. Press Save.

Setting for receiving notice for push message

1. Press Menu > Messaging > Settings.

2. Press Push Message > Receive.

3. Select On or Off.

NOTE: When you receive push message the [ ] icon will displays.

Voice message setting

Setting for receiving voice message

1. Press Menu > Messaging > Settings.

2. Press Voice Mail.

3. Enter the number of the voice mail center > Save.

Note: This number may be pre-configured by the service provider upon

activation.

You can receive emails from your service provider.

Receiving an email

1. Press Menu > Messaging > Mobile Email.

2. Select an email > OK.

Using instant messenger

Use Instant Messenger (IM) to send and receive short, simple messages

that are delivered immediately.

Starting an instant messenger

1. Press Menu > Messaging > IM.

2. Select the IM application > Select.

3. Enter login and password > Sign In.

Viewing the conversation log

You can view the conversations log in the Instant Messenger Saved

History.

4. Multimedia

Camera

Photo album

Video album

Audio album

Music player

Music player settings

Media player

Other files

Managing memory

Playing games

Camera

You can take pictures and record movies using the built-in camera. The

photos and video clips can be saved and sent via multimedia messages.

Setting camera settings

1. Press Menu > My Stuff > Tools & Utilities.

2. Press Camera.

3. Press Options > Settings to change settings prior to taking a picture.

In the options menu for camera

Icons Name Description

White Balance

Auto( ), Day Light( ), Tungsten( ), Fluorescent( )

Effect

Normal( ), Sepia( ), Negative( ), B&W( )

Self Timer

Off( ), 5 secs( ), 10 secs( )

Picture Size 1600x1200(), 1280x960 ( ), 1024x768 ( ),

640x480 ( ),320x240 ( )

Advanced Picture Quality, Save Location, Shutter Sound,

Timer Sound, Default File Name

In the options menu for video camera

Icons Name Description

White Balance

Auto( ), Day Light( ), Tungsten( ), Fluorescent( )

Effect

Normal( ), Sepia( ), Negative( ), B&W( )

Self Timer

Off( ), 5 secs( ), 10 secs( )

Resolution

176x144(MMS)( ),176x144( ) 320X240( ),

Video Share( )

Advanced Video Quality, Sound Recording, Save Location,

Timer Sound, File Format, Default File Name

Size

Video mode

Camera mode

Self Timer

White Balance

Effect

Bright

Zoom

Zoom in and out

1. Press [ / ]. It ranges from x1 to x4.

Increasing or decreasing the brightness

1. Press [ / ]. It ranges from -2 to +2.

Taking a picture

1. Press [ ] in standby mode or press Menu > My Stuff > Tools.

2. Press Camera.

3. Focus on the object > OK or press Options > Capture.

NOTE: Your photo will be saved automatically to My Stuff > Picture>

Camera.

Changing to video camera mode

1. Press [ ] in standby mode or press Menu > My Stuff >Tools >

Camera.

2. Press Options while camera mode is activated.

3. Press Video Camera Mode.

4. Focus on the object > OK or press Options > Record.

5. Record the motion > Stop.

NOTE: Your video will be saved automatically to My Stuff > Video.

Viewing the taken picture

1. Press [ ] in standby mode or press Menu > My Stuff > Tools >

Camera.

2. Press Options > Photo Album.

3. Select the picture > OK.

After taking pictures

To Press

Set as wallpaper Options > Set as > Wallpaper Set as address book Options > Set as > Caller ID Send a multimedia message Options > Send > as Multimedia

Message

Send using Bluetooth Options > Send > via Bluetooth Upload photos on the web Options > Send > to HP’s Snapfish Rename Options > Rename

Multiple Select Options > Multiple Select Delete Options > Delete

Delete All Options > Delete All

Copy to External Memory Options > Copy to External Memory Move to External Memory Options > Move to External Memory

Slide Show Options > Slide Show

View photo’s information Options > Properties View by Grid Options > View by Grid

Recording a video

1. Press Menu > My Stuff > Tools > Video Camera.

2. Focus on the object > OK or press Options > Record.

3. Press Stop to stop.

4. Press Options > Play to play the video clip.

5. Press Stop > Back

Quality

Changing to camera mode

1. Press Menu > My Stuff > Tools > Video Camera.

2. Press Options while video camera mode is activated.

3. Press Camera Mode.

For details on taking a picture, see page 38.

Viewing the recorded video clip

1. Press Menu > My Stuff > Tools > Video Camera.

2. Press Options > Video Album.

3. Select the video clip > View.

After saving recorded video clips

To Press

Send a multimedia message Options > Send > as Multimedia

Message

Send using Bluetooth Options > Send > via Bluetooth View recorded video clip Options > Play Delete Options > Delete

Rename Options > Rename View the information Options > Properties

During recording a video

To Press

Receive an incoming call [ ] Stop recording OK

Photo album

You can view, send, save to your phone or an external memory card and

also delete photos. JPEG format is supported, and other formats are saved

in the Camera folder.

NOTE: To access Camera, press Menu > Picture > Camera.

Viewing the saved pictures

1. Press Menu > My Stuff.

2. Press Picture > Camera.

3. Select a picture > View or press Options > View.

Setting as wallpaper in the display

1. Press Menu > My Stuff.

2. Press Picture > Camera.

3. Select a picture > Options > Set as > Wallpaper.

Setting as caller identification

1. Press Menu > My Stuff.

2. Press Picture > Camera.

3. Select a picture > Options > Set as > Caller ID.

Sending pictures using multimedia message

1. Press Menu > My Stuff.

2. Press Picture > Camera.

3. Select a picture.

4. Press Options > Send > as Multimedia Message.

For details on creating a multimedia message, see page 31.

Uploading pictures on the web

1. Press Menu > My Stuff.

2. Press Picture > Camera.

3. Select a picture > Options > Send > to HP’s Snapfish.

Deleting multiple pictures

1. Press Menu > My Stuff.

2. Press Picture > Camera.

3. Press Options > Multiple Select.

4. Press OK to select more than one picture.

5. Press OK to unselect.

6. Press Options > Delete.

Viewing file information

1. Press Menu > My Stuff.

2. Press Picture > Camera.

3. Select a picture.

4. Press Options > Properties.

Video album

You can view, send, save and delete videos.

Playing the saved video clips

1. Press Menu > My Stuff.

2. Press Video.

3. Select a video clip > OK or press Options > Play.

Using video player controls

To Press

Play & Pause OK Rewind

hold

Fast forward

hold

Mute Mute

Set Repeat Reapear On/Off

View the information Options > Properties

Sending video clip using multimedia message

1. Press Menu > My Stuff.

2. Press Video.

3. Select a video.

4. Press Options > Send > as Multimedia Message.

For details on creating a multimedia message, see page 31.

Deleting multiple video clips

1. Press Menu > My Stuff.

2. Press Video.

3. Press Options > Multiple Select.

4. Press OK to select more than one video.

5. Press OK to unselect.

6. Press Options > Delete.

Audio album

You can play, send, delete, moves to external memory or to phone the

saved sounds. The supported formats are MP3, AAC, AAC+, and WMA.

Listening the recorded sound

1. Press Menu > My Stuff > Audio.

2. Press My Voice > select a sound > Play.

Using sound controls

To Press

Play & Pause OK Stop Options > Stop Rewind

Hold

Mute Mute

Set Repeat Reapear On/Off

View the information Options > Properties

Fast forward

Hold

Control volume

Side key up or down or /

Setting as a ring tone

1. Press Menu > My Stuff > Audio.

2. Select a sound > Options > Set as Ring Tone.

Moving or copying multiple sound to external memory

1. Press Menu > My Stuff > Audio.

2. Press Options > Multiple Select.

3. Press OK to select more than one sound file.

4. Press Options > Copy to External Memory or Move to External

Memory. The selected sound will copy to Audio folder in external memory

card.

Sending sound file using multimedia message

1. Press Menu > My Stuff > Audio.

2. Select a sound file.

3. Press Options > Send > as Multimedia Message.

Music Player

You can listen MP3 and audio files even your device is closed. It can be

only play audio files saved in MP3, .AAC, .AAC+, and .WMA,.

When It means

Music is playing Music has been paused Music has been stopped

Note: microSD card must be inserted to transfer music to your device.

Adding music from Windows Media Player

1. Connect the USB cable to the device and the computer.

2. Select Music Player > Yes.

3. Open the Sync tab in Windows Media PlayerTM in your computer.

4. Select the music from the list and drag and drop to your device.

Note: Windows Media PlayerTM 10, 11 and Window XP version is required.

Playing the music

1. Press [ ] in standby mode or press Menu > AT&T Music > Music

Player.

2. Select the categorize using [ / ] to play the music.

3. Select the file using [ / ] then press OK.

4. Press Options > Add to Playlist to add to the playlist.

5. Press Options > Stop to stop playing.

Note: To stop playing music in the standby mode, press [ ].

When receiving a call press [ ] and music will stop without asking.

Icons for player

Icon Name Description

Volume Previous

Short Press : Previous, Next

Long Press : Fast Rewind, Fast

Forward

Pause

Play

Repeat On

Shuffle On

Making playlist

1. Press [ ] in standby mode or press Menu > AT&T Music > Music

Player.

2. Press Playlists > New Playlist.

3. Select All Music, Albums, Artists or Genres.

4. Select the music file using [ / ]then press OK to add to playlist.

5. Press Done > name the playlist > Save.

Add music to playlist

1. Press [ ] in standby mode or press Menu > AT&T Music > Music

Player.

2. Press Playlists.

3. Select the playlist to add music > Options > Add Tracks.

4. Select the music to add > OK > Done.

5. To remove tracks press Options > Remove Tracks > select the music

by pressing OK > Remove.

6. To rename the playlist press Options > Rename Playlist.

7. To delete the playlist press Options > Delete.

Listening music with Bluetooth headset

1. While music is playing in the standby mode, press [ ] in standby mode

or press Menu > AT&T Music > Music Player.

2. Press Now Playing > Options > Transfer to B/T Headset.

Viewing the information

1. Press [ ] in standby mode or press Menu > AT&T Music > Music

Player.

2. Select the categorize using [ / ]to play the music.

3. Select the file using [ / ] then press OK.

4. Press Options > Properties.

5. Use [ / ] to view Title, Artist, Album, Genre, Filename,

Location, Format, Bit Rate, Length, Size, Date Added, License and

Sharing.

Setting as ringtone

1. Press [ ] in standby mode or press Menu > AT&T Music > Music

Player.

2. Select the categorize using [ / ] to play the music.

3. Select the file using [ / ] then press OK.

4. Press Options > Set as Ring Tone.

Note: During playing the music the file can not be set as ring tone. You

cannot set a file which is larger than 300 Kb as a ringtone.

Deleting music

1. Press [ ] in standby mode or press Menu > AT&T Music > Music

Player.

2. Select the music from the list.

3. Press Options > Delete.

Note: If the music is playing you cannot delete.

Shopping the music

1. Press [ ] in standby mode or press Menu > AT&T Music.

2. Press Shop Music.

3. To go to previous page press Back.

Using music identification

1. Press [ ] in standby mode or press Menu > AT&T Music.

2. Press MusicID.

3. Hold the phone close to the music. Your phone will analyze the music

and display the artist, title and album.

Note: For the cost plan contact your nearest carrier.

Listening the radio

1. Press [ ] in standby mode or press Menu > AT&T Music.

2. Press XM Radio.

Watching the music video

1. Press [ ] in standby mode or press Menu > AT&T Music.

2. Press Music Videos.

Viewing Billboard information

1. Press [ ] in standby mode or press Menu > AT&T Music.

2. Press The Buzz.

Launching to community

1. Press [ ] in standby mode or press Menu > AT&T Music.

2. Press Community.

Launching more applications

1. Press [ ] in standby mode or press Menu > AT&T Music.

2. Press Music Apps.

Music player settings

Shuffling music

1. Press [ ] in standby mode or press Menu > AT&T Music > Music

Player.

2. Press Settings.

3. Select Shuffle.

4. Select Shuffle On or Shuffle Off > OK.

Repeating the music

1. Press [ ] in standby mode or press Menu > AT&T Music > Music

Player.

2. Press Settings.

3. Select Repeat.

4. Select Repeat All Tracks, Repeat Single Track or Repeat Off > OK.

Setting equalizer

1. Press [ ] in standby mode or press Menu > AT&T Music > Music

Player.

2. Press Settings.

3. Select Equalizer.

4. Select the category by using [ / ] > OK.

Removing

1. Press [ ] in standby mode or press Menu > AT&T Music > Music

Player.

2. Press Settings.

3. Select Remove.

4. Select License Data File or All Music Contents > OK.

Media player

You can play video clips with the media player.

NOTE: Do not use this feature illegally. Sound and video can be protected

by copyright. It is illegal to copy such sound / video tracks for the purpose

of selling or distribution. Pantech does not in any way support the

unauthorized use of content on your phone media player.

Background skin

Duration

Playing time

Player controls

Volume controls

Duration

Playing time

Player controls

Volume controls

Icons for player

Icon Name Description

Volume

Long Press : Fast Rewind, Fast Forward

Pause

Play

Repeat On

Playing the video clip

1. Press Menu > My Stuff

2. Press Tools> Media Player.

3. Press Video.

4. Select a file > Options > Play.

Playing the audio file

1. Press Menu > My Stuff

2. Press Tools> Media Player

3. Press Audio.

4. Select the folder > select a file > Options > Play.

For the video player control see page 40.

Other files

You can manage files in unsupported formats saved on your phone. It also

lists files received via Bluetooth from other devices.

Viewing the list of the files

1. Press Menu > My Stuff.

2. Press Other Files.

Managing memory

Viewing memory status

1. Press Menu > My Stuff.

2. Press Used Space

3. Press [ / ] to view Phone and External memory.

Playing games

You can download games to play with. It is easy to download and you can

preview them beforehand. You will only be able to view games that are

available on your mobile.

Shop games

1. Press Menu > My Stuff.

2. Press Games.

3. Select Shop Games > Select.

4. Play the demo and press BUY to download the complete game.

5. Useful Features

Alarm

Calendar

Notepad and voice memo

Calculator, converter and stop watch

Business card

Memory information

Alarm

Setting an alarm

1. Press Menu > My Stuff > Tools> Alarms.

2. Press New for new alarm for the first time.

3. Set the Cycle, Time, Alarm Sound, Alert Type, Volume, and Power

Alarm > Save.

Viewing the saved alarms

1. Press Menu > My Stuff > Tools> Alarms.

Editing existing alarms

1. Press Menu > My Stuff > Tools> Alarms.

2. Select an alarm > Options > Change Alarm.

3. Press Options > Delete to delete an alarm.

4. Press Options > Create to add new alarm.

Calendar

Calendar helps you manage your schedule including your time for calls or

special days. You can set a reminder on any given date with this function.

Viewing calendar

1. Press Menu > My Stuff > Tools> Calendar.

NOTE: Monthly view is displayed as default.

In the monthly view

To Press

Move to another day

[ ] for Previous

[ ] for Next

Move to another week

[ ] for Previous

[ ] for Next

View other month

Side key up for Previous

Side key down for Next

Creating a new event and edit

1. Select a day > Options > New Event.

2. Select Schedule, Task or Note.

3. Input the events > Save.

NOTE: You can create events for dates from 01/01/1980 to 12/31/2050.

Notepad and voice memo

Using notepad

1. Press Menu > My Stuff > Tools > Notepad.

2. Press New for the first time. To add new note press Options > Create

New.

3. To edit memo press Options > Edit.

4. Press Options > Save to save.

Recording voice memo

3. Press Menu > My Stuff > Tools> Voice Memo.

4. Press Options > Record.

5. Press Stop to stop recording. It will automatically save on My Voice.

6. Press Options > Play to listen.

NOTE: To access My Voice, press Options > My Voice.

Listening the recorded sound

1. Press Menu > My Stuff > Audio > My Voice.

2. Select a sound > Options > Play.

Using sound controls

To Press

Pause OK Play OK

Stop Options > Stop Control volume

Side key up or down or /

Calculator, converter and stop watch

Using stop watch

1. Press Menu > My Stuff > Tools> Stop Watch.

2. Press Options > Start to start.

3. Press Stop to stop.

4. Press Continue to restart.

5. Press Reset to clear.

6. To change to lap time, press Options > Advanced Settings > Lap

Time Mode.

7. To split the stopwatch, press Options > Advanced Settings > Split

Time Mode.

Using the calculator

1. Press Menu > My Stuff > Tools> Calculator.

2. Use [ / / / /OK] to calculate.

3. Press [ ] to erase one digit.

4. Press Reset to reset.

5. Press [ ] to use the decimal point.

Using the converter

1. Press Menu > My Stuff > Tools> Converter.

2. Select the categories

3. Select current unit and enter figure.

4. Select the unit to be changed.

Business card

You can send your information by sending it as multimedia message.

Creating your own business card

1. Press Menu > Address Book > My Business Card.

2. Edit the fields > Options > Save or press OK.

Forwarding

1. Press Menu > Address Book > My Business Card.

2. Press Options > Send This Card > Multimedia Message or

Bluetooth.

3. Write a message for Multimedia Message.

4. Press Send to.

Updating information

1. Press Menu > Address Book > My Business Card.

2. Press Options > Edit.

3. Update information.

4. Press Options > Save.

Memory information

You can view the information of your phone for Applications, Audio,

Games , Picture, Video, Other Files and Tools

Viewing the information

1. Press Menu > My Stuff > Used Space.

6. Connectivity

Bluetooth

Using the browser

Profile settings

Bluetooth

Bluetooth technology enables free wireless connections between electronic

devices within a maximum range of 33 feet (10 meters). Bluetooth

connection can be used to send images, text, business cards, calendar

notes or to connect to computers using Bluetooth technology.

Your mobile phone supports:

•

Connect to PC to access internet.

•

Connect to Hands-Free.

•

Connect to electronic devices.

Icons for Bluetooth

Bluetooth is active Transmitting file using Bluetooth Bluetooth is active and the headset is connected USB is connected

Activating

1. Press Menu > Settings > Connectivity > Bluetooth > Activation.

2. Select On or Off.

Adding a device

1. Press Menu > Settings > Connectivity > Bluetooth >My Devices.

2. Press Search for Devices > Search or press OK.

3. The available device will display.

4. To select the device press Options > Select Device. To view the

details press View Detail.

5. Enter password.

Note: The other device must be in pairing mode.

Sending an object

1. Select the file from Menu > My Stuff > Audio, Picture, Video or

Other Files.

2. Press Options > Send > via Bluetooth.

3. Press Search or press OK.

4. Select the device > Select.

NOTE: If the other Bluetooth device requests pairing, the object is sent

after pairing is completed. Locked object or ones containing original rights

may not be forwarded.

Receiving an object

The receiving an object starts only when the receipt has been approved.

The received file will be saved in each place. For example, if you received

contacts information from the sender, it will be saved in your phone’s

memory.

Setting the visibility

1. Press Menu > Settings > Connectivity > Bluetooth > Visibility.

2. Select Hide or Show.

Naming the phone

1. Press Menu > Settings > Connectivity > Bluetooth > My Bluetooth

Info.

2. Select the Name > Edit > edit the field > Options > Save.

Note: This is what others will see in their device’s display for your phone when

searching for your device.

Using the browser

Accessing browser

1. Press OK in standby mode or press Menu > Mobil Web > Home.

NOTE: It will access provider’s homepage.

Viewing bookmarks

1. Press Menu > Mobil Web > Bookmarks.

2. To open the site, press Options > Go.

3. To send via text message, press Send by MSG.

Setting new bookmarks

1. Press Menu > Mobil Web > Bookmarks.

2. Press Options > Create New.

3. Enter the field > Save.

Entering address

1. Press Menu > Mobil Web > Enter Address.

2. Enter the web address > Go.

Viewing history

1. Press Menu > Mobil Web > History.

Setting advanced options

1. Press Menu > Mobil Web > Manage > Options.

2. Select the category > Select.

3. Select the option > Select.

Viewing certificates

1. Press Menu > Mobil Web > Manage > Security > Certificates.

Using preferences

1. Press Menu > Mobil Web > Manage > Preferences.

Using memory operations

1. Press Menu > Mobil Web > Manage > Memory Operations.

2. To clear the cache, press Clear Cache > Yes

3. To clear the cookies, press Clear Cookies > Yes.

4. To clear the history, press Clear History > Yes.

Viewing status of downloading

1. Press Menu > Mobil Web > Manage > Download Manage.

Profile settings

You can set profile and view Profile Name, Home URL, Connection Type,

Proxy Address and Proxy Port.

Adding new profile

1. Press Menu > Mobil Web > Manage > WAP Profiles.

2. Press Options > Create.

3. Enter the fields > Options > Save.

Editing profile

1. Press Menu > Mobil Web > Manage > WAP Profiles.

2. Select other profile > Options > Edit.

Viewing default profile

1. Press Menu > Mobil Web > Manage > WAP Profiles.

2. Select Mobil Web > Options > View.

Deleting profile

1. Press Menu > Mobil Web > Manage > WAP Profiles

2. Select a profile > Options > Delete.

7. Settings

Language

Time and date

Touch sense level

Mode transition time

Ringtones

Decorating the display

Locks

To enable fixed dialing

Reset

TTY

Language

Setting up

1. Press Menu > Settings > Phone > Language.

2. Select Screen Text or Predictive.

3. Select the language > Select.

Time and date

Setting up

1. Press Menu > Settings > Phone > Time & Date.

2. Select the category > Select.

3. Select the options > Select.

Touch sense level

Setting up

1. Press Menu > Settings > Phone > Touch Sense Level.

2. Select Level 1, Level 2, Level 3, Level 4 or Level 5

Transition Effect

Setting up

1. Press Menu > Settings > Display

2. Select on or off

Mode transition time

You can set the time to display the selected screen as menus, text editing,

etc, for during switching the screen.

Setting up

1. Press Menu > Settings > Phone > Mode Transition Time.

2. Select 5 Secs or 10 Secs.

Ringtones

Setting ringtones

1. Press Menu > My Stuff > Audio > Ring Tones

2. Select Options > Set as Ring Tone.

Setting sound profile

1. Press Menu > Settings > Profiles.

2. Select Normal, Vibrate and Ring, Vibrate Only, Silent or Flight Mode.

Decorating the display

Setting the display

You can set the Wallpaper, Clock Type and Text.

1. Press Menu > Settings > Display > Home Screen.

Setting the menu type

1. Press Menu > Settings > Display > Menu Type.

Setting the color theme

1. Press Menu > Settings > Display > Color Theme

Setting the font

1. Press Menu > Settings > Display > Font Style.

2. Press Menu > Settings > Display > Font Size.

Setting the brightness

1. Press Menu > Settings > Display > Brightness.

Note: Modifying brightness may affect battery life.

Setting time for backlight

1. Press Menu > Settings > Display > Backlight Timer.

Note: Modifying backlight time may affect battery life.

Locks

Locking the phone

1. Press Menu > Settings > Security > Phone Lock > Phone Lock.

2. Select On.

NOTE: The default password is ‘1234’. To change the password press

Menu > Settings > Security > Phone Lock > Change Password.

Locking the PIN

The Personal Identification Number is the security code that protects the

phone or SIM against unauthorized use.

1. Press Menu > Settings > Security > PIN > PIN Lock. .

2. Enter PIN code > OK.

NOTE: To change the PIN code press Menu > Settings > Security > PIN

> Change PIN.

Changing PIN 2

1. Press Menu > Settings > Security > Change PIN2.

Locking the keypad automatically

You can set locking keypad automatically to prevent mistaken key presses.

1. Press Menu > Settings > Security > Auto Key Lock.

2. Select On.

Unlocking Auto Key Lock

1. Press Menu > Settings > Security > Auto Key Lock.

2. Select Off.

Changing hidden key

The hidden key is a security code for USIM Contact. You can lock the

person’s information in the USIM Contacts with the hidden key.

1. Press Menu > Settings > Security > Change Hidden Key.

Note: The default password is dependent by SIM card. (either depends on

the SIM card or determined by the SIM card)

To enable fixed dialing

Enabling and disabling

1. Press Menu > Settings > Security > FDN.

2. Select On or Off.

For details on fixed dialing, see page 27.

Reset

Resetting the phone

1. Press Menu > Settings > Reset

2. Enter password > Master Reset.

NOTE: It will return configuration settings to default. The default password

is ‘1234’.

Clearing the phone

1. Press Menu > Settings > Reset

2. Enter password > Master Clear.

NOTE: It will change the setting as default and erase all personal data. The

default password is ‘1234’.

TTY

The teletypewriter (TTY) is a telecommunications device that allows people

who are deaf or hard of hearing, or who have speech or language

disabilities, to communicate via a telephone.

Setting teletypewriter

1. Press Menu > Settings > TTY.

2. Select Disable, TTY Full, TTY Talk or TTY Hear.

- Disable: TTY mode is disabled.

- TTY Full: User who cannot talk and hear, sends and receives a text

message.

- TTY Talk: User who can talk but cannot hear, receive a text message and

send voice message.

-TTY Hear: User who can hear but cannot talk, sends a text message and

receive voice message.

8. Appendix

Alert message

Troubleshooting checklist

Safety information

Safety precautions

About the battery usage

FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless

Devices

FCC Regulatory Compliance

Warranty

Alert message

If you experience any problem while using your mobile phone, please refer

to the following checklist. If the problem still persists, contact your dealer or

nearest carrier.

When the “Insert SIM Card” message appears:

Make sure the SIM card is correctly installed. Check to see if the SIM card

is working properly. If it does not work, try to clean the contact points of the

card with a dry cloth. If it is out of order, take it to your service provider.

When the “Messages full” message appears:

The received or saved messages are full in your phone memory. You need

to delete the message.

When the “Phone and SIM messages is full. Delete Messages”

message appears:

The received or saved messages are full in your phone and SIM card

memory. You need to delete the message.

When the “Password” message appears in Phone locked state:

Enter the phone password. The default password is”1234”. If you cannot

remember the password, contact the nearest carrier.

When the “Enter PIN1” message appears:

Input PIN1. If you cannot remember it, contact your service provider. You

can still receive calls even if your mobile phone becomes locked after

entering the incorrect PIN1 on three consecutive attempts.

When the “No Service” or “Network Search” appears:

If you cannot make/receive a call when you are indoors or undergrounds

where the signal strength is poor, move toward a window or go out to an

open area. If you still cannot make a connection, contact your service

provider.

Troubleshooting checklist

When audio quality is poor:

End a call and try again.

When the other party cannot hear you speaking:

Your phone may be set to MUTE. Disable the MUTE function. Or your hand

may be covering the microphone located below the [*] key.

When battery lifetime is shorter than usual:

This may happen when you are in an area with low signal strength. Turn off

your phone when it is not in use. Change the battery when battery energy

is exhausted.

When your mobile phone does not turn on:

Make sure your battery is charged. Check to see if your phone works while

recharging the battery.

When you are unable to send a message:

Either you are not registered to receive an SMS service, or you may be in

an area where your network service provider cannot provide such a

service.

When you are unable to make a call:

Your phone may be set to “fixed dial.” Cancel the “fixed dial” function.

When you are unable to charge the battery:

This may be the result of one of the following three cases.

1. Your charger may be out of order. Contact your nearest dealer.

2. You may be attempting to use the phone in an overly hot/cold

temperature. Try changing the charging environment.

3. Your battery may have not been connected to the charger properly.

Check the connector.

When you are unable to input data into your Address Book:

Your Address Book memory may be full. Try deleting some entries from

your Address Book.

When you are unable to select a certain function:

You may not have subscribed to that function, or your network service

provider may be in an area where such service cannot be provided.

Contact your local service provider.

Safety information

The following list shows how to maintain your mobile phone, together with

precautions to take.

•

Keep your mobile phone and its accessories out of the reach of

children and pets.

•

Maintain your mobile phone in dry conditions and keep it within normal

operating temperatures. Temperatures higher than 55°C (131°F) or

lower than -20°C (-4°F) may damage your phone.

•

Do not try to dry your phone in a microwave oven. If not, sparks can

occur and cause an explosion or ﬁre.

•

Do not use or store your mobile phone in dusty, dirty areas.

•

Do not attempt to disassemble your mobile phone.

•

Do not drop or cause severe impact to your mobile phone.

•

Do not use chemical products, cleaning solvents or detergents to clean

your mobile phone.

•

If your mobile phone does not work properly, contact your dealer

immediately.

•

Use only authorized batteries, battery chargers and accessories. Any

malfunction or damage caused by the use of unauthorized batteries,

battery chargers and accessories will void the limited product warranty.

•

Ensure that the battery and battery charger do not come in contact with

conductive objects.

Safety precautions

Using a mobile phone while driving may be prohibited.

Please check local laws and regulations with regard to the prohibition of

mobile phone use while driving, and comply with them.

Use of your phone while you are driving may disturb your concentration

and so cause an accident. Always switch your phone off to drive safely.

You should use your phone in an emergency, either use a hands free

device built into your car or pull over in a safe place first.

Switch off in restricted areas

Always switch your phone off in areas where mobile phone use is

restricted.

Switch off in explosive or dangerous areas

Always switch your phone off in areas with explosive or dangerous

materials (such as fuels, fuel stations or areas containing chemical goods)

and obey any instructions or signals. Do not remove your mobile phone’s

battery in such areas.

Switch off in aircraft

Always switch your phone off or select Flight Mode (press the Menu >

Settings > Profiles > Flight Mode) when you are in an aircraft. The

electromagnetic waves emitted by your phone may affect the electronic

navigation equipment in the aircraft.

Switch off in hospitals and near medical equipment

Always switch your phone off in hospitals, and obey the regulations or rules

of the hospital.

Switch your phone off when using medical equipment for private purposes,

if possible. Always consult with the medical equipment’s manufacturer or an

expert regarding phone use near the medical equipment.

Installing a hands free device in your vehicle

Install vehicle hands free devices away from the steering wheel and airbag

expansion area, otherwise injury may result.

Mobile phones and other electronic devices

Mobile phones emit electromagnetic waves that may affect nearby

electronic devices. When it is switched on, do not place your phone close

to delicate electronic equipment.

About the battery usage

Your phone is powered by a Lithium Ion (Li-Ion) battery. This means that,

unlike other forms of battery technology, you can recharge your battery

while some charge remains without reducing your phone’s autonomy due

to the “battery memory effect” inherent in those technologies.

•

Do not use a damaged battery or charger.

•

Do not disassemble or open crush, bend or deform, puncture or shred

•

Do not modify or remanufacture, attempt to insert foreign objects into

the battery, immerse or expose to water or other liquids, expose to fire,

explosion or other hazard.

•

Do not put your battery into contact with conductive objects.

•

Dispose of and recycle used batteries in accordance with local

regulations. Do not dispose of batteries by burning; they may explode.

•

Do not use an unauthorized charger.

•

Only use the battery for the device for which it is specified

•

Only use the battery with a charging device that has been qualified with

the device per this standard. Use of an unqualified battery or charger

may present a risk of fire, explosion, leakage, or other hazard.

•

Do not short circuit a battery or allow metallic conductive objects to

contact battery terminals.

•

Replace the battery only with another battery that has been qualified

with the device per this standard, IEEE-Std-1725-2006. Use of an

unqualified battery may present a risk of fire, explosion, leakage or

other hazard.

•

Promptly dispose of used batteries in accordance with local regulations

•

Battery usage by children should be supervised.

•

Avoid dropping the phone or battery. If the phone or battery is dropped,

especially on a hard surface, and the user suspects damage, take it to

a service center for inspection.

•

Use your battery for the specified purpose only.

•

The closer you are to your network’s base station, the longer your

phone usage time because less battery power is consumed for the

connection.

•

The battery recharging time varies depending on the remaining battery

capacity and the battery and charger type you use.

•

Battery life inevitably shortens over time.

•

Use an authorized battery and charger only.

•

Since overcharging may shorten battery life, remove the phone from its

charger once it is fully charged. Unplug the charger, once charging is

complete. Leaving the battery in hot or cold places, especially inside a

car in summer or winter, may reduce the capacity and life of the

battery. Always keep the battery within normal temperatures.

•

To prevent injury or burns, ensure that no metal objects come into

contact with the + and – terminals of the battery.

FCC Hearing-Aid Compatibility (HAC) Regulations

for Wireless Devices

On July 10, 2003, the U.S. Federal Communications Commission (FCC)

Report and Order in WT Docket 01-309 modified the exception of wireless

phones under the Hearing Aid Compatibility Act of 1988 (HAC Act) to

require digital wireless phones be compatible with hearing-aids. The intent

of the HAC Act is to ensure reasonable access to telecommunications

services for persons with hearing disabilities.

While some wireless phones are used near some hearing devices (hearing

aids and cochlear implants), users may detect a buzzing, humming, or

whining noise. Some hearing devices are more immune than others to this

interference noise, and phones also vary in the amount of interference they

generate.

The wireless telephone industry has developed a rating system for wireless

phones, to assist hearing device users find phones that may be compatible

with their hearing devices. Not all phones have been rated. Phones that

are rated have the rating on their box or a label located on the box.

The ratings are not guarantees. Results will vary depending on the user ’s

hearing device and hearing loss. If your hearing device happens to be

vulnerable to interference, you may not be able to use a rated phone

successfully. Trying out the phone with your hearing device is the best way

to evaluate it for your personal needs.

•

M-Ratings: Phones rated M3 or M4 meet FCC requirements and are

likely to generate less interference to hearing devices than phones that

are not labeled. M4 is the better/higher of the two ratings.

•

T-Ratings: Phones rated T3 or T4 meet FCC requirements and are

likely to generate less interference to hearing devices than phones that

are not labeled. T4 is the better/higher of the two ratings.

Hearing devices may also be rated. Your hearing device manufacturer or

hearing health professional may help you find this rating. Higher ratings

mean that the hearing device is relatively immune to interference noise.

The hearing aid and wireless phone rating values are then added together.

A sum of 5 is considered acceptable for normal use. A sum of 6 is

considered for best use.

In the above example, if a hearing aid meets the M2 level rating and the

wireless phone meets the M3 level rating, the sum of the two values equal

M5. This is synonymous for T ratings. This should provide the hearing aid

user with “normal usage” while using their hearing aid with the particular

wireless phone. “Normal usage” in this context is defined as a signal quality

that is acceptable for normal operation.

The M mark is intended to be synonymous with the U mark. The T mark is

intended to be synonymous with the UT mark. The M and T marks are

recommended by the Alliance for Telecommunications Industries Solutions

(ATIS). The U and UT marks are referenced in Section 20.19 of the FCC

Rules. The HAC rating and measurement procedure are described in the

American National Standards Institute (ANSI) C63.19 standard.

To ensure that the Hearing Aid Compatibility rating for your phone is

maintained, secondary transmitters such as Bluetooth and WLAN

components must be disabled during a call. See Page XX for instructions to

disable these components.

FCC Regulatory Compliance

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Your mobile device is a low power radio transmitter and receiver. When it is

ON, it receives and also sends out radio frequency (RF) signals. In August

1996, the Federal Communications Commission (FCC) adopted RF

exposure guidelines with safety levels for mobile devices. Those guidelines

are consistent with safety standards previously set by both U.S. and

international standards bodies: American National Standard Institute

(ANSI), National Council of Radiation Protection and

Measurements(NCRP), and International Commission on Non-Ionizing

Radiation Protection (ICNRP). Those standards were based on

comprehensive and periodic evaluations of the relevant scientific literature.

The design of your phone complies with the FCC guidelines and

applicable.

Statement according to FCC part 15.105

NOTE: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Statement according to FCC part 15.21

Modifications not expressly approved by this company could void the user's

authority to operate the equipment.

RF exposure FCC

For body worn operation, to maintain compliance with FCC RF exposure

guidelines, use only accessories that contain no metallic components and

provide a separation distance of 15mm (0.6 inches) to the body. Use of

other accessories may violate FCC RF exposure guidelines and should be

avoided.

This device and its antenna must not be co-located or operating in

conjunction with any other antenna or transmitter.

Health and Safety Information FCC

This EUT has been shown to be capable of compliance for localized

specific absorption rate (SAR) for uncontrolled environment/general

population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and

had been tested in accordance with the measurement procedures specified

in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-2003

Ministry of Health (Canada), Safety Code 6. The standards include a

substantial safety margin designed to assure the safety of all persons,

regardless of age and health. The exposure standard for wireless mobile

phones employs a unit of measurement known as the Specific Absorption

Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg *.

* In the U.S. and Canada, the SAR limit for mobile phones used by the

public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The

standard incorporates a substantial margin of safety to give additional

protection for the public and to account for any variations in.

**This device contains 1800 MHz GSM functions that are not operational in

U.S. Territories; this filing is applicable only for 850 MHz GSM and 1900

MHz PCS operations.

Warranty

Protect Your Warranty

Read your Warranty carefully, with the special consideration to paragraph

seven of the Limited Warranty for your unit.

“

Warranty does not apply to... or to any product or part thereof which has

suffered through alteration... mishandling, misuse, neglect or accident”.

Many companies are making look alike accessories and in some cases,

promoting that their product is equal to or better than the Pantech product.

Be careful. Some of these products may not be compatible to use with your

Pantech product and may damage the unit or cause it to malfunction.

If service is required on your unit and it is determined that a non-Pantech

accessory has created the problem with your unit, the Warranty will not

apply. In addition, if the unit has already suffered irreversible damage by

reason of a non-compatible accessory, the Warranty will be voided. To

protect your Warranty, use only compatible accessories which cannot

damage or interfere with the functioning of your Pantech product.

12 Month Limited Warranty

Pantech Wireless, Inc. (the Company) warrants to the original retail

purchaser of this Pantech handheld portable cellular telephone, that should

this product or any part thereof during normal consumer usage and

conditions, be proven defective in material or workmanship that results in

product failure within the first twelve (12) months period from the date of

purchase, such defect(s) will be repaired or replaced (with new or rebuilt

parts) at the Company’s option, without charge for parts or labor directly

related to the defect(s).

The antenna, key pad, display, rechargeable battery and battery charger, if

included, are similarly warranted for twelve (12) months from date of

purchase. This Warranty extends only to consumers who purchase the

product in the United States or Canada and it is not transferable or

assignable.

This Warranty does not apply to:

(a) Product subjected to abnormal use or conditions, accident, mishandling,

neglect, unauthorized alteration, misuse, improper installation or repair or

improper storage;

(b) Product whose mechanical serial number or electronic serial number

has been removed, altered or defaced.

or extreme environmental conditions;

(d) Damage resulting from connection to, or use of any accessory or other

product not approved or authorized by the Company;

(e) Defects in appearance, cosmetic, decorative or structural items such as

framing and non-operative parts;

(f) Product damaged from external causes such as fire, flooding, dirt, sand,

weather conditions, battery leakage, blown fuse, theft or improper usage of

any electrical source.

The Company disclaims liability for removal or reinstallation of the product,

for geographic coverage, for inadequate signal reception by the antenna or

for communications range or operation of the cellular system as a whole.

To obtain repairs or replacement within the terms of this Warranty, the

product should be delivered with proof of Warranty coverage (e.g. dated bill

of sale), the consumer’s return address, daytime phone number and/or fax

number and complete description of the problem, transportation prepaid, to

the Company by calling the number listed below or to the place of purchase

for repair or replacement processing.

To locate Pantech Authorized Service Center, call: (800) 962-8622 or email

HandsetHelp@Pantech.com.

Please have the following information available when you send the phone

in for repair:

- A valid original Proof of Purchase

- Return address

- Daytime phone number or fax number

- Model #

- IMEI # (Look for the 15 digit IMEI # behind the battery of the device.)

- Complete description of the problem

- Transportation prepaid

Other Warranty Program

You may have other warranty program with your purchase, such as

warranty exchange. If so, please refer to equipment package or the original

point of sale.

THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS

WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT

PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S

LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER

FOR THE PRODUCT.

ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY

OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,

SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN

WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY MUST

BE BROUGHT WITHIN A PERIOD OF 18 MONTHS FROM DATE OF

ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE

FOR ANY SPECIAL CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR

BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR

IMPLIED, WHATSOEVER. THE COMPANY SHALL NOT BE LIABLE FOR

THE DELAY IN RENDERING SERVICE UNDER THIS WARRANTY OR

LOSS OF USE DURING THE TIME THE PRODUCT IS BEING REPAIRED

OR REPLACED.

No person or representative is authorized to assume for the Company any

liability other than expressed herein in connection with the sale of this

product.

Some states or provinces do not allow limitations on how long an implied

warranty lasts or the exclusion or limitation of incidental or consequential

damage so the above limitation or exclusions may not apply to you. This

Warranty gives you specific legal rights, and you may also have other rights

which vary from state to state or province to province.

For technical support in the U.S. & Canada, call (800) 962-8622.

Or email: HandsetHelp@Pantech.com.

Or visit the web site: www.pantechusa.com

For all other inquiry, write to:

PANTECH WIRELESS, INC.

5607 Glenridge Dr. Suite 500 Atlanta, GA 30342

Pantech Multisync User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
