Pantech 5U000242C0A, Reveal User Manual

Download

5U000242C0A REV.01

Parte del contenido en este manual puede variar en el teléfono dependiendo del

software del teléfono o tu proveedor del servicio.

de AT&T Inc. proporcionan productos y servicios utilizando la marca de AT&T.

sof

tware del teléfono o tu proveedor del servicio.

009 AT&T Intellectual Property. Las

emp

res

sub

AT&T Inc. proporcionan prod

uct

Guía del usuario

Some of the contents in this manual may differ from your phone depending on the software of the phone or your service provider. © 2009 AT&T Intellectual Property. All rights reserved. Subsidiaries and afﬁ liates of AT&T Inc. provide products and services under the AT&T brand.

009 AT&T Intellectual Property. All

rig

hts

afﬁ liates of AT&T Inc.

pro

vid

e p

User Guide

PANTECH Reveal User Guide

5U000242C0A REV.01

Your phone is designed to make it easy for you to access a wide variety of content. For your protection, we want you to be aware that some applications that you enable may involve the location of your phone being shared. For applications available through AT&T, we offer privacy controls that let you decide how an application may use the location of your phone and other phones on your account. However, the AT&T privacy tools do not apply to applications available outside of AT&T. Please review the terms and conditions and the associated privacy policy for each location-based service to learn how location information will be used and protected. In addition, your AT&T phone may be used to access the Internet and to download, and/or purchase goods, applications, and services from AT&T or elsewhere from third parties. AT&T provides tools for you to control access to the Internet and certain Internet content. These controls may not be available for certain devices which bypass AT&T controls.

Su teléfono está diseñado para hacerlo fácil para acceder a una amplia variedad de contenido. Para su protección, queremos que

usted esté enterado que algunas aplicaciones que le permite puede implicar la ubicación de su teléfono para ser compartida. Para

aplicaciones disponibles a través de AT&T, ofrecemos controles de privacidad que le permiten decidir cómo una aplicación puede

utilizar la ubicación de su teléfono y otros teléfonos en su cuenta. Sin embargo, el AT&T herramientas de privacidad no se aplican

a las aplicaciones disponibles fuera de AT&T. Por favor, revise los términos y condiciones asociadas y la política de privacidad para

cada lugar de servicio para saber cómo la información sobre la localización serán utilizados y protegidos. Además, su AT&T teléfono

puede ser usado para acceder a Internet y para descargar, y / o la adquisición de bienes, aplicaciones y servicios de AT&T o en

otra parte de terceros. AT&T proporciona herramientas para que usted controle el acceso a Internet ya determinados contenidos de

Internet. Estos controles pueden no estar disponibles para ciertos dispositivos de bypass que AT&T controles.

REVEAL USER MANUAL

Thank you for choosing the Pantech Reveal, our latest 3G mobile phone. The Pantech Reveal has many features designed to enhance your mobile experience. From its unique, stylish design and QWERTY keypad, we know you will enjoy the entire Reveal experience. This User Guide contains important and useful information that will maximize your familiarity with all that the Pantech Reveal has to offer.

Specifications

Design

Single slider with QWERTY keypad

Displays

• 260k colors TFT LCD with 2.2” internal display

• 320*240 resolution

• 5 lines for text in basic mode with 16-point font

• Three soft keys and four-way scroll and selection

keys

M elodies

MP3, MIDI, iMelody, MMF, WAV, SMAF, AAC+

Camera

Integrated 1.3M CMOS Camera

• Resolution up to 1280 x 1024 (1,310,720 pixels)

• Mpeg4 Video recording/playing up to 15f/s(QVGA size)

• Self-timer function (5 seconds or 10 seconds)

• Photo album and video album

Dimensions & Weight

• Weight: 112g/3.950oz (with standard battery)

• Dimensions: 99.3 mm x 59.9 mm x 14.8 mm

3.90“ x 2.35“ x 0.58“

Power Management (Performance)

Battery Type Capacity Standby Time Talk Time

Standard

Lithium-Ion

(Li-ion)

Up to 930

mAh

Up to 11

days(290

hours)

Up to

4.5(4.8) hours

Operating Frequency

• GSM 850Mhz, GSM 900Mhz, GSM 1800Mhz, GSM 1900Mhz, UMTS 850Mhz, UMTS 1900 Mhz, and UMTS 2100Mhz networks in North America, South America, Europe, Africa, and Asia-Pacific where these networks are supported.

• Automatic band switching.

Receiver

Display

Left/Right Soft key

Perform the functions shown At the bottom line of the display

Clear key

Return to previous screen or delete characters in text mode

Power on&off/Menu exit key/End key

Turn phone on/off, end calls, exit menus

International call prefix key

Messaging

Key

Send key

QWERTY

Keypad

5 way navigation

Up: Write New SMS

Down: Contact List

Left: E-mail

Right: IM

Center: @ / Mobile

Web

Phone overview

Number pad view

Menu features

Address Book Messaging IM Mobile Email Mobile Web AppCenter AT&T GPS YPmobile My Stuff AT&T Music CV Settings

note:

Holding the device by the internal antenna area might affect the quality of all calls.

Camera

Charger slot/Ear mic

Side key

MicroSD slot

Camera key

Internal antenna

Speaker

QWERTY keypad view

CAPS/Shift key

To type a single uppercase

letter, press this key then

a letter.

Function key

To enter a number or a

symbol, press the

function key, and press

the corresponding key.

note: To use the QWERTY keypad, hold the phone horizontally and slide the screen up.

Delete key

Press to delete a number or letter.

Enter key

Press to create new line while writing a message.

Space key

Press to enter a space.

Numbered menu items, such as menus, sub-menus, and options can be quickly accessed by using their shortcut numbers. In Menu mode, Main Menus can be accessed by pressing the number keys (1 to 0,*,#) corresponding to

their location on the screen. Example: Accessing the Language menu.

1. Press the Menu.

2. Press the

# for Settings.

3. Press the 4 for Phone.

4. Press the 1 for Language.

5. Press Select for Screen Text.

6. Press the U or D scroll key to display the list of available languages.

note:

In main menu screen the number keypad is matched

with the menus as follows.

Using shortcuts

Keys Functions

Address Book

Messaging

Mobile Email

Mobile Web

AppCenter

AT&T GPS

YPmobile

My Stuff

AT&T Music

Settings

Menu overview

Address Book

Contacts Add Contact Speed Dial Groups My Business Card Memory in Use My Phone Number Used Space Service Numbers

FDN List

Messaging

Inbox Create Message Mobile Email IM Sent Outbox Drafts Voice Mail Settings Templates Used Space

IM Mobile Email

AT&T GPS

AT&T Navigator Where AllSport GPS Platinum

YPmobile

Mobile Web AppCenter

My Stuff

Applications Audio Games Picture Video Tools Other Files Used Space

AT&T Music

Music Player Shop Music MusicID XM Radio Music Videos Make -UR-Tones Community Music Apps

CV Settings

Profiles Display Call Phone Network Connections Network

Connectivity Security

Software Reset TTY

SIM dependent N Network dependent

Quick & easy

Keys Functions

Perform the functions shown at the bottom line of the display by using these soft keys. Scroll through the menu options in Menu mode. In standby mode,

Left: Access E-mail menu Right: Access IM menu Up: Access Create Message menu Down: Access Contacts menu Work in Word search mode if pressed in the Predictive text input mode.

Select a menu function or store user-input information, such as names. Also use this key for confirmation as the @ key. Launch the Mobile Web directly if pressed in standby mode.

Delete characters from the display, or return to previous menu.

Send or receive a call. Show the recent call list in standby mode.

Keys Functions

Complete the current call. Turn on/off the phone if pressed and held Cancel user input and return to main screen while in Menu mode.

Quickly connect to the voice mail server if pressed and held in standby mode.

0~9

Enter numbers, letters or special characters. Go to the dial screen if pressed in standby mode.

Enter or exit from vibrate mode if pressed and held in standby mode. Show the symbol input screen if pressed in text input mode.

Enter an international dialing prefix if pressed and held in standby mode. Enter the space character in text input mode.

Change various text input modes if pressed at the text-editing screen. Adjust the earpiece volume while making a call.

Control the Ringtone volume, vibrate mode and silent all mode in standby. Mute the ringtone of an incoming call.

Press and hold to access the Multitask menu.

Turn camera capture mode on. Work as a camera shutter in capture mode.

Contents

Specifications .......................................2

Phone overview ....................................3

Using shortcuts ....................................5

Menu overview .....................................6

Quick & easy .........................................9

1. Getting Started

SIM card and battery .....................16

Turn phone on/off .........................17

Keypad lock ...................................17

Essential display indications ..........17

Memory card .................................19

Assigning the menu .......................20

Updating software .........................20

Using the QWERTY key pad .........20

Using the multitask menu ..............21

Contents

2. Calls and address book

Make, receive and end calls ..........24

Using video share ..........................25

Options during a call ......................26

Call settings ..................................28

Settings for video share .................28

Checking all calls ...........................29

Speed dialing .................................30

Using the address book .................31

Caller identification ........................32

Using your headset .......................32

Service numbers and fixed dialing 32

3. Messaging

Entering text ..................................36

Messaging .....................................37

Receiving messages ....................38

Creating and sending text

messages ......................................39

Creating multimedia messages .....39

Message templates .......................42

Message settings .........................42

Voice message settings ................43

Email ..............................................43

Using instant messenger ...............43

4. Multimedia

Camera ..........................................48

Photo album ..................................50

ContentsContents

Video album...................................51

Audio album...................................52

Music Player ..................................53

Music player settings .....................56

Media player ..................................57

Other files ......................................58

Managing memory .........................58

Playing games ..............................58

5. Useful Features

Alarm .............................................62

Calendar ........................................62

Notepad and voice memo .............63

Calculator, tip calculator and

converter .......................................63

Stop watch .....................................64

Business card ................................64

Memory information .......................65

6. Connectivity

Bluetooth .......................................68

Using the Mobile Web ..................69

Using the browser .........................69

Profile settings ..............................70

7. Settings

Language.......................................74

Time and date ...............................74

Ringtones .....................................74

Decorating the display ...................74

Locks .............................................75

Security .........................................76

Reset .............................................76

TTY ................................................76

8. Appendix

Alert message................................80

Troubleshooting checklist ..............80

Safety information .........................81

Safety precautions .........................81

About the battery usage ................82

FCC Hearing-Aid Compatibility

(HAC) Regulations for Wireless

Devices ..........................................83

FCC Regulatory Compliance ........84

Warranty ........................................85

Reveal

Getting Started

Calls and address book

Messaging

Multimedia

Useful Features

Connectivity

Settings

Appendix

SIM card and battery

Turn phone on/off

Keypad lock

Essential display indications

Memory card

Assigning the menu

Updating software

Using the QWERTY key pad

Using the multitask menu

Getting Started

SIM card and battery

About your SIM card

When you subscribe to your network operator, you receive a SIM (Subscriber Identity Module) card containing your registration information, PIN code, etc. Like a credit card, it should be kept secure and handled carefully. Do not bend, scratch or expose it to moisture. Avoid static electricity. To avoid corrupting your SIM card’s memory, always switch off your phone before removing or inserting your SIM card.

About your battery

Your phone uses a Li-Ion battery. Make sure to use an authorized battery and charger only. For more details, please inquire at your nearest dealer.

note:

Your phone is powered by a Lithium Ion (Li-Ion) battery. Unlike other forms of battery technology, you can recharge your battery while some charge remains without reducing your phone’s autonomy due to the “battery memory effect” inherent in those technologies.

Installing/removing SIM card and battery

1. Remove the battery cover from the unit.

2. To fit the battery cover, put it on the guide rail and push up.

3. Insert the SIM card into the slot. The gold contacts of the SIM card should go against the metal contacts of the phone. Put the contacts of the battery into the hole located at the bottom of the unit insert and press the upper side of the battery until you hear the “click”.

4. To remove the battery push the bottom of the battery to upwards(1) and remove(2) the battery. Push the SIM card in the direction of the arrow as shown.

Getting Started

Turn phone on/off

To turn on

1. Press and hold

To turn off

1. Press and hold

Keypad lock

Locking the keypad

1. Press hold

Unlocking the keypad

1. Press Unlock >

to unlock.

Essential display indications

Signal strength. The greater the number of bars, the stronger the signal When network is in searching mode is displayed

A call is being made. When you are in no service area is displayed

Call forwardingN is active

To charge your battery

1. To charge, open the protective cover on the top right side and connect the charger adapter. Make sure you align the connector as the image. If not, it will damage the charging connector on the phone and will not charge.

Incorrect Correct

2. To remove the adapter connection press the adapter’s side buttons (1) and pull the adapter away (2).

Incoming calls set to ring only (Normal) Incoming calls set to Vibrate and Ring Incoming calls set to Vibrate Only Incoming calls set to Silent

Flight Mode is active

Received one or more text messages Received one or more multimedia messages Received one or more WAP push messages Received one or more configuration messages Received one or more voice messages A message is being sent A message is being received An alarm is set Schedule Alarm is set

Browser is Active, Secured and being downloaded

Bluetooth is active Bluetooth is Transfer

Bluetooth headset is connected Headset is connected

USB is connected TTY is active

A GPRS signal is available. It is displayed when there is an active GPRS session

An EDGE signal is available. It is displayed when there is an active EDGE session

A 3G signal is available. It is displayed when there is an active 3G session

microSD card is insert Battery strength

When the battery charge is low, is displayed Available, Away, Invisible Status of AIM

Online, Away, Busy, Offline Status of MSN

Available, Busy, Invisible Status of YAHOO

You have received one or more IM messages

BGM is play, pause and being stopped

Network dependent

Getting Started

Memory card

You can use microSD card as a memory card. It gives you more space to save pictures, videos, music, etc.

Inserting and removing the memory card

1. Open the memory card slot.

2. Insert the card. The icon will be display.

3. Press the card to remove.

Using memory card

You can save, move and delete the files between your phone and external memory card. You can also move and copy the files to computer from your phone.

Resetting the card

1. Press Menu > Settings > Reset.

2. Enter the password > External Memory Reset.

note:

The default password is ‘1234’.

To copy the file to the card

1. Select the file > Options > Copy to External Memory.

2. To copy the file back to phone, press Options > Copy to

Phone.

To move the file to the card

1. Select the file > Options > Move to External Memory.

2. To move the file back to phone, press Options > Move to

Phone.

To delete the file from the card

1. Select the file from the card > Options > Delete.

To move the file from the card to the computer

1. Connect the data cable with mobile and the computer.

2. Press Menu > Settings > Connectivity.

3. Press Select USB Mode.

4. Select Music Player, Mass Storage or Ask on

Connection.

5. Follow the instruction on your computer screen.

note:

Select Music Player when you want to add music to the playlist in your device. When you select Ask on

Connection, it will ask you to select either the Music Player

or Mass Storage every time you connect your device with your computer.

Assigning the menu

You can set the most commonly used menu in Options in standby mode.

1. Press Shortcuts in standby mode > select Unassigned.

2. Press Add.

3. Select the menu and sub menu.

Updating software

You can update your software without visiting your nearest dealer.

To update the software

1. Press Menu > Settings > Software > Software Update.

2. Press Check for Update > Yes to check whether or not

you need to update the software.

note:

After downloading the software, the device will ask you whether to update the software now or later. If you choose to update the software now, it will restart the handset. If you postpone updating the software, you can select between 30 mins, 1 hour or 4 hours in the Options.

After selecting the updating time, you will be sent back to standby mode. If you go to Software Update while you are in postponing, press Continue Update.

To view the version of software

1. Press Menu > Settings > Software.

2. Press Phone Information and scroll down to Software

Version.

Using the QWERTY key pad

Your phone has QWERTY keypad which provides a superior typing experience on a small handheld for easy and comfortable texting. You can use all of the phone functions with the QWERTY keypad opened.

note:

QWERTY keypad can be used when the number pad is closed. With the number pad is opened, the QWERTY keypad can not be opened.

Key Function

S/S

Perform the functions shown at the bottom line of the display by using these soft keys

Press to change ab Ab AB at the text editing screen

dbc

(all small caps / first letter caps / all caps)

Getting Started

Multitask functions

To using multitask function, press and hold the side up key . You can choose from one of the following function:

• Call: Make a voice call while using the handset for other

tasks. If Music Player is active, it is muted during the call.

• Messaging: Send a text or multimedia message while using

the handset for other tasks.

• Mobil Web: Launch the browser while using the handset for

other tasks.

• Music Player: Launch the Music Player while using the

handset for other tasks. If an incoming call is received or you want to make a call, the Music Player is muted.

• Games & Apps: Access Games and Applications while using

the handset for other tasks.

Key Function

Press to type a special character or number, at the applicable key pad. To enter symbols and numbers continually, press until displays

Enter the space character in text input mode Insert a carriage return in text input mode

Delete a character to the left of the text cursor in text editing screen

Press to type a special character that is not placed on the keypad

Using the multitask menu

Press and hold to launch the Multitask menu that can be activated from within any active window or page on the phone. There is no need to stop what you are doing, if you quickly want to jump out and activate another common feature. The idea is to allow you to temporarily exit from your current location to access a group of common functions such as: Call,

Messaging, Mobil Web, Music player and Games & Apps.

This key keeps you from having to completely exit from your current task or window, whether that be a text message, a web page, or an active call, quickly do something else.

Reveal

Getting Started

Calls and address book

Messaging

Multimedia

Useful Features

Connectivity

Settings

Appendix

Calls and address book

Make, receive and end calls

Using video share

Options during a call

Call settings

Settings for video share

Checking all calls

Speed dialing

Using the address book

Caller identification

Using your headset

Service numbers and fixed dialing

Make, receive and end calls

Making a call

1. Enter the area code and phone number.

2. Press

Answering a call

1. Press

Ending a call

1. Press

Once the call is complete, a call summary is displayed.

Rejecting a call

1. Press

or Ignore.

Making a call using call list

Your phone logs up to 20 dialed, received and missed call numbers.

1. Press

to display the Recent Calls list.

2. Select All Calls, Missed Calls, Received Calls, or Dialed

Calls pressing the L/R.

3. Select a number.

4. Press

to dial the selected number.

note:

To redial the last number in the Recent Calls list, press

Making a call during a call

1. Enter the phone number or look it up in Address Book.

2. Press

to dial the second call. The first call is

automatically put on hold.

Switching between two calls

1. Press Swap.

Making an international call

1. Press and hold

key for the international prefix until

the ‘+’ character appears.

2. Type the country code, area code, and phone number.

3. Press

Making an emergency call

You can make emergency calls even if your phone does not have a SIM card.

Calls & address book

1. Press Emergency Number, or press SOS if your phone

does not have a SIM card.

2. Press

Replying to a missed call

1. Press View to display the list of missed calls.

2. Select a number to call by pressing the U/D key.

3. Press

Answering a second call

1. Press

. The first call is automatically put on hold.

2. Press

to end the second call.

The call on hold is automatically reconnected.

Using video share

You can share live or recorded video while on a call. You can send or receive video.

note:

Video Share is not available in all markets. Both parties must be in a 3G service area–a 3G icon must appear by the signal bars prior to a call being placed, and both parties must remain in the 3G coverage area for the duration of the Video Share.

Making video share call

1. Enter the area code and phone number >

2. Press Options > Video Share.

3. Select Live or Recorded.

note:

To use video share in the Recent Calls, press Options

> Video Share.

Turning off the speakerphone

1. Press @ or press Options > Speakerphone Off during video share mode.

2. Press Options > Mute to mute the sound.

Stopping video share

1. Press Stop to end.

2. To end a call press

Increasing or decreasing the brightness

1. Press Options > Brightness.

2. Adjust the brightness by pressing

L/R

Zoom in and out

1. Press Options > Zoom. It ranges from x1 to x3.

Stopping the recording

1. Press Options > Stop Record.

For details on setting for automatic recording, see page 39.

Ending video share

1. Press Stop to end the video share.

2. It will ask you whether you will stop video share > Yes to

stop.

note:

Even you end video share, the call will not be ended.

Press

to end the call. The recorded video will be saved

in My Stuff > Video.

Receiving video share

1. After receiving video share, it will ask you whether to accept or reject the video share > Yes to accept and No for reject.

2. Press Options > Full Screen to landscape the screen.

Options during a call

Microphone off and on

Switching your phone’s microphone off

1. Press Options > Mute [ ].

Switching your phone’s microphone back on

1. Press Options > Unmute.

Talking on speaker

1. Press Speaker Phone [ ].

Putting a call on hold and returning

Putting a call on hold

1. Press Options > Hold or press

Calls & address book

Returning to a held call

1. Press Options > Unhold or press

again.

Multi-party calls

You can talk with more than one person or have conference call.

Making a multi-party call

1. Call the first participant.

2. Call the second participant. The first call is automatically put on hold.

3. Press Options > Join.

Having a private conversation with one participant

1. Press Options > Split.

2. Press @.

3. Select the participant and press @.

All of the multi-party call participants can now hear each other.

Removing one participant from a multi-party call

1. Press Options > End.

2. Select the participant and press @.

The call ends with that participant, but you can continue to talk to the other participants.

Searching for a number in the address book during a call

1. Press D or press @ or press Options > View Contacts

> Contacts.

2. Select a number >

Searching for a name or group in the address book

Enter the first letters of the name for Name Search. The entries are displayed starting with the first entry matching your input.

Finding a name manually in the address book

1. Press the

U/D

key.

Viewing the details of the highlighted entry in the address book

1. Press View.

For details on address book, see page 31.

Reading a message during a call

1. Press Options > View Message.

2. Select a message > @.

Entering a message during a call

1. Press Options > Send Message.

For details on creating a text message, see page 39.

Viewing calendar during a call

1. Press Options > View Calendar.

Entering a notepad during a call

1. Press Options > Notepad.

Voice recording

1. Press Options > Voice Recording.

Setting DTMF

1. Press Option > DTMF On or Off.

Call settings

Setting auto redial

1. Press Menu > Settings > Call > Auto Redial.

2. Select On or Off.

Answering by pressing any key

1. Press Menu > Settings > Call > Any Key Answer.

2. Select Answer with Any Key.

note:

You can answer with any key except

and

Ignore.

Settings for video share

Turning the alert on/ off

1. Press Menu > Settings > Call > Video Share.

2. Press Alerts.

3. Select On or Off > Select.

Setting for automatic recording

1. Press Menu > Settings > Call > Video Share.

2. Press Auto Record.

3. Select On or Off > Select.

Setting for service

1. Press Menu > Settings > Call > Video Share.

2. Press Service.

Calls & address book

3. Select On or Off > Select.

Setting for profile

1. Press Menu > Settings > Call > Video Share.

2. Press Profile.

3. Select AT&T IMS or Media Net > Select.

Setting recording location

1. Press Menu > Settings > Call > Video Share.

2. Press Recording Location.

3. Select Phone Memory or External Memory > Select.

Checking all calls

You can view information about all Recent Calls. For more options for all, missed, received and dialed calls press Options.

You can also view the call history simply by pressing

Viewing missed calls

1. Press Shortcuts in standby mode or press Menu > My

Stuff > Tools.

2. Press Recent Calls > Missed Calls.

Viewing received calls

1. Press Shortcuts in standby mode or press Menu > My

Stuff > Tools.

2. Press Recent Calls > Received Calls.

Viewing dialed calls

1. Press Shortcuts in standby mode or press Menu > My

Stuff > Tools.

2. Press Recent Calls > Dialed Calls.

Viewing Ranking calls

1. Press Shortcuts in standby mode or press Menu > My

Stuff > Tools.

2. Press Recent Calls > Call Ranking.

Deleting call logs

1. Press Shortcuts in standby mode or press Menu > My

Stuff > Tools.

2. Press Recent Calls > Delete Call Logs.

3. Select All Calls > Yes.

Viewing call time

1. Press Shortcuts in standby mode or press Menu > My

Stuff > Tools.

2. Press Recent Calls > Call Time.

3. Press

U/D

to view Last Call, Received Calls, Dialed

Calls and Total Calls.

Resetting all call times

1. Press Shortcuts in standby mode or press Menu > My

Stuff > Tools.

2. Press Recent Calls > Call Time.

3. Press Reset > Yes.

4. Enter password > @.

note:

The default password is ‘1234’.

Viewing data transmitted information

1. Press Shortcuts in standby mode or press Menu > My

Stuff > Tools.

2. Press Recent Calls > Packet Counter.

•

Current Info: You can view transmitted data in the current

session, in Kbytes. Sent, Received and Total information are also available.

•

Last Info: You can view Sent, Received, Total and

Duration information of the previous session’s transmitted

in Kbytes.

•

Total Info: You can view all the Sent, Received, Total

and Duration transmitted data in Kbytes.

•

Clear Logs: The default password is ‘1234’.

Speed dialing

You can dial quickly using speed dialing. Up to 8 phone numbers can be programmed using numbers 2 to 9.

: Voice mail

: Prefix for international call

Setting speed dial

1. Press Menu > Address Book > Speed Dial.

2. Select an empty entry and press Add.

3. Select a person and press @ or Select.

Changing speed dialing person

1. Press Menu > Address Book > Speed Dial.

2. Select a number > Change or @ .

3. Select a person > @ or Select.

Removing from speed dial

1. Press Menu > Address Book > Speed Dial.

2. Select a number > Delete.

Calls & address book

Using the address book

You can save names, phone numbers, and information on the SIM or phone. Entries can depend on the capacity of the SIM card.

Viewing the contact list

1. Press D or press Menu > Address Book > Contacts.

Searching for a phone number

1. Press D or press Menu > Address Book > Contacts.

2. Input the first letter or two of the person’s name and scroll with

U/D

3. Press @ to view the detailed information.

4. To update information, press Edit.

Calling from the contact list

1. Press D or press Menu > Address Book > Contacts.

2. Select a person to call.

3. Press

Forwarding contact details

1. Press D or press Menu > Address Book > Contacts.

2. Select a contact > Options > Send This Card.

3. You can send the information using Multimedia Message or Bluetooth.

Deleting a contact

1. Press D or press Menu > Address Book > Contacts.

2. Select a contact > Options > Delete.

Adding a contact

1. Press Menu > Address Book > Add Contact.

2. Select Phone or SIM.

3. Input the fields.

4. Press @ or Save.

Making groups

1. Press Menu > Address Book > Groups.

2. You can select group either on phone or SIM. There will be defaulted groups.

3. To add new group, press Options > Add Group.

4. To edit group press, Edit Group. You can also set a specific ringtone by selecting Ringtone > Select > select the ringtone.

Caller identification

Caller identification N

1. Press Menu > Settings > Call > Display My Number.

2. Select Network Default, Show or Hide > Select.

Using your headset

You can send or receive a call using your headset. When you connect your headset to the jack the button on the headset works as follows.

note:

You need to use the headset designed for this device,

and it is optional item. Also not every headset has a button.

While in standby mode

1. Press the button once to list recent calls.

2. Press the button twice to redial the last call.

While the phone is closed

1. Press the button once to receive a call.

2. Press the button once to end the call.

Service numbers and fixed dialing

Calling your service numbers

You can see the service number to reach the service provider.

1. Press Menu > Address Book > Service Numbers.

2. Select a number > press

Viewing the fixed dialing list

Fixed dialing is a service that limits your access to specific numbers in the address book list recorded on the SIM. Input the PIN2 to set up or cancel this service.

1. Press Menu > Address Book > FDN List.

2. Select a number > press

note:

PIN2 must be correctly entered within 3 attempts. If you input the incorrect code three times in a row the PIN2 code will be blocked. If the PIN2 code is blocked please contact your service provider. PIN2 code supplied with the SIM card.

Calls & address book

Reveal

Getting Started

Calls and address book

Messaging

Multimedia

Useful Features

Connectivity

Settings

Appendix

Messaging

Entering text

Messaging

Receiving messages

Creating and sending text messages

Creating multimedia messages

Message templates

Message settings

Voice message settings

Using instant messenger

Entering text

You can enter text with multi-tap, predictive, numeric or symbol.

Useful keys

Functions only work when the slide is closed.

Display symbols

Adding space

Press to change capital mode Press to change ab Ab AB and press to change from multi to predictive to Number

Multi-tap

dbc

(all small caps / first letter caps

/ all caps) Predictive

gef

(all small caps / first letter

caps / all caps) Number

For details on using QWERTY key pad, see page 20.

Key characters by language

Each of the following keys will scroll through these sequential options listed by language.

Key English French Spanish

1 . , - ? ! / ' @ : 2

abc ç à ä á ã ç

def é è é

ghi í

jkl

mno ö ñ ó ñ

pqrs ß

tuv ù ü ú ü

wxyz

Predictive mode

The predictive mode automatically compares your keystrokes with an internal linguistic dictionary to determine the correct word. It will display the most commonly used word first. The most commonly used word will appear first. To save a word not listed in phone's dictionary, press Options > Predictive

Settings > Selection List > On.

1. Press

to change the mode to predictive.

2. Press

to input text. For example, to write

‘hello’ press

4 3 5 5 6

Messaging

Alphabet input mode

Press the key labeled with the target letter once for the first letter; press it twice for the second letter, and so on.

1. Press

to change the mode as multi-tap.

2. Press

to input text repeatedly. To write the

letter “C”, press

3 times. To write number 2 press

4 times.

Numeric mode

You can input numbers in this mode.

1. Press

to change the mode to 123.

2. Press

and

to input numbers.

Symbol mode

You can input symbols.

1. Press

to view the symbols.

2. Press

U/D/L/R

to select symbol and press Insert.

Messaging

You can send, receive and save the text messages and multimedia messages.

Managing memory

When the message box is full the messages full icon will appear. All messages share memory.

When It means

Text message is full

(SIM and Phone messages)

Moving a message to SIM

1. Press Menu > Messaging > Inbox.

2. Select a message > Options > Move to SIM.

Deleting a message in a mailbox

1. Select a message > Options > Delete > Selected > @.

Deleting multiple messages

1. Press Options > Delete > Multiple.

2. Select the message to erase by pressing @.

3. Press Options > Delete.

4. To select all message, press Options > Select All.

5. To deselect message, press Options > Deselect All.

Replying to a message

1. Select a message > Options > Reply.

Viewing memory space information

1. Press Menu > Messaging > Used Space.

2. Press

L/R

to view SIM and Phone memory.

Receiving messages

Viewing a new message

1. Press View or press @.

Reading a message from the inbox

1. Press Menu > Messaging > Inbox.

2. Select a received message > View.

Saving the sender address from a received message

1. Select a received message > View.

2. Press Options > Save.

3. Select New Contact or Update Contact.

Saving the object in the received multimedia message

1. Open the multimedia message.

2. Select an object.

3. Press Options > Use > Save.

It will be saved in one of the categories in the My Stuff folder.

For details on photo album, see page 50.

Listening to voice message

1. Press and hold

or press Menu > Messaging >

Voice Mail.

It will automatically call the voice mail center.

Loading URL using Push message

1. Press Menu > Messaging > Inbox > @.

2. Press Options > Load URL.

Save connection setting using Configuration message

1. Press Menu > Messaging > Inbox > @.

2. Press Options > Install.

Messaging

Creating and sending text messages

Sending new text message

1. Press U or press Menu > Messaging > Create Message.

2. Write the message.

3. To save the message as draft, press Options > Save to

Drafts.

4. Press > Send to and select the person to send message and press Select or

5. Press Send.

6. To view sent message, press Menu > Messaging > Sent.

note:

All successfully send messages will be saved in Sent while the messages that failed to be sent will save in the

Outbox.

Finding all sent messages

1. Press Menu > Messaging > Sent.

Creating multimedia messages

You can create new multimedia message. Capacity is 100Kb, 300Kb, 600Kb and an error message will alert you once you exceed the capacity.

Adding a saved picture to the message

1. Press U or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Insert > Picture > Picture > Camera.

4. Scroll to the saved picture and press Select or

5. To preview the current page, press Options > Preview >

Current.

6. To preview the whole message, press Options > Preview > Whole Message. To go back to text editor page, press

Stop.

7. To edit the text message, press [U/D] to select the text box.

8. Press Send to and select the person to send message and press Select or @.

9. Press Send.

Adding a new picture to the message

1. Press U or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Insert > Take New Picture.

4. Focus on the object > @.

5. To preview the current page, press Options > Preview >

Current.

6. To preview the whole message, press Options > Preview > Whole Message. To go back to text editor page, press

Stop.

7. To edit the text message, press [

U/D

] to select the text

box.

8. Press Send to and select the person to send message and press Select or @.

9. Press Send.

For the taking picture, see page 49.

Adding a saved video to the message

1. Press U or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Insert > Video > Video.

4. Scroll to the saved video clip and press Select or @.

5. To preview the current page, press Options > Preview >

Current.

6. To preview the whole message, press Options > Preview > Whole Message. To go back to text editor page, press

Stop.

7. To edit the text message, press [

U/D

] to select the text

box.

8. Press Send to and select the person to send message and press Select or

9. Press Send.

Adding a new video to the message

1. Press U or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Insert > Record New Video.

4. Focus on the object > Options > Record.

5. To stop recording and save press Stop.

6. To edit the text message, press [U/D] to select the text box.

7. To preview the current page, press Options > Preview >

Current.

8. To preview the whole message, press Options > Preview > Whole Message. To go back to text editor page, press

Messaging

Stop.

9. Press Send to and select the person to send message and press Select or @.

10.Press Send.

For the recording video, see page 50.

Adding a recorded voice memo to the message

1. Press U or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Insert > Sound.

4. Select Audio > My Voice.

5. Scroll to the saved audio clip and press Select or

6. To edit the text message, press [U/D] to select the text box.

7. To preview the current page, press Options > Preview >

Current.

8. Press Pause to stop listening.

9. To preview the whole message, press Options > Preview > Whole Message. To go back to text editor page, press

Stop.

10. Press Send to and select the person to send message

and press Select or @.

11.Press Send.

Adding a new voice memo to the message

1. Press U or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Insert > Record New Sound.

4. Press Record or @ to record the sound.

5. To stop and save press Stop.

6. To edit the text message, press [U/D] to select the text box.

7. To preview the current page, press Options > Preview >

Current.

8. Press Pause to stop listening.

9. To preview the whole message, press Options > Preview > Whole Message. To go back to text editor page, press

Stop.

10. Press Send to and select the person to send message

and press Select or

11.Press Send.

For the recording voice memo, see page 63.

Adding other file to the message

1. Press U or press Menu > Messaging > Create Message.

2. Write a message.

3. Press Insert > Other Files > Other Files.

4. Select the file and press Select or @.

5. To edit the text message, press [U/D] to select the text box.

6. To preview the current page, press Options > Preview >

Current.

7. To preview the whole message, press Options > Preview > Whole Message. To go back to text editor page, press

Stop.

8. Press Send to and select the person to send message and press Select or

9. Press Send.

Message templates

When you often use the same phrases, you can save the message under template messages.

Adding the message as a template

1. Press Menu > Messaging > Templates.

2. Press Options > Add New.

3. Write the frequently used message > Options > Save.

Sending a message with template

1. Press Menu > Messaging > Templates.

2. Select the message to send.

3. Press Send or @ to add more messages.

4. Press Send to and select the person to send message and press Select or @.

5. Press Send.

note:

You can add a template while entering a message. Write a message > Insert > Templates. Select the message to add.

Message settings

Setting message center

1. Press Menu > Messaging > Settings.

2. Press Text Message.

3. Enter new Center Address.

4. Press Save.

Setting profiles for multimedia message

1. Press Menu > Messaging > Settings.

2. Press Multimedia Message > MMS Profiles.

3. Select a profile.

Messaging

note:

When you receive push message the [ ] icon will displays.

Voice message settings

Setting for receiving voice message

1. Press Menu > Messaging > Settings.

2. Press Voice Mail.

3. Enter the number of the voice mail center > Save.

note:

This number may be pre-con gured by the service provider upon activation.

You can receive emails from your service provider.

Receiving an email

1. Press Menu > Messaging > Mobile Email.

2. Select an email > @.

Using instant messenger

Use Instant Messenger (IM) to send and receive short, simple messages that are delivered immediately.

Setting for sending multimedia message

1. Press Menu > Messaging > Settings.

2. Press Multimedia Message > Sending Settings.

3. You can set the Validity Period, Delivery Time, Priority,

Creation Mode and Max Message Size.

Setting for receiving multimedia message

1. Press Menu > Messaging > Settings.

2. Press Multimedia Message > Receiving Settings.

3. You can set the Automatic Download, Allow Delivery

Reply, Allow Read Reply and Accepted Messages.

Setting e-mail gateway

1. Press Menu > Messaging > Settings.

2. Press Email Gateway.

3. Enter new gateway for sending text message by email address.

4. Press Save.

Setting for receiving notice for push message

1. Press Menu > Messaging > Settings.

2. Press Push Message > Receive.

3. Select On or Off.

Starting an instant messenger

1. Press Menu > Messaging > IM.

2. Select the IM application > Select.

3. Enter login and password > Sign In.

Viewing the conversation log

You can view the conversations log in the Instant Messenger Saved History.

Messaging

Reveal

Getting Started

Calls and address book

Messaging

Multimedia

Useful Features

Connectivity

Settings

Appendix

Multimedia

Camera Photo album Video album Audio album Music player

Music player settings

Media player

Other files

Managing memory

Playing games

Camera

You can take pictures and record movies using the built-in camera. The photos and video clips can be saved and sent via multimedia messages.

In the options menu for camera

Icons Name Description

White Balance

Auto ( ), Day Light ( ), Tungsten ( ), Fluorescent ( )

Effect

Normal ( ), Sepia ( ), Negative ( ), B&W ( )

Self Timer Off ( ), 5 secs ( ), 10 secs ( )

Picture Size

1280x1024(

), 1024x768 ( ), 640x480

(

), 320x240 ( )

Advanced

Picture Quality, Save Location, Shutter Sound, Timer Sound, Default File Name

In the options menu for video camera

Icons Name Description

White Balance

Auto ( ), Day Light ( ), Tungsten ( ), Fluorescent ( )

Effect

Normal ( ), Sepia ( ), Negative ( ), B&W ( )

Self Timer Off ( ), 5 secs ( ), 10 secs ( )

Resolution

176x144 (MMS) (

), 176x144 ( ), 320x240 ( ), Video Share( )

Setting camera settings

1. Press Menu > My Stuff > Tools.

2. Press Camera.

3. Press Options > Settings to change settings prior to

taking a picture.

Options Back

(1226)

Video mode

White balance

Zoom

Brightness

Self Timer

Remain

Camera mode

Effect

Size

Multimedia

Icons Name Description

Advanced

Video Quality, Sound Recording, Save Location, Timer Sound, File Format, Default File Name

Zoom in and out

1. Press

U/D

. It ranges from x1 to x4.

Increasing or decreasing the brightness

1. Press

L/R

. It ranges from -2 to +2.

Taking a picture

1. Press

in standby mode or press Menu > My Stuff >

Tools.

2. Press Camera.

3. Focus on the object > @ or press Options > Capture.

note:

Your photo will be saved automatically to My Stuff >

Picture > Camera.

Changing to video camera mode

1. Press

in standby mode or press Menu > My Stuff

>Tools > Camera.

2. Press Options while camera mode is activated.

3. Press Video Camera Mode.

4. Focus on the object >

or press Options > Record.

5. Record the motion > Stop.

note:

Your video will be saved automatically to My Stuff

> Video.

Viewing the taken picture

1. Press

in standby mode or press Menu > My Stuff >

Tools > Camera.

2. Press Options > Photo Album.

3. Select the picture > @.

After taking pictures

To Press

Send a multimedia message

Options > Send > as Multimedia Message

Send using Bluetooth Options > Send > via Bluetooth

Upload photos on the web Options > Send > to HP’s Snapfish

Set as wallpaper Options > Set as > Wallpaper

Set as address book Options > Set as > Caller ID

Delete Options > Delete

Rename Options > Rename

To Press

View photo’s information Options > Properties

Recording a video

1. Press Menu > My Stuff > Tools > Video Camera.

2. Focus on the object > @ or press Options > Record.

3. Press Stop to stop.

4. Press Options > Play to play the video clip.

5. Press

to go back to preview mode.

Changing to camera mode

1. Press Menu > My Stuff > Tools > Video Camera.

2. Press Options while video camera mode is activated.

3. Press Camera Mode.

For details on taking a picture, see page 49.

Viewing the recorded video clip

1. Press Menu > My Stuff > Tools > Video Camera.

2. Press Options > Video Album.

3. Select the video clip > @.

After saving recorded video clips

To Press

Send a multimedia message

Options > Send > as Multimedia Message

Send using Bluetooth Options > Send > via Bluetooth

View recorded video clip Options > Play

Delete Options > Delete

Rename Options > Rename

View the information Options > Properties

During recording a video

To Press

Receive an incoming call

Stop recording Stop

Photo album

ou can view, send, save to your phone or an external memory

card and also delete photos. JPEG format is supported, and other formats are saved in the Picture folder.

note:

To access Picture, press Menu > My Stuff > Picture.

Multimedia

Viewing the saved pictures

1. Press Menu > My Stuff.

2. Press Picture > Camera.

3. Select a picture > @.

Setting as wallpaper in the display

1. Press Menu > My Stuff.

2. Press Picture > Camera.

3. Select a picture > Options > Set as > Wallpaper.

Setting as caller identification

1. Press Menu > My Stuff.

2. Press Picture > Camera.

3. Select a picture > Options > Set as > Caller ID.

Sending pictures using multimedia message

1. Press Menu > My Stuff.

2. Press Picture > Camera.

3. Select a picture.

4. Press Options > Send > as Multimedia Message.

For details on creating multimedia message, see page 39.

Uploading pictures on the web

1. Press Menu > My Stuff.

2. Press Picture > Camera.

3. Select a picture > Options > Send > to HP’s Snapfish.

Deleting multiple pictures

1. Press Menu > My Stuff.

2. Press Picture > Camera.

3. Press Options > Multiple Select.

4. Press

to select more than one picture.

5. Press @ to unselect.

6. Press Options > Delete.

Viewing file information

1. Press Menu > My Stuff.

2. Press Picture > Camera.

3. Select a picture.

4. Press Options > Properties.

Video album

You can view, send, save and delete videos.

Playing the saved video clips

1. Press Menu > My Stuff.

2. Press Video.

3. Select a video clip >

Using video player controls

To Press

Pause

Play

Rewind

Hold

Fast forward

Hold

Control volume

Side key up or down or

U/D

Sending video clip using multimedia message

1. Press Menu > My Stuff.

2. Press Video.

3. Select a video clip.

4. Press Options > Send > as Multimedia Message.

For details on creating multimedia message, see page 39.

Deleting multiple video clips

1. Press Menu > My Stuff.

2. Press Video.

3. Press Options > Multiple Select.

4. Press @ to select more than one video.

5. Press @ to unselect.

6. Press Options > Delete.

Audio album

You can play, send, delete, moves to external memory or to phone the saved sounds. The supported formats are MP3, AAC, AAC+, and WMA.

Listening the recorded sound

1. Press Menu > My Stuff > Audio.

2. Press My Voice > select a sound > @.

Using sound controls

To Press

Play & Pause

Stop Options > Stop

Rewind

Hold

Multimedia

To Press

Fast forward

Hold

Control volume

Side key up or down or

U/D

Setting as a ring tone

1. Press Menu > My Stuff > Audio.

2. Select a sound > Options > Set as Ring Tone.

Moving or copying multiple sound to external memory

1. Press Menu > My Stuff > Audio.

2. Select a sound and press Options > Multiple Select.

3. Press @ to select more than one sound file.

4. Press Options > Copy to External Memory or Move to

External Memory. The selected sound will copy to Audio

folder in external memory card.

Sending sound file using multimedia message

1. Press Menu > My Stuff > Audio.

2. Select a sound file.

3. Press Options > Send > as Multimedia Message.

Music Player

You can listen MP3 and audio files even your device is closed. It can be only play audio files saved in MP3, .AAC, .AAC+, and .WMA.

When It means

Music is playing

Music has been paused

Music has been stopped

note:

microSD card must be inserted to transfer music to

your device.

Adding music from Windows Media Player

™

1. Connect the USB cable to the device and the computer.

2. Select Music Player > Yes.

3. Open the Sync tab in Windows Media PlayerTM in your computer.

4. Select the music from the list and drag and drop to your device.

note:

Windows Media PlayerTM 10, 11 and Window XP

version is required.

Playing the music

1. Press Menu > AT&T Music > Music Player.

2. Select the categorize using

U/D

to play the music.

3. Select the file using

U/D

then press @.

4. Press Options > Add to Playlist to add to the playlist.

5. Press Options > Stop to stop playing.

note:

Music will pause when you receive an incoming call

and Music will resume when the call ends.

Icons for player

Icon Name Description

Volume 7 Pause

Play Fast Rewind

Fast Forward

Long Press : Fast Rewind, Fast Forward

Previous Track Next Track

Short Press : Previous, Next

Icon Name Description

Repeat all tracks

Repeat off Repeat Single

Track

Shuffle On / Off

ON: the current list of songs are randomly shuffled for playback OFF: songs play in order and are not shuffled

Making playlist

1. Press Menu > AT&T Music > Music Player.

2. Press Playlists > New Playlist.

3. Input Playlist Name.

4. Select All Music, Albums, Artists or Genres.

5. Select the music file using [

U/D

] then press @ to add to

playlist.

6. Press Done > Saved.

Add music to playlist

1. Press Menu > AT&T Music > Music Player.

2. Press Playlists.

Multimedia

3. Select the playlist to add music > Options > Add Tracks.

4. Select the music to add > @ > Done.

5. To remove tracks press Options > Remove Tracks >

select the music by pressing @ > Remove.

6. To rename the playlist press Options > Rename Playlist.

7. To delete the playlist press Options > Delete.

Listening music with Bluetooth headset

1. While music is playing in the standby mode, press Menu >

AT&T Music > Music Player.

2. Press Now Playing > Options > Transfer to B/T

Headset.

Viewing the information

1. Press Menu > AT&T Music > Music Player.

2. Select the categorize using [

U/D

] to play the music.

3. Select the file using [

U/D

] then press @.

4. Press Options > Properties.

5. Use [

U/D

] to view Title, Artist, Album, Genre, Duration,

File Name, File Size, Location, Format, Bit Rate, Created, License and Sharing.

Setting as ringtone

1. Press Menu > AT&T Music > Music Player.

2. Select the categorize using [

U/D

3. Select the file using [

U/D

4. Press Options > Set as Ring Tone.

note:

During playing the music the  le can not be set as ring tone. You cannot set a  le which is larger than 300 Kb as a ringtone.

Deleting music

1. Press Menu > AT&T Music > Music Player.

2. Select the music from the list.

3. Press Options > Delete.

note:

If the music is playing you cannot delete.

Shopping the music

1. Press Menu > AT&T Music.

2. Press Shop Music.

3. To go to previous page press C.

Using music identification

1. Press Menu > AT&T Music.

2. Press MusicID.

3. Hold the phone close to the music. Your phone will analyze the music and display the artist, title and album.

note:

For the cost plan contact your nearest carrier.

Listening the radio

1. Press Menu > AT&T Music.

2. Press XM Radio.

Watching the music video

1. Press Menu > AT&T Music.

2. Press Music Videos.

Viewing Billboard information

1. Press Menu > AT&T Music.

2. Press Make – UR – Tones.

Launching to community

1. Press Menu > AT&T Music.

2. Press Community.

Launching more applications

1. Press Menu > AT&T Music.

2. Press Music Apps.

Music player settings

Shuffling music

1. Press Menu > AT&T Music > Music Player.

2. Press Settings.

3. Select Shuffle.

4. Select Shuffle On or Shuffle Off > @.

Repeating the music

1. Press Menu > AT&T Music > Music Player.

2. Press Settings.

3. Select Repeat.

4. Select Repeat All Tracks, Repeat Single Track or

Repeat Off > @.

Setting equalizer

1. Press Menu > AT&T Music > Music Player.

2. Press Settings.

3. Select Equalizer.

4. Select the category by using

L/R

> @.

Auto Full Screen

1. Press Menu > AT&T Music > Music Player.

Multimedia

Background skin

Options Back

Video image Playing time

Duration

Player control

Volume controls

Icons for player

Icon Name Description

Volume Previous

Long Press : Fast Rewind, Fast Forward

Pause Play

Repeat On

2. Press Settings.

3. Select Auto Full Screen.

4. Select Auto Full Screen On or Auto Full Screen Off >

Removing

1. Press Menu > AT&T Music > Music Player.

2. Press Settings.

3. Select Remove.

4. Select License Data File or All Music Contents >

Media player

You can play video clips with the media player.

note:

Do not use this feature illegally. Sound and video can be protected by copyright. It is illegal to copy such sound / video tracks for the purpose of selling or distribution. Pantech does not in any way support the unauthorized use of content on your phone media player.

Playing the video clip

1. Press Menu > My Stuff.

2. Press Tools > Media Player.

3. Press Video.

4. Select a file > Play or

5. Select a file > Options > Send or Rename or Multiple

Select or Delete or Delete All or Properties or View by Grid.

Playing the audio file

1. Press Menu > My Stuff.

2. Press Tools > Media Player.

3. Press Audio.

4. Select the folder > select a file > Play.

For the audio player control see page 52.

Other files

You can manage files in unsupported formats saved on your phone. It also lists files received via Bluetooth from other devices.

Viewing the list of the files

1. Press Menu > My Stuff.

2. Press Other Files.

Managing memory

Viewing memory status

1. Press Menu > My Stuff.

2. Press Used Space.

3. Use

U/D

to view the information.

Playing games

You can download games to play with. It is easy to download and you can preview them beforehand. You will only be able to view games that are available on your mobile.

Shop games

1. Press Menu > My Stuff.

2. Press Games.

3. Select Shop Games > Select.

4. Play the demo and press BUY to download the complete game.

Multimedia

Reveal

Getting Started

Calls and address book

Messaging

Multimedia

Useful Features

Connectivity

Settings

Appendix

Useful Features

Alarm

Calendar

Notepad and voice memo

Calculator, tip calculator and converter

Stop watch

Business card

Memory information

Alarm

Setting an alarm

1. Press Menu > My Stuff > Tools > Alarms.

2. Press Select for new alarm for the first time.

3. Set the Cycle, Time, Alarm Sound, Alert Type, Volume,

Snooze and Power Alarm > Save.

Viewing the saved alarms

1. Press Menu > My Stuff > Tools > Alarms.

Editing existing alarms

1. Press Menu > My Stuff > Tools > Alarms.

2. Select an alarm > Edit.

3. Press Options > Delete to delete an alarm.

4. Press Options > Create New to add new alarm.

Setting a simple alarm

1. Press Menu > My Stuff > Tools > Alarms.

2. Select Simple Alarm > Edit.

3. Set the alarm schedule and press Save.

Calendar

Calendar helps you manage your schedule including your time for calls or special days. You can set a reminder on any given date with this function.

Viewing calendar

1. Press Menu > My Stuff > Tools > Calendar.

note:

Monthly view is displayed as default.

In the monthly view

To Press

Move to another day

for Previous

for Next

Move to another week

for Previous

for Next

Move to another month

Side key up for Previous Side key down for Next

Creating a new event and edit

1. Select a day > Options > New Event.

2. Select Schedule, Task or Note.

Useful Features

3. Input the events > Save.

note:

You can create events for dates from 01/01/2000 to

12/31/2099.

Notepad and voice memo

Using notepad

1. Press Menu > My Stuff > Tools > Notepad.

2. Press Select for the first time. To add new note press

Create New.

3. Write a message. Press Save or

Recording voice memo

1. Press Menu > My Stuff > Tools >

Voice Memo.

2. Press @ or Record.

3. Press Stop to stop recording. It will automatically save on My Voice.

Listening the recorded sound

1. Press Menu > My Stuff > Audio > My Voice.

2. Select a sound > Play.

Using sound controls

1. Press Menu > My Stuff > Tools > Voice Memo.

2. Select to Play.

To Press

Pause

Play

Stop Options > Stop

Control volume

Side key up or down or

U/D

Calculator, tip calculator and converter

Using the calculator

1. Press Menu > My Stuff > Tools >

Calculator.

2. Use [L/R/U/D/@] to calculate.

3. Press C to erase one digit.

4. Press Reset to reset.

5. Press

to use the decimal point.

Using tip calculator

1. Press Menu > My Stuff > Tools > Tip

Calculator.

2. Enter values for all variable fields (Bill($), Tip(%), Split) and the corresponding calculation fields (Tip($), Total($), You Pay) are updated automatically.

3. Press Reset to reset.

4. Press

to use the decimal point.

Using the converter

1. Press Menu > My Stuff > Tools >

Converter.

2. Select the categories

3. Select current unit and enter figure.

4. The result will be displayed in all other unit.

Stop watch

Using stop watch

1. Press Menu > My Stuff > Tools >

Stop Watch.

2. Press Start or @.

3. Press Stop to stop.

4. Press Continue to restart.

5. Press Reset to clear.

6. To change to lap time, press Mode > Lap Time Mode.

7. To split the stopwatch, press Mode > Split Time Mode.

Business card

You can send your information by sending it as multimedia message.

Creating your own business card

1. Press Menu > Address Book > My Business Card.

2. Edit the fields > Save or press @.

Forwarding

1. Press Menu > Address Book > My Business Card.

Useful Features

2. Press Options > Send This Card > Multimedia Message or Bluetooth.

3. Search for device or choose the device to send via

Bluetooth and press Select. Write a message for Multimedia Message.

4. Press Send to and select the person to send message and press Select or @.

5. Press Send.

Updating information

1. Press Menu > Address Book > My Business Card.

2. Press Edit.

3. Update information.

4. Press Save.

Memory information

You can view the information of your phone for Used, Audio,

Games, Applications, Picture, Video, Other Files and System.

Viewing the information

1. Press Menu > My Stuff > Used Space.

Reveal

Getting Started

Calls and address book

Messaging

Multimedia

Useful Features

Connectivity

Settings

Appendix

Connectivity

Bluetooth

Using the Mobile Web

Using the browser

Profile settings

Bluetooth

Bluetooth technology enables free wireless connections between electronic devices within a maximum range of 33 feet (10 meters). Bluetooth connection can be used to send images, text, business cards, calendar and notes or to connect to computers using Bluetooth technology. Your mobile phone supports:

• Connect to PC to access internet.

• Connect to Hands-Free.

• Connect to electronic devices.

Icons for Bluetooth

Bluetooth is active Transmitting file using Bluetooth Bluetooth is active and the headset is connected USB is connected

Activating

1. Press Menu > Settings > Connectivity > Bluetooth >

Activation.

2. Select On or Off.

Adding a device

1. Press Menu > Settings > Connectivity > Bluetooth > My

Devices.

2. Press Search or press @.

3. The available device will display.

4. To select the device press > Select. To view the details press View.

5. Enter password.

note:

The other device must be in pairing mode.

Sending an object

1. Select the file from Menu > My Stuff > Picture, Video,

Audio or Other Files.

2. Press Options > Send > via Bluetooth.

3. Press Search or press @.

4. Select the device > Select.

note:

If the other Bluetooth device requests pairing, the object is sent after pairing is completed. Locked object or ones containing original rights may not be forwarded.

Receiving an object

The receiving an object starts only when the receipt has been approved.

Connectivity

The received file will be saved in each place. For example, if you received contacts information from the sender, it will be saved in your phone’s memory.

Setting the visibility

1. Press Menu > Settings > Connectivity > Bluetooth >

Visibility.

2. Select Hide or Show.

Naming the phone

1. Press Menu > Settings > Connectivity > Bluetooth > My

Bluetooth Info.

2. Select the Name > Edit > edit the field > Save.

note:

This is what others will see in their device’s display

for your phone when searching for your device.

Using the Mobile Web

Accessing Mobile Web

1. Press @ in standby mode or press Menu > Mobile Web.

note:

It will access the Mobile Web homepage.

Using the browser

Accessing browser
