Pantech C740 AT-T, Matrix AT-T User Guide

Matrix User Manual

Thank you for choosing the Pantech Matrix, our latest 3G mobile phone. The Pantech Matrix has many features designed to enhance your mobile experience. From its sleek, stylish design and QWERTY keypad, we know you will enjoy the entire Matrix experience. This User Guide contains important and useful information that will maximize your familiarity with all that the Pantech Matrix has to offer.

Speciﬁcations

Design

Dual slider with QWERTY keypad

Displays

• 260k colors TFT LCD with 2.2" internal display

• 176x220 resolution

• 7 lines for text in basic mode with 16-point font

• Two soft keys and four-way scroll and selection OK keys

Melodies

MP3, MIDI, iMelody, MMF, WAV, SMAF, AAC+

Camera

Integrated 1.3M CMOS Camera

• Resolution up to 1280 x 960 (1,228,800 pixels)

• Mpeg4 Video recording/playing up to 15f/s(QCIF size)

• Self-timer function (5 seconds or 10 seconds)

• Photo album and video album

Dimensions & Weight

• Weight: 132g/4.66oz (with standard battery)

• Dimensions: 102 mm x 50 mm x 19.9 mm

4.02" x 1.97" x 0.78"

Power Management (Performance)

Battery Type Capacity Standby Time Talk Time

Standard

Lithium-Ion

(Li-ion)

Up to

920 mAh

Up to

16 days

Up to

5 hours

Operating Frequency

• GSM 850Mhz, GSM 900Mhz, DCS 1800Mhz, and PCS 1900Mhz networks in North America, South America, Europe, Africa, and Asia-Pacic where these networks are supported.

• Automatic band switching.

Phone overview

Number pad view

Earpiece

Display

Charger slot/Ear mic

microSD slot

Camera

Side key

Navigation

key

Scroll through

the menu

options

Music key

Send key

Voicemail

Vibrate mode

Microphone

Left/Right Soft key

Perform the functions shown at the bottom line of the display

OK key

or access

Press to enter menu system

Clear key

Returns to previous screen or deletes characters in text mode.

Power on&off/Menu exit key/End key

Turns phone on/off, ends calls, exits menus

International call preﬁx key

MEdia Net

Camera key

note: antenna area might affect the quality of all calls.

Menu features

AT&T Music Messaging Yellowpages.com MEdia Net AT&T Mall AT&T GPS My Stuff Address Book Settings

Internal antenna

Holding the device by the internal

QWERTY keyboard view

Left/Right Soft key

Perform the functions

shown at the bottom line of

To type a single uppercase

letter, press this key then

To enter a number or a

function key, and press

the corresponding key

note: To use the QWERTY keyboard, ensure that the Number pad is closed, then hold the phone horizontally and slide the screen up.

the display.

CAPS/Shift key

a letter.

Function key

symbol, press the

Space key

Press to enter a space.

Delete key

Press to delete a number or letter.

Enter key

Press to create new line while writing a message.

Clear/Back key

Return to previous screen or delete characters in text mode.

Using shortcuts Menu overview

Numbered menu items, such as menus, sub-menus, and options can be quickly accessed by using their shortcut numbers. In Menu mode, Main Menus can be accessed by pressing the number keys (1 to 9) corresponding to their

location on the screen. Example: Accessing the Language menu.

1. Press the

2. Press the 9 for Settings.

3. Press the 4 for Phone.

4. Press the 1 for Language.

5. Press Select for Screen Text.

6. Press the U or D scroll key to display the list of available

Menu.

languages.

AT&T Music

Music Player Shop Music MusicID XM Radio Music Videos Make-UR-Tones Community Music Apps

Messaging

Inbox Create Message Mobile Email IM Sent Outbox Drafts Voice Mail Settings Templates Memory Info

Yellowpages.com

MEdia Net

MEdia Net Home Bookmarks Enter Address History Manage

MEdia Mall AT&T GPS

AT&T Navigator

My Stuff

Audio Games Applications Graphics Video Tools & Utilities Other Files Memory Info

Address Book

Contacts Add Contact Speed Dial Groups My Business Card Memory in Use My Phone Number Memory Info Service Numbers FDN List

SIM dependent N Network dependent

Settings

Proles Display Call Phone Network Connections

Network Connectivity

Security Software Reset TTY

Quick & easy

Keys Functions

< >

Perform the functions shown at the bottom line of the display by using these soft keys. Scroll through the menu options in Menu mode. In standby mode,

Left: Access Mobile Email menu Right: Access IM menu Up: Access Create Message menu Down: Access Contacts menu Work in Word search mode if pressed in the Predictive text input mode.

Select a menu function or store user-input information, such as names. Also use this key for conrmation as the [OK] key. Launch the MEdia Net directly if pressed in standby mode.

Access AT&T Music menu.

Delete characters from the display, or return to previous menu. Access Calendar menu if pressed quickly in standby mode.

Keys Functions

0~9

Send or receive a call. Show the recent call list in standby mode.

Complete the current call. Turn on/off the phone if pressed and held. Cancel user input and return to main screen while in Menu mode.

Quickly connect to the voice mail server if pressed and held in standby mode. Enter numbers, letters or special characters. Go to the dial screen if pressed in standby mode. Enter or exit from vibrate mode if pressed and held in standby mode.

Show the symbol input screen if pressed in text input mode. Enter an international dialing prex if pressed and held in standby mode.

Enter the space character in text input mode. Change various text input modes if pressed at the text-editing screen. Adjust the earpiece volume while making a call.

Control the Ringtone volume, vibrate mode and silent all mode in standby. Mute the ringtone of an incoming call.

Turn camera capture mode on. Work as a camera shutter in capture mode.

Contents

Specications ................................2

Phone overview .............................3

Using shortcuts .............................5

Menu overview ..............................5

Quick & easy ..................................8

Getting Started

SIM card and battery .....................14

Turn phone on/off .........................15

Keypad lock ...................................15

Essential display indications ..........15

Memory card .................................16

Assigning the menu .......................17

Updating software .........................17

Using the QWERTY key pad .........18

MEdia Mall ....................................19

2. Calls and address book

Making, receiving and ending

a call ..............................................22

Using video share ..........................23

Options during a call ......................24

Call settings ..................................26

Settings for video share .................27

Checking all calls ...........................27

Speed dialing .................................28

Using the address book .................29

Caller identication ........................30

Using your headset .......................30

Service numbers and xed

dialing ............................................30

3. Messaging

Entering text ..................................34

Messaging .....................................35

Receiving messages ....................36

Creating and sending text

messages ......................................36

Creating a multimedia messages ..37

Message templates .......................38

Message settings .........................39

Voice message setting ..................40

Email ..............................................40

Using instant messenger ...............40

Multimedia

Camera ..........................................44

Photo album ..................................46

Contents

Video album...................................47

Audio album...................................48

Music Player ..................................49

Music player settings .....................52

Media player ..................................53

Other les ......................................54

Managing memory .........................54

Playing games ..............................54

Useful Features

Alarm .............................................58

Calendar ........................................58

Notepad and voice memo .............59

Calculator, converter and stop

watch .............................................59

Business card ................................60

Memory information .......................61

6. Connectivity

Bluetooth .......................................64

Using the browser .........................65

Prole settings ..............................66

Settings

Language.......................................70

Time and date ...............................70

Mode transition time ......................70

Ringtones .....................................70

Decorating the display ...................70

Locks .............................................71

To enable xed dialing .................72

Reset .............................................72

TTY ................................................72

Appendix

Alert message................................76

Troubleshooting checklist ..............76

Safety information .........................77

Safety precautions .........................77

About the battery usage ................78

FCC Regulatory Compliance ........79

Warranty ........................................80

Contents

Matrix

Getting Started

Calls and address book

Messaging

Multimedia

Useful Features

Connectivity

Settings

Appendix

Getting Started

SIM card and battery

Turn phone on/off

Keypad lock

Essential display indications

Memory card

Assigning the menu

Updating software

Using the QWERTY key pad

MEdia Mall

SIM card and battery

About your SIM card

When you subscribe to your network operator, you receive a SIM (Subscriber Identity Module) card containing your registration information, PIN code, etc. Like a credit card, it should be kept secure and handled carefully. Do not bend, scratch or expose it to moisture. Avoid static electricity. To avoid corrupting your SIM card’s memory, always switch off your phone before removing or inserting your SIM card.

About your battery

Your phone uses a Li-Ion battery. Make sure to use an authorized battery and charger only. For more details, please inquire at your nearest dealer.

note:

Your phone is powered by a Lithium Ion (Li-Ion) battery. Unlike other forms of battery technology, you can recharge your battery while some charge remains without reducing your phone’s autonomy due to the “battery memory effect” inherent in those technologies.

Installing/removing SIM card and battery

1. Remove the battery cover from the unit. To t the battery cover, put it on the guide rail and push up.

2. Insert the SIM card into the slot. The gold contacts of the SIM card should go against the metal contacts of the phone. Put the contacts of the battery into the hole located at the bottom of the unit insert and press the upper side of the battery until you hear the “click”.

3. To remove the battery push the bottom of the battery to upwards (1) and remove (2) the battery. Push the SIM card in the direction of the arrow as shown.

Getting Started

To charge your battery

1. To charge, open the protective cover on the top right side and connect the charger adapter. Make sure you align the connector as the image. If not, it will damage the charging connector on the phone and will not charge.

Correct Incorrect

2. To remove the adapter connection press the adapter’s side buttons (1) and pull the adapter away (2).

Turn phone on/off

To turn on

1. Press and hold E.

To turn off

1. Press and hold E.

Keypad lock

Locking the keypad

1. Press Menu > press * to lock.

Unlocking the keypad

1. Press Unlock > * to unlock.

Essential display indications

Signal strength. The greater the number of bars, the stronger the signal. When network is in searching mode is displayed.

A call is being made. When you are in no service area is displayed

Call forwardingN is active Incoming calls set to ring only (Normal) Incoming calls set to Vibrate and Ring Incoming calls set to Vibrate Only Incoming calls set to Silent

Flight Mode is active

Received one or more text messages Received one or more multimedia messages Received one or more WAP push messages

Received one or more conguration messages Received one or more voice messages A message is being sent A message is being received An alarm is set Bluetooth is active Headset is connected

USB is connected TTY is active

A GPRS signal is available. It is displayed when there is an active GPRS session

An EDGE signal is available. It is displayed when there is an active EDGE session

A 3G signal is available. It is displayed when there is an active 3G session

WAP is connected. When the security is set is displayed. When the contents download is in progress, is displayed.

Battery strength. When the battery charge is low, is displayed

Available, Away, Invisible Status of AIM

Online, Away, Busy, Ofine Status of MSN

Available, Busy, Invisible Status of YAHOO

You have received one or more IM messages

Network dependent

Memory card

You can use microSD card as a memory card. It gives you more space to save pictures, videos, music, etc.

Inserting and removing the memory card

1. Open the memory card slot.

2. Insert the card. The icon will be display.

3. Press the card to remove.

Using memory card

You can save, move and delete the les between your phone and external memory card. You can also move and copy the les to computer from your phone.

Getting Started

Resetting the card

1. Press Menu > Settings > Reset.

2. Enter the password > External Memory Reset.

note:

The default password is ‘1234’.

To copy the le to the card

1. Select the le > Options > Copy to External Memory.

2. To copy the le back to phone, press Options > Copy to

Phone.

To move the le to the card

1. Select the le > Options > Move to External Memory.

2. To move the le back to phone, press Options > Move to

Phone.

To delete the le from the card

1. Select the le from the card > Options > Delete.

To move the le from the card to the computer

1. Connect the data cable with mobile and the computer.

2. Press Menu > Settings > Connectivity.

3. Press Select USB Mode.

4. Select Mass Storage or Ask on Connection.

5. Follow the instruction on your computer screen.

note:

Select Music Player when you want to add music to the playlist in your device. When you select Ask on

Connection, it will ask you to select either the Music Player

or Mass Storage every time you connect your device with your computer.

Assigning the menu

You can set the most commonly used menu in Options in standby mode.

1. Press Options in standby mode > select Unassigned.

2. Press Edit.

3. Select the menu and sub menu.

note:

User can change Options menu except CV.

Updating software

You can update your software without visiting your nearest dealer.

To update the software

1. Press Menu > Settings > Software > Software Update.

2. Press Check for Update > Yes to check whether or not

you need to update the software.

note:

After downloading the software, the device will ask you whether to update the software now or later. If you choose to update the software now, it will restart the handset. If you postpone updating the software, you can select between 30 mins, 1 hour or 4 hours in the Options. After selecting the updating time, you will be sent back to standby mode. If you go to Software Update while you are in postponing, press Continue Update.

To view the version of software

1. Press Menu > Settings > Software.

2. Press Phone Information and scroll down to Software

Version.

Using the QWERTY key pad

Your phone has QWERTY keypad which provides a superior typing experience on a small handheld for easy and comfortable text writing. You can use all of the phone functions with the QWERTY keypad opened.

note:

QWERTY keypad can be used when the number pad is closed. With the number pad is opened, the QWERTY keypad can not be opened.

Key Function

Perform the functions shown at the bottom line of the

display by using these soft keys. Press to change ab Ab AB at the text editing screen.

Multi-tap

dbc

all caps) Press to change type to alphabet, special character and

number, special character and number on lock, at the applicable key pad. Press + to type a special character that is not placed on the keypad.

Enter the space character in text input mode. Insert a carriage return in text input mode. Delete a character to the left of the text cursor in text

editing screen. Return to previous menu.

Delete a character to the left of the text cursor in text editing screen.

Enter characters, symbols or numbers.

Press and hold to enter special symbols or numbers.

(all small caps / rst letter caps /

Getting Started

MEdia Mall

You can log on to MEdia Mall 2.0 where you can download multimedia contents for your phone.

Launching MEdia Mall

1. Press Menu > MEdia Mall.

Matrix

Getting Started

Calls and address book

Messaging

Multimedia

Useful Features

Connectivity

Settings

Appendix

Calls and address book

Making, receiving and ending a call

Using video share

Options during a call

Call settings

Settings for video share

Checking all calls

Speed dialing

Using the address book

Caller identication

Using your headset

Service numbers and xed dialing

Making, receiving and ending a call

Making a call

1. Enter the area code and phone number.

2. Press S key.

Answering a call

1. Press S.

Ending a call

1. Press E.

Once the call is complete, a call summary is displayed.

Rejecting a call

1. Press E or Ignore.

Making a call using call list

Your phone logs up to 20 dialed, received and missed call numbers.

1. Press S to display the Recent Calls list.

2. Select All Calls, Missed Calls, Received Calls, or Dialed

Calls pressing the

3. Select a number.

4. Press S to dial the selected number.

note:

To redial the last number in the Recent Calls list,

press S.

L/R

Making a call during a call

1. Enter the phone number or look it up in Address Book.

2. Press S to dial the second call. The rst call is automatically put on hold.

Switching between two calls

1. Press Swap.

Making an international call

1. Press and hold 0 key for the international prex until the ‘+’ character appears.

2. Type the country code, area code, and phone number.

3. Press S.

Making an emergency call

You can make emergency calls even if your phone does not have a SIM card.

Calls & address book

1. Press Emergency Number, or press SOS if your phone

does not have a SIM card.

2. Press S.

Replying to a missed call

1. Press View to display the list of missed calls.

2. Select a number to call by pressing the

3. Press S.

Answering a second call

1. Press S. The rst call is automatically put on hold.

2. Press E to end the second call.

The call on hold is automatically reconnected.

U/D

key.

Using video share

You can share live or recorded video while on a call. You can send or receive video.

note:

Video Share is not available in all markets. Both parties must be in a 3G service area – a 3G icon must appear by the signal bars prior to a call being placed, and both parties must remain in the 3G coverage area for the duration of the Video Share.

Making video share call

1. Enter the area code and phone number > S.

2. Press Options > Video Share.

3. Select Live or Recorded.

note:

To use video share in the Recent Calls, press Options

> Video Share.

Turning off the speakerphone

1. Press OK or press Options > Speakerphone Off during

video share mode.

2. Press Options > Mute to mute the sound.

Stopping video share

1. Press Stop to end.

2. To end a call press E.

Increasing or decreasing the brightness

1. Press Options > Brightness.

2. Adjust the brightness by pressing

L/R

Zoom in and out

1. Press Options > Zoom. It ranges from x1 to x3.

Stopping the recording

1. Press Options > Stop Record.

For details on setting for automatic recording, see page

27.

Ending video share

1. Press Stop to end the video share.

2. It will ask you whether you will stop video share > Yes to

stop.

note:

Even you end video share, the call will not be ended. Press E to end the call. The recorded video will be saved in

My Stuff > Video.

Receiving video share

1. After receiving video share, it will ask you whether to

accept or reject the video share > Yes to accept and No for reject.

2. Press Options > Landscape to landscape the screen.

Options during a call

Microphone off and on

Switching your phone’s microphone off

1. Press Options > Mute [ ].

Switching your phone’s microphone back on

1. Press Options > Unmute.

Talking on speaker

1. Press Speaker Phone [ ].

Putting a call on hold and returning

Putting a call on hold

1. Press Options > Hold or press S.

Calls & address book

Returning to a held call

1. Press Options > Unhold or press S again.

Multi-party calls

You can talk with more than one person or have conference call.

Making a multi-party call

1. Call the rst participant.

2. Call the second participant. The rst call is automatically put on hold.

3. Press Options > Join.

Having a private conversation with one participant

1. Press Options > Split.

2. Press OK.

3. Select the participant and press OK.

All of the multi-party call participants can now hear each other.

Removing one participant from a multi-party call

1. Press Options > End.

2. Select the participant and press OK.

The call ends with that participant, but you can continue to talk to the other participants.

Searching for a number in the address book during a call

1. Press D or press Options > View Contacts > Contacts.

2. Select a number > S.

Searching for a name or group in the address book

Enter the rst letters of the name for Name Search. The entries are displayed starting with the rst entry matching your input.

Finding a name manually in the address book

1. Press the

U/D

key.

Viewing the details of the highlighted entry in the address book

1. Press OK.

For details on address book, see page 29.

Reading a message during a call

1. Press Options > View Message.

2. Select a message > OK.

Writing a message during a call

1. Press Options > Create Message.

For details on creating a text message, see page 36.

Viewing calendar during a call

1. Press Options > View Calendar.

Writing a notepad during a call

1. Press Options > Notepad.

Voice recording

1. Press Options > Voice Recording.

Setting DTMF

1. Press Option > DTMF On or Off.

Call settings

Setting auto redial

1. Press Menu > Settings > Call > Auto Redial.

2. Select On or Off.

Answering by pressing any key

1. Press Menu > Settings > Call > Any Key Answer.

2. Select Answer with Any Key.

note:

You can answer with any key except E and Ignore.

Ending a call

1. Press Menu > Settings > Call > End Call Options.

2. Press Slide Down.

3. Select On or Off.

Limiting incoming calls

1. Press Menu > Settings > Security > Phone Barring.

2. Press Incoming.

3. Select On or Off.

Limiting outgoing calls

1. Press Menu > Settings > Security > Phone Barring.

2. Press Outgoing.

3. Select Bar All, Bar Prexed or Off.

• Bar All: Barring all outgoing calls.

• Bar Prexed: Barring prexed numbers.

• Off: Cancel all the barring including the bar prexed.

Calls & address book

Settings for video share

Turning the alert on/ off

1. Press Menu > Settings > Call > Video Share.

2. Press Alerts.

3. Select On or Off > Select.

Setting for automatic recording

1. Press Menu > Settings > Call > Video Share.

2. Press Auto Record.

3. Select On or Off > Select.

Setting for service

1. Press Menu > Settings > Call > Video Share.

2. Press Service.

3. Select On or Off > Select.

Setting for prole

1. Press Menu > Settings > Call > Video Share.

2. Press Prole.

3. Select AT&T IMS or Media Net > Select.

Setting recording location

1. Press Menu > Settings > Call > Video Share.

2. Press Recording Location.

3. Select Phone Memory or External Memory > Select.

Checking all calls

You can view information about all Recent Calls. For more options for all, missed, received and dialed calls press Options. You can also view the call history simply by pressing S.

Viewing missed calls

1. Press Options in standby mode or press Menu > My Stuff > Tools & Utilities.

2. Press Recent Calls > Missed Calls.

Viewing received calls

1. Press Options in standby mode or press Menu > My Stuff > Tools & Utilities.

2. Press Recent Calls > Received Calls.

Viewing dialed calls

1. Press Options in standby mode or press Menu > My Stuff > Tools & Utilities.

2. Press Recent Calls > Dialed Calls.

Deleting call logs

1. Press Options in standby mode or press Menu > My Stuff > Tools & Utilities.

2. Press Recent Calls > Delete Call Logs.

3. Select All Calls > Yes.

Viewing call time

1. Press Options in standby mode or press Menu > My Stuff > Tools & Utilities.

2. Press Recent Calls > Call Time.

3. Press

U/D

Calls and Total Calls.

to view Last Call, Received Calls, Dialed

Resetting all call times

1. Press Options in standby mode or press Menu > My Stuff > Tools & Utilities.

2. Press Recent Calls > Call Time.

3. Press Reset > Yes.

4. Enter password > OK.

note:

The default password is ‘1234’

Viewing data transmitted information

1. Press Options in standby mode or press Menu > My Stuff > Tools & Utilities.

2. Press Recent Calls > Packet Counter.

•

Current Info: You can view transmitted data in the current

session, in Kbytes. Sent, Received and Total information are also available.

•

Last Info: You can view Sent, Received, Total and

Duration information of the previous session’s transmitted

in Kbytes.

•

Total Info: You can view all the Sent, Received, Total

and Duration transmitted data in Kbytes.

•

Clear Logs: The default password is ‘1234’.

Speed dialing

You can dial quickly using speed dialing. Up to 8 phone numbers can be programmed using numbers 2 to 9.

: Voice mail

: Prex for international call

Setting speed dial

1. Press Menu > Address Book > Speed Dial.

Calls & address book

2. Select an empty entry and press Add.

3. Select a person and press OK or Select.

Changing speed dialing person

1. Press Menu > Address Book > Speed Dial.

2. Select a number > OK or Options > Change.

3. Select a person > OK or Select.

Removing from speed dial

1. Press Menu > Address Book > Speed Dial.

2. Select a number > Options > Delete.

Using the address book

You can save names, phone numbers, and information on the SIM or phone. Entries can depend on the capacity of the SIM card.

Viewing the contact list

1. Press D or press Menu > Address Book > Contacts.

Searching for a phone number

1. Press D or press Menu > Address Book > Contacts.

2. Input the rst letter or two of the person’s name and scroll with

U/D

3. Press

OK to view the detailed information.

4. To update information, press Options > Edit.

Calling from the contact list

1. Press D or press Menu > Address Book > Contacts.

2. Select a person to call.

3. Press S.

Forwarding contact details

1. Press D or press Menu > Address Book > Contacts.

2. Select a contact > Options > Send This Card.

3. You can send the information using Multimedia Message or Bluetooth.

Deleting a contact

1. Press D or press Menu > Address Book > Contacts.

2. Select a contact > Options > Delete.

Adding a contact

1. Press Menu > Address Book > Add Contact.

2. Select Phone or SIM.

3. Input the elds.

4. Press OK or Save.

Making groups

1. Press Menu > Address Book > Groups.

2. You can select group either on phone or SIM. There will be defaulted groups.

3. To add new group, press Options > Add Group.

4. To edit group press, Edit Group. You can also set a specic ringtone by selecting Ringtone > OK > select the ringtone.

Caller identiﬁcation

Caller identication N

1. Press Menu > Settings > Call > Display My Number.

2. Select Network Default, Show or Hide > Select.

Using your headset

You can send or receive a call using your headset. When you connect your headset to the jack the button on the headset works as follows.

note:

You need to use the headset designed for this device,

and it is optional item. Also not every headset has a button.

While in standby mode

1. Press the button once to list recent calls.

2. Press the button twice to redial the last call.

While the phone is closed

1. Press the button once to receive a call.

2. Press the button once to end the call.

Service numbers and ﬁxed dialing

Calling your service numbers

You can see the service number to reach the service provider.

1. Press Menu > Address Book > Service Numbers.

2. Select a number > press S.

Viewing the xed dialing list

Fixed dialing is a service that limits your access to specic numbers in the address book list recorded on the SIM. Input the PIN2 to set up or cancel this service.

1. Press Menu > Address Book > FDN List.

2. Select a number > press S.

Calls & address book

note:

PIN2 must be correctly entered within 3 attempts. If you input the incorrect code three times in a row the PIN2 code will be blocked. If the PIN2 code is blocked please contact your service provider. PIN2 code supplied with the SIM card.

Matrix

Getting Started

Calls and address book

Messaging

Multimedia

Useful Features

Connectivity

Settings

Appendix

Messaging

Entering text

Messaging

Receiving messages

Creating and sending text messages

Creating a multimedia messages

Message templates

Message settings

Voice message setting

Using instant messenger

Entering text

You can enter text with multi-tap, predictive, numeric or symbol.

Useful keys

Display symbols

Adding space

Press to change capital mode. Press to change ab Ab AB and press to change from multi to predictive to Number

Multi-tap

dbc

all caps) Predictive

caps / all caps) Number

For details on using QWERTY key pad, see page 18.

Key characters by language

Each of the following keys will scroll through these sequential options listed by language.

(all small caps / rst letter caps /

gef

(all small caps / rst letter

Key English French Spanish

1 . , - ? ! / ' @ : 2

a b c ç à ä á ã ç

d e f é è é

g h i í 5 6 7 8 9

j k l

m n o ô ñ ó ñ

p q r s ß

t u v ù ü ú ü

w x y z

Predictive mode

The predictive mode automatically compares your keystrokes with an internal linguistic dictionary to determine the correct word. It will display the most commonly used word rst. The most commonly used word will appear rst. To save a word not listed in phone’s dictionary, press Options > Predictive

Settings > Selection List > On.

1. Press # to change the mode to predictive.

2. Press 2 to 9 to input text. For example, to write ‘hello’ press

4 3 5 5 6

Messaging

Alphabet input mode

Press the key labeled with the target letter once for the rst letter; press it twice for the second letter, and so on.

1. Press # to change the mode as multi-tap.

2. Press 2 to 9 to input text repeatedly. To write the letter “C”, press 2 3 times. To write number 2 press

4 times.

Numeric mode

You can input numbers in this mode.

1. Press # to change the mode to 123.

2. Press 1 to 9 and 0 to input numbers.

Symbol mode

You can input symbols.

1. Press * to view the symbols.

2. Press

U/D/L/R

to select symbol and press Insert.

Messaging

You can send, receive and save the text messages and multimedia messages.

Managing memory

When the message box is full the messages full icon will appear. All messages share memory.

When It means

Text message is full

(SIM and Phone messages)

Moving a message to SIM

1. Press Menu > Messaging > Inbox.

2. Select a message > Options > Move to SIM.

Deleting a message in a mailbox

1. Select a message > Options > Delete > Yes.

Replying to a message

1. Select a message > Options > Reply.

Viewing memory space information

1. Press Menu > Messaging > Memory Info.

2. Press

L/R

to view SIM and Phone memory.

Receiving messages

Viewing a new message

1. Press View or press OK.

Reading a message from the inbox

1. Press Menu > Messaging > Inbox.

2. Select a received message > OK.

Saving a number or e-mail from a received message

1. Select a received message > Options > View.

2. Press Options > Save.

3. Select New Contact or select Update Contact.

Saving the object in the received multimedia message

1. Open the multimedia message.

2. Select an object.

3. Press Options > Use > Save.

It will be saved in one of the categories in the My Stuff folder.

For details on photo album, see page 46.

Listening to voice message

1. Press and hold 1 or press Menu > Messaging >

Voice Mail.

It will automatically call the voice mail center.

Loading URL using Push message

1. Press Menu > Messaging > Inbox > OK.

2. Press Options > Load URL.

Save connection setting using Conguration message

1. Press Menu > Messaging > Inbox > OK.

2. Press Options > Install.

Creating and sending text messages

Sending new text message

1. Press U or press Menu > Messaging > Create Message.

2. Write the message.

3. Press Options > Send.

4. To view sent message press Menu > Messaging > Sent.

Messaging

note:

All successfully send messages will be saved in Sent while the messages that failed to be sent will save in the

Outbox.

Finding all sent messages

1. Press Menu > Messaging > Sent.

Creating a multimedia messages

You can create new multimedia message. Capacity is 100Kb, 300Kb, 600Kb and an error message will alert you once you exceed the capacity.

Adding a saved picture to the message

1. Press U or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Options > Add Picture > Saved Pictures.

4. Select Graphics > Camera > select a le.

5. Press Options > Select.

6. To preview the current page, press Options > Preview >

Current.

7. To preview the whole message, press Options > Preview

> Whole Message.

8. To edit the text message, press box.

9. Press Options > Send.

U/D

to select the text

Adding a new picture to the message

1. Press U or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Options > Add Picture > Take Picture.

4. Focus on the object > OK.

5. Press Options > Send.

For the taking picture, see page 45.

Adding a recorded voice memo to the message

1. Press U or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Options > Add Sound > Saved Sounds.

4. Select Audio > My Voice > Select.

5. Select the le, press Options > Select.

6. To listen select the recorded memo Options > Play.

7. Press Pause to stop listening.

8. To select other recorded memo press Back and select another memo.

9. Press Options > Send.

Adding a new voice memo to the message

1. Press U or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Options > Add Sound > Record Sound.

4. Press Options > Record to record the sound.

5. To stop and save press Stop.

6. Press Options > Send.

For the recording voice memo, see page 59.

Adding a saved video to the message

1. Press U or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Options > Add Video > Saved Video.

4. Select a video > Options > Select.

5. To preview the current page, press Options > Preview >

Current.

6. To preview the whole message, press Options > Preview > Whole message.

7. To stop press Stop.

8. Press Options > Send.

Adding a new video to the message

1. Press U or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Options > Add Video > Record Video.

4. Focus on the object > Options > Record.

5. To stop recording and save press Stop.

6. Press Options > Send.

For the recording video, see page 46.

Adding other le to the message

1. Press U or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Options > Add Other File.

4. Select the le > Options > Select.

5. Press Options > Send.

Message templates

When you often use the same phrases, you can save the message under template messages.

Adding the message as a template

1. Press Menu > Messaging > Templates.

2. Press Options > Add New.

Messaging

3. Write the frequently used message > Options > Save.

Sending a message with template

1. Press Menu > Messaging > Templates.

2. Select the message to send.

3. Edit the message > Options > Send.

note:

You can add a template while writing message. Write a message > Options > Add Template. Choose Text or

Multimedia and select the message to add.

Message settings

Setting message center

1. Press Menu > Messaging > Settings.

2. Press Text Message.

3. Enter new Center Address.

4. Press Save.

Setting proles for multimedia message

1. Press Menu > Messaging > Settings.

2. Press Multimedia Message > MMS Proles.

3. Select a prole.

Setting for sending multimedia message

1. Press Menu > Messaging > Settings.

2. Press Multimedia Message > Sending Settings.

3. You can set the Validity Period, Delivery Time, Priority,

Creation Mode and Max Message Size.

Setting for receiving multimedia message

1. Press Menu > Messaging > Settings.

2. Press Multimedia Message > Receiving Settings.

3. You can set the Automatic Download, Allow Delivery

Reply, Allow Read Reply and Accepted Messages.

Setting e-mail gateway

1. Press Menu > Messaging > Settings.

2. Press Email Gateway.

3. Enter new gateway for receiving e-mail.

4. Press Save.

Setting for receiving notice for push message

1. Press Menu > Messaging > Settings.

2. Press Push Message > Receive.

3. Select On or Off.

note:

When you receive push message the [ ] icon will displays.

Voice message setting

Setting for receiving voice message

1. Press Menu > Messaging > Settings.

2. Press Voice Mail.

3. Enter the number of the voice mail center > Save.

note:

This number may be pre-congured by the service provider upon activation.

You can receive emails from your service provider.

Receiving an email

1. Press Menu > Messaging > Mobile Email.

2. Select an email > OK.

note:

In order to reduce power consumption and extend the battery life, please exit the mobile e-mail application when you have nished checking your mail.

Using instant messenger

Use Instant Messenger (IM) to send and receive short, simple messages that are delivered immediately.

Starting an instant messenger

1. Press Menu > Messaging > IM.

2. Select the IM application > Select.

3. Enter login and password > Sign In.

Viewing the conversation log

You can view the conversations log in the Instant Messenger Saved History.

Messaging

Matrix

Getting Started

Calls and address book

Messaging

Multimedia

Useful Features

Connectivity

Settings

Appendix

Multimedia

Camera

Photo album

Video album Audio album

Music player

Music player settings

Media player

Other les

Managing memory

Playing games

Camera

You can take pictures and record movies using the built-in camera. The photos and video clips can be saved and sent via multimedia messages.

In the options menu for camera

Icons Name Description

White Balance

Auto ( ), Day Light ( ), Tungsten ( ), Fluorescent ( )

Effect

Normal ( ), Sepia ( ), Negative ( ), B&W ( )

Self Timer Off ( ), 5 secs ( ), 10 secs ( )

Picture Size

960x1280 ( ), 768x1024 ( ), 480x640 ( ), 240x320 ( ), 144x176 ( )

Advanced

Picture Quality, Save Location, Shutter Sound, Timer Sound, Default File Name

In the options menu for video camera

Icons Name Description

White Balance

Auto ( ), Day Light ( ), Tungsten ( ), Fluorescent ( )

Effect

Normal ( ), Sepia ( ), Negative ( ), B&W ( )

Self Timer Off ( ), 5 secs ( ), 10 secs ( )

Resolution

96x64 (MMS) ( ), 128x96 (MMS) ( ), 176x144 (MMS) ( ), 96x64 ( ), 128x96 ( ), 176x144 ( ), Video Share( )

Video mode

White balance

Zoom Brightness

Self Timer

Remain

Setting camera settings

1. Press Menu > My Stuff > Tools & Utilities.

2. Press Camera.

3. Press Options > Settings to change settings prior to

taking a picture.

Camera mode

Effect

Size

Multimedia

Advanced

Video Quality, Sound Recording, Save Location, Timer Sound, File Format, Default File Name

Zoom in and out

1. Press

U/D

. It ranges from x1 to x4.

Increasing or decreasing the brightness

1. Press

L/R

. It ranges from -2 to +2.

Taking a picture

1. Press Q in standby mode or press Menu > My Stuff >

Tools & Utilities.

2. Press Camera.

3. Focus on the object > OK or press Options > Capture.

note:

Your photo will be saved automatically to My Stuff >

Graphics > Camera.

Changing to video camera mode

1. Press Q in standby mode or press Menu > My Stuff

>Tools & Utilities > Camera.

2. Press Options while camera mode is activated.

3. Press Video Camera Mode.

4. Focus on the object > OK or press Options > Record.

5. Record the motion >

note:

Your video will be saved automatically to My Stuff

Stop.

> Video.

Viewing the taken picture

1. Press Q in standby mode or press Menu > My Stuff >

Tools & Utilities > Camera.

2. Press Options > Photo Album.

3. Select the picture > OK.

After taking pictures

To Press

Send a multimedia message

Send using Bluetooth Options > Send via Bluetooth

Upload photos on the web Options > Send > to HP’s Snapsh

Set as wallpaper Options > Set as > Wallpaper

Set as address book Options > Set as > Caller ID

View photo’s information Options > Properties

Options > Send > as Multimedia Message

Delete Options > Delete

Rename Options > Rename

Recording a video

1. Press Menu > My Stuff > Tools & Utilities > Video

Camera.

2. Focus on the object > OK or press Options > Record.

3. Press Stop to stop.

4. Press Options > Play to play the video clip.

5. Press C to go back to preview mode.

Changing to camera mode

1. Press Menu > My Stuff > Tools & Utilities > Video

Camera.

2. Press Options while video camera mode is activated.

3. Press Camera Mode.

For details on taking a picture, see page 45.

Viewing the recorded video clip

1. Press Menu > My Stuff > Tools & Utilities > Video

Camera.

2. Press Options > Video Album.

3. Select the video clip > OK.

After saving recorded video clips

To Press

Send a multimedia message

Send using Bluetooth Options > Send via Bluetooth

View recorded video clip Options > Play

View the information Options > Properties

Options > Send > as Multimedia Message

Delete Options > Delete

Rename Options > Rename

During recording a video

To Press

Receive an incoming call

Stop recording OK

Photo album

ou can view, send, save to your phone or an external memory

card and also delete photos. JPEG format is supported, and other formats are saved in the Graphics folder.

note:

To access Graphics, press Menu > My Stuff >

Graphics.

Multimedia

Viewing the saved pictures

1. Press Menu > My Stuff.

2. Press Graphics > Camera.

3. Select a picture > OK or press Options > View.

Setting as wallpaper in the display

1. Press Menu > My Stuff.

2. Press Graphics > Camera.

3. Select a picture > Options > Set as > Wallpaper.

Setting as caller identication

1. Press Menu > My Stuff.

2. Press Graphics > Camera.

3. Select a picture > Options > Set as > Caller ID.

Sending pictures using multimedia message

1. Press Menu > My Stuff.

2. Press Graphics > Camera.

3. Select a picture.

4. Press Options > Send > as Multimedia Message.

For details on creating a multimedia message, see page

37.

Uploading pictures on the web

1. Press Menu > My Stuff.

2. Press Graphics > Camera.

3. Select a picture > Options > Send > to HP’s Snapsh.

Deleting multiple pictures

1. Press Menu > My Stuff.

2. Press Graphics > Camera.

3. Press Options > Multiple Select.

4. Press OK to select more than one picture.

5. Press OK to unselect.

6. Press Options > Delete.

Viewing le information

1. Press Menu > My Stuff.

2. Press Graphics > Camera.

3. Select a picture.

4. Press Options > Properties.

Video album

You can view, send, save and delete videos.

Playing the saved video clips

1. Press Menu > My Stuff.

2. Press Video.

3. Select a video clip > OK or press Options > Play.

Using video player controls

To Press

Pause OK

Play OK

Rewind

Hold L

Fast forward

Rotate to landscape mode Options > Landscape

Control volume

Hold R

Side key up or down or

Sending video clip using multimedia message

1. Press Menu > My Stuff.

2. Press Video.

3. Select a video.

4. Press Options > Send > as Multimedia Message.

For details on creating a multimedia message, see page 37.

U/D

Deleting multiple video clips

1. Press Menu > My Stuff.

2. Press Video.

3. Press Options > Multiple Select.

4. Press OK to select more than one video.

5. Press OK to unselect.

6. Press Options > Delete.

Audio album

You can play, send, delete, moves to external memory or to phone the saved sounds. The supported formats are MP3, AAC, AAC+, and WMA.

Listening the recorded sound

1. Press Menu > My Stuff > Audio.

2. Press My Voice > select a sound > Options > Play.

Using sound controls

To Press

Play & Pause OK

Stop Options > Stop

Rewind

Hold

Multimedia

Fast forward

Hold

Control volume

Side key up or down or

U/D

Setting as a ring tone

1. Press Menu > My Stuff > Audio.

2. Select a sound > Options > Set as Ring Tone.

Moving or copying multiple sound to external memory

1. Press Menu > My Stuff > Audio.

2. Press Options > Multiple Select.

3. Press OK to select more than one sound  le.

4. Press Options > Copy to External Memory or Move to

External Memory. The selected sound will copy to Audio

folder in external memory card.

Sending sound  le using multimedia message

1. Press Menu > My Stuff > Audio.

2. Select a sound  le.

3. Press Options > Send > as Multimedia Message.

Music Player

You can listen MP3 and audio  les even your device is closed. It can be only play audio  les saved in MP3, .AAC, .AAC+, and .WMA.

When It means

Music is playing

Music has been paused

Music has been stopped

note:

microSD card must be inserted to transfer music to

your device.

Adding music from Windows Media Player

™

1. Connect the USB cable to the device and the computer.

2. Select Music Player > Yes.

3. Open the Sync tab in Windows Media PlayerTM in your computer.

4. Select the music from the list and drag and drop to your device.

note:

Windows Media PlayerTM 10, 11 and Window XP

version is required.

Playing the music

1. Press B in standby mode or press Menu > AT&T Music > Music Player.

2. Select the categorize using

U/D

to play the music.

3. Select the le using

U/D

then press OK.

4. Press Options > Add to Playlist to add to the playlist.

5. Press Options > Stop to stop playing.

note:

To stop playing music in the standby mode, press E. When receiving a call press S and music will stop without asking.

Icons for player

Icon Name Description

Volume Previous

Next Pause

Play

Repeat All

Tracks Shufe On

Short Press : Previous, Next Long Press : Fast Rewind, Fast Forward

Making playlist

1. Press B in standby mode or press Menu > AT&T Music

> Music Player.

2. Press

Playlists > New Playlist.

3. Select All Music, Albums, Artists or Genres.

4. Select the music le using

U/D

then press OK to add to

playlist.

5. Press Done > name the playlist > Save.

Add music to playlist

1. Press B in standby mode or press Menu > AT&T Music

> Music Player.

2. Press Playlists.

3. Select the playlist to add music > Options > Add Tracks.

4. Select the music to add > OK > Done.

5. To remove tracks press Options > Remove Tracks > select the music by pressing OK > Remove.

6. To rename the playlist press Options > Rename Playlist.

7. To delete the playlist press Options > Delete.

Listening music with Bluetooth headset

1. While music is playing in the standby mode, press B in standby mode or press Menu > AT&T Music > Music

Player.

2. Press Now Playing > Options > Transfer to B/T

Headset.

Multimedia

Viewing the information

1. Press B in standby mode or press Menu > AT&T Music

> Music Player.

2. Select the categorize using

3. Select the le using

4. Press Options > Properties.

5. Use

U/D

to view Title, Artist, Album, Genre, Filename,

Location, Format, Bit Rate, Length, Size, Date Added, License and Sharing.

U/D

then press OK.

U/D

to play the music.

Setting as ringtone

1. Press B in standby mode or press Menu > AT&T Music

> Music Player.

2. Select the categorize using

3. Select the le using

4. Press Options > Set as Ring Tone.

note:

During playing the music the le can not be set as ring tone. You cannot set a le which is larger than 300 Kb as a ringtone.

U/D

then press OK.

U/D

to play the music.

Deleting music

1. Press B in standby mode or press Menu > AT&T Music

> Music Player.

2. Select the music from the list.

3. Press

Options > Delete.

note:

If the music is playing you cannot delete.

Shopping the music

1. Press B in standby mode or press Menu > AT&T Music.

2. Press Shop Music.

3. To go to previous page press Back.

Using music identication

1. Press B in standby mode or press Menu > AT&T Music.

2. Press MusicID.

3. Hold the phone close to the music. Your phone will analyze the music and display the artist, title and album.

note:

For the cost plan contact your nearest carrier.

Listening the radio

1. Press B in standby mode or press Menu > AT&T Music.

2. Press XM Radio.

Watching the music video

1. Press B in standby mode or press Menu > AT&T Music.

2. Press Music Videos.

Creating ringtones

1. Press B in standby mode or press Menu > AT&T Music.

2. Press Make-UR-Tones.

Launching to community

1. Press B in standby mode or press Menu > AT&T Music.

2. Press Community.

Launching more applications

1. Press B in standby mode or press Menu > AT&T Music.

2. Press Music Apps.

Music player settings

Shufing music

1. Press B in standby mode or press Menu > AT&T Music

> Music Player.

2. Press Settings.

3. Select Shufe.

4. Select Shufe On or Shufe Off > OK.

Repeating the music

1. Press B in standby mode or press Menu > AT&T Music > Music Player.

2. Press Settings.

3. Select Repeat.

4. Select Repeat All Tracks, Repeat Single Track or

Repeat Off > OK.

Setting equalizer

1. Press B in standby mode or press Menu > AT&T Music > Music Player.

2. Press Settings.

3. Select Equalizer.

4. Select the category by using

L/R

> OK.

Removing

1. Press B in standby mode or press Menu > AT&T Music > Music Player.

2. Press Settings.

3. Select Remove.

4. Select License Data File or All Music Contents > OK.

Multimedia

Media player

You can play video clips with the media player.

note:

Do not use this feature illegally. Sound and video can be protected by copyright. It is illegal to copy such sound / video tracks for the purpose of selling or distribution. Pantech does not in any way support the unauthorized use of content on your phone media player.

Background skin Video image

Playing time

Duration

Player control

Volume controls

Icons for player

Icon Name Description

Volume Previous

Next Pause

Play Repeat On

Long Press : Fast Rewind, Fast Forward

Playing the video clip

1. Press Menu > My Stuff

2. Press Tools & Utilities > Media Player.

3. Press Video.

4. Select a le > Options > Play.

Playing the audio le

1. Press Menu > My Stuff

2. Press Tools & Utilities > Media Player

3. Press Audio.

4. Select the folder > select a le > Options > Play.

For the video player control see page 48.

Other ﬁles

You can manage les in unsupported formats saved on your phone. It also lists les received via Bluetooth from other devices.

Viewing the list of the les

1. Press Menu > My Stuff.

2. Press Other Files.

Managing memory

Viewing memory status

1. Press Menu > My Stuff.

2. Press Memory Info.

3. Use

U/D

to view the information.

Playing games

You can download games to play with. It is easy to download and you can preview them beforehand. You will only be able to view games that are available on your mobile.

Shop games

1. Press Menu > My Stuff.

2. Press Games.

3. Select Shop Games > Select.

4. Play the demo and press BUY to download the complete game.

Multimedia

Matrix

Getting Started

Calls and address book

Messaging

Multimedia

Useful Features

Connectivity

Settings

Appendix

Useful Features

Alarm

Calendar

Notepad and voice memo

Calculator, converter and stop watch

Business card

Memory information

Alarm

Setting an alarm

1. Press Menu > My Stuff > Tools & Utilities > Alarms.

2. Press New for new alarm for the rst time.

3. Set the Cycle, Time, Alarm Sound, Alert Type, Volume, and Power Alarm > Save.

Viewing the saved alarms

1. Press Menu > My Stuff > Tools & Utilities > Alarms.

Editing existing alarms

1. Press Menu > My Stuff > Tools & Utilities > Alarms.

2. Select an alarm > Options > Change Alarm.

3. Press Options > Delete to delete an alarm.

4. Press Options > Create to add new alarm.

Calendar

Calendar helps you manage your schedule including your time for calls or special days. You can set a reminder on any given date with this function.

Viewing calendar

1. Press Menu > My Stuff > Tools & Utilities > Calendar.

note:

Monthly view is displayed as default.

In the monthly view

To Press

Move to another day

Move to another week

View other month

for Previous

for Next

for Previous

for Next

Side key up for Previous Side key down for Next

Creating a new event and edit

1. Select a day > Options > New Event.

2. Select Schedule, Task or Note.

3. Input the events > Save.

note:

You can create events for dates from 01/01/1980 to

12/31/2050.

Useful Features

Notepad and voice memo

Using notepad

1. Press Menu > My Stuff > Tools & Utilities > Notepad.

2. Press New for the rst time. To add new note press

Options > Create New.

3. To edit memo press Options > Edit.

4. Press Options > Save to save.

Recording voice memo

1. Press Menu > My Stuff > Tools &

Utilities > Voice Memo.

2. Press Options > Record.

3. Press Stop to stop recording. It will automatically save on My Voice.

4. Press Options > Play to listen.

note:

To access My Voice, press Options > My Voice.

Listening the recorded sound

1. Press Menu > My Stuff > Audio > My Voice.

2. Select a sound > Options > Play.

Using sound controls

To Press

Pause OK

Play OK

Stop Options > Stop

Control volume

Side key up or down or

U/D

Calculator, converter and stop watch

Using the calculator

1. Press Menu > My Stuff > Tools &

Utilities > Calculator.

2. Use

L/R/U/D/

3. Press C to erase one digit.

4. Press Reset to reset.

5. Press * to use the decimal point.

OK to calculate.

Using the converter

1. Press Menu > My Stuff > Tools &

Utilities > Converter.

2. Select the categories

3. Select current unit and enter gure.

4. Select the unit to be changed.

Using stop watch

1. Press Menu > My Stuff > Tools &

Utilities > Stop Watch.

2. Press Options > Start to start.

3. Press Stop to stop.

4. Press Continue to restart.

5. Press Reset to clear.

6. To change to lap time, press Options >

Advanced Settings > Lap Time Mode.

7. To split the stopwatch, press Options > Advanced

Settings > Split Time Mode.

Business card

You can send your information by sending it as multimedia message.

Creating your own business card

1. Press Menu > Address Book > My Business Card.

2. Press Yes for new business card for the rst time

3. Edit the elds > Options > Save or press OK.

Forwarding

1. Press Menu > Address Book > My Business Card.

2. Press Options > Send This Card > Multimedia Message or Bluetooth.

3. Write a message for Multimedia Message.

4. Press Options > Send.

Updating information

1. Press Menu > Address Book > My Business Card.

2. Press Options > Edit.

3. Update information.

4. Press Options > Save.

Useful Features

Memory information

You can view the information of your phone for Used, Audio,

Games, Applications, Graphics, Video, Other Files and System.

Viewing the information

1. Press Menu > My Stuff > Memory Info.

Matrix

Getting Started

Calls and address book

Messaging

Multimedia

Useful Features

Connectivity

Settings

Appendix

Connectivity

Bluetooth

Using the browser

Prole settings

Bluetooth

Bluetooth technology enables free wireless connections between electronic devices within a maximum range of 33 feet (10 meters). Bluetooth connection can be used to send images, text, business cards, calendar notes or to connect to computers using Bluetooth technology. Your mobile phone supports:

• Connect to PC to access internet.

• Connect to Hands-Free.

• Connect to electronic devices.

Icons for Bluetooth

Bluetooth is active Transmitting le using Bluetooth Bluetooth is active and the headset is connected USB is connected

Activating

1. Press Menu > Settings > Connectivity > Bluetooth >

Activation.

2. Select On or Off.

Adding a device

1. Press Menu > Settings > Connectivity > Bluetooth >My

Devices.

2. Press Search for Devices > Search or press OK.

3. The available device will display.

4. To select the device press Options > Select Device. To view the details press View Detail.

5. Enter password.

note:

The other device must be in pairing mode.

Sending an object

1. Select the le from Menu > My Stuff > Graphics, Video,

Audio or Other Files.

2. Press Options > Send > via Bluetooth.

3. Press Search or press OK.

4. Select the device > Select.

note:

If the other Bluetooth device requests pairing, the object is sent after pairing is completed. Locked object or ones containing original rights may not be forwarded.

Receiving an object

The receiving an object starts only when the receipt has been approved.

Connectivity

The received le will be saved in each place. For example, if you received contacts information from the sender, it will be saved in your phone’s memory.

Setting the visibility

1. Press Menu > Settings > Connectivity > Bluetooth >

Visibility.

2. Select Hide or Show.

Naming the phone

1. Press Menu > Settings > Connectivity > Bluetooth > My

Bluetooth Info.

2. Select the Name > Edit > edit the eld > Options > Save.

note:

This is what others will see in their device’s display

for your phone when searching for your device.

Using the browser

Accessing browser

1. Press OK in standby mode or press Menu > MEdia Net >

MEdia Net Home.

note:

It will access provider’s homepage.

Viewing bookmarks

1. Press Menu > MEdia Net > Bookmarks.

2. To open the site, press Options > Go.

3. To send via text message, press Send by MSG.

Setting new bookmarks

1. Press Menu > MEdia Net > Bookmarks.

2. Press Options > Create New.

3. Enter the eld > Save.

Entering address

1. Press Menu > MEdia Net > Enter Address.

2. Enter the web address > Go.

Viewing history

1. Press Menu > MEdia Net > History.

Setting advanced options

1. Press Menu > MEdia Net > Manage > Options.

2. Select the category > Select.

3. Select the option > Select.

Viewing certicates

1. Press Menu > MEdia Net > Manage > Security >

Certicates.

Using preferences

1. Press Menu > MEdia Net > Manage > Preferences.

Using memory operations

1. Press Menu > MEdia Net > Manage > Memory

Operations.

2. To clear the cache, press Clear Cache > Yes.

3. To clear the cookies, press Clear Cookies > Yes.

4. To clear the history, press Clear History > Yes.

Viewing status of downloading

1. Press Menu > MEdia Net > Manage > Download

Manage.

Proﬁle settings

You can set prole and view Prole Name, Home URL,

Connection Type, Proxy Address and Proxy Port.

Adding new prole

1. Press Menu > MEdia Net > Manage > WAP Proles.

2. Press Options > Create.

3. Enter the elds > Options > Save.

Editing prole

1. Press Menu > MEdia Net > Manage > WAP Proles.

2. Select other prole > Options > Edit.

Viewing default prole

1. Press Menu > MEdia Net > Manage > WAP Proles.

2. Select MEdia Net > Options > View.

Deleting prole

1. Press Menu > MEdia Net > Manage > WAP Proles.

2. Select a prole > Options > Delete.

Connectivity

Matrix

Getting Started

Calls and address book

Messaging

Multimedia

Useful Features

Connectivity

Settings

Appendix

Settings

Language

Time and date

Mode transition time

Ringtones

Decorating the display

Locks

To enable xed dialing

Reset

TTY

Language

Setting up

1. Press Menu > Settings > Phone > Language.

2. Select Screen Text or Predictive.

3. Select the language > Select.

Time and date

Setting up

1. Press Menu > Settings > Phone > Time & Date.

2. Select the category > Select.

3. Select the options > Select.

Mode transition time

You can set the time to display the selected screen as menus, text editing, etc, for during switching the screen.

Setting up

Press Menu > Settings > Phone > Mode Transition Time.

2. Select 5 Secs or 10 Secs.

Ringtones

Setting ringtones

1. Press Menu > My Stuff > Audio.

2. Select the folder > select a le > Options > Set as Ring

Tone.

Setting sound prole

1. Press Menu > Settings > Proles.

2. Select Normal, Vibrate and Ring, Vibrate Only, Silent or

Flight Mode.

Decorating the display

Setting the display

You can set the Wallpaper, Clock Type and Text.

1. Press Menu > Settings > Display > Home Screen.

Setting the menu type

1. Press Menu > Settings > Display > Menu Type.

Setting the font

1. Press Menu > Settings > Display > Font Style.

Settings

Setting the brightness

1. Press Menu > Settings > Display > Brightness.

note:

Modifying brightness may affect battery life.

Setting time for backlight

1. Press Menu > Settings > Display > Backlight Timer.

note:

Modifying backlight time may affect battery life.

Locks

Locking the phone

1. Press Menu > Settings > Security > Phone Lock >

Phone Lock.

2. Select On.

note:

The default password is ‘1234’. To change the password press Menu > Settings > Security > Phone Lock >

Change Password.

Locking the PIN

The Personal Identication Number is the security code that protects the phone or SIM against unauthorized use.

1. Press Menu > Settings > Security > PIN > PIN Lock.

2. Enter PIN code > OK.

note:

To change the PIN code press Menu > Settings >

Security > PIN > Change PIN.

Changing PIN 2

1. Press Menu > Settings > Security > Change PIN2.

Locking the keypad automatically

You can set locking keypad automatically to prevent mistaken key presses.

1. Press Menu > Settings > Security > Auto Key Lock.

2. Select On.

Unlocking Auto Key Lock

1. Press Menu > Settings > Security > Auto Key Lock.

1. Press Off.

Changing hidden key

The hidden key is a security code for USIM Contact. You can lock the person’s information in the USIM Contacts with the hidden key.

1. Press Menu > Settings > Security > Change Hidden

Key.

note:

The default password is dependent by SIM card. (either depends on the SIM card or determined by the SIM

card)

To enable ﬁxed dialing

Enabling and disabling

1. Press Menu > Settings > Security > FDN.

2. Select On or Off.

For details on xed dialing, see page 30.

Reset

Resetting the phone

1. Press Menu > Settings > Reset.

2. Enter password > Master Reset.

note:

It will return conguration settings to default. The default password is ‘1234’.

Clearing the phone

1. Press Menu > Settings > Reset.

2. Enter password >

note:

It will change the setting as default and erase all

personal data. The default password is ‘1234’.

Master Clear.

TTY

The teletypewriter (TTY) is a telecommunications device that allows people who are deaf or hard of hearing, or who have speech or language disabilities, to communicate via a telephone.

Setting teletypewriter

1. Press Menu > Settings > TTY.

2. Select Disable, TTY Full, TTY Talk or TTY Hear.

• Disable: TTY mode is disabled.

• TTY Full: User who cannot talk and hear, sends and receives a text message.

• TTY Talk: User who can talk but cannot hear, receive a text message and send voice message.

• TTY Hear: User who can hear but cannot talk, sends a text message and receive voice message.

Settings

Matrix

Getting Started

Calls and address book

Messaging

Multimedia

Useful Features

Connectivity

Settings

Appendix

Alert message

Troubleshooting checklist

Safety information

Safety precautions

About the battery usage

FCC Regulatory Compliance

Warranty

Alert message

If you experience any problem while using your mobile phone, please refer to the following checklist. If the problem still persists, contact your dealer or nearest carrier.

When the “Insert SIM Card” message appears:

Make sure the SIM card is correctly installed. Check to see if the SIM card is working properly. If it does not work, try to clean the contact points of the card with a dry cloth. If it is out of order, take it to your service provider.

When the “Messages full” message appears:

The received or saved messages are full in your phone memory. You need to delete the message.

When the “Phone and SIM messages is full. Delete Messages” message appears:

The received or saved messages are full in your phone and SIM card memory. You need to delete the message.

When the “Password” message appears in Phone locked state:

Enter the phone password. The default password is”1234”. If you cannot remember the password, contact the nearest carrier.

When the “Enter PIN1” message appears:

Input PIN1. If you cannot remember it, contact your service provider. You can still receive calls even if your mobile phone becomes locked after entering the incorrect PIN1 on three consecutive attempts.

When the “No Service” or “Network Search” appears:

If you cannot make/receive a call when you are indoors or undergrounds where the signal strength is poor, move toward a window or go out to an open area. If you still cannot make a connection, contact your service provider.

Troubleshooting checklist

When audio quality is poor:

End a call and try again.

When the other party cannot hear you speaking:

Your phone may be set to MUTE. Disable the MUTE function. Or your hand may be covering the microphone located below the * key.

When battery lifetime is shorter than usual:

This may happen when you are in an area with low signal strength. Turn off your phone when it is not in use. Change the battery when battery energy is exhausted.

When your mobile phone does not turn on:

Make sure your battery is charged. Check to see if your phone works while recharging the battery.

When you are unable to send a message:

Either you are not registered to receive an SMS service, or you may be in an area where your network service provider cannot provide such a service.

06 07

Appendix

When you are unable to make a call:

Your phone may be set to “xed dial.” Cancel the “xed dial” function.

When you are unable to charge the battery:

This may be the result of one of the following three cases.

1. Your charger may be out of order. Contact your nearest dealer.

2. You may be attempting to use the phone in an overly hot/cold temperature. Try changing the charging environment.

3. Your battery may have not been connected to the charger properly. Check the connector.

When you are unable to input data into your Address Book:

Your Address Book memory may be full. Try deleting some entries from your Address Book.

When you are unable to select a certain function:

You may not have subscribed to that function, or your network service provider may be in an area where such service cannot be provided. Contact your local service provider.

Safety information

The following list shows how to maintain your mobile phone, together with precautions to take. – Keep your mobile phone and its accessories out of the reach of

children and pets.

– Maintain your mobile phone in dry conditions and keep it within normal

operating temperatures. Temperatures higher than 55°C (131°F) or lower than -20°C (-4°F) may damage your phone.

– Do not try to dry your phone in a microwave oven. If not, sparks can

occur and cause an explosion or re. – Do not use or store your mobile phone in dusty, dirty areas. – Do not attempt to disassemble your mobile phone. – Do not drop or cause severe impact to your mobile phone. – Do not use chemical products, cleaning solvents or detergents to clean

your mobile phone. – If your mobile phone does not work properly, contact your dealer

immediately. – Use only authorized batteries, battery chargers and accessories. Any

malfunction or damage caused by the use of unauthorized batteries,

battery chargers and accessories will void the limited product warranty. – Ensure that the battery and battery charger do not come in contact

with conductive objects.

Safety precautions

Using a mobile phone while driving may be prohibited.

Please check local laws and regulations with regard to the prohibition of mobile phone use while driving, and comply with them. Use of your phone while you are driving may disturb your concentration and so cause an accident. Always switch your phone off to drive safely. You should use your phone in an emergency, either use a hands free device built into your car or pull over in a safe place rst.

Switch off in restricted areas

Always switch your phone off in areas where mobile phone use is restricted.

Switch off in explosive or dangerous areas

Always switch your phone off in areas with explosive or dangerous materials (such as fuels, fuel stations or areas containing chemical goods) and obey any instructions or signals. Do not remove your mobile phone’s battery in such areas.

Switch off in aircraft

Always switch your phone off or select Flight Mode (press the Menu > Settings > Proles > Flight Mode) when you are in an aircraft. The electromagnetic waves emitted by your phone may affect the electronic navigation equipment in the aircraft.

Switch off in hospitals and near medical equipment

Always switch your phone off in hospitals, and obey the regulations or rules of the hospital. Switch your phone off when using medical equipment for private purposes, if possible. Always consult with the medical equipment’s manufacturer or an expert regarding phone use near the medical equipment.

Installing a hands free device in your vehicle

Install vehicle hands free devices away from the steering wheel and airbag expansion area, otherwise injury may result.

Mobile phones and other electronic devices

Mobile phones emit electromagnetic waves that may affect nearby electronic devices. When it is switched on, do not place your phone close to delicate electronic equipment.

About the battery usage

Your phone is powered by a Lithium Ion (Li-Ion) battery. This means that, unlike other forms of battery technology, you can recharge your battery while some charge remains without reducing your phone’s autonomy due to the “battery memory effect” inherent in those technologies. – Do not use a damaged battery or charger. – Do not disassemble or open crush, bend or deform, puncture or shred – Do not modify or remanufacture, attempt to insert foreign objects into

the battery, immerse or expose to water or other liquids, expose to re,

explosion or other hazard. – Do not put your battery into contact with conductive objects. – Dispose of and recycle used batteries in accordance with local

regulations. Do not dispose of batteries by burning; they may explode. – Do not use an unauthorized charger. – Only use the battery for the device for which it is specied – Only use the battery with a charging device that has been qualied

with the device per this standard. Use of an unqualied battery or

charger may present a risk of re, explosion, leakage, or other hazard. – Do not short circuit a battery or allow metallic conductive objects to

contact battery terminals. – Replace the battery only with another battery that has been qualied

with the device per this standard, IEEE-Std-1725-2006. Use of an

unqualied battery may present a risk of re, explosion, leakage or

other hazard. – Promptly dispose of used batteries in accordance with local regulations – Battery usage by children should be supervised.

06 07

Appendix

– Avoid dropping the phone or battery. If the phone or battery is dropped,

especially on a hard surface, and the user suspects damage, take it to

a service center for inspection. – Use your battery for the specied purpose only. –

The closer you are to your network’s base station, the longer your phone

usage time because less battery power is consumed for the connection. – The battery recharging time varies depending on the remaining battery

capacity and the battery and charger type you use. – Battery life inevitably shortens over time. – Use an authorized battery and charger only. – Since overcharging may shorten battery life, remove the phone from

its charger once it is fully charged. Unplug the charger, once charging

is complete. Leaving the battery in hot or cold places, especially inside

a car in summer or winter, may reduce the capacity and life of the

battery. Always keep the battery within normal temperatures. – To prevent injury or burns, ensure that no metal objects come into

contact with the + and – terminals of the battery.

FCC Regulatory Compliance

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Your mobile device is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals.

In August 1996, the Federal Communications Commission (FCC) adopted RF exposure guidelines with safety levels for mobile devices. Those guidelines are consistent with safety standards previously set by both U.S. and international standards bodies: American National Standard Institute (ANSI), National Council of Radiation Protection and Measurements(NCRP), and International Commission on NonIonizing Radiation Protection (ICNRP). Those standards were based on comprehensive and periodic evaluations of the relevant scientic literature. The design of your phone complies with the FCC guidelines and applicable.

Statement according to FCC part 15.105 NOTE: This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

Statement according to FCC part 15.21

Modications not expressly approved by this company could void the user’s authority to operate the equipment.

RF exposure FCC

For body worn operation, to maintain compliance with FCC RF exposure guidelines, use only accessories that contain no metallic components and provide a separation distance of 15mm (0.6 inches) to the body. Use of other accessories may violate FCC RF exposure guidelines and should be avoided. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.

Health and Safety Information FCC

This EUT has been shown to be capable of compliance for localized specic absorption rate (SAR) for uncontrolled environment/general population exposure limits specied in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specied in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-2003 Ministry of Health (Canada), Safety Code 6. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specic Absorption Rate, or SAR. The SAR limit set by the FCC is

1.6W/kg *. * In the U.S. and Canada, the SAR limit for mobile phones used by the

public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The

standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in.

** This device contains 1800 MHz GSM functions that are not

operational in U.S. Territories; this ling is applicable only for 850 MHz GSM and 1900 MHz PCS operations.

Warranty

Protect Your Warranty

Read your Warranty carefully, with the special consideration to paragraph seven of the Limited Warranty for your unit.

“Warranty does not apply to... or to any product or part thereof which has suffered through alteration... mishandling, misuse, neglect or accident”.

Many companies are making look alike accessories and in some cases, promoting that their product is equal to or better than the Pantech product. Be careful. Some of these products may not be compatible to use with your Pantech product and may damage the unit or cause it to malfunction.

If service is required on your unit and it is determined that a non-Pantech accessory has created the problem with your unit, the Warranty will not apply. In addition, if the unit has already suffered irreversible damage by reason of a non-compatible accessory, the Warranty will be voided. To protect your Warranty, use only compatible accessories which cannot damage or interfere with the functioning of your Pantech product.

06 07

Appendix

12 Month Limited Warranty

Pantech Wireless, Inc. (the Company) warrants to the original retail purchaser of this Pantech handheld portable cellular telephone, that should this product or any part thereof during normal consumer usage and conditions, be proven defective in material or workmanship that results in product failure within the rst twelve (12) months period from the date of purchase, such defect(s) will be repaired or replaced (with new or rebuilt parts) at the Company’s option, without charge for parts or labor directly related to the defect(s).

The antenna, key pad, display, rechargeable battery and battery charger, if included, are similarly warranted for twelve (12) months from date of purchase. This Warranty extends only to consumers who purchase the product in the United States or Canada and it is not transferable or assignable.

This Warranty does not apply to:

(a) P

roduct subjected to abnormal use or conditions, accident, mishandling, neglect, unauthorized alteration, misuse, improper installation or repair or improper storage;

(b) Product whose mechanical serial number or electronic serial number

has been removed, altered or defaced.

temperatures or extreme environmental conditions;

(d) Damage resulting from connection to, or use of any accessory or

other product not approved or authorized by the Company;

(e) Defects in appearance, cosmetic, decorative or structural items such

as framing and non-operative parts;

(f) Product damaged from external causes such as re, ooding, dirt,

sand, weather conditions, battery leakage, blown fuse, theft or improper usage of any electrical source.

The Company disclaims liability for removal or reinstallation of the product, for geographic coverage, for inadequate signal reception by the antenna or for communications range or operation of the cellular system as a whole.

To obtain repairs or replacement within the terms of this Warranty, the product should be delivered with proof of Warranty coverage (e.g. dated bill of sale), the consumer’s return address, daytime phone number and/ or fax number and complete description of the problem, transportation prepaid, to the Company by calling the number listed below or to the place of purchase for repair or replacement processing.

To locate Pantech Authorized Service Center, call: (800) 962-8622 or email HandsetHelp@Pantech.com.

Please have the following information available when you send the phone in for repair:

– A valid original Proof of Purchase – Return address – Daytime phone number or fax number – Model # – IMEI # (Look for the 15 digit IMEI # behind the battery of the device.) – Complete description of the problem – Transportation prepaid

Other Warranty Program

You may have other warranty program with your purchase, such as warranty exchange. If so, please refer to equipment package or the original point of sale.

THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT.

ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY MUST BE BROUGHT WITHIN A PERIOD OF 18 MONTHS FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR ANY SPECIAL CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER. THE COMPANY SHALL NOT BE LIABLE FOR THE DELAY IN RENDERING SERVICE UNDER THIS WARRANTY OR LOSS OF USE DURING THE TIME THE PRODUCT IS BEING REPAIRED OR REPLACED.

No person or representative is authorized to assume for the Company any liability other than expressed herein in connection with the sale of this product.

Some states or provinces do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damage so the above limitation or exclusions may not apply to you. This Warranty gives you specic legal rights, and you may also have other rights which vary from state to state or province to province.

For technical support in the U.S. & Canada, call (800) 962-8622. Or email: HandsetHelp@Pantech.com. Or visit the web site: www.pantechusa.com

For all other inquiry, write to:

PANTECH WIRELESS, INC.

5607 Glenridge Dr. Suite 500 Atlanta, GA 30342

Gracias por elegir el Pantech Matrix, nuestro más reciente teléfono móvil 3G.

Manual del Usuario de Matrix

El Pantech Matrix posee muchas funciones diseñadas para mejorar su experiencia móvil. Por su diseño elegante, con estilo y teclado QWERTY, sabemos que disfrutará de toda la experiencia del Matrix. Esta Guía del usuario contiene información importante y útil que lo ayudará a familiarizarse al máximo con todo lo que Pantech Matrix tiene para ofrecer.

Especiﬁcaciones

Diseño

Deslizador doble con teclado QWERTY

Pantallas

• LCD TFT de 260000 colores con pantalla interna de

2.2 pulgadas

• Resolución 176*220

• 7 líneas para texto en modo básico con fuente de 16 puntos

• Dos teclas programables, teclas de desplazamiento en cuatro

direcciones y de selección OK.

Melodías

MP3, MIDI, iMelody, MMF, WAV, SMAF, AAC+

Cámara

Cámara CMOS integrada de 1.3M

• Resolución hasta 1280 x 960 (1,228,800 píxeles)

• Grabación y reproducción de videos Mpeg4 hasta 15 marcos por segundo (tamaño QCIF)

• Función de temporizador automático (5 ó 10 segundos)

• Álbum de fotos y álbum de videos

Dimensiones y peso

• Peso: 132g/4.66oz (con batería estándar)

• Dimensiones: 102 mm x 50 mm x 19.9 mm

4.02" x 1.97" x 0.78"

Administración de energía (Rendimiento)

Tipo de

batería

Ión de litio

estándar (Ión-litio)

Capacidad

Hasta

920 mAh

Tiempo de

espera

Hasta

16 días

Tiempo de

conversación

Hasta

5 horas

Frecuencia operativa

• Redes GSM de 850 Mhz, GSM de 900Mhz, DCS de 1800 Mhz y PCS de 1900 Mhz en América del Norte, América del Sur, Europa, África y Asia Pacíco, donde cuentan con soporte.

• Cambio de banda automático.

Generalidades del teléfono

Vista del teclado numérico

Auricular Pantalla

Tecla programable izquierda/derecha

Ejecuta las funciones que

Tecla de

navegación

Se desplaza por

las opciones de

menú.

Tecla de músicay

Tecla HABLAR Correo de voz

Modo de

vibración

Micrófono

aparecen en la parte inferior de la pantalla.

Tecla OK

Presione para entrar al sistema de menú

Tecla Borrar

Vuelve a la pantalla anterior o elimina los caracteres en modo de texto.

Encendido o apagado/Tecla de salida de menú/Tecla Terminar

Enciende y apaga el teléfono, naliza llamadas, sale de menús

Tecla de preﬁjo de llamadas internacionales

o acceda

MEdia Net

Charger slot/Ear mic

Ranura para microSD

Camera

Tecla

lateral

Tecla de cámara

nota:

sostener el dispositivo por el área de

Antena interna

la antena interna puede afectar la calidad de las llamadas.

Características del menú

AT&T Música Mensajería Yellowpages.com MEdia Net Comprar MEdia AT&T GPS Mi material

Libreta de direcciones

Conguración

Vista del teclado QWERTY

Tecla programable

izquierda/derecha

Ejecuta las funciones que

aparecen en la parte inferior

Para escribir una sola letra

mayúscula, presione esta

Para ingresar un número

note: para usar el teclado QWERTY, asegúrese de que el teclado numérico esté cerrado, luego coloque el teléfono en forma horizontal y deslice la pantalla hacia arriba.

de la pantalla.

Tecla Bloq/mayús

tecla y luego una letra.

Tecla de función

o un símbolo, presione

la tecla de función y

luego presione la tecla

correspondiente

Tecla espacio

Presione para ingresar un espacio.

Tecla supr

Presione para borrar un número o letra.

Tecla Enter

Presione para crear una nueva línea mientras escribe un mensaje.

Tecla borrar/atrás

Vuelve a la pantalla anterior o elimina los caracteres en modo de texto.

Uso de los accesos directos Generalidades del menú

Se puede acceder fácilmente a los elementos de menú numerados, como menús, submenús y opciones, mediante sus números de atajo. En modo Menú, se puede tener acceso a los menús principales presionando las teclas numéricas (1 a 9)

que corresponden a su ubicación en la pantalla. Ejemplo: acceso al menú Idioma.

1. Presione

2. Presione 9 para Conguración.

3. Presione el 4 para Teléfono.

4. Presione 1 para Idioma.

5. Presione Seleccionar para Texto de pantalla.

6. Presione la tecla de desplazamiento [arriba] o [abajo] para

Menú.

mostrar la lista de idiomas disponibles.

AT&T Música

Reproductor de música Comprar música MúsicaID Radio XM Video musical Lo más novedoso Comunidad Música aplicaciones

Mensajería

Buzón de entrada Crear mensaje Mobile Email IM Enviado Buzón de salida Borradores Correo de voz Conguración Plantillas Info de memoria

Yellowpages.com

MEdia Net

Inicio de MEdia Net Favoritos Ingresar dirección Historial Administrar

Comprar MEdia AT&T GPS

Navegar AT&T

Mi material

Audio Juegos Aplicaciones Grácos Video Herramientas y utilidades Otros archiv. Info de memoria

Libreta de direcciones

Contactos Añadir contacto Marcación rápida Grupos Mi tarjeta de presentación Memoria en uso Mi número de teléfono Info de memoria Números de servicio Lista FDN

Depende de SIM N Depende de la red

Conguración

Perles Pantalla Llamada Teléfono Conexiones de red

Red Conectividad

Seguridad Software Restablecer TTY

Rápido y fácil

Teclas Funciones

< >

Ejecuta las funciones que aparecen en la parte inferior de la pantalla utilizando estas teclas programables. Se desplaza a través de las opciones de menú en el modo Menú. En modo de espera,

Izquierda: accede al menú de Mobile Email Derecha: accede al menú IM Arriba: accede al menú Crear mensaje Abajo: accede al menú Contactos Funciona en modo de búsqueda de palabras, si se presiona en el modo de ingreso de texto predictivo.

Selecciona una función del menú o almacena información ingresada por el usuario, como nombres. Esta tecla también se usa para conrmar como la tecla [OK]. Inicia MEdia Net directamente si se presiona en modo de espera.

Accede al menú AT&T Música.

Elimina caracteres de la pantalla o vuelve al menú anterior. Accesar al menú de Calendario si se presione en modo de espera.

Teclas Funciones

Envía o recibe una llamada. Muestra la lista de llamadas recientes en modo de espera.

Finaliza la llamada actual. Al mantenerla presionada, enciende o apaga el teléfono.

Cancela lo ingresado por el usuario y vuelve a la pantalla principal mientras está en el modo Menú.

0~9

Al mantenerla presionada en modo de espera, conecta rápidamente al servidor de correo de voz. Ingresa números, letras o caracteres especiales. Al presionarla en modo de espera, lleva a la pantalla

de marcación. Al mantenerla presionada en modo de espera, ingresa o sale del modo de vibración.

Al mantenerla presionada en modo de ingreso de texto, muestra la pantalla de ingreso de símbolos. Si se mantiene presionada en el modo de espera, ingresa un prejo de marcación internacional.

Ingresa el carácter de espacio en el modo de ingreso de texto. Al presionarla en la pantalla de edición de texto, cambia entre los diversos modos de ingreso de texto. Ajusta el volumen del auricular durante una llamada.

Controla el volumen de tono de timbre, el modo de vibración y el modo todo silencioso en espera. Silencia el tono de timbre de una llamada entrante.

Activa el modo de captura de la cámara. Funciona como disparador de la cámara en modo de captura.

Contents

Contenidos

Especicaciones ..................................2

Generalidades del teléfono .................3

Uso de los accesos directos ...............5

Generalidades del menú .....................5

Rápido y fácil ........................................8

1. Inicio

Tarjeta SIM y batería ............................14

Encendido/apagado del teléfono ..........15

Bloqueo del teclado ..............................15

Indicaciones básicas de pantalla ..........15

Tarjeta de memoria ..............................16

Asignación del menú ............................18

Actualización de software .....................18

Uso del teclado QWERTY ....................18

Comprar MEdia ....................................19

2. Llamadas y libreta de direcciones

Realización, recepción y

nalización de una llamada ..................22

Uso de compartir video.........................23

Opciones durante una llamada ............25

Conguración de llamada .....................27

Conguración para compartir video .....27

Vericación de todas las llamadas .......28

Marcación rápida ..................................29

Uso de la libreta de direcciones ...........30

Identicación de llamada ......................31

Uso del auricular ...................................31

Números de servicio y marcación ja ...32

3. Mensajería

Ingreso de texto ....................................36

Mensajería ............................................37

Recepción de mensajes .......................38

Creación y envío de mensajes de

texto ......................................................39

Creación de mensajes de multimedia ..39

Plantillas de mensaje ............................41

Conguración de mensajes ..................41

Conguración de mensajes de voz ......42

Correo electrónico ................................42

Uso de Mensajero instantáneo .............43

4. Multimedia

Cámara .................................................46

Álbum de fotos ......................................49

Álbum de video .....................................50

Contents

Álbum de audio .....................................51

Reproductor de música ........................52

Conguración del reproductor de

música ..................................................55

Reproductor multimedia .......................56

Otros archivos ......................................57

Administración de memoria ..................57

Juegos ..................................................57

5. Características útiles

Alarma ..................................................60

Calendario ............................................60

Bloc de notas y memo de voz ..............61

Calculadora, convertidor y

cronómetro ...........................................62

Tarjeta de presentación ........................62

Información de memoria .......................63

6. Conectividad

Bluetooth...............................................66

Uso del navegador ...............................67

Conguración de perl..........................68

7. Conﬁguración

Idioma ...................................................72

Hora y fecha .........................................72

Modo de tiempo de transición ..............72

Tonos de timbre ....................................72

Conguración de la pantalla .................72

Bloqueos ...............................................73

Para activar la marcación ja ...............74

Restablecer ..........................................74

TTY .......................................................74

8. Apéndice

Mensajes de alerta ...............................78

Lista de control de solución de

problemas .............................................78

Información de seguridad .....................79

Medidas de seguridad ..........................80

Acerca del uso de la batería .................80

Cumplimiento con las

reglamentaciones de la FCC ................81

Garantía ................................................83

Contenidos

Matrix

Inicio

Llamadas y libreta de direcciones

Mensajería

Multimedia

Características útiles

Conectividad

Conﬁguración

Apéndice

Inicio

Tarjeta SIM y batería

Encendido/apagado del teléfono

Bloqueo del teclado

Indicaciones básicas de pantalla

Tarjeta de memoria

Asignación del menú

Actualización de software

Uso del teclado QWERTY

Comprar MEdia

Tarjeta SIM y batería

Acerca de la tarjeta SIM

Cuando se suscriba a un operador de red, recibirá una tarjeta SIM (Módulo de identidad del abonado) que contiene la información de registro, el código PIN, etc. Al igual que una tarjeta de crédito, debe mantenerla en un lugar seguro y manejarla con cuidado. No debe doblarla, rayarla ni tampoco exponerla a la humedad. Evite la electricidad estática. Para evitar que se corrompa la memoria de la tarjeta SIM, apague siempre el teléfono antes de extraer o insertar la tarjeta.

Acerca de la batería

Este teléfono utiliza una batería de ión litio. Asegúrese de utilizar solamente baterías y cargadores autorizados. Para obtener más detalles, comuníquese con el distribuidor más cercano.

nota:

La energía del teléfono proviene de una batería de ión de litio (ión-litio). A diferencia de otras tecnologías, se puede recargar la batería mientras aún queda carga, sin reducir la autonomía del teléfono debido al “efecto de memoria de la batería” inherente a estas tecnologías.

Instalación/retiro de la tarjeta SIM y de la batería

1. Extraiga la cubierta de la batería de la unidad. Para ajustar la cubierta de la batería, póngala en el riel guía y presione hacia arriba.

2. Introduzca la tarjeta SIM en la ranura. Los contactos dorados de la tarjeta SIM deben coincidir con los contactos metálicos del teléfono. Coloque los contactos de la batería en el oricio de la parte inferior de la unidad y luego presione la parte superior de la batería hasta escuchar un chasquido.

3. Para extraer la batería, presione la parte inferior de ésta hacia arriba (1) y sáquela (2). Empuje la tarjeta SIM en la dirección de la echa, como lo indica la imagen.

Inicio

Para cargar la batería

1. Para cargar la batería, abra la cubierta protectora del costado superior derecho y conecte el adaptador del cargador.

Asegúrese de alinear el conector como el

imagen. Si no, se daño la carga conector en el teléfono y no cobrar.

Correcto Incorrecto

2. Para desconectar el adaptador, presione los botones (1) laterales de éste y jálelo para retirarlo (2).

Encendido/apagado del teléfono

Para encender

1. Mantenga presionada la tecla E.

Para apagar

1. Mantenga presionada la tecla E.

Bloqueo del teclado

1. Presione Menú > presione * para bloquear.

Desbloqueo del teclado

1. Presione Desbloq. > * para desbloquear.

Indicaciones básicas de pantalla

Intensidad de la señal. A mayor número de barras, más potente es la señal. Cuando la red está en modo de búsqueda, aparece .

Hay una llamada en curso. Cuando esté en un área sin servicio, aparece .

Transferencia de llamadaN está activo. Las llamadas entrantes se ajustaron en sólo timbre

(Normal) Las llamadas entrantes se ajustaron en Vibración y timbrar Las llamadas entrantes se ajustaron en Sólo vibrar Las llamadas entrantes se ajustaron en Silencioso

El Modo de vuelo está activo. Se recibieron uno o más mensajes de texto. Se recibieron uno o más mensajes multimedia. Se recibieron uno o más mensajes WAP de envío

automático. Se recibieron uno o más mensajes de conguración. Se recibieron uno o más mensajes de voz. Se está enviando un mensaje. Se está recibiendo un mensaje. Se programó una alarma. Bluetooth está activo.

El auricular está conectado. USB conectado TTY está activo.

Señal GPRS disponible. Aparece cuando hay una sesión GPRS activa.

Señal EDGE disponible. Aparece cuando hay una sesión EDGE activa.

Señal 3G disponible. Aparece cuando hay una sesión 3G activa.

WAP conectado. Cuando la seguridad está congurada aparece . Cuando la descarga de contenido está en curso, aparece

Nivel de la batería. Si la carga de la batería es baja, aparece

Estado de AIM: Disponible, Ausente, Invisible

Estado de MSN: Conectado, Ausente, Ocupado, No conectado

Estado de YAHOO: Disponible, Ocupado, Invisible

Recibió uno o más mensajes IM.

Depende de la red

Tarjeta de memoria

Puede usar la tarjeta microSD como tarjeta de memoria. Esta tarjeta le entrega más espacio para guardar imágenes, videos, música, etc.

Inicio

Instalación y extracción de la tarjeta de memoria

1. Abra la ranura de la tarjeta de memoria.

2. Introduzca la tarjeta. En la pantalla verá el icono .

3. Presione la tarjeta para extraerla.

Uso de la tarjeta de memoria

Puede guardar, mover y eliminar archivos entre el teléfono y la tarjeta de memoria externa. También puede mover y copiar archivos desde el teléfono a la computadora.

Restablecimiento de la tarjeta

1. Presione Menú > Conguración > Restablecer.

2. Ingrese la contraseña > Restablecimiento de memoria

externa

nota:

la contraseña predeterminada es “1234”.

Para copiar el archivo a la tarjeta

1. Seleccione el archivo > Opciones > Copiar a memoria

externa.

2. Para copiar el archivo nuevamente al teléfono, presione

Opciones > Copiar a teléfono.

Para mover el archivo a la tarjeta

1. Seleccione el archivo > Opciones > Mover a memoria

externa.

2. Para mover el archivo nuevamente al teléfono, presione

Opciones > Mover a teléfono.

Para eliminar el archivo de la tarjeta

1. Seleccione el archivo de la tarjeta > Opciones > Eliminar.

Para mover el archivo de la tarjeta a la computadora

1. Conecte el cable de datos al teléfono móvil y a la computadora.

2. Presione Menú > Conguración > Conectividad.

3. Presione Seleccionar modo USB.

4. Seleccione Almacenamiento masivo o Preguntar al

conectar.

5. Siga las instrucciones de la pantalla de la computadora.

nota:

seleccione Reproductor de música cuando desee agregar música a la lista de reproducción en su dispositivo. Cuando seleccione Preguntar al conectar, se le pedirá que seleccione el Reproductor de música o el Almacenamiento

masivo cada vez que conecte el dispositivo a la computadora.

Pantech C740 AT-T, Matrix AT-T User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
