Self Stick (PPMA)
Size Code Pipe Diameter Marker Size UOM
A 3/4" to 1 1/4" 1" x 8" Each
B 1 1/2" to 2" 1 1/2" x 8" Each
D 2 1/2" to 6" 2 1/2" x 12" Each
H 8" to 10" 4" x 24" Each
Legend
Part
No.
1583
1585
1587
1589
1591
1593
1595
1597
1599
1601
1603
1605
1607
1609
1611
Legend
Part
No.
1613
1615
1617
1619
1621
1623
1625
1627
1629
1631
1633
1635
1637
1639
1641
Legend
Part
No.
1643
1645
1647
1649
1651
1653
1657
1659
1661
1663
1665
1667
1669
Snap On Pipe Markers (PPMS)
Size Code Pipe Diameter Marker Size UOM
A 3/4" to 1 1/4" 6" x 8" Each
B 1 1/2" to 2" 9" x 8" Each
C 2 1/4" to 3" 14" x 12" Each
E 3 1/4" to 5" 19" x 12"* Each
F 5 1/4" to 6" 25" x 12"* Each
*Have self-adhesive leading edge for secure fit
Legend
B2.
Cable
Accessories
B3.
Stainless
Steel Cable
Ties &
Accessories
C1.
Wiring
Duct
C2.
Abrasion
Protection
C3.
Cable
Management
D1.
Terminals
D2.
Power
Connectors
D3.
Grounding
Connectors
How to Order
Pipe Markers:
Select Material Code:
1
Self Stick – PPMA
Select Pipe Marker Base
2
Part Number:
1523
Select Size Code:
3
3/4" to 1 1/4" – A
Color Banding Pipe Marking Tapes Directional Flow Arrow Tapes
Variety of colors are ideal for coding pipes.
• 0.005" tapes with self-adhesive back, no liner
• Service temperature range -20° to 140°F
• Available in 1", 2" and 3" widths
• 108-ft. rolls
Available colors with color code:
Red – RED, Green – GRN, Blue – BLU, Gray – GRY, Brown – BRN,
Black – BLK, Yellow – YEL, Orange – ORN, White – WHT, Purple – PUR
To Order: Add color code after part number.
Example: Part No. PFM1X36 + Color Code YEL = PFM1X36YEL
Part No. Size UOM
PFM1X36 1" x 108-ft. Roll
PFM2X36 2" x 108-ft. Roll
PFM3X36 3" x 108-ft. Roll
Provide 360° visibility for fl ow direction, with repeated arrows on the
tape’s length.
• 0.006" self-adhesive vinyl
• Available in 1", 2" and 4" widths
• 54-ft. and 108-ft. rolls
Available colors with color code:
Black/Yellow – BY, Green/White – GW, Blue/White – BLW,
Red/White – RW, Black/Orange – BO, White/Brown – WBR
To Order: Add color code after part number.
Example: Part No. PPMR1X54 + Color Code BY = PPMR1X54BY
Part No. Size UOM Part No. Size UOM
PPMR1X54 1" x 54-ft. Roll PPMR1X108 1" x 108-ft. Roll
PPMR2X54 2" x 54-ft. Roll PPMR2X108 2" x 108-ft. Roll
PPMR4X54 4" x 54-ft. Roll PPMR4X108 4" x 108-ft. Roll
Combine Codes in Speci c Order
4
for Complete Part Number:
PPMA1523A
Meets ASME
A13.1, 3.1
