Panduit EA001 Selection Guide

Download
Best in Class Outlet Density
TM
TM
TM
Optimal Form Factors
Superior Reliability
iPDU Pocket Guide
NORTH AMERICA
TM
Welcome to the Panduit G5 Series
Quality & Reliability
3-Year standard & 5-Year extended warranty.
High Temp
Built with high-temperature grade premium components to withstand 60°C high temperature at full load for extended period to provide
high quality and reliability.
High Density Power
Unique outlets design for high power density & compact form-factors minimizing cabinet space.
HotSwappable & Upgradable
Hot-Swappable Controller with large OLED display and high contrast ratio.
Hardened Security
Enhanced security w/ (SNMPv3 & RESTful/
TLS) with certicate-based
advanced asymmetric encryption, validated and hardened with multiple security scanning tools.
1G Redundant Network Access
High Networking speed (1G) with Redundant Network Access (RNA) for connectivity redundancy or for allowing separate Colo/Tenant Network connectivity.
Real-Time Monitor
Real-time Monitoring of Power, Environmental & Physical Access Security.
Environmental Plug and Play Sensors
Variety of Plug and Play Environment & Access Security accessories thru U-Ports.
Multi-Device WebGUI
Enhanced User-Experience w/ BYOD WebGUI & colored PDU, cords & cable ties.
Multi-Color
A variety of colored PDU chassis, power cords & cable ties.
2
Product Families
Monitored Input (MI Series)
Rack PDUs that have the ability for aggregate power monitoring to quickly identify potential power issues, and reclaim available or under­utilized power capacity.
Monitored Switched (MS Series)
Rack PDUs that have the ability for aggregate power monitoring and outlet level switching capabilities for individual outlets or a group of outlets. Enabling power sequencing, rebooting equipment or restrict unauthorized use of individual outlets.
Monitored Per Outlet (MPO Series)
Rack PDUs that have the ability for outlet level power monitoring to quickly identify potential power issues, and reclaim available or under­utilized power capacity at the outlet level enabling the redeployment or decommissioning of individual servers to reclaim available or under­utilized power capacity.
Monitored and Switched Per Outlet (MSPO Series)
Rack PDUs that have the ability for outlet level power monitoring and outlet level switching capabilities for individual outlets or a group of outlets. Power monitoring at the individual outlet level provides actionable management data on the power consumption of each connected IT device enabling the redeployment or decommissioning of individual servers to reclaim available or under-utilized power capacity.
Accessories
Offering a variety of Environmental Sensors; Security Devices; and Power Cords.
3
High Density
Outlet conguration allows
full length SKU’s t within
42U rack with top, bottom,
or front exit cable
Best-in-Class Billing
Grade Accuracy
+/- 1% throughout
entire range of
operational spec
G5 iPDU
Hot Swappable
Network Module
With large OLED and graphic bars for easy
Phases Load Balancing
Low Prole Design
Industry leading
design saves rack
space and ensures
good access
Designed for
High Temperature
Safe, Reliable Operation
at 60°C with Full Load
Rating
4
Daisy Chain Capabilities
Up to 4 PDUs
And 32 sensors
1G Redundant Network
Access (RNA)
In 2N conguration for
network redundancy or
CoLo/Tenant use
1-Phase
Color Coded Outlets and Circuit Breakers
For easy source
Identication
USB Port
FW Upgrade,
rack light strip
Environmental & Security
Ready with support for up to 8
digital plug-and-play sensors or
proximity card access
Power and Energy
Metering
V, A, VA, W, KWh, PF
Premium Hydraulic-
Magnetic Circuit Breakers
Stable trip characteristics at
extreme temperatures
Locking IEC Outlets
Provide secure power
connection with optional
locking cords or integrated
locking features
5
Monitored Input
(MI Series)
Input
Current
per phase Form Factor Input Plug Type
15 1U 5-15P 1.4 8 (8)5-20R 1.7 17.5 10.6 P08D09M
20 1U 5-20P 1.9 8 (8)5-20R 1.7 17.5 10.6 P08D10M
20 1U L5-20P 1.9 8 (8)5-20R 1.7 17.5 10.6 P08D11M
20 1U L6-20P 3.3 12 (12)C13 1.7 17.5 10.6 P12D13M
15 0U HALF 5-15P 1.4 16 (16)5-20R 32.2 2.0 2.1 P16D20M
20 0U HALF 5-20P 1.9 16 (16)5-20R 32.2 2.0 2.1 P16D21M
20 0U HALF L5-20P 1.9 16 (16)5-20R 32.2 2.0 2.1 P16D22M
100-240VAC, 1-Phase
30 0U MID L5-30P 2.9 24 (24)5-20R 58.7 2.0 2.1 P24D23M
20 0U MID L6-20P 3.3 24 (20)C13, (4)C19 58.7 2.0 2.1 P24D24M
30 2U L5-30P 2.9 16 (16)5-20R 3.4 17.5 10.6 P16D12M
50 1U CS8265C 8.3 6 (6)C19 1.7 17.5 10.6 P06D15M
30 2U L6-30P 5.0 16 (12)C13, (4)C19 3.4 17.5 10.6 P16D14M
30 0U MID L6-30P 5.0 24 (20)C13, (4)C19 58.7 2.0 2.1 P24D07M
30 0U FULL L6-30P 5.0 38 (32)C13, (6)C19 68.9 2.0 2.1 P38D25M
200-240VAC, 1-Phase
50 0U FULL CS8265C 8.3 36 (30)C13, (6)C19 68.9 2.0 2.1 P36D26M
Apparent
Power
(kVA)
Outlet Count Outlet Conguration
6
1-Phase
Length
(inches)
Width
(inches)
Depth (inches)
at Outlet position
Panduit
Part No.
7
Monitored Input
(MI Series)
Input
Current
per phase Form Factor Input Plug Type
30 1U L21-30P 8.6 6 (6)C19 1.7 17.5 10.6 P06D17M
30 0U MID L21-30P 8.6 24 (18)C13, (6)C19 58.7 2.0 2.1 P24D01M
30 0U FULL L21-30P 8.6 30
100-120/200-
240VAC, 3-Phase
30 0U FULL L21-30P 8.6 38
30 1U L15-30P 8.6 6 (6)C19 1.7 17.5 10.6 P06D16M
50 1U CS8365C 14.4 6 (6)C19 1.7 17.5 10.6 P06D18M
60 1U IEC 60309 3P+E 9h 17.3 6 (6)C19 1.7 17.5 10.6 P06D19M
30 0U MID L15-30P 8.6 24 (18)C13, (6)C19 58.7 2.0 2.1 P24D27M
30 0U FULL L15-30P 8.6 36 (30)C13, (6)C19 68.9 2.0 2.1 P36D08M
50 0U FULL CS8365C 10.0 36 (30)C13, (6)C19 68.9 2.0 2.1 P36D29M
50 0U FULL CS8365C 14.4 24 (12)C13, (12)C19 68.9 2.0 2.1 P24D31M
60 0U FULL IEC 60309 3P+E 9h 17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24D34M
208VAC, 3-Phase
50 0U HALF - 2 Sided CS8365C 14.4 24 (18)C13, (6)C19 36.0 2.0 4.4 P24D30M
60 0U HALF - 2 Sided IEC 60309 3P+E 9h 17.3 24 (18)C13, (6)C19 36.0 2.0 4.4 P24D33M
50 0U FULL - 2 Sided CS8365C 14.4 48 (36)C13, (12)C19 71.7 2.0 4.4 P48D32M
60 0U FULL - 2 Sided IEC 60309 3P+E 9h 17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48D35M
Apparent
Power
(kVA)
Outlet Count Outlet Type
8
Length
(inches)
Width
(inches)
Depth (inches)
at Outlet position
Panduit
Part No.
(18)C13, (6)C19, (6)5-20R
(30)C13, (6)C19, (2)5-20R
68.9 2.0 2.1 P30D02M
68.9 2.0 2.1 P38D28M
9
Monitored Input
(MI Series)
Input
Current
per phase Form Factor Input Plug Type
30 1U
30 1U
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
30 1U NEMA L22-30P 17.3 6 (6)C19 1.7 17.5 10.6 P06D02M
30 0U FULL
30 0U FULL
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
30 0U FULL NEMA L22-30P 17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24D04M
30 0U FULL
30 0U FULL
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
30 0U FULL NEMA L22-30P 17.3 36 (24)C13, (12)C19 68.9 2.0 2.1 P36D02M
30 0U FULL - 2 Sided
415VAC, 3-Phase
30 0U FULL - 2 Sided
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
30 0U FULL - 2 Sided NEMA L22-30P 17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48D02M
30 0U FULL - Wide NEMA L22-30P 17.3 48 (48)C13, 68.9 3.3 2.1 P48D03M
30 0U FULL - Wide
30 0U FULL - Wide
30 0U FULL +
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP67)
30 0U FULL + NEMA L22-30P 17.3 42 (36)C13, (6)C19 74.6 2.0 2.1 P42D07M
30 0U FULL +
IEC 60309 3P+N+E
6h 30A (IP44)
Apparent
Power
Outlet
(kVA)
Count Outlet Type
17.3 6 (6)C19 1.7 17.5 10.6 P06D01M
17.3 6 (6)C19 1.7 17.5 10.6 P06D03M
17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24D02M
17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24D05M
17.3 36 (24)C13, (12)C19 68.9 2.0 2.1 P36D01M
17.3 36 (24)C13, (12)C19 68.9 2.0 2.1 P36D03M
17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48D01M
17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48D07M
17.3 48 (48)C13, 68.9 3.3 2.1 P48D04M
17.3 48 (48)C13, 68.9 3.3 2.1 P48D08M
17.3 42 (36)C13, (6)C19 74.6 2.0 2.1 P42D05M
17.3 42 (36)C13, (6)C19 74.6 2.0 2.1 P42D08M
10
1-Phase
Length
(inches)
Width
(inches)
Depth (inches)
at Outlet position
Panduit
Part No.
11
Monitored Switched
(MS Series)
Input
Current
per phase Form Factor Input Plug Type
15 1U 5-15P 1.4 8 (8)5-20R 1.7 17.5 10.6 P08E14M
20 1U 5-20P 1.9 8 (8)5-20R 1.7 17.5 10.6 P08E15M
20 1U L5-20P 1.9 8 (8)5-20R 1.7 17.5 10.6 P08E16M
20 1U L6-20P 3.3 8 (8)C13 1.7 17.5 10.6 P08E18M
30 2U L5-30P 2.9 16 (16)5-20R 3.4 17.5 10.6 P16E17M
15 0U HALF 5-15P 1.4 12 (12)5-20R 36.1 2.0 2.1 P12E20M
20 0U HALF 5-20P 1.9 12 (12)5-20R 36.1 2.0 2.1 P12E21M
100-240VAC, 1-Phase
20 0U HALF L5-20P 1.9 12 (12)5-20R 36.1 2.0 2.1 P12E22M
20 0U HALF L6-20P 3.3 16 (12)C13, (4)C19 36.1 2.0 2.1 P16E24M
30 0U MID L5-30P 2.9 18 (18)5-20R 58.7 2.0 2.1 P18E23M
30 2U L6-30P 5.0 16 (12)C13, (4)C19 3.4 17.5 10.6 P16E19M
30 0U FULL L6-30P 5.0 24 (20)C13, (4)C19 68.9 2.0 2.1 P24E28M
1-Phase
30 0U FULL L6-30P 5.0 36 (30)C13, (6)C19 68.9 2.0 2.1 P36E33M
200-240VAC,
30 0U FULL L21-30P 8.6 24 (18)C13, (6)C19 68.9 2.0 2.1 P24E30M
3-Phase
100-120/
30 0U FULL L21-30P 8.6 36 (30)C13, (6)C19 68.9 2.0 2.1 P36E35M
200-240VAC,
30 0U FULL L15-30P 8.6 24 (18)C13, (6)C19 68.9 2.0 2.1 P24E29M
30 0U FULL L15-30P 8.6 36 (30)C13, (6)C19 68.9 2.0 2.1 P36E34M
50 0U FULL CS8365C 14.4 24 (12)C13, (12)C19 68.9 2.0 2.1 P24E31M
50 0U FULL CS8365C 10.0 36 (30)C13, (6)C19 68.9 2.0 2.1 P36E12M
60 0U FULL IEC 60309 3P+E 9h 17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24E32M
208VAC, 3-Phase
60 0U FULL - 2 Sided IEC 60309 3P+E 9h 17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48E13M
Apparent
Power
(kVA)
Outlet Count Outlet Type
12
Length
(inches)
Width
(inches)
Depth (inches)
at Outlet position
Panduit
Part No.
13
Monitored Switched
(MS Series)
Input
Current
per phase Form Factor Input Plug Type
30 0U FULL
30 0U FULL
30 0U FULL
30 0U FULL
30 0U FULL
30 0U FULL
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP44)
30 0U FULL NEMA L22-30P 17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24E06M
30 0U FULL NEMA L22-30P 17.3 24 (18)C13, (6)C19 68.9 2.0 2.1 P24E12M
30 0U FULL NEMA L22-30P 17.3 24 (24)C13 68.9 2.0 2.1 P24E13M
415VAC, 3-Phase
30 0U FULL - Wide
30 0U FULL - Wide
30 0U FULL - Wide
30 0U FULL - Wide
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP44)
30 0U FULL - Wide NEMA L22-30P 17.3 36 (24)C13, (12)C19 68.9 3.3 2.1 P36E02M
30 0U FULL - Wide NEMA L22-30P 17.3 36 (30)C13, (6)C19 68.9 3.3 2.1 P36E06M
Apparent
Power
Outlet
(kVA)
Count Outlet Type
17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24E05M
17.3 24 (18)C13, (6)C19 68.9 2.0 2.1 P24E07M
17.3 24 (24)C13 68.9 2.0 2.1 P24E08M
17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24E09M
17.3 24 (18)C13, (6)C19 68.9 2.0 2.1 P24E10M
17.3 24 (24)C13 68.9 2.0 2.1 P24E11M
17.3 36 (24)C13, (12)C19 68.9 3.3 2.1 P36E01M
17.3 36 (30)C13, (6)C19 68.9 3.3 2.1 P36E03M
17.3 36 (24)C13, (12)C19 68.9 3.3 2.1 P36E04M
17.3 36 (30)C13, (6)C19 68.9 3.3 2.1 P36E05M
14
1-Phase
Length
(inches)
Width
(inches)
Depth (inches)
at Outlet position
(table continues on next page)
Panduit
Part No.
15
Monitored Switched
(MS Series)
Input
Current
per phase Form Factor Input Plug Type
30 0U FULL - 2 Sided
30 0U FULL - 2 Sided
30 0U FULL - 2 Sided
30 0U FULL - 2 Sided
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP44)
30 0U FULL - 2 Sided NEMA L22-30P 17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48E02M
30 0U FULL - 2 Sided NEMA L22-30P 17.3 48 (48)C13 71.7 2.0 4.4 P48E14M
30 0U FULL - Wide + NEMA L22-30P 17.3 48 (48)C13 74.0 3.3 2.1 P48E04M
415VAC, 3-Phase
30 0U FULL - Wide +
30 0U FULL - Wide +
30 0U FULL - Wide +
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP67)
30 0U FULL - Wide + NEMA L22-30P 17.3 48 (42)C13, (6)C19 74.0 3.3 2.1 P48E06M
30 0U FULL - Wide +
IEC 60309 3P+N+E
6h 30A (IP44)
Apparent
Power
Outlet
(kVA)
Count Outlet Type
17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48E01M
17.3 48 (48)C13 71.7 2.0 4.4 P48E07M
17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48E08M
17.3 48 (48)C13 71.7 2.0 4.4 P48E09M
17.3 48 (48)C13 74.0 3.3 2.1 P48E03M
17.3 48 (48)C13 74.0 3.3 2.1 P48E11M
17.3 48 (42)C13, (6)C19 74.0 3.3 2.1 P48E05M
17.3 48 (42)C13, (6)C19 74.0 3.3 2.1 P48E12M
16
1-Phase
Length
(inches)
Width
(inches)
Depth (inches)
at Outlet position
Panduit
Part No.
17
Monitored Per Outlet
(MPO Series)
Input
Current
per phase Form Factor Input Plug Type
30 0U FULL L6-30P 5.0 24 (20)C13, (4)C19 68.9 2.0 2.1 P24F01M
1-Phase
30 0U FULL L6-30P 5.0 36 (30)C13, (6)C19 68.9 2.0 2.1 P36F15M
200-240VAC,
30 0U FULL L15-30P 8.6 24 (18)C13, (6)C19 68.9 2.0 2.1 P24F02M
30 0U FULL L21-30P 8.6 24 (18)C13, (6)C19 68.9 2.0 2.1 P24F03M
30 0U FULL L15-30P 8.6 36 (30)C13, (6)C19 68.9 2.0 2.1 P36F16M
30 0U FULL L21-30P 8.6 36 (30)C13, (6)C19 68.9 2.0 2.1 P36F17M
50 0U FULL CS8365C 14.4 24 (12)C13, (12)C19 68.9 2.0 2.1 P24F04M
50 0U FULL CS8365C 10.0 36 (30)C13, (6)C19 68.9 2.0 2.1 P36F18M
208VAC, 3-Phase
60 0U FULL IEC 60309 3P+E 9h 17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24F05M
60 0U FULL - 2 Sided IEC 60309 3P+E 9h 17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48F19M
Apparent
Power
(kVA)
Outlet Count Outlet Type
30 0U FULL
30 0U FULL
30 0U FULL
30 0U FULL
30 0U FULL
415VAC, 3-Phase
30 0U FULL
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP44)
17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24F09M
17.3 24 (18)C13, (6)C19 68.9 2.0 2.1 P24F11M
17.3 24 (24)C13 68.9 2.0 2.1 P24F12M
17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24F13M
17.3 24 (18)C13, (6)C19 68.9 2.0 2.1 P24F14M
17.3 24 (24)C13 68.9 2.0 2.1 P24F15M
30 0U FULL NEMA L22-30P 17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24F10M
30 0U FULL NEMA L22-30P 17.3 24 (18)C13, (6)C19 68.9 2.0 2.1 P24F16M
30 0U FULL NEMA L22-30P 17.3 24 (24)C13 68.9 2.0 2.1 P24F17M
18
Length
(inches)
Width
(inches)
Depth (inches)
at Outlet position
Panduit
Part No.
(table continues on next page)
19
Monitored Per Outlet
(MPO Series)
Input
Current
per phase Form Factor Input Plug Type
30 0U FULL - Wide
30 0U FULL - Wide
30 0U FULL - Wide
30 0U FULL - Wide
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP44)
30 0U FULL - Wide NEMA L22-30P 17.3 48 (24)C13, (12)C19 68.9 3.3 2.1 P36F02M
30 0U FULL - Wide NEMA L22-30P 17.3 48 (30)C13, (6)C19 68.9 3.3 2.1 P36F06M
30 0U FULL - 2 Sided
30 0U FULL - 2 Sided
30 0U FULL - 2 Sided
30 0U FULL - 2 Sided
415VAC, 3-Phase
30 0U FULL - 2 Sided NEMA L22-30P 17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48F02M
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP44)
30 0U FULL - 2 Sided NEMA L22-30P 17.3 48 (48)C13 71.7 2.0 4.4 P48F10M
30 0U FULL - Wide + NEMA L22-30P 17.3 48 (48)C13 74.0 3.3 2.1 P48F04M
30 0U FULL - Wide +
30 0U FULL - Wide +
30 0U FULL - Wide +
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP67)
30 0U FULL - Wide + NEMA L22-30P 17.3 48 (42)C13, (6)C19 74.0 3.3 2.1 P48F06M
30 0U FULL - Wide +
IEC 60309 3P+N+E
6h 30A (IP44)
Apparent
Power
Outlet
(kVA)
Count Outlet Type
17.3 48 (24)C13, (12)C19 68.9 3.3 2.1 P36F01M
17.3 48 (30)C13, (6)C19 68.9 3.3 2.1 P36F03M
17.3 48 (24)C13, (12)C19 68.9 3.3 2.1 P36F04M
17.3 48 (30)C13, (6)C19 68.9 3.3 2.1 P36F05M
17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48F01M
17.3 48 (48)C13 71.7 2.0 4.4 P48F07M
17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48F08M
17.3 48 (48)C13 71.7 2.0 4.4 P48F13M
17.3 48 (48)C13 74.0 3.3 2.1 P48F03M
17.3 48 (48)C13 74.0 3.3 2.1 P48F11M
17.3 48 (42)C13, (6)C19 74.0 3.3 2.1 P48F05M
17.3 48 (42)C13, (6)C19 74.0 3.3 2.1 P48F12M
20
1-Phase
Length
(inches)
Width
(inches)
Depth (inches)
at Outlet position
Panduit
Part No.
21
Monitored & Switched Per Outlet
(MSPO Series)
Input
Current
per phase Form Factor Input Plug Type
30 0U FULL L6-30P 5.0 24 (20)C13, (4)C19 68.9 2.0 2.1 P24G01M
1-Phase
30 0U FULL L6-30P 5.0 36 (30)C13, (6)C19 68.9 2.0 2.1 P36G18M
100-240VAC,
30 0U FULL L21-30P 8.6 24 (18)C13, (6)C19 68.9 2.0 2.1 P24G03M
3-Phase
100-120/
30 0U FULL L21-30P 8.6 36 (30)C13, (6)C19 68.9 2.0 2.1 P36G19M
200-240VAC,
30 0U FULL L15-30P 8.6 24 (18)C13, (6)C19 68.9 2.0 2.1 P24G02M
30 0U FULL L15-30P 8.6 36 (30)C13, (6)C19 68.9 2.0 2.1 P36G22M
50 0U FULL CS8365C 14.4 24 (12)C13, (12)C19 68.9 2.0 2.1 P24G04M
50 0U FULL CS8365C 10.0 36 (30)C13, (6)C19 68.9 2.0 2.1 P36G20M
60 0U FULL IEC 60309 3P+E 9h 17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24G05M
208VAC, 3-Phase
60 0U FULL - 2 Sided IEC 60309 3P+E 9h 17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48G21M
Apparent
Power
(kVA)
Outlet Count Outlet Type
30 0U FULL
30 0U FULL
30 0U FULL
30 0U FULL
30 0U FULL
415VAC, 3-Phase
30 0U FULL
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP44)
17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24G09M
17.3 24 (18)C13, (6)C19 68.9 2.0 2.1 P24G13M
17.3 24 (24)C13 68.9 2.0 2.1 P24G14M
17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24G15M
17.3 24 (18)C13, (6)C19 68.9 2.0 2.1 P24G16M
17.3 24 (24)C13 68.9 2.0 2.1 P24G17M
30 0U FULL NEMA L22-30P 17.3 24 (12)C13, (12)C19 68.9 2.0 2.1 P24G10M
30 0U FULL NEMA L22-30P 17.3 24 (18)C13, (6)C19 68.9 2.0 2.1 P24G18M
30 0U FULL NEMA L22-30P 17.3 24 (24)C13 68.9 2.0 2.1 P24G19M
22
1-Phase
Length
(inches)
Width
(inches)
Depth (inches)
at Outlet position
Panduit
Part No.
(table continues on next page)
23
Monitored & Switched Per Outlet
(MSPO Series)
Input
Current
per phase Form Factor Input Plug Type
30 0U FULL - Wide
30 0U FULL - Wide
30 0U FULL - Wide
30 0U FULL - Wide
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP44)
30 0U FULL - Wide NEMA L22-30P 17.3 36 (24)C13, (12)C19 68.9 3.3 2.1 P36G02M
30 0U FULL - Wide NEMA L22-30P 17.3 36 (30)C13, (6)C19 68.9 3.3 2.1 P36G06M
30 0U FULL - 2 Sided
30 0U FULL - 2 Sided
30 0U FULL - 2 Sided
30 0U FULL - 2 Sided
415VAC, 3-Phase
30 0U FULL - 2 Sided NEMA L22-30P 17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48G02M
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP67)
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP44)
30 0U FULL - 2 Sided NEMA L22-30P 17.3 48 (48)C13 71.7 2.0 4.4 P48G11M
30 0U FULL - Wide +
IEC 60309 3P+N+E
6h 30A (IP67)
30 0U FULL - Wide + NEMA L22-30P 17.3 48 (48)C13 74.0 3.3 2.1 P48G04M
30 0U FULL - Wide +
30 0U FULL - Wide +
IEC 60309 3P+N+E
6h 30A (IP44)
IEC 60309 3P+N+E
6h 30A (IP67)
30 0U FULL - Wide + NEMA L22-30P 17.3 48 (42)C13, (6)C19 74.0 3.3 2.1 P48G06M
30 0U FULL - Wide +
IEC 60309 3P+N+E
6h 30A (IP44)
Apparent
Power
Outlet
(kVA)
Count Outlet Type
17.3 36 (24)C13, (12)C19 68.9 3.3 2.1 P36G01M
17.3 36 (30)C13, (6)C19 68.9 3.3 2.1 P36G03M
17.3 36 (24)C13, (12)C19 68.9 3.3 2.1 P36G04M
17.3 36 (30)C13, (6)C19 68.9 3.3 2.1 P36G05M
17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48G01M
17.3 48 (48)C13 71.7 2.0 4.4 P48G07M
17.3 48 (36)C13, (12)C19 71.7 2.0 4.4 P48G08M
17.3 48 (48)C13 71.7 2.0 4.4 P48G10M
17.3 48 (48)C13 74.0 3.3 2.1 P48G03M
17.3 48 (48)C13 74.0 3.3 2.1 P48G12M
17.3 48 (42)C13, (6)C19 74.0 3.3 2.1 P48G05M
17.3 48 (42)C13, (6)C19 74.0 3.3 2.1 P48G13M
24
1-Phase
Length
(inches)
Width
(inches)
Depth (inches)
at Outlet position
Panduit
Part No.
25
Accessories
Environmental Sensors
Description:
Dimensions
L x W x H (in)
Length
(ft)
Panduit Part No.
Temperature Sensor 1.73x0.83x.43 6.56 EA001
Temperature + Humidity Sensor 1.73x0.83x.43 6.56 EB001
3 Temperature + Humidity Sensor 1.73x0.83x.43 6.56 EC001
Water - Rope 2.36x2.36x0.87 6.56 ED001
Water- Spot 2.36x2.36x0.87 16.40 EE001
3 Sensor Hub 3.35x1.26x1.06 n/a EF001
Water - Rope extension n/a 6.56 EG001
EA001
EE001
EB001
EF001
EC001
ED001
EG001
26
Security
Description:
Dimensions
L x W x H (in)
Door Switch (magnetic 2 piece) 1.73x0.83x0.43
(1.14x0.67x0.28
for magnet)
Access hub for handle
3.74x1.46x1.14 n/a ACB01
(cold & hot aisle selectable) Access hub harness cold aisle (ACE02) n/a 9.84 ACB02 Access hub harness hot aisle (ACE02) n/a 8.53 ACB03
Access hub harness cold aisle (ACE01) n/a 9.84 ACB04
Access hub harness hot aisle (ACE01) n/a 8.53 ACB05
Dry Contact Input 1.73x0.83x0.43 5.91 ACC01 USB Light Strip 15.04 n/a ACD01
Swinghandle No Card Reader n/a n/a ACE01
Swinghandle With Card Reader (125kHz)
Swinghandle With Card Reader
(13.5MHz)
n/a n/a ACE02
n/a n/a ACE03
Length
(ft)
Panduit Part No.
3.28 ACA01
ACA01
ACB04
ACE01 ACE02 ACE03
ACB01
ACB05
ACB02
ACC01
ACB03
ACD01
27
Accessories
W-Lock Dual Locking Power Cords
(UL, CE, VDE, TUV Approved)
Color Description Ratings
Red IEC C14 to IEC C13 10A/250V 17AWG / 1.0mm2 SJT/H05VV-F Straight 2 LPCA01X
Red IEC C14 to IEC C13 10A/250V 17AWG / 1.0mm2 SJT/H05VV-F Straight 3 LPCA02X
Red IEC C14 to IEC C13 10A/250V 17AWG / 1.0mm2 SJT/H05VV-F Straight 4 LPCA03X
Red IEC C14 to IEC C13 10A/250V 17AWG / 1.0mm2 SJT/H05VV-F Straight 6 LPCA04X
Blue IEC C14 to IEC C13 10A/250V 17AWG / 1.0mm2 SJT/H05VV-F Straight 2 LPCA06X
Blue IEC C14 to IEC C13 10A/250V 17AWG / 1.0mm2 SJT/H05VV-F Straight 3 LPCA07X
Blue IEC C14 to IEC C13 10A/250V 17AWG / 1.0mm2 SJT/H05VV-F Straight 4 LPCA08X
Blue IEC C14 to IEC C13 10A/250V 17AWG / 1.0mm2 SJT/H05VV-F Straight 6 LPCA09X
Black IEC C14 to IEC C13 10A/250V 17AWG / 1.0mm2 SJT/H05VV-F Straight 2 LPCA11X
Black IEC C14 to IEC C13 10A/250V 17AWG / 1.0mm2 SJT/H05VV-F Straight 3 LPCA12X
Black IEC C14 to IEC C13 10A/250V 17AWG / 1.0mm2 SJT/H05VV-F Straight 4 LPCA13X
Black IEC C14 to IEC C13 10A/250V 17AWG / 1.0mm2 SJT/H05VV-F Straight 6 LPCA14X
Gauge / Cross
Section Area Jacket
Connector
Angle
28
1-Phase
Length
(feet)
Panduit Part No.
(10 pk)
C14 C13
C14 C13
C14 C13
29
Accessories
W-Lock Dual Locking Power Cords
(UL, CE, VDE, TUV Approved)
Color Description Ratings
Red IEC C20 to IEC C19 16A/250V 15AWG / 1.5mm2 SJT/H05VV-F Straight 2 LPCB01X
Red IEC C20 to IEC C19 16A/250V 15AWG / 1.5mm2 SJT/H05VV-F Straight 3 LPCB02X
Red IEC C20 to IEC C19 16A/250V 15AWG / 1.5mm2 SJT/H05VV-F Straight 4 LPCB03X
Red IEC C20 to IEC C19 16A/250V 15AWG / 1.5mm2 SJT/H05VV-F Straight 6 LPCB04X
Blue IEC C20 to IEC C19 16A/250V 15AWG / 1.5mm2 SJT/H05VV-F Straight 2 LPCB06X
Blue IEC C20 to IEC C19 16A/250V 15AWG / 1.5mm2 SJT/H05VV-F Straight 3 LPCB07X
Blue IEC C20 to IEC C19 16A/250V 15AWG / 1.5mm2 SJT/H05VV-F Straight 4 LPCB08X
Blue IEC C20 to IEC C19 16A/250V 15AWG / 1.5mm2 SJT/H05VV-F Straight 6 LPCB09X
Black IEC C20 to IEC C19 16A/250V 15AWG / 1.5mm2 SJT/H05VV-F Straight 2 LPCB11X
Black IEC C20 to IEC C19 16A/250V 15AWG / 1.5mm2 SJT/H05VV-F Straight 3 LPCB12X
Black IEC C20 to IEC C19 16A/250V 15AWG / 1.5mm2 SJT/H05VV-F Straight 4 LPCB13X
Black IEC C20 to IEC C19 16A/250V 15AWG / 1.5mm2 SJT/H05VV-F Straight 6 LPCB14X
Gauge / Cross
Section Area Jacket
Connector
Angle
30
1-Phase
Length
(feet)
Panduit Part No.
(10 pk)
IEC C20 IEC C19
IEC C20 IEC C19
IEC C20 IEC C19
31
Complete Warranty & Compliance information can be found at www.panduit.com
Customer Service: cs@panduit.com or 800.777.3300
Technical Support: techsupport@panduit.com or 866.405.6654
©2019 Panduit Corp. ALL RIGHTS RESERVED.
Replaces PUCB20 PUCB23--SA-ENG 7/2019
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
