Modular Patch Panels
SELECTION GUIDE
An Extensive Selection of Patch Panels Supports
Your Application
Panduit offers an extensive selection of modular patch panels, with various styles and port densities and an
assortment of labeling options making them ideal for any installation. Select patch panels are available in a
standard White color option.
Modular patch panels accept all Mini-Com® Modules in copper, ber, and A/V, which snap in and out for easy moves,
adds, and changes. This modular system is ideal for multimedia applications, providing exibility to customize any
installation. All patch panels mount to standard EIA 19-inch or 23-inch racks with optional extender brackets.
A variety of accessories are available to optimize the installation. Strain relief bars are recommended for all installa-
tions to properly support cables exiting the back of the panel. Covers and blank panels promote proper airow and
cooling by lling unused rack openings.
Unshielded and Shielded
Unshielded Patch Panels
Unshielded patch panels consist of a metal panel and molded snap-in faceplates. Removable faceplates on select
panels allow front access to installed modules.
Available features:
• Label pockets for easy identication; designs without a label pocket accommodate optional adhesive labeling
• Standard and high density
• Flush mount and front access
• Flat, angled, and recessed designs
Shielded Patch Panels
Shielded patch panels are recommended for high RFI/EMI environments, where interference is a risk. Panduit’s
shielded offering includes integrated shielding which allows seamless integration with the Panduit® Structured Ground™
Grounding System.
Available features:
• Stainless steel construction (48-port High Density includes a molded faceplate)
• Dedicated areas for port identication which accept adhesive labels
• Accept Mini-Com® Shielded Jack Modules
• Standard and High Density
• Flat and angled designs
• Select models include built-in strain relief bar
2
Representative offering only, visit www.panduit.com for complete listing of products.
Style
Flat
Flat panels require horizontal cable managers to help organize and route cables into vertical managers. Extended strain
relief bars are recommended to allow proper cable support.
Angled
Angled panels enable higher density by allowing cables to ow to each side of the rack, thus minimizing the need for
horizontal cable managers and allowing patch cords to be routed directly into vertical cable managers. Straight strain
relief bars are recommended, as closer mounting to the panel eliminates sagging and provides improved cable support.
High-Density Patch Panels
High-density patch panels are an ideal solution for installations with space constraints, are available in at and angled
designs, with 48 ports in one rack space and 72 ports in two rack spaces. The angled design increases rack density,
managing high-density applications in one-fourth the area needed for conventional cable management systems.
(High capacity vertical managers are recommended.)
Strain Relief Bars
Strain relief bars (SRB) are used to support and manage cables in
telecommunication rooms. Panduit’s extensive selection offers the exibility to t
in a variety of applications, and ranges from a simple straight bar to one with
distinctive features such as integrated adjustable clips.
In single rail cabinets or racks, the strain relief bar with direct patch panel mount and
quick release bracket is recommended; it attaches directly to most Panduit patch
panels providing integrated support.
DISCLAIMER: The information contained herein is intended as a guide for use by persons having technical skill. Buyer shall determine the suitability of the Panduit
product for his intended use and Buyer assumes all risk and liability whatsoever in connection therewith.
visit www.panduit.com
3
Unshielded
Front Access
• Recommended for installations where access to the back of the rack is limited
• Label feature available, includes label and cover
CPP24WBLY
CPPL24WBLY
1/2"
Front removable faceplate extends ½" from the rack,
providing front access to the connections
Easy quick release tab
CPP48WBLY
CPPL48WBLY
CPPLA24WBLY
CPPLA48WBLY
Label and label cover
CPPL24WRBLY
Part Number Style Ports RU
CPP24WBLY
CPP48WBLY 48 2 —
CPPL24WBLY 24 1
CPPL48WBLY 48 2
CPPLA24WBLY
CPPLA48WBLY 48 2
CPPL24WRBLY Recessed 24 1 —
4
Representative offering only, visit www.panduit.com for complete listing of products.
Flat
Angled
24 1
24 1
Recommended
SRB
Extended
Straight
Replacement
Faceplate
CFFP4BL
CFFPL4BL C4PPLK Pocket
Replacement
Label Label
—
Adhesive A
Label (see
page 19)
A, B
Unshielded
Ultimate ID® Patch Panels
• Recommended for installations that follow common labeling standard or where multiple labeling areas are needed
• Meet TIA-606-B labeling standards with ease
Single or dual label pockets
with clear snap-in cover
(labels sold separately)
UICMPP24BLY
UICMPP48BLY
UICMPPA24BLY
Extends 1/8"
from the rack
UICMPPT24BLY
UICMPPT48BLY
UICMPPA48BLY
UICMPPTA24BLY
UICMPPTA48BLY
UICPPL4BL
Part Number Style Ports RU
UICMPP24BLY
UICMPP48BLY 48 2
UICMPPT24BLY 24 1 UICPP2L4BL
UICMPPT48BLY 48 2
UICMPPA24BLY
UICMPPA48BLY 48 2
UICMPPTA24BLY 24 1 UICPP2L4BL
UICMPPTA48BLY 48 2
Flat
Angled
24 1
24 1
Recommended
SRB
Extended
Straight
UICPP2L4BL
Replacement
Faceplate
UICPPL4BL
UICPP2L4BL
UICPPL4BL
UICPP2L4BL
Replacement
Cover Label
UILC4CL-X Pocket E, H
Label (see
page 19)
visit www.panduit.com
5
Unshielded
Flush Mount
• Mount ush with the rack to match other product or equipment installed
• Optional vertical number sequence simplies installation by mimicking common switch-port numbering
• Pre-printed numbers above each port
• White write-on areas for port or panel identication
• Select part numbers available in standard White color option on page 20
Pre-printed numbers for easy identication
Write on areas for custom adhesive labels
CPP24FMWBLY
CPP48FMWBLY
Part Number Style Ports RU
CPP24FMWBLY
CPP48FMWBLY
CPP48FMVNSWBLY
CPPA24FMWBLY
CPPA48FMWBLY 48 2
Flat
Angled
24 1
48 2
24 1
Flush mount design allows panel to
align with other rack-mountable products
CPPA24FMWBLY
CPPA48FMWBLY
Recommended
SRB Label
Extended
Straight
Label (see
page 19)
Adhesive A
Representative offering only, visit www.panduit.com for complete listing of products.
6
Unshielded
6-Port Conguration
• Modules arranged in groups of six to match the layout of select switches
• Faceplate style (M6) includes label pocket with preprinted labels and cover
• Flush mount style (FM6) mounts ush with the rack to match other product or equipment installed
Faceplate Style
CPPL24M6BLY
CPPL48M6BLY
Extends 1/8" from the rack Pre-printed
labels included
6-port conguration
Part Number Style Ports RU
CPPL24M6BLY Flat 24 1
CPPL48M6BLY Flat 48 2
Flush Mount Style
CPP48FM6BL
CPP48FM6VNSBL
Recommended
SRB
Extended CFPLM6BLY
Replacement
Faceplate
Vertical number
sequence
mimics common
switch port
numbering
Replacement
Label Label
C6PPLK1-24
C6PPLK1-24
C6PPLK25-48
Pocket C
Write-on area for custom
adhesive labeling
Label (see
page 19)
CPPA48FM6BL
Part Number Style Ports RU
CPP48FM6BL
CPP48FM6VNSBL
CPPA48FM6BL
CPPA48FM6VNSBL
Flat
48 2
Angled Straight
Recommended
SRB Label
Extended
Labels
(page 19)
Adhesive G
visit www.panduit.com
7
Unshielded
High Density
• Recommended for installations with limited real estate
• Allows up to 48 unshielded connections per rack unit
• Select part numbers available in standard White color option on page 20
Standard number
sequence (no labeling)
Enhanced label area
accepts custom
adhesive labeling
Vertical number
sequence mimics
common switch
port numbering
(no labeling)
CPP48HDWBLY
Part Number Style Ports RU
CPP48HDWBLY
CPP48HDEWBL Adhesive
CPP48HDVNSWBL — —
CPPA48HDWBLY
CPPA48HDEWBL Adhesive E
CPPA48HDVNSWBL — —
Flat
48 1
Angled SRBM19BLY
CPP48HDEWBL
Recommended
SRB Label
Extended
Label (see
page 19)
—
— —
—
CPP48HDVNSWBL
E
8
Representative offering only, visit www.panduit.com for complete listing of products.
Unshielded
High Density
• Recommended for installations with limited real estate; allows up to 72 connections in 2 rack units
Faceplate Design
• Faceplate can be removed from the front of the panel, allowing easy access to the connections
• Recommended for installations with space limitation that need labeling
• Includes label pocket with labels and label covers
Extends 1/8"
from the rack
Preprinted
labels included
CPPL72WBLY
CPPLA72WBLY
Flush Mount Design
Flush mount
design allows
panel to blend with
equipment and other
panels on the rack
Preprinted numbers
Accepts adhesive
labels
Part Number Style Ports RU
Flush Mount Design
CPP72FMWBLY Flat
CPPA72FMWBLY Angled SRBM19BLY
Faceplate Design
CPPL72WBLY Flat
CPPLA72WBLY Angled SRBM19BLY
72 2
72 2
Recommended
SRB
Extended
Extended
CPP72FMWBLY
CPPA72FMWBLY
Replacement
Label Label
NA Adhesive E
C72PPLK Pocket D
Label (see
page 19)
visit www.panduit.com
9
Unshielded
32 Port
• Recommended for installations in need of a semi-high-density panel in 1 RU
Arranged in groups of 8
CPP32WBLY
Part Number Style Ports RU
CPP32WBLY Flat 32 1
Recommended
SRB Label
Extended
Adhesive
Label (see
page 19)
E
Wall Mount
• Recommended for wall mount applications with limited space, when few ports are required
• Accepts custom adhesive labels
• Front access for easier access to connections
Extends 1/8"
from the rack
Jacks mount in
90° orientation
CPP12WBL (WB89D bracket not included)
Built-in mounting frame
CWPP12WBL
Part Number Style Ports RU
CPP12WBL
CWPP12WBL
89D
Wall Mount
12
—
—
3"
WB89D
Replacement
Faceplate Label
CFFP4BL Adhesive A
Label (see
89D bracket for use
with CPP12WBL
page 19
10
Representative offering only, visit www.panduit.com for complete listing of products.
Shielded
Standard Density
• Recommended for environments with potential RFI/EMI interference
• Shielded jack module removal tool included
CP16BLY
All stainless steel construction
allows shielded jacks to bond
directly to panels
CP24BLY
CP48BLY
CPA24BLY
Built in
grounding
lug bonds
panel to rack
Write-on areas
accept custom
adhesive
labeling
CPA48BLY
Part Number Style Ports RU
CP16BLY
CP24BLY 24
CP48BLY 48 2
CPA24BLY
CPA48BLY 48 2
Flat
Angled
16
24 1
Recommended
SRB Label
1
Extended
Adhesive
Straight
Label (see
page 19)
F
A
visit www.panduit.com
11
Shielded
Standard Density with Integral Support
• Recommended for environments with potential RFI/EMI interference
• Shielded jack module removal tool included
Integral
support bar helps
organize cables
(cable ties included)
CP16WSBLY
Write-on areas
accept custom
adhesive
labeling
Stainless steel
construction allows
shielded jacks to
bond directly to
the panel
CP24WSBLY
Built-in grounding
lug helps bond
panel to rack
CP48WSBLY
Part Number Style Ports RU Label
CP16WSBLY
CP24WSBLY 24
CP48WSBLY 48 2
Representative offering only, visit www.panduit.com for complete listing of products.
12
Flat
16
1
Adhesive
Label (see
page 19)
F
A
Shielded
High Density
• Recommended for installations with limited real estate and potential RFI/EMI interference
• 48 ports in 1 RU
Preprinted numbers
for easy port identication;
accepts custom adhesive labeling
Stainless steel
construction with metal
bonding strip properly
bonds shielded jack modules
CP48HDBL
CPA48HDBL
Part Number Style Ports RU
CP48HDBL Flat
CPA48HDBL Angled
*Includes trilobular screws to properly bond the panel to the rack
48 1
Recommended
SRB Label
Extended
Straight
Label (see
page 19)
Adhesive E
visit www.panduit.com
13
Shielded
High Density
• Recommended for installations with limited real estate and potential RFI/EMI interference
• 72 ports in 2 RU
• Shielded jack module removal tool included
Stainless steel
construction
properly bonds
shielded jack
Built-in
grounding
lug helps
bond panel to
the rack
Write-on areas accept
custom adhesive labeling
CP72BLY
CPA72BLY
Part Number Style Ports RU
CP72BLY Flat
CPA72BLY Angled
72 2
Recommended
SRB Label
Extended
Straight
Label (see
page 19)
Adhesive E
14
Representative offering only, visit www.panduit.com for complete listing of products.
QuickNet™ Patch Panels
• Designed to work with Panduit’s preterminated Copper and Fiber systems
• High density available for areas with limited real estate
• For shielded or unshielded applications
• Select part numbers available in standard White color option on page 21
QPP24BL
QSP24BL^
QPP48HDBL
QPP48HDVNSBL**
QSP48HDBL^
QAPP24BL
QASP24BL^
QAPP48HDBL
QAPP48HDVNSBL**
QASP48HDBL^
Part Number Style Ports RU
QPP24BL
QSP24BL^ Adhesive/
Flat
QPP48HDBL
QPP48HDVNSBL — —
QSP48HDBL^ — —
QAPP24BL
QASP24BL^ Adhesive/
Angled
QAPP48HDBL
QAPP48HDVNSBL — —
QASP48HDBL^ — —
^Shielded
24
48
1
24
48
Recommended
SRB Label
Extended
Straight
**Vertical numbering sequence
Label (see
page 19)
Adhesive/
QPPLC24
QPPLC24
— —
Adhesive/
QPPLC24
QPPLC24
— —
G
G
visit www.panduit.com
15
Patch Panel Kits
• One easy-to-order part number with all necessary components
• Select kits available in at or angled style, in multiple
performance levels
Unshielded
Supplied with black Mini-Com® Giga-TX™ Jack Modules
Category 6A
CJ6X88TGBL
Category 6
CJ688TGBL
Category 5e
CJ5E88TGBL
Category 6
CJS688TGY
Part Number Category Ports Patch Panel Style RU Labeling
CPPKL6ATG24WBL
CPPKL6ATG48WBL 48 CPPL24WBLY 2 A, B
CPPKLA6ATG24WBL 24 CPPLA24WBLY
CPPKLA6ATG48WBL 48 CPPLA24WBLY 2 A, B
CPPK6G24WBL
CPPKL6G24WBL CPPL24WBLY
UICMPPK6G24BL UICMPP24BLY E, H
CPPKA6G24WBL CPPA24WBL*
CPPKLA6G24WBL CPPLA24WBLY
UICMPPKA6G24BL UICMPPA24BLY E, H
CPPKL6G48WBL
CPPKL5EG24WBL
CPPKL5EG48WBL
* This patch panel only available in this kit
6A
6
5e
24 CPPL24WBLY
CPP24WBLY
24
48
24
48
CPPL24WBLY
CPPL24WBLY
CPPL24WBLY 2 A, B
Flat
Angled
Flat
Angled
Flat
Flat
1
1 A, B
1
2 A, B
1
Pocket
Adhesive A
Pocket
Adhesive A
Pocket
Pocket
Label (see
page 19)
Shielded
Supplied with Mini-Com® Giga-TX™ Shielded Jack Modules and strain relief bars.
Part Number Category Ports Patch Panel
CP24WSK6TGLGY
CP24WSBBK6TGBL CP24BLY SRBBRCT-KIT
^ The color of this patch panel is light gray. All other panels are black.
6 24
CP24WSLGY^ Integrated
Included
SRB Style RU Labeling
Flat 1 Adhesive A
Label (see
page 19)
A, B
A, B
A, B
A, B
Coupler panels
Supplied with preinstalled couplers
Part Number Category Ports Patch Panel Style RU Labeling
CP246X88BL 6A
Category 6A
CC6X88BL
Category 6
CC688BL
Category 5e
CC5E88BL
16
Representative offering only, visit www.panduit.com for complete listing of products.
CP245E88BLY 5e CPP24WBLY
CPP24WBLY
24
Label (see
page 19)
Flat 1 Adhesive ACP24688BL 6 CPP24WBLY
Accessories
SRBS19BL-XY
SRBWCY
Strain Relief Bars
Straight
SRBS19BL-XY Straight strain relief bar. Package of 10.
SRBWCY Straight strain relief bar with clips
SRBM19BLY
SRBCT
SRB19BLY
SRB19D5BL
SRB19D7BL
SRBM19BLY Straight strain relief bar with Tak-Ty
Loop Cable Ties
SRBCT Straight strain relief bar with cable ties
®
Hook &
Extended
SRB19BLY Extended strain relief bar — 2.8"
SRB19D5BL Extended strain relief bar — 4.5"
SRB19D7BL Extended strain relief bar — 7.6"
SRB19MDBL Extended multi-depth strain relief bar — 7"
SRB19MDBL
SRBPBL
SRBPPQBRKT
SRBPBL Extended pivoting strain relief bar
SRBPPQBRKT Direct mount PP strain relief bar
visit www.panduit.com
17
Accessories
SRBBRKT
Strain Relief Bars
Quick Release Bracket Kits
SRBBRKT Quick release brackets
SRBBRCT-KIT
SRBBRM-KIT
SRBBRWC-KIT
WMBZ
SRBBRCT-KIT Quick release bracket + SRB with cable ties
(SRBBRKT + SRBCT)
SRBBRM-KIT Quick release bracket + SRB with Tak-Ty® Cable
Ties
(SRBBRKT + SRBM19BLY)
SRBBRWC-KIT Quick release bracket + SRB with clips
(SRBBRKT + SRBWCY)
Front Manager
WMBZ Strain relief bar with bend radius clips, front
mountable zero RU
Angled Covers
CPATCBL Transitional cover
CPATCBL
CPAF1BLY Blank angled cover — 1 RU
CPAF1BL
CPAF2BLY Blank angled cover — 2 RU
CPAF2BL
18
Representative offering only, visit www.panduit.com for complete listing of products.
Accessories (continued)
Flat Covers
DPFP1 Blank at cover — 1 RU
DPFP1
DPFP2 Blank at cover — 2 RU
DPFP2
DPFP4 Blank at cover — 4 RU
DPFP4
DPFP8
FLBSIM-Y
TLBP1S-V, TLBP1R-V
TLBP2S-V, TLBP2R-V
DPFP8 Blank at cover — 8 RU
FLBSIM-Y Full length blanking shade 4-45 RU
Tool-Less Blanking Panels
TLBP1S-V For 3/8" cage nut holes — 1 RU
TLBP2S-V For 3/8" cage nut holes — 2 RU
TLBP1R-V For tapped rails — 1 RU
TLBP2R-V For tapped rails — 2 RU
PEB1
PEB2
Extender Brackets
PEB1 Converts 19" panels to 23" panels — 1 RU
PEB2 Converts 19" panels to 23" panels — 2 RU
Mounting Screws
Standard
Imperial size #12-24 x 0.5" round head S1224-C RGTBSG-C RGTBS-C
Metric size #M6-1.0mm x 0.15mm SCREWM6-C RGTBSM6G-C RGTBSM6-C
M6 screw with cage nut CNWSM6-C — —
Bonding
Green
visit www.panduit.com
Bonding
Black
19
Standard White Products
Patch Panels
CPP24FMWWH
CPP48FMWWH
CPPA24FMWWH
CPPA48FMWWH
Part Number Style Ports RU
CPP24FMWWH
24 1
CPP48FMWWH
CPPA24FMWWH
CPPA48FMWWH
Flat
48 2
24 1
Angled
48 2
Recommended
SRB's Label Type
Extended
Straight
Label
Options
Adhesive A
High Density Patch Panels
Part Number Style Ports RU
CPP48HDWWH
CPP48HDWWH
CPPA48HDWWH
CPPA48HDWWH
Recommended
SRB's Label Type
Flat
48 1
Angled Straight
Extended
Label
Options
— —
20
Representative offering only, visit www.panduit.com for complete listing of products.
Standard White Products
Quick-Net™ Patch Panels
QPP24WH
QSP24WH
QPP48HDWH
QPP48HDVNSWH
QSP48HDWH
Part Number Style Ports RU
QPP24WH
QSP24WH^
QPP48HDWH
Flat
QPP48HDVNSWH
QSP48HDWH^
QAPP24WH
24
48
48
48
Recommended
1
SRB's Label Type
Adhesive/
QPPLC24
Extended
— —
Label
Options
G
QAPP24WH
QASP24WH
QAPP48HDWH
QAPP48HDVNSWH
QASP48HDWH
QASP24WH^
QAPP48HDWH
QAPP48HDVNSWH
QASP48HDWH^
^Shielded
Angled
24
Straight
48 — —
Adhesive/
QPPLC24
G
visit www.panduit.com
21
Standard White Products
Accessories
CPATCWH Transitional Cover
CPATCWH
CPAF1WH Blank angled cover - 1 RU
CPAF1WH
CPAF2WH Blank angled cover - 2 RU
CPAF2WH
DPFP1WH
DPFP2WH
DPFP1WH Blank at cover - 1 RU)
DPFP2WH Blank at cover - 2 RU
Labeling
Labeling Options
Laser/Ink LS8E
A C252X030FJJ C252X030FJC
B C261X035Y1J C261X035Y1C
C C390X030Y1J C390X030Y1C
D C282X030Y1J C282X030Y1C
E — T024X000VPC-BK
F C061X030FJJ C061X030FJC
G C379X030FJJ C379X030FJC
H UILJ4 UILS8BW
Permanent labeling is critical for all network cabling
system installations. Panduit labeling solutions provide
clean and efcient labeling of the network physical
infrastructure in accordance with TIA/EIA-606-B.
denotes Adhesive labels
Part Number Description
TDP43ME
300 dpi printer; includes printer, Panduit® Easy-Mark™
Labeling Software, RMEH4BL hybrid black ribbon, AC
power adapter with US power cord, USB cable, user
manual, quick start card, and driver disk.
TDP43ME
22
Representative offering only, visit www.panduit.com for complete listing of products.
Labeling (continued)
LS8EQ
LS8E
Part Number Description
LS8EQ
Includes LS8EQ printer with QWERTY keyboard,
one cassette of S100X150VAC self-laminating labels, six
AA alkaline batters and quick reference card.
Part Number Description
LS8E
Includes LS8E printer, one cassette of S100X150VAC
self-laminating labels, six AA alkaline batteries and quick
reference card.
Unshielded
Ports Part Number
CPP24WBLY A
CPPL24WBLY A, B
CPPL24M6BLY C
CPPL24WRBLY A, B
CPP24FMWBLY A
24
48
MISC
CPPA24FMWBLY A
CPPLA24WBLY A, B
UICMPP24BLY E, H
UICMPPA24BLY E, H
UICMPPT24BLY E, H
UICMPPTA2BLY E, H
CPP48WBLY A
CPPL48WBLY A, B
CPPL48M6BLY C
CPP48FMWBLY A
CPPA48FMWBLY A
CPPLA48WBLY A, B
CPP48HDWBLY –
CPPA48HDWBLY –
CPP48HDEWBLY E
CPPA48HDEWBLY E
CPP48FM6BL G
CPPA48FM6BL G
CPP48FM6VNSBL G
CPPA48FM6VNSBL G
UICMPP48BLY E, H
UICMPPA48BLY E, H
UICMPPT48BLY E, H
UICMPPTA48BLY E, H
CPPL72WBLY D
CPPLA72WBLY D
CPP32WBLY E
CWPP12WBL A
CPP12WBL A
CPP72FMWBLY E
CPPA72FMWBLY E
Original
Recommendation
Ports Part Number
16
24
48
72
48HD
CP16BLY
CP16WSBLY
CP24BLY
CP24WSBLY
CPA24BLY
CP48BLY
CP48WSBLY
CPA48BLY
CP72BLY
CPA72BLY
CP48HDBL
CPA48HDBL
Standard White
Ports Part Number
CPP24FMWWH
CPPA24FMWWH
24
48
QPP24WH
QSP24WH
QAPP24WH
QASP24WH^
CPP48FMWWH
CPPA48FMWWH
Shielded
Recommended
Labels
F
A
E
Recommended
Labels
A
G
A
visit www.panduit.com
23
Panduit Corp.
World Headquarters
Tinley Park, IL 60487
cs@panduit.com
US and Canada: 800.777.3300
Europe, Middle East, and Africa:
44.20.8601.7200
Latin America: 52.33.3777.6000
Asia Pacific: 65.6305.7575
www.panduit.com
©2018 Panduit Corp. ALL RIGHTS RESERVED COSG18--SA-ENG replaces COSG07 8/2018
Loading...
