Pantech breEZe C520 User Manual

Thank you for choosing the Pantech Breeze C520, our latest mobile phone.

The Pantech Breeze C520 has many features designed to enhance your mobile experience. From its EZ to read menus, to its sleek, stylish design, we know you will enjoy the entire Breeze C520 experience.

This User Guide contains important and useful information that will maximize your familiarity with all that the Pantech Breeze C520 has to offer.

Breeze C520 User Manual

Speciﬁcations

Design

Clamshell phone with internal and external display

Displays

•

260k colors TFT LCD with 2.2” internal display

•

65k colors STN LCD with 1.04” external display

•

7 lines for text in basic mode with 16 point font

•

Two soft keys and four-way scroll and selection

keys

Melodies

MP3, AAC, AAC+, WMA, AMR-NB, MIDI, SP-MIDI

Camera

Integrated VGA (300k) CMOS Camera

• Resolution up to 640x480 (330,000 pixels)

•

Mpeg4 Video recording/playing up to 15f/s (QCIF size)

• Self-timer function (5 seconds or 10 seconds)

• Photo album and video album

Dimensions & Weight

• Weight: 96g (with standard battery)

• Dimensions: 99.3 mm x 50 mm x 19.6 mm

Power Management (Performance)

Battery Type Capacity Standby Time Talk Time

Standard

Lithium-Ion

(Li-ion)

Up to

920 mAh

Up to

250 hours

Up to

3 hours

Operating Frequency

• GSM 850Mhz, GSM 900Mhz, DCS 1800Mhz, and PCS 1900Mhz networks in North America, South America, Europe, Africa, and Asia-Paciﬁc where these networks are supported.

• Automatic band switching.

1 Address Book

2 Messaging 3 My Stuff 4 Tools 5 Settings 6 Phone Status

Phone overview

Earpiece

Internal display Navigation key

Scroll through the menu options

Left/Right Soft key

Perform the functions shown at the bottom line of the display

OK key

or access

MEdia Net

Press to enter menu system

Camera key Power on&off/Menu exit

key/End key

Turns phone on/off, ends calls, exits menus

Clear key and Calendar

Returns to previous screen or deletes characters in text mode. Access Calendar menu

One-touch

Quick Call

Speaker Mode

Send key

Voicemail

Vibrate mode

Microphone

Menu features (Breeze Mode)

Address Book Messaging My Stuff

Tools Settings Phone Status

note:

Holding device at internal antenna

area might affect call quality reception.

Camera

Speaker

Side key

External display

Internal antenna

Example: Accessing the

Phone Mode menu.

1. Press the Menu

2. Press the

for

Settings

3. Press the

for

Phone Mode

4. Press the

U/D

scroll key to select the mode.

Numbered menu items, such as menus, sub-menus, and options can be quickly accessed by using their shortcut numbers. In Menu mode, Main Menus can be accessed by pressing the number keys (1 to 0) corresponding to their location on the screen.

Address Book

Contact List ¦P28 New Contact ¦P28 Speed Dial ¦P27 My Phone Number

Messaging

Write New ¦P38 Inbox ¦P36 Sent ¦P38 Voice Mail ¦P42 Email ¦P43

IM ¦P43 Settings ¦P41

My Stuff

Photo Album ¦P51 Video Album ¦P52 Audio ¦P72 Graphics ¦P51 Games & Apps ¦P54

Using Shortcuts

Menu overview

Breeze mode menu

NOTE:

The steps vary by mode and that throughout the manual it will be notated by [EZ] for EZ Mode or [ADV] for Advanced Mode.

SIM dependent N Network dependent

Tools

Phone Status ¦P62 Camera ¦P46 Alarm ¦P58 Calendar ¦P58 Notepad ¦P60 Voice Memo ¦P60 Calculator ¦P59

Settings

Phone Mode ¦P18 Sounds & Alerts ¦P72 Ring Volume ¦P72 Wallpaper ¦P72 Backlight Timer

¦P73

Answer Type ¦P25

Phone Status

My Phone Number Signal Strength Battery Remaining Sound & Alerts Alarm New Messages

Email & IM

Mobile Email ¦P43 IM ¦P43

Messaging

Write New ¦P37 Inbox ¦P36 Sent ¦P38 Outbox Voice Mail ¦P42 Settings ¦P41 Memory Info ¦P53

Advanced mode menu

Recent Calls

Missed Calls ¦P26 Received Calls

¦P26 Dialed Calls ¦P26 Delete Call ¦P26 Logs

Call Time ¦P26 GPRS Info ¦P27

MEdia Net

MEdia Net ¦P68 Home

Bookmarks ¦P68 Go to URL ¦P68 Proﬁles ¦P68 Options Security ¦P68 Version

AT&T Mall

Shop Tones Shop Games Shop Graphics Shop Multimedia Shop Applications MEdia Net Home

Games & Apps

SIM dependent N Network dependent

My Stuff

Audio ¦P72 Graphics ¦P51 Photo Album ¦P51 Video Album ¦P52 Other Files ¦P53 Tools Memory Info ¦P53

Address Book

Contact List ¦P28 New Contact ¦P28 Speed Dial ¦P27 Groups ¦P29 My Business Card

¦P61 My Phone Number ¦P62 Memory Info ¦P36 Service Numbers

Settings

Phone Mode ¦P18 Sounds & Alerts

¦P72

Display ¦P72 Call Phone Flight Mode ¦P81 Connectivity ¦P66 Security

¦P30

Software Reset ¦P74 TTY ¦P75

Quick & easy

Keys Functions

< >

Perform the functions shown at the bottom line of the display by using these Soft keys. Scroll through the menu options in Menu mode. In standby mode,

Left Scroll: Access My Stuff menu Right Scroll: Access Alarm menu Up Scroll: Access Write New menu Down Scroll: Access Contact List menu

Select a menu function or store user-input information, such as names. Also use this key for conﬁrmation (as the [OK] key). Launch the MEdia Net directly if pressed in standby mode.

Delete characters from the display, or return to previous menu. Open Calendar view if pressed quickly in standby mode.

Make or receive a call. Show the recent call list in standby mode. Re-dial the last call number if pressed and held in standby mode.

Keys Functions

Complete the current call. Turn on/off the phone if pressed and held. Cancel user input and return to standby mode while in Menu mode.

Quickly connect to the voice mail server if pressed and held in standby mode.

0~9

Enters numbers, letters or special characters. Go to the dial screen if pressed in standby mode.

Enter or exit from vibrate mode if pressed and held in standby mode. Show the symbol input screen if pressed and held in text input mode. Work in Word search mode if pressed in the Predictive text input mode.

Enter the + sign preﬁx for international dialing if pressed and held. Enter the space character in text input mode.

Change various text input modes if pressed and held at the text-editing screen. Adjust the earpiece volume while making a call.

Control the Ringtone volume, vibrate mode and silent all mode in standby. Mute the ringtone of an incoming call. Reject the incoming call if pressed and held when you receive an incoming call.

Turn camera capture mode on. Work as a camera shutter in capture mode.

Turn the speaker mode on.

Contents

Speciﬁcations.............................2

Phone overview ..........................

Using Shortcuts .........................

Menu overview ...........................

Quick & easy ...............................

1. Getting starte

Package contents .................14

SIM card and battery ............15

Turn on/off the phone ...........16

Keypad lock ..........................16

Essential display indications

..17

Setting theme .......................18

EZ quick call keys .................19

Updating software ................19

2. Calls & address book

Making, receiving and

ending a call .........................22

Options during a call .............23

Call setting ............................25

Checking all calls ..................26

Speed dialing ........................27

Using address book ..............28

Caller identiﬁcation...............29

Using your headset ..............29

Service number and

ﬁxed dialing...........................

3. Messagin

Entering text .........................34

Messaging ............................35

Receiving messages ............36

Creating and sending

text message ........................

Creating a multimedia

message ...............................

Message template ................41

Message settings ................41

Setting voice message .........42

Email .....................................43

Using instant messenger ......43

4. Multimedi

Camera .................................46

Photo album .........................51

Video album ..........................52

Other ﬁles .............................53

Managing the memory .........53

Playing games .....................54

5. Useful feature

Calendar ...............................58

Alarm ....................................58

Calculator, converter and

stopwatch .............................

Notepad and voice memo ....60

Business card .......................61

Phone status .........................62

6. Connectivity

Bluetooth ..............................66

Using the browser ................68

Proﬁles setting......................69

7. Setting

Language ..............................72

Time and date .......................72

Ringtones ............................72

Decorating the display ..........72

Locks ....................................73

To enable ﬁxed dialing ........74

Reset ....................................74

TTY .......................................75

8. Appendi

Alert message .......................78

Troubleshooting checklist .....79

Safety information ................80

Safety precautions ................80

About the battery usage .......82

Hearing aid compatibility

with mobile phones ..............83

FCC regulatory compliance

....84

Warranty ...............................86

Contents

Breeze

C520

Package contents

SIM card and battery

Turn on/off the phone

Keypad lock

Essential display indications

Setting theme

EZ quick call keys

Updating software

Getting started

Calls & address book

Messaging

Multimedia

Useful features

Connectivity

Settings

Appendix

Package contents

Phone Battery Travel charger User Manual

Getting Started

SIM card and battery

About your SIM card

When you subscribe to your network operator, you receive a SIM (Subscriber Identity Module) card containing your registration information, PIN code, etc.

Like a credit card, it should be kept secure and handled carefully. Do not bend, scratch or expose it to moisture. Avoid static electricity. To avoid corrupting your SIM card’s memory, always switch your phone off before removing or inserting your SIM card.

About your battery

Your phone uses a Li-Ion battery. Make sure to use an authorized battery and charger only. For more details, please inquire at your nearest dealer.

note

: Your phone is powered by a Lithium

Ion (Li-Ion) battery. This means that, unlike

other forms of battery technology, you can recharge your battery while some charge remains without reducing your phone’s autonomy due to the “battery memory effect” inherent in those technologies.

Installing/removing SIM card and battery

1. Remove the battery cover from the unit. To ﬁt the battery cover, put it on the guide rail and push up.

2. Insert the SIM card into the slot. The gold contacts of the SIM card should go against the metal contacts of the phone. Put the contacts of the battery into the hole located at

the upper side of the unit, then insert and press the bottom side of the battery until you hear the “click”.

3. To remove the battery push the bottom of the battery to upwards (1) and remove (2) the battery. Push the SIM card in the arrow direction as shown.

To charge your battery

1. To charge, open the protective cover on the top left side and connect the charger adapter. The arrow on the charger have to face the top of the phone.

2. To remove the adapter connection press the adapter’s side buttons (1) and pulling the adapter away (2).

Turn on/off the phone

To turn on

1. Press and hold

To turn off

1. Press and hold

Keypad lock

Locking the keypad

1. Press Menu >

to lock.

Unlocking the keypad

1. Press Unlock >

within 3 seconds to

unlock.

Getting Started

Essential display indications

Signal strength. The greater the number of bars, the stronger the signal. When network is in searching mode is displayed.

Flight mode is active. A call is being made. When you are in no

service area

is displayed

Call forwarding

is active

FAX mode

is active

Data

folder

Incoming calls set to ring only (Normal

) Incoming calls set to Vibrate then Ring Incoming calls set to Vibrate Only Incoming calls set to Silent Received one or more text messages Received one or more multimedia messages Received one or more WAP push messages

Received one or more FAX messages Received one or more other messages Received one or more voice messages A message is being sent A message is being received An alarm is set Bluetooth is active Headset is connected TTY is active An EDGE signal is available. It is displayed

when there is an active EDGE session A GPRS signal where only 2G is available. It is

displayed when there is an active GPRS session. WAP is connected. When the security is set

is displayed. Battery strength. When the battery charge is

low,

is displayed

N Network dependent

< Breeze Mode> <Advanced Mode>

To change the theme

1. Press Menu > Settings > Phone Mode.

2. Select Breeze Mode or Advanced Mode

Assigning the menu

In Breeze Mode, you can set the most commonly used menu in Options in standby mode.

1. Press Options in standby mode > select

Unassigned

2. Press Options

> Edit.

3. Select the menu and sub menu.

Available, Away, Invisible Status of AIM

Online, Away, Busy, Ofﬂine Status of MSN

Available, Busy, Invisible Status of YAHOO

You have received one or more IM messages

Setting theme

Your phone has two customized themes, Breeze and Advanced. The default is set to Breeze mode which provides EZ access to the functions used most frequently. In the Breeze mode, you view an abbreviated menu: Address Book, Messaging

My Stuff, Tools, Settings and Phone Status

. The Advanced mode allows access to all menu items.

Getting Started

EZ quick call keys

Getting in touch with those you call most is now as EZ as 1-2-3.

note:

The following direction is an example with

using

key. The usage of y and z key will

be same as the following.

To assign a contact

1. Press x.

2. Press Option

> Assign Contact.

3. Select a contact > Options >

To use call using one touch key

1. Press and hold x to call.

To send a message using one touch key

1. Press x.

2. Press Option

> Send Message.

Updating software

You can update your software without visiting your nearest dealer.

To update the software

ADV

1. Press Menu > Settings > Software >

Software Update

2. Press Phone Information to check software version of your phone.

3. After checking your software version, press

4. Press Check for Update

> Yes.

To view the version of software

ADV

1. Press Menu > Settings > Software >

Software Version

Breeze C520

Getting started

Calls & address book

Messaging

Multimedia

Useful features

Connectivity

Settings

Appendix

Calls & address book

Making, receiving and ending a call

Options during a call

Call setting

Checking all calls

Speed dialing

Using address book

Caller identiﬁcation

Using your headset

Service number and ﬁxed dialing

Making, receiving and ending a call

Making a call

1. Enter the area code and phone number.

2. Press

Answering a call

1. Press

Ending a call

1. Press

. Once the call is completed, a call summary is displayed.

Rejecting a call

1. Press

or Ignore.

Making a call using call list

Your phone logs up to 30 dialed, received and missed call numbers.

1. Press

to display the Recent Calls list.

2. Select All Calls, Missed Calls, Received

Calls, or Dialed Calls by pressing the

L/R

key.

3. Select a number.

4. Press

to dial the selected number.

note:

To redial the last number in the Recent Calls

list, press

Making a call during a call

1. Enter the phone number or press Options >

Contact Search

2. Press

to dial the second call. The ﬁrst call

is automatically put on hold.

Calls & address book

Switching between two calls

1. Press Swap.

Making an international call

1. Press and hold

key for the international

preﬁx until the ‘+’ character appears.

2. Type the country code, area code, and phone number.

3. Press

Making an emergency call

You can make emergency calls even if your phone does not have a SIM card.

1. Press Emergency Number, or press SOS if your phone does not have a SIM card.

2. Press

Replying to a missed call

1. Press View to display the list of missed calls.

2. Select a number to call by pressing the

U/D

key.

3. Press

Answering a second call

1. Press

. The ﬁrst call is automatically put

on hold.

2. Press

to end the second call.

The call on hold is automatically reconnected.

Options during a call

Microphone off and on

Switching your phone’s microphone off

1. Press Mute [ ].

Switching your phone’s microphone back on

1. Press Unmute.

Talking on speaker

1. Press the

key above the send key.

Putting a call on hold and return

Putting a call on hold

1. Press Options > Hold or press

Returning to a held call

1. Press Retrieve or press

again.

Multi-party calls

You can talk with more than one person or conference call.

Making a multi-party call

1. Call the ﬁrst participant.

2. Call the second participant. The ﬁrst call is automatically put on hold.

3. Press Options

> Join.

Adding a caller to a multi-party call

1. Press Options > Join All.

Having a private conversation with one participant

1. Press Options > Split.

2. Press

3. Select the participant and press

. All of the multi-party call participants can now hear each other.

Removing one participant from a multiparty call

1. Press Options > End Call.

2. Select the participant and press

. The call ends with that participant, but you can continue to talk with other participants.

Calls & address book

Searching a number in address book during a call

1. Press D or press Options > Contact Search.

2. Select a number >

Searching for a name or group in address book

Enter the ﬁrst letters of the name for Name Search. The entries are displayed starting with the ﬁrst entry matching your input.

Finding a name manually in address book

1. Press the

U/D

key.

Viewing the details of highlighted entry in address book

1. Press @.

For details on address book, see page 28

Reading a message during a call

1. Press Options > Messaging.

2. Press Inbox > select a message.

Writing a message during a call

1. Press Options > Messaging.

2. Press Write New

For details on creating a text message, see page 37

note

: During the call, you can only send text messages. Multimedia messages cannot be sent, but can be saved.

Call setting

Answering with any key press

1. [EZ] Press Menu > Settings > Answer Type. [ADV] Press Menu

> Settings > Call > Answer

Type

2. Select Any Key.

note:

You can answer with any key except

and Reject

Setting auto redial

ADV

1. Press Menu > Settings > Call > Auto Redial.

2. Select On or Off

Checking all calls

You can view information about all Recent Calls. For more options for all, missed, received and dialed calls press Options. In Beeze mode press

to view all Recent Calls.

Viewing missed calls

ADV

1. Press Menu > Recent Calls > Missed Calls.

Viewing received calls

ADV

1. Press Menu > Recent Calls > Received

Calls

Viewing dialed calls

ADV

1. Press Menu > Recent Calls > Dialed Calls.

Deleting call logs

ADV

1. Press Menu > Recent Calls > Delete Call

Logs

2. Select All Calls > Yes

note:

If no logs exist, the message “List Empty”

appears.

Viewing call time

ADV

1. Press Menu > Recent Calls > Call Time.

2. Press

U/D

to view Last Call, Received

Calls, Dialed Calls, and Total Calls

Resetting all call times

ADV

1. Press Menu > Recent Calls > Call Time.

2. Press Reset Call Times

2. Enter password >

Calls & address book

note:

The default password is ‘1234’.

Viewing data transmitted information

ADV

1. Press Menu > Recent Calls > GPRS Info.

• Current Info: You can view transmitted data in

the current session, in Kbytes.

• Last Info: You can view Sent, Received,

and Total transmitted in previous sessions, in Kbytes.

• Total Info: You can view all Sent, Received,

and Total transmitted data in Kbytes.

• Clear Logs: The default password is ‘0000’.

Speed dialing

You can dial quickly using speed dialing. Up to 8 phone numbers can be progrmmed using numbers 2 to 9.

: Voice mail

: Preﬁx for international call

Setting speed dial

1. Press Menu > Address Book > Speed Dial.

2. Select an empty entry and press Add

3. Select a person and press

or Option >

Select

Changing speed dialing person

1. Press Menu > Address Book > Speed Dial.

2. Select a number and press

or Options >

Edit

3. Select a person and press

or Option >

Select

Removing from speed dial

1. Press Menu > Address Book > Speed Dial.

2. Select a number and press Options

Remove

Setting speed dial from address book

1. Press Menu > Address Book > Contact List.

2. Select a person > Options

> Add to Speed

Dial

3. Select an entry and press

or Select.

Using address book

You can save names, phone numbers, and information on the SIM or phone. Entries can depend on the capacity of the SIM card.

Adding a contact

1. Press Menu > Address Book > New Contact.

2. Select SIM Card or Phone

3. Input the ﬁelds.

4. Press

or Options > Save.

Viewing contact list

1. Press D or press Menu > Address Book >

Contact List

note:

In Advanced Mode youou can set speed dial

when you are viewing contact list. Press Options

Add to Speed Dial

Searching for a phone number

1. Press Menu > Address Book > Contact List.

2. Input the ﬁrst letter or two of the person’s name and scroll with

U/D

3. Press

to view detail information.

4. To update information press Options

> Edit.

Calling from contact list

1. Press D or press Menu > Address Book >

Contact List

2. Select a person to call.

3. Press

Calls & address book

Forwarding contact details

1. Press Menu > Address Book > Contact List.

2. Select a contact > Options

> Forward

Contact Info

3. You can send the information Send as

Multimedia Message or Send via Bluetooth

Deleting a contact

1. Press Menu > Address Book > Contact List.

2. Select a contact > Options

> Delete.

Making a groups

ADV

1. Press Menu > Address Book > Groups.

2. There will be defaulted groups.

3. To add new group press Options

> New.

4. To edit group press Rename

5. To set a speciﬁc ring tone, press Options

Group Ring tones

Caller identiﬁcation

Caller identiﬁcationN

ADV

1. Press Menu > Settings > Call > Caller ID.

2. Select Send My No. or Hide my No.

> Select.

Using your headset

You can send or receive a call using your headset. When you connect your headset to the jack the button on the headset works as follows.

note:

You need to use the headset designed for this device and it is optional item. Also not every headset has a button.

While in standby mode

1. Press the button once to list recent calls.

2. Press the button twice to redial the last call.

While the phone is closed

1. Press the button once to receive a call.

2. Press the button once to end the call.

Service number and ﬁxed dialing

Calling your service numbersS

ADV

You can see the service number to reach the service provider.

1. Press Menu

> Address Book > Service

Numbers

2. Select a number > press

Viewing ﬁxed dialing list

ADV

Fixed dialing is a service that limits your access to speciﬁc numbers in the address book list recorded on the SIM. Input the PIN2 to set up or cancel this

service.

1. Press Menu

> Settings > Security.

2. Press Fixed Dialing

> Fixed Dial List.

note:

PIN2 must be correctly entered within 3 attempts. If you input incorrect code three times in a row the PIN2 code will be blocked. If the PIN2 code is blocked please contact your service provider. PIN2 code is supplied with SIM card.

Calls & address book

Breeze C520

Getting started

Calls & address book

Messaging

Multimedia

Useful features

Connectivity

Settings

Appendix

Messaging

Entering text

Messaging

Receiving message

Creating and sending text message

Creating a multimedia message

Message template

Message settings

Setting voice message

Using instant messenger

Entering text

You can enter text with multi-tap, predictive, numeric or symbol.

Useful keys

Display and undisplay symbols

Adding space

Press to change capital mode. Quick press to change dbc and long press to change from multi to predictive to Number to Symbol Multi-tap

dbc (all small caps / ﬁrst letter caps / all caps) Predictive

gef (all small caps / ﬁrst letter caps / all caps) Number

Symbols

Key characters by language

Each of the following keys will scroll through these sequential options listed by language.

Key English Spanish French

. , - ? ! ' @ : 1

a b c 2 á ã ç ç à â á ä

d e f 3 é é è ê ë

g h i 4 í î ï í

j k l 5 ó ñ ô ó ö ñ

m n o 6 ß

p q r s 7 ú ü ù û ú ü

t u v 8

w x y z 9

Space + = < > € £ $ ¥ % & 0

Messaging

Predictive mode (T9)

The predictive mode automatically compares your keystrokes with an internal linguistic dictionary to determine the correct word. The most commonly used word will appear ﬁrst. To save a word not listed in phone’s dictionary press Options > My

word

1. Press and hold

to change the mode as

T9.

2. Press

to input text. For example,

to write ‘hello’ press

43556

Alphabet input mode

Press the key labeled with the target letter once for the ﬁrst letter; press it twice for the second letter, and so on.

1. Press and hold

to change the mode as

multi-tap.

2. Press

to input text repeatedly.

To write the letter “C”, press

3 times. To

write number 2 press

4 times.

Numeric mode

You can input numbers in this mode.

1. Press and hold

to change the mode 123.

2. Press

and

to input

numbers.

Symbol mode

You can input symbols.

1. Press and hold

to change the mode as

symbols.

2. Press

input symbol. For more

symbols press

U/D

Messaging

You can send, receive and save text and multimedia messages.

Managing memory

When the message box is full the messages full icon will appear.

When It means

Text message is full Multimedia message is full

Moving a message to SIM

ADV

1. Press Menu > Messaging > Inbox.

2. Select a message > Options

> Move To SIM.

Moving a message to phone

ADV

1. Press Menu > Messaging > Inbox.

2. Select a message > Options

> Move To

Phone

Deleting a message in a mailbox

1. Press Menu > Messaging > Inbox.

2. Select a message > Options

> Delete > Yes.

Replying to a message

1. Press Menu > Messaging > Inbox.

2. Select a message > Reply

Viewing memory space information

ADV

1. Press Menu > Messaging > Memory Info.

2. Press

L/R

to view SIM and Phone memory.

Receiving messages

Viewing a new message

1. Press View or press @.

Reading a message from the inbox

1. Press Menu > Messaging > Inbox.

2. Select a received message >

Messaging

3. To reply press Reply.

Saving number or e-mail from received message

1. Press Menu > Messaging > Inbox.

2. Select a received message >

3. Press Options

> Save Number & Email.

4. Press Options

> Save.

5. Select New Contact or select Update

Existing

Saving URL address from received message

1. Press Menu > Messaging > Inbox.

2. Select a received message >

3. Press Options

> Save URL.

4. Press Options

> Save.

Saving the object in the received multimedia message

1. Open the multimedia message.

2. Press Options

> Save Objects.

3. Select an object > Save

4. Edit the ﬁlename > Options

> Save.

It will be saved in one of the categories in the

My Stuff folder

For details on photo album, see page 51.

Listening to voice messages

1. Press and hold

or press Menu >

Messaging > Voice Mail

It will automatically call to the voice mail center.

Creating and sending text messages

Sending new text message

1. Press U or press Menu > Messaging > Write

New

2. Press Text Message.

3. Write the message.

4. Press

5. Enter the phone number to send or press

Options > Contact List > ﬁnd a person to

send.

6. To send more then one person press

select. To unselect press

7. To view sent message press Menu

Messaging

> Sent.

note

: You can send up to 10 person at a time.

note

: All successfully sent messages will save in

Sent

Finding all sent messages

1. Press Menu > Messaging > Sent.

Creating a multimedia message

You can create new multimedia message. Capacity is 300kb and will alert you once that is exceeded via error message.

Adding saved picture to the message

1. Press Menu > Messaging > Write New.

2. Select Multimedia Message

3. Write a message.

4. Press Options

> Add Object > Add Image.

5. Select Photo Album > select a picture >

Options Select

6. To preview press Options

> Preview.

7. To edit the text message, press

U/D

to select

the text box, press Options

> Edit Text.

8. Press

Messaging

Adding new picture to the message

1. Press Menu > Messaging > Write New.

2. Select Multimedia Message

3. Write a message.

4. Press Options

> Add Object > Add Image.

5. Select Take a Photo > focus on the object >

6. Press Insert

7. Press Options

> Send to.

For details on taking a pictures, see page 48

Adding recorded voice memo to the message

1. Press Menu > Messaging > Write New.

2. Select multimedia message.

3. Write a message.

4. Press Options

> Add Object > Add Sound.

5. Select Voice Memo > select a voice memo >

6. To listen select the recorded memo > Play

7. To stop press

8. To select other recorded memo press Back and select other memo.

9. Press Options

> Send to.

Adding new voice memo to the message

1. Press Menu > Messaging > Write New.

2. Select multimedia message.

3. Write a message.

4. Press Options

> Add Object > Add Sound.

5. Select New Voice Memo > record the sound.

6. To save press

7. Press Options

> Send to.

For details on recording voice memo, see page 60

Adding saved video to the message

1. Press Menu > Messaging > Write New.

2. Select multimedia message.

3. Write a message.

4. Press Options

> Add Object > Add Image.

5. To play press Options

> Play.

6. Select Video Album > select a video >

Options

> Select.

7. To preview with the text press Options

Preview

8. To stop press Pause

9. To go back to the message editor press Back

10. Press Options

> Send to.

Adding new video to the message

1. Press Menu > Messaging > Write New.

2. Select multimedia message.

3. Write a message.

4. Press Options

> Add Object > Add Image.

5. Select Take a Video > focus on the object >

6. To stop recording press

7. To preview with the text press Options

Preview

8. To stop press Pause

9. To go back to the message editor press Back

10. Press Options

> Send to.

For details on recording video, see page 49

Adding other ﬁle to the message

1. Press Menu > Messaging > Write New.

2. Select

Multimedia Message.

3. Write a message.

4. Press Options

> Add Object.

5. Select Add Other ﬁles

6. Select the ﬁle > Options

> Select.

7. Press Options

> Send.

Messaging

Message template

When you often use the same phrases, you can save the message under template messages.

Adding to the existing template

ADV

1. Press Menu > Messaging > Write New.

2. Select Multimedia Message

3. Write a message.

4. Press Options

> Add Template.

5. Select the template.

Message settings

Setting default editing mode

1. Press Menu > Messaging > Settings.

2. [EZ] Press Default Edit Mode

[ADV] Press Common Settings

> Default Edit

Mode

3. Select Alphabet or Predictive

Setting sent message

1. Press Menu > Messaging > Settings.

2. [EZ] Press Save Messages

[ADV] Press Common Settings

> Save

Messages

3. Select On or Off

It will save all out going messages.

Setting deleting read message

1. Press Menu > Messaging > Settings.

2. [EZ] Press Auto Delete Read Message

[ADV] Press Common Settings

> Auto

Delete Read Message.

3. Select On or Off

Setting message center

ADV

1. Press Menu > Messaging > Settings.

2. Press Text Massage > Message Center

3. Enter new Message Center.

4. Press Select.

Setting e-mail gateway

ADV

5. Press Menu > Messaging > Settings.

6. Press Text Massage

> E-mail Gateway.

7. Enter new gateway for receiving e-mail.

8. Press Select

Setting default save place

ADV

1. Press Menu > Messaging > Settings.

2. Press Text Massage

> Save to.

3. Select SIM or Phone

Setting proﬁles for multimedia message

ADV

1. Press Menu > Messaging > Settings.

2. Select Multimedia Massage > WAP Proﬁles

3. Select a proﬁle.

Setting receiving method for push message

ADV

1. Press Menu > Messaging > Settings.

2. Press Push Message

> Receive.

3. Select the method.

note

: When you receive push message the [ ]

icon will displays.

Setting voice message

Setting receiving voice message

ADV

1. Press Menu > Messaging > Settings.

2. Press Voice Mail

3. Enter the number of the voice mail center >

note:

This number may be pre-conﬁgured by the

service provider upon activation.

Messaging

You can receive email from your service provider.

Receiving an email

1. [EZ] Press Options > Mobile Email or Menu >

Messaging > Mobile Email

[ADV] Press Menu

> Email & IM > Mobile

2. Select an email >

Using instant messenger

Use Instant Messenger (IM) to send and receive short, simple messages that are delivered immediately.

Starting an instant messenger

1. [EZ] Press Options > IM or Menu >

Messaging > IM

[ADV] Press Menu

> Email & IM > IM.

2. Select the IM application > Select

3. Enter logon and password > Sign On

Viewing the conversation log

You can view the log of your conversations in the Instant Messenger Saved History.

Breeze C520

Getting started

Calls & address book

Messaging

Multimedia

Useful features

Connectivity

Settings

Appendix

Multimedia

Camera Photo album Video album

Other ﬁles

Managing the memory

Playing games

Camera

You can take pictures and record movies using the built-in camera. The photos and video clips can be saved and sent via multimedia message.

[ADV] Press

in standby mode or press

Menu > My Stuff > Tools

Press Menu

> My Stuff > Tools.

2. Press Camera

> Take a Photo.

3. Press Options to change settings prior to taking a picture.

In options menu for camera

Icons Name Description

Take a Picture

ADV

View Photos

ADV

Take a Video

ADV

Image Size

ADV

176x220 ( ), 320x240 ( ), 640x480 ( )

Image Quality

ADV

Low ( ), Medium ( ), High ( )

Effects

Nomal, Sepia, Monochrome, Nagative, Embossing

Size

Quality

Recording Type

Recording

White

balance

Zoom

Brightness

Remain

Self Timer

Multi-shot

Duration

Setting camera settings

1. [EZ] Press

in standby mode or press

Menu > Tools

Brightness

Multimedia

White Balance

Auto ( ), Sunlight ( ), Cloudy ( ), Fluorescent ( ), Incandescent ( )

Multi-shot

Off, 4EA ( ), 6EA ( ),

9EA ( ) Self Timer Off, 5Sec ( ), 10Sec ( ) Display Icons On, Off

Shutter Sound On, Off

Icons for camera

Icon Name Description

Remain Picture

Zoom

x1, x2, x3, x4

Brightness

-3, -2, -1 0 +1, +2, +3

note:

Zoom tool is disabled when the picture size

set for 640x480.

In options menu for video camera

Icons Name Description

Take a Video

View Videos

Take a Photo

Video Size

128x96

( )

, 176x144

( )

Image Quality

Low

( )

, High

( )

Record Type

Unlimitied

( )

, For Msg

( )

Effects

Nomal, Sepia, Monochrome, Nagative, Embossing

Display Icons

On, Off

Icons for video camera

Icon Name Description

Brightness

-3, -2, -1 0 +1, +2, +3

Zoom in and out

1. Press

U/D

Increasing or decreasing the brightness

1. Press

L/R

Taking a picture

1. [EZ] Press

in standby mode or press

Menu > Tools

[ADV] Press

in standby mode or press

Menu > My Stuff > Tools

2. Press Camera > Take a Photo

3. Focus on the object >

or press Options >

Take a Picture

note:

Your photo will be saved automatically to

My Stuff > Photo Album

Changing to video camera mode

1. [EZ] Press

in standby mode or press

Menu > Tools > Camera > Take a Photo

[ADV] Press

in standby mode or press

Menu > My Stuff > Tools > Camera > Take a Photo

2. Press Options while camera mode is activated.

3. Press Take a Video

4. Focus on the object >

or press Options >

Take a Video

5. Press

to stop.

Multimedia

6. Press @ to save.

Viewing the taken picture

Press

in standby mode or press Menu > My

Stuff > Tools > Camera > Take a Photo

2. Press Options

> View Photos.

3. Select the picture >

After taking pictures

To Press

Send a multimedia

message

Options

> Send as Multimedia

message

View taken


ADV

Options > View Photos

Delete Options

> Delete

Send using

Bluetooth

ADV

Options > Send via Bluetooth

Upload photos on the web

ADV

Options > Send to HP’s Snapﬁsh

Set as wallpaper Options > Set as > Wallpaper

Set as address book

Options

> Set as > Address

Book

Go back to

preview

ADV

Options > Back to Preview

Rename

ADV

Options > Rename

Recording a video

1. [EZ] Press

in standby mode or press

Menu > Tools > Camera > Take a Video

[ADV] Press

in standby mode or press

Menu > My Stuff > Tools > Camera > Take a Video

2. Focus on the object >

or press Options >

Take a Video

3. Press

to stop.

4. Press Play to play the video clip.

5. Press Back to go back to preview mode.

6. Press @ to save.

Changing to camera mode

1. [EZ] Press

in standby mode or press

Menu > Tools > Camera > Take a Video

[ADV] Press

in standby mode or press

Menu > My Stuff > Tools > Camera > Take a Video

2. Press Options while video camera mode is activated.

3. Press Take a Photo

For details on taking a picture, see page 48

Viewing the recorded video clip

1. [EZ] Press

in standby mode or press

Menu > Tools > Camera > Take a Video

[ADV] Press

in standby mode or press

Menu > My Stuff > Camera > Take a Video

2. Press Options

> View Videos.

3. Select the video clip >

After recording video clips

To Press

Send a multimedia

message

Options

> Send as Multimedia

message

View recorded

video clip

ADV

Options > View Videos

Delete Options

> Delete

Send using

Bluetooth

ADV

Options > Send via Bluetooth

Go back

to preview

ADV

Options > Back to Preview

Rename

ADV

Options > Rename

Multimedia

During recording a video

To Press

Receive an incoming call

Stop recording

Save the clip

Photo album

You can view, send, save to your phone or an external memory card and also delete photos. JPEG format is supported, and other formats are saved in the Graphics folder.

note:

To access Graphics, press Menu > My Stuff

> Graphics

Viewing the saved pictures

1. Press

in standby mode or press Menu >

My Stuff > Photo Album

2. Select a picture >

Setting as wallpaper in the display

1. Press

in standby mode or press Menu >

My Stuff > Photo Album

2. Select a picture > Options

> Set as >

Wallpaper

Uploading pictures on the web

ADV

1. Press

in standby mode or press Menu >

My Stuff > Photo Album

2. Select a picture > Options

> Send to HP’s

Snapﬁsh

Deleting multiple pictures

1. Press

in standby mode or press Menu >

My Stuff > Photo Album

2. Press Options

> Multi-Select.

3. Press

to select more than one picture.

4. Press Back to unselect.

5. Press Delete.

Sending pictures using multimedia message

1. Press

in standby mode or press Menu >

My Stuff > Photo Album

2. Select a picture.

3. Press Options

> Send as Multimedia

Message

For details on creating a multimedia message, see page 38

Viewing ﬁle information

ADV

1. Press

in standby mode or press Menu >

My Stuff > Photo Album

2. Select a picture.

3. Press Options

> File Info.

Video album

You can view, send, save to your phone and also delete videos.

Playing the saved video clips

1. Press

in standby mode or press Menu >

My Stuff

> Video Album.

2. Select a video clip >

or press Options >

Play

Using video controls

To Press

Pause

Stop Stop

Rewind

Hold

Fast forward

Hold

Multimedia

Mute Mute

Control volume Side key up or down

Deleting multiple video clips

1. Press

in standby mode or press Menu >

My Stuff

> Video Album.

2. Press Options

> Multi-Select.

3. Press

to select more than one video.

4. Press Back to unselect.

5. Press Delete

Sending video clip using multimedia message

1. Press

in standby mode or press Menu >

My Stuff

> Video Album.

2. Select a video.

3. Press Options

> Send as Multimedia

Message

For details on creating a multimedia message, see page 38

Other ﬁles

ADV

You can manage ﬁles in unsupported formats saved on your phone. It also lists ﬁles received via Bluetooth from other devices.

Viewing the list of the ﬁles

1. Press Menu > My Stuff > Other Files.

Managing the memory

Viewing memory status

ADV

1. Press Menu > My Stuff > Memory Info.

2. Use

U/D

to view the information.

Playing games

You can download games to play with. It is easy to download and you can preview them beforehand. You will only be able to view games that are available on your mobile.

Previewing games

1. [EZ] Press Menu > My Stuff > Games &

Apps

[ADV] Press Menu

> Games & Apps.

2. Select a game >

3. Play the demo and press BUY to download the complete game.

Multimedia

Breeze C520

Getting started

Calls & address book

Messaging

Multimedia

Useful features

Connectivity

Settings

Appendix

Useful features

Calendar

Alarm

Calculator, converter and stopwatch

Notepad and voice memo

Business card

Phone status

Calendar

Calendar helps you manage your schedule including your time for calls or special days. You can set a reminder on any given date with this function.

Viewing calendar

1. [EZ] Press

in standby

mode or press Menu

> Tools

> Calendar.

[ADV] Press

in standby

mode or press Menu

> My

Stuff

> Tools > Calendar.

note

: Monthly view is displayed as default.

In the monthly view

To Press

Move to another day

for Previous

for Next

Move to another week

for Previous

for Next

View other month Side key up for Previous

Side key down for Next

Creating a new event and edit

1. Select a day > Options > New Event.

2. Input the events > Save

note

: You can create up to 50 scheduled events.

note

: You can create events for dates from

01/01/2000 to 12/31/2049.

Alarm

Setting an alarm

1. [EZ] Press R to access alarm or press Menu > Tools > Alarm

[ADV] Press Menu

> My Stuff > Tools >

Alarm

Useful features

2. Press Options > New > edit a new alarm >

Save

note

: The alarm will not ring if you set the phone to Vibrate Only or Silent. To make it ring on vibrate mode, press Options > Wake-Up Call On

The alarm will not go off if the phone is turned off.

note

: Only the ﬁrst alarm will be Simple Alarm . It will only ring once as default alarm tone.

Viewing the saved alarms

1. [EZ] Press R to access alarm or press Menu > Tools > Alarm

[ADV] Menu

> My Stuff > Tools > Alarm.

Editing existing alarms

1. [EZ] Press R to access alarm or press Menu > Tools > Alarm

[ADV] Menu

> My Stuff > Tools > Alarm.

2. Select an alarm > Options

> Select.

3. Edit the alarm settings.

4. To delete an alarm > Options

> Delete.

note

: You cannot delete Simple Alarm.

Calculator, converter and stopwatch

Using the calculator

1. [EZ] Press Menu > Tools >

Calculator

[ADV] Press Menu

> My Stuff

> Tools > Calculator.

2. Use [

L/R/U/D/@

] to

calculate.

3. Press

to clear.

4. Press [

. ] to use the decimal point.

Using the converter

ADV

1. Press Menu > My Stuff >Tools > Converter.

2. Select the categories

3. Select current unit and enter ﬁgure.

4. Select the unit to be changed.

Using stopwatch

ADV

1. Press Menu > My Stuff >

Tools

> Stopwatch.

2. Press

to start.

3. Press

to restart.

4. To record lap time, press Lap

5. Press Reset to clear.

Notepad and voice memo

Using notepad

1. [EZ] Press Menu >Tools > Notepad. [ADV] Press Menu

> My Stuff >Tools >

Notepad

2. Press Options

> Create New.

(Press New to create memo for the ﬁrst time.)

3. To edit memo press Options

> Edit.

4. Press Options

> Save to save.

Recording voice memo

1. [EZ] Press Menu > Tools >

Voice Memo

[ADV] Press Menu

> My Stuff

> Tools > Voice Memo.

2. Press Options

> Create New. (Press New to create memo for the ﬁrst time.)

Useful features

3. Press @ to stop recording.

4. Press Re-rec to re-record. Press Pause to pause recording.

5. Press Play to listen.

6. Press

[ ] to save.

Listening the recorded sound

1. [EZ] Press Menu > Tools > Voice Memo.

[ADV] Press Menu

> My Stuff > Tools >

Voice Memo

2. Select a sound > Options

> Select.

Using sound controls

To Press

Pause

Stop

Rewind

Fast forward

Control volume Side key up or down

Business card

ADV

You can send your information by sending it as multimedia message.

Creating your own business card

1. Press Menu > Address Book > My Business

Card

2. Edit the ﬁelds > Options

> Save or press @.

Forwarding

1. Press Menu > Address Book > My Business

Card

2. Press Options

> Send via Bluetooth or Send

via Multimedia Message

3. Write a message.

4. Press Options

> Send.

Updating information

1. Press Menu > Address Book > My Business

Card

2. Press Options

> Edit.

3. Update information.

4. Press Options

> Save.

Phone status

You can view status of your phone for My Phone

Number

, Signal Strength, Battery Remaining,

Sounds & Alerts

, Alarm, and New Messages.

Viewing the status

1. [EZ] Press Menu > Phone Status.

[ADV] Press Menu

> My Stuff > Tools >

Phone Status

Useful features

Breeze C520

Getting started

Calls & address book

Messaging

Multimedia

Useful features

Connectivity

Settings

Appendix

Connectivity

Bluetooth

Using the browser

Proﬁles setting

Bluetooth

Bluetooth technology enables free wireless connections between electronic devices within a maximum range of 33 feet (10 meters). Bluetooth connection can be used to send images, text, business cards, calendar notes, or to connect to computers using Bluetooth technology.

Your mobile phone supports:

• Connect to PC to access internet.

• Connect to Hands-Free.

• Connect to electronic devices.

Activating

1. [EZ] Press Options in standby mode >

Bluetooth > Bluetooth

[ADV] Press Menu

> Settings > Connectivity

> Bluetooth > Bluetooth.

2. Select On or Off

Adding a device

1. [EZ] Press Options in standby mode >

Bluetooth > Paired Devices

[ADV] Press Menu

> Settings > Connectivity

> Bluetooth > Paired Devices.

2. Press New

> Search All.

3. The available device will display.

4. To select the device press Option

> Select.

5. Enter password.

note

: The other device must be in pairing mode.

Setting device for outgoing call

1. [EZ] Press Options in standby mode >

Bluetooth > Outgoing Call Device

[ADV] Press Menu

> Settings > Connectivity

> Bluetooth > Outgoing Call Device.

Connectivity

2. Select Headset, Always Ask or Phone.

Sending an object

1. Select the ﬁle from Menu > My Stuff > Photo

Album

, Video Album, Audio, Graphics or

Other Files

2. Press Options

> Send via Bluetooth.

3. Select the device > Options

> Select.

note

: If the other Bluetooth device requests pairing, the object is sent after pairing is completed. Locked object or ones containing original rights may not be forwarded.

Receiving an object

When you receive the object a pop-up message will displayed if it is authorized. The ﬁle will be saved to the appropriate folder. For example, if you receive contacts information it will be saved in your phone’s memory

Setting the visibility

1. [EZ] Press Options in standby mode >

Bluetooth > Visibility

[ADV] Press Menu

> Connectivity >

Bluetooth

> Visibility.

2. Select Hidden or Shown to All

note

: It will allow your phone to be visible to

other’s devices.

Naming the phone

1. [EZ] Press Options in standby mode >

Bluetooth > Name

[ADV] Menu

> Connectivity > Bluetooth >

Name

2. Enter the name > Options

> Save.

note

: This is what others will see in their device’s display for your phone when searching for your device.

Using the browser

Accessing browser

1. [EZ] Press @ in standby mode. [ADV] Press

in standby mode or press

> MEdia Net > MEdia Net Home.

note

: It will access provider’s homepage.

Setting new bookmarks

ADV

1. Press Menu > MEdia Net > Bookmarks.

2. Press Options

> Add.

3. Enter the web address >

Viewing bookmarks

1. [EZ] Press @ > Options > Bookmarks. [ADV] Press Menu

> MEdia Net >

Bookmarks

2. To open the site, press Select

3. To send via text message, press Send

Message

Entering address

1. [EZ] Press @ > Options > Go to URL. [ADV] Press Menu

> MEdia Net > Go to URL.

2. Enter the web address >

Setting proﬁle

ADV

1. Press Menu > MEdia Net > Proﬁles.

2. Select Options

Viewing certiﬁcates

ADV

1. Press Menu > MEdia Net > Security >

Certiﬁcates

Setting the security warning

ADV

1. Press Menu > MEdia Net > Security >

Warning

2. Select Off or On

Connectivity

Proﬁles setting

ADV

You can set proﬁle and view Proﬁle Name, Home

URL

, Connection Type, Proxy Address, Proxy

Port

, Proxy Login ID, Proxy Password and Data

Bearer

Viewing default proﬁle

1. Press Menu > MEdia Net > Proﬁles.

2. Select MEdia Net Home

> Options > View.

Editing proﬁle

1. Press Menu > MEdia Net > Proﬁles.

2. Select other proﬁle > Options

> Edit.

Adding new proﬁle

1. Press Menu > MEdia Net > Proﬁles.

2. Select Empty > Options

> Add.

3. Enter the proﬁle name > Options

> Save.

Deleting proﬁle

1. Press Menu > MEdia Net > Proﬁles.

2. Select a proﬁle > Options

> Delete.

Breeze C520

Getting started

Calls & address book

Messaging

Multimedia

Useful features

Connectivity

Settings

Appendix

Settings

Language

Time and date

Ringtones

Decorating the display

Locks

To enable ﬁxed dialing

Reset

TTY

Language

ADV

Setting up

1. Press Menu > Settings > Phone > Language.

Time and date

ADV

Setting up

1. Press Menu > Settings > Phone > Time &

Date

2. Set each option > Save

Ringtones

Setting ringtones

1. Press Menu > My Stuff > Audio.

2. Select the ringtone > Options > Set as

Ringtone

Setting sound proﬁle

1. Press Menu > Settings > Sounds & Alerts

2. Select Normal, Vibrate and Ring

, Vibrate

Only, or Silent

Decorating the display

Setting the display

1. [EZ] Press Menu > Settings. [ADV] Press Menu

> Settings > Display >

Main Screen

2. Press Wallpaper > Graphic or Photo Album

3. Select the ﬁle > Options > Set as

Setting the font

ADV

1. Press Menu > Settings > Display > Font. You can set the style and the size of the font

for your device.

Settings

Entering greeting message

ADV

1. Press Menu > Settings > Display > Greeting.

Setting the brightness

ADV

1. Press Menu > Settings > Display >

Brightness

note

: Modifying brightness may affect battery life.

Setting time for backlight

1. [EZ] Press Menu > Settings > Backlight

Timer

[ADV] Press Menu

> Settings > Display >

Backlight Timer

note

: Modifying backlight time may affect battery

life.

Locks

Locking the phone

ADV

1. Press Menu > Settings > Security > Phone

Lock

2. Select On

note

: The default password is ‘1234’. To change the password press Menu

> Settings > Security >

Change Password

Locking the PIN

ADV

The Personal Identiﬁcation Number is the security code that protects the phone or SIM against unauthorized use.

1. Press Menu

> Settings > Security > PIN1

Check

2. Select On

3. Enter PIN code > @.

note:

To change the PIN code press Menu >

Settings > Security > Change PIN1

Changing PIN 2

ADV

1. Press Menu > Settings > Security > Change

PIN2

To enable ﬁxed dialing

Enabling

ADV

Press Menu > Settings > Security > Fixed

Dialing

For ﬁxed dialing, see page 30

Reset

Resetting the phone

ADV

1. Press Menu > Settings > Reset > Master

Reset

note

: It will return conﬁguration settings to default. The default password is ‘1234’.

Clearing the phone

ADV

1. Press Menu > Settings > Reset > Master

Clear

note

: It will change the setting as default and erase all personal data. The default password is ‘1234’.

Settings

TTY

The teletypewriter (TTY) is a telecommunications device that allows people who are deaf or hard of hearing, or who have speech or language disabilities, to communicate via a telephone.

Setting teletypewriter

ADV

1. Press Menu > Settings > TTY.

2. Select Disabled, TTY Full, TTY Talk, or TTY

Hear

•

Disabled: TTY mode is disabled.

•

TTY Full: User who cannot talk and hear send

and receive a text message.

•

TTY Talk: User who can talk but cannot

receive a text message and send voice message.

•

TTY Hear: User who can hear but cannot

talk send a text message and receive voice message.

Breeze C520

Getting started

Calls & address book

Messaging

Multimedia

Useful features

Connectivity

Settings

Appendix

Alert message

Troubleshooting checklist

Safety information

Safety precautions

About the battery usage

Hearing aid compatibility with mobile phones

FCC Regulatory Compliance

Warranty

Alert message

If you experience any problem while using your mobile phone, please refer to the following checklist. If the problem still persists, contact your service provider.

When the “Insert SIM Card” message appears:

Make sure the SIM card is correctly installed. Check to see if the SIM card is working properly. If it does not work, try to clean the contact points of the card with a dry cloth. If it is out of order, take it to your service provider.

When the “Text Message Full” message appears:

The received or saved messages are full in your phone or SIM memory. You need to delete the message.

When the

“Multimedia Message Full” message

appears:

The saved messages are full in your phone memory. When you receive new message you will see

“Multimedia Message Full. Move To Inbox?” You can move to inbox or delete the message.

When the “Password” message appears in Phone locked state:

Enter the phone password. The default password is “1234”. If you cannot remember the password, contact the nearest carrier.

When the “Enter PIN1” message appears:

Input PIN1. If you cannot remember it, contact your service provider. You can still receive calls even if your mobile phone becomes locked after entering the incorrect PIN1 on three consecutive attempts.

When the “No Service” or “Network Search” appears:

If you cannot make/receive a call when you are indoors or undergrounds where the signal strength is poor, move toward a window or go out to an open area. If you still cannot make a connection, contact your service provider.

06 07

Appendix

Troubleshooting checklist

When audio quality is poor:

End a call and try again.

When the other party cannot hear you speaking:

Your phone may be set to MUTE. Disable the MUTE function. Or your hand may be covering the microphone located below the

key.

When battery lifetime is shorter than usual:

This may happen when you are in an area with low signal strength. Turn off your phone when it is not in use. Change the battery when battery energy is exhausted.

When your mobile phone does not turn on:

Make sure your battery is charged. Check to see if your phone works while recharging the battery.

When you are unable to send a message:

Either you are not registered to receive an SMS service, or you may be in an area where your network service provider cannot provide such a service.

When you are unable to make a call:

Your phone may be set to “ﬁxed dial.” Cancel the “ﬁxed dial” function.

When you are unable to charge the battery:

This may be the result of one of the following three cases.

1. Your charger may be out of order. Contact your

nearest dealer.

2. You may be attempting to use the phone in an overly

hot/cold temperature. Try changing the charging environment.

3. Your battery may have not been connected to the

charger properly. Check the connector.

When you are unable to input data into your Address Book:

Your Address Book memory may be full. Try deleting some entries from your Address Book.

When you are unable to select a certain function:

You may not have subscribed to that function, or your

network service provider may be in an area where such service cannot be provided. Contact your local service provider.

Safety information

The following list shows how to maintain your mobile phone, together with precautions to take. – Keep your mobile phone and its accessories out of the

reach of children.

– Maintain your mobile phone in dry conditions and keep

it within normal operating temperatures. Temperatures higher than 55°C (131°F) or lower than -20°C (-4°F) may damage your phone.

– Do not use or store your mobile phone in dusty, dirty

areas. – Do not attempt to disassemble your mobile phone. – Do not drop or cause severe impact to your mobile

phone.

– Do not use chemical products, cleaning solvents or

detergents to clean your mobile phone.

– If your mobile phone does not work properly, contact

your dealer immediately.

– Use only authorized batteries, battery chargers and

accessories. Any malfunction or damage caused by the use of unauthorized batteries, battery chargers and accessories will void the limited product warranty.

– Ensure that the battery and battery charger do not

come in contact with conductive objects.

Safety precautions

Using a mobile phone while driving may be prohibited.

Please check local laws and regulations with regard to the prohibition of mobile phone use while driving, and comply with them. Use of your phone while you are driving may disturb your concentration and may lead to an accident. Always switch your phone off to drive safely.

06 07

Appendix

Should you use your phone in an emergency, either use a hands free device built into your car or pull over in a safe place ﬁrst.

Switch off in restricted areas

Always switch your phone off in areas where mobile phone use is restricted.

Switch off in explosive or dangerous areas

Always switch your phone off in areas with explosive or dangerous materials (such as fuels, fuel stations or areas containing chemical goods) and obey any instructions or signals. Do not remove your mobile phone’s battery in such areas.

Switch off in aircraft

ADV

When you are in an aircraft, always switch your phone off or select Flight Mode On (press the Menu > Settings > Phone > Flight mode in Advanced Mode. In Breeze

Mode you need to assign to options. Press Options in

main screen. Select one of the Unassigned > Options >

Edit. Press Settings > Flight Mode). The electromagnetic

waves emitted by your phone may affect the electronic navigation equipment in the aircraft.

Switch off in hospitals and near medical equipment

Always switch your phone off in hospitals, and obey the regulations or rules of the hospital.Switch your phone off when using medical equipment for private purposes, if possible. Always consult with the medical equipment’s manufacturer or an expert regarding phone use near the medical equipment.

Installing a hands free device in your vehicle

Install vehicle hands free devices away from the steering wheel and airbag expansion area, otherwise injury may result.

Mobile phones and other electronic devices

Mobile phones emit electromagnetic waves that may affect nearby electronic devices. When it is switched on, do not place your phone close to delicate electronic equipment.

About the battery usage

Your phone is powered by a Lithium Ion (Li-Ion) battery. This means that, unlike other forms of battery technology, you can recharge your battery while some charge remains without reducing your phone’s autonomy due to the “battery memory effect” inherent in those technologies.

– Do not use a damaged battery or charger. – Do not disassemble or open crush, bend or deform,

puncture or shred. – Do not modify or remanufacture, attempt to insert

foreign objects into the battery, immerse or expose

to water or other liquids, expose to ﬁre, explosion or

other hazard. – Do not put your battery into contact with conductive

objects.

– Dispose of and recycle used batteries in accordance

with local regulations. Do not dispose of batteries by

burning; they may explode. – Do not use an unauthorized charger. –

Only use the battery for the device for which it is speciﬁed – Only use the battery with a charging device that has

been qualiﬁed with the device per this standard. Use

of an unqualiﬁed battery or charger may present a risk

of ﬁre, explosion, leakage, or other hazard. – Do not short circuit a battery or allow metallic

conductive objects to contact battery terminals. – Replace the battery only with another battery that

has been qualiﬁed with the device per this standard,

IEEE-Std-1725-2006. Use of an unqualiﬁed battery

may present a risk of ﬁre, explosion, leakage or other

hazard. – Promptly dispose of used batteries in accordance with

local regulations. – Battery usage by children should be supervised. – Avoid dropping the phone or battery. If the phone or

battery is dropped, especially on a hard surface, and

06 07

Appendix

the user suspects damage, take it to a service center

for inspection. – Use your battery for the speciﬁed purpose only. – The closer you are to your network’s base station, the

longer your phone usage time because less battery

power is consumed for the connection. – The battery recharging time varies depending on

the remaining battery capacity and the battery and

charger type you use. – Battery life inevitably shortens over time. – Use an authorized battery and charger only. – Since overcharging may shorten battery life, remove

the phone from its charger once it is fully charged.

Unplug the charger, once charging is complete.

Leaving the battery in hot or cold places, especially

inside a car in summer or winter, may reduce the

capacity and life of the battery. Always keep the

battery within normal temperatures. – To prevent injury or burns, ensure that no metal

objects come into contact with the + and

– terminals

of the battery.

Hearing aid compatibility with mobile phones

When some mobile phones are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference noise, and phones also vary in the amount of interference they generate.

The wireless telephone industry has developed ratings for some of their mobile phones, to assist hearing device users in ﬁnding phones that may be compatible with their hearing devices. Not all phones have been rated. Phones that are rated have the rating on their box or a label on the box.

The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated phone successfully. Trying out the phone with your hearing

device is the best way to evaluate it for your personal needs.

M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference to hearing devices than phones that are not labeled. M4 is the better/higher of the two ratings.

T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely to be more usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated phones. T4 is the better/higher of the two ratings. (Note that not all hearing devices have telecoils in them.)

Hearing devices may also be measured for immunity to this type of interference. Your hearing device manufacturer or hearing health professional may help you ﬁnd results for your hearing device. The more immune your hearing aid is, the less likely you are to experience interference noise from mobile phones.

FCC regulatory compliance

FCC Regulatory Compliance

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Your mobile device is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals. In August 1996, the Federal Communications Commission (FCC) adopted RF exposure guidelines with safety levels for mobile devices. Those guidelines are consistent with safety standards previously set by both U.S. and international standards bodies: American National Standard Institute (ANSI), National Council of Radiation Protection and Measurements (NCRP), and International Commission on Non-Ionizing Radiation Protection (ICNRP). Those

06 07

Appendix

standards were based on comprehensive and periodic evaluations of the relevant scientiﬁc literature. The design of your phone complies with the FCC guidelines and applicable.

Statement according to FCC part 15.105

note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential

installation. This energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV

technician for help.

Statement according to FCC part 15.21

Modiﬁcations not expressly approved by this company could void the user’s authority to operate the equipment.

RF exposure FCC

For body worn operation, to maintain compliance with FCC RF exposure guidelines, use only accessories that contain no metallic components and provide a separation distance of 15mm (0.6 inches) to the body. Use of other accessories may violate FCC RF exposure guidelines and should be avoided. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.

Health and Safety Information FCC

This EUT has been shown to be capable of compliance for localized speciﬁc absorption rate (SAR) for uncontrolled environment/general population exposure limits speciﬁed in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures speciﬁed in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-2003 Ministry of Health (Canada), Safety Code 6. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the Speciﬁc Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg *.

* In the U.S. and Canada, the SAR limit for mobile

phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give

additional protection for the public and to account for any variations in.

** This device contains 1800 MHz GSM functions that

are not operational in U.S. Territories; this ﬁling is applicable only for 850 MHz GSM and 1900 MHz PCS operations.

Warranty

Protect Your Warranty

Read your Warranty carefully, with the special consideration to paragraph seven of the Limited Warranty for your unit.

“Warranty does not apply to... or to any product or part thereof which has suffered through alteration... mishandling, misuse, neglect or accident”.

Many companies are making look alike accessories and in some cases, promoting that their product is equal to or better than the Pantech product. Be careful. Some of these products may not be compatible to use with your

06 07

Appendix

Pantech product and may damage the unit or cause it to malfunction. If service is required on your unit and it is determined that a non-Pantech accessory has created the problem with your unit, the Warranty will not apply. In addition, if the unit has already suffered irreversible damage by reason of a non-compatible accessory, the Warranty will be voided. To protect your Warranty, use only compatible accessories which cannot damage or interfere with the functioning of your Pantech product.

12 Month Limited Warranty

Pantech Wireless, Inc. (the Company) warrants to the original retail purchaser of this Pantech handheld portable cellular telephone, that should this product or any part thereof during normal consumer usage and conditions, be proven defective in material or workmanship that results in product failure within the ﬁrst twelve (12) months period from the date of purchase, such defect(s) will be repaired or replaced (with new or rebuilt parts) at the Company’s option, without charge for parts or labor directly related to the defect(s).

The antenna, key pad, display, rechargeable battery and battery charger, if included, are similarly warranted for twelve (12) months from date of purchase.

This Warranty extends only to consumers who purchase the product in the United States or Canada and it is not transferable or assignable.

This Warranty does not apply to:

(a) Product subjected to abnormal use or conditions,

accident, mishandling, neglect, unauthorized alteration, misuse, improper installation or repair or improper storage;

(b) Product whose mechanical serial number or

electronic serial number has been removed, altered or defaced.

excessive temperatures or extreme environmental conditions;

(d) Damage resulting from connection to, or use of

any accessory or other product not approved or authorized by the Company;

(e) Defects in appearance, cosmetic, decorative or

structural items such as framing and non-operative parts;

(f) Product damaged from external causes such as

ﬁre, ﬂooding, dirt, sand, weather conditions, battery leakage, blown fuse, theft or improper usage of any electrical source.

The Company disclaims liability for removal or reinstallation of the product, for geographic coverage, for inadequate signal reception by the antenna or for communications range or operation of the cellular system as a whole.

To obtain repairs or replacement within the terms of this Warranty, the product should be delivered with proof of Warranty coverage (e.g. dated bill of sale), the consumer’s return address, daytime phone number and/ or fax number and complete description of the problem, transportation prepaid, to the Company by calling the number listed below or to the place of purchase for repair or replacement processing.

In addition, you may telephone us at (800) 962-8622, or email us at HandsetHelp@Pantech.com

THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT.

ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY MUST BE BROUGHT WITHIN A PERIOD OF 18 MONTHS FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR ANY SPECIAL CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER. THE COMPANY SHALL NOT BE LIABLE FOR THE DELAY IN RENDERING

06 07

Appendix

SERVICE UNDER THIS WARRANTY OR LOSS OF USE DURING THE TIME THE PRODUCT IS BEING REPAIRED OR REPLACED.

No person or representative is authorized to assume for the Company any liability other than expressed herein in connection with the sale of this product. Some states or provinces do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damage so the above limitation or exclusions may not apply to you. This Warranty gives you speciﬁc legal rights, and you may also have other rights which vary from state to state or province to province.

PANTECH WIRELESS, INC.

11240 Warland Drive, Cypress, CA 90630 (800) 962-8622

Memo

Pantech breEZe C520 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
